Optoma DS317 User manual

DS317 | Multimedia Projector
All Specifications are subject to change without notice. ©2009 Optoma Technology, Inc. DLP®and the DLP logo are
registered trademarks of Texas Instraments. All other names mentioned herein are property of their respective owners.
Data-DS317-001-0709
NO FILTER
REQUIRED
Optional Accessories
Lamp:
Remote:
Mount:
VGA Cable (1.8m):
Power Cord (1m):
Power Cord (11m):
S-Video Cable (1.8m):
Composite Cable (1.8m):
VGA to Component Cable (1.8m):
VGA to Component Adapter:
Carrying Case:
84" Matte White 4:3 Manual Pull-Down Screen:
BL-FP180D
BR-5027L
BM-5001U
BC-VGVGXX02
BC-PUPIXY01
BC-PUPIXY11
BC-SVSVXX02
BC-COCOXX02
BC-VGCRXX02
BC-VGCRXY00
BK-4023
DS-3084PM
Menu
Source & Left
Direction Key
Power
LED
Lamp
LED
Temp
LED
Enter
Keystone- &
Down Direction Key
Keystone+ & Up
Direction Key
Menu AV-Mute Power
Control Panel
Re-Sync
Projection Distance/Image Size
Projection Distance
(Feet)
6
8
10
12
14
16
18
Diagonal Image
(Inches)
45.0
60.0
75.0
90.0
105.0
120.0
135.0
www.OptomaUSA.com
Display Technology:
Resolution:
Maximum Resolution:
Brightness (Typical):
Contrast Ratio:
Lamp Type:
Lamp Life (STD/Bright):
Throw Ratio:
Image Size (Diagonal):
Projection Distance:
Noise Level (STD/Bright):
Remote Control:
Computer Compatibility:
Video Compatibility:
Aspect Ratio:
Projection Lens:
Offset:
User Controls:
Audio:
Keystone Correction:
Vertical Refresh Rate:
Horizontal Scan Rate:
Power Supply:
Power Consumption:
Weight:
Dimensions (W x H x D):
Operating Temperature:
Displayable Colors:
Projection Method:
Uniformity:
Security:
I/O Connectors:
Standard Accessories:
Optional Accessories:
Warranty:
UPC:
Single 0.55” DMD DLP®Technology by Texas Instruments
Native SVGA (800 x 600)
WUXGA (1920 x 1200)
2600 ANSI Lumens
3000:1 (Full On/Full Off)
180W P-VIP
Estimated at 4000/3000 Hours
2.0:1 (Distance/Width)
25” to 300” (0.65 to 7.62m)
3.28’ to 40.02’ (1.0 to 12.2 m)
30dB/32dB
Fully Featured IR Remote with Laser Pointer and Mouse
WUXGA, HD, WXGA+, UXGA, WXGA, SXGA+, SXGA, XGA, SVGA, VGA,
VESA, PC and Macintosh Compatible
NTSC, PAL, SECAM, SDTV (480i), EDTV (480p), HDTV (720p, 1080i/p)
4:3 Native, 16:9 and 16:10 Compatible
F = 2.55, f = 22.2mm
114%
Complete On-Screen Menu Adjustments in 22 Languages
2-Watt Speaker, Variable Audio-Out
± 30º Vertical
43 to 87 Hz
15 kHz, 30 to 91.4 kHz
AC Input 100 - 240V, 50-60 Hz, Auto-Switching
230 Watts (Bright), 210 Watts (STD), < 1 Watts (Standby)
5.5 lbs (2.5 kg)
11.0” x 3.2” x 8.1” (280 x 80 x 205 mm)
41-104º F (5-40º C) (85% Humidity), Adjustable Fan Speed for High Altitude
Application
1.07 Billion
Front, Rear, Table Top and Ceiling Mount
80%
One Kensington®Lock Port, Keypad Lock
VGA-In, S-Video, Composite Video, Stereo RCA Audio-In, Stereo Audio-Out,
RS-232 and Mini-USB
AC Power Cord, VGA to VGA Cable, Remote Control, Batteries for Remote,
Lens Cap, CD-ROM User‘s Manual, Quick Start Guide and Warranty Card
Ceiling Mount, VGA to Component Cable, S-Video Cable, Composite Video
Cable and Panoview™ Series Screens
1 Year Limted Parts and Labor, 90 Days on Lamp
796435 41 152 7
Specifications
