Optoma ZH506e User manual

User manual
DLP®Projector

English
2
TABLE OF CONTENTS
SAFETY............................................................................................... 4
Important Safety Instruction....................................................................................................... 4
Laser Radiation Safety Information ........................................................................................... 5
Laser Notice .............................................................................................................................. 5
Copyright ................................................................................................................................... 6
Disclaimer.................................................................................................................................. 6
Trademark Recognition ............................................................................................................. 6
FCC ........................................................................................................................................... 6
Declaration of Conformity for EU countries ............................................................................... 7
WEEE........................................................................................................................................ 7
INTRODUCTION ................................................................................ 8
Package Overview..................................................................................................................... 8
Standard accessories................................................................................................................ 8
Optional accessories ................................................................................................................. 8
Product Overview ...................................................................................................................... 9
Connections.............................................................................................................................. 10
Keypad ..................................................................................................................................... 12
Remote control ......................................................................................................................... 13
SETUP AND INSTALLATION........................................................... 14
Installing the projector .............................................................................................................. 14
Connecting sources to the projector......................................................................................... 17
Adjusting the projector image................................................................................................... 20
Remote setup ........................................................................................................................... 21
USING THE PROJECTOR ............................................................... 23
Powering on / off the projector.................................................................................................. 23
Selecting an input source ......................................................................................................... 24
Menu navigation and features .................................................................................................. 25
OSD Menu tree......................................................................................................................... 26
Display image settings menu.................................................................................................... 35
Display 3D menu ...................................................................................................................... 38
Display aspect ratio menu ........................................................................................................ 39
Display edge mask menu ......................................................................................................... 44
Display zoom menu.................................................................................................................. 44
Display image shift menu ......................................................................................................... 44
Display geometric correction menu .......................................................................................... 44
Audio mute menu ..................................................................................................................... 45
Audio volume menu.................................................................................................................. 45
Audio audio input menu............................................................................................................ 45
Audio audio / mic input function menu...................................................................................... 45
Setup projection menu.............................................................................................................. 46

English 3
Setup screen type menu........................................................................................................... 46
Setup power settings menu...................................................................................................... 46
Setup security menu................................................................................................................. 47
Setup HDMI link settings menu ................................................................................................ 47
Setup test pattern menu ........................................................................................................... 47
Setup remote settings menu..................................................................................................... 48
Setup projector ID menu........................................................................................................... 48
Setup 12V trigger menu............................................................................................................ 48
Setup options menu.................................................................................................................. 48
Setup reset OSD menu ............................................................................................................ 49
Network LAN menu .................................................................................................................. 50
Network control menu............................................................................................................... 51
Setup network control settings menu ....................................................................................... 52
Info menu.................................................................................................................................. 57
MAINTENANCE................................................................................. 58
Installing and cleaning the dust lter ........................................................................................ 58
ADDITIONAL INFORMATION.......................................................... 59
Compatible resolutions............................................................................................................. 59
Image size and projection distance .......................................................................................... 62
Projector dimensions and ceiling mount installation................................................................. 65
IR remote codes ....................................................................................................................... 66
Troubleshooting ........................................................................................................................ 68
Warning indicators.................................................................................................................... 70
Specications ........................................................................................................................... 71
Optoma global ofces............................................................................................................... 72

English
4
SAFETY
The lightning ash with arrow head within an equilateral triangle is
intended to alert the user to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may be of su󰀩cient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
Please follow all warnings, precautions and maintenance as recommended in this user’s guide.
Important Safety Instruction
• Do not stare into the beam, RG2.
As with any bright source, do not stare into the direct beam, RG2 IEC 62471-5:2015.
• Do not block any ventilation openings. To ensure reliable operation of the projector and to protect from
over heating, it is recommended to install the projector in a location that does not block ventilation.
As an example, do not place the projector on a crowded co󰀨ee table, sofa, bed, etc. Do not put the
projector in an enclosure such as a book case or a cabinet that restricts air ow.
• To reduce the risk of re and/or electric shock, do not expose the projector to rain or moisture. Do not
install near heat sources such as radiators, heaters, stoves or any other apparatus such as ampliers
that emits heat.
• Do not let objects or liquids enter the projector. They may touch dangerous voltage points and short
out parts that could result in re or electric shock.
• Do not use under the following conditions:
± In extremely hot, cold or humid environments.
(i) Ensure that the ambient room temperature is within 5°C ~ 40°C
(ii) Relative humidity is 10% ~ 85%
± In areas susceptible to excessive dust and dirt.
± Near any appliance generating a strong magnetic eld.
± In direct sunlight.
• Do not use the unit if it has been physically damaged or abused. Physical damage/abuse would be
(but not limited to):
± Unit has been dropped.
± Power supply cord or plug has been damaged.
± Liquid has been spilled on to the projector.
± Projector has been exposed to rain or moisture.
± Something has fallen in the projector or something is loose inside.
• Do not place the projector on an unstable surface. The projector may fall over resulting in injury or the
projector may become damaged.
• Do not block the light coming out of the projector lens when in operation. The light will heat the object
and may melt, cause burns or start a re.
• Please do not open or disassemble the projector as this may cause electric shock.
• Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous
voltages or other hazards. Please call Optoma before you send the unit for repair.
• See projector enclosure for safety related markings.

English 5
• The unit should only be repaired by authorized service personnel.
• Only use attachments/accessories specied by the manufacturer.
• Do not look into straight into the projector lens during operation. The bright light may harm your eyes.
• This projector will detect the life of the light source itself.
• When switching the projector o󰀨, please ensure the cooling cycle has been completed before
disconnecting power. Allow 90 seconds for the projector to cool down.
• Turn o󰀨 and unplug the power plug from the AC outlet before cleaning the product.
• Use a soft dry cloth with mild detergent to clean the display housing. Do not use abrasive cleaners,
waxes or solvents to clean the unit.
• Disconnect the power plug from AC outlet if the product is not being used for a long period of time.
• Do not setup the projector in places where it might be subjected to vibration or shock.
• Do not touch the lens with bare hands.
• Remove battery/batteries from remote control before storage. If the battery/batteries are left in the
remote for long periods, they may leak.
• Do not use or store the projector in places where smoke from oil or cigarettes may be present, as it
can adversely a󰀨ect the quality of the projector performance.
• Please follow the correct projector orientation installation as non standard installation may a󰀨ect the
projector performance.
• Use a power strip and or surge protector. As power outages and brown-outs can KILL devices.
Laser Radiation Safety Information
• This product is classied as CLASS 1 LASER PRODUCT - RISK GROUP 2 of IEC60825-1 : 2014 and
also complies with 21 CFR 1040.10 and 1040.11 as a Risk Group 2, LIP (Laser Illuminated Projector)
as dened in IEC 62471:2006 except for deviations pursuant to Laser Notice No. 50, dated June 24,
2007.
IEC 60825-1:2014, EN 60825 1 2014 A11 2021, EN 50689:2021 CLASS 1 CONSUMER-: + :
LASER PRODUCT RISK GROUP 2, Complies with 21 CFR 1040.10 and 1040.11 except for
conformance as a Risk Group 2 LIP as defined in IEC 62471-5:Ed.1.0. For more information
see Laser Notice No. 57, dated May 8, 2019.
IEC 60825-1:2014 1 RG2
IEC 60825-1:2014 1 RG2
Failure to comply with the following could result in death or serious injury.
• This projector has built-in Class 4 laser module. Disassembly or modication is very dangerous and
should never be attempted.
• Any operation or adjustment not specically instructed by the user’s guide creates the risk of
hazardous laser radiation exposure.
• Do not open or disassemble the projector as htis may cause damage by the exposure of laser
radiation.
• Do not stare into beam when the projector is on. The bright light may result in permanent eye damage.
• When turning on the projector, make sure no one within projection range is looking at the lens.
• Without following the control, adjustment or operation procedure may cause damage by the exposure
of laser radiation.
• Adequate instructions for assembly, operation, and maintenance, including clear warnings concerning
precautions to avoid possible exposure to laser.
Laser Notice
IEC 60825-1:2014: CLASS 1 LASER PRODUCT - RISK GROUP 2.
The product’s intended use as a consumer laser product and compliant with EN 50689:2021.
CLASS 1 CONSUMER LASER PRODUCT
EN 50689:2021

English
6
Copyright
This publication, including all photographs, illustrations and software, is protected under international copyright
laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced
without written consent of the author.
© Copyright 2018
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no representations
or warranties with respect to the contents hereof and specically disclaims any implied warranties of
merchantability or tness for any particular purpose. The manufacturer reserves the right to revise this publication
and to make changes from time to time in the content hereof without obligation of the manufacturer to notify any
person of such revision or changes.
Trademark Recognition
Kensington is a U.S. registered trademark of ACCO Brand Corporation with issued registrations and pending
applications in other countries throughout the world.
HDMI, the HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries.
DLP®, DLP Link and the DLP logo are registered trademarks of Texas Instruments and BrilliantColorTM is a
trademark of Texas Instruments.
MHL, Mobile High-Denition Link and the MHL Logo are trademarks or registered trademarks of MHL Licensing,
LLC.
All other product names used in this manual are the properties of their respective owners and are Acknowledged.
FCC
This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15
of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this device does cause
harmful interference to radio or television reception, which can be determined by turning the device o󰀨 and on is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the device and receiver.
• Connect the device into an outlet on a circuit di󰀨erent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/television technician for help.
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables to maintain compliance with FCC
regulations.
Caution
Changes or modications not expressly approved by the manufacturer could void the user's authority, which is
granted by the Federal Communications Commission, to operate this projector.

English 7
Operation Conditions
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference and
2. This device must accept any interference received, including interference that may cause undesired operation.
Notice: Canadian users
This Class B digital apparatus complies with Canadian ICES-003.
Remarque à l'intention des utilisateurs canadiens
Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada.
Declaration of Conformity for EU countries
• EMC Directive 2014/30/EU (including amendments)
• Low Voltage Directive 2014/35/EU
• RED 2014/53/EU (if product has RF function)
WEEE
Disposal instructions
Do not throw this electronic device into the trash when discarding. To minimize pollution and ensure
utmost protection of the global environment, please recycle it.

English
8
INTRODUCTION
Package Overview
Carefully unpack and verify that you have the items listed below under standard accessories. Some of the items
under optional accessories may not be available depending on the model, specication and your region of
purchase. Please check with your place of purchase. Some accessories may vary from region to region.
The warranty card is only supplied in some specic regions. Please consult your dealer for detailed information.
Standard accessories
Optional accessories
Note:
•Optional accessories vary depending on model, specication and region.
•*(3) Available only for USA and Asian regions.
Projector Remote control Power lead Documentation

Warranty Card*(1)

Basic User Manual

Paper UM*(2)
F3
On
Geometric
Mode
Correction PIP/PBP
Off
F1 F2
AV Mute
ENTER
Source
Volume D Zoom
Info.
VGA
1
S-Video
2
HDMI1
3
HDMI2
HDMI3
Format Freeze Remote
ID All
HDBaseT
4
Video
5
DVI
6
BNC
7
YPbPr
8
DisplayPort
9
3D
0
Re-Sync
Menu
F3
Note:
•The remote control is shipped with the battery.
•*(1) For European warranty Information, please visit www.optoma.com.
•*(2) Available only for Asian region.
Lens cap CD user manual*(3) Carry bag VGA cable

English 9
INTRODUCTION
Product Overview
2
1
3
4 5
6
8
9
8
812
1011
7
Note:
•Do not block projector intake and exhaust vents.
•When operating the projector in an enclosed space, allow at least 30 cm clearance around the intake
and exhaust vents.
No Item No Item
1. IR Receivers 7. Ventilation (outlet)
2. Keypad 8. Tilt-Adjustment Feet
3. Lens Shift Dial 9. Kensington™ Lock Port
4. Ventilation (inlet) 10. Input / Output
5. Zoom Lever 11. Power Socket
6. Focus Ring 12. Lens

English
10
INTRODUCTION
Connections
Type 1 (12 IO)
8
621 3 4 5
9
11121314 10
7
Type 2 (15 IO)
8
621 3 4 5
9
11121314 17 10
1615 7

English 11
INTRODUCTION
No Item Type 1 (12 IO) Type 2 (15 IO)
1. HDMI 2 Connector √ √
2. HDMI 1 / MHL Connector √ √
3. USB Power Out (5V 1.5A) Connector √ √
4. VGA In / VGA In 1 Connector √ √
5. Video Connector √ √
6. Audio In 1 / MIC In Connector √ √
7. 12V Out Connector √ √
8. KensingtonTM Lock Port √ √
9. Audio Out Connector √ √
10. Audio In 2 Connector √ √
11. VGA Out Connector √ √
12. RS232 Connector √ √
13. RJ-45 Connector √ √
14. Power Socket √ √
15. VGA In 2 Connector N/A √
16. S-Video Connector N/A √
17. HDBaseT Connector N/A √
Note: “√” means the item is supported, “N/A” means the item is not available.
Note:
•USB Type A supports mouse / service capability.
•Remote mouse requires special remote control.

English
12
INTRODUCTION
Keypad
10
21 3 5 6
9 78
4
No Item No Item
1. Lamp LED 6. Temp LED
2. Power and Power LED 7. Re-Sync
3. Menu 8. Four Directional Select Keys
4. Keystone Correction 9. Source
5. Enter 10. Information

English 13
INTRODUCTION
Remote control
F3
On
Geometric
Mode
Correction PIP/PBP
Off
F1 F2
AV Mute
ENTER
Source
Volume D Zoom
Info.
VGA
1
S-Video
2
HDMI1
3
HDMI2
HDMI3
Format Freeze Remote
ID All
HDBaseT
4
Video
5
DVI
6
BNC
7
YPbPr
8
DisplayPort
9
3D
0
Re-Sync
Menu
F3
10
1
2
3
4
5
6
8
7
9
11
34
33
32
31
12
13
15
14
16
19
2017 2118
27
26
29
30
28
25
24
23
22
No Item No Item
1. Power on 18. YPbPr (not supported)
2. Geometric Correction 19. Numeric keypad (0-9)
3. Function button (F1) (Assignable) 20. Display port (not supported)
4. Mode 21. 3D
5. Four directional select keys 22. DVI (not supported)
6. Information 23. HDMI3 (not supported)
7. Function button (F3) (Assignable) 24. HDMI1
8. Source 25. HDMI2
9. Menu 26. Remote ID / Remote all
10. Volume - / + 27. Digital Zoom - / +
11. Freeze 28. Re-sync
12. Format (Aspect Ratio) 29. Laser (not supported)
13. VGA 30. Enter
14. S-Video 31. AV Mute
15. HDBase-T 32. Function button (F2) (Assignable)
16. Video 33. PIP/PBP (not supported)
17. BNC (not supported) 34. Power o󰀨
Note: Some keys may have no function for models that do not support these features.

English
14
SETUP AND INSTALLATION
Installing the projector
Your projector is designed to be installed in one of four possible positions.
Your room layout or personal preference will dictate which installation location you select. Take into consideration
the size and position of your screen, the location of a suitable power outlet, as well as the location and distance
between the projector and the rest of your equipment.
Table mount front Ceiling mount front
Table mount rear Ceiling mount rear
Projector should be placed at on a surface and 90 degrees / perpendicular to the screen.
• How to determine projector location for a given screen size, please refer to distance table on pages
62-64.
• How to determine screen size for a given distance, please refer to distance table on pages 62-64.
Note: The further away the projector is placed from the screen the projected image size increases and vertical
offset also increases proportionally.
IMPORTANT!
Do not operate the projector in any orientation other that table top or ceiling mount. The projector should
be horizontal and not tilted either forwards/backwards or left/right. Any other orientation will invalidate the
warranty and may shorten the lifetime of the projector light source or the projector itself. For none standard
installation advise please contact Optoma.

English 15
SETUP AND INSTALLATION
Projector installation notice
• Place the projector in a horizontal position.
The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed
in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically,
and may lead to other unpredictable damages.
15°
-15°
• Allow at least 30 cm clearance around the exhaust vent.
Minimum 100mm
(3.94 inches) Minimum 300mm
(11.81 inches)
Minimum 300mm
(11.81 inches)
Minimum 100mm
(3.94 inches)
Minimum 100mm
(3.94 inches)
Minimum 100mm
(3.94 inches)
• Ensure that the intake vents do not recycle hot air from the exhaust vent.
• When operating the projector in an enclosed space, ensure that the surrounding air temperature within
the enclosure does not exceed operation temperature while the projector is running, and the air intake
and exhaust vents are unobstructed.
• All enclosures should pass a certied thermal evaluation to ensure that the projector does not recycle
exhaust air, as this may cause the device to shutdown even if the enclosure temperature is with the
acceptable operation temperature range.

English
16
SETUP AND INSTALLATION
Note: Projector brightness will be decreased to 70% lumen and fan full load

English 17
SETUP AND INSTALLATION
Connecting sources to the projector
Type 1 (12 IO)
12
3
4
56
7
8
9
11
12
1314
15
16
10

English
18
SETUP AND INSTALLATION
Type 2 (15 IO)
12
3
4
56
7
8
9
11
12
1314
15
16
17
18
10

English 19
SETUP AND INSTALLATION
No Item Type 1 (12 IO) Type 2 (15 IO)
1. HDMI Cable √ √
2. MHL Cable √ √
3. HDMI Dongle √ √
4. USB Power Cable √ √
5. VGA In Cable √ √
6. RCA Component Cable √ √
7. Video Cable √ √
8. Audio In Cable √ √
9. Audio In Cable √ √
10. 12V DC Jack √ √
11. Microphone Cable √ √
12. Audio Out Cable √ √
13. VGA Out Cable √ √
14. RS232 Cable √ √
15. RJ-45 Cable √ √
16. Power Cord √ √
17. S-Video Cable N/A √
18. RJ-45 Cable (Cat5 Cable) N/A √
Note: “√” means the item is supported, “N/A” means the item is not available.

English
20
SETUP AND INSTALLATION
Adjusting the projector image
Image height
The projector is equipped with elevator feet for adjusting the image height.
1. Locate the adjustable foot you wish to adjust on the underside of the projector.
2. Rotate the adjustable foot clockwise or counterclockwise to raise or lower the projector.
Tilt-Adjustment Feet
Tilt-Adjustment Ring
Zoom, lens shift, and focus
• To adjust the image size, turn the zoom lever clockwise or counterclockwise to increase or decrease
the projected image size.
• To adjust the image position, turn the lens shift dial clockwise or counterclockwise to adjust the
position of the projected image vertically.
• To adjust the focus, turn the focus ring clockwise or counterclockwise until the image is sharp and
legible.
Zoom Lever
Lens Shift Dial
Focus Ring
Note: The projector will focus at a distance of 1.3m to 9.4m.
