optris PI 160 User manual

optris®PI160, PI200, PI400, PI450
Thermal Imager
Operator’s manual

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
1
Optris GmbH
Ferdinand-Buisson-Str. 14
13127 Berlin
Germany
Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]
Internet: www.optris.com
CE - Conformity
The product complies with the following standards:
EMC: EN 61326-1:2006
(Basic requirements)
EN 61326-2-3:2006
Safety regulations: EN 61010-1:2001
Laser protection: EN 60825-1:2007
The product accomplishes the requirements of the EMC Directive 2004/108/EG and of the Low Voltage
Directive 2006/95/EG.
Note
Read the manual carefully before the initial start-up. The producer reserves the right to change the
herein described specifications in case of technical advance of the product.

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
2
Warranty
Each single product passes through a quality process. Nevertheless, if failures occur please contact the
customer service at once. The warranty period covers 24 months starting on the delivery date. After the
warranty is expired the manufacturer guarantees additional 6 months warranty for all repaired or substituted
product components. Warranty does not apply to damages, which result from misuse or neglect. The
warranty also expires if you open the product. The manufacturer is not liable for consequential damage. If a
failure occurs during the warranty period the product will be replaced, calibrated or repaired without further
charges. The freight costs will be paid by the sender. The manufacturer reserves the right to exchange
components of the product instead of repairing it. If the failure results from misuse or neglect the user has to
pay for the repair. In that case you may ask for a cost estimate beforehand.

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
3
Content
CE - Conformity.......................................................................................................................................................1
Warranty ..................................................................................................................................................................2
Content ....................................................................................................................................................................3
1. Welcome!........................................................................................................................................................4
2. Scope of Supply..............................................................................................................................................5
3. Maintenance....................................................................................................................................................6
4. Technical Datas ..............................................................................................................................................7
5. Optical Datas.................................................................................................................................................10
6. Mechanical Installation..................................................................................................................................12
7. Electrical Installation .....................................................................................................................................18
8. Initial start-up...............................................................................................................................................21
9. Software PIConnect......................................................................................................................................22
10. Basics of Infrared Thermometry....................................................................................................................27
Appendix A –Emissivity Table Metals...................................................................................................................34
Appendix B –Emissivity Table Non Metals...........................................................................................................35
Appendix C - Serial Communication (a brief overview).........................................................................................36
Appendix D –Interprocess Communication (IPC).................................................................................................37
Appendix E –Optris PI Connect Resource Translator..........................................................................................38
Appendix F –Process Interface ............................................................................................................................39

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
4
1. Welcome!
Thank you for choosing the optris PI thermal imager!
The optris PI calculates the surface temperature based on the emitted infrared
energy of objects [►Basics of Infrared Thermometry]. The two-dimensional
detector (FPA - focal plain array) allows a measurement of an area and will be
shown as thermal image using standardized palettes.
The radiometric processing of the picture data enables the user to do a
comfortable detailed analysis with the software PI Connect.
Please take care of the following notes:
Notes
The optris PI is a precise instrument and contains a sensitive infrared detector and a high-
quality lens. The alignment of the camera to intensive energy sources (high power laser or
reflections of such equipment, e.g.) can have effect on the accuracy of the measurement or
can cause an irreparable defect of the infrared detector.
The mounting should be made only via the mounting threads or tripod connection the
housing is providing.
Avoid static electricity, arc welders, and induction heaters. Keep away from very strong
EMF (electromagnetic fields).
Avoid abrupt changes of the ambient temperature.
In case of problems or questions which may arise when you use the infrared camera,
please contact our service department.

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
5
2. Scope of Supply
Standard version
optris PI160, PI200, PI400 or PI450 incl. 1 lens
USB cable (1 m1))
Table tripod
Process interface cable incl. terminal block (1 m)
Software package PI Connect
Operators manual
Aluminum case
optris PI200 only: focusing tool for VIS camera
Thermal Analysis Kit
optris PI160 or PI200
3 lenses (23°, 6° and 48°, incl. calibration certificate)
USB cable (1 m1) and 10 m)
Tripod (20 - 63 cm)
Process interface cable incl. terminal block (1 m)
Software package PI Connect
Operators manual
Aluminum case
optris PI200 only: focusing tool for VIS camera
1) The camera plug of USB cable (1 m) does not feature an IP67 protection class. For industrial applications there are cables with IP67
available starting at 5 m.

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
6
3. Maintenance
Lens cleaning
Blow off loose particles using clean compressed air. The lens surface can be cleaned with a soft, humid
tissue moistened with water or a water based glass cleaner.
Note
Never use cleaning compounds which contain solvents (neither for the lens nor for the housing).

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
7
4. Technical Datas
Factory Default Settings
The unit has the following presetting at time of delivery:
Temperature range -20...100 °C
Emissivity 1,000
Process interface (PIF) inactive
Interprocess Communication (IPC) inactive
Measurement function Rectangle measure area
General Specifications
Environmental rating IP65 (NEMA-4)
Ambient temperature 0...50 °C
Storage temperature -20...70 °C
Relative humidity 10...95 %, non condensing
Material (housing) aluminum, anodized
Dimensions 45 x 45 x 62 - 65 mm3(depending on lens)
46 x 56 x 86 - 90 mm3(depending on lens)
Weight (incl. lens) PI160: 195 g, PI200: 215 g, PI400 / PI450: 320 g
Cable length (USB 2.0) 1 m (Standard), 5 m, 10 m, 20 m1)
Vibration IEC 68-2-6: 3G, 11 –200Hz, any axis
Shock IEC 68-2-27: 50G, 11ms, any axis
1) Installation of 20 m cable in the ground is not allowed without protection by conduits, corrugated pipes, tubes or similar. If installed
outside the cable must be protected as well (see aforementioned arrangements).

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
8
Electrical Specifications
Power Supply 5 VDC (powered via USB 2.0 interface)
Current draw max. 500 mA
Output Process Interface (PIF out) 0-10 V (TObj, TInt, flag status or alarm status)
Input Process Interface (PIF in) 0-10 V (Emissivity, Ambient temperature, Reference temperature,
Flag control, triggered video or triggered snapshots)
Digital Input Process Interface Flag control, triggered video or triggered snapshots)
Digital interface USB 2.0 [► Appendix F: PIF]
Measurement Specifications
Temperature ranges -20...100 °C; 0...250 °C; 120...900 °C; option: 200…1500°C1)
Detector PI160 / PI200: UFPA, 160 x 120 pixels
PI400 / PI450: UFPA, 382 x 288 pixels
Spectral range 7.5...13 µm
Lenses (FOV) PI160 / PI2002): 23° x 17°; 6° x 5°; 48° x 37°; 80° x 60°
PI400 / PI450: 30° x 23°; 13° x 10°
System accuracy3) ±2 °C or ±2 %
1) The additional measurement range of 200…1500°C is not available for cameras optris PI400 / PI450 as well as for camera version
PI160 / PI200 featuring 80° HFOV optics
2) For ideal combination of IR and VIS image the lenses of optris PI200 featuring 23° and 48° HFOV are recommended
3) At ambient temperature 235 °C; whichever is greater

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
9
Temperature resolution (NETD) PI160 / PI200: 0.08 K with 23°; 0.3 K with 6°; 0.1 K with 48° and 80°
PI4001): 0.08 K with 30°; 0.1 K with 13°
PI4501): 0.04 K with 30°; 0.06 K with 13°
Frame rate PI160: 120 Hz
PI200: 128 Hz2)
PI400 / PI450: 80 Hz
Warm-up time 10 min
Emissivity 0.100…1.000 (adjustable via software)
Visual camera (PI200 only) 640 x 480 pixels, 32 Hz, 54° x 40° FOV2)
Software PI Connect
1) Value is valid at 40 Hz and 25°C room temperature
2) The following options can be set: Option 1 (IR with 96 Hz at 160 x 120 px; VIS with 32 Hz at 640 x 480 px);
Option 2 (IR with 128 Hz at 160 x 120 px; VIS with 32 Hz at 596 x 447 px)

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
10
5. Optical Datas
The variety of different lenses offers the possibility to precisely measure objects in different distances. We
offer lenses for close, standard distances and large distances. Different parameters are important if using
infrared cameras. They display the connection between the distance of the measured object and the size of
the pixel (please see tables at the end of this section).
With the help of BI-SPECTRAL technology at optris PI200, a visual image
(VIS) can be combined with a thermal image (IR). Both can be finally
captured time synchronously:
Note
Please make sure that the focus of thermal channel and visual channel (optris PI200 only) is
adjusted correctly. For focusing the thermal camera please turn the lens, for focusing the visual
camera please use the focusing tool supplied in the scope of delivery.
IR channel
VIS channel
Focusing tool for VIS camera

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
11

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
12
Measurement field of the thermal imager optris PI
representing the standard lens 23° x 17°

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
13
6. Mechanical Installation
The PI is equipped with two metric M4 thread holes on the bottom side (6 mm depth) and can be installed
either directly via these threads or with help of the tripod mount (also on bottom side).
optris PI200,
dimensions in mm
optris PI160,
dimensions in mm

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
14
optris PI400 / PI450,
dimensions in mm

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
15
Mounting accessories (optional)
Mounting base, stainless steel,
adjustable in 2 axes
Product code: ACPIMB
Protective housing, stainless steel,
Incl. Mounting base
Product code: ACPIPH

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
16
High temperature accessories (optional for PI160 only)
The imager optris PI160 can be used at ambient temperature up to 50°C
At higher temperatures (up to 240°C) the cooling jacket should be used.
Cooling jacket for optris PI
Product code: ACCJPI
Mounting bracket for cooling jacket,
adjustable in two axes
Product code: ACCJAB

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
17
Cooling jacket dimensions:

____________________________________________________________________________________________________________
____________________________________________________________________________________________________________
optris PI –E2011-11-A
18
7. Electrical Installation
At the back side of the PI you will find two connector plugs. Please connect the supplied USB cable with the
right plug. The left connector plug is only used for the process interface.
Process Interface
The PI is equipped with a process interface (cable with integrated electronics and terminal block), which can
be programmed via the software as an Analog Input (PIF in) and Digital Input (Dig In) in order to control the
camera or as an Analog Output (PIF out) in order to control the process. The signal level is always 0-10 V.
Note
Please make sure that the process interface (electronics within cable as well as industrial interface)
is powered separately (5-24 VDC).
Plug for USB cable
Plug for PIF cable
Backside of camera with
connectors
