Oracura OC400 User manual

THANK YOU
Thank you for choosing ORACURA’s
OC400 Compact Plus Water Flosser
Please check if the package is intact before using it.
Package Content
How to Charge Water Flosser
How To Fill Water Tank
Power Button & Functional Modes
Operation Instructions
Cleaning & Maintenance
Environmental Protection
To Deal With Battery
Product Information
ORACURA Product Range
Service Station
3
4
5
6
7
8
9
10
11
12
12
Index

0.6mm
Ultra-Fine Water
Jet Spray
Package Content
3600
Rotary Nozzle
Water Tank
Capacity of 120ml
3
Operation Modes
Rechargeable
Charging Point
Protection Design
Accessories Included
OC400 USB Charging Cable
Operational Manual 5 Nozzle Tips
Travel Pouch
#3

Installment and Removal of the Jet Tips
How to Charge the OC400 Water Flosser
1] Take out the Standard Nozzle tip from the tip storage.
2] Insert the Standard Nozzle tip into the hole where it can
hold the tip firmly.
3] When you hear the “click” sound it means its successfully
installed.
4] Please press the tip button first when you want to
remove the tip, then take it out and put it into the tip
storage.
1] Take out the charging point rubber
and insert the USB Charging Cable plug
securely into the water flosser®
charging point socket. Before inserting
the plug, ensure that there are no
traces of liquid inside the socket.
2] Connect the USB Charging Cable to
the USB Charging Source.
3] The "CH" indicator blinks when the
water flosser® is charging and it will
turn o once it is fully charged.
4] After charging, cover the charging
point again with charging point rubber.
If the “CH” indicator blinks during or
after water flossing, it means that the
water flosser® battery needs to be
recharged. Full recharging will take
about 5 hours.
Warning: Please don’t press the tip button when the device is working
Charging Point
Rubber
Tip Button
#4

Filling Water in the Tank
1] Open the valve of the water tank, and
pull the water tank downwards till the
watermark line.
2] Hold the water tank horizontally, and fill
the water into the water tank.
3] After it’s filled, close the valve of the
water tank.
Note: Open the valve of the water tank BEFORE pulling it
downward or it may get dicult because of the air pressure.
Clean running water is recommended. If you feel the water is cold,
you can use warm water with a temperature below 40°C.
It's the same with salt water with below 50% concentration or mouthwash.
Valve of Water Tank
#5
Watermark Line

Power Button and Functional Modes
Normal Mode: Higher water
pressure ensures advanced cleaning.
Ideal for everyday use.
Pulse Mode: The flow of water comes out in
short bursts, which is ideal for cleaning &
massaging the gums.
Soft Mode: The low water pressure allows for
gentle cleaning of the mouth. Ideal for first-time
users, children (age 8+ years), the elderly, and
people with gum problems.
You can select the desired operation mode by pressing the power
button on your water flosser® handle.
Press the power button and the indicator light will turn on.
Change the functional modes - Normal, Soft, and Pulse by
pressing the power button within 5 seconds.
The soft mode is recommended for beginning use.
The product has a smart memory chip inside, which can
remember the user's habits.
It will work automatically based on the mode you used last
time.
Note - There’s a single button for modes, pressure settings, and power on and o.
#6

You can schedule a live product demonstration by
scanning the above QR code.
Scan for Live Demo
Operation Instructions
1] Put the jet tip into the mouth and press the power button to select the desired mode.
2] Aim the jet tip at the teeth, crevices, or gums and tilt your head lightly so that the water flows
down vertically to the rinse area.
3] Point the water jet to the areas between teeth and gums.
4] When cleaning the teeth, please open your mouth slightly to avoid the water spray.
5] Keep the device vertically during use to prevent the interruption of water flow while usage.
#7

Cleaning and Maintenance
Check the device/ charger to see voltage compatibility; do not connect to a dierent voltage
Do not touch charger with wet hands.
Do not use this product if there is any damage on the USB Charging Cable, plug, or the product itself or if the
product is not functioning properly.
Do not direct water under the tongue, into the ear, nose or other delicate areas as the pressure may cause
serious damage.
Use this product only as indicated in these instructions or as recommended by your dentist.
Fill the water tank with water or other dentist recommended solutions only.
Do not drop or insert any foreign object into any opening of the product.
USB Charging cable cannot be replaced; if it is damaged please do not use it.
Do not use this product outdoors or operate where aerosol (spray) products are being used or where oxygen is
being administered.
Do not use iodine, bleach or water insoluble concentrated essential oils in this product. Use of these can reduce
product performance and will shorten the life of the product.
Remove any oral jewelry before using this product.
Do not use it if you have any open wounds on your tongue or in your mouth.
If your physician advised you to receive antibiotic premedication before dental procedures, you should consult
your dentist before using this instrument or any other oral hygiene aid.
Children should be supervised to ensure that they do not play with the device.
Storage space should be dry and clean, keep free from direct sunlight and heat.
If the device needs to be stored for a period of time more than 3 months, it must be fully charged before storing.
Try not to operate the device when the water tank is empty so as to avoid damaging the device.
TO CLEAN - Switch o the power, open the water tank cover and pour out the water.
Turn on the switch and drain the water in the tank.
This product is IPX7 Waterproof designed and can be cleaned directly with water.
Gently wipe the water on the device with a soft cloth and keep it in a dry place.
FOR MAINTENANCE - Wash with water and dry with cloth.
It is recommended to replace the tip that is deformed or it will further aect the use and break down.
TO CLEAN THE BODY - Use a soft slightly moistened cloth and wipe the outside of the product with a small
amount of mild detergent.
The water tank is removable for easy cleaning.
It is recommended to clean the water tank once a week.
Note
Do not wash the device with hot water above 50°C.
Do not use diluents, alcohol or other stimulants otherwise the product could be damaged.
Attention
To reduce the risk of burning, electrocution, re, or injury to people
#8

Environmental Protection
#9
If you face any problems while using our
product or have any complaints
regarding the same, we advise you to
visit our return policy page.
https://oracura.in/pages/return-policy
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
2 Years
If you want to discard this product, please do not place it together with domestic waste but
send it to the ocially designated recycling center and dispose the battery at the ocially
designated battery recycling center. Doing so can benefit environmental protection.
Register your product by scanning the
QR code or visiting the link given below.
https://oracura.in/pages/register
2 years of limited warranty is applicable for material,
manufacturing, or operational defects existing at the
time of delivery or for the occurrence of any
operational error during regular use. Any mishandling
of the product or alteration/repair done by an
unauthorized person will void the warranty. Consumer
is required to submit the original purchase invoice as
proof of purchase date and if requested submit the
entire product to support, to claim warranty.
Please Note: The nozzle tips should be replaced after every 3-4 months.

To Deal With The Battery
To Remove The Battery
The built-in rechargeable battery contains substances that may pollute the environment. Please make
sure to remove the built-in battery when you want to throw the device away.Then take the battery or
the device to the ocial recycling center. Do not remove the rechargeable battery of the device unless
you don’t want it. Make sure the battery power has been run o before you remove it.
Problems
Not working
Leakage occurs between
tip and handle knob
Low Water Pressure
No water shot
There is dirt stuck to the filter
The water storage unit is not filled
with water when using the product
When using the product it tilts
too much
The water pipe is not installed
The water pump is full of dirt
Clean the filter
Fill the water storage tank
Use the product in vertical state
Reload plumbing
Contact customer service
The tip doesn't insert
completely
The product has just been
purchased or it has been idle for
more than 3 months.
Charge the product for 5 hours.
Dirt stuck in the tip
The top of the tip has pressure got
deformed
Dirt in the pump
Take o the tip and replace it
Change the tip
Contact customer service
Reasons Solutions
Switch o the device
Open the top cover of the device
Remove the battery
Oracura Solutions Private Limited, 6th Floor, Unit 1, Vidhani Kalpavruksha, Plot No. 233/2 D block MIDC,
TTC Industrial Area, Thane-Belapur Road, Shirvane, Navi Mumbai-400706.
Support Contact - [phone]
#10

Product Information
Working Modes
Pulse Rated Voltage
Rated Power
Rated Water Pressure
Pulse Frequency
Charging Time
Water Tank Capacity
Battery Specication
Executive Standard
Normal, Soft, Pulse
5V DC
8W
30-90 PSI
1600 rmp/min
5 Hours
120 ml
1100mAh 3.6V Lithium Battery
EN 60335-1: 2012; EN 60335-2-52:2003;EN
62233: 2008
#11

ORACURA® Product Range
Keep Your Product Up & Running, Always!
Accessories & Spare Parts To Buy with OC400
Service Station:
ORACURA® Solutions Pvt. Ltd.
6th Floor, Unit 1, Plot No. 233/2 Vidhani Kalpavruksha, MIDC Industrial Area, T.T.C. Industrial
Area, Mumbai - Pune Hwy, Shiravane, Nerul, Navi Mumbai, Maharashtra, 400706
Visit Us: www.oracura.in Email: [email protected] Phone: [phone]
Standard Tip Orthodontic Tip
Tongue Scraper Pocket tip
ORACURA® also oers various products such as:
Water Flossers
Sonic Electric Toothbrushes
Combo Packs
Spare Parts
Accessories
Certicate Manufacturer
#12
For the complete product range,
Visit: https://oracura.in/
OR Scan Above QR Code
USB Charging
Cable
Travel Pouch
