Orava CL-100 WW User manual

Christmas string LED lights
0EN
CL-100 WW/CW
Instruction manual

2EN
Intended use of the device
The device is intended exclusively as a light Christmas decoration for
decoration, which is determined by technical and operational parameters
and functions, safety and user instructions and external influences of the
operating environment.
ORAVA electrical equipment is manufactured according to the knowledge
of the current state of technology and recognized safety and technical
rules. Nevertheless, incorrect and unprofessional use or use contrary to the
intended purpose may create a risk of injury or endanger the life of the user
or a third party, resp. damage to equipment and other property.
1.1. General safety instructions
• Before putting the device into operation, we recommend that you read the
instructions carefully and operate the device according to the specified
instructions! The luminaires are designed either for indoor use indoors or
for outdoor use outdoors, depending on the type of product.
• By failing to observe the safety instructions and warnings, the
manufacturer is not liable for any damage to health or property!
• Always keep the operating instructions with the device for future reference
and use by new users.
• Use the device only for the intended purpose and in the manner specified
by the manufacturer.
• The device is intended for use in the home and in similar indoor areas
intended for housing without special focus.
• The manufacturer is not liable for damage caused during transport,
incorrect use, damage or destruction of the device due to adverse weather
conditions.
• Do not use the device in an industrial or outdoor environment!
• Do not expose the device to:
- sources of excessive heat or open flame
- insects, animals and flora,
- aggressive and chemical substances.
• The operating environment of the device must always comply with the
specified basic characteristics.
1.2. Operating environment safety
• Ambient temperature: -10 to +65 ° C
• Humidity: 15 ÷ 85%
• Altitude: ≤ 2,000 m
• Occurrence of water: occasional condensation of water or the presence of
water vapor 5. Occurrence of foreign bodies: the amount and type of dust
are insignificant
• Degree of protection by cover: IP20

3EN
1.3.Electrical safety
• Before connecting the device to the mains for the first time, make sure that
the mains voltage indicated on the device plate of the device corresponds
to the mains voltage in your home.
• The electrical device is intended to be supplied from the mains 1/N/PE ~
230 V 50 Hz.
• The electrical safety of the device is only guaranteed if it is connected
correctly to the mains.
• Always connect electrical equipment to an easily accessible power socket.
In the event of an operating fault, the device must be switched off and
disconnected from the mains as soon as possible.
• Do not unplug the power cord / power cord by pulling on the cord / cord.
Disconnect by unplugging the power cord by the plug of the power cord /
power cord.
• If you use an extension power cord, make sure that the total ampere rating
of all the devices connected to the extension cord does not exceed the
max. current load of extension cable.
• The plug of the device power cord must be compatible with the AC socket.
Never use any adapters or otherwise modify the socket. Do not use
unsuitable and damaged sockets!
• Do not bend, squeeze, or otherwise expose the device’s power cord /
power cord to mechanical stress or external heat. Damage to the power
cord may result in electric shock.
• If the power cord is damaged, unplug the device and do not continue to
use it.
• If the supply cord / plug is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to
avoid a hazard.
1.4. Personal safety
• This device is intended for use and operation by persons without electrical
qualification - by laymen, according to the instructions specified by the
manufacturer.
• Operations of the equipment include activities such as turning the
equipment on and off, user manipulation and setting of operating
parameters, visual or auditory inspection of the equipment, and user
cleaning and maintenance.
• The device can only be installed from the age of 18.
• Always keep the device out of the reach of children during use and
operation. Remember that the device can also be downloaded with a
freely accessible power cord.
• Always take extra care when operating electrical equipment!
1.5.Cleaning, maintenance and repairs
• To clean the device, wipe it with a soft, dry cloth. Unplug the device before
cleaning.
• Only entrust warranty or post-warranty repair of the electrical device to a
qualified technician.

4EN
Special safety instructions
• The electrical equipment is designed and manufactured in such a way
as to enable safe operation and use by persons without professional
qualifications. Despite all the measures taken by the manufacturer for safe
use, operation and use, there are certain residual risks and the associated
hazards.
• The following symbols and their meanings have been used on the device
and in the accompanying documentation to warn of possible dangers:
This symbol alerts users to the fact that the device operates
on hazardous electrical voltage. Do not remove the protective
covers on the device. Failure to observe the safety instructions
for the use and operation of the device may result in:
Danger of electric shock! Danger of serious injury or death!
This symbol alerts users to the risk of serious injury or death if
the safety instructions for the use and operation of the device
are not observed! Danger of equipment damage or other
property damage!
This symbol means that the product is made with double
insulation between dangerous live parts (parts with dangerous
mains voltage) and parts that are accessible during normal use.
This symbol alerts users that the device is protected against
the ingress of bodies with a diameter greater than 12.5 mm, for
example a finger, and is not protected against the ingress of
water.
Unpacking/Packaging
• Before putting the device and accessories into operation, unpack and
remove all parts of the packaging materials, labels and labels. Keep
packaging materials in a safe place or keep them out of the reach of
children and incompetent persons. Danger of serious injuries! Danger of
suffocation!
• We recommend performing initial and subsequent regular inspections of
the device. Use the device only with accessories and spare parts supplied
and approved by the manufacturer.
IP20

5EN
Inspection/Commissioning
• Never use the device if it is incomplete, damaged or its parts or
accessories have been damaged during use (e.g. due to a fall - tearing of
the cable).
There is a risk of electric shock!
Danger of serious injuries!
Warning!
• Prior to commissioning, make sure that the correct voltage is available.
• Before each use, check the power cord for damage.
• Do not use the device if you find any damage on it. Danger of serious
injuries!
There is a risk of damage to the device or other property damage!
• Do not use the device in places where there is a risk of explosion, in which
there are flammable liquids, gases or dust. There is a risk of serious injury!
There is a risk of damage to the device or other property damage!
Operation/Supervision
• This device may only be used with original and undamaged parts and
accessories.
• Equipment that is not removed from the packaging must not be connected
to a power source. There is a risk of fire!
WARNING!
• Do not use or place the device near containers containing water. If the
device falls into water, take it to a qualified service representative to
verify that it is safe and working properly. There is a risk of electric shock!
Danger of electrical short circuit!
• Never overload the device above the limits set by the technical
parameters!
• Always divide the operating mode (operating / operating time and break
time) of the device into the recommended operating intervals and follow
these instructions.
• If you notice any abnormal manifestations (sounds, odors, smoke ...) while
using the device, turn off the device immediately and disconnect it from
the mains. Have the device checked by a specialist garage.
• Do not install the device in places where it could be damaged.
• Warning! Risk of electric shock if the LED is damaged or missing. In this
case, do not use the device. The device must not be combined with other
types of lighting.
• Never look directly or with any devices at the connected LEDs due to
possible eye irritation or eye damage.
• Do not cover the connected adapter or kit.
• Never underestimate the possible dangers and take extra care!!!

6EN
Power supply safety instructions
• Do not grab the AC adapter and cord and do not connect to the AC socket
while your hands are wet or the AC adapter cord and cord or the device
itself are wet. Always wipe your hands, power cord, and device thoroughly
with a dry cloth. There is a risk of electric shock!
• Never insert any conductive objects (such as a screwdriver, etc.) into the
connector for connecting the AC adapter.
Danger of electrical short circuit! Danger of explosion!
• Do not use travel adapters (for foreign sockets) as the power cord.
There is a risk of electric shock! There is a risk of fire!
• To disconnect the device from the power supply by pulling the plug out of
the socket, do not pull on the power cord.
Disposal
• At the end of its service life, return the device for waste recycling
electrical and electronic equipment.
Product information
Decorate your tree and your home with modern Christmas LED lighting,
which will create a wonderful Christmas atmosphere in your home. Lights on
LED chains are really economical, and therefore save up to 90% of energy
costs compared to conventional Christmas bulbs. A lifespan of up to 30,000
hours is a guarantee that you don’t have to change your Christmas lights
every Christmas, but our Christmas LED lights will last you a really long
time.
By purchasing this LED light chain, you have got a great decoration that will
allow you to have a beautiful Christmas in the circle of your loved ones!
Indoor and outdoor Christmas LED lighting can be used during Christmas to
decorate a tree indoors or outdoors, but also other uses where you want to
induce a pleasant Christmas well-being.
Advantages of LED lighting:
• Does not heat up and saves energy.
• If one LED goes out, nothing happens, the other LEDs continue to light
without any problems
• Significant economic savings, LEDs consume a fraction of the electricity
compared to light bulbs.
• Possibility of interconnection of several light chains and thus obtain longer
chain.

7EN
connector (female) connector (male)
round seal
Description of parts
The string chain consists of the following components:
Using a string chain
You can use the chain as a standalone product immediately after purchase.
1 Unpack the chain from the packing material, after unpacking it to the
maximum length.
2 Place the chain where you want to use it (decorate the Christmas tree
with it or hang it where you want it) near an easily accessible electrical
socket with the prescribed voltage.
3 Insert the chain plug into an electrical socket. The chain lights up.
4 Unplug the chain from the electrical socket after use. The chain goes out.
5 When the chain is no longer in use, store it in its packaging and store it in
a dry and convenient place.
Connection of connecting connectors (male and female) when using
several chains connected into one unit
You can buy more chains, connect them together and get a longer chain.
The total power input and current load must not exceed the permitted
current load of the circuit and circuit breaker of the socket used.
1 Connect the connector (male) to the connector (female).
socket (plug)
end cover
hanger
round
seal round
seal
connector
(female)
nut
light string chain
connector
(male)
connector
(female)
nutrectifier 3 A

8EN
2 Screw the lock nut of the connector (female) onto the thread on the
connector (male).
Warning!
Ensure that there is a round seal between the connectors (male and
female). After connecting the connectors, screw the nut from the connector
(female) to the thread on the connector (male).
Slide on the supplied shrink tube to ensure a secure connection and prevent
water from entering.
Closing the connector with the end cap and terminating the chain
1 Carefully slide the end cap into the connector (female)
2 Poistnú maticu na konektore (samica) naskrutkujte na koncový kryt.
connector (female)
end cover
round seal
connector (female) connector (male)
connector (female)
end cover

9EN
Warning!
Ensure that there is a round seal between the connectors (male and
female). After sliding the end cover, screw the nut from the connector
(female) onto the thread on the end cover.
Slide on the supplied shrink tube to ensure a secure connection and prevent
water from entering.
Cleaning and storage
Surface cleaning
To clean the surface, use a soft cloth slightly moistened with a mild cleaning
solution. Do not use harsh cloths, scouring powders,
nor solvents such as diluent, gasoline or alcohol. They can damage the
surface. Disconnect the chain from the mains before cleaning.
If you do not intend to use the product for a long time, store it
in the original packaging in a dry and cooler place out of direct sunlight, out
of reach of heat sources and out of reach of children.

10EN
Technical specifications
Power supply: 230 V~, 60 Hz
Power consumption: 7 W
Number of LEDs in the chain: 100 ks
Length: 10 m
Max. allowed number of connected chains: 20
Supplied accessories: Instruction manual(1)
Technical data subject to change without notice!

DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
The symbol on the product or on its packaging indicates that this product does not belong
to household waste. It is necessary to take it to a collection point for electrical recycling
and electronic equipment.
By ensuring proper disposal of this product, you will help prevent negative consequences
to the environment and human health that would otherwise be caused by inappropriate
disposal of this product. For more detailed information about recycling of this product,
please contact your local authority, your household waste disposal service or the shop
where you purchased the product.
This product meets all the essential requirements of the EU directives that apply to it.
Producer:
Importer:
ORAVA retail 1, a.s.
Seberíniho 2
821 03 Bratislava
Slovenská republika
ORAVA distribution CZ, s.r.o.
Ostravská 494
739 25 Sviadnov
Česká republika
ORAVA retail 1, a.s.
Seberíniho 2
821 03 Bratislava
Slovenská republika
