Orbic AIRSURF 5G User manual

Quick
Start
Guide

Package content ������������������������������������������������������������������������������������������������������������������ 3
Device Overview������������������������������������������������������������������������������������������������������������������� 4
Charge your Orbic AirSurf 5G PC������������������������������������������������������������������������������� 5
SIM Card Replacement����������������������������������������������������������������������������������������������������� 6
Software Update management��������������������������������������������������������������������������������������7
Windows 10������������������������������������������������������������������������������������������������������������������������������7
Features������������������������������������������������������������������������������������������������������������������������������������ 9
Technical datasheet ��������������������������������������������������������������������������������������������������������� 10
Use Orbic standard safety information��������������������������������������������������������������������12
Support & More������������������������������������������������������������������������������������������������������������������� 13
Index
2�

If any of the items are missing or damaged, please contact manufacturer
immediately and save the entire package for transport�
Package Content
3�
Verify that the following items are included in the package:
1X Orbic AirSurf 5G PC
1X Power Adapter
1X Quick Start Guide
1X SIM tool

Device Overview
Thank you for purchasing Orbic AirSurf 5G PC
Power Key
Power Indicator Light
Number Indicator Light
Caps Lock Indicator Light
LCD
MicCameraMic
Type-C
Full FunctionType-C
SIM
Card USB 2�0
Earphone
Speaker
4�
Charging
Indicator Light
USB 3�0

Charge Your Orbic AirSurf 5G PC
5�
1
2

SIM Card Replacement
12
3
4
6�

Software Update Management
During software updates or during download operations do not remove
the power supply as it may cause irreversible data loss� Any tampering
with the software may generate additional costs for recovery�
Windows 10
Start
Press and release the power button for 1 second� (Note: if there is no
response when you press the power button, the device battery may
need to be charged)�
Power OFF / Reboot
From the Start screen, press the Power button > Sleep/Shut Down/Restart
Lock the Screen
Press the power button�
Network Connection
Your Orbic AirSurf 5G PC has built in support for mobile broadband service
on 5G and 4G networks� This capability gives you the power to access the
internet, send email, or connect to your corporate network without the need
for Wi-Fi network or the use of a Wi-Fi hotspot�
7�

8�
Cellular service is provided using a relevant activated SIM card that is
inserted on the left side of the computer�
To connect to the mobile network find the task bar:
1� Select the network status icon�
2� Select Network & Internet settings�
3� Under the Network & Internet section, select Cellular, and then
select Advanced Options�
4� Select the Mobile network you have service with to connect�
Wi-Fi Connection
Select the network icon on the taskbar, select the desired Wi-Fi network,
connect, then type the password and follow the instructions�
Bluetooth 5.1
Using your Orbic Airsurf 5G PC bluetooth capability, you can connect all
your wireless devices seamlessly�
Changing the Language of the System
From Settings go to Date/Time and language > Region/Language�
Start Menu
Activating the start menu at the bottom left, you will find the quick links
to File Explorer, Settings, Stop (Suspend, Stop System, Restart System),
all Apps�
The applications you use more often appear in the upper left corner�
The tiles (live tiles) that appear on the right side of the start menu act
as quick links to the applications� You can reorganize, resize, add and
remove tiles whenever you want�

9�
Display
Large 14�1 inch FHD display�
Memory
16 GB of RAM and 256 GB of ROM�
Jack Audio 3.5 mm
Connect headphones or earphones through this output�
Camera
The 2MP built-in camera lets you take photos and videos along with
video calling support�
Microphone
It captures your voice and the surrounding incoming sounds�
Speaker
It oers a clear and optimal quality of sound�
Features

Dimensions
Chip
Graphics
Width: 324 mm | Height: 222
mm |Thickness: 18�1 mm |
Weight: 54�1 OZ
Intel i3, 10110U, 2�1 GHz
Modem Qualcomm X55 to 64
bit operating up to 2�60 GHz
Intel® UHD Graphics 600
operating up to 650 MHz
Technical Datasheet
Display
Keyboard
Touchscreen14�1” FHD
Resolution 1920 x 1080 FHD
Keyboard with touchpad
multi touch
10�

Operating
System
Memory
Inputs |
Outputs
Windows 10 Home
RAM LPDDR4 16 GB Storage
capacity 256 GB eMMC
1 Port USB 2.0
1 Port USB 3.0
1 Port USB Type-C full function
1 Port USB Type-C
1 Earphone output 3�5 mm
256
Battery
Connection
Camera |
Audio
Lithium polymer battery:
Dual Cell 6000 mAh 7.6 V
• Wi-Fi 802�11a/b/g/n/ac/ax
Dual Band
• Bluetooth 5.1
• Audio: 2integrated speakers
• Camera: 2MP Front
11�
256
6000

EXPLOSION HAZARD if the battery is replaced with a non
compliant model� Dispose of used batteries according to
the manufacturer’s instructions�
DO NOT THROW the battery in municipal waste bins� The X symbol
on the disposal bin indicates that the battery should not be thrown
in the bins of municipal waste�
DO NOT THROW your Orbic AirSurf 5G PC in municipal waste bins�
This product has been designed to enable the reuse of some parts
and the recycling of other parts� The X symbol on the disposal bin
indicates that the product (electrical, electronic, batteries containing
mercury) should not be thrown in the bins of municipal waste� Check
local regulations for proper disposal of electronic products�
DO NOT THROW your Orbic AirSurf 5G PC in the fire� DO NOT create a
short circuit between the contacts� DO NOT disassemble your product�
12�
Use Orbic Standard Safety Information

More Information
Download a User Guide from
"verizonwireless�com/support
Customer service
Call 1�800�922�0204
Twitter@VZWSupport
International travel
For features and rates when outside the US,
visit “verizonwireless�com/international�”
Get help for your device, visit
“verizonwireless�com/support�”
13�
Support & More

Your Wireless Device and Third-party Services
Verizon Wireless is the mobile carrier associated with this wireless
device, but many services and features oered through this device are
provided by or in conjunction with third parties� Verizon Wireless is not
responsible for your use of this device or any non-Verizon Wireless
applications, services and products, including any personal information
you choose to use, submit or share with others� Specific third-party
terms and conditions, terms of use and privacy policies apply� Please
review carefully all applicable terms, conditions and policies prior to
using this wireless device and any associated application,
product or service�
OAS_QSG_VZ_V15
