ORFELD JS6632 User manual
IMPORTANT: Read Before Using.
www.orfeldtech.com
Model No.: JS6632
INSTRUCTION MANUAL
Laser Jig Saw
www.facebook.com/orfeldtech
Contents
1.Safety Warnings-------------------------------1
2.Product And Functions---------------------- 3
3.Specification------------------------------------3
4.Functional Description-----------------------4
5.Operation Instruction ------------------------8
6. Maintenance And Cleaning------------------11
7. Environmental Protection--------------------11
General safety hints for work with electric tools,
Please read and take note of the following comments that regard your protection
against electric shock and risk of injury and fire.
1.Verify that the power supply in your area is compatible with the voltage listed on the machine.
2.Check the electric tools and electrical connections for any damage.
3.Connect the power lead to the mains only with the tool turned off.
4.Always turn on the tool before setting it against the piece you are working on.
5.Adopt protective measures against electric shock. Avoid body contact with earthed parts,
such as metal pipes, radiators, cooking ranges, refrigerators and the like.
6.Large variations in temperature can lead to condensation on live part. Before use:
Give the machine time to adjust to the temperature of the work area.
7.Do not use machines, tools and recommended accessories for works other than those for
which they are designed!
8.Secure the workpiece. Use clamping devices ora vise to hold the workpieces securely.
9.To avoid accidents，do not wear jewellery or loose clothing that could be caught up by
moving parts. It is recommended to wear protective footwear and gloves. Long hair should be tied up.
10.When dust, splinters or shavings are a problem while working, or when working overhead,
please wear protective eyewear and, if necessary, a protective mask.
11.When operating the machine, wear ear protection.
12.Be sure you always have safe footing, when working on floors, ladders and scaffoldings.
13.Keep electric tools away from humidity and rain. Do not immerse it.
14.When working outdoors, only use approved tools and extension cables marked for outdoor use.
15.Do not use the equipment in areas where danger of explosion exists.
16.When passing this device over to a third person, these instructions must be handed out too.
17.Only have repairs done by specialists using original parts.
18.Make sure the power cord is not torn before use.
1.Safety Warnings
1
WARNING:
The consumption of alcohol, medication, plus states of illness, fever and fatigue affect your reaction.
Do not use electric tools in any of these situations.
1. Keep electric tools away from children.
2. Store electric tools in the original box in a safe place and out of the reach of children.
3. When not in use, during breaks, when doing adjustment works, changing accessories
or during repair, always unplug the cable.
4. Never carry the tool by the cable. Never unplug the tool by pulling on the cable.
5. Do not adjust the speed when the load is working.
6. Keep your workplace tidy: untidiness can cause accidents!
7. Avoid abnormal body postures while working.
8. Avoid switching on or starting up the machine unintentionally.
9. Do not leave keys, spanners and adjusting tools inserted in the machine
10.After switching off, do not stop the saw blade to a stop by applying side pressure.
11.Use only sharp, flawless saw blades. Replace immediately cracked, bent or dull saw blades.
12.Always pull out the mains plug before changing the saw blade and/or adjusting the saw base.
13.The saw blade must be locked in its mount absolutely securely. Check from time to time that
it is securely seated.
14.The saw base must stand securely on its entire surface.
15.Sawing asbestos cement may generate dust dangerous to your health. Comply with
government regulations and manufacturer recommendations.
16. The laser can't illuminate human eyes to avoid injury.
2
3
3.Specification
Model
Voltage
Frequency
Rate Current
No load Speed
Max Cutting
Laser
Accessories Blade: 6 pcs, Dust chute : 1 pcs， Guide Rule : 1 pcs,
Hex wrench :1 pcs, Manual : 1 pcs，Warranty Card:1 pcs
Plastic box : 1 pcs,
Weight
Cord length
LPA
(Sound pressure level)
LWA
(Sound power level)
Vibration level
Protection class
3m
JS6632
AC 120V
50~60Hz
6.5A
100mm for Wood
10mm for Steel
800~3200r/min
AC Laser
L =97.7dB(A),K=3.0dB(A)
L =86.7dB(A),K=3.0dB(A)
WA
PA
Noise
a =7.9 m/s2, k=1.5 m/s2
a =6.0 m/s2, k=1.5 m/s2
h,M
h,B
Noise
1234
5
6
7
8
9
11
12
2.Product And Functions
1.Speed Switch
2.Locking Button
3.On/Off Switch
4.HEX Angle Wrench
5.Dust Chute
6.Cutting Action Changing Lever
7. Base Plate(Aluminum alloy)
8. Guide Rule
9. Blade
10.Guide Roller
11. Dust Cover for Vacuuming
12. Laser Switch
10
2.1 kg
4.Functional Description
4.1.Switch Action
CAUTION:
Before plugging in the tool, always check to see that the switch trigger actuates properly and
returns to the "OFF" position when released.
2
1
► 1. Switch trigger 2. Lock button
To start the tool, simply pull the switch trigger. Tool speed is increased by increasing pressure on the switch trigger.
Release the switch trigger to stop.For continuous operation, pull the switch trigger, push in the lock button and then
release the switch trigger.To stop the tool from the locked position, pull the switch trigger till its end, then release it.
4.2.Speed switch
1.Speed Switch：6 stroke（Min.1 to Max.6)
Remarks: When you try the machine for the first time, please select the low stroke,
after getting familiar with the machine, operate in the high-speed mode.
CAUTION:
Before plugging in the tool, always check to see that the switch trigger actuates properly
and returns to the "OFF" position when released.
4.3.Selecting the cutting action
1
4
► 1. Cutting Action Changing Lever
This tool can be operated with an orbital or a straight line (up and down) cutting action.
The orbital cutting action thrusts the jig saw blade forward on the cutting stroke and greatly increases cutting speed.
To change the cutting action, just turn the cutting action changing lever to the desired cutting action position.
Refer to the table to select the appropriate cutting action
4.4.Laser
► 1. Laser Switch 2.Laser Line
Plug in the machine, turn on the matching power supply on the nameplate, and press the laser switch
to turn the laser on and off.
CAUTION:Do not irradiate human eyes with laser, in case of unnecessary damage.
1
1
2
5
Position Cutting action Applications
For cutting mild steel, stainless
steel and plastics.For clean cuts
in wood and plywood
0
1
2
3Large orbit
cutting action
Medium orbit
cutting action
Small orbit
cutting action
Straight line
cutting action
For cutting mild
steel, aluminum
and hard wood
For cutting wood and plywood.
For fast cutting in aluminum
and mild steel.
For fast cutting in
wood and plywood
4.5.Saw blade installation and disassembly
ASSEMBLY
Always be sure that the tool is switched off and unplugged before carrying out any work on the tool.
Installing or removing jig saw blade
CAUTION:
Always clean out all chips or foreign matter adhering to the jig saw blade and/or blade holder.
Failure to do so may cause insufficient tightening of the blade, resulting in a serious personal injury.
CAUTION:
Do not touch the jig saw blade or the workpiece immediately after operation.
They may be extremely hot and could burn your skin.
CAUTION:
Always secure the jig saw blade firmly. Insufficient tightening of the blade may cause
blade breakage or serious personal injury.
12 3
► 1. Quick Chuck Knob 2. Blade 3. Stroke Rod
Select the suitable blade, set the chuck knob to a position parallel to the model, insert the jig saw blade
into the blade holder, and push it as deep as possible. Make sure that the slot of the saw blade is installed
in the quick chuck,and loosen the chuck knob.At this time, the saw blade is fixed on the troke Rod.
To check whether the saw blade is installed in place, you can pull the saw blade very hard.
If the blade stay solid,the installation is done.
When removing the jig saw blade, please set the quick chuck to the parallel position of the model, at this time,
the saw blade will pop up automatically.
Note: When the blade is ejected, it must not be aimed at people or animals to avoid injury.
Note: When installing the saw blade, please look at the shape of the blade head. To avoid mismatched saw blades.
OK NG
6
4.6.Base Plate Angle Adjustment
CAUTION:
Always be sure that the tool is switched off and unplugged before tilting the base.
► 1. Hex Socket Screw 2. Hex Wrench 3. Angle Limit Bolt 4.Base Sawtooth
When the machine leaves the factory, the bottom plate is perpendicular to the machine (0 degree position).
If the angle of the bottom plate is adjusted,Proceed as follows:
1.Using a hex wrench, loosen the 2 hex socket screws in the counterclockwise direction.
2.Pull down the BASE, rotate the BASE, select the required angle, and snap the bottom plate saw teeth
into the angle limit bolt.
3. Use a hex wrench to tighten the two hex socket screws clockwise.
4.7.Hex Wrench Storage
► 1. Hex Wrench 2. Power Cord Protective Cover
When not in use, store the hex wrench as shown in the picture .
12
3
4
1
2
7
8
5.Operation Instruction
5.1 Straight cut
CAUTION:
Always hold the base flush with the workpiece.
Otherwise, it may cause jig saw blade breakage, resulting in a serious injury.
CAUTION:
Push the tool very slowly when cutting curves or scrolling.
Abuse of force on tool may cause a slanted cutting surface and jig saw blade breakage.
► 1. Cutting Line 2. Base
Turn on the tool, making no contact with jig saw blade until making any contact and wait until the blade attains full speed.
Then rest the base flat on the workpiece and gently move the tool forward along the previously marked cutting line.
5.2 Bevel Cutting
CAUTION:
Always be sure that the tool is switched off and unplugged before tilting the base.
CAUTION:
Raise the dust cover all the way before making bevel cuts With the base tilted,
you can make bevel cuts at any angle between 0° and 45° (left or right).For more details, please read 4.6.
1
2
5.3 Cutouts
Cutouts can be made with either of two methods "Boring a starting hole" or "Plunge cutting".
Drill a starting hole .
For internal cutouts without a lead-in cut from an edge,pre-drill a starting hole 12 mm or more in diameter.
Insert the jig saw blade into this hole to start your cut.
5.4 Plunge Cutting
9
if you take below steps carefully,thena starting hole or a lead-in cut is unnecessary.
1.Tilt the tool up on the front edge of the base with the jig saw blade point positioned just above the work-piece surface.
2.Holding tight to the tool so that the front edge of the base will not move when you switch on the tool and
gently lower the back end of the tool slowly.
3.As the jig saw blade pierces the workpiece, slowly lower the base of the tool down onto the workpiece surface.
4.Complete the cut in the normal manner.
5.5 Edge trimming
To trim edges or make dimensional adjustments, run the jig saw blade lightly along the cut edges.
5.6 Metal cutting
Always use a suitable coolant (cutting oil) when cutting metal. Otherwise it will cause serious wear of the jig saw blade.
The underside of the workpiece can be greased instead of using a coolant.
5.7 Dust extraction：
Turn the switch to the front side,
the dust is discharged backward
(When used for dust collection)
Turn off to the rear side,
the dust is discharged forward
(when dust collection is not required)
► 1. Dust Collection Switch 2. Dust Chute 3. Vacuum Cleaner Hose (Vacuum cleaner accessories)
Clean cutting operations can be performed by connecting this tool to a vacuum cleaner.
Insert the hose of the vacuum cleaner into the hole at the rear of the tool.
NOTE: Dust extraction cannot be performed when making bevel cuts.
2
1
3
10
5.8 Parallel guide
CAUTION:
Switched off and unplugged before installing or removing accessories.
When repeatedly cutting widths of 150 mm or less, use of the rip fence will assure fast, clean, straight cuts.
►1. Bolt 2. Hex wrench 3.Guide Rule
When installing the Guide Rule plate and inserting it into the rectangular hole on the tool base side,
make the parallel guide plate guide plate face down. Slide the saw guide to the desired cutting width,
and then tighten with bolts. (The parallel guide can be installed on both sides).
1
2
3
11
6. Maintenance And Cleaning
Before any work on the machine itself, pull the mains plug.
The guide roller 10 should be regularly checked for wear and lubricated with a drop of oil.
If the guide roller worn，it should be replaced.For safe and proper working,
always keep the machine and the ventilation slots clean.
Should the tool was faulty despite the rigorous at manufacturing and testing procedures, repair should be carried out
by authorized customer services center to
7. Recycling and Disposal
Recycle raw materials instead of disposing as waste.
Machine, accessories and packaging should be sorted for environmentfriendly recycling.
The plastic components are labeled for categorized recycling.
These instructions are printed on recycled paper manufactured without chlorine.
MADE IN CHINA
Thank you for choosing Orfeld.
If you have any doubt or query, please contact us
www.orfeldtech.com
www.facebook.com/orfeldtech
ADD:RM513 and 515, Building B, Baoneng Zhichuang Valley, No. 6,
Fukang Road, Hehua Community, Pinghu Street,
Longgang District, Shenzhen,China
ShenZhen XiaoSi Technology Co.,Ltd.
Table of contents
