Makita DSC250 User manual

DSC250
EN Cordless Steel Rod Cutter INSTRUCTION MANUAL 4
SV Sladdlös stålstångskapare BRUKSANVISNING 13
NO Batteridrevet stålrørkutter BRUKSANVISNING 22
FI Akkuharjateräsleikkuri KÄYTTÖOHJE 32
LV Bezvada tērauda stieņu frēze LIETOŠANAS INSTRUKCIJA 42
LT Belaidis plieninių strypų
pjoviklis NAUDOJIMO INSTRUKCIJA 52
ET Terasvarraste juhtmeta lõikur KASUTUSJUHEND 62
RU Аккумуляторные
гидравлические ножницы
РУКОВОДСТВО ПО
ЭКСПЛУАТАЦИИ 72

2
1
2
78
6
54
9
3
Fig.1
1
2
2
1
3
Fig.2
1
Fig.3
OI
1
2
3
4
5
Fig.4
1
2
1
2
Fig.5
1
2
Fig.6
1
Fig.7

3
1
Fig.8
1
Fig.9
1
2
3
4
5
6
7
Fig.10
1
Fig.11
1
Fig.12
1
Fig.13

4ENGLISH
ENGLISH (Original instructions)
Before installing and operating this machine, read, understand and follow all
instructions and operating procedures. Keep this Instruction Manual with the
machine.
Read, understand and follow all safety instructions and operating
procedures. If you do not understand the instructions, or if condi-
tions are not correct for proper operation, DO NOT OPERATE THE
MACHINE. Consult your supervisor or other responsible person.
SPECIFICATIONS
Model: DSC250
Voltage D.C. 18 V
Weight 3.94 - 4.0 kg (8.686 - 8.818 lbs)
Dimensions (L x W x H) 471 mm x 137 mm x 139 mm / 18-17/32″ x 5-25/64″ x 5-15/32″ (excluding a handle)
Cutting Capacity of a rebar
(620 N/mm2/ 90,000 psi )
φ10 to φ25 mm (SD490)
3/8″ to 1″ (Grade 60)
No load speed 2200 min-1
External Diameter of Blade 110 mm / 4.3″
Battery cartridge BL1830B / BL1840B / BL1850B / BL1860B
Charger DC18RC / DC18RD / DC18SE / DC18SF / DC18SD
• Specications and design may be subject to change without prior notice.
• Specications and battery cartridge may differ from country to country.
• The weight may differ depending on the attachment(s), including the battery cartridge. The lightest and heavi-
est combination, according to EPTA-Procedure 01/2014, are shown in the table.
WARNING
Read and understand this instruction manual before
operating this machine. Failure to follow operating
instructions could result in death or serious injury.
WARNING LABELS RELATED TO
SAFETY
Flying debris and loud noise hazards. Wear ear and
eye protection.
Moving blade. Keep hands clear while machine is
operating. Turn power off before servicing.
Symbols
The following show the symbols used for the equip-
ment. Be sure that you understand their meaning before
use.
Cd
Ni-MH
Li-ion
Only for EU countries
Do not dispose of electric equipment or
battery pack together with household waste
material!
In observance of the European Directives,
on Waste Electric and Electronic
Equipment and Batteries and Accumulators
and Waste Batteries and Accumulators
and their implementation in accordance
with national laws, electric equipment and
batteries and battery pack(s) that have
reached the end of their life must be col-
lected separately and returned to an envi-
ronmentally compatible recycling facility.

5ENGLISH
SAVE THESE INSTRUCTIONS
Meaning of “caution” and “warning” indications
Caution: Indicates a potentially hazardous situation
which, if not avoided, may result in minor
or moderate injury. This is also used to
alert against unsafe practices associated
with events that could lead to personal
injury.
Warning: Indicates a potentially hazardous situation
which, if not avoided, will result in death or
serious injury.
*** Makita shall not be responsible for any inci-
dental damages or personal injuries result-
ing from negligence of Warnings and Safety
Instructions contained in the Instruction
Manual.
Intended use
The tool is intended for cutting rebar.
Noise
The typical A-weighted noise level determined accord-
ing to EN60745:
Sound pressure level (LpA) : 78 dB(A)
Uncertainty (K) : 3 dB(A)
WARNING: Wear ear protection.
Vibration
The vibration total value (tri-axial vector sum) deter-
mined according to EN60745:
Work mode: impact tightening of fasteners of the maxi-
mum capacity of the tool
Vibration emission (ah) : 2.5 m/s2
Uncertainty (K) : 1.5 m/s2
NOTE: The declared vibration emission value has
been measured in accordance with the standard test
method and may be used for comparing one tool with
another.
NOTE: The declared vibration emission value
may also be used in a preliminary assessment of
exposure.
WARNING: The vibration emission during actual
use of the power tool can differ from the declared
emission value depending on the ways in which the
tool is used.
WARNING: Be sure to identify safety measures
to protect the operator that are based on an estima-
tion of exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as the
times when the tool is switched off and when it is run-
ning idle in addition to the trigger time).
EC Declaration of Conformity
For European countries only
The EC declaration of conformity is included as Annex A
to this instruction manual.
IMPORTANT SAFETY
INSTRUCTIONS
• The “important safety instructions” described
below should always be followed to reduce the
risk of a re, electric shock, and personal injury.
• Before operating the machine, read and carefully
follow these instructions.
• This manual should be retained for future
reference.
WARNING
1. Before use, read this Instruction Manual
thoroughly.
2. Use only the charger and battery specied in
this Instruction Manual.
· Any combination, except that specied in this
manual, may cause injury or damage due to
explosion.
3. Charge properly.
· Use this charger only with the rated AC power
supply. Do not use booster transformers or vehicle
generator, or use the charger to supply DC power.
Incorrect use may cause overheating and re.
· Do not charge the battery at a temperature under
10°C (50°F) or more than 40°C (104°F) as this
may cause an explosion or re.
4. Do not short-circuit the pins of the battery.
Avoid storing battery in a container with other
metal objects such as nails, coins, etc. This
may cause overheating, re and explosion due
to short-circuit.
5. Guard against an electric shock.
· Do not touch the power plug with a wet or damp
hands as this may result in an electric shock.
6. Consider the work area environment.
· Do not expose the charger and battery to rain or
use them in damp or wet locations, as this may
cause overheating or electric shock.
· Keep the work area well lighted. Working where
there is insufcient light may cause an accident.
· Do not use or charge the battery where there are
ammable uids or gases, as this may cause
explosion or re.
7. Wear Safety Glasses and Protective Clothing
· Always wear eye protection, dust mask, non-skid
safety shoes, helmet and any other mandated
or necessary protective clothing while using this
equipment. Failure to do so may result in injury.
8. Prevent unintentional starting.
· Ensure the switch is in the off-position before con-
necting to power source and/or battery pack, pick-
ing up or carrying the tool. Carrying power tools
with your nger on the switch invites accidents.
9. Secure the work.
· Use clamps or a vice to hold the work. This frees
both hands to properly hold, control, and operate
the tool. Failure to properly secure the work may
result in injury.

6ENGLISH
10. Disconnect the tools power supply, by remov-
ing the Battery and engaging the Trigger
Switch Lock, whenever one of the following
situations occur.
· The tool is not in use or is being serviced.
· Any parts, such as a blade, are being replaced.
· There is a recognised hazard.
Failure to do so may result in accidental operation
and damage or injury.
11. Only use the specied accessories or
attachments.
· Use only the accessories or attachments
described in this Instruction Manual and the
Makita catalog. Use of any other accessories or
attachments may result in an accident or injury.
12. Do not expose the battery to re as it may
explode or generate poisonous substances.
13. Under conditions of abuse, liquid may be
ejected from the battery; avoid contact.
· If contact accidentally occurs, ush with clear
water.
· If liquid contacts eyes, ush with clear water and
seek immediate medical help as it may result in
loss of eyesight.
14. If operating time has reduced very signi-
cantly, stop operating immediately. There is a
risk of overheating which may result in burns
and even an explosion.
CAUTION
1. Work area safety
· Keep work area clean and well lit. Cluttered or
dark areas invite accidents.
2. Keep Children and bystanders away while
operating a power tool. Distractions can cause
you to lose control.
3. Store idle power tools correctly.
· Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power
tool. Power tools are dangerous in the hands of
untrained users.
· Do not store the tool and battery in locations
where the temperature may reach or exceed 50°C
(122°F), such as a metal box or car in summer.
It may shorten the battery service life or result in
smoke and re.
4. Do not force power tools.
· Use the tool at the proper speed and for which the
tool was designed. Cutting too fast may result in
damage to the tool or personal injury.
· Do not use the tool in a way that could cause the
motor to lock. It may result in smoke or re.
5. Use the power tool for the right application.
· Use the power tool, its attachments and blades
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Do not use for a big tool operation.
Using for applications that are different from those
intended may result in personal injury.
6. Dress properly.
· Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts.
Loose clothes, jewelry or long hair can be caught
in moving parts.
· Wear rubber gloves and non-skid safety shoes
when operating a power tool outdoors. Slippery
gloves or shoes may result in a personal injury.
7. Do not abuse a cord of charger.
· Never use the cord for carrying, pulling or unplug-
ging the power tool.
· Keep cord away from heat, oil, sharp edges or
moving parts.
· Make sure a cord is located where it will not be
stepped on, tripped over, or otherwise subjected
to damage or stress. Damaged or entangled cords
increase the risk of electric shock or re.
8. Do not overreach.
· Keep proper footing and balance at all times. This
enables better control of the power tool in unex-
pected situations.
9. Maintain power tools.
· Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
Damaged blades may cause personal injury.
· Keep handles dry, clean and free from oil and
grease. Slippery handles may result in personal
injury.
· Check power cord of the charger regularly.
Damaged cord will increase risk of electric shock
or short circuit resulting in re.
10. Remove any adjusting key or wrench before
turning the power tool on.
· A wrench or key left attached to a rotating part of
the power tool may result in personal injury.
11. When charging outdoors, use a cabtyre cable
or a cabtyre extension cord.
· Use only the accessories or attachments
described in this Instruction Manual and the
Makita catalog. Use of any other accessories or
attachments may result in an accident or injury.
12. Stay alert, watch what you are doing and use
common sense when operating a power tool.
· Do not use a power tool while you are tired or
under the inuence of drugs, alcohol or medica-
tion. A moment of inattention while operating
power tools may result in serious personal injury.
13. Check for damaged parts before use.
· Check safety covers and other parts that may
affect the tools function for breakage or damage. If
damaged, replace or repair before use.
· Check for misalignment or binding of moving
parts, breakage of parts and any other condition
that may affect the power tool’s operation. If dam-
aged, have the power tool repaired before use.
Many accidents are caused by poorly maintained
power tools.
· Do not use damaged extension cord. If damaged
replace it before use. Use of damaged extension
cord will increase risk of electric shock or short
circuit resulting in re.

7ENGLISH
· Do not use the charger if the power cord or power
plug is damaged or if it is dropped or it is damaged
in any way. A damaged charger will increase risk
of electric shock or short circuit resulting in re.
· Do not use a power tool if the switch doesn’t turn
it on and off. Any power tool that cannot be con-
trolled with the switch is dangerous and must be
repaired.
· Follow instructions for lubricating and changing
accessories.
· Disconnect the battery from the power tool before
making any adjustment or changing accessories.
Such preventive safety measures reduce the risk
of starting the power tool accidentally.
14. Have your power tool serviced by a qualied
repair person using only identical replacement
parts. This will ensure that the safety of the
power tool is maintained.
· Do not disassemble or modify the battery and
charger.
· This power tool is designed in conformity with
safety regulations. Do not modify a power tool.
· Have your power tool serviced if it overheats or if
any other unusual symptoms are observed.
· Do not permit an unqualied person to repair the
tool as this may compromise the tool safety and
result in accident and personal injury.
15. Do not operate power tools in explosive atmo-
spheres, such as in the presence of ammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
Electrical Safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of elec-
tric shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet con-
ditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces
the risk of electric shock.
Personal Safety
1. Use personal protective equipment. Always
wear eye protection. Protective equipment such
as dust mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate conditions
will reduce personal injuries.
2. If devices are provided for the connection of
dust extraction and collection facilities, ensure
these are connected and properly used. Use of
dust collection can reduce dust-related hazards.
Power tool use and care
1. Do not force the power tool. Use the correct
power tool for your application. The correct
power tool will do the job better and safer at the
rate for which it was designed.
2. Do not use the power tool if the switch does
not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and
must be repaired.
3. Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools. Such pre-
ventive safety measures reduce the risk of starting
the power tool accidentally.
4. Use the power tool, accessories and tool bits
etc. in accordance with these instructions, tak-
ing into account the working conditions and
the work to be performed. Use of the power tool
for operations different from those intended could
result in a hazardous situation.
Battery tool use and care
1. Recharge only with the charger specied by
the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of re
when used with another battery pack.
2. Use power tools only with specically desig-
nated battery packs. Use of any other battery
packs may create a risk of injury and re.
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal
objects, that can make a connection from one
terminal to another. Shorting the battery termi-
nals together may cause burns or a re.
4. Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If con-
tact accidentally occurs, ush with water. If
liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause
irritation or burns.
CAUTION
1. Hold the tool securely while it is in use.
· If the tool is not held securely, you may be injured.
2. Keep your hands and face away from the mov-
ing parts.
· They may cause an injury.
3. Release the Switch immediately to stop opera-
tion when the tool is out of order or makes an
abnormal sound during use.
Have it inspected and repaired by an autho-
rized service center.
· Failure to do so may result in damage or injury.
4. If you drop or strike the tool, check carefully
that the body is not damaged, cracked, or
deformed.
· Any such damage could cause injury.

8ENGLISH
5. Do not short the battery. A battery short can
cause a large current ow, overheating, pos-
sible burns and even a breakdown.
· Do not touch the terminals with any conductive
materials.
· Avoid storing battery in a container with other
metal objects such as nails, coins, etc.
· Do not expose battery to water or rain.
· Do not cut the cord.
6. Do not operate the tool or charge the battery in
explosive atmospheres, such as in the presence
of lacquer, paint, benzin, thinner, gasoline, gasses
or adhesive. This may cause an explosion or re.
7. Do not charge the battery on paper, cardboard,
cloth, cushions, mats, carpets, vinyl or in the pres-
ence of dust. This may cause re.
8. Do not expose the Charger to water or metal items
that can short out the charging terminals.
9. Do not use charger for any other purpose than
charging the battery.
10. Make sure tipped saw blades have no chips or
cracks before using the tool.
11. Do not use water or cutting oil when cutting.
12. Use only Makita genuine tipped saw.
13. Do not leave the tool on the oor with switch
locked on. The tool will run continuously and it
may cause personal injury.
14. Do not operate the tool close to ammable and
fragile items or personnel not necessary to the
operation. During cutting hot debris and sparks will
be ejected from the tool which may cause damage
to the surroundings, re or personal injury.
15. Do not cut concrete. It causes damage to the tool
and may result in personal injury.
16. Check for the presence of people on the ground
during operation in an elevated place. Any materi-
als or tools dropped may cause an accident.
17. If during charging, there is an abnormal generation
of heat, stop charging immediately by disconnect-
ing the battery. Continuing charging may cause
smoke, re or explosion.
18. Do not allow anything to cover or clog the motor
vents.
This may cause the motor to overheat.
19. When using an extension cord with the charger,
it is recommended to use a cord with the cross
section below and with a length as short as pos-
sible. For charging outdoors, use a cord rated for
outdoor use.
Relation between usable cord thickness and maximum
length
Cord size
(Nominal cross sectional area of
conductor)
Maximum cord
length
0.75 mm220 m
1.25 mm230 m
WARNING FOR USING
TIPPED SAW
Work area safety
1. Ensure the Dust Bag is xed correctly. Without the
Dust Bag, when Tipped Saw Blades are damaged,
pieces of the blades y off and can cause serious
personal injury.
2. Keep bystanders away from operations. Even with
the Dust Bag tted, damaged blades or hot debris
can y out of the bag, resulting in serious personal
injury.
3. Sparking may occur when cutting with Tipped Saw
Blades. Do not use the tool where there is the risk
of re or explosion.
4. Cutting with Tipped Saw Blades is noisy. Consider
the work area environment.
Dress and protective equipment
5. Wear protective equipment; safety glasses, safety
shoes, dust mask and helmet. Even with the Dust
Bag tted, damaged blades or hot debris can y
out of the cover, resulting in personal injury.
6. Dress properly. Do not wear a tie, loose clothing or
knit gloves. Keep hair covered with a hair cover or
a cap to be away from rotating blades.
Before use
7. Ensure that Tipped Saw Blades are not deformed,
chipped, cracked or worn-out. Do not use a Tipped
Saw if any damage or wear is found. Cutting under
such conditions may cause further damage to the
blades and serious personal injury.
8. Do not use the Tipped Saw for any application
other than that stated in the tool specication.
Using the Tipped Saw for other applications can
cause excessive wear, detachment of blades, low
cutting performance and abnormal generation of
heat, resulting in damage to the blades and seri-
ous personal injury.
Tipped saw replacement
9. When replacing the Tipped Saw, ensure that the
battery is removed from the tool to prevent acci-
dental operation and personal injury.
10. Ensure there is no one in the surroundings before
operation and no abnormal sounds or abnormal
vibrations occur when operating. Operating with
abnormal sounds or abnormal vibrations can dam-
age the blades resulting in serious personal injury.
During operation
11. Do not use the Tipped Saw for any purpose other
than cutting. Do not subject the blades to damage
or stress. It can break the blades resulting in seri-
ous personal injury.
12. Hold the material rmly, in a vice or similar, so
that it cannot move when cutting. If the material
moves, the operation becomes unstable and
cannot be controlled, resulting in damage to the
blades and possible serious personal injury.
13. Start cutting only after the Tipped Saw has
reached maximum speed. If the Tipped Saw is set
against the material before the motor is started,
the blades will be overloaded and damaged,
resulting in possible serious personal injury.

9ENGLISH
14. Do not cut in zigzags, curves, diagonals, or use
the side of the blade to prise or for any other
purpose.
15. If during cutting, there is an abnormal sound,
abnormal vibration, or if the cutting parts are badly
worn, stop operation.
Continuing the operation under such conditions
will damage the Tipped Saw blades with the result
that chips may be ejected causing serious per-
sonal injury.
16. Continuous operation makes the Tipped Saw
blades hot and reduces the cutting performances.
Maintenance
17. If there is deformation, a crack or damage on the
Tipped Saw, stop the operation. Continuing the
operation under such conditions will further dam-
age the Tipped Saw which may break up. Ejected
broken parts can cause serious personal injury.
18. Only keep and use Tipped Saws that are in good
condition and the blades sharp and clean.
WARNING: Always wear protective equip-
ment; safety glasses, safety shoes, dust mask
and helmet.
WARNING: Use only Makita supplied Tipped
Saw. Using non Makita parts may damage the tool
and can result in serious accident or injury.
Important safety instructions for
battery cartridge
1. Before using battery cartridge, read all instruc-
tions and cautionary markings on (1) battery
charger, (2) battery, and (3) product using
battery.
2. Do not disassemble battery cartridge.
3. If operating time has become excessively
shorter, stop operating immediately. It may
result in a risk of overheating, possible burns
and even an explosion.
4. If electrolyte gets into your eyes, rinse them
out with clear water and seek medical atten-
tion right away. It may result in loss of your
eyesight.
5. Do not short the battery cartridge:
(1) Do not touch the terminals with any con-
ductive material.
(2) Avoid storing battery cartridge in a con-
tainer with other metal objects such as
nails, coins, etc.
(3) Do not expose battery cartridge to water
or rain.
A battery short can cause a large current
ow, overheating, possible burns and even a
breakdown.
6. Do not store the tool and battery cartridge in
locations where the temperature may reach or
exceed 50 °C (122 °F).
7. Do not incinerate the battery cartridge even if
it is severely damaged or is completely worn
out. The battery cartridge can explode in a re.
8. Be careful not to drop or strike battery.
9. Do not use a damaged battery.
10. The contained lithium-ion batteries are sub-
ject to the Dangerous Goods Legislation
requirements.
For commercial transports e.g. by third parties,
forwarding agents, special requirement on pack-
aging and labeling must be observed.
For preparation of the item being shipped, consult-
ing an expert for hazardous material is required.
Please also observe possibly more detailed
national regulations.
Tape or mask off open contacts and pack up the
battery in such a manner that it cannot move
around in the packaging.
11. Follow your local regulations relating to dis-
posal of battery.
SAVE THESE INSTRUCTIONS.
CAUTION: Only use genuine Makita batteries.
Use of non-genuine Makita batteries, or batteries that
have been altered, may result in the battery burst-
ing causing res, personal injury and damage. It will
also void the Makita warranty for the Makita tool and
charger.
Tips for maintaining maximum
battery life
1. Charge the battery cartridge before completely
discharged. Always stop tool operation and
charge the battery cartridge when you notice
less tool power.
2. Never recharge a fully charged battery car-
tridge. Overcharging shortens the battery
service life.
3. Charge the battery cartridge with room temper-
ature at 10 °C - 40 °C (50 °F - 104 °F). Let a hot
battery cartridge cool down before charging it.
4. Charge the battery cartridge if you do not use
it for a long period (more than six months).
PART NAMES
► Fig.1: 1. Battery 2. Motor 3. Dust Bag Holder
4. Outlet 5. Guide 6. Tipped Saw 7. Handle
8. Lock Button 9. Switch

10 ENGLISH
Installing or removing battery
cartridge
CAUTION: Always be sure that the tool is
switched off and the battery cartridge is removed
before adjusting or checking function on the tool.
CAUTION: Always switch off the tool before
installing or removing of the battery cartridge.
CAUTION: Hold the tool and the battery car-
tridge rmly when installing or removing battery
cartridge. Failure to hold the tool and the battery
cartridge rmly may cause them to slip off your hands
and result in damage to the tool and battery cartridge
and a personal injury.
► Fig.2: 1. Button 2. Red indicator 3. Battery cartridge
To remove the battery cartridge, slide it from the tool
while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the
battery cartridge with the groove in the housing and slip
it into place. Insert it all the way until it locks in place
with a little click. If you can see the red indicator on the
upper side of the button, it is not locked completely.
CAUTION: Always install the battery cartridge
fully until the red indicator cannot be seen. If not,
it may accidentally fall out of the tool, causing injury to
you or someone around you.
CAUTION: Do not install the battery cartridge
forcibly. If the cartridge does not slide in easily, it is
not being inserted correctly.
Battery protection system (Lithium-
ion battery with star marking)
► Fig.3: 1. Star marking
Lithium-ion batteries with a star marking are equipped
with a protection system. This system automatically
cuts off power to the tool to extend battery life. The tool
will automatically stop during operation if the tool and/or
battery are placed under one of the following conditions:
Overloaded:
The tool is operated in a manner that causes it to draw
an abnormally high current. In this situation, release the
trigger switch on the tool and stop the application that
caused the tool to become overloaded. Then pull the
trigger switch again to restart. If the tool does not start,
the battery is overheated. In this situation, let the bat-
tery cool before pulling the trigger switch again.
Low battery voltage:
The remaining battery capacity is too low and the tool
will not operate. In this situation, remove and recharge
the battery.
OPERATING
PROCEDURE
WARNING: Before the battery is inserted into
the tool, ensure that the Switch is at the “O” posi-
tion and the Switch is off.
CAUTION: Push the Lock Button and ensure
that the Button comes up when it is released.
If the Lock Button will not come up when it is
released, the Tipped Saw will be prevented from
rotating when the tool is operated resulting in
damage to parts and the motor to burn out.
CAUTION: Slide the Switch to the “l” posi-
tion and ensure it stays there and does not move.
Then push down on the rear of the Switch to
ensure that the Switch moves to the “O” position
automatically.
CAUTION: Ensure that the bolts retaining the
Tipped Saw Cover and all other bolts are tight-
ened rmly.
► Fig.4: 1. Handle Position (parallel / left side) 2. Lock
Button 3. Handle Position (parallel / right
side) 4. Switch 5. Handle Position (vertical /
upper side)
Operation
► Fig.5: 1. Guide 2. Rebar
► Fig.6: 1. Rebar 2. Guide
1. Screw the Handle into threaded hole at the vertical
or parallel position for easier operation.
2. Ensure that the Switch is at “O” position.
CAUTION: As a safety function of this tool,
the Motor cannot be energised when the battery is
inserted with the Switch at “l” position. For fur-
ther safety, please note that the battery should be
inserted with the Switch at “O” position.
3. Insert the battery into the tool.
4. Slide the Switch to “l” position. The motor is on.
Then push down on the forward end of the Switch to
lock it for operating continuously.
WARNING: Do not touch the rotating parts as
they can cause serious injury.
5. Position the Guide in the opening against the
rebar.
Then push the tool forward slowly to start to cut
the rebar.
CAUTION: When cutting, both at the begin-
ning and near the end, slow down the tool’s for-
ward (cutting) movement. A fast cutting action, at
these times, will damage the Tipped Saw blades
and can cause injury from ying debris.
