USER’S GUIDE
OBHDUAL
The features described in this user’s guide are subject to modifications without prior notice.
Smart HD Dual Camera with narrow/wide angle viewing
and motion tracking
Welcome...
to your new Smart HD Dual Camera!
Thank you for purchasing the Smart HD Dual Camera. Featuring patent-
pending dual cameras for simultaneous narrow and wide-angle viewing from
the same unit. Using AI Motion Tracking, the bottom camera automatically
follows the movement by panning and tilting, allowing parents to keep an
eye on their little one as they move around the room. The ConnectChat™
feature allows for easy two-way communication between parent and child.
Control all features, and much more, on the HubbleClub for Partners App.
Download for free and enjoy exciting perks like HubbleClub for Partners
App Community, the Baby Growth Tracker, and notifications when sound,
motion, or temperature fluctuations are detected.
Please keep your original dated sales receipt for your records. For warranty
service of your Oricom product, you will need to provide a copy of your
dated sales receipt to confirm warranty status. Registration is not required
for warranty coverage.
For product related questions, please contact:
Australia:
(02) 4574 8888 / Monday - Friday 8am – 6pm AEST
New Zealand:
0800 674 266 / Monday - Friday 10am - 8pm NZST
Email: [email protected]
Visit www.oricom.com.au to download the User Guide with instructions,
answers to frequently asked questions, and more to help you get the most
from your product.
Inside the Box
• 1 x Baby Unit (Camera Unit)
• 1 x Wall Mount
• 1 x Power Adaptor
Overview of Camera Unit
Important guidelines for installing your Smart Camera
• Use of other 2.4 GHz products, such as other wireless networks, BT™ systems
or microwave ovens may cause interference with this product. Keep the Wi-
Fi® Camera Unit away from these types of products, or turn them OFF if they
appear to be causing interference.
• Always ensure that you have a good Wi-Fi® connection available.
1. Speaker
2. Infrared LEDs (x6, top Camera
for night vision)
3. Camera Lens (top Camera)
4. High Sensitivity Microphone
5. Infrared LEDs (x8, bottom
Camera for night vision)
6. Camera Lens (bottom Camera)
7. Light Sensor (Night Vision Mode)
8. Temperature Sensor
9. ConnectChat™ button
10. Power indicatior
11. Talk back / ConnectChat™
indicatior
12. Wall Mount
13. Lock Screw
14. Adjusting Nut
15. Power Socket
16. Rubber pads
17. PAIR button
18. Universal Mounting Thread
19. Rubber pad
1
2
3
4
5
6
7
11
10
98
12
13
17
18
15
19
16
14
Bottom View of
Baby Unit
4
Table of contents
Table of contents
1. Safety Instructions ............................................................................... 5
2. Getting Started ..................................................................................... 7
2.1 Connecting the Power Supply for the Camera Unit ..........................7
2.2 (Optional) Fixing the wall mount to the wall .....................................7
3. Using the Camera Unit ......................................................................... 8
3.1 Setting Up..........................................................................................8
3.2 Night Vision Mode.............................................................................8
3.3 ConnectChat™ .................................................................................8
3.4 Remote Pan and Tilt...........................................................................9
3.5 AI Motion Tracker...............................................................................9
4. Wi-Fi® Internet Viewing ..................................................................... 10
4.1 Minimum System Requirements ......................................................10
4.2 Getting started - Connecting Devices .............................................10
4.3 Setup................................................................................................11
4.4 User Account and Camera Setup on Android™ Devices or iPhone®/
iPad® ...............................................................................................11
4.4.1 Power ON and Connect the Camera....................................11
4.4.2 Download HubbleClub for Partners App.............................. 11
4.4.3 Sign up with Hubble on your smart device...........................12
4.4.4 Add the Camera to your account ........................................13
5. Disposal of the Device (environment) ............................................ 16
6. Cleaning and reseting the camera ................................................. 17
7. Help.......................................................................................................... 18
8. General Information ........................................................................... 24
9. Technical Specifications .................................................................... 28
5
Safety Instructions
1. Safety Instructions
WARNING:
Strangulation hazard. Children have
STRANGLED on cords. Keep this cord out
of the reach of children (more than 1 meter
away). Never use extension cords with AC
adaptors. Only use the AC adaptor provided.
6Safety Instructions
CAMERA UNIT SET UP & USE:
• Choose a location for the Camera Unit that will provide the best
view of your baby in his/her cot.
• Place the Camera Unit on a flat surface, such as a dresser, bureau
or shelf, or mount the Camera Unit on a wall securely using the
keyhole slots in the underside of the stand.
• NEVER place the Camera Unit or cords within the cot.
WARNING
This Smart camera is compliant with all relevant standards regarding
electromagnetic fields and is, when handled as described in the User’s
Guide, safe to use. Therefore, always read the instructions in this User’s
Guide carefully before using the device.
• Adult assembly is required. Keep small parts away from children when
assembling.
• This product is not a toy. Do not allow children to play with it.
• Keep this User’s Guide for future reference.
• Keep the cords out of reach of children.
• Do not cover the Smart camera with a towel or blanket.
• Do not use the Smart camera in damp areas or close to water.
• Do not install the Smart camera in extreme cold or heat, direct sunlight, or
close to a heat source.
• Only use supplied power adaptors. Do not use other chargers or power
adaptors as this may damage the device.
• Do not touch the plug contacts with sharp or metal objects.
• Connect the power adaptors to easily accessible electrical sockets.
7
Getting Started
2. Getting Started
2.1 Connecting the Power Supply for the Camera Unit
• Insert the DC plug of the power adaptor into
the DC socket on the back of the Camera
Unit.
• Connect the other end of the power adaptor
to a suitable electrical outlet.
• The camera will power up automatically, the
power indicating LED will illuminate in green.
Note:
ONLY USE THE SUPPLIED POWER ADAPTOR
(DC5V/2A).
2.2 (Optional) Fixing the wall mount to the wall
• Use (2) wall anchors and (2) screws (not supplied) suitable for the type of
wall the wall mount will be installed on.
• Place Camera on wall mount as shown and fasten the lock screw, make
sure the unit is attached securely and rmly to the wall mount.
• Power on the Camera and adjust the angle to select the best view on
your smart device.
8Using the Camera Unit
3. Using the Camera Unit
3.1 Setting Up
Mount the camera in a convenient / safe location and point the camera lens
towards the area you want to monitor. Adjust the angle of the camera until
you are satised with the image shown in the Hubble Club for Partners App.
Note:
Do not place the Camera Unit within the baby’s reach! If there is inter-
ference with the picture or sound, try moving the camera to different
locations, and ensure the camera is not close to other electrical equipment.
3.2 Night Vision Mode
The camera has 8 high-intensity infrared LEDs for picking up clear images in
the dark. When the built-in light sensor on the top of the unit detects a low
level of ambient light, the LEDs will automatically activate and the image will
display in black and white.
3.3 ConnectChat™
The ConnectChat™ feature allows for easy two-way communication
between parent and child. When the ConnectChat™ button on the base
of the baby unit is pressed, the device immediately creates a one-way audio
call with the HubbleClub for Partners App.
1. Press Connect Chat button（ （for 1 second, the indicator blinks Green
and a dialing tone is heard.
2. If the call is rejected or not answered the indicator blinks Green and a
voice prompt announces “your parents are busy at the moment, please
try after some time".
3. Press Connect Chat button （for second to hang up the call, the Green
indicator is now OFF.
Note:
Before using ConnectChat™ feature, you will need to connect the camera
to the HubbleClub for Partners App.
9
Using the Camera Unit
3.4 Remote Pan and Tilt
The bottom camera can be remotely controlled from the APP.
1. Press the +UP button or - DOWN button to tilt upward or downward.
2. Press the <LEFT button or >RIGHT button to pan left or right.
Note:
The top camera is manually controlled by rotating the camera towards the
required image.
3.5 AI Motion Tracker
Using AI Motion Tracking, the bottom camera automatically follows the
movement by panning and tilting, allowing parents to keep an eye on their
little one as they move around the room.
This can be activated in the Hubble Club for Partners App.
10 Wi-Fi® Internet Viewing
4. Wi-Fi® Internet Viewing
4.1 Minimum System Requirements
Android™ System
• Version 8.0 or above
iPhone®/iPad® iOS
• Version 12.0 or above
High Speed (Wi-Fi®) Internet
• At least 0.6 Mbps upload bandwidth per camera (you can test your
internet speed on this site: http://www.speedtest.net)
4.2
Getting started - Connecting Devices
How does it work?
Access your
Camera locally
View your Camera from any
compatible device remotely
Wi-Fi RouterWi-Fi®
Camera
Hubble
Service
When a user tries to access the Camera, our Hubble server authenticates
the user’s identity and permits access to the Camera.
