Audio Link
Quick User Guide
2
Audio Link Instruction
Content
Audio Link device
Micro USB Charging Cable
USB Power Adaptor
3.5mm Phone Jack Cable
3
AP Mode
Factory default is AP Mode that iPhone, iPad or Android device connect to Audio Link directly, but your device is no Internet function.
4
Client Mode
Audio Link can connect to your home WiFi network and suggest using this mode.
Note:Don’tconnecttopublicormessnetworkenvironment.AudioLinkisfit
toconnecttobesimpleandcleannetworkenvironment.
5
Set up Audio Link
1. Please Audio Link placed to location of good WiFi network signal in home
2. Please connect power USB adaptor with Micro USB charging cable to Audio Link.
Then power button will display RED light and please press power button which will display GREEN light.
Audio Link
Micro USB Charging Cable
Power USB Adaptor
6
3. Connect Audio Link to your Hi-Fi or power speaker with audio output (AUX or S/PDIF). Setup is done.
4. Go to wifi setting on your iPhone, iPad or Android device > Choose Audio Link from the list of available network and connect it.
S/PDIF Output3.5mm Audio Output
Note:Volumeup/downiscontrolledbyamplifier.
7
8
5. Your smartphone/table download QR Code application first from Apple Store/Google Play. And scan QR Code on back of Audio
Link with your smartphone/table. You are viewing Audio Link's setting page from your smartphone/tablet. (Or type 192.168.0.1 in
the browser and you’re also viewing Audio Link’s setting page.)
SetupQRCode:
ScanthisQRcodetoentry
AudioLink’ssetting
page.(192.168.0.1)
9
6. Please follow the screen instruction step by step. Choose your home WiFi network and Audio Link is going to connect to your
home WiFi network that it means your iOS/Android device is connected to in the same network then you’ll enjoy streaming music.
7. Rename Device, you can change Audio Link name or enter password.
10
11
[iOS/Airplay] Streaming Music
Tap “Music” on your iPhone, iPad or iPod touch > Tap “Airplay” icon > Choose “Audio Link”
Music will play via Audio Link.
12
[Android/DLNA] Streaming Music
Samsung, HTC and Sony user can use music application built-in and no need to download application. And the other brands can
download “Total Media” or “Bubble UPnP” app from Google Play.
Tota lMediaApp:
SelectMusic>ChooseAudioLink>play
Samsung:
SelectMusic>ChooseAudioLink>play
13
[Windows XP/WIN7/WIN8/Mac] Streaming Music
You can select iTunes or Windows Media Player application to stream music.
Open “iTunes” on your Mac/PC > Click “AirPlay” icon and choose Audio Link > Play
14
Windows Media Player >open media streaming options > select music > play to Audio Link
15
Specification
Power Button (ON/OFF)
Reset
3.5mm phone jack
S/PDIF
Micro USB port
I/O port
Direct Link (AP)/ Network Link (Client) Mode switch
Indicate LED LED ( Green light : ON ; Red light : OFF )
Power Supply 5V 1A
WiFi Standard IEEE 802.11b/g/n compatible WLAN
Protocol AirPlay, DLNA 1.5, Digital Media Renderer, UPnP,
DHCP
Audio Format MP3, AAC, WAV, WMA, FLAC, ALAC, M4A
Dimension 84.2X30X78.5 mm
16
How to upgrade Firmware
Step1. Download the Firmware from official support web site.
Step2. Unzip the file.
Step3. Connect to Audio Link on PC/Mac and open browser (IE or Google Chrome) and enter http://192.168.0.1 to access the Audio
Link’s setting page when Audio Link’s switch is Direct Link (AP) Mode.
Step4. Choose your location of Firmware file and please click “Upload”.
Step5. Audio Link will display loading icon that means it’s upgrading. Loading icon will disappear once it complete to upgrade.
Then Audio Link will reboot 50 seconds automatically. PC/Mac connect to Audio Link and access Audio Link’s setting page again
then check whether release the Firmware version to be latest at left corner.
IMPORTANT: Please do NOT interrupt firmware upgrade. Any interruption during the process may cause unexpected results.
Or if upgrade to fail, please try to upgrade it again.
Note: Temporarily disable firewalls (both network and local) and security software. Security software and firewalls may block ports that Audio
Link device access Audio Link’s setting page. You can often resolve issues with security software by updating,
17
Federal Communication Commission Interference Statement
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttoPart15oftheFCCRules.These
limitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.
Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,may
causeharmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.
Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffand
on,theuserisencouragedtotrytocorrecttheinterferencebyoneofthefollowingmeasures:
.Reorientorrelocatethereceivingantenna.
.Increasetheseparationbetweentheequipmentandreceiver.
.Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
.Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:
(1)Thisdevicemaynotcauseharmfulinterference,and(2)Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay
causeundesiredoperation.
FCCCaution:Toassurecontinuedcompliance,anychangesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliance
couldvoidtheuser'sauthoritytooperatethisequipment.(Example‐useonlyshieldedinterfacecableswhenconnectingtocomputeror
peripheraldevices).
FCCRadiationExposureStatement
18
ThisequipmentcomplieswithFCCRFradiationexposurelimitssetforthforanuncontrolledenvironment.Thisequipmentshouldbeinstalled
andoperatedwithaminimumdistanceof20centimetersbetweentheradiatorandyourbody.
Thistransmittermustnotbeco‐locatedoroperatinginconjunctionwithanyotherantennaortransmitter.
Theantennasusedforthistransmittermustbeinstalledtoprovideaseparationdistanceofatleast20cmfromallpersonsandmustnotbe
co‐locatedoroperatinginconjunctionwithanyotherantennaortransmitter.
