OS 22112 User manual

OS
home office
furniture
&
22112

2
Thank you for purchasing this quality product. Please be sure to check all packing
material carefully for small parts which may have came loose inside the carton
during shipment. Count all parts and hardware and compare with the parts list to
be sure all parts are present. If any parts are missing or damaged, phone, fax or
email to our Customer Service Department. For efficient and speedy service
please indicate the model number and code letter of part(s) needed.
If you have any damaged or missing parts please contact us at:
OS Home & Office Furniture
1011a Gulf
Lamar, MO 64759
417 682 5522
417 682 5524 fax
[email protected]
IMPORTANT NOTE: Follow instructions listed below in proper sequence as
numbered to assure fast, easy and correct assembly.

hardware
(P) x 2
drawer pull
(Q) x 4
3/4”round-head screw
(R) x 10
big cam bolt
(T) x 8
1 1/4”x 1/4”dia wood
dowel with ridges
(S) x 10
big cam lock
(V) x 10
small cam lock
(W) x 24
1 1/4”x 3/8”dia wood
dowel with ridges
(Y) x 42
1/2”flat-head screw
(X) x 4
three ball bearing slide
(Bb) x 10
1 3/8”flat-head screw
(Aa) x 4
plastic file hanger
(Z) x 2
glue
(Ee) x 14
9/16 ”round-head screw
(Cc) x 2
1/2”round-head screw
(Ff) x 2
plastic anti-tip hardware
(U) x 10
small cam bolt
(Dd) x 1
anti-tip hardware
(Gg) x 1
lock
(Hh) x 2
lock plate
(Kk) x 2
plastic file hanger
(Ii) x 1
lock bar
(Ll) x 2
plastic file hanger
(Jj) x 4
plastic file hanger
3

ITEM DESCRIPTION QUANTITY
4
A
left panel
right panel
bottom panel
bottom rail
back rail
back panel
upper drawer front
drawer left
drawer back
drawer right
drawer bottom
drawer support rail
drawer pull
lower drawer front
big cam bolt
bottom panel
top panel
big cam lock
1 1/4”x 1/4” dia wood
dowel with ridges
small cam bolt
small cam lock
1 1/4”x 3/8”dia wood
dowel with ridges
three ball bearing slide
1/2”flat-head screw
3/4”round-head screw
glue
1
1
1
1
1
2
1
1
1
1
2
2
2
4
10
8
10
2
2
2
10
10
4
42
2
4
A
B
C
D
E
F
G
H
I
J
K
L
N
Q
S
T
V
M
O
P
R
U
W
X
Y
Z
Aa
1 3/8”flat-head screw
Bb
1/2”round-head screw 2
Cc
1
Dd
9/16”round-head screw 14
Ee
2
Ff
1
Gg
lock plate 2
Hi
1
Ii
plastic file hanger
4
Jj
2
Kk
2
Ll
B
C
G
H
I
J
K
L
M
N
O
D
E
F
F
KL
O
M
N
24
10
anti-tip hardware
plastic anti-tip hardware
lock
lock bar
plastic file hanger
plastic file hanger
plastic file hanger

1. 2. 3.
4. 5.
how to use the cam lock system
180º
5

step 1.
C
R
R
R
Ii
Y
Y
(R) x 3
big cam bolt
(Y) x 8
1/2”flat-head screw
(Ii) x 1
lock bar
6
1.Install big cam bolts (R) into right panel C.
2.Install lock bar (Ii) using screws (Y).
Front Edge
Top Edge

step 2.
7
X
X
Y
Y
(X) x 2
three ball bearing slide
(Y) x 8
1/2”flat-head screw
C
1.Separate the drawer slide by pressing lock lever as shown in diagram A.
2.Attach drawer slide to panel C using the holes noted in diagram B.
Diagram A
Diagram B

step 3.
X
Y
Y
R
R
R
(R) x 3
big cam bolt
(Y) x 8
1/2”flat-head screw
(X) x 2
three ball bearing slide (Cc) x 2
1/2”round-head screw
(Dd) x 1
anti-tip hardware
Cc
Dd
X
B
8
Diagram A
Diagram B
1.Attach big cam bolts (R) to left panel (B).
2.Attach drawer slides to panel (B) using the holes noted in diagram B.
3.Attach anti tip hardware (Dd) using screws (Cc).

step 4.
9
(W) x 2
1 1/4”x 3/8”dia wood
dowel with ridges
E
F
W
1.Attach parts E and F using dowels & glue.
(Z) glue
Z

step 5.
D
F
(W) x 2
1 1/4”x 3/8”dia wood
dowel with ridges
W
10
1.Attach parts D and F using dowels & glue.
(Z) glue
Z

step 6.
11
B
C
G
EF
F
D
W
S
(S) x 6
big cam lock
(W) x 14
1 1/4”x 3/8”dia wood
dowel with ridges
S
W
W
S
1.Glue dowels into both ends of parts E,F,G and D.
2.Place big cam locks (S) into both ends of parts D,E and G.
3.Carefully assemble as shown,tightening cam locks as you go.
(Z) glue
Back Edge Bottom Edge
Z

step 7.
A
W
R
SH
(R) x 4
big cam bolt
(S) x 4
big cam lock
(W) x 6
1 1/4”x 3/8”dia wood
dowel with ridges
W
12
1.Slide back panel into grooves.
2.Insert big cam bolts (R) and glue dowels (W) into underside of top panel A.
3.Insert big cam locks (S) and a little glue into the top edge of left panel (B) and right panel (C).
4.Place top panel (A) into place and tighten cam locks.
(Z) glue
Z

step 8.
X2
K
M
Y
X
Hh
(X) x 4
three ball bearing slide
(Y) x 16
1/2”flat-head screw
13
X
Y
Y
(Hh) x 2
lock plate
1.Attach drawer slides to drawer left (K) and drawer right (M) using screws (Y) using the holes noted in diagram C.
2.Attach lock plate (Hh) to drawer right (M) as shown.
3.Repeat process for remaining left and right drawer sides.
Groove
Groove
Diagram C

step 9.
1.Attach parts K and M to drawer back (L) using screws (Bb).
(Bb) x 8
1 3/8”flat-head screw
Bb
K
M
L
Bb
14
Groove
Groove
Groove

step 10.
1. Attach drawer support rail (O) to drawer back (L) using screw (Bb).
2. Slide drawer bottom (N) into grooves.
3. Attach plastic anti tip hardware (Ff) to drawer left (K) using screw (Ee).
* Note,part (Ff) goes below the slide on one drawer and above the slide on the other drawer.
(Bb) x 2
1 3/8”flat-head screw
(Ee) x 4
9/16 ”round-head screw
(Ff) x 2
plastic anti-tip hardware
Ff
K
M
L
N
O
Ee
Bb
Ee Ff
K
M
L
N
O
Bb
15

I
J
Ll
Ll
step 11.
(Ee) x 10
9/16 ”round-head screw
Ee
Ee
(Ll) x 2
plastic file hanger
U
U
(U) x 10
small cam bolt
16
1.Install glue and small dowels (T) to drawer fronts (I) and (J).
2.Attach plastic file hanger (Ll) to drawer front.
3.Install small cam bolts (U) to drawer fronts (I) and (J).
(T) x 8
1 1/4”x 1/4”dia wood
dowel with ridges
(Z) glue
U
T
U
T
Z

I
J
V
VQ
P
Q
P
step 12.
(V) x 10
small cam lock
(P) x 2
drawer pull
(Q) x 4
round-head screw
17
1. Attach drawer pull (P) to front with screw (Q).
2. Install small cam lock (U) into drawer sides.
3. Attach top drawer front (J) to drawer assembly with plastic anti tip hardware below the slide.
4. Carefully tighten all 5 small cam locks.
5. Attach bottom drawer front (I) to drawer assembly with plastic anti tip hardware above the slide.
6. Carefully tighten all 5 small cam locks.
Top drawer
Bottom drawer

Gg
Y
Kk
Jj
Kk
Jj
step 13.
1. Remove washer from lock (Gg) and attach with screws (Y) per diagram D.
2. Install plastic file hanger (Jj) and (Kk) as shown.
(Y) x 2
1/2”flat-head screw
(Gg) x 1
lock
(Kk) x 2
plastic file hanger
(Jj) x 4
plastic file hanger
18
Jj
Jj
Diagram D
Y
Gg

step 14.
1. Install plastic file hanger (Mm) as shown.
(Aa) x 4
plastic file hanger
19
Aa
Aa

I
step 15.
1. Swing bottom tab of anti tip hardware (Dd) to the front as shown in diagram E.
2. Slide the bottom drawer into the corresponding slides on the cabinet.
20
Diagram E
