OSP furniture DESIGNlab LDT5454GLD User manual

IMPORTANT-PLEASE KEEP THESE INSTRUCTIONS IN CASE OF ANY CUSTOMER SERVICE ISSUES
IMPORTANT-PLEASE KEEP THESE INSTRUCTIONS IN CASE OF ANY CUSTOMER SERVICE ISSUES
Model Number: JN02-03-22k
© Office Star Products September 2020
LDT5454GLD (SF)
LOADOUT L-SHAPED GAMING DESK
ASSEMBLY INSTRUCTIONS
OSP FURNITURE LIMITED PRODUCT WARRANTY
Design Lab Products
• 3 years on gaming desks and chairs
• Upholstery is not warranted against routine scratching and scuffing
*All warranties are limited to the original purchaser for normal commercial usage defined as a standard forty hour work week by persons weighing 250 lbs. or
less. This warranty will not cover labor, freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other
event beyond the control of Office Star Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or
consequential damages is excluded. The user assumes all risk of injury resulting from use of this product. When usage is more than 40 hours per week, a two
year warranty on all parts applies. Fabric and foam is warranted for one year. This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
It is the customer’s responsibility to prepay freight on any components returned to the factory. Return freight on components covered by warranty
will be paid by Office Star Products.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts are damaged or missing. Our
Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail parts@officestar.net, by Fax [phone], or toll free
parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00 p.m. Pacific Time.
WARNING
1. Use this product only one person at a time.
2. Do not use this product unless all bolts screws and knobs are
securely tightened.
3. Check that all bolts screws and knobs are tight every three
months or as needed.
4. Do not overturn back tilt knob when decreasing tension.
5. Dispose of packing material properly. Do not use plastic cover as
head covering. It may cause suffocation.
6. Do not use product as a stepladder.
7. Use this product for its intended purpose only.
8. Use mild detergent only for cleaning.

HARDWARE LIST
NO DRAWING DESCRIPTION SIZE QUANTITY
AGlue 1 PC
8 PCS
17 PCS
17 PCS
1 PC
15 PCS
4 PCS
16 PCS
4 PCS
Wooden Dowel
Cam Screw
Cam Nut
Allen Wrench
Allen Bolt
Allen Bolt
Allen Bolt
Allen Bolt
Ø
Ø
Ø
Ø
Ø
6 x 12 x 10mm
6 x 32 x 10mm
6 x 25 x 10mm
6 x 45 x 10mm
B
C
D
E
F
G
I
2 PCSWood Screw 4 x 12 x 8mmJ
2 PCSWood Screw 3.5 x 12 x 6mmK
13 PCSFlat Head Allen Bolt 6 x 32 x 10mmL
H
(1) Left Top Shelf (1 PC) (2) Right Top Shelf (1 PC)
PARTS
180°
CAM LOCK INSTALLATION
Screw Cam Screw in. Fully Tighten.
Align hole in panel with Cam Screw.
Screw Cam Nut in. Turn clock-wise until
you feel Cam Nut securely fasten to
Cam Screw. Fully tighten Cam Nut.
Phillips Screwdriver also needed for assembly (not provided).

PARTS
(15) Power Outlet (1 PC)
(17) Middle Upper Frame (1 PC)
(16) Remote Control (1 PC)
(18) Rear Leg (1 PC)
(19) LED Power Supply (1 PC) (20) Rear Lower Crossbar (2 PCS)
(21) Left Front Crossbar (1 PC)
(23) Left Upper Crossbar (1 PC)
(25) Storage Tray (1 PC)
(22) Right Front Crossbar (1 PC)
(24) Right Upper Crossbar (1 PC)
PART
(3) Left Desktop (1 PC)
(5) Left Side Frame (1 PC)
(4) Right Desktop (1 PC)
(6) Right Side Frame (1 PC)
(7) Left Back Panel (1 PC) (8) Right Back Panel (1 PC)
(9) Rear Frame (2 PCS)
(11) Right Upper Frame (1 PZ)
(10) Left Upper Frame (1 PC)
(12) Accessory Hook (1 PC)
(13) Cup Holder (1 PC) (14) Wireless Charger (1 PC)
TOP

Remove all the parts from carton, separate them into part numbers indicated on the list and make sure part quantities are correct.
STEP 1 Screw in six Cam Screws (C) into Left Desktop (3), three Cam Screws (C) into Right Desktop (4) and two Cam Screws (C) into both
Left Side Frame (5) and Right Side Frame (6). FULLY TIGHTEN ALL CAM SCREWS (C).
STEP 2 Insert four Wooden Dowels (B) into both Left Back Panel (7) and Right Back Panel (8). Use a small amount of Glue (A) for each dowel hole. Screw
in four Cam Screws (C) into Rear Leg (18). FULLY TIGHTEN ALL CAM SCREWS (C).
STEP 3 Attach Left Side Frame (5) and Rear Leg (18) to Left Back Panel (7) and secure using four Cam Nuts (D). FULLY TIGHTEN CAM NUTS (D).
Attach Rear Lower Crossbar (20) to Rear Frame (9) using two Allen Bolts (I). FULLY TIGHTEN ALLEN BOLTS (I).
STEP 4 Attach Right Back Panel (8) between Right Side Frame (6) and Rear Leg (18) and secure using four Cam Nuts (D). FULLY TIGHTEN CAM
NUTS (D).
LDT5454GLD (SF)
LOADOUT L-SHAPED GAMING DESK
ASSEMBLY INSTRUCTIONS
LDT5454GLD (SF)
LOADOUT L-SHAPED GAMING DESK
ASSEMBLY INSTRUCTIONS
3
C
STEP 1
STEP 2
C
4
C
5
C
6
C
18
B
8
7
B
STEP 4
9
7
5
STEP 3
18
D
20 I
D
18
6
8
x2

LDT5454GLD (SF)
LOADOUT L-SHAPED GAMING DESK
ASSEMBLY INSTRUCTIONS
STEP 5 Secure top end of Rear Frames (9) to Left Back Panel (7) and Right Back Panel (8) using two Allen Bolts (G) for each Rear Frame (9). Secure Rear
Lower Crossbars (20) using two Allen Bolts (F) for each Rear Lower Crossbar (20). FULLY TIGHTEN ALL BOLTS (F & G).
STEP 6 Secure Left Front Crossbar (21) between Left Side Frame (5) and Right Back Panel (8) using two Allen Bolts (F) and one Allen Bolt (H). FULLY
TIGHTEN ALL ALLEN BOLTS (F & H).
LDT5454GLD (SF)
LOADOUT L-SHAPED GAMING DESK
ASSEMBLY INSTRUCTIONS
STEP 7 Secure Right Front Crossbar (22) between Right Side Frame (9) and Left Front Crossbar (21) using two Allen Bolts (F) and one Allen Bolt (H).
FULLY TIGHTEN ALL BOLTS (F & H).
STEP 8 Attach Left Desktop (3) to assembly and secure to Right Back Panel (8) using six Cam Nuts (D). Secure to Left Side Frame (5) using two Allen
Bolts (F) and secure to Left Front Crossbar (21) using four Allen Bolts (H). FULLY TIGHTEN ALL CAM NUTS (D) AND ALL ALLEN BOLTS (F & H).
STEP 6
STEP 7
F5
8
F
22
H
STEP 8
D
H
F
21
21
H
5
8
3
STEP 5
F
9
G
6
8
F
7
5
20
9
F
20
21
6
21
6

LDT5454GLD (SF)
LOADOUT L-SHAPED GAMING DESK
ASSEMBLY INSTRUCTIONS
STEP 9 Attach Right Desktop (4) to assembly and secure to Left Back Panel (7) using three Cam Nuts (D). Secure to Right Side Frame (6) using two Allen
Bolts (F) and secure to Right Front Crossbar (22) using three Allen Bolts (H). FULLY TIGHTEN ALL CAM NUTS (H) AND ALL ALLEN BOLTS (F & H).
STEP 10 Attach Cup Holder (13), Wireless Charger (14) and Storage Tray (25) to desktop. Secure Power Outlet (15) to desktop using two Wood
Screws (K). Secure Accessory Hook (12) to side of desk using two Wood Screws (J). FULLY TIGHTEN ALL WOOD SCREWS (J & K).
LDT5454GLD (SF)
LOADOUT L-SHAPED GAMING DESK
ASSEMBLY INSTRUCTIONS
STEP 11 Secure Left Upper Frame (10), Right Upper Frame (11) and Middle Upper Frame (17) to rear of assembly using two Allen Bolts (H) for each frame.
FULLY TIGHTEN ALL ALLEN BOLTS (H).
STEP 10
STEP 11
1 2 3
1st Postion 2nd Postion 3rd Postion
17
10
11
H
H
H
NOTE: There are THREE different positions for the Add-On Shelves as show in Figure 1.
Please decide your preferred height at this time
13
25
15
K
14
J
12
STEP 9 4
F
HD
6

LDT5454GLD (SF)
LOADOUT L-SHAPED GAMING DESKSK
ASSEMBLY INSTRUCTIONS
STEP 12 Secure Left Upper Crossbar (23) between Left Upper Frame (10) and MIddle Upper Frame (17) using two Allen Bolts (F). FULLY TIGHTEN
ALLEN BOLTS (F).
STEP 13 Secure Right Upper Crossbar (24) between Left Upper Crossbar (23) and Right Upper Frame (11) using one Allen Bolts (F) and one Allen Bolt (H).
FULLY TIGHTEN ALLEN BOLTS (F & H).
LDT5454GLD (SF)
LOADOUT L-SHAPED GAMING DESK
ASSEMBLY INSTRUCTIONS
STEP 11 Secure Left Top Shelf (1) and Right Top Shelf (2) to assembly using thirteen Flat Allen Bolts (L). FULLY TIGHTEN ALL FLAT
ALLEN BOLTS (L).
STEP 15 Connect cords of Left Top Shelf (1) and Right Top Shelf (2). Connect cord of Left Top Shelf (1) to LED Power Supply (19).
STEP 12
STEP 13
F
23
24
F
STEP 14
STEP 15
2
1
L
17
10
H23
11
19

DIY 1
RGBW
DIY 2DIY 3
QUICK
SLOW
AUTO
FLASHDIY 4DIY 5DIY 6
FADE7JUMP3JUMP7 FADE3
SAFETY WARNINGS - PLEASE READ FIRST
