OSP furniture DESIGNlab RLDP60 User manual

RLDP60
GAMING DESK
ASSEMBLY INSTRUCTIONS
OSP FURNITURE LIMITED PRODUCT WARRANTY
Design Lab Products
• 3 years on gaming desks and chairs
*All warranties are limited to the original purchaser for normal commercial usage dened as a standard forty hour work week by persons weighing 250 lbs. or less.
This warranty will not cover labor, freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other event
beyond the control of Ofce Star Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or consequential
damages is excluded. The user assumes all risk of injury resulting from use of this product. When usage is more than 40 hours per week, a two year warranty on
all parts applies. Fabric and foam is warranted for one year. This warranty gives you specic legal rights, and you may also have other rights which vary from state
to state.
It is the customer’s responsibility to prepay freight on any components returned to the factory. Return freight on components covered by warranty will be paid by
Ofce Star Products.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts are damaged or missing. Our
Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail parts@ofcestar.net, by Fax [phone], or toll free
parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 3:30 p.m. Pacic Time.
INSPECT ON ARRIVAL This product has been inspected and packaged with durable internal packing and external corrugated. Responsibility for safe delivery was
assumed by the carrier at time of shipment. CLAIMS FOR LOSS OR DAMAGE TO THE CONTENTS SHOULD THEREFORE BE MADE UPON THE CARRIER AS BELOW.
WARNING
1. Do not use this product unless all bolts, screws and knobs are
securely tightened.
2. Check that all bolts, screws and knobs are tight every three months
or as needed.
3. Dispose of packing material properly. Do not use plastic cover as
head covering. t may cause suffocation.
4. Use this chair for its intended purpose only.
5. Use mild detergent only for cleaning.
NOTE: This equipment has been tested and found to comply with the limits for the Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interferences in a residential installation. This equipment generates, uses
and can radiate frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
-- This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
-- Instructions shall caution users that modifications not approved by part responsible for compliance
could void user’s authority to operate the equipment.
FCC INSTRUCTIONS
Office Star Products
Model number:JN02-03-22K

(1) Desk Top (1 PC)
(3) Right Side Frame (1 PC)
(5) Middle Front Cross Bar (1 PC)
(7) Rear Lower Cross Bar (1 PC)
(9) Cup Holder (1 PC)
(2) Left Side Frame (1 PC)
(4) Rear Frame (1 PC)
(6) Rear Upper Cross Bar (1 PC)
(8) Accessory Hook (1 PC)
(10) Storage Tray (1 PC)
PARTS
FRONT
TOP
TOP
FRONT
(11) Power Outlet (1 PC)
(13) LED Power Supply (1 PC)
(12) Remote (1 PC)
PARTS
6 x 12 x 10mm
6 x 32 x 10mm
6 x 45 x 10mm
6 x 25 x 10mm
4 x 10 x 8mm
3.5 x 12 x 6mm
4mm
6 PCS
12 PCS
2 PCS
2 PCS
2 PCS
2 PCS
1 PC
DRAWINGNO DESCRIPTION SIZE QUANTITY
HARDWARE LIST
Bolt
Bolt
Bolt
Bolt
Bolt
Screw
Allen Wrench
Phillips screwdriver also needed for assembly (not provided)
A1
B2
C3
D4
E5
F6
G7

STEP 1
A1
A1
A1
7
6
5
2
3
TOP
FRONT
C3
FRONT
4
7
6
D4 D4
TOP
2
5
A1
6
3
C3
A1
A1
A1
A1
1
B2
B2 B2
B2
B2 B2 B2
B2
B2
B2
B2
B2
2
2
3
6
5
8
E5
910
F6
F6
11
1
B2
B2 B2
B2
B2 B2 B2
B2
B2
B2
B2
B2
2
2
3
6
5
8
E5
910
F6
F6
11
13
1
13
1
STEP 2
STEP 3
STEP 4
STEP 5
STEP 3 Secure Desk Top (1) to assembly using twelve Bolts (B2). FULLY TIGHTEN ALL BOLTS (B2) USING ALLEN WRENCH (G7).
STEP 4 Secure Accessory Hook (8) to Left Side Frame (2) using two Bolts (E5). FULLY TIGHTEN ALL BOLTS (E5) USING ALLEN WRENCH (G7).
Insert Power Outlet (11) into its slot and secure using two Screws (F6). FULLY TIGHTEN ALL SCREWS (F6) USING PHILLIPS SCREWDRIVER (not provided).
Insert Cup Holder (9) and Storage Tray (10) into their slots.
STEP 5 Connect LED Power Supply (13) to existing cord on Desk Top (1).
IMPORTANT: MAKE SURE ALL BOLTS & SCREWS ARE SECURELY TIGHTENED BEFORE USING PRODUCT.
RLDP60
GAMING DESK
ASSEMBLY INSTRUCTIONS
RLDP60
GAMING DESK
ASSEMBLY INSTRUCTIONS
Remove all parts from carton, separate by part numbers indicated on parts list, and verify part quantities.
STEP 1 Attach Rear Frame (4) between Cross Bars (6 & 7) using two Bolts (D4) for Rear Upper Cross Bar (6) and two Bolts (C3) for Rear Lower Cross Bar (7).
DO NOT FULLY TIGHTEN BOLTS.
STEP 2 In the upright position, attach Rear Upper Cross Bar (6) and Rear Lower Cross Bar (7) between Left Side Frame (2) and Right Side Frame (3) using four
Bolts (A1). DO NOT FULLY TIGHTEN BOLTS. Attach Middle Front Cross Bar (5) between Left Side Frame (2) and Right Side Frame (3) using two Bolts (A1).
APPLY FIRM PRESSURE TO ALIGN ASSEMBLY AND FULLY TIGHTEN ALL BOLTS USING ALLEN WRENCH (G7).

DIY 1
RGBW
DIY 2DIY 3
QUICK
SLOW
AUTO
FLASHDIY 4DIY 5DIY 6
FADE7JUMP3JUMP7 FADE3
WARNING
1. Do not use this product unless all bolts, screws and knobs are
securely tightened.
2. Check that all bolts, screws and knobs are tight every three months
or as needed.
3. Dispose of packing material properly. Do not use plastic cover as
head covering. t may cause suffocation.
4. Use this chair for its intended purpose only.
5. Use mild detergent only for cleaning.
2 IN 1 MONITOR MOUNT
ASSEMBLY INSTRUCTIONS
OSP FURNITURE LIMITED PRODUCT WARRANTY
Design Lab Products
• 3 years on gaming desks and chairs
*All warranties are limited to the original purchaser for normal commercial usage dened as a standard forty hour work week by persons weighing 250 lbs. or less.
This warranty will not cover labor, freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other event
beyond the control of Ofce Star Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or consequential
damages is excluded. The user assumes all risk of injury resulting from use of this product. When usage is more than 40 hours per week, a two year warranty on
all parts applies. Fabric and foam is warranted for one year. This warranty gives you specic legal rights, and you may also have other rights which vary from state
to state.
It is the customer’s responsibility to prepay freight on any components returned to the factory. Return freight on components covered by warranty will be paid by
Ofce Star Products.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts are damaged or missing. Our
Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail parts@ofcestar.net, by Fax [phone], or toll free
parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 3:30 p.m. Pacic Time.
INSPECT ON ARRIVAL This product has been inspected and packaged with durable internal packing and external corrugated. Responsibility for safe delivery was
assumed by the carrier at time of shipment. CLAIMS FOR LOSS OR DAMAGE TO THE CONTENTS SHOULD THEREFORE BE MADE UPON THE CARRIER AS BELOW.

PART QTY
A. Mounting Bracket ...................2
B. Arm Frame ........................1
C. C-Clamp ..........................1
D. Support Post ...................... 1
E. Plastic Plug ........................1
F. Cord Managment Clip. . . . . . . . . . . . . . . . .1
G. Mounting Plate (optional) ..............1
H. Thumb Screw ......................2
I. Phillips Screw .......................2
J.Rubber Sticker .....................5
K.Allen Bolt .........................3
L . Grommet Plate (optional) ..............1
M . Allen Wrench (4mm) ................1
N . Allen Wrench (5mm) .................1
O . Allen Wrench (6mm) .................1
MOUNTING HARDWARE QTY
M-A. Bolt (M4 x 12) ....................8
M-B. Bolt (M4 x 16) ....................8
M-C. Bolt (M5 x 12) ....................8
M-D. Bolt (M5 x 16) ................... 8
M-E. Washer (D5) .....................8
M-F. Spacer .........................8
Remove all the parts from carton, separate them into part numbers indicated on the list and make sure part quantities are correct.
STEP 1 Insert Plastic Plug (E) into Support Post (D).
STEP 2A Remove adjustment knob from C-Clamp (C) using Phillips Screwdriver (not provided). Attach Rubber Stickers (J) to underside of Mounting
Plate (G). Remove Plastic Hole Cover from Desk Top (1). Attach Support Post (D) to Mounting Plate (G) and align with grommet hole of mounting surface. Slide
adjustment knob through Grommet Plate (L), mounting surface, Mounting Plate (G) and into Support Post (D). SECURELY TIGHTEN ADJUSTMENT KNOB.
STEP 2B Attach Rubber Stickers (J) to underside of C-Clamp (C). Secure C-Clamp (C) to Support Post (D) using Allen Bolts (K).
FULLY TIGHTEN ALLEN BOLTS (K) USING ALLEN WRENCH (M).
STEP 3A Slide Cord Management Clip (F) onto Support Post (D). Attach Arm Frame (B) to top end of Support Post (D) and secure using
Allen Wrenches (N & O). FULLY TIGHTEN PRE-INSTALLED BOLTS.
STEP 3B To remove arm on Arm Frame (B), unscrew and remove pre-installed bolt using Allen Wrench (N).
Slide Cord Management Clip (F) onto Support Post (D). Attach Arm Frame (B) to top end of Support Post (D) and secure using Allen Wrenches (N & O). FULLY
TIGHTEN PRE-INSTALLED BOLTS.
STEP 1 STEP 3A
DUAL MONITOR OPTION
STEP 3B
SINGLE MONITOR OPTION
Phillips screwdriver also needed for assembly
(not provided)
STEP 2A
GROMMET OPTION
1
mounting surface
STEP 2B
C-CLAMP OPTION
2 IN 1 MONITOR MOUNT
ASSEMBLY INSTRUCTIONS
2 IN 1 MONITOR MOUNT
ASSEMBLY INSTRUCTIONS

STEP 4
STEP 4 Secure Mounting Bracket (A) to rear of TV/monitor. Choose correct hardware conguration based on depth of TV/monitor mounting holes.
FULLY TIGHTEN BOLTS USING PHILLIPS SCREWDRIVER (not provided).
STEP 5 Carefully slide Mounting Bracket (A) onto Arm Frame (B). Secure Mounting Bracket (A) using one Phillips Screw (I) and one Thumb Screw (H) for each
Mounting Bracket (A). FULLY TIGHTEN PHILLIPS SCREWS (I) USING PHILLIPS SCREWDRIVER (not provided).
Further secure Mounting Brackets (A) by fully tightening pre-installed bolts on ends of Arm Frame (B) using Allen Wrench (O).
ATTENTION: MAKE SURE ALL screws & BOLTS ARE FULLY TIGHTENED BEFORE USING PRODUCT.
STEP 5
Run TV/Monitor cables through cable management clips. Be sure Arm Frame (B) remains in a straight (xed)
position from point of contact with Support Post (D).
Cord Management Clip (F) provides Allen Wrench caddy. Mounting Brackets (A) can be adjusted up and down
as well as a + or - 45� pivot.
2 IN 1 MONITOR MOUNT
ASSEMBLY INSTRUCTIONS
2 IN 1 MONITOR MOUNT
ASSEMBLY INSTRUCTIONS
© Ofce Star Products April 2022
