Osstem A200E User manual

AE Set
A200E / A400E

1
5
9
2
6
10
3
7
4
8
11

Align
Open
Close
Chuck Open
Chuck Close
12
16
13 14 15
17

1
ENGLISH
Air Motor
Class
WARNING
CAUTION
NOTICE
Degree of Risk
Hazard that could result in serious injury or damage to the device if the safety
instructions are not correctly followed.
Hazard that could result in light or moderate injury or damage to the device if the
safety instructions are not correctly followed.
General product specification information highlighted to avoid product malfunction
and performance reduction.
AE Set
AE motor
eceipdnaHelgnAartnoCrotomriA
A200E
Straight Handpiece
A400E
User and Intended Use
User : Qualified Professionals
Intended Use : Dental Treatment (A200E, AE motor)
Dental Treatment / Dental Prosthetics (Cutting, Polishing) (A400E)
Precautions for handling and operation
Please read these precautions carefully and use only as intended or instructed.
Safety instructions are intended to avoid potential hazards that could result in personal injury or damage
to the device. Safety instructions are classified as follows in accordance with the seriousness of the risk.
Set Component List

2
CAUTION
Disconnect the handpiece only after the motor has completely stopped rotating.
Air Motor (AE)
CAUTION
Read this Operation Manual before use to fully understand the product functions and file for future
reference.
When operating the product always consider the safety of the patient.
This product does not consider patient’s age, gender nor physical condition.
This product does not consider operator’s age, gender nor physical condition.
Users are responsible for the operational control, maintenance and continual inspection of this
product.
Do not attempt to disassemble the product nor tamper with the mechanism except as recommend
by OSSTEM in this Operation Manual.
Do not allow any impact on to the product. Do not drop the product.
Operators and all others in the area must wear eye protection and a mask when operating this motor.
Should the product function abnormally, cease operation immediately and contact your Authorized
OSSTEM IMPLANT Co,. Ltd Dealer.
Do not use high acid water or sterilizing solutions to wipe, immerse or clean the product.
The products are delivered in a non-sterile condition and must be autoclaved prior to use.
Perform regular function and maintenance checks.
If the product is not used for a long period check it is functioning correctly before using on a patient.
To avoid clinical downtime it is recommended that a spare be kept on hand in case of a breakdown
during surgery.
U.S. Federal law restricts this device to sale by or on the order of a licensed physician.
1. Setting of Air & Water Supply Pressure
Measure the supply pressure at the handpiece / hose connection point and set the pressure to the value
specified on the specification table. (Fig. 1)
For Multi Gauge information refer to Option Parts List.
WARNING
Do not exceed the optimum pressure specified on the specification table.
CAUTION
Do not use air contaminated by dust, moisture and oil.
2. Connection & Disconnection of the Handpiece
2-1 Connection
1) Connect the handpiece direct to the motor. (Fig. 2)
2) Make sure the handpiece is firmly connected to the motor.
2-2 Disconnection
Hold the motor and the handpiece separately and disconnect with care.
3. Check before treatment
Connect the handpiece to the motor and check for motor vibration, noise and overheating. If any
abnormalities are found do not use the motor and contact your Authorized OSSTEM Dealer.

3
ENGLISH
Air Motor
CAUTION
After washing with Thermo-Disinfector and prior to lubrication, dry the product until all internal
moisture is thoroughly removed. Thermo-Disinfector moisture remaining inside the product could
reduce the effect of lubrication and could cause corrosion inside of the product.
To clean the product never use any solvent such as benzine or thinner.
CAUTION
When applying spray be sure to hold the motor firmly to prevent the motor from slipping out of the
hand due to the spray pressure.
Hold the spray can upright.
4. Water and Chip Air Supply to the Handpiece
1) Attach the attached FX Spray nozzle to the neck of the Contra Angle handpiece.
2) Trim the tube to the desired length then insert the tube end into the nozzle clamp on the motor. (Fig. 3)
5. Forward / Reverse Rotation
1) Forward Rotation : Turn the FWD/REV Change Ring to “F”. (Fig. 4)
2) Reverse Rotation : Turn the FWD/REV Change Ring to “R”. (Fig. 5)
3) When the FWD/REV Change Ring is positioned at the middle of “F” and “R” , the drive air is interrupted
and the motor does not rotate. (Fig. 6)
F : Forward Rotation R : Reverse Rotation
6. Maintenance
After each patient maintain the product as follows.
6-1 Cleaning
1) Remove dirt and debris from the product. Do not use a wire brush.
2) Wipe clean with alcohol-immersed cotton swab or cloth.
This icon denotes that the product can be washed via Thermo Disinfector. (AE)
Refer to the Thermo-Disinfector manual.
6-2 Lubrication
PANA SPRAY Plus
Apply PANA SPRAY Plus every time after each use and/or before autoclaving.
1) Remove the motor from the hose.
2) Mount the arrow-head spray nozzle tip into the spray can port. (Fig. 7)
3) Insert the Spray Nozzle into the Drive Air Port of the motor. Hold the motor and spray for approximately
2-3 seconds. Apply lubricant until it expels from the exhaust air part for at least 2 seconds. (Fig. 8)
Lubrication Oil
1) Remove the motor from the hose.
2) Apply 1-2 drops of lubrication oil into the Drive Air Port shown in the Fig. 8.
3) Connect the motor to the hose. Operate the motor for about 10 seconds.
6-3 Sterilization
Sterilize the product by autoclave sterilization. Remove the handpiece after each patient and sterilize as
noted below.
1) Insert into an autoclave pouch. Seal the pouch.
2) Autoclavable under the conditions below.
Autoclave for more than 20 min. at 121°C, or 15 min. at 132°C, or 3 min. at 134°C.
3) The motor should remain in the autoclave pouch until required for use.

4
NOTICE
OSSTEM recommends Class B sterilizers as stated in EN13060.
CAUTION
Do not autoclave the product with other instruments even when it is in a pouch. This is to prevent
possible discoloration and damage to the product from chemical residue on other instruments.
Keep the product in suitable atmospheric pressure, temperature, humidity, ventilation, and sunlight.
The air should be free from dust, salt and sulphur.
Do not heat or cool the product too quickly. Rapid change in temperature could cause damage to the
product.
If the sterilizer chamber temperature may exceed 135°C during the dry cycle then delete the dry
cycle.
Autoclave sterilization is recommended for the product. The validity of other sterilization methods is
not confirmed.
Do not touch the product immediately after autoclaving as it will be very hot and must remain in a
sterile condition.
8. Symbol
This product is Autoclavable up to Max.135°C.
This product can be washed via Thermo Disinfector.
Conforms to CE European Directive of “Medical device directive 93/42/EEC.”
Manufacturer.
Authorized representative in the European community.
Caution: U.S. Federal law restricts this device to sale by or on the order of a licensed physician.
7. Periodical Maintenance Checks
Perform periodical maintenance checks every three months, referring to the check sheet below. If any
abnormalities are found, contact your Authorized OSSTEM IMPLANT CO,. LTD Dealer.
Points to check
Rotation
Details
Rotate the motor and check for abnormalities such as abnormal rotation, vibration,
noise, and overheating.
9. Warranty
OSSTEM products are warranted against manufacturing errors and defects in materials. OSSTEM reserves the
right to analyze and determine the cause of any problem. Warranty is voided should the product be not used
correctly or for the intended purpose or has been tampered with by unqualified personnel or has had non
OSSTEM parts installed. Replacement parts are available for seven years beyond discontinuation of the model.
10. Option Parts List
Model
MG-4H Multi Gauge
Order Code
Z109400
Compatible Product
AE
11. Disposing product
In order to avoid the health risks of operators handling the disposal of medical equipment, as well as the
risks of environmental contamination caused thereof, a surgeon or a dentist is required to confirm the
equipment is sterile. Ask specialist firms who are licensed to dispose of specially controlled industrial
wastes, to dispose the product for you.

5
ENGLISH
Air Motor
Model
Hose Connection Type
Handpiece Connection Type
Max. Rotation Speed
Breakdown Torque
Drive Air Pressure
Air Consumption
Water Pressure
Chip Air Pressure
Coolant Water Supply
Coolant Air Supply
Water Spray Type
Use Environment
Transportation and Store
Environment
Thermo Disinfector
ISO 9168 Type 2 (Midwest 4 hole)
0.15 - 0.25MPa (1.5 - 2.5kgf/cm2)
AE
E Type ISO 3964
25,000min-1
2.0N·cm
0.20 - 0.25MPa (2.0 - 2.5kgf/cm2)
50±5NL/min(0.25MPa)
0.10 - 0.25MPa (1.0 - 2.5kgf/cm2)
50mL/min and more (0.25MPa)
1.5L/min and more (0.25MPa)
External Spray
Temperature: 0 - 40°C (No Condensation), Humidity: 30 - 75%,
Atmospheric Pressure: 700 - 1,060hPa
Temperature: -10 - 50°C, Humidity: 10 - 85%,
Atmospheric Pressure: 500 - 1,060hPa
12. Specifications

6
CAUTION
CAUTION
Disconnect the handpiece only after the motor has completely stopped rotating.
Contra Angle Handpiece (A200E)
Read this Operation Manual before use to fully understand the product functions and file for future
reference.
When operating the product always consider the safety of the patient.
This product does not consider patient’s age (except infants), gender, weight or nationality.
This product does not consider operator’s age (mature person), height, weight, gender, or nationality.
Users are responsible for the operational control, maintenance and continual inspection of this
product.
Do not attempt to disassemble the product nor tamper with the mechanism except as recommend
by OSSTEM in this Operation Manual.
Do not allow any impact on to the product. Do not drop the product.
Operators and all others in the area must wear eye protection and a mask when operating this
handpiece.
Should the product function abnormally, cease operation immediately and contact your Authorized
OSSTEM IMPLANT Co,. Ltd Dealer.
Depressing the Push Button while the handpiece is in operation may cause overheating, serious
technical damage and possible premature handpiece failure. During operation avoid contact with any
oral tissue that may cause the Push Button to be depressed while the handpiece is in operation.
Do not use high acid water or sterilizing solutions to wipe, immerse or clean the handpiece.
The products are delivered in a non-sterile condition and must be autoclaved prior to use.
Perform regular function and maintenance checks.
If the product is not used for a long period check it is functioning correctly before using on a patient.
To avoid clinical downtime it is recommended that a spare be kept on hand in case of a breakdown
during surgery.
U.S. Federal law restricts this device to sale by or on the order of a licensed physician.
1. Connection & Disconnection of the Handpiece and Motor
1-1 Connection
1) Connect the handpiece direct to the motor. (Fig. 2)
2) Make sure the handpiece is firmly connected to the motor.
1-2 Disconnection
Hold the motor and the handpiece separately and disconnect with care.
2. Insertion & Removal of the Bur
2-1 To Insert the Bur
1) Insert the bur until it is correctly seated in place.
2) Depress the Push Button and insert the bur into the chuck until the bur "notch" mechanism engages.
Release the button. (Fig. 9)
3) Ensure that the bur is secure by gently pulling and pushing the bur WITHOUT depressing the Push
Button.
2-2 To Remove the Bur
Depress the Push Button firmly and remove the bur. (Fig. 10)

7
ENGLISH
Contra Angle Handpiece
CAUTION
After washing with Thermo-Disinfector and prior to lubrication, dry the product until all internal
moisture is thoroughly removed. Thermo-Disinfector moisture remaining inside the product could
reduce the effect of lubrication and could cause corrosion inside of the product.
To clean the product never use any solvent such as benzine or thinner.
CAUTION
Always insert the bur all the way into the chuck.
Remove the bur only after the handpiece has completely stopped rotating.
Always keep the bur shank clean. Entry of debris into the chuck, via the bur shank, could cause bur
rotation slip and also prevent the bur from being securely located in the chuck.
Do not exceed the bur speed recommended by the bur manufacturer.
Do not exceed maximum bur length recommended by the handpiece manufacturer.
Do not apply excess pressure to the bur as it may break or bend or become difficult to remove.
DO NOT use bur with problems listed below as the bur may break or disengage from the chuck.
- Bent, deformed, worn, rusted, broken, deficient bur.
- Bur which is cracked on the edge or axis.
- Non-ISO standard, or tampered bur.
5-1 Cleaning
1) Remove dirt and debris from the product. Do not use a wire brush.
2) Wipe clean with alcohol-immersed cotton swab or cloth.
This icon denotes that the product can be washed via Thermo Disinfector. (A200E)
Refer to the Thermo-Disinfector manual.
CAUTION
When applying spray be sure to hold the handpiece firmly to prevent the handpiece from slipping out
of the hand due to the spray pressure.
Hold the spray can upright.
3. Check before treatment
Check that the Head Cap is firmly tightened. Also check for handpiece vibration, noise and overheating.
If any abnormalities are found do not use the handpiece and contact your Authorized OSSTEM IMPLANT
Co,. Ltd Dealer.
4. Connection of the Spray Nozzle
1) Attach the FX Spray nozzle to the neck of the handpiece.
2) Trim the tube to the desired length then insert the tube end into the nozzle clamp on the motor. (Fig. 11)
5. Maintenance
After each patient maintain the product as follows.
5-2 Lubrication
PANA SPRAY Plus
Apply PANA SPRAY Plus every time after each use and/or before autoclaving.
1) Remove the bur from the handpiece.
2) Insert the Spray Nozzle into the Spray Port nozzle on the can.
3) Insert the Spray Nozzle in rear of the handpiece. Hold the handpiece and spray for approximately 2-3
seconds. Apply lubricant until it expels from the handpiece head for at least 2 seconds. (Fig. 12)

8
NOTICE
OSSTEM recommends Class B sterilizers as stated in EN13060.
CAUTION
Do not autoclave the product with other instruments even when it is in a pouch. This is to prevent
possible discoloration and damage to the product from chemical residue on other instruments.
Keep the product in suitable atmospheric pressure, temperature, humidity, ventilation, and sunlight.
The air should be free from dust, salt and sulphur.
Immediately after use, the handpiece should be cleaned, lubricated and sterilized. If blood remains
on the external or internal surfaces it can become clotted and cause rust.
Do not heat or cool the product too quickly. Rapid change in temperature could cause damage to the
product.
If the sterilizer chamber temperature may exceed 135°C during the dry cycle then delete the dry
cycle.
Autoclave sterilization is recommended for the product. The validity of other sterilization methods is
not confirmed.
Do not touch the product immediately after autoclaving as it will be very hot and must remain in a
sterile condition.
CAUTION
Be sure to insert the wrench straight into the handpiece head. Do not insert the wrench as shown in
Fig. A-2.
When pulling out the drive shaft, tightly hold the wrench as directed in Fig. B.
NSK Care3 Plus
When using NSK Care3 Plus automatic handpiece cleaning and lubrication system, refer to the Care3
System instructions.
5-3 Sterilization
Sterilize the product by autoclave sterilization. Remove the bur after each patient and sterilize as noted
below.
1) Insert an autoclave pouch. Seal the pouch.
2) Autoclavable under the conditions below.
Autoclave for more than 20 min. at 121°C, or 15 min. at 132°C, or 3 min. at 134°C.
3) The handpiece should remain in the autoclave pouch until required for use.
6. Replacing the Cartridge
1) Detach the shank by turning it counter clockwise and remove the head from the shank. (Fig. 13)
2) Insert the wrench firmly into the rear of the handpiece head until it stops, as shown in Fig. A-1.
3) Tightly hold the wrench as directed in Fig.B then pull out the drive shaft straight in the direction of the
arrow. (Fig. B)
Hold tight!Hold tight!
2-A1-A
B

9
ENGLISH
Contra Angle Handpiece
CAUTION
After removing, do not hold the shank upside down as it could cause the internal parts to drop.
Before turning the head cap, make sure the wrench is correctly aligned with the cap. Do not turn the
wrench at an angle as abrasion of the wrench may occur.
Secure the shank firmly to the handpiece head so that there is no gap between them. A loose
connection could make the head unstable, resulting in an accident during use.
Use only a genuine NSK cartridge.
If a non genuine cartridge is used OSSTEM cannot guarantee performance and the handpiece warranty
would become invalid.
Always first finger tighten the head cap then secure firmly with the wrench.
OSSTEN never recommends the disassembly and repair of any NSK cartridge. There is NO EXCEPTION.
In such a case a handpiece may perform abnormally (abnormal noise or abnormal vibration).
Damage, failure or accidents are outside of our guarantee.
Points to check
Head cap is loose
Rotation
Details
Tighten firmly using the correct head cap wrench.
Rotate the handpiece and check for abnormalities such as abnormal rotation,
vibration, noise, and overheating.
8. Symbol
This product is Autoclavable up to Max.135°C.
This product can be washed via Thermo Disinfector.
Conforms to CE European Directive of “Medical device directive 93/42/EEC.”
Manufacturer.
Authorized representative in the European community.
Caution: U.S. Federal law restricts this device to sale by or on the order of a licensed physician.
9. Warranty
OSSTEM products are warranted against manufacturing errors and defects in materials. OSSTEM reserves the
right to analyze and determine the cause of any problem. Warranty is voided should the product be not used
correctly or for the intended purpose or has been tampered with by unqualified personnel or has had non
NSK parts installed. Replacement parts are available for seven years beyond discontinuation of the model.
4) Locate the correct wrench tool for the head cap then turn the wrench counter clockwise to loosen the
cap. Remove the cap.(Fig. 14)
5) Use the bur to gently lever the entire cartridge out from the head.(Fig. 15)
6) Clean the head interior with PANA SPRAY Plus.
7) Wipe the PANA SPRAY Plus oil over the head interior.
8) Insert the new cartridge into the head by aligning the pin on the cartridge with the slot on the head.
(Fig. 16)
9) Tighten the head cap with the correct wrench.
10) Insert the drive shaft firmly into the handpiece head until it clicks. If the click is not heard, insert it
again.
11) Reattach the shank.
*Refer to Spare Parts List to identify the correct cartridge.
7. Periodical Maintenance Checks
Perform periodical maintenance checks every three months, referring to the check sheet below. If any
abnormalities are found, contact your Authorized OSSTEM IMPLANT Co,. LTD Dealer.

10
Model
Max. Rotation Speed (Motor)
Max. Rotation Speed (Handpiece)
Gear Ratio
Bur Type
Chucking Length
Max. Bur Length
Max. Working Part Diameter
Use Environment
Transportation and Store
Environment
Thermo Disinfector
A200E
40,000 min-1
40,000 min-1
-
1:1 Direct Drive
ISO 1797-1 Type1 ø2.35mm CA Bur
11.5mm
22.5mm
ø4.0mm
Temperature: 0 - 40°C (No Condensation), Humidity: 30 - 75%,
Atmospheric Pressure: 700 - 1,060hPa
Temperature: -10 - 50°C, Humidity: 10 - 85%,
Atmospheric Pressure: 500 - 1,060hPa
10. Spare Parts List
Model
FX25-03
FX Wrench
FX Spray Nozzle
Order Code
C1052700
C1052701
C1052702
Compatible Product
A200E
A200E
A200E
Remarks
Cartridge
11. Disposing product
In order to avoid the health risks of operators handling the disposal of medical equipment, as well as the
risks of environmental contamination caused thereof, a surgeon or a dentist is required to confirm the
equipment is sterile. Ask specialist firms who are licensed to dispose of specially controlled industrial
wastes, to dispose the product for you.
12. Specifications

11
ENGLISH
Straight Handpiece
CAUTION
Disconnect the handpiece only after the motor has completely stopped rotating.
CAUTION
Make sure to align the mark with " " mark. If those marks are not completely aligned, it may
cause handpiece overheating or patient burn injuries.
Always insert the bur fully into the chuck. Insufficient insertion of the bur could cause premature
failure of the bearing.
Straight Handpiece (A400E)
CAUTION
Read this Operation Manual before use to fully understand the product functions and file for future
reference.
When operating the product always consider the safety of the patient.
This product does not consider patient’s age (except infants), gender, weight or nationality.
This product does not consider operator’s age (mature person), height, weight, gender, or nationality.
Users are responsible for the operational control, maintenance and continual inspection of this
product.
Do not attempt to disassemble the product nor tamper with the mechanism except as recommend
by OSSTEM in this Operation Manual.
Do not allow any impact on to the product. Do not drop the product.
Operators and all others in the area must wear eye protection and a mask when operating this
handpiece.
Should the product function abnormally, cease operation immediately and contact your Authorized
OSSTEM IMPLANT Co,. Ltd Dealer.
Do not use high acid water or sterilizing solutions to wipe, immerse or clean the handpiece.
The products are delivered in a non-sterile condition and must be autoclaved prior to use.
Perform regular function and maintenance checks.
If the product is not used for a long period check it is functioning correctly before using on a patient.
To avoid clinical downtime it is recommended that a spare be kept on hand in case of a breakdown
during surgery.
U.S. Federal law restricts this device to sale by or on the order of a licensed physician.
1. Connection & Disconnection of the Handpiece and Motor
1-1 Connection
1) Connect the handpiece direct to the motor. (Fig. 2)
2) Make sure the handpiece is firmly connected to the motor.
1-2 Disconnection
Hold the motor and the handpiece separately and disconnect with care.
2. Insertion & Removal of the Bur
2-1 To Insert the Bur
1) Turn the Bur Lock Ring in the direction of the " " mark until it clicks. (Fig. 17)
2) Insert the bur fully into the chuck then turn the Bur Lock Ring in the direction of the mark " " until it
clicks.
3) Test that the bur is secure by gently pulling and pushing the bur.
2-2 To Remove the Bur
Turn the Bur Lock Ring in the direction of the " " mark until it clicks then remove the bur.

12
CAUTION
After washing with Thermo-Disinfector and prior to lubrication, dry the product until all internal
moisture is thoroughly removed. Thermo-Disinfector moisture remaining inside the product could
reduce the effect of lubrication and could cause corrosion inside of the product.
To clean the product never use any solvent such as benzine or thinner.
Remove the bur only after the handpiece has completely stopped rotating.
Do not rotate the handpiece when the Bur Lock Ring is turned to " " (OPEN) position or a bur is
not inserted.
Always keep the bur shank clean.Entry of debris into the chuck, via the bur shank, could cause bur
rotation slip and also prevent the bur from being securely located in the chuck.
Do not exceed the bur speed recommended by the bur manufacturer.
Do not exceed maximum bur length recommended by the handpiece manufacturer.
Do not apply excess pressure to the bur as it may break or bend or become difficult to remove.
DO NOT use burs with problems listed below as the bur may break or disengage from the chuck.
- Bent, deformed, anisomerous (worn), rusted, broken, deficient bur.
- Bur which is cracked on the edge or axis.
- Non-ISO standard, or tampered bur.
3. Check before treatment
Check for handpiece vibration, noise and overheating. If any abnormalities are found do not use the
handpiece and contact your Authorized OSSTEM IMPLANT Co,. Ltd Dealer.
4. Maintenance
After each patient maintain the product as follows.
4-1 Cleaning
1) Remove dirt and debris from the product. Do not use a wire brush.
2) Wipe clean with alcohol-immersed cotton swab or cloth.
This icon denotes that the product can be washed via Thermo Disinfector. (A400E)
Refer to the Thermo-Disinfector manual.
CAUTION
When applying spray be sure to hold the handpiece firmly to prevent the handpiece from slipping out
of the hand due to the spray pressure.
Hold the spray can upright.
4-2 Lubrication
PANA SPRAY Plus
Apply PANA SPRAY Plus every time after each use and/or before autoclaving.
1) Remove the bur from the handpiece.
2) Insert the Spray Nozzle into the Spray Port nozzle on the can.
3) Insert the Spray Nozzle in rear of the handpiece. Hold the handpiece and spray for approximately 2-3
seconds. Apply lubricant until it expels from the handpiece head for at least 2 seconds. (Fig. 12)
NSK Care3 Plus
When using NSK Care3 Plus automatic handpiece cleaning and lubrication system, refer to the Care3
System instructions.
4-3 Sterilization
Sterilize the product by autoclave sterilization. Remove the bur after each patient and sterilize as noted
below.
1) Insert into an autoclave pouch. Seal the pouch.
2) Autoclavable under the conditions below.

13
ENGLISH
Straight Handpiece
CAUTION
Do not autoclave the product with other instruments even when it is in a pouch. This is to prevent
possible discoloration and damage to the product from chemical residue on other instruments.
Keep the product in suitable atmospheric pressure, temperature, humidity, ventilation, and sunlight.
The air should be free from dust, salt and sulphur.
Immediately after use, the product should be cleaned, lubricated and sterilized. If blood remains on
the external or internal surfaces it can become clotted and cause rust.
Do not heat or cool the product too quickly. Rapid change in temperature could cause damage to the
product.
If the sterilizer chamber temperature may exceed 135°C during the dry cycle then delete the dry
cycle.
Autoclave sterilization is recommended for the product. The validity of other sterilization methods is
not confirmed.
Do not touch the product immediately after autoclaving as it will be very hot and must remain in a
sterile condition.
Points to check
Rotation
Details
Rotate the handpiece and check for abnormalities such as abnormal rotation,
vibration, noise, and overheating.
6. Symbol
This product is Autoclavable up to Max.135°C.
This product can be washed via Thermo Disinfector.
Conforms to CE European Directive of “Medical device directive 93/42/EEC.”
Manufacturer.
Authorized representative in the European community.
Caution: U.S. Federal law restricts this device to sale by or on the order of a licensed physician.
7. Warranty
OSSTEM products are warranted against manufacturing errors and defects in materials. OSSTEM reserves the
right to analyze and determine the cause of any problem. Warranty is voided should the product be not used
correctly or for the intended purpose or has been tampered with by unqualified personnel or has had non
NSK parts installed. Replacement parts are available for seven years beyond discontinuation of the model.
8. Option Parts List
9. Disposing product
In order to avoid the health risks of operators handling the disposal of medical equipment, as well as the
risks of environmental contamination caused thereof, a surgeon or a dentist is required to confirm the
equipment is sterile. Ask specialist firms who are licensed to dispose of specially controlled industrial
wastes, to dispose the product for you.
Model
Spray Nozzle
Order Code
H019711
Autoclave for more than 20 min. at 121°C, or 15 min. at 132°C, or 3 min. at 134°C.
3) The handpiece should remain in the autoclave pouch until required for use.
NOTICE
OSSTEM recommends Class B sterilizers as stated in EN13060.
5. Periodical Maintenance Checks
Perform periodical maintenance checks every three months, referring to the check sheet below. If any
abnormalities are found, contact your Authorized OSSTEM IMPLANT Co,. Ltd Dealer.

14
Model
Max. Rotation Speed (Motor)
Max. Rotation Speed (Handpiece)
Gear Ratio
Bur Type
Chucking Length
Max. Bur Length
Max. Working Part Diameter
Use Environment
Transportation and Store
Environment
Thermo Disinfector
40,000 min-1
40,000 min-1
A400E
-
1:1 Direct Drive
ISO 1797-1 Type2 ø2.35mm HP Bur /
30mm
44.5mm
ø4mm
Temperature: 0 - 40°C (No Condensation), Humidity: 30 - 75%,
Atmospheric Pressure: 700 - 1,060hPa
Temperature: -10 - 50°C, Humidity: 10 - 85%,
Atmospheric Pressure: 500 - 1,060hPa
10. Specifications

OSSTEM IMPLANT
8th FL, World Meridian II, 123,
Gasan digital 2-ro, Geumcheon-gu,
Seoul 153-759, Korea
www.osstem.com
