Outsider KAMADO FHTA80107B User manual

Questions, problems, or missing parts?
Before returning to the store, call Customer Service.
8am - 5pm, PST Monday - Friday
Model No. FHTA80107B/FHTA80107
B A R B E C U E S
FHTA 80 1 0 7B / F HTA80107 OUTSI DE RB AR BE CU ES .C OM 866-292-88 00
RETAIN THIS MANUAL FOR FUTURE USE.
ASS E M B L Y INST R U C T I O N S
INSTR U C T I O N S D E M O NTA G E
G U ÍA D E L P R O D U C T O
KAMADOC A B I N E T
G R I L L

IMPORTANT
If you have any problems with this product (missing or damaged parts, assembly issues, etc.),
P L E A S E D O NOT RE T U R N T O T H E R E T A I L E R / S T O R E
from where you purchased the product.
Please call our Toll-Free Customer Service Hotline at:
1-866-292-8800
To expedite any future warranty claims, please retain the instruction sheet and
receipt for future use.
SAFETY INSTRUCTIONS
SAFETY SYMBOLS
IMPORTANT: RETAIN F O R F U T U R E R E F E R E N C E , AN D R E A D C A R E F U L L Y .
THIS PRODUC T IS F O R O U T D O O R U S E O N L Y .
C A U T I O N DANGER
Indicates a potentially
hazardous situation or
unsafe practice which, if not
avoided, may result in minor
or moderate injury.
Indicates a imminently
hazardous situation which, if
not avoided, will result in
death or serious injury.
WARNING
Indicates a potentially
hazardous situation which,
if not avoided, could result
in death or serious injury.
FHTA80 10 7B /F HTA80107 OU TSID ER BA RB EC UE S. CO M866-292-88 00

PARTS LIST
Key Qty Description
AA
2 M4*30
BB 2 Washer-1
1
1
Grill Cabinet Body
2 1
Heat Pad
3 1 Handle
OU TS ID ER BA RB EC UE S. CO M866-292-8800
1
2
3
Washer-1
M4*30
x 2AA
BB x 2
M6*20
CC x 4
DD x 2
EE x 1
Wrench
Washer-2
CC
4 M6*20
DD
2 Washer-2
EE
1
Wrench
FHTA8 01 07 B/ FHTA 80 10 7

LEVELING THE CABINETS
I M P O RTANT:
Leveling the cabinets is the most important part of installation, to ensure doors align properly and
countertop sets evenly. Cabinets need to be level and square. Each cabinet features levelers at
the corners that can be adjusted to acheive a perfectly level countertop. Turn levelers clockwise
to raise the height of the cabinet, and counter-clockwise to reduce the height.
L E V E L I N G Y O U R CABINETS
Be sure to level your cabinets in all three directions:
1. Front to Back
2. Vertically
3. Horizontally
OUTSIDERBARBECUES.COM866-292-8800
FHTA80 10 7B /F HTA80 10 7
1
2
3

ASSEMBLY
S T E P 1
Requires: AA, BB, 2, 3
ATTACHING THE HANDLE
Attach the handle (3) to the door using bolts (AA) and washers (BB).
OUTSIDERBARBECUES.COM866-292-88 00
AA
BB
FHTA80107B /FHTA80107
2
3

ASS E M B L Y
S T E P 2
Requires: 1, 2
Place the heat pad (1) on the shelf of the grill cabinet body (2).This will protect the shelf from
the heat of the kamado grill.
OUTSIDERBARBECUES.COM 866-292-8800
FHTA80 10 7B /F HTA80 10 7
1
2
H E ATT H E P A D O N T H E S HEL F
PLAC E

ASSEMB L Y
STE P 3
Requires: 1, DD, CC
OU TSID ER BA RB EC UE S. CO M 866-292-88 00
Connect two cabinets together
using connector plate (DD) and
bolts (CC).
STE P 4
Your cabinets include ports for running electrical or plumbing. Installation of either is required to
be completed by licensed professionals. Each port has a cover that can be removed for access.
CCDD
FHTA80107B /FHTA80107

CARE AND MAINTENANCE
CLEANING & MAINTENANCE
FHTA80107B / FHTA80107 OUTSIDERBARBECUES.COM 866-292-8800

WARRANTY
LIMITE D WARRANTY P R O G R A M
FHTA80107B / FHTA80107 OUTSIDERBARBECUES.COM866-292-8 80 0
The Manufacturer will either repair or replace defective components in accordance with this Limited
Warranty, according the scope and period below:
SCOPE OF COVERAGE PERIOD OF COVERAGE TYPE OF FAILURE COVERAGE
