OVERWATCH XE11 Parts list manual

Basic Function Operation

Buttons Description
Setting Menu
Play Back
Interface Description
Summary

→Turn On/Off the Device, Turn On/Off the Monitor
→Start/Stop Recording Audio
→Push to Talk
→Start/Stop Recording Video, One Touch Recording
→Take Pictures and Capture Snapshots during the recording

Long Press will turn on the Flash Light.
Long Press for over 3 seconds will start a Panic Alarm and Record,
this Alarm can be sent through 3G/4G/WiFi to Server.

For Connecting with Earphone, Mic, Intercom and
Car USB Charger etc.
Short Press will turn On/Off the Laser Light, Long Press will turn
On/Off the IR
Please hold the 3G/4G SIM chip-side in
the same direction as the front of the
device, the bevel-edge outward!

Display the Menu and Confirm
Return and One Key Playback

Device Indicator Green Light Red Light Yellow Light
Implication Idle Recording Video RecordingAudio
4 IR Lights, Up to 15 Meters Night
Vision, Up to 8 Meters with Visible
Face Image

Preview Mode, Resolution is 1920*1080
Pre-Recording 20 seconds
Date and Time
Product ID_Officer ID
Available Memory/Total Memory

Press Fast Forward, Up to X32 times
Press Return to Normal Speed

Record Resolution: 1920×1080 (1080p),
1280×720 (720P) or 640×360 (VGA)
Record FPS: 5,10,15,20,25 and 30 fps
Record Quality: Super, High, Medium and Low
: Live Resolution: 1920×1080 (1080p),
1280×720 (720P) or 640×360 (VGA)
Live view FPS: 5,10,15,20,25,30 fps
Live Quality: Super, High, Medium and Low

Live Mode: Fluency First and Quality First
Picture Size: 8640x4752(40M)/7680x4288/
5760x3216/3840x2144/2880x1584/1920x1080
3G/4G: On, Off
WiFi: On, AP, Off
GPS: On, Off
USB Mode: Auto, Host, Device

LCD Brightness: Auto, High, Medium, Low
Auto screen off : Off, 30s, 1min, 3min, 5min
Record mode: Manual, Auto
OverWrite mode: On, Off
Mic Volume: 0~10 (Default: 8)
IR switch: Manual, Auto

Spk Volume: 0~10 (Default: 9)
Voice reminder: On, Off
Vibrate reminder: On, Off
Time Sync: On, Off
External Audio: HeadPhone,InterPhone,None
File Length: 5, 10, 20, 30min

Pre-Recording: Off, 5s, 10s, 20s
Setting Mode: On, Off
Post-Recording: Off, 5s, 10s, 20s
Laser: Disable, Enable
Language: English
Device Info

Summary
One Touch Recording and One Touch Remote Alarm
Pre and Post Recording
SIM Card Installation
Determine whether Connect to Network and Server
Play Back
Select the Resolution and Picture Size
Record Video/Audio, Take Snaps
