Ovislink Air Live SmartCube 300W User manual

SmartCube 300W
Intelligent 3MP Wireless Cube IPCAM
with Temperature and Humidity Sensor
Quick Installation Guide
Setup using Smartphone and router
without WPS push button.
Please check if your wireless router has "WPS
Push Button" shown as an example in the
picture below. If it doesn't, please use this
guide. If it does have the WPS push button,
please download the guide "Setup using
Smartphone and router with WPS push
button"
Ant.Reset/WPSLAN4 LAN3 LAN2 LAN1WAN USB
butto
ing
ush
s
"
n
t
h
thi
tt
WPS Push Button

Support
You can download the
complete guides and
supporting programs from
<http://www.airlive.com/pro
duct/smartcube-300w/downl
oad>, or scan the QR code
here.
Please consult with the FAQs
<http://www.airlive.com/pro
duct/smartcube-300w/faq>
before writing to OvisLink
Tech Support Team for further
assistance
For any other question, please read the user
manual in the CD or mail to [email protected]
for technical support.
SmartCube 300W Package Contents
Please check the package contents and contact
your distributor if any part is missing.
1
2
3
SmartCube 300W
5V AC Power Adapter
4 Quick Installation Guide
5 User Manual CD
6Label
Mounting Accessories
(Screws / Plastic Anchors)

I/O Interface
802.11n Wi-Fi
Micro SD Slot
I/O Interface
Power Input
Ethernet Port
WPS and Reset Button
DC

Remove Cover box
01 Remove Cover box Remove Cover box01

Assemble the bracket and the stand
02
Assemble the bracket and the stand
Assemble the bracket and the stand02

Assemble the bracket and the stand
02 Assemble the bracket and the stand 02

Assemble the bracket and the stand
02 Assemble the bracket and the stand 02

Plug the power cable into the camera.
Plug the adapter
03
When SmartCube 300W is powered on, the
green led will be on first. After SmartCube
300W is ready, the red len will be on and the
green led will be off.
Power on SmartCube 300W
04

Please use three screws to fix the camera.
Mount the camera
05 Adjust the View of the Camera06

After inserting a micro SD card, the blue led will
be on. Please use empty microSDHC Class 10
8GB or better.
Insert a Micro SD07
micro
SD
This step is not needed during the setup. But if
the camera is not responding and you want to
restore the camera to default settings. Please
press and hold the Reset/WPS button for 10
seconds,then release the button. The red led
will be off and green led will be on. After
SmartCube 300W is ready, the red led will be
on and the green led will be off.
Reset the Camera to default settings
08
10 seconds
Reseting Reset OK

You can configure the camera by connecting
the SmartCube's LAN port to your router's LAN
port by Ethernet cable. Then use your
Smartphone, to setup the camera's WiFi
setting.
Set up the camera by Ethernet port
09
Camera
Smartphone
Wireless Router
LAN Port
a
LAN Port
10 Download the AirLive APPCAM APP
Please visit App Store or Google Play to
download AirLive APPCAM APP. You can use
QR code scanner software directly or simply
search the “AirLive APPCAM”.
App Store Google Play
APPCAMAPPCAM
APPCAM

Start the AirLive APPCAM
11
Click the “AirLive APPCAM” icon on your device.
12
Click "Camera" to add SmartCube 300W
Search and Add the Camera

13
Please scan the camera's UID QR Code to add
the camera. You can find the camera's UID QR
code on the "QR Code card" or in the back of
the camera.
Scan the QR code
QR Code
card
Or
Back of the camera
Key in the password to link the camera. The
default password is "airlive".
Please select “SmartCube series” ,no matter
the camera connects to Internet by wireless or
wired.
Key in the password14
UB83DSARUZ58G6XW123A

15
Please change the password when logging to
the camera at the first time. Please do not
forget this password as you will be asked to
enter this new password when setting up the
camera.
Change the password 16 Live View

17
Please click on the "Web UI" button to setup the
camera via Mobile Web Wizard. When
prompted for username and password, please
enter "admin" as the username and enter your
new password as password.
Setup the Camera
Important: The Web UI function only works when
the SmartCube and the smart phone is on the
same local network. For example, if you install
the camera at home, the function only works
when your smart phone is connected to your
home's network.
18
Click the Setup tab to switch the page.
Mobile Web Wizard

19
In the Setup page, please click on the
"Wireless"
Mobile Wizard Wifi Setup 20
Please select SSID and key in the password
then click on the "Save".
Mobile Wizard Wifi Setup

21
After connecting to the router, The wizard will
show "Connected".
Mobile Wizard Wifi Setup 22
When user unplugs the Ethernet cable, please
replug the power cable at the same time.
Wireless connection will be rebuilt in three
minutes.
Mobile Wizard Wifi Setup

23
Click the buttons to switch the page.
Mobile Web Wizard 24
For first time configuration, please
click on the "Wizard" and follow through and
finish the process.
Setup the Camera

25
In the Live View page. you can see Live View
from this page.
Live View 26
You can see the temperature and humidity
values on this page. For more alarm settings,
please click "Setup" button.
Sensors

27
Please select setup page, click "Wizard" button.
SmartCube 300W Setup 28
Please change the default password and click
"Next" button.
Change the camera password
