Oxford Instruments ANDOR iKon-XL Series Installation instructions

iKon-XL Hardware Guide
andor.com © Andor Technology Ltd. 2019
Version 1.9 rev 21 Oct 2019

Version 1.9 rev 21 Oct 2019
2
IKon-XL
TABLE OF CONTENTS
SECTION 1: INTRODUCTION............................................................................................................... 9
1.1 TECHNICAL SUPPORT.......................................................................................................... 10
1.2 DISCLAIMER .......................................................................................................................... 11
1.3 COPYRIGHT AND PROTECTIVE NOTICES........................................................................... 11
1.4 TRADEMARKS AND PATENT INFORMATION....................................................................... 11
1.5 SUPPLIED COMPONENTS .................................................................................................... 12
1.5.1 iKon-XL ModeL options .............................................................................................. 13
1.5.2 optionaL accessories .................................................................................................. 14
1.5.3 repLaceMent shutters.............................................................................................................14
SECTION 2: PRODUCT OVERVIEW................................................................................................... 15
2.1 EXTERNAL FEATURES OF THE IKON XL ............................................................................. 15
2.2 REAR PANEL .......................................................................................................................... 16
2.3 CAMERA CONTROL UNIT (CCU-500)................................................................................... 18
2.4 POWER REQUIREMENTS ..................................................................................................... 19
SECTION 3: INSTALLATION ............................................................................................................... 20
3.1 TRANSPORT AND STORAGE INFORMATION ...................................................................... 20
3.2 MOUNTING THE IKON XL USING THE MOUNTING FLANGE ............................................. 20
3.3 ATTACHING TO MOUNTING POSTS ..................................................................................... 21
3.4 INSTALLING THE CCU-500 CAMERA CONTROL UNIT ....................................................... 21
3.5 CONNECTING THE IKON-XL TO THE PC............................................................................. 22
3.6 CONNECTING THE IKON-XL TO THE CAMERA CONTROL UNIT AND POWER SUPPLY
23
3.7 CONNECTING A COOLING SYSTEM.................................................................................... 24
3.7.1 iMportant considerations when using Liquid cooLing systeMs ...................................... 24
3.7.2 cooLing hose connectors........................................................................................... 24
3.8 COOLANT RECOMMENDATIONS ......................................................................................... 25
3.9 CONNECTING THE LIQUID COOLING SYSTEM .................................................................. 25

Version 1.9 rev 21 Oct 2019
3
IKon-XL
3.9.1 connecting the cooLant hoses ................................................................................... 25
3.9.2 disconnecting the cooLant hoses ............................................................................... 25
3.10 INSTALLING SOFTWARE AND USB DRIVERS ..................................................................... 26
3.10.1 MiniMuM coMputer requireMents ................................................................................ 26
3.10.2 instaLLing soLis software and usB drivers ................................................................ 26
3.10.3 new hardware wizard (windows)................................................................................ 26
3.11 INSTALLING A USB 3.0 CARD (IF REQUIRED) ..................................................................... 27
3.11.1 disaBLing power ManageMent for the usB 3.0 host controLLer................................ 27
3.12 INSTALLING A FIBRE OPTIC CARD...................................................................................... 27
3.12.1 instaLLing fiBre optic card drivers (windows onLy) .................................................... 28
SECTION 4: OPERATION .................................................................................................................. 29
4.1 EMERGENCY MAINS DISCONNECTION .............................................................................. 29
4.2 POWER-UP SEQUENCE........................................................................................................ 29
4.3 POWER-DOWN SEQUENCE.................................................................................................. 29
4.4 USING THE IKON-XL ............................................................................................................. 29
SECTION 5: MAINTENANCE.............................................................................................................. 30
5.1 REGULAR CHECKS ............................................................................................................... 30
5.2 ANNUAL ELECTRICAL SAFETY CHECKS ............................................................................ 30
5.3 GENERAL CLEANING & DECONTAMINATION INFORMATION............................................ 30
5.4 CLEANING THE CAMERA WINDOW..................................................................................... 30
5.4.1 tooLs required ........................................................................................................... 31
5.4.2 window cLeaning procedure ....................................................................................... 31
5.5 FUSE REPLACEMENT ........................................................................................................... 31
5.6 REPLACEMENT OF THE SHUTTER ...................................................................................... 32
5.7 COOLING HOSES AND CONNECTIONS............................................................................... 32
5.8 CCU-500 COOLING FANS ..................................................................................................... 32
SECTION 6: TROUBLESHOOTING .................................................................................................... 33
6.1 PREVENTING CONDENSATION ............................................................................................ 33
6.2 QUICK TROUBLESHOOTING GUIDE.................................................................................... 33

Version 1.9 rev 21 Oct 2019
4
IKon-XL
APPENDIX A: TECHNICAL SPECIFICATIONS................................................................................... 34
APPENDIX B: MECHANICAL DRAWINGS......................................................................................... 37
APPENDIX C: DEWPOINT INFORMATION ........................................................................................ 40
APPENDIX D: REFERENCE INFORMATION...................................................................................... 41
APPENDIX E: OTHER INFORMATION ............................................................................................... 44

Version 1.9 rev 21 Oct 2019
5
IKon-XL
Revision HistoRy
Version Released Description
1.0 30 Nov 2016 Initial Release
1.1 13 Jan 2017
Provided additional clarication on sensor variants (Sections 1.5.1, 2.1 and
Appendix A).
Updated power requirements (Appendix A).
1.2 30 Jun 2017 Updated Mechanical Drawing for Deep Cooled model (Appendix B).
1.3 13 Oct 2017 Expanded and updated bre optic card and USB 3 connection information
(Sections 3.11 and 3.12).
1.4 18 Dec 2017
Camera I/O logic information expanded (Section 2.2).
Added some further more detail during installation steps (Section 3).
Further updates to software installation steps (Sections 3.11 and 3.12).
Added link to decontamination form (Section 5.3).
1.5 14 Mar 2018
Corrected active pixels of 231 sensor model to 4096 x 4108 and aligned specs
with Specication Sheet.
Added further details on iRIG-B (Section 2.2).
Updated software installation steps- including Linux (Section 3.10)
Updated power requirements (Appendix A).
Added notes to indicate the bre optic is multimode type and that CCU-500 can
be remotely powered on and off.
1.6 10 May 2018 Claried mounting information (Section 3.2).
Updated information on condensation risks and prevention (Sections 3.1 and 6.1)
1.7 17 Jul 2018 Added information on Sensor Compensation and Baseline clamp software settings
(Appendix D)
1.8 24 Apr 2019 Updated USA and Asia-Pacic ofce addresses.
1.9 21 Oct 2019 Updated mechanical drawings and backplate views. Updated China ofce
address.
Updates to tHe ManUal
Changes are periodically made to the product and these will be incorporated into new editions of the manual. Please
check for new releases of the manual in MyAndor: http://my.andor.com/login.aspx. If you nd an issue in this manual

Version 1.9 rev 21 Oct 2019
6
IKon-XL
safety and WaRning infoRMation
READ THIS INFORMATION FIRST
1. If the equipment is used in a manner not specied by Andor, the protection provided by the equipment may be
impaired.
2. Before using the system, please follow and adhere to all warnings, safety, manual handling and operating
instructions located either on the product or in this Hardware Guide.
3. Users must be authorised and trained personnel only; otherwise this may result in personal injury, and/ or
equipment damage and impaired system performance.
4. There are no user-serviceable parts inside the product and the enclosure must not be opened. Only authorised
service personnel may service this equipment.
5. Do not position this product so that it is difcult to operate the Mains disconnecting device. See SECTION 4.1,
“Emergency Mains Disconnection”.
6. Protective earth is an integral part of the protection against electric shock in this product, and is provided via
the earth pin of the external power supply. Ensure that this is plugged into the building earth system via the
mains socket. Do not tamper with any of the earthing measures.
7. Only the correctly specied mains supply should be used.
8. Only the AC/DC external power supply provided with the product should be used.
9. Only the power supply cord provided with the product should be used. Should this not be correct for your
geographical area, contact your local Andor representative.
10. Make sure the power supply cord is located so that it will not be subject to damage. If replacement of the
detachable power supply cord is required, ensure replacement is of same type and rating.
11. Only use the CCU-500 congured for the specied cable length. Using a 5 m cable with a unit congured for
15 m cable may result in damage to the camera.
12. Performance of the system may be adversely affected by rapidly changing environmental conditions or
operation outside of the operating conditions specied in “TECHNICAL SPECIFICATIONS”
13. While running an experiment, try to keep temperature as stable as possible.
14. This equipment has not been designed and manufactured for the medical diagnosis of patients.
15. Electromagnetic Compatibility: This is a Class A product. In a domestic environment this product may cause
electromagnetic interference, in which case the user may be required to take adequate measures.
16. This product has been designed and tested to perform successfully in a normal (basic) electromagnetic
environment, e.g. a typical life science test laboratory, as per the EU EMC Directive. It is not designed to
operate in a harsh electromagnetic environment, e.g. close to the following equipment: EMI/RFI generators,
electrostatic eld generators, electromagnetic or radioactive devices, plasma sources, arc welders, x-ray
instruments, intense pulsed sources, or other similar sources of high energy elds whose emissions are not
within the normal range expected under the EU EMC Directive.
17. Please note that this product is not designed to provide protection from ionising radiation. Any customer using
this product in such an application should provide their own protection.
18. Your product is a precision scientic instrument containing fragile components. Always handle it with care.

Version 1.9 rev 21 Oct 2019
7
IKon-XL
19. Ensure bre cables are not bent tightly as this may damage the internal optical bre. For transport or storage,
bre cables should be coiled loosely with a diameter of 300 mm or greater.
20. Do not wet or spill liquids on the product, and do not store or place liquids on the product.
21. If spillage occurs on the product, switch off power immediately, and wipe off with a dry, lint-free cloth.
22. If any ingress of liquids has occurred or is suspected, unplug the mains cables, do not use, and contact Andor
Customer Support.
23. When using a liquid cooling system it is recommended that an overpressure device is tted to avoid leaks that
may nd their way to the mains electricity supply and create a hazard. Refer to the information in SECTION 3.7
for general guidelines on the correct installation and use of a liquid cooling system.
24. See SECTION 5.1, “Cleaning and Decontamination”.
25. Do not expose the product to extreme hot or cold temperatures.
26. Do not expose the product to open ames.
27. Do not allow objects to fall on the product.
28. Keep this hardware guide in a safe place for future reference.

Version 1.9 rev 21 Oct 2019
8
IKon-XL
WaRning and safety labels
The following warning labels appear on the product:
When connected via the bre optic connection the iKon-XL is classied as a Class 1 laser product under IEC 60825-1
and CDRH Title 21 CFR 1040.10. The Class 1 laser classication indicates that emissions are safe under all conditions of
normal use and does not constitute an eye or skin hazard.
The Camera Control Unit (CCU-500) contains hazardous voltages (100-240 VAC). Do not attempt to open the CCU-500
enclosure. There are no user serviceable components inside.
The CCU-500 product identication and serial label (above left) shows the product model and serial numbers and build
date. It is located on the right side panel.
CCU-500 Manufacturer: Andor Technology Ltd., Belfast, BT12 7AL, UK.
The serial label of the iKon-XL (above right) is located on the side plate of the camera. It shows the product model and
serial numbers and build date.
WoRking WitH optical fibRes
1. Optical bres can easily be damaged by bending or general mishandling. Ensure that the minimum curvature is
never exceeded when handling. Recommended minimum bend radius is 30 mm.
2. Optical bres are prone to damage by bending local to the connector. Take care that the bre optic cable has
adequate strain relief/support at the connection and that the routing avoids tight radii.
3. The coupler is not designed to withstand pulling of the bre- always insert or remove using the connector body.
If the bre is pulled the system performance could be compromised or the system may fail.
Unpacking infoRMation
Carefully unpack the unit and retain the packaging materials to transport or return equipment if required:
• If the equipment appears damaged in any way, return it to sales outlet in its original packaging.
• No responsibility for damage arising from the use of non-approved packaging will be accepted.
• Ensure all items and accessories specied at the time of ordering and as detailed on the packing list are present:
if any items are missing, please contact your sales representative.
• The camera has an uneven weight distribution- take care when lifting.
• The camera has a shipping cover - remove before use and store in a safe place so it may be used at a future time.

Version 1.9 rev 21 Oct 2019
9
IKon-XL
SECTION 1: INTRODUCTION
This manual provides an overview of the iKon-XL camera series. The iKon-XL houses several large area high resolution
CCD sensor variants and housing and cooling congurations to suit demanding applications such as Astronomy or
X-ray/Neutron radiography (see Section 1.5.1). This manual includes a description of the main features of the iKon-XL,
installation, routine operation and troubleshooting. It also provides a summary of some of the technical features of the
iKon-XL series. For further information on operation and control of the iKon-XL refer to the relevant software guide e.g.
Solis, and to the andor website for further technical information to help you get the best from your camera.
Figure 1: The iKon-XL (Flexi-model shown)

Version 1.9 rev 21 Oct 2019
10
IKon-XL
1.1 tecHnical sUppoRt
If you have any questions regarding the use of this equipment, please contact the representative* from whom your
system was purchased, or:
Europe USA
Andor Technology Ltd.
7 Millennium Way
Springvale Business Park
Belfast
BT12 7AL
Northern Ireland
Tel. [phone]
Fax. [phone]
Andor Technology
300 Baker Avenue
Suite # 150
Concord
MA 01742
USA
Tel. [phone]
Fax. [phone]
Asia-Pacic China
Andor Technology (Japan)
5F IS Building
3-32-42 Higashi-Shinagawa
Tokyo 140-0002
Japan
Tel: [phone]
Fax: [phone]
Andor Technology (China)
Haitong Times Business Center,
Building B2 West,
No.11 West Third Ring North Road,
Haidian District,
Beijing,
100089
China
Tel: [phone]
Fax. [phone]
* The latest contact details for your local representative can be found on the Contact and Support page of our website.

Version 1.9 rev 21 Oct 2019
11
IKon-XL
1.2 disclaiMeR
THE INFORMATION CONTAINED HEREIN IS PROVIDED “AS IS” WITHOUT WARRANTY, CONDITION OR
REPRESENTATION OF ANY KIND, EITHER EXPRESS, IMPLIED, STATUTORY OR OTHERWISE, INCLUDING BUT NOT
LIMITED TO, ANY WARRANTY OF MERCHANTABILITY, NON-INFRINGEMENT OR FITNESS FOR A PARTICULAR
PURPOSE.
IN NO EVENT SHALL ANDOR BE LIABLE FOR ANY LOSS OR DAMAGE, WHETHER DIRECT, INDIRECT, SPECIAL,
INCIDENTAL, CONSEQUENTIAL OR OTHERWISE HOWSOEVER CAUSED WHETHER ARISING IN CONTRACT, TORT
OR OTHERWISE, ARISING OUT OF OR IN CONNECTION WITH THE USE OF THE INFORMATION PROVIDED HEREIN.
1.3 copyRigHt and pRotective notices
The copyright in this document and the associated drawings are the property of Andor Technology Ltd. and all rights
are reserved. This document and the associated drawings are issued on condition that they are not copied, reprinted or
reproduced, nor their contents disclosed.
The publication of information in this documentation does not imply freedom from any patent or proprietary right of
Andor Technology Ltd. or any third party.
1.4 tRadeMaRks and patent infoRMation
Andor and the Andor logo are trademarks of Andor Technology Ltd. Andor Technology Ltd. is an Oxford Instruments
company. All other marks are property of their owners.
iKon-XL Manufacturers Information
Andor Technology Ltd., Belfast, BT12 7AL, UK.

Version 1.9 rev 21 Oct 2019
12
IKon-XL
1.5 sUpplied coMponents
Description Quantity
iKon-XL CCD Camera
(model as ordered: refer to Section 1.5.1
Supplied with shipping plate tted)
1
Software & Driver
CDs (or Flash Drive)
(Solis and SDK are ordered
separately)
1Hardware Guide in
electronic format 1
Fibre Optic
PCIe Card
1Quick Start Guide 1
USB3
PCIe Card
1
FIbre optic LC-LC
(multimode)
(15 m)
1
CCU-500 Camera
Control Unit and
country specic
power cord
1
BNC-SMA Cable
(2 m)
3
CCU-500 to camera
cable
(5 m as standard)
1USB 3.0 Cable
(3 m) 1
CCU-500 19”
mounting brackets-
pair. Includes 6 off
M5 x 10 csk screws
1Anti-static
Wrist band 1
CCU-500 mounting
lugs. Includes 6 off
M5 x 10 csk screws
1Coolant hose inserts 2
Performance Booklet 1Hex Key
(3 mm) 1

Version 1.9 rev 21 Oct 2019
13
IKon-XL
1.5.1 ikon-Xl Model options
There are a number of models of ikon XL, based on either the “230” or the “231” sensor (see also Section 2.1). The
options for each model can be identied by the product codes as outlined below:
iKon-XL 230 Sensor Models
Sensor Types Cooling Options Shutter Options
Description Code Description Code Description Code
BV: midband AR coating EA01 Flexi Cooling (max. cooling -75ºC @ coolant
temp of 10ºC; -55ºC max. air cooling) CStandard (0°C and +30°C) S
Broadband AR coating EA02 Deep Cooled (max. cooling -100ºC @ coolant
temp of 10ºC) DExtended Range (-30°C and +30°C) S-EXT
No Shutter 0
Therefore, for the following example the iKon-XL 230 camera with model code XL-EA01-DS would have the following
options:
(EA01) The sensor type is BV: midband AR coating
(D) The cooling type is Deep Cooled
(S) The shutter type is Standard Shutter
iKon-XL 231 Sensor Models
Sensor Types Cooling Options Shutter Options
Description Code Description Code Description Code
BV: midband AR coating EA03 Flexi Cooling (max. cooling -75ºC @ coolant
temp of 10ºC; -55ºC max. air cooling) CStandard (0°C and +30°C) S
Broadband AR coating EA04 Deep Cooled (max. cooling -100ºC @ coolant
temp of 10ºC) DExtended Range (-30°C and +30°C) S-EXT
EX2 dual AR coating EA05 No Shutter 0
BR-DD deep depletion with
fringe suppression EA06
BEX2-DD deep depletion
with fringe suppression and
dual AR coating
EA07
Therefore, for the following example the iKon-XL 231 camera with model code XL-EA05-CS-EXT would have the
following options:
(EA05) The sensor type is EX2 dual AR coating
(C) The cooling type is Flexi Cooled
(S-EXT) The shutter type is Extended Range Shutter

Version 1.9 rev 21 Oct 2019
14
IKon-XL
1.5.2 optional accessoRies
A range of accessories is available for the iKon-XL (see table below). The iKon-XL is intended only for use with accessories
supplied and recommended by Andor. Please contact your local Andor representative if further information is required.
Description Code
15 m camera cable with straight attachment for the CCU-500A (iKon-XL Flexi model)
If this is ordered it will be provided instead of the standard 5 m cable.
XL-F-CAB-ST-15M
15 m camera cable with straight attachment for the CCU-500B (iKon-XL Deep Cooled model)
If this is ordered it will be provided instead of the standard 5 m cable.
XL-DC-CAB-ST-15M
Additional 25 m multimode bre optic cable, LC-LC patch lead OM2. FIBR-25M
Additional 100 m multimode bre optic cable, LC-LC patch lead OM3. FIBR-100M
Hard shell protective transport case for the iKon-XL Flexi model. Tailored to dimensions of the
iKon-XL Flexi model for secure transport to and from observing sites.
XL-F-TRANS-CASE
Hard shell protective transport case for the iKon-XL Deep Cooled model. Tailored to dimensions
of the iKon-XL Deep Cooled model for secure transport to and from observing sites.
XL-DC-TRANS-CASE
1.5.3 ReplaceMent sHUtteRs
Description Code
Replacement ‘standard’ shutter unit for the iKon-XL.
For use between 0°C and +30°C ambient temperatures. XL-SH-STD
Replacement ‘extended temperature range’ shutter unit for the iKon-XL.
For use between -30°C and +30°C ambient temperatures.
XL-SH-EXT

Version 1.9 rev 21 Oct 2019
15
IKon-XL
SECTION 2: PRODUCT OVERVIEW
This section provides an overview of the iKon-XL. Please note that iKon-XL conguration including housing, cooling
connectivity and mounting ange may vary for your specic model. Please refer to the additional information supplied for
details of any model specic differences.
Flexi-Cooling Model: May be congured for air or liquid cooling. With liquid cooling it provides max. cooling of -80ºC
[75ºC] at a coolant temp of 10ºC [16ºC]. When set for air cooling, a maximum cooling of -60ºC may be achieved.
Deep Cooled Model: The deep cooled model facilitates liquid cooling only, achieving a maximum cooling of -100ºC
[95ºC] at a coolant temp of 10ºC [16ºC].
2.1 eXteRnal featURes of tHe ikon Xl
Figure 2: iKon-XL (Deep Cooled model shown)
Mounting Flange
The standard conguration of mounting ange has 8 x threaded holes for M5 bolts on 189 PCD. Refer to the additional
supplied information or specication sheet appropriate for your specic model.
Sensor
The iKon-XL features high resolution CCD sensors such as the CCD-230-84 or CCD-231-84 16.8 Megapixel CCD
sensors. Andor’s unique UltraVacTM vacuum technology has been applied to the iKon-XL. UltraVac provides a permanent
hermetically sealed enclosure for maximum QE and cooling performance over many years operation.
Camera Window
The standard iKon-XL features a Single AR coated UV grade silica window for optimum transmission. For more
information on camera windows please see http://www.andor.com/learning-academy/camera-windows-optimizing-for-
different-spectral-regions.
Shutter
A mechanical shutter is an option for the iKon-XL for e.g. dark-frame subtraction for at-eld correction of long exposure
images. Where applicable, the shutter is mounted onto the faceplate. This has been designed so that simple in-eld
replacement of the shutter is possible.
Mounting
Flange
Sensor
Mounting post
locations Camera
Window

Version 1.9 rev 21 Oct 2019
16
IKon-XL
Mounting Post Locations
Deep Cooled model: Four sets of 2x ¼ -20 UNC mounting holes are located at each 90 degrees.
Flexi-cooling model: Four sets of 1x ¼ -20 UNC mounting holes are located at each 90 degrees.
2.2 ReaR panel
Figure 3: Rear Panel
USB 3.0
Connects the iKon-XL to the control PC USB 3 card via a high speed USB 3.0 connection.
TTL / Logic
The TTL/Logic connection permit connection to other devices for synchronisation and control of re, trigger and shutter
operations. Connector type: SMA, provided with SMA - BNC cable Fire (Output), External Trigger (Input), Shutter
(Output).
Input & Output Timing Hardware
• VIH (High level input voltage): 2.2 V (min) to 5 V (max)
• VIL (Low level input voltage): 0.88 V (min)
Water
Cooling
Power Input
I2C
TTL/Logic
IRIG-B
USB 3.0
Fibre Optic

Version 1.9 rev 21 Oct 2019
17
IKon-XL
External Trigger Input (at connector)
• Fire. Shutter, Arm and Frame Output (at connector)
• Use 50 Ω cable and high impedance input (>1kΩ)
• Drive both TTL and CMOS unterminated input
I2C
The I2C provides a connection option via the I2C interface. Compatible with Fischer type SC102A054-130 connector. (1)
Shutter (TTL), (2) I2C Clock, (3) I2C Data, (4) +5 Vdc, (5) Ground.
Fibre Optic
The LC bre-optic I/O connection provides a convenient connection over longer distances: 15 m as standard (25 m and
100 m options are also available from Andor). Note that the bre is the multimode (MM) type.
IRIG-B
The iRIG-B connection is compatible with IRIG-B standard (GPS with 10 ms resolution). The iRIG info is only stored
in the IRIGDATA eld and is retrieved from an independent time source – it does not have any bearing on the DATE or
FRAME elds whose data is from the PC. The table of IRIG data is available from FITS les.
Liquid Cooling Connections (liquid cooled models only)
Liquid cooling connections provide the facility for connection to recirculator or other water/liquid cooling system. Refer
to Section 3.7.
Power
Power input connection for connection to the CCU-500. Refer to Section 2.3.
Notes:
Minimum cable clearance required at rear of camera 150 mm.
12
3
4
5

Version 1.9 rev 21 Oct 2019
18
IKon-XL
2.3 caMeRa contRol Unit (ccU-500)
The Camera Control Unit provides control functions and a stable DC power supply for the iKon-XL.
CCU-500A Supplied with the iKon-XL Flexi-cooling Model
CCU-500B Supplied with the iKon-XL Deep Cooled Model
Figure 4: The CCU-500 Camera Control Unit (front View)
Display Diagnostics
Switch display lights on or off. Switching the diagnostic lights off may be useful if background light levels must be
minimised.
Output Good
This LED (green) indicates that the power status of the CCU-500 is within normal parameters.
Thermal Alarm
This LED (red) illuminates to warn the user if the CCU-500 unit overheats e.g. due to obstruction to the cooling fans, or if
there is a fan failure.
Remote Shutdown
Enables remote power on/off using a cable with BNC connection. The LED (orange) illuminates if the unit has been
remotely powered down (Note there is no indication of power status in Solis).
• CCU-500 On: Open-circuit (or logic 0).
• CCU-500 Off: User must supply drive TTL logic high +2.4 V at 10 mA to powerdown the CCU-500.
Camera Cable Outlet
A camera control cable connects the CCU-500 to the iKon-XL camera. The standard supplied cable is 5 metres long- if
the CCU-500 is to be situated at a longer distance (15 m options available) this must be specied at time of ordering as
the CCU-500 must be congured for the cable used.
Warning
LEDs
Display
Diagnostics
Switch
Remote
Shut-down
Camera
Cable Outlet

Version 1.9 rev 21 Oct 2019
19
IKon-XL
Figure 5: The CCU-500 Camera Control Unit (Rear View)
Power Input (& Power Switch)
There is a switched power input (I= on, O= Off) from the mains AC supply to the CCU-500. Note that there are fuses in
the line input (see Section 5.5 for details and replacement procedure).
Fans
3 fans provide cooling to the unit- ensure that there is sufcient space at the front and rear of the unit for unrestricted air
ow (minimum 100 mm).
2.4 poWeR ReqUiReMents
Ensure that the power connector for the iKon-XL camera is inserted securely. The connector is keyed to aid correct
orientation. Refer to technical specications for power supply requirements.
NOTES:
1. The electrical mains lead should be certied for use in your country and in applicable countries the plug
must be tted with a 240V 5A fuse.
2. The iKon-XL is designed to use the CCU-500 camera control unit for power and signal operations. If users
use any other power supply, they do so at their own risk.
Power Input Fans (x3)

Version 1.9 rev 21 Oct 2019
20
IKon-XL
SECTION 3: INSTALLATION
WARNINGS:
• PRIOR TO COMMENCING INSTALLATION, THE USER SHOULD REFER TO THE SAFETY AND WARNING
INFORMATION AND UNPACKING INSTRUCTIONS AT THE BEGINNING OF THIS MANUAL.
• THE IKON-XL WEIGHS ~8-12 KGS (~18-26 LBS). DUE CARE MUST BE TAKEN WHEN LIFTING THE CAMERA.
ENSURE THAT THE MOUNTING AND CONNECTED ASSEMBLY IS SECURE AND ABLE TO SUPPORT THE
WEIGHT OF THE CAMERA.
• POWER CABLING AND CONTROL CABLES SHOULD BE ROUTED TO PREVENT ACCIDENTS, DAMAGE AND
ACCIDENTAL UNPLUGGING; AVOID BEND RADII OF LESS THAN 30 MM AND ENSURE THERE IS ADEQUATE
CABLE STRAIN RELIEF FOR THE CONNECTORS.
•
THE CCU-500 IS CONFIGURED AT THE FACTORY FOR THE LENGTH OF CABLE USED TO CONNECT IT TO THE
IKON-XL. IF A CCU-500 CONFIGURED FOR 15 M CABLE IS CONNECTED TO A CAMERA USING A 5 M CABLE
THE CAMERA WILL BE DAMAGED.
• TEMPERATURE AND HUMIDITY MUST MEET THE SPECIFICATIONS DEFINED IN TECHNICAL
SPECIFICATIONS.
3.1 tRanspoRt and stoRage infoRMation
• The iKon-XL is packed in a normal transport packaging for shipping. Hard shell transport cases are available for the
iKon-XL for convenient and safe transport of the iKon-XL to and from the installation site e.g. observatory.
• Allow the product to reach the ambient temperature after unpacking- especially if moving from a colder environment
to a warm environment as this may lead to condensation (see Section 6.1 for further information).
Storage
• Storage Temperature: -30°C to 50°C.
• If it is to be stored after use at a temperature below the coolant freezing point, ensure that all liquid coolant has been
expelled from the camera.
3.2 MoUnting tHe ikon Xl Using tHe MoUnting flange
The iKon-XL mounting ange features 8 off M5 tapped holes x20 deep on a 189 PCD. These can be used to secure the
iKon-XL to the mounting plate of the telescope or other optical system.
8 off M5 tapped
holes x20 deep
on a 189 PCD iKon-XL secured
to mounting plate
