Ozito ELM-1800 User manual

ECOMOW
ELECTRIC MOWER
1800W 420mm
INSTRUCTION MANUAL
SPECIFICATIONS
Power: 1800W
Input: 220-240V~50/60Hz
No Load Speed: 3,200/min
Cutting Diameter: 420mm
Cutting Heights: 20mm, 30mm, 40mm,
50mm, 60mm & 70mm
Catcher Capacity: 45 litre
Weight: 14.5kg
ELM-1800
WHAT’S IN THE BOX
Electric Lawn Mower
Handle Securing Set &
Cable Clips
3 Piece Grass Catcher
ozito.com.au

1
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
KNOW YOUR PRODUCT SETUP & PREPARATION
1 Motor cover
2 Lifting handle
3 Lower handle
4 Cord clips
5 Start/stop lever
6 Cord retainer
7 Front wheel
8 Height adjustment lever
9 Quick adjustment knob
10 Rear wheel
11Grasscatcherap
12 Grass catcher
13 Handle securing set
14 Upper handle
1. ASSEMBLY
ECOMOW ELECTRIC MOWER
1
910 11 12 13
2 3 4 6
7 8 14
5
WARNING!: ENSURE THE TOOL IS DISCONNECTED
FROM THE POWER SUPPLY BEFORE ASSEMBLY.
Fitting the Lower Handle to Mower Body
1. Unscrew quick adjustment
knobonbothsides,tthelower
handle onto the threaded ends.
2. By using the lines as a guide
for correct alignment, adjust
the lower handle to the correct
position for comfortable height,
thentandsecureinplacewith
the quick adjustment knobs.
1. Place the upper handle over
the lower handle. From the
insideofthehandle,tthe
bolts from the handle securing
set.
2. Place the plastic spacer onto
thethread,thentthehandle
securing knobs and tighten
rmly.
Fitting the Upper Handle to the Lower Handle
Bolt
Plastic
Spacer Knob
4 Cord clip 13 Handle securing set
413

1
OPERATION
1. Make a loop with the cord and
secure over the hook.
2. Connect the plug into the
extension cord.
The height adjustment lever provides 6 cutting heights from 20mm to
70mm.
1. Pull the height adjustment lever
outward and adjust to the desired
cutting height.
WARNING!: WHEN ASSEMBLING THE GRASS
CATCHER BACK TO THE MOWER AFTER
EMPTYING, ALWAYS ENSURE THERE IS NO BUILD
UP OF GRASS IN THE GRASS CHUTE. IF NEEDING TO
CLEAR THE GRASS, ALWAYS ENSURE THE MOWER
IS DISCONNECTED FROM THE POWER SUPPLY
PRIOR TO CLEARING. A BUILD UP OF GRASS IN THE
GRASS CHUTE MAY PREVENT GRASS FROM MOVING
INTO THE GRASS CATCHER EFFECTIVELY.
1. Secure the power cord using the
two cord clips (supplied).
1. Align the two halves and push
each individual plastic lug into its
opposite location. Ensure lugs
engage correctly and lock/click in
place.
2. Fit the top onto the catcher
assembled in step 1. Align each
individual plastic lug into its
opposite location.
WARNING!: DISCONNECT THE MOWER FROM
THE POWER SUPPLY AND ENSURE THE BLADE
HAS STOPPED COASTING BEFORE ADJUSTING THE
HEIGHT.
Securing the Power Cord to the Handles
“CLICK”
“CLICK”
Assembling the Grass Catcher
“CLICK” “CLICK”
“CLICK”
“CLICK”
Fitting and Removing Grass Catcher
Using the Cord Retainer
HOOK
2. PREPARATION
Cutting Height Adjustment
The cord retainer prevents the extension cord from being disconnected
during use.
CAUTION: BE CAREFUL DURING CUTTING HEIGHT
ADJUSTMENTS OF THE LAWN MOWER TO PREVENT
ENTRAPMENT OF THE FINGERS BETWEEN MOVING
HEIGHT ADJUSTMENT LEVER AND THE MOWER
HOUSING.
3. Toemptythegrasscatcher,liftthecatcherapandwiththeother
hand remove the catcher.
The catcher must be attached to the two raised hooks on the mower.
1. Liftupthecatcherapandguide
the catcher over the two hooks
2. Lower the grass catcher in place
andlowerthecatcherap.
Assemble the three sections of the grass catcher.
Grass Catcher Volume Indicator
Indicatoroatsupwhenempty.
Indicator is down when full.
Empty
Full

1
3. HOW TO MOW
1. Press and hold the lock-off button
in.
2. Pull the Start/stop lever towards
the handle and hold in position,
the motor will now start.
3. Release the lock-off button
4. Release the Start/stop lever to
stop the mower.
• Always use an approved extension lead suitable for power input of
this tool.
• Heavy duty power leads recommended.
• While using your lawn mower always wear substantial footwear
and long trousers.
• Make sure the lawn is clear of sticks, stones, wire and debris; they
could be thrown by the blade.
• Before using the lawn mower and after any impact, check for signs
of wear or damage and repair as necessary.
• Replace a worn or damaged blade together with the blade bolt to
preserve balance.
Topreventaccidentalstartupthemoweristtedwithadualaction
switch
Switching On/Off
2
1
WARNING! THE BLADE WILL COAST AFTER
THE SWITCH HAS BEEN RELEASED. BE AWARE
OF THE NECESSARY TIME IT TAKES FOR THE BLADE
TO STOP COASTING. DO NOT ATTEMPT TO STOP THE
BLADE.
Start mowing the edge of the lawn
nearest to the power point so the
lead is laid out on the lawn you have
already cut.
For optimum grass collection, always mow in a straight line; do
not swing the lawn mower from side to side.
Mowing long thick grass may cause the motor speed to drop; you will
hear a change in the motor sound. If the motor speed drops you may
overload your lawn mower, which may cause damage. When mowing
inlongthickgrassrstcutwiththecuttingheightsetinthehighest
position, this will help reduce the load.
Do Not Overload the Mower
The tool is recommended for use with a residual current device with a
rated residual current of 30mA or less.
ELM-1800
WARNING! KEEP
EXTENSION CORD
AWAY FROM BLADES.
Overload Protection
The mower has an internal cut off switch which will stop the operation
of the motor temporarily if overloaded. This cut off switch will suddenly
stop the motor from operating should the motor become too hot
during the operation of the mower.
First disconnect the mower from the power supply and inspect blade
for any obstructions.
Wait of up to 2 minutes in cooling time, or longer depending on
ambient temperature and the operation being performed, before
switching On the mower and resuming normal operation.

Ozito Industries will not be responsible for any damage or injuries
caused by repair of the tool by an unauthorised person or mishandling
or mistreatment of the tool. This tool is designed for Domestic Home Use
only. Use in commercial or industrial environments will void the warranty.
CAUTION!: ALWAYS HANDLE THE BLADE WITH CARE
– SHARP EDGES COULD CAUSE SERIOUS INJURY.
USE GLOVES.
CARING FOR THE ENVIRONMENT
Tools that are no longer usable should not be disposed of with
household waste but in an environmentally friendly way. Please
recycle where facilities exist. Check with your local council
authority for recycling advice.
Recyclingpackagingreducestheneedforlandllandraw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
Blade SPELM1800-35
Blade Bolt SPELM1800-37
Front Wheel SPELM1800-42
Rear Wheel SPELM1800-19
Belt SPELM1800-5433
Switch Box Assy. SPELM800-01
Spare parts can be ordered from the Special Orders Desk
at your local Bunnings Warehouse.
For further information, or any parts not listed here, visit
www.ozito.com.au or contact Ozito customer service
Australia 1800 069 486
New Zealand 0508 069 486
E-mail: [email protected]
SPARE PARTS
MAINTENANCE
WARNING!: BEFORE CLEANING YOUR ECOMOW
ELECTRIC MOWER OR CARRYING OUT ANY
MAINTENANCE PROCEDURE, MAKE SURE THAT THE
MOTOR IS OFF AND THE TOOL DISCONNECTED FROM
THE POWER SUPPLY TO PREVENT ACCIDENTAL
STARTING.
Removing the Blade
1. To remove the blade bolt, hold
thebladermlyandwitha13mm
spanner (not supplied) loosen
the blade bolt by turning it anti-
clockwise.
2. Remove the blade bolt, washer and
blade.
3. Inspect for damage and clean as
necessary.
Replace the metal blade after
50 hours mowing or 2 years whichever is the sooner – regardless of
condition. If the blade is cracked or damaged replace it with a new one.
Never use a blade bolt if the insulated head is damaged, cracked or
missing.
1. Fit the blade to the fan with the tilt edges of the blade facing towards the
mower, ensuring the blade is located onto the fan location lugs correctly.
2. Re-assemble blade bolt with washer through blade and fan.
3. Holdthebladermlyandtightenbladeboltwitha13mmspanner(not
supplied), by turning in a clockwise direction. Do not over tighten.
Fitting the Blade
• Keep all nuts, bolts and screws tight to be sure the lawn mower is in a safe
working condition.
• Check the catcher frequently for wear or deterioration.
• Replace worn or damaged parts for safety.
• Onlyusethereplacementblade,bladebolt,andimpellerspeciedforthis
product.
• Be careful during adjustments of the lawn mower to prevent entrapment of
thengersbetweenmovingbladeandxedpartsofthemachine.
• Oil the wheel pins.
• When not in use, the mower should be stored in a dry, frost-free location, out
of reach of children.If the housing of the mower requires cleaning, do not use
solvents but a moist soft cloth and brush only.
• Frequentlycheckthewheelthreadsarermandtight.
VVolts Hz
~Alternating current W
/min Revolutions or
reciprocation per minute
no
Warning
Regulator compliance mark
Read instruction manual
Disconnect the mains plug
if the cord is damaged
or entangled
The sound power level
indicates by LwAin dB
Keep bystanders away. Do not mow whilst people especially children
or pets are in the mowing area.
Double insulated
Danger - High Voltage Keep extension cord
away from cutting blades.
Always keep the lawnmower on the ground when mowing.
Tilting or lifting the lawnmower may cause stones to be thrown out.
Beware of severing toes or hands. Do not put hands or feet near
a rotating blade.
Blades continue to rotate after machine is switched off
STOP
Switch Off! Remove plug from mains before adjusting, cleaning or if
cable is entangled or damaged. Keep the cable away from the blade.
Don’t use on steep slopes. Don’t use with rear flap
open.
Hertz
Watts
No load speed
96
CAUTION!: DO NOT TOUCH ROTATING BLADES.
DESCRIPTION OF SYMBOLS

SPARE PARTS Tool:
Model No.
Item
No. Description Part No.
How To Order
35
37
42
19
5433
01
Blade
Blade Bolt
Front Wheel
Rear Wheel
Belt
Switch Box Assy.
SPELM1800-35
SPELM1800-37
SPELM1800-42
SPELM1800-19
SPELM1800-5433
SPELM1800-01
Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any
further questions, please contact Ozito Customer Service on:
Australia: 1800 069 486
New Zealand: 0508 069 486
[email protected]
The following is a list of spare parts carried by Ozito.
Please contact Customer Service for any parts not
listed.
Tool: 1800W Electric Lawn Mower
Model No. ELM-1800
1
2
3
4
5
33
7
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
28
50
49
51
46
47
45
44
43
43
42
41
53
54
56
57
58
59
60
61
55 52 48
38
27
29
30
31
32
37
39
40
36
35
34
33
33
33
33
33
33
33
33
33
8
9
10
11
6
1-15
1-1
54-24
54-23
54-22
54-21
54-1
54-2
54-3
54-4
54-5
54-6
54-7
54-9
54-10
54-11
54-12
54-15
54-14
54-16
54-17
54-18
54-19
54-20
54-13
54-25
54-26
54-27
54-28
54-29
54-30
54-31
54-32
54-32
54-33
54-34
54-35
54-36
54-37
54-38
54-39
54-40
54-41
54-42
54-8
1-2
1-3
1-4
1-5
1-5
1-5
1-7
1-8
1-9
1-10
1-11
1-14 1-6
1-13
1-12
1-16
1-17
1-18
1-19
1-20
1-21
Item
No. Description Part No.

WARNING! If not used properly this lawn mower can be dangerous!
This lawn mower can cause serious injury to the operator and others, the warnings and
safetyinstructionsmustbefollowedtoensurereasonablesafetyandefciencyinusingthis
lawn mower. The operator is responsible for following the warning and safety and instructions in
this manual and on the lawn mower. Never use the mower unless the catcher or guards provided
by the manufacturer are in the correct position.
Thisapplianceisnotintendedforusebyyoungchildrenorinrmpersonsunlesstheyhave
been adequately supervised by a responsible person to ensure that they can use the appliance
safely.
Young children should be supervised to ensure that they do not play with the appliance.
1) Training
• Read the instructions carefully. Be familiar with the controls and the proper use of the appliance.
• Never allow children or people unfamiliar with these instructions to use the appliance. Local
regulations may restrict the age of the operator.
• Never mow while people, especially children, or pets are nearby.
• The operator or user is responsible for accidents or hazards occurring to other people or their
property.
2) Preparation
• While mowing, always wear substantial footwear and long trousers.
• Do not operate the appliance when barefoot or wearing open sandals.
• Thoroughly inspect the area where the appliance is to be used and remove all stones, sticks,
wires, bones, and other foreign objects.
• Before using, always visually inspect to see that the blades, blade bolts and cutter assembly are
not worn or damaged. Replace worn or damaged blades and bolts in sets to preserve balance.
• On multi-bladed appliances, take care as rotating one blade can cause other blades to rotate.
3) Operation
•Mowonlyindaylightoringoodarticiallight.
• Avoid operating the appliance in wet grass, where feasible.
• Always be sure of your footing on slopes.
• Walk, never run.
• For wheeled rotary mowers, mow across the face of slopes, never up and down.
• Exercise extreme caution when changing direction on slopes.
• Do not mow excessively steep slopes.
• Use extreme caution when reversing or pulling the appliance towards you.
• Stop the blade(s) if the appliance has to be tilted for transportation when crossing surfaces other
than grass, and when transporting the appliance to and from the area to be mowed.
• Never operate the appliance with defective guards or shields, or without safety devices, for
exampledeectorsand/orgrasscatchers,inplace.
• Switch on the motor according to instructions and with feet well away from the blade(s).
• Do not tilt the appliance when switching on the motor, except if the appliance has to be tilted for
starting. In this case, do not tilt it more than absolutely necessary and lift only the part which
is away from the operator. Always ensure that both hands are in the operating position before
returning the appliance to the ground.
• Do not put hands or feet near or under rotating parts. For rotary mowers, keep clear of the
discharge opening at all times.
• Never pick up or carry an appliance while the motor is running.
• Pull the plug from the socket:
- whenever you leave the machine;
- before clearing a blockage;
- before checking, cleaning or working on the appliance;
- after striking a foreign object. Inspect the appliance for damage and make repairs as necessary;
- if the appliance starts to vibrate abnormally (check immediately).
4) Maintenance and storage
• Keep all nuts, bolts, and screws tight to be sure the appliance is in safe working condition.
• Check the grass catcher frequently for wear or deterioration.
• Replace worn or damaged parts for safety.
• For rotary mowers, ensure that only replacement cutting means of the right type are used.
WARNING! When using mains-powered tools, basic safety precautions, including
the following, should always be followed to reduce risk of re, electric shock,
personal injury and material damage.
Read the whole manual carefully and make sure you know how to switch the tool off in an
emergency, before operating the tool.
Save these instructions and other documents supplied with this tool for future reference.
The electric motor has been designed for 230V and 240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New
Zealand.
This tool is double insulated in accordance with AS/NZS 60335-1;
therefore no earth wire is required.
If the supply cord is damaged, it must be replaced by an electrician or a power tool repairer
in order to avoid a hazard.
Note: Double insulation does not take the place of normal safety precautions when operating this
tool. The insulation system is for added protection against injury resulting from a possible electrical
insulation failure within the tool.
1. Before use, examine cord for damage; replace it if there are signs of damage or ageing.
2. Do not use the lawn mower if the electric cables are damaged or worn.
3. Immediately disconnect from the mains electricity supply if the cord is cut, or the insulation is
damaged. Do not touch the electric cord until the electricity supply has been disconnected. Do not
repair a cut or damaged cord; replace it with a new one.
4.Yourextensionleadmustbeunwound,coiledleadscanoverheatandreducetheefciencyof
your mower.
5. Keep lead away from lawn mower; always work away from the power point mowing up and down
never in circles.
6. Do not pull lead around sharp objects.
7. Always switch off at the mains before disconnecting any plug, cord or extension lead.
8. Never carry the product by the cord.
9. Never pull on the cord to disconnect any of the plugs.
10. Use only AC mains supply voltage shown on the product rating label.
11. It is recommended that the appliance should by supplied via a residual current device (RCD) with
a tripping current of not more than 30 mA.
12. Use at least a 10 Amp rated 1.0 mm2 extension cord with a maximum of 25 meters and the cord
shall be not lighter than:
-Ifrubberinsulated,ordinarytoughrubbersheathedexiblecord(codedesignation60245IEC53);
-Ifpolyvinylchlorideinsulated,ordinarypolyvinylchloridesheathedexiblecord(codedesignation
60227 IEC 53).
WARNING! Read all safety warnings and all instructions. Failure to follow the warnings
andinstructionsmayresultinelectricshock,reand/orseriousinjury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause you
to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way.
Do not use any adapter plugs with earthed (grounded) power tools.Unmodiedplugsand
matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will increase
the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the inuence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious personal
injury.
b. Use personal protective equipment. Always wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools with
yourngerontheswitchorenergisingpowertoolsthathavetheswitchoninvitesaccidents.
d. Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool may result
in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control of
the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving
parts.
g. If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-related
hazards.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tool’s operation. If damaged, have
the power tool repaired before use. Many accidents are caused by poorly maintained power
tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a qualied repair person using only identical
replacement parts. This will ensure that the safety of the power tool
is maintained.
b. If the supply cord is damaged, it must be replaced by the manufacturer,
itsserviceagentorsimilarlyqualiedpersonsinordertoavoidahazard.
GENERAL POWER TOOL SAFETY WARNINGS
ELECTRICAL SAFETY
ADDITIONAL SAFETY INSTRUCTIONS FOR LAWN MOWERS

IN ORDER TO MAKE A CLAIM UNDER THIS
WARRANTY YOU MUST RETURN THE PRODUCT
TO YOUR NEAREST BUNNINGS WAREHOUSE WITH
YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY
PLEASE TELEPHONE OUR CUSTOMER SERVICE
HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE
HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE
REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY
HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
OZITO Australia/New Zealand (Head Oce) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
The benets provided under this warranty are in addition
to other rights and remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded
at law. You are entitled to a replacement or refund for a major failure and
for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with
a claim under this warranty, however, where you have suered
any additional direct loss as a result of a defective product you
may be able to claim such expenses by contacting our customer service
helpline above.
1013
2 YEAR REPLACEMENT WARRANTY
Your product is guaranteed for a period of 24 months from
the original date of purchase and is intended for DIY (Do It
Yourself) use only. If a product is defective it will
be replaced in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: grass catcher,
wheels, blade, cord clips, bearings & carbon brushes
WARNING
The following actions will result in the warranty being void.
• If the tool has been operated on a supply voltage other
than that specified on the tool.
• If the tool shows signs of damage or defects caused
by or resulting from abuse, accidents or alterations.
• Failure to perform maintenance as set out within the
instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
