Pacific PA-315 User manual

Introduction
1. OSD KeyPad Button
（※ （※ This operation manual are in accordance with special OSD Key Pad））
Button
Motion
Move to each item
Change each item’s level
ENTER
OK
（Process when Enter Key button
）
Menu Screen
2. To enter to setting screen
Press “ ENTER” Key to display a setting screen.Cursor position is shown as mark.
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

Initial Seeting Value ( Each item is set as below at the same time Initial Seeting Value ( Each
item is set as below at the same time of factory shipment)
ALC/ELC
☒ALC
☐ELC
（Default : level 20）
Shutter Speed at ALC
PAL(PA-315)
☒OFF（1/50）
☐1/250
☐1/500
☐1/700
☐1/1,000
☐1/1,600
☐1/2,500
☐1/5,000
☐1/7,000
☐1/10,000
☐1/30,000
☐1/60,000
NTSC(PA-310)
☒OFF（1/60）
☐1/120
☐1/250
☐1/700
☐1/1,000
☐1/1,600
☐1/2,500
☐1/5,000
☐1/7,000
☐1/10,000
☐1/30,000
☐1/60,000
FLICKERLES
S
☐OFF
☒ON
WDR/BLC
☒OFF
☐BLC
☐HLC
☐WDR+BLC
☐WDR
WDR level：
☐LOW
☒MIDDLE
☐HIGH
BLC Area Setting：
Top: 54
Bottom: 122
Left: 95
Right: 129
AGC
☐OFF
☒ON
ON Max Gain level （0-20dB）：
OFF Manual Gain level （0-20dB）：
（ 27 ）dB
（ 00 ）dB
W.BALANCE
☒ATW
☐W.B FTX
☐AWC
☐NATW
COLOR
（C.KILLER
）
☒OFF
☐ON
SYNC
☒INT
☐L/L
CAM TITLE
☒OFF
☐ON
ON Title Position：
☐UL
☐UR
☐DL
☒DR
D/N
☒AUTO
☐DAY
☐NIGHT
☐EXT
AUTO ON Setup for Duration Time/Level Shifting
NIGHT （5-20/20 level）
（ 18 ）
DAY （0-15/20 level）：
（ 02 ）
CONTINUOUS Duration Time Setting（0-255 sec.）：
（ 1 ）sec
NIGHT ON BURST Signal
☒OFF
☐ON
SMART IR
☐LED POWER
☐FULL
☐DIMMING
☐OFF
ANTI-SAT(level-20)
SAT.AREA(level 1-20)
H.MIRROR
☒OFF
☐ON
PRIVACY
Each Area Setting (8 Areas)
MASK No.:
Area Number ( 1 to 4 )
DISPLAY:
☒OFF
☐ON
LOCATE:
TOP[ ]
BOTTOM[ ]
LEFT[ ]
RIGHT[ ]
MASK LV
BLUE
RED
CYAN
MAGENTA
BLACK
GRAY-1
GRAY-2
GRAY-3
GRAY-4
WHILE
YELLOW
GREEN
SHARPNESS
☒ON （Default : level 20）
BLINK_POS
☒OFF
☐U_LEFT
☐U_RIGHT
☐L_LEFT
☐L_RIGHT
DNR
☐OFF
☐LOW
☐MIDDLE
☐HIGH
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

MOTION
DETECT
Each Area Setting (4 Areas)
AREA:
Area Number ( 1 to 4 )
DISPLAY:
☒OFF
☐ON
TOP
BOTTOM
LEFT
RIGHT
SENSITIVITY
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

＜＜MENU＞ ＞ Setting Item
Set those items below on this MENU page
Menu Screen
■ALC/ELC
■FLICKERLESS
■WDR/BLC
■AGC
■W. BALANCE
■COLOR
■SYNC
■OPITION （Other Sett, Go to Page 7.）
CAM TITLE, DAY/NIGHT, H-MIRROR, PRIVACY,
SHARPNESS, BLINK_POS, OTHERS
■EXIT （Go to Page 11）
ALCの調整
1. ALC*/ELC*（（Light Adjustment））
Switching –over ALC/ELC
Press （ ）Key to switch –over ALC/ELC.
ALC （（Auto Light Control））adjustment
ALClevel
It sets an average of light on screen. Use this function when an auto iris lens is used or an
electrical shutter speed is fixed. Adjust ALClevel by （ ）Key. Level extent is from 20 levels.
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

Shutter Speed
Shutter speed is fixed to protect from shaking for subject moves at high speed or road
surveillance
Select depend on the below value.
PA-295
PAL
OFF（1/50
）
1/120
1/250
1/500
1/700
1/1,000
1/1,600
1/2,500
1/5,000
1/7,000
1/10,000
1/30,000
1/60,000
PA-290
NTSC
OFF（1/60
）
FL（1/100
）
1/120
1/250
1/700
1/1,000
1/1,600
1/2,500
1/5,000
1/7,000
1/10,000
1/30,000
1/60,000
ELC（（Electro Luminance Control））Adjustment
It sets an average range of light on screen. Use this function when an electrical shutter is used.
Adjust ELC level by key. Level extent is from 20 levels.
Shutter max at ECL set the upper limit of electronic shutter
Flicker less
2. FLICKERLESS
Reduce flicker level. Switch-over [ON/OFF] by key. When you select [ON] on this menu, Item
ALC/ELC is set automatically as [ALC].
Model
Shutter Speed at flicker
less setting
PA-290 (NTSC)
1/60
PA-295 (PAL)
1/50
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

3. WDR*/BLC* ―Picture adjustment with a large contrast.
Switch-over WDR & BLC
Switch-over [OFF/WDR/BLC/WDR+BLC] by key.
Adjust WDR level 
It shows images naturally automatically adjusting the contract between light and dark when
WDR is set. Set the level of WDR by pressing key after entering the sub menu. Select
[LOW/HIGH/MIDDLE] by key.
BLC AREA (default value)
Set the variable area BLC
Set freely the photometric area of BLC which is adjusted to the under central position of people
at factory setting. Set the area based on the coordinate number of each area;
TOP/BOTTOM/LEFT/RIGHT by key.
Convert a part of the high brightness into black of HLS level
Select LOW/MIDDLE/HIGH.
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

4. AGC*
Switch-over [ON/OFF] by key. Adjustment level extent is as below.
It is the max level when it is ON. On the other hand, it sets a fixed manual gain and its value is
set despite the condition between light and dark. The adjusting level for each as followed.
AGC－ON(AGC-MAXレベル)
AGC－OFF（manual Gain）
■ ON：： AGC MAX GAIN ：： 0~20dB
■ OFF：： Manual set GAIN ：： 0~20dB
W.B FIX adjustmen
5. W. BALANCE*
Select White Balance from [ATW / N.ATW / FIX* / AWC]
by key.
Level adjustment of each item is as below.
。
ITEM
Contents
ATW
Normal white balance setting
AWC
It is displayed as ‘‘PUSHING’’ while
pressing ‘ENTER’ key. White balance is
calculated in the meantime, and then it is
fixed once releasing
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

NATW
It shows a natural color which people see
without pulling colors in.
W.B
FIX
R-GAIN （0~160
）
Adjusts gain which
was fixed at AWC
setting
B-GAIN （0~160
）
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

Color Adjustment
6. COLOR ―Chroma Gain Adjustment
Adjust color level by key. Level extent is 0-20.
With C.KILLER*, you can select [ON/OFF].
7. SYNC
―Switch-over between internal synchronization &
external synchronization
You can select a way of synchronization between [INT]
(Internal synchronization) & [L/L] (Line Lock). Change it
by key. From this item; [L/L] (Line lock), you can go to
the sub menu where you set phase.
L/L selection
Power Input
3.3~5.0 V
Frequency
Extent
49.5~50.5 Hz
59.5~60.5 Hz
Phase Extent
30~330°
0~360°
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

<< OPTION>> Additonal setting
You can set those items below on this OPTION page.
■TITLE
■DAY/NIGHT
■H-MIRROR
■MASK
■SHARPNESS
■BLINKING_POSITON
■OTHERS(2D DNR, INITIALIZE etc  )
Additional Setting
Addional Setting
Camera Title
1. CAM TITLE ―Select name for each camera & position which the name is displayed
on screen
You can input 8 characters (MAX.) for each camera. Select alphabet by key and press
‘ENTER’ key.
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

AUTO ON Setting
2. DAY/NIGHT
Switch-over Day/Night function Select from [AUTO/DAY/ NIGHT/EXT].
At NIGHT mode, it sets not only to switch over into monochrome also to cut a burst signal in
order to improve resolution.
Also it sets to switch over to infrared filter to synchronize DAY/NIGHT setting at a D/N unit
model.
AUTO
It switches over automatically to DAY/NIGHT based on the AGC level. The AGC level can be
selected as followed.
■AGC Increase⇒⇒to NIGHT mode：： 05~20 level （（Default : 18））
■AGC Decrease⇒⇒to DAY mode：： 00~15 level （（Default: 02））
CONTINUOUS ―Duration time of DAY/NIGHT
CONTINUOUS is a function to set a duration time from Day to Night or vice versa. Adjust key.
Once it reaches to the value you set, it switches between Day and Night within the time you set
not to move back to threshold.
NIGHT Sub menu
It cuts a burst signal in order to improve resolution at a night mode (monochrome mode) by sub
menu.
EXT
It switches over [DAY/NIGHT] by controlling terminal level by a switch or driver IC, using the 7th
pin of OSD key connector (CN5). FIY, this function cannot be used while OSD menu is shown
on screen.
3. H-MIRROR ― Horizontal Reversal Function
It is used when you want to flip mirror image to horizontal axis. Switch over [ON/OFF] by key.
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

4. PRIVACY ――Privacy masking
It sets an area which you don’t record. 4 masks are available to use.
When you use mask, switch-over [ON/OFF] on item; DISPLAY. Set the masking position by
[TOP/BOTTOM/LEFT/ RIGHT].
[BLACK/GRAY1~4/WHITE/RED/GREEN/BLUE/YELLOW/CYAN/MAGENTA]
5. SHARPNESS
Make a sharp image by emphasizing the edge.
Select a sharp image not only by [ON/OFF] also by an extent value from 20 level at [ON] mode.
Blinking function
6. BLINK_POS ―Blinking function
At surveillance with recorder, there is such a case which cannot be judged if the camera is
working even if an image doesn’t find any movement on screen or if the recorder is broken.
This function is easy to avoid such problems to put a blinking mark on each position.
U_LEFT
Upper left （initial value）
U_RIGHT
Upper right
D_LEFT
Down left
D_RIGHT
Down right
Remarks) Item; MOTION DETECT (Go to Page 11) is prior to Item; BLINK_POS.
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

<<<OTHERS>>> Others
You can set those items below on this OTHERS page.
■DNR
■MOTION DETECT
■GAMMA
■SETUP LEVEL
■SERIAL Com ID
■COLOR ADJ.
■INITIAL
1. DNR*
Select level of DNR. Select [LOW/MIDDLE/HIGH/AUTO/OFF] by key.
※ ※ It adjusts DNR level automatically when you set as AUTO by AGC [ON/OFF].
2.MOTION DETECT ― Motion Detect function
Motion detect function
Motion Detect
It shows a box-shaped mark in yellow on the upper left of screen when it detects people, car etc on
screen. 4 areas are available to set. In addition, you can set a detection area with mixing these 4
areas.
To see each area, switch-over [ON/OFF] by DISPLAY. Change those area position by
TOP/BOTTOM/LEFT/ RIGHT by key.
It positions upper and left side of the monitor (coordination:0,0,0,0） as images shown.
3. GAMMA
Use the setting [0.35-0.70] on normal operation.
In case that there is no necessary for Gamma correction such as image processing, use the
setting [1.0]
PACIFIC CORPORATION UK
www.pacific-cameras.co.uk

4. SETUP LEVEL
Choose [LOW]/ [MIDDLE] / [HIGH]. Adjust Select key.
5.SERAIL Com
 Set camera ID to use at the time of communication.
Effective range （0～255）. Push （ ）Key and set ID
6.COLOR ADJ.
 Choose 8 level (RY-GAIN+/ RY-GAIN-/ BY-GAIN+/
BY-GAIN-/RY-HUR+/RY-HUR-/BY-HUR+/BY-HUR-) for adjustment.
Effective range （0～255）.。
7.INITIALIZE ―Setting initialization
Change to set for initialization as pege 2
Push ENTER KEY then automatically saved and out of menu screen.
Remarks) you cannot go back to the set you saved once pressing ‘ENTER’ key. Please re-set
in case it happens.
EXIT ― Save the setting
It set the saved condition before it is out of setting screen.
Select from [SAVE / NOSAVE / RELOAD]. More in detail is as below.
■SAVE: Save the function you set. You can use the same after turning electricity
on.
■NOSAVE: Not to save the function you set. Therefore it returns to the function you
previously save.
■RELOAD: Return to the function you previously save without a need to turn
electricity on.
