Color HD（720p）Board Camera
VPC-HD10
Product Specification
& Operational Manual

©2010 Pacific Corporation.
1
Table of Contents
PAGE
1. Scope of Application ········································································································································· 2
2. Handling Precautions ········································································································································ 2
3. Product Outline ················································································································································· 3
4. Bundled Items ··················································································································································· 3
4.1. StandardBundled Items ································································································································3
4.2. Optional Items·············································································································································· 3
5. Specifications···················································································································································· 4
5.1. General Specifications ································································································································· 4
5.2. Camera Input/Output Signals ······················································································································· 5
6. Part Names and Functions ································································································································· 6
7. External Connector Pin Assignment ·················································································································· 7
7.1. Power Input and Signal Output Connectors·································································································· 7
7.2. OSD Switch Connectors ※Optional Connectors ························································································· 8
7.3. Remote Control Cable Connectors ··············································································································· 8
8. Camera Operating Instructions ·························································································································· 9
8.1. Switch Operation without OSD Menu·········································································································· 9
8.2. PC Operation via RS232C···························································································································· 9
8.3. Switch Operation with OSD Menu··············································································································· 9
9. Factory Settings (Underlined and Bold letters show the factory settings) ························································ 15
10. Dimensions ····················································································································································· 16
11. Cases for Indemnity (Limited Warranty) ········································································································· 17
12. CMOS Pixel Defect········································································································································· 17
13. Product Support··············································································································································· 17

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
2
1. Scope of Application
This is to describe VPC-HD10, analog color HD (720P) board camera assembly.
All specifications contained herein are subject to change without prior notice.
Reproduction in whole or in part is prohibited.
2. Handling Precautions
The camera assembly must not be used for any nuclear equipments or aerospace equipments with which
mechanical failure or malfunction could result in serious bodily injury or loss of human life. Our warranty
does not apply to damages or defects caused by irregular and/or abnormal use of the product.
Please observe all warnings and cautions stated below.
Our warranty does not apply to damages or malfunctions caused by neglecting these precautions.
zDo not directly touch the board camera while camera is in operation. The board camera can be very hot
and you may burn yourself.
zDo not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power supply
voltage may cause damages or malfunction of the camera.
zDo not directly touch the optical surface. CMOS image sensor is fragile.
zDo not use or store the camera assembly in the dusty or humid places.
zDo not apply excessive force or static electricity that could damage the camera assembly.
zIn some cases, hunting may occur when using electric iris, depending on the object to shoot.
zIn some cases, color may change under fluorescent lamp when using electric iris.
zDo not shoot direct images that are extremely bright (e.g., light source, sun, etc). When the camera is
not in use, please put the protection cap on.
zFollow the instructions in Chapter 7, “External Connector Pin Assignment” for connecting the camera.
Improper connection may cause damages not only to the camera but also to the connected devices.
In case of abnormal operation, contact the distributor from whom you purchased the product.

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
3
3. Product Outline
VPC-HD10 is a HD (720P) output, color board camera assembly utilizing 1/3 type CMOS image sensor.
With our own image processing technologies, electrical zoom, long time exposure function, OSD functions,
and others are incorporated into the camera.
32x32mm ＋42x42mm (2 boards) in size should best match for embedded systems.
HD 720p/60, 720p/59.94、720p/50 analog component (Y/Pb/Pr) and RGB output available.
Key Features
□Long time exposure shutter function enables to capture clear images even under low illumination.
□On Screen (OSD) function enables to set camera settings by menu. (OSD operational switch needed).
□Camera settings can be set with RS 232C via PC. (Dedicated remote control unit needed).
4. Bundled Items
4.1. Standard Bundled Items
□Board Camera
□Cable Harness for power supply and video signal output. (10pins connector, 10 cores)
□Camera fixing screws (4pcs)
4.2. Optional Items
□Dedicated lens
□Cable Harness for OSD switch connection. (10pins connector)
□RE-300: Remote control cable (Between camera and PC)

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
4
5. Specifications
5.1. General Specifications
Device Type 1/3 type COMSSONY IMX035LQR-C
Effective Pixel Numbers 1329(H) × 1049(V)
Unit Cell Size 3.63µm(H) ×3.63µm(V)
(1) Pick up device
Chip Size 7.64mm(H) × 7.64mm(V)
(2) Resolutions 1280(H) × 720(V)
(3) Aspect Ratio 16 : 9
60fps Horizontal Frequency 45 kHz
Vertical Frequency 60 Hz
59.94fps Horizontal Frequency 44.95 kHz
Vertical Frequency 59.94 Hz
50fps Horizontal Frequency 37.50 kHz
(4) Video output frequency
Vertical Frequency 50 Hz
(5) Sync. system Internal sync
Analog Component Output : Y/Pb/Pr 1Vp-p (3 Values, Sync signals) 75Ωterminal
RGB Output : RGB1Vp-p(without SYNC ) 75Ωterminal
(6) Video output standard
HD, VDTTL level (over 2.1V1KΩterminal)
(7) Horizontal resolution 600TV lines (contour correction SHARP)
(8) Sensitivity F4.0 2000lx
60fps,59.94fps : F2.5 6.0lx (with dedicated board camera lens)
F1.4 3.0lx (with F1.4 lens)
50fps : F2.5 5.0lx (with dedicated board camera lens)
F1.4 2.5lx (with F1.4 lens)
(9) Minimum illumination
Conditions : VIDEO 50%, AGC 36dB, Electrical Shutter OFF
(10) Dust or stains
in optical systems
No dust or stain shall be detected on the testing screen with dedicated lens installed, or
with setting the camera aperture at F16 if there is no lens.
(11) Power requirements DC+9〜+15V
(12) Power consumption 2.0W (Max. 2.4 W) at DC+12V IN
(13) Dimension Refer to overall dimension drawing.
(14) Mass Approx. 45g (including optional dedicated lens).
(15) Lens Mount Dedicated board camera lens mount. ※Refer to overall dimension drawing.
AGC (Max gain : +18dB, +24dB, +30dB, +36dB), AGC OFF(0dB)(16) Gain Setting
MANUAL : 0dB〜36dB
OFF : 1/60(60fps, 59.94fps),1/50(50fps)
FL : 1/100(60fps, 59.94fps), 1/120(50fps)
MANUAL : 1/10k, 1/4k, 1/2k, 1/1k, 1/500, 1/250, 1/120, 1/100, 1/60, 1/50, 1/30, 1/25,
1/15, 1/8, 1/4, 1/2, 1s, 2s, 4s, 8s
(17) Shutter Speed Variable
Range
AUTO : 1/10ks〜8s (Upper or lower limit can be set.)
ATW1 : 2200〜9000K, ATW2 : 3200〜6500K
(18) White Balance
Adjustment Range Preset:3200K, 4800K, 6500K, Manual: 2200〜9000K
(19) Electrical Zoom ×1〜×4 PAN, TILT
(20) AUTO IRIS Signals Responses are adjustable.
Usable with electrical shutter (with priority to electrical shutter).

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
5
(21) Back Light Divided into 49 screens (7x7), and each screen can be individually masked. (Masked
part shall be ignored.) The same settings are applicable to ATW.
Character Display: alphanumeric characters and symbols (Max 24 letters)
Display Position: The upper left portion of the screen (fixed)
(22) Character Display
Characters can be edited by OSD.
(23) Contour Correction SHARP/STD./SOFT selectable.
(24) Chromaticness
Adjustment
Chromaticness is adjustable. 255(typ.)〜0(B/W)
(25) Gamma Compensation Gamma is adjustable. γ=0.45〜1.0 Data (127〜0)
OFF/ON (Initial Setting) / ON (User Setting)
Maximum correction value: 63 values (Depending on conditions.)
Maximum correction value and detection start level can be set.
(26) Pixel Defect
(White Spot) Correction
※When correction is started after blocking light, long time exposure and AGC is set
automatically to start.
Operable via RS232C.
9600bps(typ), with no parity, stop pit: 1bit
(27) Remote Control
Operation
Communication speed selection : 2400, 4800, 9600, 19200 bps
UL: Conform to UL Standard including materials and others.
CE: Emission: EN55022:2006(Class B)
Immunity: EN55024:1998/A1:2001/A2:2003
(28) Safety/Quality standards
RoHS: Conform to RoHS
Specifications guaranteed 0 〜+40℃Humidity: 20 〜80%RH
with no condensation
(29) Operational
environment
Operation guaranteed -5 〜+45℃Humidity: 20 〜80%RH
with no condensation
(30) Storage environment Temperature : -25 〜+60℃Humidity: 20 〜80%RH with no condensation.
5.2. Camera Input/Output Signals
White clip level: 760mV ±10%
Video Signals
SYNC level: 300mV ±10% (3values sync signals)

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
6
2
3
4
51
67
CN4
CN6
CN5
CN2
CN3
(NO MOUNT)
(NO MOUNT)
8
6. Part Names and Functions
①Power Input and Video Output
With the bundled harness, power input and video output signals are connected to a monitor.
Please refer to Chapter 7, “External connector pin assignment”.
②OSD Operational Switch Connector
With the optional harness, OSD operational switch is connected.
Please refer to Chapter 7, “External connector pin assignment”.
③Remote Control Connector
Optional remote control cable (RE-300) is connected.
With connecting the remote control cable (RE-300) to a PC, serial communication via RS-232C is valid.
Please refer to the other materials for the communication details. (To be prepared)
④Dedicated board camera lens
Lenses are optional.
⑤Camera Mounting Holes
With bundled attachment screws, mount the camera.
⑥Extended Connectors (Not implemented. Can be implemented on request.)
⑦DCIRIS Connectors (Not implemented. Can be implemented on request.)

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
7
7. External Connector Pin Assignment
7.1. Power Input and Signal Output Connectors
Connectors of camera side Connectors of bundled harness side
53398-1090 (molex) 51021-1000 (molex)
CN4 Signals Component Output RGB Output
1 Pb/B OUT Pb output (3values SYNC) BLUE output (without SYNC)
2 Pr /R OUT Pr output (3values SYNC) RED output (without SYNC)
3 IRIS OUT Video Iris signals ←
4 HD OUT HD output ←
5 GND GND (for video signals) ←
6 VD OUT VD output ←
7 GND GND (for video signals) ←
8 Y/G OUT Y output (3values SYNC) GREEN output (without SYNC)
9 GND GND (Power) ←
10 POWER Power Input (DC+12V) ←
Connection for Component Y/Pb/Pr output
Pb/B_OUT
Pr/R_OUT
HD OUT
GND
IRIS_SIG
DC+12VIN
VD OUT
Y/G_OUT
1
2
3
4
5
6
7
8
9
10
51021-1000
to MONITOR
Y
Pr
Pb
DC+12V
GND
+12V
GND
IRIS OUT
to VIDEO IRIS LENS
POWER IN
N.C.
N.C.
GND
GND
(Component Terminal)
Connection for RGB output
Pb/B_OUT
Pr/R_OUT
HD OUT
GND
IRIS_SIG
DC+12VIN
VD OUT
Y/G_OUT
1
2
3
4
5
6
7
8
9
10
51021-1000
to MONITOR
DC+12V
GND
+12V
GND
IRIS OUT
to VIDEO IRIS LENS
POWER IN
GND
GND
15
610
11 15
234
789
12 13 14
HD15PIN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
RED
GREEN
BLUE
N.C.
GND
GND(RED)
GND(GREEN)
GND(BLUE)
N.C.
GND
N.C.
SDA
HSYNC
VSYNC
SCL
N.C.
N.C.
N.C.
N.C.
N.C.
(VGA Terminal)

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
8
7.2. OSD Switch Connectors ※Optional Connectors
Connectors of camera side Connectors of optional harness side
BM10B-SRSS (NICHIATSU) SHR-10V-S-B (NICHIATSU)
CN6 Signals
1 N.A. (OPEN)
2 N.A. (OPEN)
3 N.A. (OPEN)
4 N.A. (OPEN)
5 N.A. (OPEN)
6 GND GND for switch connection
7 SW_BACK Switch connecting terminal (BACK)
8 SW_UP Switch connecting terminal (UP)
9 SW_ENTER Switch connecting terminal (ENTER)
10 SW_DOWN Switch connecting terminal (DOWN)
1
2
3
4
5
6
7
8
9
10
SHR-10V-S-R
UP
BACK ENTER
DOWN
GND
SW_BACK
SW_UP
SW_ENTER
SW_DOWN
7.3. Remote Control Cable Connectors
Connectors of camera side Connectors of remote control cable side
53398-0271 (molex) 51021-0200 (molex)
CN6 Signals
1 GND Remote Control GND
2 REMOTE Remote Control Signals (Input/Output)

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
9
8. Camera Operating Instructions
There are 3 different operating methods, operating with OSD menu, operating without OSD menu, and operating
via PC with dedicated remote control cable connected to the remote control terminals. Depending on its
operating methods, selectable camera settings are different. Please refer to the selectable settings by each
operational method as below.
8.1. Switch Operation without OSD Menu
Operational Functions
EZOOM, PAN, TILT, and Video Format Selection
EZOOM Operation
EZOOM can be operated with [UP] KEY and [DOWN] KEY.
With [DOWN] KEY, it goes to TELE side, and with [UP] KEY, it goes to WIDE side.
Except when EZOOM is x1.00, it goes to EZOOM→PAN→TILT→EZOOM every time when
[BACK] KEY is pushed. PAN and TILT values can be set as well.
* When EZOOM is x1.00, PAN and TILT will automatically go back to the center of the image.
Display Format Selection
Video format can be changed as follows, pushing [ENTER] KEY while pushing [BACK] KEY.
720p/60 Y/PbPr →720p/59.94 Y/PbPr →720p/50 Y/Pb/Pr →
720p/60 RGB →720p/59.94 RGB →720p/50 RGB →720p/60 Y/Pb/Pr
* The selected settings with operations explained the above can not be saved as they are.
To save those settings, EXIT→SAVE shall be done by OSD displayed operation.
* Initial setting is 720p/59.94 Y/Pb/Pr.
8.2. PC Operation via RS232C
Camera can be controlled via a PC using camera control software, with dedicated remote control cable (RE-300)
connected to the remote control terminal.
8.3. Switch Operation with OSD Menu
[ENTER] KEY: To enter into the menu with pushing this button for long.
In the menu, this button works to go to the next menu, and works as [→] KEY.
[BACK] KEY: In the menu, this button works to go back to the prior menu, and works as [←] KEY.
[UP] KEY: To select items in the menu.
When operating volume type menu, this button makes the value to ＋direction.
[DOWN] KEY: To select items in the menu.
When operating volume type menu, this button makes the value to −direction.

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
10
Main Menu
Items SELECT Next menu Explanation
OFF Set AGC OFF to make Gain 0dB.
AGC> →MAX
GAIN
Set AGC ON.
[ENTER] to go to the next menu to enable to set the maximum Gain.
GAIN
MANUAL> →MANUA
L GAIN
Set Gain manually.
[ENTER] to go to the next menu to enable to set the manual value.
OFF Set the electronic shutter OFF.
The same shutter speed set as frame rate will be set.
FL Set to be flicker-less.
When the set frame rate is 60fps, and 59.94fps, 1/100s shutter speed will
be set, while the set frame rate is 50fps, 1/120s shutter speed will be set.
AES> →AES
SETTING
Operate Auto electronic shutter.
[ENTER] to go to the next menu to enable LOW SHUTT, LIM
(limitation of electronic high sensitivity), and HIGH SHUTT LIM
(limitation of high speed electronic shutter).
SHUTTER
MANUAL> →MANUA
L
SHUTTER
Set the electronic shutter manually.
[ENTER] to go to the next menu to enable to set the manual value.
ATW> →ATW
SETTING
Operate Auto White Balance.
[ENTER] to go to the next menu to enable to set tracking range, tracking
speed, and OFF SET of convergent point.
3200K Fix white balance to 3200K.
4800K Fix white balance to 4800K.
6500K Fix white balance to 6500K.
WHITE_BAL
MWB> →MANUA
L WHITE
BAL
Set White Balance manually.
[ENTER] to go to the next menu to enable to set the manual value.
LEVEL> →AE
LEVEL
[ENTER] to go to the next menu to enable to set the brightness of auto
exposure.
RESPONS> →AE
RESPONS
[ENTER] to go to the next menu to enable to set the operational speeds of
AGC, AES, and Auto Iris. Volume adjustment of Video Iris can be
checked as well.
AESET
BLC> →BLC
SETTING
[ENTER] to go to the next menu to enable to set back light setting.
PICTURE> →PICTUR
E
[ENTER] to go to the next menu to enable to set the image sharpness,
gamma compensation, saturation, and defective pixel correction of the
image sensor.
EZOOM> →EZOOM [ENTER] to go to the next menu to enable to set electronic shutter.
DISPLAY> →DISPLA
Y
[ENTER] to go to the next menu to enable to set the display settings of
title indication and electronic zoom magnifications.
OPTION
REMOTE> →REMOTE
SETTING
[ENTER] to go to the next menu to enable to set the serial communication
speed.
SAVE> END Save the data set with OSD, and terminate the menu.
CANSEL> END Restore the data set with OSD, and terminate the menu.
EXIT
DEFAULT> END Restore the data to the initial settings, and terminate the menu.

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
11
MAX GAIN
Items SELECT Next menu Explanation
18dB
24dB
30dB
MAX GAIN
36dB
Set the maximum gain of AGC.
MANUAL GAIN
Items SELECT Next menu Explanation
MANUAL
GAIN
0dB-36dB Set the manual gain.
AES SETTING
Items SELECT Next menu Explanation
LOW
SHUTT.LI
M
8s,4s,2s,1s,
1/2,1/4,1/8,
1/15,1/25,
1/30,1/50,
1/60,1/100,
1/120,1/250,1/
500,1/1K,
1/2K,1/4K,
1/10K
Limit the low speed limitation of electronic shutter auto.
Higher speed than HIGH SHUTT.LIM. can’t be set.
HIGH
SHUTT.LI
M
8s,4s,2s,1s,
1/2,1/4,1/8,
1/15,1/25,
1/30,1/50,
1/60,1/100,
1/120,1/250,1/
500,1/1K,
1/2K,1/4K,
1/10K
Limit the high speed limitation of electronic shutter auto.
Lower speed than LOW SHUTT.LIM. can’t be set.
MANUAL SHUTTER
Items SELECT Next menu Explanation
SHUTTER
SPEED
8s,4s,2s,1s,
1/2,1/4,1/8,
1/15,1/25,
1/30,1/50,
1/60,1/100,
1/120,1/250,1/
500,1/1K,
1/2K,1/4K,
1/10K
Set the shutter speed manually.

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
12
ATW SETTING
Items SELECT Next menu Explanation
ATW1 Set the ATW range to 2200〜9000K. ATW RANGE
ATW2 Set the ATW range to 3200〜6500K.
SLOW
MID.
ATW RES
FAST
Set the speed of ATW.
R OFFSET 0-255 Adjust R offset value of ATW White standard.
B OFFSET 0-255 Adjust B offset value of ATW White standard.
MANUAL WHITE BAL.
Items SELECT Next menu Explanation
ENDONE PUSH
CAL.
One push to set the manual white balance value automatically.
[D]: to go to END->CAL to start detection.
With completion, it goes to CAL->END and its results are reflected in
RED GAIN and in BLUE GAIN.
R/B OFFSET of ATW SETTING is to be reflected.
RED GAIN 0-255 Gain adjustment of RED.
BLUE GAIN 0-255 Gain adjustment of BLUE.
AE LEVEL
Items SELECT Next menu Explanation
AE LEVEL 0-127 Set the AE level.
Operate AGC, AES, and Auto Iris settings.
AE RESPONS
Items SELECT Next menu Explanation
AGC RES. 0-255 Set the response speed of AGC.
The bigger the value goes, the slower the speed will be.
AES RES. 0-255 Set the response speed of AES.
The bigger the value goes, the slower the speed will be.
IRIS RES. 0-255 Set the response speed of Auto Iris.
The bigger the value goes, the slower the speed will be.
Hunting may occur if the speed is too fast.
IRIS LEVEL 0-127 Set Video Iris typed Auto Iris lens.
Please refer to the usage method of Auto Iris lens.
BLC SETTING
Items SELECT Next menu Explanation
OFF OFF back light. (Full Photometry)
ON(3×3) ON back light. (Center 3×3)
BLC
SETTING
ON(USER)
>
→BLC
WINDOW
SET
ON back light.
With the next menu, window settings can be done.

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
13
Items SELECT Next menu Explanation
SOFT
STD.
SHARPNES
S
SHARP
Set the sharpness.
GAMMA 0-127 Set gamma. (Data 127:γ0.45)
CHROMA 0-255 Set chromaticness. Data 0: B/W
OFF OFF pixel defect correction of image sensor (White spot).
USER> →BLEMIS
H COMP.
ON pixel defect correction of image sensor (White spot) by user
setting. [ENTER] to go to the next menu to enable to correct blemish
by user settings.
BLEMISH
COMP.
FACT. ON pixel defect correction of image sensor (White spot) by factory
setting.
EZOOM
Items SELECT Next menu Explanation
EZOOM ×1-×4 Set magnification of electronic zoom.
PAN 0-255 When magnification ratio is more than x1, video output range can be
horizontally shifted.
When magnification ratio is x1, PAN value becomes 128 and the
video output range will return to the center.
TILT 0-255 When magnification ratio is more than x1, video output range can be
vertically shifted.
When magnification ratio is x1, PAN value becomes 128 and the
video output range will return to the center.
DISPLAY
Items SELECT Next menu Explanation
OFF OFF the display of title indication.TITLE
CHAR> →CAM
TITLE
EDIT
ON the display of the title indication.
Alphanumeric characters and symbols can be displayed.
[ENTER] to go to the next menu to enable to edit.
OFF OFF the video format indication and electronic zoom indication when
the menu is not displayed.
MODE
ON ON the video format indication and electronic zoom indication when
the menu is not displayed.
When video format is changed, it is indicated and disappears
automatically after approx. 10 seconds.
When PAN, TILT, and EZOOM are changed, it is indicated and
disappears automatically after approx. 5 seconds.
REMOTE SETTING
Items SELECT Next menu Explanation
19200bps
9600bps
4800bps
BIT RATE
2400bps
Set the speed of serial communication.

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
14
BLC WINDOW SET
Items SELECT Next menu Explanation
7x7(49)
Window
MASK
SET/CLR
window0〜
window48
Set Mask ON/OFF for back light.
The masked area (whiteout part) will not be reflected by auto
exposure. [D]: to MASK ON and goes to the next area.
[U]: to MASK OFF and goes to the next area.
BLEMISH COMP.
Items SELECT Next menu Explanation
DISP. Indicate the corrected are by pixel defect correction (White spot) with
blinking.
START Start detection of pixel defect area (White spot) with shielding and
blacking-out the entire lens.
With successfully completed, transmit to DISP and display the area to
be corrected with blinking.
If not successfully completed, transmit to ERROR.
USER
COMP.
ERROR If not shielded or max qty is too low, ERROR might occur.
In such case, shielded completely and increase the max qty to restart.
START
LEVEL
16-127 Set the beginning level to start detection.
The level will go higher gradually from this level.
MAX. QTY 4-63 Set the maximum qty to detect.
The qty to be detected shall be less than this qty.
If there are too many areas to be corrected, reduce this qty.
CAM TITLE EDIT
Items SELECT Next menu Explanation
Character
Selection
ABCDEFG
HIJKLMNO
PQRSTUV
WXYZ
abcdefghijkl
mnopqrstuv
wxyz-.,()01
23456789
[U], [D] to select characters, and [ENTER] to shift the character
position to edit to the right.
Usage Method ofAuto Iris Lens
This camera outputs signals for auto iris so that Video Iris lenses can be connected.
Here, we would like to explain how to adjust variable resister installed in the Video Iris lenses.
Please refer to the Section 7, External Connector Pin Assignment, for connection.
First of all, set GAIN OFF and SHUTTER OFF, then set AESET >AERESPONS with OSD menu.
Try to shoot the area as blight as possible, set the ALC volume to Av side, and then, adjust the level volume of
lens-side, trying to position the cursor of IRIS LEVEL to be center.
After adjusting, restore GAIN and SHUTTER settings to be used. When adjusting brightness, please do not use
lens-side volume. Adjust the brightness with AE LEVEL after the explained adjustment is completed.
If lens-side volume is forced to use to adjust brightness, AGC and AES would not work properly in conjunction with
the other.

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
15
9. Factory Settings (Underlined and Bold letters show the factory settings)
OSD Settings
OFF
AGC> MAX GAIN 36dB
GAIN
MANUAL> MANUAL
GAIN 0dB
OFF
FL
LOW
SHUTT.LIM. 1/8AES>
HIGH
SHUTT.LIM. 1/10k
SHUTTER
MANUAL> SHUTTER
SPEED 1/250
ATW RANGE ATW1
ATW RES MID.
R OFFSET 128
ATW>
B OFFSET 128
3200K
4800K
6500K
ONE PUSH END
RED GAIN 128
WHITE_BAL
MWB>
BLUE GAIN 128
LEVEL> AE LEVEL 64
AGC RES. 32
AES RES. 32
IRIS RES. 32
RESPONS>
IRIS LEVEL -
OFF
ON(3x3)
AESET
BLC> BLC SETTING
ON(USER)> CENTER(1)
SHARPNESS STD.
GAMMA 127
CHROMA 192
OFF
USER> USER COMP. DISP.
START LEVEL 16
MAX. QTY 63
PICTURE>
BLEMISH
COMP.
FACT.
EZOOM x1.000
PAN 128
EZOOM>
TILT 128
OFFTITLE
CHAR> VPC-HD10
OFF
DISPLAY>
MODE
ON
19200bps
9600bps
4800bps
OPTION
REMOTE> BIT RATE
2400bps
SAVE>
CANSEL>
MAIN
EXIT
DEFAULT>

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
16
10. Dimensions

4-f 2.2 hole
4-R1
19
31
42±0.3
38±0.15
38±0.15
32
32
10.5
(19.2)
8.7
2 (mounting surface
to imaging surface)
CN6
CN4
CN5
12 2.55
999-540-00-00
(Unit:mm)
M14×1.0
±0.3
42

PACIFIC CORPORATION Tokyo H.Q.
 2-23-3 EBISU-MINAMI SHIBUYA-KU TOKYO 150-0022 JAPAN TEL: [phone] FAX : [phone]
2010 Pacific Corporation.
17
11. Cases for Indemnity (Limited Warranty)
We shall be exempted from taking responsibility and held harmless for damage or losses incurred by the user
in the following cases.
zIn case damage or losses are caused by fire, earthquake, or other acts of God, acts by third party,
deliberate or accidental misuse by the user, or use under extreme operating conditions.
zIn case indirect, additional, consequential damages (loss of business interests, suspension of
business activities) are incurred as result of malfunction or non-function of the equipment,
we shall be exempted from responsibility for such damages.
zIn case damage or losses are caused by failure to observe the information contained in the
instructions in this product specification & operation manual.
zIn case damage or losses are caused by use contrary to the instructions in this product
specification & operation manual.
zIn case damage or losses are caused by malfunction or other problems resulting from use of
equipment or software that is not specified.
zIn case damage or losses are caused by repair or modification conducted by the customer or any
unauthorized third party (such as an unauthorized service representative).
zExpenses we bear on this product shall be limited to the individual price of the product.
12. CMOS Pixel Defect
Noticeable CMOS pixel defects (White Spot) found during our inspection process are compensated. On very
rare occasions, however, CMOS pixel defects might be noted with time of usage of the products.
The cause of the CMOS pixel defects is the characteristic phenomenon of CMOS itself and Pacific
Corporation are exempted from taking any responsibilities for them. Pixel defects (White Spot) compensation
we perform is not to guarantee its effects to whole white spot.
 CMOS pixel defects (White Spot) may be seen when gain is increased by AGC or when slow shutter is used,
however, this shall not be considered as an inferior product.
13. Product Support
When defects or malfunction of our products occur, and if you would like us to investigate on the cause and
repair, please contact your distributors you purchased from to consult and coordinate.
Camera control sample software (RS232C) is available. We shall be exempted from taking responsibility and
held harmless for damage or malfunction of your hardware and software caused by using this control software.
The purpose of this control software is for you to check operation and evaluate our products. Please be noted
that Pacific Corporation do not customize the program nor provide source code.
