Pacifica M5 Mirage 3 User manual

M5 Mirage 3
Please read the instructions carefully before any operation
Barbecue gas grill | Griglia barbecue a gas

IMPORTANT: READ ALL INSTRUCTIONS AND OPERATIONS BEFORE
OPERATING THIS UNIT.
FOLLOW ALL STEPS IN ORDER. NEVER ALLOW CHILDREN TO
OPERATE THIS UNIT.
Warnings:
Only to be used outdoors.
Read the instructions before using the appliance.
Accessible parts maybe very hot, keep young children away.
Do not move the appliance during use.
Turn off the gas supply at the gas container after use.
Any modification of the appliance may be dangerous.
Parts sealed by the manufacturer or his agent must not be altered by the user.
Attention:
Some parts of this appliance become
very hot, take special care when children or elderly are present.
For your safety:
Do not store or use gasoline or mentholated fuels
or any other flammable vapors and liquids in the
vicinity of this or any other appliance.
Never light a gas grill with gasoline or
comparable fluids!
Suggestion: user should not change the assembly that the manufacturer packaged.
The gas cylinder is recommend to 5kg LPG gas bottle, it is sufficient foraheating
period of approx.5 hours with full power.
1. Technical data
Model: M5 - Mirage 3
Product Identification Number 0359CP1429
Gas Category
Gas and Supply Pressure
Butane(G30)
28-30 mbar
Country of Destination
I : BE,CH,CY,CZ,ES,FR,GB,GR,IE,IT,LT,LU,LV,PT,SK,SI.SA
I : BE,CY,DK,EE,FI,HU,LT,NL,NO,SE,SI,SK,RO,HR,TR,BG,LU,MT.SA
Main Burner Injector Size
Side Burner Injector Size
Total Nominal Heat Inputs (Hs)
Side Burner Heat Inputs (Hs)
Serial Number
Use Outdoors Only .
Read the instructions before using the appliance.
Warning : Accessible parts may be very hot. Keep young children away.
Product name
Model Number
Outdoor gas Grill
M5 - Mirage 3
I I I
Propane(G31) Butane Butane
37 mbar 29 mbar 50 mbar
3+(28-30/37) 3B/P(30) 3B/P(50)
3+(28-30/37)
3B/P(30)
3B/P(50)
I : AT,CH,DE,SK
Ø 0.9 mm Ø 0.9 mm Ø 0.81 mm
Ø 0.88 mm Ø 0.88 mm Ø 0.75 mm
Side burner 3kW(218 g/h)
Main burner 10.5kW(765g/h )： ；
： ；
0
063-15

2. Exploded View
3. Single part list
seq.
NO.
appellation qty seq. NO. appellation qty
1eldnahdil21diL1
3 thermometer 1 4 warming rack 1
5cast iron cooking grids 3 6 heat distribution panel 7
7 firebox assembly 1 8 main burnertube assembly 3
9 right sidetable 1 10 reinforce bar 1
11 reinforce bar 4 12 control panel assembly 1
13 Cartattachment bracket 4 14 control knob 4
15 grease tray 1 16 grease cup assembly 1
17 cartfrontbeam 1 18 door magnet 1

2A-geL022B-geL91
21 sidelow panel 2 22 rearsidelow panel 1
23 bottom panel assembly 1 24 swivel caster 4
25 door assembly 2 26 side burner nozzle base 1
27 side burnercover 1 28 side burnercooking grid 1
29 side burnerassembly 1 30 side burner insert tray 1
4. Fixing elements
5. Mounting steps
Make sure your grill is assembled properly. Detailed assembly instructions are packed
with each grill giving specific assembly procedures for each model. Follow these
instructions carefully to ensure the correct and safe assembly of the grill.
Caution: Although we take every effort to ensure that the assembly process is as easy
as possible, it is inherent with fabricated steel parts that corners and edged can cause
cuts if improperly handled during assembly procedures. Be careful while handling any
parts during assembly. It is strongly recommended that you protect hands with a pair
of work gloves.
Figure 1

Figure 2

Figure 3

Figure 4
Figure 5

Figure 6

Figure 7

Figure 8

Figure 9
Figure 10

Figure 11
Figure 12

Figure 13

Figure 14
Figure 15

MODEL M5 - Mirage 3
6. Preparation
You will need to purchase a5kg LPG gas bottle and the pressure regulator should
correspond to the pressure and gas category of the appliance, which can be obtained
from your nearest Gas Retailer. The regulator should be comply with EN12864 or
EN16129 with current version and national regulation.
You will need to purchase a gas bottle and a 28-30/37 mbar regulator for I3+ and
28-30mbar regulator for I3B/P(30), 50 mbar regulator for I3B/P(50) to operate this
gas grill which can be obtained from your nearest Gas Retailer.
See point 9 for farther instructions.
Strongly Recommends Information:
a) The gas cylinder is to be used only in the upright position.
b) Only to be used with a gas cylinder that does not exceed 500 mm
in height and>240mm<310mm in diameter.
c)This appliance must only be used with an approved hose and regulator.

Energy saving tips:
a) Reduce the opening time of the lid.
b) Turn the grill off as soon as cooking is completed.
c) Preheat the gas grill for 10 to 15 minutes only.
(Except for the first use)
d) Do not preheat longer then recommended.
e) Do not use a higher setting than required.
Connect the hose and regulator to the gas container at the right side of the gas
grill .Keeping in mind that the gas container must be kept away from heat and in a
safe position .The hose dimension is 8mm diameter.
7. Installation
After purchasing your gas bottle you will then be ready to set it up with your gas grill.
a) When changing the gas bottle which shall be carried out away from any
source of ignition. Position the gas bottle at the side of your gas grill, not
underneath, keeping in mind that the bottle must be kept away from heat and in a
safe position.
b) When ready to use your gas grill insert the regulator into the gas bottle valve and
tighten firmly. The maximum length of hose shall not exceed 1.5m.
Warning: Before attempting to light your gas grill you must refer to your
lighting instructions and warning / safety points.
Check the hose before each use, searching for cracking, cuts or any abrasions. If the
hose is found to be faulty in any way do not attempt to use your gas grill.
When changing your gas bottle ensures that there are no sources of ignition close by
i.e. fires, cigarettes, naked flames etc. Make sure that the appliance is switched off.
Ensure that the hose is not subjected to twisting which will affect the gas flow
when using your gas grill. Also the hose must not have undue tension and must not
touch any part of the gas grill which may be hot.
Please choose flexible hose whose heatproof higher than 80℃
Every2years changing the flexible hose when the national conditions require it.
How to connect a gas bottle
a) Turn the orange cap so that the arrow is pointing to the gap in the shroud.
b) Remove the orange safety cap by pulling the lanyard out, then out. Do not use
tools. Leave the cap hanging.
c) Check that the black sealing washer is fitted inside the cylinder valve. Place the
regulator down over the valve with switch.
d) Turn the switch clockwise on gas bottle-then turn on the gas grill as instructed.

8. Warning and safety points
Please read the following points before using your gas grill:
a) Read the instructions before using the appliance. Please followallassembly
instructions in this manual; if instructions are not followed it may cause problems
in use.
b) This gas grill accessible parts maybe very hot when being used. Keep young
children away. Use protective when handling particularly hot components.
c) In the event of a gas leak shut off gas to the gas grill, extinguish any open flames,
open lid and if leak continues check for damages, poor connections etc. Contact
your local gas dealer immediately if the problem can’t be solved.
d) Do not move Gas grill during use.
e) Do not use or store any flammable liquids or vapors in the vicinity when operating
the gas grill.
f) This gas grill only to be used outdoors.
g) Do not use a naked flame to check for gas leaks.
h) Do not operate gas grill if there is a gas leak. Turn off the gas supply.
i) Do not attempt to disconnect any gas fitting part if your gas grill is being used, on
the gas grill or the gas regulator / bottle.
j) Care is advised when operating your gas grill, you should never leave unattended
when in use. Turn off the gas supply at the gas container after use.
k) The gas grill should be cleaned on a regular basis.
Take care not to enlarge burner ports or orifice/nozzle openings when cleaning the
burner or valves.
l) Do not attempt to use this appliance in a garage or any enclosed area. Also this
appliance must be keep away from flammable materials, etc. We recommend
keeping a distance of at least 0.5 to 1.0 meter clear of any flammable materials.

m) We would recommend that this gas grill be serviced by your local gas retail outlet
at least onceayear by a competent engineer. Do not attempt to service this
appliance yourself.
n) Any modification of the appliance may be dangerous. Do not attempt any
unauthorized interference of the main controls on this gas grill, i.e. gas taps,
injectors, valves etc.
WARNING: The Handle Black Area (See Above Picture for Reference) Will
Become Hot When the Gas grill In Use, BE CAREFUL! Do Not Touch The Black
Area.
“Since this barbecue has no restriction in the emission of unburned gas, this barbecue
must be installed and/or used outdoors or in an amply ventilated area. Were this BBQ
in an amply ventilated area，the area must have at least 25% of the surface（sum of
the wall surface）area open.
Strongly recommends minimum clearances from combustible materials must be:
0 Rear - 450mm
Sides - 250 mm
Top - 1000 mm
9. Safety precautions
a) Always test gas line for leaks at connector with soapy water after making
connections.
b) The top lid must always be open when lighting the burner.
c) Use oven gloves and sturdy, long handled gas grill tools when cooking on the grill.
d) Be prepared if an accident or fire should occur. Know where the first aid kit and
fire extinguishers are and know how to use them.
e) Keep any electrical supply cord and the fuel supply hose away from any heated
surfaces.
f) Always cook with great care.
1000mm
250mm
250mm
450mm

10. Lighting instructions
Caution: The lid must be open when lighting the burner!
Do not stand with your face directly over the gas grill when lighting it.
Your gas grill will have following method of ignition:
Pilot Gas Control Ignition:
With all gas controls on the Gas grill in the “OFF” position, turn the gas cylinder
valve to the on position at the regulator. To create a spark you must push the control
knob in (A) and hold in this position for 3-5 seconds to allow gas flow and then turn
anticlockwise to” HIGH” (B). It can spark to the burner lighting tube (C). You will
hear a “snap” from the igniter and you will also see a 3”-5” orange flame coming
from the burner lighting tube at the left side of the burner (D).
Continue to hold the burner control knob in for two seconds after the “snap”, this will
allow gas to flow completely down the burner tube (E) and insure ignition.
When the burner is alight, adjacent burners will cross light when their controls are
turned to “HIGH”
At “High” setting the burner flame should be approximately 12-20mm long with a
minimum of orange flame. Turn the gas control fully anticlockwise for minimum
setting.
Should you have any difficulty lighting your gas grill following the above steps,
contact your dealer for advice.
Warning : If the burner still does not light ,turn the burner control knob
to” OFF” and wait 5 minutes to let the gas clear before lighting again.
