Disassembly Manual

Chapter 3 43
Machine Disassembly and Replacement
IMPORTANT:The outside housing and color may vary from the mass produced model.
This chapter contains step-by-step procedures on how to disassemble the notebook computer for
maintenance and troubleshooting.
Disassembly Requirements
To disassemble the computer, you need the following tools:
•Wrist grounding strap and conductive mat for preventing electrostatic discharge
•Flat screwdriver
•Philips screwdriver
•Plastic flat screwdriver
•Plastic tweezers
NOTE: The screws for the different components vary in size. During the disassembly process, group the
screws with the corresponding components to avoid mismatch when putting back the components.
Chapter 3

44 Chapter 3
General Information
Pre-disassembly Instructions
Before proceeding with the disassembly procedure, make sure that you do the following:
1. Turn off the power to the system and all peripherals.
2. Unplug the AC adapter and all power and signal cables from the system.
3. Place the system on a flat, stable surface.
4. Remove the battery pack.
Disassembly Process
IMPORTANT:The LCD Module cannot be disassembled outside of factory conditions. If any part of the LCD
Module is faulty, such as the camera, antenna or LCD panel, the whole module must be replaced.
The disassembly process is divided into the following stages:
•External module disassembly
•Main unit disassembly
The flowcharts provided in the succeeding disassembly sections illustrate the entire disassembly sequence.
Observe the order of the sequence to avoid damage to any of the hardware components. For example, if you
want to remove the mainboard, you must first remove the keyboard, then disassemble the inside assembly
frame in that order.
Main Screw List
Screw Quantity Part Number
M2.45D 8.0L K 5.5D 0.8T ZKNL 14 86.WBF02.001
M2.5D 5L K 5.5D ZK NL + CR3 23 86.WBF02.010
M2.46D 3.0L K 5.5D 0.8T ZKNL 3 86.WBF02.002
M1.98D 3.0L K 4.6D 0.8T ZKNL 20 86.WBF02.003
M3.0D 3.0L K 4.9D NI 8 86.WBF02.005
M2D 4.0L K 4.6D NI NL 2 86.WBF02.007
ASSY THML SPRING 4 86.WBF02.009

Chapter 3 45
External Module Disassembly Process
IMPORTANT:The outside housing and color may vary from the mass produced model.
External Modules Disassembly Flowchart
The flowchart below gives you a graphic representation on the entire disassembly sequence and instructs you
on the components that need to be removed during servicing. For example, if you want to remove the main
board, you must first remove the keyboard, then disassemble the inside assembly frame in that order.
NOTE: Items enclosed with broken lines (— - - —) are optional and may not be present.
Screw List
Step Screw Quantity Part No.
WLAN Module M2*3 1 86.WBF02.003
ODD Module M2.5*5 1 86.WBF02.010
ODD Bracket M2*3 2 86.WBF02.003
Primary HDD Carrier M3*3 4 86.WBF02.005
Secondary HDD Carrier M3*3 4 86.WBF02.005
Disconnect power
and signal cables
from system
Remove
Battery
Turn off system
and peripherals
power
Remove
DIMMs
Remove
WLAN
Remove
Primary HDD
Remove
ODD
Remove
Lower Covers
Remove
Dummy Cards
Remove
Secondary HDD

46 Chapter 3
Removing the Battery Pack
1. Turn computer over. Slide the battery lock in the direction shown.
2. Slide and hold the battery release latch to the release position (1), then lift out the battery pack from the main
unit (2).
1
2

Chapter 3 47
Removing the SD dummy card
1. Push the SD dummy card all the way in to eject it.
2. Pull the card out from the slot.

48 Chapter 3
Removing the Lower Covers
1. See “Removing the Battery Pack” on page 46.
2. Loosen the five captive screws in the memory and HDD covers.
3. Remove the HDD1 Cover.
4. Remove the HDD2, WLAN, and Memory Cover as shown.
HDD1
Cover
HDD2, WLAN,
and Memory
Cover

Chapter 3 49
Removing the Optical Drive Module
1. See “Removing the Lower Covers” on page 48.
2. Remove the screw securing the ODD module.
3. Insert a suitable tool into the access slot as shown. Gently lever the ODD module out of the chassis.
4. Pull the optical drive module out from the chassis.
Step Size Quantity Screw Type
ODD Module M2.5*5 1

50 Chapter 3
5. Remove the two screws securing the ODD bracket and remove the ODD bracket from the optical disk drive
module.
6. Remove the ODD bezel by rotating the top edge downward and pulling it clear of the module.
Step Size Quantity Screw Type
ODD Bracket M2*3 2

Chapter 3 51
Removing the DIMM Modules
1. See “Removing the Lower Covers” on page 48.
2. Push out the release latches on both sides of the DIMM socket to release the DIMM module.
3. Remove the DIMM module.
4. Repeat steps for the second DIMM module if present.

52 Chapter 3
Removing the WLAN Module
1. See “Removing the Lower Covers” on page 48.
2. Remove the adhesive tape securing the Antenna cables in place.
3. Disconnect the antenna cables from the WLAN Module.
NOTE: Cable placement is Black to the MAIN terminal (left) and White to the AUX terminal (right).

Chapter 3 53
4. Move the Antennas away and remove the two screws to release the WLAN Module.
5. Detach the WLAN Module from the WLAN socket.
NOTE: When reattaching the antennas, ensure the cables are tucked into the chassis to prevent damage.
Step Size Quantity Screw Type
WLAN Module M2*3 1

54 Chapter 3
Removing the Primary HDD Module
1. See “Removing the Lower Covers” on page 48.
2. Using the pull-tab, slide the HDD Module in the direction of the arrow to disconnect the interface.
3. Lift the HDD Module clear of the HDD bay.
NOTE: To prevent damage to device, avoid pressing down on it or placing heavy objects on top of it.
4. Remove the four screws (two each side) securing the hard disk to the carrier.
Step Size Quantity Screw Type
HDD Carrier M3*3 4

Chapter 3 55
5. Remove the HDD from the carrier.

56 Chapter 3
Removing the Secondary HDD Module
NOTE: The Secondary HDD is optional and may not be present.
1. See “Removing the Lower Covers” on page 48.
2. Using the pull-tab, slide the HDD Module in the direction of the arrow to disconnect the interface.
3. Lift the HDD Module clear of the HDD bay.
NOTE: To prevent damage to device, avoid pressing down on it or placing heavy objects on top of it.

Chapter 3 57
4. Remove the four screws (two each side) securing the hard disk to the carrier.
5. Remove the HDD from the carrier.
Step Size Quantity Screw Type
HDD Carrier M3*3 4

58 Chapter 3
Main Unit Disassembly Process
Main Unit Disassembly Flowchart
Screw List
Step Screw Quantity Part No.
Switch Cover M2.5*5 3 86.WBF02.010
LCD Module M2.5*8 4 86.WBF02.001
M2.5*5 2 86.WBF02.010
Upper Cover M2.5*8 10 86.WBF02.001
M2.5*5 9 86.WBF02.010
M2.5*3 3 86.WBF02.002
TouchPad Bracket M2*3 1 86.WBF02.003
Speaker Module M2*3 4 86.WBF02.003
Modem Board M2*3 2 86.WBF02.003
USB Board M2.5*5 1 86.WBF02.010
Mainboard M2.5*5 1 86.WBF02.010
CPU Fan M2*3 3 86.WBF02.003
Thermal Module M2.5*6.5 4 86.WBF02.009
Remove
Mainboard
Remove
USB Board
Remove
Switch Cover
Remove
Keyboard
Remove
Upper Cover
Remove
LCD Module
Remove
LED Board
Remove External
Modules before
proceeding
Remove
TouchPad
Bracket
Upper
Cover
Lower
Cover
Remove
Speaker Module
Remove
Modem Module
Remove
Media Board
Remove
Media Board FFC
Remove
CPU
Remove
RTC Battery
Remove
Thermal Module
Remove
RJ-11 Jack

Chapter 3 59
Removing the Switch Cover
1. See “Removing the Battery Pack” on page 46.
2. Lift the Media Board FFC cover as shown to expose the FFC connector.
3. Open the FFC locking latch and disconnect the Media Board FFC.
4. Remove the three securing screws from the Lower Cover.
Step Size Quantity Screw Type
Switch Cover M2.5*5 3

60 Chapter 3
5. Open the computer lid to approximately 45° and push the Switch Cover from the underside of the computer to
release the locking latches securing the cover in place.
6. Turn the computer over and open the lid fully. Lift the left side of the Switch Cover as shown.
7. Working along the Switch Cover toward the right hinge, gently pry up the cover as shown.

Chapter 3 61
8. Rotate the Switch Cover toward the LCD panel and lift it away from the Upper Cover.
