Packard Bell EasyNote W3 Series Installation instructions

Packard Bell
EasyNote W3 Series
(Dragon A)
Disassembly Manual

0
Table of Contents
Overview 1
Disassembly Instructions 1
Reassembly Instructions 1
Required Tools 1
Hazardous Voltage 2
Avoid Electrostatic Discharge 2
Power Supply Unit 2
Battery and AC Adapter 4
Removing the Hard Disk Drive 4
Bottom Panel 5
CPU and Fan 6
Top Cover 6
Removing the LCD Panel 8
Disassembling the LCD Panel 8
Optical Disk Drive 10
Bottom Base Assembly 11
Top Cover 12
Main Board Assembly 12
Notice 15

1
Overview
This document contains step-by-step disassembly instructions for the EasyNote W3
(Dragon A) chassis. The instructions are illustrated where necessary with images of the
part that is being removed or disassembled.
Packard Bell reserves the right to make changes to the chassis without notice.
Disassembly Instructions
When disassembling the system unit, follow these general rules:
nTurn off the power.
nDisconnect the AC adapter.
nRemove the battery.
nDo not disassemble the system into parts that are smaller than those specified
in the instructions.
nLabel all removed connectors; note where the connector goes and in what
position it was installed.
Reassembly Instructions
Reassembly is the reverse of the disassembly process. Use care to ensure that all
cables and screws are returned to their proper positions. Check that no tools or any
loose parts have been left inside the chassis. Check that everything is properly installed
and tightened.
Required Tools
All disassembly procedures can be performed using the following tools:
nPhilips (#2 bit) screwdriver
nHex bolt screwdriver

2
Hazardous Voltage
There is hazardous voltage present inside the
computer when it is connected to an AC
supply, even when the computer’s power
switch is off. Exposure to hazardous voltage
could cause personal injury. To avoid risk of
injury, contact an Authorized Service Provider
for proper (un)installation of optional
hardware devices.
Avoid Electrostatic Discharge
Electrostatic electricity can easily damage
circuit cards and integrated circuits (ICs). To
reduce risk of damage, store them in
protective packaging whenever they are not
installed in your system.
Add-in cards can be extremely sensitive to
ESD and always require careful handling.
After removing the card from the computer,
place the card flat on a grounded, static-free
surface, component-side up. Use a
conductive foam pad if available, but not the
card wrapper. Do not slide the card over any
surface.
Before you install or remove memory
modules, video memory, disk drives, circuit
cards or other devices, protect them from
static electricity. To do so, make sure your
computer’s power switch is OFF. Then,
unplug the computer’s AC power cord. Before
picking up the device you (un)install, you
should wear an anti-static wrist wrap
(available at electronic supply stores). Be
sure to connect the wrist wrap to an
unpainted metal portion of the computer
chassis. As an alternative, you can dissipate
electrostatic build-up by touching an
unpainted metal portion of the computer
chassis with one hand. Then touch the device
you are (un)installing with the other hand, and
maintain continuous contact with it until it is
(un)installed in the computer.
Power Supply Unit
Under no circumstances should you
attempt to disassemble the power
supply. The power supply contains
no user-serviceable parts. Inside the
power supply are hazardous
voltages that can cause serious
personal injury. Always return a
defective power supply to your
dealer.
WARNING
Ensure that the computer is
disconnected from its power source
and from all telecommunications
links, networks, or modem lines
whenever the chassis cover is
removed. Do not operate the
computer with the cover removed.
AVERTISSEMENT
Assurez-vous que le système est
débranché de son alimentation ainsi
que de toutes les liaisons de
télécommunication, des réseaux, et
des lignes de modem avant
d’enlever le capot. Ne pas utiliser le
système quand le capot est enlevé.
WARNUNG
Das System darf weder an eine
Stromquelle angeschlossen sein
noch eine Verbindung mit einer
Telekommunikationseinrichtung,
einem Netzwerk oder einer Modem-
Leitung haben, wenn die
Gehäuseabdeckung entfernt wird.
Nehmen Sie das System nicht ohne
die Abdeckung in Betrieb.
ADVERTENCIA
Asegúrese de que cada vez que se
quite la cubierta del chasis, el
sistema haya sido desconectado de
la red de alimentación y de todos lo
enlaces de telecomunicaciones, de
red y de líneas de módem. No
ponga en funcionamiento el sistema
mientras la cubierta esté quitada.

3
WAARSCHUWING
Zorg er voor dat alle verbindingen van en
naar de computer (stroom, modem, netwerk,
etc) verbroken worden voordat de behuizing
geopend wordt. Zet de computer nooit aan
als de behuizing geopend is.
AVVERTENZA
Prima di rimuovere il coperchio del
telaio, assicurarsi che il sistema sia
scollegato dall’alimentazione, da tutti
i collegamenti di comunicazione, reti
o linee di modem. Non avviare il
sistema senza aver prima messo a
posto il coperchio.

4
Battery and AC Adapter
To remove the rear bezel, do as follows:
1. Turn off the computer.
2. Disconnect the AC adapter.
3. Remove the battery.
Fig. 1 The bottom base.
Removing the Hard Disk Drive
To remove the hard disk drive, perform the following steps:
1. Remove two screws (2xA) from the HDD cover (as shown in Fig. 1).
2. Remove the HDD cover.
3. Remove one screw (1xB).
4. Slide the HDD to the left, away from its connector. Then lift it out.
Fig. 2 Removing the hard disk drive.

5
5. Remove four screws (4xC) from the HDD bracket.
6. Remove two screws (2xD) from the HDD bracket.
7. Remove the HDD bracket and connector.
Fig. 3 Removing the hard disk drive.
Bottom Panel
Perform the following steps to remove the bottom panel:
1. Remove nine screws (9xA) and take away the bottom panel.
Fig. 4 Removing the bottom panel.
2. Remove the memory module.
3. Remove the Mini-
PCI Wireless LAN card and disconnect the antenna
cable(s).
4. Remove the screws (2xA) from the modem.
5. Release the ground cable and modem.
6. Disconnect the modem cable from the modem.

6
Fig. 5 After removing the bottom panel.
CPU and Heat Sink
To remove the CPU and its heat sink, follow the steps below:
1. Disconnect the CPU fan cable.
2. Remove the screws (4xE) from the heat sink (see Fig. 5).
3. Take away the heat sink.
4. Lift the CPU lever and remove the CPU.
Top Cover
Remove the top cover by following the steps below:
1. Remove the button bar by sliding it to the left.
Fig. 6 Removing the button bar.
2. Remove the screws (4xD) from the keyboard.
Fig. 7 Removing the keyboard screws.

7
3. Flip keyboards towards you.
4. Disconnect the keyboard flat cable.
Fig. 8 Removing the keyboard flat cable.
5. Disconnect the touchpad flat cable.
Fig. 9 Disconnecting touchpad flat cable
6. Remove the two hinge covers.
Fig. 10 The hinge covers.
7. Disconnect the lid switch connector.
8. Remove the screw (1xD) and remove the lid switch unit.
Fig. 11 Lid switch and hinges.

8
Removing the LCD Panel Assembly
Follow the steps below to remove the LCD panel:
1. Disconnect the two LCD connectors.
2. Release the Wireless antenna cable.
3. Remove the screws (4xF) from the hinges (see Fig. 11).
4. Take away the LCD assembly.
Disassembling the LCD Panel Assembly
To disassemble the LCD panel, follow the steps below:
1. Remove the screw covers and screws (2xG).
2. Remove the screw covers and screws (4xH).
3. Unclip the front bezel by pushing it outwards from the inside
4. Take away the bezel.
Fig. 12 LCD panel front bezel.
5. Remove the screws (2xH) at the top (see Fig. 13).
6. Remove the screws (3xD) from the top supporting bracket.
7. Remove the screws (4xJ) from the hinges.
8. Remove the screws (2xD) from the lower supporting bracket.
9. Remove the screws (2xD) from the inverter board.

9
Fig. 13 LCD display panel.
10. Disconnect the inverter backlight connector.
Fig. 14 LCD inverter backlight connecter.
11. Remove the lower supporting bracket.
12. Take away the LCD display panel and inverter board.
13. Disconnect the LCD cable from the inverter board.
14. Disconnect the LCD cable from the back of the LCD display panel.
Fig. 15 LCD display cable.

10
15. Remove the screws (3x D, 1xA) from the left LCD bracket. The same
goes for the right bracket.
Fig. 16 LCD display cable.
16. Take away the top, left and right bracket from the LCD display panel.
17. Remove the screws (2xD) holding the wireless antenna and take
away the antenna.
Fig. 17 Wireless antenna.
Optical Disk Drive
To remove the optical disk drive follow the steps below:
1. Remove the screws (1xB, 1xJ) and push the optical disk drive out of
its bay.
Fig. 18 The screws of the optical disk drive.

11
2. Remove the screws (2xK) from the side ODD bracket and remove it.
3. Remove the screws (2xK) from the rear ODD bracket and remove it.
Fig. 19 The screws of the optical disk drive brackets.
Bottom Base Assembly
Disassemble the bottom base assembly as follows:
1. Remove the screws (15xJ, 3xG, 2xB) from the bottom base.
Fig. 20 The bottom base assembly.
2. Remove the screws from the rear (2xB).
Fig. 21 The screws at the bottom base rear.
3. Remove bottom cover from base assembly.
4. Disconnect the subwoofer connector.
5. Remove the screws (2xG) and lift out the subwoofer assembly.
6. Remove the rubber stabilizers (2xM) from the subwoofer assembly.
7. Remove the screw (1xB) from the modem connector board.

12
Fig. 22 The bottom cover.
8. Disconnect the cable connector from the modem connector board.
Top Cover
Follow the steps below to remove the top cover:
1. First remove the screws (2xA, 2xL).
2. Then remove the screws (4xJ).
Fig. 23 The top cover.
Note: Make sure that during re-assembly the clips of the top cover lock into place before
fastening the screws.
Main Board Assembly
To remove the main board from the top cover, follow the steps below:
1. Flip the top cover around.
2. Disconnect left speaker connector from main board.
3. Remove the screw (1xN).

13
4. Slightly lift main board and slide out left speaker assembly.
5. Disconnect right speaker from main board.
6. Remove the screw (1xG) and take away the right speaker assembly.
7. Remove the screw (1xB) from main board.
8. Remove the screws (2xO) from the VGA connector on the rear.
Fig. 24 The main board and speakers.
9. Take away the main board.
10. Partially remove the foil over the touchpad.
11. Disconnect the touchpad cable.
Fig. 25 The touch pad connector.
12. Remove the screws (3xB) and remove the heat plate.
13. Push out the touchpad assembly.

14
Fig. 26 Removing the heat plate.

15
Notice
The information in this guide is subject to change without notice.
This guide contains information protected by copyright. No part of this guide may be
photocopied or reproduced in any form or by any means without prior written consent
from NEC Computers International BV.
NEC COMPUTERS INTERNATIONAL BV SHALL NOT BE LIABLE FOR TECHNICAL
OR EDITORIAL ERRORS OR OMISSIONS CONTAINED HEREIN; NOR FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE
FURNISHING, PERFORMANCE, OR USE OF THIS MATERIAL.
Copyright © 2005 NEC Computers International BV. All rights reserved.
Packard Bell is a trademark of NEC Computers International BV.
The names of actual companies and products mentioned herein may be trademarks
and/or registered trademarks of their respective owners.
The software described in this guide is furnished under a license agreement or
nondisclosure agreement. The software may be used or copied only in accordance with
the terms of the agreement.
EasyNote W3 (Dragon A) Disassembly Manual
Author: Michael Snijders
First Edition: August 2005
Version: 1.0
Packard Bell
A division of NEC Computers International BV
