Packet8 SoftalK User manual

S ftalkTM
SoftalK™
User’s Manual
(Firmware version 1.5 and later)
Revision 1.5

Contents
ii
Chapter 1: Introduction . . .. . . . .. . . .. . . .. . . . .. . . .. . . .. . . .. . . . .. . . .. . . .. . . . .. 1
What is Packet8 Softalk™? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
How does Packet8 Softalk™ Work? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chapter 2: Installation . . . .. . . .. . . . .. . . .. . . .. . . .. . . . .. . . .. . . .. . . . .. . . .. . . .. . . 3
Minimum System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Multi-media Device Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installing Packet8 Softalk™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Uninstalling Packet8 Softalk™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Starting Packet8 Softalk™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 3: Using Packet8 Softalk™ . . . . .. . . .. . . .. . . . .. . . .. . . .. . . . .. . . .. . . .. . . 5
The Key Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Before Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Things to Keep in Mind . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Logging In . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Placing a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Encryption . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Placing a Call on Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Dial Pad Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Microphone and Speaker Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Softalk Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Account Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Setting up for Security outside of Softalk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setting up for Security within Softalk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
The Privacy Management Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
The About Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Window Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Controls within Packet8 Softalk™ for Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Chapter 4: Advanced Calling Features . . . . .. . . .. . . .. . . . .. . . .. . . .. . . .. . . . .. . .25
Call Conferencing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Starting a Conference Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Removing a Caller from the Conference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Adding a caller to the conference from the Contact Drawer . . . . . . . . . . . . . . . . . . 26

Contents
iii
Do Not Disturb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Auto-Answer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Speakerphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Call Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Chapter 5: The Wings & Settings Menu . . . .. . . .. . . .. . . . .. . . .. . . .. . . .. . . . .. . .28
The Contact Wing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Managing Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Managing the Lists of Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
The Video Wing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Chapter 6: Application Hot Keys . . . . .. . . . .. . . .. . . .. . . . .. . . .. . . .. . . .. . . . .. . .36
Packet8 Softalk™ Troubleshooting . . .. . . . .. . . .. . . .. . . . .. . . .. . . .. . . .. . . . .. . .38
Audio Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

1
CHAPTER 1
Introduction
What is Packet8 Softalk™?
Packet8 Softalk™ is a software telephone (also known as a “softphone”) with all of the
features of traditional business telephones, including hold, transfer, and conferencing.
Packet8 Softalk™ also has video calling and messaging capabilities.
The following is a partial list of features available and specifications in the Packet8
Softalk™ softphone:
■Call record
■Acoustic echo cancellation
■Message waiting indicator
■Audio & video tuning wizard
■Touch tones
■Call forwarding
■3 caller audio & video conferencing
■Speakerphone
■Caller ID
■Call timer
■Mute
■Direct IP calling
■Speed dial
■Hold
■Do not disturb
■Call ignore
■Send to voicemail
■Redial
■2 lines

Chapter 1 - How does Packet8 Softalk™Work?
2
■Managed contact list - importing and exporting contacts between Softalk and other
applications
■Call history - list of received, missed, dialed and blocked calls.
■Keyboard shortcuts for most major functions
■SIP compliant
■STUN, TURN & ICE NAT traversal
■Packet8 Softalk™ supports the following audio codecs: G.711u. G.711a, G.729, iLBC
■Packet8 Softalk™ supports the following video codecs: H.263, H.264
How does Packet8 Softalk™ Work?
Instead of phoning over traditional telephone networks, Packet8 Softalk™ calls are
made over computer networks through an Internet service provider or a local area
network (LAN). This breakthrough in telecommunications is called Voice over Internet
Protocol – VoIP, or “Voice over IP.”
Calls made anywhere in the world to similar Internet-based telephones are generally
free, while calls made to traditional telephone systems can be much cheaper than
typical long-distance and international rates. Voice quality for conversations using VoIP
technologies can greatly exceed traditional telephone services.
Packet8 Softalk™ uses the Session Initiation Protocol (SIP) for session signaling and the
International Telecommunications Union (ITU) codec standards for voice and video
(G.711, iLBC, G.729, H.263, H.264).

3
CHAPTER 2
Installation
Minimum System Requirements
Multi-media Device Requirements
Since Packet8 Softalk™ is a software application, both speakers and a microphone are
required to make calls. Any of the following configurations are acceptable:
■External speakers and microphone
■Dual-jack multimedia headset
■Built-in microphone and speakers
■USB multimedia headset
■USB phone
Calls made with Packet8 Softalk™ will work without a video camera, but one is necessary
to allow other callers to see a caller’s image. Packet8 Softalk™ will work with most USB
video cameras.
Audio Only All Features
Minimum Optimal Minimum Optimal
Processor Intel® Pentium II
400 MHz or
equivalent
Pentium III®
1.3 GHz or
equivalent
Intel Pentium III
700 MHz or
equivalent
Pentium 4®
2.0 GHz or
equivalent
Memory 128 MB RAM 128 MB RAM 256 MB RAM 256 MB RAM
Hard Disk Space 15 MB 30 MB 30 MB 30 MB
OperatingSystem Windows® 2000
Windows® XP
Windows 2000
Windows XP
Connection IP network connection (Dial up, broadband, LAN, and wireless)
Sound Card Full duplex, 16 bit

Chapter2 - Installing Packet8 Softalk™
4
Installing Packet8 Softalk™
Installing Packet8 Softalk™ is straightforward and follows typical software installation
procedures.
Follow the instructions below for a Windows installation of Packet8 Softalk™:
1. Exit any software applications that use sound such as CD and media players.
2. Run the setup executable file. This file will typically be called Packet8-Packet8
Softalk™ -Win32-[build number].exe or something similar. NOTE THAT THE
INSTALLATION WIZARD WILL PROMPT YOU TO SHUT DOWN ANY VERSIONS OF
PACKET8 SOFTALK™ ALREADY RUNNING.
3. Follow the prompts offered by the installation wizard. NOTE THAT YOU MUST ACCEPT
THE LICENSE AGREEMENT TERMS TO INSTALL PACKET8 SOFTALK™ FOR WINDOWS.
4. Select Launch Packet8 Softalk™ at the final step of the wizard to start using the
softphone.
5. Click Finish to complete the installation.
Uninstalling Packet8 Softalk™
To uninstall an existing version of Packet8 Softalk™, follow the steps given below:
1. Launch the Windows Control Panel
2. Select Add or Remove Programs
3. Select the appropriate version of Packet8 Softalk™ and click Change/Remove (or Add/
Remove)
Starting Packet8 Softalk™
You can start Packet8 Softalk™ for Windows by following the steps given below:
1. Click the Start button.
2. Select Programs (All Programs on some systems)
3. Select the Packet8 Softalk™ folder (or the folder specified upon install).
4. Click the Packet8 Softalk™ icon.
NOTE You can also launch Packet8 Softalk™ by double-clicking on the appropriate desktop
shortcut icon.

5
CHAPTER 3
Using Packet8 Softalk™
The Key Pad
The Packet8 Softalk™ softphone provides an easy-to-use key pad as the main user
interface, which allows for quick access to both basic and advanced calling features.
Refer to Figure 1 below for an illustration of the Packet8 Softalk™ user interface.
Figure: 1 Packet8 Softalk™ User Interface

Chapter 3 - Before Making a Call
6
Before Making a Call
Things to Keep in Mind
Making calls with Packet8 Softalk™ is simple; there are, however, some differences
between a softphone and a traditional telephone which the user should be aware of:
1. A softphone is a computer application that must be running to make or receive calls.
2. Softphone software must login to the network before making or receiving calls. This
procedure may take a few seconds as the softphone contacts Packet8’s network.
Once the softphone’s call status reads Logged in – Enter Phone Numbe the user is
ready to make or receive calls.
3. Since calls are transmitted over the Internet, service quality may drop due to network
congestion. Although Packet8 Softalk™ includes advanced signal processing
features to mask the effect of such congestion, decreased voice quality may be
noticeable during poor network conditions. Most broadband connections provide
adequate bandwidth for high-quality voice and video. If you experience poor audio
or video quality, please see “Packet8 Softalk™ Troubleshooting” in Appendix A.
Logging In
The log in dialog will show up and request user to log in to the network by entering your
Packet8 Softalk™ number and password.
When finished entering all of the information, click Log In. If all required information is
saved, Softalk will attempt to login to the Packet8’s network, indicated by a Logging in…
message in the call status screen.
IMPORTANT When the message Ready - Your Softalk Number: 1-XXX-XXX-XXXX appears in
the call status screen, then Packet8 Softalk™ is ready to make and receive calls. If You see the
message Login failed!, then they failed to login successfully and will not be able to make or
receive calls. For such cases refer to Appendix A: Packet8 Softalk™ Troubleshooting of this
document, which includes tips for this and other potential softphone problems.
Figure: 2 Log In Dialog Box

Chapter 3 - Placing a Call
7
Placing a Call
As mentioned in the previous section, Packet8 Softalk™ is ready to make or receive calls
once you see the message Ready – Your Packet8 Softalk™ Number in the call status
screen.
There are several ways to enter a phone number in Packet8 Softalk™. You can click the
digits of Packet8 Softalk™’s on screen numeric keypad, or you can enter the numbers/
letters directly from your computer’s alphanumeric keyboard.
Notice that when you begin to enter a number, Line 1 is automatically selected as the
line in use for that call—as shown in Figure 3 below.
If at any point you enter erroneous digits, click the Clearbutton within the dial pad or
press Backspace button on the computer keyboard to make corrections.
When you enter a phone number, you will receive prompts for completing that number
(as shown in Figure 3). To enter the rest of the number as suggested, hit the Tabkey on
the computer keyboard to enter the remaining digits.
When you are finished entering a number, click the green telephone icon button on
screen or press Enter on the computer keyboard to dial.
As with a traditional telephone, you will hear ringing as Packet8 Softalk™ tries to access
the remote caller. At this time, you also will also see the message “Ringing” in the call
status screen. When the remote caller answers, you should hear him/her and see the
message “Call Established” in the call status screen.
Figure: 3 Dialing a Number

Chapter 3 - Placing a Call
8
You can also place a call by clicking on an available on screen line button and dialing the
appropriate number. Conference calling is covered in “Call Conferencing” of this
document.
How Description
Keying 1. If you start to enter a name and the Turn Letters feature is
on, then these letters are converted to numbers. Press
Clear, then press spacebar and try again. See “Options -
General - Application” on page 13 for details on the Turn
Letters feature.
2. Click or press Enter.
Partial keying As you key in an entry, a suggestion for completing the entry may
appear. Press Tab to accept the suggestion. Then click or press Enter.
Drag-and-drop Drag an entry from the Contacts tab or any of the lists in the Calls tab
to the Call display.
If the Contacts list contains lots of contacts, use the field to filter
the list. Then drag the entry.
Right clicking Right-click an entry on the Contacts tab or any of the lists in the Calls
tab, and choose Phone this Person.
If the Contacts list contains lots of contacts, use the field to filter
the list. Then right-click the entry.
Redialing Press Redial.
From Outlook If you have set up contacts in Microsoft® Outlook®, you can place a
call from there.
■Double-click the contact in the Contacts list in Outlook. The
Contact dialog box appears.
■Click the in the top left corner and select the phone number
to dial. As soon as you release, Softalk will be brought to the
front (or will be started) and the call will be placed.
For information on how Softalk and Outlook contacts work together,
see “Exporting Contacts” in Chapter 5
Figure: 4 Call Alert box

Chapter 3 - Encryption
9
If you have turned on Call Alerts, the Call Alert box appears at the bottom of the screen.
For information on turning on alerts, see “Options - General - Alerts and Sounds” on
page 13
You will hear a ringing tone while Softalk attempts to make a connection.
Encryption
The outgoing call may be encrypted, depending on your security settings. For
information on the current security settings, see “Encryption” on page 9.
■If an encrypted call is established, the icon appears on the Call display. This icon
indicates that the call is guaranteed to be secure between you and your proxy, and
may or may not be secure beyond that first hop. See “Encryption” on page 9for more
details on how encryption works.
■If an unencrypted call is established, the unencrypted icon appears.
■If the call cannot be established with the specified security, the call will fail.
Ending a Call
As with traditional phones, softphone calls are brought to a close when either the
Packet8 Softalker or the other caller hangs up.
You can end an active call by clicking the on screen Hangup button. When a call
has ended the message Hung up will appear in the call status screen.
After a call has ended, details of the call (such as the length of the call and the caller ID)
will remain in the call display. To clear the display, click the Clearbutton.
Redial
To redial a number, click the Redialbutton within the on screen dial pad.
Answering a Call
Packet8 Softalk™ must be enabled to answer incoming calls. When you receive a new
call, a ring tone will sound over the computer’s configured speaker device. You will hear
the softphone ringing from whatever device (e.g. headset/USB phone)
If the Softalk is hidden behind another window or minimized, the application will pop
into view when the incoming call is received.
Incoming calls are indicated in the call display as shown in Figure 4 below.
Incoming calls arrive on Line 1 by default. They are indicated by a flashing light on the
line button.

Chapter 3 - Placing a Call on Hold
10
You can choose to ignore calls by clicking the Ignore button found within the call status
screen below the caller ID of the incoming call.
As a call arrives, click the Dialbutton (or press Enter on the computer keyboard) to
answer. You can also click the appropriate flashing line button to answer the incoming
call.
Placing a Call on Hold
While engaged with a call, you can place that call on hold by either clicking the
corresponding line button or by selecting another line altogether. The on hold line’s
button will flash to indicate that its corresponding call has been placed on hold. To
resume a call that is on hold, select the line again by clicking on the appropriate line
button “1” or “2.”
Dial Pad Controls
The keypad includes several controls which allow you to customize your Packet8
Softalk™ experience:
Microphone and Speaker Adjustment
The Packet8 Softalk™ keypad includes microphone and speaker sliders as shown in
Figure 1. Click and drag on the slider up or down to increase or decrease the desired
volume level.
You may also mute the Softalk phone so that the other caller cannot hear you. Click the
MUTE button at the bottom-left of the keypad to mute the phone. Toggle the button
once more to take the phone off mute.
Figure: 5 Incoming Call

Chapter 3 - Softalk Menu
11
Softalk Menu
Packet8 Softalk™ includes a Softalk menu that allows you to quickly access the following
features:
■Settings- Settings control the way that you work with Softalk. See “Options - General
- Application” on page 13.
■Open Dialgnostic Log - Customer support may ask you to pen this log if you are
experiencing problems with Softalk. For information, see “Options - Advanced -
Diagnostics” on page 19.
■Open Diagnostic Folder - Customer support may ask you to pen this log if you are
experiencing problems with Softalk. For information, see “Options - Advanced -
Diagnostics” on page 19.
■Privacy Management - See “The Privacy Management Window” on page 23.
■Log In - This is where you login to your new Softalk or exisiting account.
■Help- This menu item takes you to http://www.packet8.net/support/faqs/.
■About - Shows the version of Softalk
■Exit- To exit Softalk.
To launch the dial pad Softalk menu by clicking at the top of the Softalk phone or
right click anywhere over the on screen dial pad, see figure “6”.
.
The Diagnostic Log contains important network and protocol information that may be
useful for troubleshooting various issues. For more on this see “Packet8 Softalk™
Troubleshooting” in Appendix A.
Figure: 6 Menu

Chapter 3 - Options
12
Options
Options are settings and preferences that apply to all accounts.
Options - General - Application.
Figure: 7 General - Application

Chapter 3 - Options
13
Options - General - Application
Options - General - Alerts and Sounds
Field Description
Always on top of other
applications Click on or off, to suit your preference.
Launch when Windows
starts Click on or off, to suit your preference.
Prompt when shutdown Click on or off, to suit your preference.
Turn letters into digits
when typing into the
phone
Click on or off, to suit your preference.
You can also turn this feature on and off at any time by pressing the
spacebar.
Number of calls in each
list Enter number to suit your preference.
EnableZeroTouchdevice
configuration When clicked on, Softalk detects the audio and video devices
connected to your computer and automatically configures one of
them for use with Softalk.
Typically, leave this setting on. If you have several audio or video
devices and you do not like the device that Softalk selects, you can
override the selection on the Devices pane. See page 25.
Enable Zero Touch
bandwidth detection When clicked on, Softalk detects the speed of your network
connection and hence the potential bandwidth. If you move your
computer to a different IP address, Softalk automatically detects the
new speed.
When clicked off, you must specify the network connection . See "
Options - General - Device" on page 25.
The recommended setting is On.
Enablestatus bar
messages When clicked on, messages relating to zero touch configuration will
appear in a notification balloon at the lower right corner of the
screen, whenever the configuration automatically changes.
(Notification balloons are supported in newer versions of Windows.)
Folder for recording Specify a location for saving files when you record your
conversations.

Chapter 3 - Options
14
On this page you can:
■Work with ringtones. You can import a ringtone (a .WAV file). You can play to try it out.
You can activate one ringtone. You can delete a ringtone.
■Set up Softalk to bring the softphone to the front automatically when a call comes in.
■Set up Softalk to display the Call Alert box (below) when a call comes in either always,
or only when Softalk is not visible.
Figure: 8 Options - General Alerts and Sounds
Figure: 9 Call Alert box

Chapter 3 - Options
15
Options - General - Device
Figure: 10 Device Menu
Field Description
Headset
Speaker device Change these fields only if you want to override the device selected
by zero-touch device configuration.
Microphone device In both these fields, select the headset you are using.
The headset is the device that is usually used for audio out (the sound
you hear) and audio in (recording your voice). The only situation in
which the headset is not used is when the Speaker Phone button on
the dialpad is pressed.
Therefore, unless you will always be using Softalk in speakerphone
mode, you must make a selection here.
Select the headset in both the Speaker device field and Microphone
device field
Use acoustic echo
cancellation (AEC)
Reduces the echo effect that can arise with a speakerphone or that
can arise if the sound from the speakerphone or headphone leaks
into the microphone. Turning this feature on improves sound quality.
Typically on.

Chapter 3 - Options
16
Use auto gain control
(AGC)
Automatically adjusts the microphone volume level so that the other
party does not hear the distortion that might be caused by too high
a microphone input or too low volume (due to too low input level).
Typically on.
Use noise reduction Automatically attempts to remove background noise.
Typically off for the headset.
Speakerphone
Speaker device Change this field only if you want to override the device selected by
zero-touch device configuration (see page 24).
Make the appropriate choice:
■Select the device that you want to use for audio out (the
sound you hear) when the Speaker Phone button is
pressed. Make sure you select a speaker device (not the
headset).
■Select None if you do not have a speaker phone. The
Speaker Phone button on the dialpad is disabled.
Microphone device Change this field only if you want to override the device selected by
zero-touch device configuration.
Make the appropriate choice:
■Select the device that you want to use for audio in
(recording your voice) when the Speaker Phone button is
pressed.
It can be any microphone: it does not have to be the
microphone on the device you specified as the speaker
device. For example, it can be the microphone on your
camera.
■Select None if you do not have a speaker phone. The
Speaker Phone button on the dialpad is disabled.
Use acoustic echo
cancellation (AEC)
Reduces the echo effect that can arise with a speakerphone or that
can arise if the sound from the speakerphone or headphone leaks
into the microphone. Turning this feature on may . However, the
drawback is that it uses more processing power, which may slow
down your applications.
Typically on.
Use auto gain control
(AGC)
Automatically adjusts the microphone volume level so that the other
party does not hear the distortion that might be caused by too high
a microphone input or too low volume (due to too low input level).
Typically on.
Use noise reduction Automatically attempts to remove background noise.
Typically on for the speakerphone.

Chapter 3 - Options
17
RingDevice
Speaker device The device where you want to hear the phone ringing: the headset,
the speakephone, or none.
Speaker volume The volume of the ringer.
Camera
Camera This field appears only on version of Softalk that include video
functionality.
Complete this field only if you have disabled zero-touch device
configuration.
Select the camera model.
