PAG 9701V User manual

SAFETY INSTRUCTIONS
This leaflet contains important safety and
operating instructions. Please read these
fully and note all warnings before using
the PAG Camera Power Adaptor.
Please follow all instructions and retain
this leaflet for future reference.
The Camera Power Adaptor is not intended
for any use other than the powering of
video cameras from the PAG Cube Charger
or the PAG V4-iPC charger.
IMPORTANT: Use only with the PAG Cube or
V4-iPC chargers. Do not attempt to connect
to any other power source.
Do not attempt to disassemble the Camera
Power Adaptor. There are no user-
serviceable parts inside, and incorrect
reassembly may result in a safety hazard.
Do not use the Camera Power Adaptor if it
has been damaged in any way. In this
event you should seek advice from your
nearest PAG Dealer, or direct from PAG Ltd.
London, by telephoning [phone].
U5088 ISS B / MAR 2011
PAG CPA Camera Power Adaptor
Models 9701V & 9701
SPECIFICATION
PAG CPA Camera Power Adaptor
For use with specified PAG V-Mount chargers.
Model No. 9701V
PAG CPA Camera Power Adaptor
For use with specified PAGlok charger.
Model No. 9701
Input Connection:
To be powered only from PAG Cube chargers
(Models 9702 & 9702V) or PAG V4-iPC
charger (Model 9700V).
Output:
16.8V DC. Maximum current 5.5A (90W).
Output Connector:
XLR-4 (F) connector. Pin 1 Negative, Pin 4
Positive.
Overall Dimensions (H x W x D):
130mm x 86mm x 47mm
(5.1" x 3.4" x 1.85" approx.)
Weight:
190g (6.7oz. approx.)
PAG Ltd.
565 Kingston Road
Raynes Park
London SW20 8SA
T [phone]
F [phone]
E [email protected]
www.paguk.com

OPERATING INSTRUCTIONS
IMPORTANT: Please ensure your camera can
accept an input voltage of 16.8V without
damage. Most newer cameras are designed
for use with 14.4V / 14.8V Li-Ion batteries,
and are likely to be suitable, but some
older cameras could be damaged by the
higher voltage. If suitability cannot be
positively established, please do not
connect your camera to the PAG CPA.
When the CPA is connected to a channel on
the charger, the channel status will
indicate CPA. This indicates the CPA has
been identified by the charger. The charger
will continue to charge any connected
batteries until the CPA is activated.
To activate the CPA, press and hold the
button on the CPA for one second. The
‘Process Indicator’ will move to the channel
with the CPA, the CPA will then become
active. The V4-iPC display will flash CPA,
and the voltage on the display will be
shown as 16.8. Charging will be suspended
while the CPA is active.
To de-activate the CPA, press and hold the
button for one second or remove the CPA
from the V4-iPC. The charger will then
resume charging any batteries connected.
The CPA is intended for use with specified
PAG chargers only (see Specification). Use
with other chargers may cause damage to
the CPA or the camera.
SERVICING AND REPAIRS
Important: Refer all servicing or repairs to
qualified servicing personnel. The PAG CPA
contains electronics that do not require
periodic maintenance, and consequently
there are no user-serviceable parts inside.
Unqualified personnel should not attempt
further investigation since this may
invalidate the guarantee and could cause
more damage than the original fault.
Seek advice from your nearest PAG dealer
or direct from PAG Ltd., London, by
telephoning [phone].
WARRANTY
Notwithstanding any provision of any
agreement the following Warranty is
exclusive: PAG Limited warrants each
Camera Power Adaptor it manufactures to
be free of defects in material and
workmanship under use and service for
TWO YEARS from the date of purchase.
This warranty extends only to the original
purchaser. This warranty shall not apply to
parts which have been subject to misuse,
neglect, accident or abnormal conditions of
operation.
In the event of failure of a product covered
by this warranty, PAG Limited will repair
equipment returned to an authorised
Service Facility within the period of the
warranty, provided the warrantor’s
examination discloses to its satisfaction
the product was defective. The warrantor
may, at its option, replace the product in
lieu of repair. With regard to any
equipment returned within this period,
said repairs or replacements will be made
without charge. If the failure has been
caused by misuse, neglect, accident or
abnormal conditions of operation, repairs
will be billed at a nominal cost. In such a
case, an estimate will be submitted before
work is started, if requested.
The foregoing Warranty is in lieu of all
other warranties, express or implied,
including but not limited to any implied
warranty or merchantability, fitness or
adequacy for any particular purpose or use.
PAG Limited shall not be liable for any
special, incidental, or consequential
damages, whether in contract, tort, or
otherwise.
