Pallmann KING COBRA User manual

Operating instructions
Floor sander KING COBRA 3,68 KW (5,0Hp) / 60Hz
#047939
#064326
UFLOOR Systems Inc. | 14705 E. 33rd Place Unit-D | Aurora CO 80011 | Tel: [phone] | Fax: [phone] | www.ufloor-systems.com

2 05/2011
As of: May 2011
UF OOR Systems Inc.
Service Center Manager
14705 E. 33rd Place Unit-D
Aurora Co, 80011
Telephone: [phone]
Fax: [phone]

This brochure uses the symbol to mark important instructions for safety and preventing
damage.
Please give special attention to the marked instructions.
They refer to a potentially dangerous situation. Failure to comply can result in fatal or severe injuries and
damage to property.
3 05/2011

4 05/2011
Contents
1 Introduction.................................................................................................................................... 6
2 Scope of delivery........................................................................................................................... 7
3 achine specifications KING COBRA ........................................................................................ 8
3.1 Important components..................................................................................................................... 8
3.2 Technical data ................................................................................................................................. 9
3.3 Safety and machine protection facilities .......................................................................................... 9
4 Proper use...................................................................................................................................... 9
5 Installing the guide tube .............................................................................................................. 10
6 Disassembling for transport ........................................................................................................ 11
6.1 Removing the guide tube ............................................................................................................... 11
6.2 Removing the motor ........................................................................................................................ 12
7 Operating the KING COBRA ....................................................................................................... 14
7.1 Protective clothing and equipment ................................................................................................ 14
7.2 Fitting the dust bag ....................................................................................................................... 15
7.3 Safety instructions regarding dust .................................................................................................. 16
7.4 Disposing of sanding dust ............................................................................................................. 17
7.5 Replacing the sanding belt ............................................................................................................ 18
7.6 Adjusting the sanding pressure ..................................................................................................... 19
7.7 Safety instructions for electric cable and connectors .................................................................... 20
7.8 Connecting the KING COBRA to the mains power ........................................................................ 20
7.9 Remarks about sanding parquet and plank floors ......................................................................... 22
7.10 Sanding with the KING COBRA ..................................................................................................... 25
8 aintenance .................................................................................................................................. 30
8.1 Changing the sanding drum .......................................................................................................... 30
8.2 Adjusting the running wheels ......................................................................................................... 32
8.3 Adjusting the castor wheels ........................................................................................................... 34
8.4 Adjusting the tension roller ............................................................................................................. 35
8.5 Tightening the V-belts...................................................................................................................... 36
8.6 Guarantee........................................................................................................................................ 37

5 05/2011

1 Introduction
Dear customer,
you have decided in favour of the PA MANN parquet floor sander KING COBRA, the correct
choice with respect to quality and performance.
The KING COBRA is the result of a consistent implementation of many years of experience.
This machine combines an extraordinary high sanding performance and an excellent sanding
quality, together with an easy to operate, proven and reliable technology.
This operating instructions contain important informations for the use and safe operation of the
KING COBRA.
Caution!
Read these operating instructions carefully before assembling or operating the
KING COBRA. Ensure that all operators read these operating instructions prior to
operate the machine.
Adherence to the safety notes helps to protect against potential dangers for health and
personal safety and to prevent an improper utilisation of the machine.
Before starting to work, make yourself familiar with the operation of the machine. It's too
late if you do it while working!
Never allow anybody without sufficient skills and knowledge to operate the machine.
6 05/2011

2 Scope of delivery
1 machine
2 dust bag
3 cable with plug and coupling
4 respirator
5 multiclip
7 hexagon socket bolt key 5 mm
8 hexagon socket bolt key 6 mm
9 hexagon socket bolt key 10 mm
10 running wheel adjusting tool
11 tool pouch
12 fork wrench 10 mm
13 fork wrench 13 mm
14 fork wrench 24 mm
15 double fork wrench 30/36 mm
16 hearing protectors
7 05/2011

3 achine specifications KING COBRA
3.1 Important components
1 pressure regulating bolt 11 bumper wheel
2 castor wheels 12 belt guard
3 running wheels 13 motor
4 drum cover 14 switch box
5 V-belt tension bolt 15 dust bag
6 tension lever 16 cable arm
7 knurled nut 17 left hand grip
8 clamping lever 18 main lifting lever
9 motor plug 19 right hand grip
10 carrying handle 20 gentle lifting lever
8 05/2011
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20

9 05/2011
3.2 Technical data
Single-phase AC motor . . . . . . . . . . . . . . . . . . . . . . 240 V, 60 Hz
Motor power. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3,68kW (5,0HP)
Sanding drum speed . . . . . . . . . . . . . . . . . . . . . . . . . . 2550 rpm
Sanding width. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 250 mm
Sanding belt dimensions . . . . . . . . . 250 mm x 750 mm, endless
Machine weight. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90 kg
3.3 Safety and machine protection facilities
KING COBRA is equipped with an
-overcurrent cutout and an
-no-volt release
The overcurrent cutout protects the machine from damage and persons from endangering in the
case of short circuits.
The no-volt release prevents uncontrolled restart of the machine after power failure. The motor
will not restart automatically when the power returns, it will have to be switched on again.
4 Proper use
The parquet floor sander KING COBRA is suitable for dry sanding of parquet and plank
floors. No other use is allowed.
Caution!
Never use KING COBRA for wet procedures (mortal risk from electric shock)!

10 05/2011
5 Installing the guide tube
Note: The KING COBRA is delivered with the guide tube (1) removed.
Caution!
Injury to the operator or other persons could occur or damage could occur if the machine
starts up unintentionally. Disconnect the machine from the power supply before working
on the machine!
Instructions:
1. Insert the guide tube (1) into the guide tube support (7). The curved section of the tube must
face toward the motor. Clamp the guide tube by means of the clamping lever (6) located on
the guide tube support.
2. Fit the connector (8) into the both bolts of th pull rod
3. Move the main lifting lever (2) into the rear position to raise the sanding drum from the floor.
4. Tighten both wing nuts

6 Disassembling for transport
For easy transportation the motor and the guide tube can be removed.
6.1 Removing the guide tube
Caution!
Injury to the operator or other persons could occur or damage could occur if the machine
starts up unintentionally. Disconnect the machine from the power supply before working
on the machine!
Instructions:
1. Fold down the cable arm (3).
2. Move the main lifting lever (2) to the front position in order to lower the sanding drum to the
floor. This removes the load from the control rod (5).
3. oosen both of the wing bolts a little (4). Push the handle down to detach the control rod
(5) from the connector (8).
4. Open the guide tube support (7) with the clamping lever (6) and pull the guide tube (1) out.
11 05/2011

6.2 Removing the motor
Caution!
Injury to the operator or other persons could occur or damage could occur if the machine
starts up unintentionally. Disconnect the machine from the power supply before working
on the machine!
Instructions:
1. Make sure that the motor switch is in the off position and that the mains cable is
disconnected from the motor plug.
2. Unbolt the knurled nut from the belt guard and open the belt guard.
3. oosen the lock nut (2) on the belt tension bolt.
4. Turn the belt tension bolt (1) counterclockwise. This will lower the motor and release the
tension on the belts.
5. Remove the belts.
12 05/2011

6. Remove the knurled nut from the motor bracket.
7. Now you can remove the motor.
13 05/2011

14 05/2011
7 Operating the KING COBRA
7.1 Protective clothing and equipment
Caution! Wear hearing protectors!
The supplied hearing protectors must be worn when using the machine.
The following sound level values have been measured for the parquet floor sander
KING COBRA according to DIN 45 645:
Idle mode EQ = 85 dB(A)
Working mode EQ = 87 dB(A)
The noise produced when the machine is working depends on various factors. ocal
conditions such as room size and quality of the floor affect noise development.
Caution! Wear a respirator!
When using the parquet floor sander KING COBRA and when disposing of the sanding
dust, always wear a respirator (see chapter 7.3 and 7.4). Wear the respirator which is
supplied with the accessories.
Caution! Wear safety goggles!
When using the parquet floor sander KING COBRA and when working on KING COBRA,
always wear safety goggles to protect your eyes.
Caution! Wear proper working clothing!
When using the parquet floor sander KING COBRA and when working on KING COBRA,
never wear loose clothing. This can get caught up in moving parts.

7.2 Fitting the dust bag
Caution!
Only use original PALL ANN dust bags for the parquet floor sander COBRA.
Caution!
The dust bag must be firmly fitted to the dust pipe before sanding.
Instructions:
1. Pull the dust bag over the dust pipe to behind the pipe reinforcement.
2. Fasten the dust bag here using the Multiclip.
15 05/2011

16 05/2011
7.3 Safety instructions regarding dust
Caution! Ultra-fine sanding dust!
Always wear a respirator when sanding parquet and plank floors (is included with the
accessories).
When the machine is used for its proper purpose, the sanding of wooden floors naturally
produces dust. The machine has an integrated dust collecting system which blows the dust into
the dust bag. The dust is collected in the dust bag. Even so, this cannot prevent fine and
ultra-fine dust being produced when using the machine.
Caution! Health risk!
Wood dust, particularly when treated with impregnating agents, solvents and coatings,
can cause allergic reactions (e.g. of the skin or respiratory system) after a sensitization
period. Beech and oak dust is classified as being carcinogenic (cancer of the nasal
mucous membranes). Dust from other kinds of wood is suspected of having a
carcinogenic effect.
Caution! Fire risk!
No smoking while sanding!
All ignition sources are prohibited in rooms where sanding work is being carried out!
Air the rooms thoroughly.
Together with an ignition source and the oxygen in the air, wood dust can cause fires and
explosions.
Caution! Fire risk!
Sanding over metal parts such as nails can produce sparks which are blown into the
dust bag together with the wood dust. Here the glowing metal chips can still cause a fire
even hours later.
Every time after the machine has stopped and at the end of working, the sanding dust
contained in the dust bag must always be disposed of immediately in a fire-proof,
non-flammable container. The container must be covered with a fire-proof,
non-flammable lid. Store the container only outdoors.

7.4 Disposing of sanding dust
Caution! Fire risk!
Because of the fire risk, the sanding dust contained in the dust bag must always be
disposed of immediately every time after the machine has stopped and at the end of
working. The sanding dust must be disposed of immediately in a fire-proof,
non-flammable container. The container must be covered with a fire-proof,
non-flammable lid. Store the container only outdoors.
Caution!
At the latest when 1/3 full, the sanding dust contained in the dust bag must be disposed
of, because the dust collecting capacity is reduced when the bag is any fuller. The
sanding dust must be disposed of in a fire-proof, non-flammable container. The container
must be covered with a fire-proof, non-flammable lid. Store the container only outdoors.
Caution!
Always wear a respirator when disposing of the sanding dust (included with the
accessories).
17 05/2011

18 05/2011
7.5 Replacing the sanding belt
Caution! Danger from machine starting up!
When replacing the sanding belt, there is a risk from the machine starting up
unintentionally. Always disconnect the parquet floor sander from the mains power before
working at the sanding belt.
Caution! Risk of cutting your hands!
The sanding grains of the sanding belt have sharp edges. Always wear safety gloves
when replacing the sanding belt.
Instructions for replacing the sanding belt:
1. Switch the machine off.
2. Disconnect the machine from the mains
power.
3. Open the sanding drum cover (1).
4. Move the tension lever (2) forward. The
sanding belt which was held under tension
is now released. Pull it out to the side.
5. Insert a new sanding belt.
6. Clamp the new sanding belt by moving the
tension lever (2) backward.
7. Close the sanding drum cover (1).

7.6 Adjusting the sanding pressure
Use the pressure regulating bolt to adjust the required sanding pressure.
High sanding pressure:
Turn the pressure regulating bolt inwards as far as it will go.
Low sanding pressure:
Turn the pressure regulating bolt outwards to the red marking (2) on the bolt thread.
1
19 05/2011

20 05/2011
7.7 Safety instructions for electric cable and connectors
Caution! ortal risk from electric shock!
There is a mortal risk from electric shock if the machine is used when the electric cable
or connectors are damaged. If the electric cable and connectors are damaged, they must
be replaced by a qualified electrician.
Caution! ortal risk from electric shock!
Running over the electric cable with the sander entails a mortal risk from electric shock!
Never point the machine towards the cable!
7.8 Connecting the KING COBRA to the mains power
2
3
1
4
