Palm 3245WW - Wireless Keyboard With Bluetooth... Installation instructions

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
1
Palm® Wireless Keyboard
with Bluetooth® wireless technology
(3245WW)
Disassembly Instructions
3245WW_Disassembly_Instructions_v101_2006-10-25.pdf

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
2
Required Tools
(1)A cross screw driver with 2mm diameter for fastening and
unfastening screws
(2)A plastic bar for removing parts without damages(optional)

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
3
The Keyboard
Remove the easel by hand

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
4
Unfasten these two screws on the left strip panel
The left strip panel is disassembled

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
5
Take the rubber dome
Take the battery cover

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
6
Unfasten these two screw on the right strip panel
Remove the strip panel by releasing the snap hook

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
7
The right strip panel is disassembled
Take the rubber cover of DC Jack

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
8
Remove the upper hinge
Take the left key module

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
9
Note, this switch is attached by double adhesive tape
Take the lower hinge

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
10
Take the right key module
Take the membrane tail by releasing connectors

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
11
The key module is disassembled
Unfasten the 9 screws on the left case

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
12
Take left case and the spring and two rubber feet
Unfasten the two screws on the button

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
13
Disassemble the button
Unfasten the 11 screws on the right case

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
14
Take right case and spring and two rubber feet
Take the PCBA

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
15
Disassemble the middle hinge
Take the rubber feet and mylar

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
16
Remove the link bar
Remove the upper holder
Push here

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
17
Holder is disassembled
Release the shaft

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
18
Easel is disassembled
Take the rubber feet

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
19
Take the rubber foot and mylar
Take the mylar

Only authorized recyclers are permitted to use these disassembly
instructions. Any attempted disassembly by a user or unauthorized party
will void the product warranty and may irreparably damage the product.
20
Take the lock from left strip panel
Remove the lock pin
