Panasonic DMR-UBC90 User manual

TQBS0033
Getting started
Watching broadcasts
Recording
Playing back video
Editing video
Copying video
Photo and Music
Network
With Other Equipment
Other functions
Setup
Reference
Thank you for purchasing this product.
Please read these instructions carefully before using this
product, and save this manual for future use.
Operating Instructions
Blu-ray Disc™ Recorder
Model No. DMR-UBC90 DMR-UBS90
Software (Firmware) Update
To support the latest features, it’s very
important you install the latest updates
to maintain proper operation of your unit.
For details, refer to “Software
(Firmware) Update” (>84) or
http://panasonic.jp/support/global/cs/
(This site is in English only.)
until
2017/03/20
EG
DMR-UBC&UBS90EG_eng.book 1 ページ ２０１７年３月２日 木曜日 午後７時６分

TQBS0033
2
You can watch UHD/HDR broadcasts.
This unit supports HLG, which is one of HDR
formats.
Refer to “Watching broadcasts”. (>30)
This unit can simultaneously record three
UHD/HDR broadcasts. Thanks to its 2 TB HDD,
the unit offers ample space for storing UHD (4K)
programmes. You can also copy recorded
programmes to a USB HDD while maintaining the
superb picture quality of UHD (4K).
Refer to “Recording TV programmes”. (>35)
Refer to “Copying programmes”. (>64)
This unit can play back recorded UHD (4K)
programmes and 4K content stored on external
media, such as USB devices.
Refer to “Playing programmes on the HDD”.
(>47)
Refer to “Operation during play”. (>53)
Refer to “4K Networking”. (>57)
This unit can play back Ultra HD Blu-ray discs.
Refer to “Enjoying Ultra HD Blu-ray”. (>55)
Small object
• Keep the Memory Card out of reach of children
to prevent swallowing.
Features
Watch UHD/HDR broadcasts
Record/store UHD/HDR programmes
Play UHD/HDR programmes and 4K content
Play Ultra HD Blu-ray Discs
Safety precautions
WARNING
Unit
• To reduce the risk of fire, electric shock or
product damage,
- Do not expose this unit to rain, moisture,
dripping or splashing.
- Do not place objects filled with liquids, such as
vases, on this unit.
- Use only the recommended accessories.
- Do not remove covers.
- Do not repair this unit by yourself. Refer
servicing to qualified service personnel.
- Do not let metal objects fall inside this unit.
- Do not place heavy items on this unit.
AC mains lead
• To reduce the risk of fire, electric shock or
product damage,
- Ensure that the power supply voltage
corresponds to the voltage printed on this unit.
- Insert the mains plug fully into the socket
outlet.
- Do not pull, bend, or place heavy items on the
lead.
- Do not handle the plug with wet hands.
- Hold onto the mains plug body when
disconnecting the plug.
- Do not use a damaged mains plug or socket
outlet.
• The mains plug is the disconnecting device.
Install this unit so that the mains plug can be
unplugged from the socket outlet immediately.
DMR-UBC&UBS90EG_eng.book 2 ページ ２０１７年３月２日 木曜日 午後７時６分

TQBS0033 3
Unit
• This unit utilizes a laser. Use of controls or
adjustments or performance of procedures other
than those specified herein may result in
hazardous radiation exposure.
• Do not place sources of naked flames, such as
lighted candles, on this unit.
• This unit may receive radio interference caused
by mobile telephones during use. If such
interference occurs, please increase separation
between this unit and the mobile telephone.
• This unit is intended for use in moderate climates.
Placement
• Place this unit on an even surface.
• To reduce the risk of fire, electric shock or
product damage,
- Do not install or place this unit in a bookcase,
built-in cabinet or in another confined space.
Ensure this unit is well ventilated.
- Do not obstruct this unit’s ventilation openings
with newspapers, tablecloths, curtains, and
similar items.
- Do not expose this unit to direct sunlight, high
temperatures, high humidity, and excessive
vibration.
Batteries
• Danger of explosion if battery is incorrectly
replaced. Replace only with the type
recommended by the manufacturer.
• Mishandling of batteries can cause electrolyte
leakage and may cause a fire.
- Do not mix old and new batteries or different
types at the same time.
- Do not heat or expose to flame.
- Do not leave the battery(ies) in a car exposed
to direct sunlight for a long period of time with
doors and windows closed.
- Do not take apart or short circuit.
- Do not recharge alkaline or manganese
batteries.
- Do not use batteries if the covering has been
peeled off.
- Remove batteries if you do not intend to use
the remote control for a long period of time.
Store in a cool, dark place.
• When disposing of the batteries, please contact
your local authorities or dealer and ask for the
correct method of disposal.
Please check and identify the supplied
accessories.
(Product numbers are correct as of March 2017.
These may be subject to change.)
• Do not use AC mains lead with other equipment.
Insert batteries
Insert so the poles (i and j) match those in the
remote control.
CAUTION Supplied accessories
Remote control (N2QAYB001114):1pc.
Batteries for remote control: 2 pcs.
AC mains lead: 1pc.
[UBC90]
RF coaxial cable: 1pc.
[UBS90]
Splitter: 1pc.
About descriptions in these operating
instructions
• These operating instructions are applicable to models
DMR-UBC90 and DMR-UBS90. The illustrations in these
Operating Instructions show images of DMR-UBC90
unless otherwise indicated.
•[UBC90] :
indicates features applicable to DMR-UBC90 only.
•[UBS90] :
indicates features applicable to DMR-UBS90 only.
• Pages to be referred to are indicated as “>±±”.
• Images are for illustration purpose, contents may change
without notice.


R6/LR6, AA
(Alkaline or manganese batteries)
DMR-UBC&UBS90EG_eng.book 3 ページ ２０１７年３月２日 木曜日 午後７時６分

TQBS0033
4
Table of contents
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety precautions . . . . . . . . . . . . . . . . . . . . 2
Supplied accessories. . . . . . . . . . . . . . . . . . 3
Getting started
Unit care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Main unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Remote Control. . . . . . . . . . . . . . . . . . . . . . . 8
CI (Common Interface) module . . . . . . . . . 9
Connection. . . . . . . . . . . . . . . . . . . . . . . . . . 11
Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
HDD and media information . . . . . . . . . . . 24
FUNCTION MENU screen . . . . . . . . . . . . 29
Watching broadcasts
Watching broadcasts . . . . . . . . . . . . . . . . . 30
Recording
Recording TV programmes. . . . . . . . . . . . 35
Timer recording. . . . . . . . . . . . . . . . . . . . . . 39
Keyword Recording . . . . . . . . . . . . . . . . . . 43
Using the external HDD (USB HDD). . . . 46
Playing back video
Playing programmes on the HDD . . . . . . 47
Playing contents on the media . . . . . . . . . 51
Operation during play. . . . . . . . . . . . . . . . . 53
4K Networking. . . . . . . . . . . . . . . . . . . . . . . 57
Playback menu . . . . . . . . . . . . . . . . . . . . . . 57
Editing video
Deleting/Editing programmes . . . . . . . . . . 60
Copying video
Copying programmes. . . . . . . . . . . . . . . . . 64
Photo and Music
Photo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Network
Network Service . . . . . . . . . . . . . . . . . . . . . 76
TV Anywhere. . . . . . . . . . . . . . . . . . . . . . . . 76
DVB-via-IP Server Function (TV>IP) . . . 77
Home Networking (DLNA) . . . . . . . . . . . . 78
With Other Equipment
Copying the HD Video (AVCHD) . . . . . . . 82
Other functions
VIERA Link . . . . . . . . . . . . . . . . . . . . . . . . . 83
Software (Firmware) Update . . . . . . . . . . 84
Other operations. . . . . . . . . . . . . . . . . . . . . 85
Setup
Basic Settings . . . . . . . . . . . . . . . . . . . . . . . 88
Reference
Troubleshooting guide. . . . . . . . . . . . . . . 103
Specifications . . . . . . . . . . . . . . . . . . . . . . 112
Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
DMR-UBC&UBS90EG_eng.book 4 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033 5
Unit care
• If the HDD or USB HDD is damaged, the
recorded content cannot be recovered.
• The unit may breakdown if cigarette smoke
or bug spray/vapour, etc. gets inside the
unit.
Before moving the unit, ensure the disc tray is
empty.
1Switch the unit to standby mode. (Wait until
“GOOD-BYE” disappears from the display.)
2Remove the AC mains lead from the
household mains socket.
3Move only after the unit has come to a
complete stop (approx. 3 minutes) in order to
avoid subjecting to vibration and shock. (Even
after the unit is switched to standby mode, the
HDD continues operating for a short time.)
The registration of the USB HDD may be
cancelled in the process of repairing this unit.
You can use the USB HDD again by
re-registering, but all recorded content already on
the USB HDD will be lost. In such cases, the
recorded content (data) cannot be recovered.
This unit may contain private information. Before
disposing of or transferring this unit, perform the
following to delete the data, including personal or
secret information:
- Format HDD (>94)
- Perform “Shipping Condition” (>102)
HDD/USB HDD handling care
• The HDD is a high precision recording
instrument and is easily susceptible to damage.
Therefore, be careful of the following points
while the unit is turned on, especially during
operation, otherwise the HDD and the recorded
content may be damaged:
- Do not subject the unit to any vibration and
shock.
- Do not remove the AC mains lead from the
household mains socket.
• The HDD is a temporary storage device
- It is recommended to save the recorded
content on a disc or to keep the original data or
CDs that they were copied from.
- If you notice a problem with the HDD such as
repetitive strange sounds, immediately save
(backup) all content and request service. If you
continue using the HDD with a problem, the
unit or the recorded content will be damaged.
Setup precautions
• Do not place on anything that generates heat
like a Set Top Box, etc.
• Place in an area where condensation does
not occur. Conditions where condensation
may occur
- When there is an extreme change in
temperature.
- When there is high humidity or a lot of steam
in the room.
In the above situation, without turning the unit
on, let the unit adjust to the room temperature
and wait 2–3 hours until condensation is gone.
Getting started
When moving the unit
Cleaning
• Wipe with a soft, dry cloth.
• Never use alcohol, paint thinner or benzine to
clean this unit.
• Before using chemically treated cloth, carefully
read the instructions that came with the cloth.
• Use the lens cleaner (not supplied) to clean the
unit’s lens.
When requesting this unit for repair
To dispose or transfer this unit
DMR-UBC&UBS90EG_eng.book 5 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033
6
Main unit
• While writing to/reading from the media, do not switch the
unit to standby mode or remove the media. Such action
may result in loss of the media contents.
• When inserting the media, ensure that it is facing the right
way up.
• When removing the SD card, press on the centre of the
card and pull it straight out.
• The USB port on the front side does not support
USB HDDs. Connect a USB HDD to the USB port on the
rear side. (>46, Connecting the USB HDD)
Front
     
Pull to flip down
the front panel.
1Disc tray
2SD card slot
3Display (>7)
4USB port ( DC 5 V 900 mA)
• This port supports USB 3.0 Super Speed.
5Remote control signal sensor
• Angle: Approx. 20° up and down, 30° left and
right
• Distance: Within approx. 7 m in front of the
unit
6CI slot (>9)
7Open/close disc tray
8Standby/on switch (Í/I)
Press to switch the unit from on to standby
mode or vice versa. In standby mode, the unit
is still consuming a small amount of power.
Inserting or removing media
∫Disc
Disc
∫SD card/USB device
DMR-UBC&UBS90EG_eng.book 6 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033 7
Class II equipment (The construction of the
product is double-insulated.)
Display

   
1Main display section indicator
• Messages and other information are
displayed. (>110)
2Drive (HDD, BD or SD) indicator
3Recording indicator
• The indicator will light up while recording.
• The indicator will blink while recording is
paused and before recording starts.
4Playback indicator
5SD card slot indicator
6USB port indicator
7Disc indicator
8Copying indicator
9Remote control signal indicator
:Timer recording indicator
This indicator lights up when the timer
recording standby or Keyword Recording
standby is activated.
Rear

    
1AC IN terminal ( ) (>12, 13)
2Cooling fan
3LNB IN 1/2 terminal ([UBS90]) (>13)
4RF IN/OUT terminal ([UBC90]) (>12)
5LAN port
6HDMI AUDIO OUT terminal (>14 to 18)
7HDMI VIDEO OUT terminal (>14 to 18)
8COAXIAL terminal (>15 to 18)
9USB port ( DC 5 V 500 mA)
• This port supports USB 2.0 High Speed.
• Connect a USB HDD to this USB port.
DMR-UBC&UBS90EG_eng.book 7 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033
8
Remote Control
Instructions for operations are generally described using the remote control.
1Transmit the remote control signal
• Point it at remote control signal sensor on
this unit. (>6)
2Switch the unit from on to standby mode or
vice versa
3Select channels and programme numbers,
etc./Enter numbers or characters
4Switch to the previously watched channel
(>30)
5Manual skip (>54)
-10s: Skip approx. 10 seconds backward
+60s: Skip approx. 1 minute forward
6Basic operations for recording and play,
REWIND LIVE TV/PAUSE LIVE TV (>34)
7Show Information (>31, 49, 53)
8Selection/OK, Frame-by-frame (>54)
9Show Video Menu, Top Menu, Pop-up Menu
(>47)
:Show OPTION menu (>57, 60, 73)
;Colour buttons (red, green, yellow, blue)
(Use in accordance with instruction on the
screen.)
<Select audio (>31, 54)
=Select drive (HDD, Disc, SD or USB)
>TV operation buttons (>19)
?Start recording (>35)
@Channel select (>30)/Change pages in the
Video Menu screen etc.
ASwitching to the radio channel list (>30)
BShow the Timer Recording screen (>40)
CShow NETFLIX screen (>76)
DShow the Network Service screen (>76)
EExit the menu screen
FShow the TV Guide screen (>33)
GShow the FUNCTION MENU screen (>29)
HReturn to previous screen
IShow subtitles (>31, 55)
JShow Teletext (>31, 55)
G
U
I
D
E
CH
CH
PAGE
AV
INPUT
TV
OK
VOL
RETURN
OPTION
DRIVE SELECT
AUDIO
REC
TEX T
ST TL
10s
+60s
INTERNET
REWIND LIVE T V
0
2
abc
5
jkl
8
tuv
1
4
ghi
7
qrs
p
3
def
6
mno
9
xyz
w
F
U
N
C
T
I
O
N
M
E
N
U
STATUS
EXIT
SLOW
RADIO/
TV
x1.3
PAUSE LIVE TV
PROG/ CHECK
LAST VIEW


























DMR-UBC&UBS90EG_eng.book 8 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033 9
CI (Common Interface) module
Encrypted programmes and broadcasts cannot be viewed with the unit by using standard
connections and settings. An appropriate CI module is required to view or record them.
You need a CI module, CAM (Conditional Access Module) together with a certified Smart Card, and a
subscription with the corresponding broadcaster.
• If not viewing/recording an encrypted broadcast, you do not need to insert the CI module.
CI modul e
This unit allows you to record/view/play an encrypted programme when automatic decryption is
enabled. (Recording may not be possible, depending on the broadcaster.)
See “Notes for recording of an encrypted broadcast”. (>37)
[UBC90] [DVB-T2]
To view freenet TV (Germany only)
freenet TV provides pay television broadcasting services for DVB-T2.
Some freenet TV broadcasts and programmes may be encrypted. A supported CAM and a separate
subscription are required to view them. Refer to the website of freenet TV for more details.
• Turn off the unit before you insert or remove the CI module.
• Insert the CAM and the Smart Card with the correct direction.
• Point the CI module at the front side of this unit, and insert it carefully.
• For more details, see the manual of the CAM and Smart Card, or consult the dealer.
Insert the CI module into the CI slot of this unit.
CI slot
This unit
Smart Card
CAM (CI module)
DMR-UBC&UBS90EG_eng.book 9 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033
10
“CI Plus” is a technical specification that imposes
contents protection, etc.
When the CI Plus compatible broadcast is
recorded, the programme may be contents
protected. There are following types of the
contents protection depending on the broadcast:
• Copying not restricted
Depending on the programme, you can
copy/move only to USB HDD, BD-RE, BD-R, or
DVD-RAM (CPRM compatible discs only).
• One generation copy is permitted
You can copy to BD-RE, BD-R or DVD-RAM
(CPRM compatible discs only) only once.
• The original programme will be deleted.
• You cannot copy from the copied BD-RE,
BD-R or DVD-RAM (CPRM compatible discs)
to HDD or another disc.
When the picture quality is changed, the original
programme will be deleted.
• icon will appear on the Video Menu
screen. (>48)
• Copying is prohibited
You cannot copy/move to the USB HDD or disc.
The content of these media may also have the
following playback restrictions.
- Retention limit (>right)
- Content License (>right)
There are some programmes for which the
playback will be disabled after a predetermined
time.
(e.g., Permitted playback period is 90 minutes
after recording.)
• When the programme does not have playback
period, icon will appear on the Video Menu
screen after decrypting. (>48)
• When the programme has playback period,
or icon will appear on the Video Menu
screen after decrypting. (>48)
Playing back a programme with this restriction
requires a CAM with a playback licence for it.
• The number of times the programme can be
played back may also be limited.
• When the programme does not have playback
period, icon will appear on the Video Menu
screen after decrypting. (>48)
• When the programme has playback period,
icon will appear on the Video Menu screen
after decrypting. (>48)
Playing back a programme with this restriction
requires a CAM and enter the PIN code.
• icon will appear on the Video Menu screen.
(>48)
About CI Plus compatible broadcast
CI Plus contents protection
Retention limit
Content License
Parental Control
DMR-UBC&UBS90EG_eng.book 10 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033 11
Connection
3D programmes or 4K images can be played back when this unit is connected to 3D or 4K
compatible terminal of a 3D or 4K compatible TV.
∫Enjoying 4K output
• To enjoy images in 4K (50p/60p), you need an HDMI cable that supports 18 Gbps.
When outputting 1080p or 24p (4K) signal, please use HDMI cables 5.0 meters or less.
It is recommended that you use Panasonic’s HDMI cable.
• If you connect this unit to a 4K-compatible TV and perform “Easy Setting”, 4K (50p/60p) will be
automatically selected. (>21)
• To view broadcasts, programmes or Ultra HD Blu-ray content in 4K/HDR format, connect the unit to
the HDMI terminal of a TV that supports HDCP2.2, 4K (50p/60p) 4:4:4, and HDR signals that meet
these standards.
• To watch HLG broadcasts in their original picture quality, connection to an HLG-compatible TV is
required.
• Before making any connections, please disconnect all the units from AC power.
(Connect the AC mains lead after making all connections.)
• Use the High Speed HDMI cables. Non-HDMI-compliant cables cannot be utilized.
• When the unit is not to be used for a long time
To save power, unplug it from the household mains socket. This unit consumes a small amount of
power, even when the unit is in standby mode. (>112)
∫To enjoy broadcasts, programmes or Ultra HD Blu-ray discs that support HDR
(High Dynamic Range)
If you see a message about compatibility with HDR during playback of a broadcast, programme or
Ultra HD Blu-ray disc, please check your TV settings as follows:
Typically, the message will inform you that this unit is not connected to a TV compatible with HDR.
1 If you are using a Panasonic TV compatible with 4K and HDR released in 2015 or 2016,
(DX900/DX800/DX780/DX750/DX730/DX700 series etc.), please check your TV settings as
follows.
- Switch the TV to the HDMI input.
- Press “MENU” button of your TV remote control
- Select “HDMI HDR Setting” in “Setup”
- Select “On” in “HDMI HDR Setting”
2 If you use a TV not from Panasonic, compatible with 4K and HDR, please refer to the operating
instructions of the TV.
3 When you play back a HDR broadcast, programme or disc on a TV without HDR capability, the
broadcast, programme or disc can be played back (in non-HDR quality) even if the message
appears.
DMR-UBC&UBS90EG_eng.book 11 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033
12
HDMI cable connection (>14 to 18)
• Keep the RF coaxial cables as far away as possible from other cables.
• Switchover from DVB-T to DVB-T2 is scheduled. For details, check the relevant announcements made by broadcast stations.
(Germany only)
[UBC90] Antenna connections
VHF/UHF
RF IN
This unit’s rear panel
Household mains socket
(AC 220 to 240 V, 50 Hz)
AC mains lead
(supplied)
• Connect only after all other
connections are complete.
To the CATV terminal or the Aerial
CATV coaxial cable or Aerial cable
RF coaxial cable
(supplied)
DMR-UBC&UBS90EG_eng.book 12 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033 13
§Check the version of the single cable router. (>22)
HDMI cable connection (>14 to 18)
[UBS90] Antenna connections
The following three connection methods are available. Choose a method suited to your environment.
AUsing a single cable router:
You can record three programmes simultaneously.
• Attach the splitter (supplied) to LNB IN 1 and LNB IN 2 terminals, then connect satellite cable to
the splitter.
BUsing a multi switcher:
You can record two programmes simultaneously.
• Connect both LNB IN 1 and LNB IN 2 to the satellite dish.
CConnecting a satellite cable directly:
You can record only one programme at a time.
• Connect LNB IN 1 terminal to the satellite dish.
This unit’s rear panel
Household mains socket
(AC 220 to 240 V, 50 Hz)
AC mains lead
(supplied)
• Connect only after all other
connections are complete.
Satellite dish Satellite dish
Multi switcher
Satellite dish
Single cable router§
Splitter (supplied)
DMR-UBC&UBS90EG_eng.book 13 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033
14
You can enjoy richer sound by using the HDMI AUDIO OUT terminal.
(Audio is output in high resolution.)
Enjoying video and audio with a 4K-compatible TV
Setting
Set the following items in the setup menu (>88):
• Set “HDMI(VIDEO) Output Mode” to “Automatic ( Video Only / Video+Audio )”. (>97)
• Set “HDMI(AUDIO) Output Mode” to “Audio Only”. (>97)
Enjoying video with a 4K-compatible TV and audio with an amplifier
Setting
Set the following items in the setup menu (>88):
• Set “HDMI(VIDEO) Output Mode” to “Automatic ( Video Only / Video+Audio )”. (>97)
• Set “HDMI(AUDIO) Output Mode” to “Audio Only”. (>97)
• To enjoy audio with a TV
Set “HDMI(VIDEO) Output Mode” to “Video+Audio”. (>97)
• The HDMI AUDIO OUT terminal is not compatible with 4K output and the VIERA Link (>83).
HDMI
This unit’s rear panel
HDMI cable
(18 Gbps)
e.g., [UBC90]
HDMI INHDMI IN
HDMI cable
(18 Gbps)
e.g., [UBC90]
HDMI cable
Amplifier/receiver
DMR-UBC&UBS90EG_eng.book 14 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033 15
Enjoying video with a 4K-compatible TV and audio with a 4K-compatible amplifier
Setting
Set the following items in the setup menu (>88):
• Set “HDMI(VIDEO) Output Mode” to “Automatic ( Video Only / Video+Audio )”. (>97)
• Set “HDMI(AUDIO) Output Mode” to “Audio Only”. (>97)
• About ARC:
When using a TV or an amplifier/receiver that does not display “ARC” on the HDMI terminal, it is necessary to connect the TV
and the amplifier/receiver with a digital audio cable to enjoy the TV audio on the amplifier/receiver.
Enjoying audio with an amplifier connected to the COAXIAL terminal
Setting
Set the following items in the setup menu (>88):
• Set “HDMI(VIDEO) Output Mode” to “Automatic ( Video Only / Video+Audio )”. (>97)
• Set “HDMI(AUDIO) Output Mode” to “Audio Only”. (>97)
• To enjoy audio with an amplifier connected to the COAXIAL terminal
Set “Audio Output” to “Off” in “Advanced Settings”. (>97)
HDMI IN
(ARC)
HDMI OUT
(ARC)
HDMI IN
HDMI cable
(18 Gbps)
e.g., [UBC90]
HDMI cable
(18 Gbps)
Amplifier/receiver
(4K-compatible)
COAXIAL IN
Coaxial digital cable
e.g., [UBC90]
Amplifier/receiver
DMR-UBC&UBS90EG_eng.book 15 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033
16
3D or 4K images can be played back when this unit is connected to a 3D or 4K compatible TV.
• This connection only supports up to 5.1ch.
• To connect a TV and amplifier with an HDMI cable, connecting terminals on both the TV and amplifier
must be ARC-compatible. (>15, “About ARC”)
Connecting an amplifier to a 4K-compatible TV
Setting
Set the following items in the setup menu (>88):
• Set “HDMI(VIDEO) Output Mode” to “Automatic ( Video Only / Video+Audio )”. (>97)
• Set “HDMI(AUDIO) Output Mode” to “Audio Only”. (>97)
Set “Audio Output” to “Off” in “Advanced Settings”. (>97)
Enjoying video with a 4K-compatible TV in combination with an amplifier
connected to the HDMI AUDIO OUT terminal and another amplifier connected to
the COAXIAL terminal
Setting
Set the following items in the setup menu (>88):
• Set “HDMI(VIDEO) Output Mode” to “Automatic ( Video Only / Video+Audio )”. (>97)
• Set “HDMI(AUDIO) Output Mode” to “Audio Only”. (>97)
• To enjoy audio with an amplifier connected to the COAXIAL terminal
Set “Audio Output” to “Off” in “Advanced Settings”. (>97)
• To enjoy audio with a TV
Set “HDMI(VIDEO) Output Mode” to “Video+Audio”. (>97)
• It is not possible to simultaneously output audio from both the amplifier connected to the HDMI AUDIO OUT terminal and the
other amplifier connected to the COAXIAL terminal.
HDMI IN
(ARC)
HDMI OUT
(ARC)
HDMI IN
e.g., [UBC90]
Amplifier/receiver
HDMI cable
(18 Gbps) HDMI cable
HDMI INHDMI IN
e.g., [UBC90]
Amplifier/receiver
HDMI cable
(18 Gbps)
HDMI cable
Coaxial
digital cable
Amplifier/receiver
DMR-UBC&UBS90EG_eng.book 16 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033 17
Enjoying video with a 4K-compatible TV in combination with a 2K-compatible
projector and an amplifier that is connected to the COAXIAL terminal
Setting
Set the following items in the setup menu (>88):
• Set “HDMI(VIDEO) Output Mode” to “Automatic ( Video Only / Video+Audio )”. (>97)
• Set “HDMI(AUDIO) Output Mode” to “Audio Only”. (>97)
• To enjoy audio with an amplifier connected to the COAXIAL terminal
Set “Audio Output” to “Off” in “Advanced Settings”. (>97)
• To enjoy audio with a TV
Set “HDMI(VIDEO) Output Mode” to “Video+Audio”. (>97)
Set “Audio Output” to “On” in “Advanced Settings”. (>97)
• To enjoy video with a projector
Set “HDMI(AUDIO) Output Mode” to “Video+Audio”. (>97)
(It is not possible to output 3D, 4K or HDR content from the HDMI OUT terminal when “Video+Audio”
is selected.)
HDMI INHDMI IN
e.g., [UBC90]
Amplifier/receiver
HDMI cable
(18 Gbps)
HDMI cable
Coaxial
digital cable
Projector
(2K-compatible)
DMR-UBC&UBS90EG_eng.book 17 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033
18
Enjoying video with a 4K-compatible TV in combination with a 2K-compatible
projector and an amplifier that is connected to the HDMI AUDIO OUT terminal
and another amplifier that is connected to the COAXIAL terminal
Setting
Set the following items in the setup menu (>88):
• Set “HDMI(VIDEO) Output Mode” to “Automatic ( Video Only / Video+Audio )”. (>97)
• Set “HDMI(AUDIO) Output Mode” to “Audio Only”. (>97)
• To enjoy audio with an amplifier connected to the COAXIAL terminal
Set “Audio Output” to “Off” in “Advanced Settings”. (>97)
• To enjoy audio with a TV
Set “HDMI(VIDEO) Output Mode” to “Video+Audio”. (>97)
• To enjoy video with a projector
Set “HDMI(AUDIO) Output Mode” to “Video+Audio”. (>97)
(It is not possible to output 3D, 4K or HDR content from the HDMI OUT terminal when “Video+Audio”
is selected.)
• It is not possible to simultaneously output audio from both the amplifier connected to the HDMI AUDIO OUT terminal and the
other amplifier connected to the COAXIAL terminal.
HDMI INHDMI IN
HDMI IN
HDMI OUT
e.g., [UBC90]
Amplifier/receiver
HDMI cable
(18 Gbps)
HDMI cable
Coaxial digital cable
Projector
(2K-compatible)
HDMI cable
Amplifier/receiver
DMR-UBC&UBS90EG_eng.book 18 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033 19
When this unit is connected to the network, you
can enjoy network functions (Ultra HD Blu-ray
Playback, DLNA function, Network Service, TV
Anywhere, etc.).
For details about connection method, refer to the
instructions supplied with the connected
equipment.
After you make the LAN cable/Wireless LAN
connection, the network setting is needed.
(>22, Easy Network Setting)
• Use category 5 or above straight LAN cables (STP) when
connecting to peripheral devices.
About wireless LAN connection (>22, Easy
Network Setting)
• The unit is not compatible with public wireless LAN
services.
Settings
The TV can be operated from the TV operation
buttons of the remote control.
• Perform the setting if you cannot operate the TV
with the TV operation buttons.
While pressing [TV Í], enter the code with
the number buttons.
Manufacturer and Code No.
• If your TV brand has more than one code listed, select the
one that allows correct operation.
• If the brand of your TV is not listed or the code number is
invalid for your TV, this remote control is not compatible
with your TV.
Network connection
LAN cable connection
Wireless LAN connection
Broadband
router, etc.
Internet
LAN (ethernet) cable
TV operation buttons
Manufacturer Code Manufacturer Code
AIWA 35
BENQ 58/59
BRANDT 10/15
CENTREX 66
CURTIS 05
DESMET 05
ELEMIS 05
FINLUX 61
Panasonic 01/02/03/04
AKAI 27/30
BEKO 05/71/72/73/74
BUSH 05
DAEWOO 64/65
DUAL 05
FERGUSON 10/34
FISHER 21
MITSUBISHI 05/19/20/47
METZ 05/28/79
MIVAR 24
NEC 36
NOKIA 25/26/27/60/61
OLEVIA 45
ORION 05
PHILCO 41/48/64
PHONOLA 05
PROVIEW 52
RADIOLA 05
NOBLEX 33
NORDMENDE 10
ONWA 30/39/70
PEONY 49/69
PHILIPS 05/06/46
PIONEER 37/38
PYE 05
SABA 10
FUJITSU 53
ITT
LG
GOLDSTAR 05/50/51
GRADIENTE 36
25
JVC 17/30/39/70
KOLIN 45
05/50/51
MAG 52
FUNAI 63/67
GOODMANS 05
GRUNDIG 09
IRRADIO 30
KDS 52
KONKA 62
HITACHI 05/22/23/40/41
SALORA 26
SANSUI 05
32/42/43/65/68SAMSUNG
SCHNEIDER 05/29/30
SELECO 05/25
SIEMENS 09
SONY 08
TELEFUNKEN 10/11/12/13/14
TOSHIBA 16/57
YAMAHA 18/41
05
WHITE
WESTINGHOUSE
SANYO 21/54/55/56
05/69/75/76/77/78 SEG
SINUDYNE 05
31/33/66/67/69TCL
TEVION 52
THOMSON 10/15/44
SHARP 18
DMR-UBC&UBS90EG_eng.book 19 ページ ２０１７年３月２日 木曜日 午後７時６分

Getting started
TQBS0033
20
The tuner in this unit is compatible with digital
Cable broadcast services and digital terrestrial
broadcast services.
• In these operating instructions,
[DVB-C]: indicates features applicable to digital
cable broadcasts (DVB-C).
[DVB-T] ([DVB-T2]): indicates features applicable
to digital terrestrial broadcasts (DVB-T).
[Switchover from DVB-T to DVB-T2 is
scheduled. (Germany only)]
• This unit can receive only one of the two
services at a time.
1Turn on the TV, then select the appropriate
AV input to suit the connections to this unit.
3Select language, then press [OK].
4Select country, then press [OK].
5Set “TV Signal Selection”.
• Select “Digital Cable Channels” or “Digital
Terrestrial Channels”, then press [OK].
8Set Quick Start to “On”, “Off” or “Timer
Setting for Quick Start”, then press [OK].
When “Easy Setting has been completed.”
appears, Easy Setting is complete.
[UBC90]
Easy Setting
2Press [Í] on the remote control or [Í/I] on
this unit.
• The Easy Setting will start at the initial
power on.
1[DVB-C]
Select the channel number allocation,
then press [OK].
• For Germany and Austria:
We recommend selecting “Preset
Channel Number”.
• For Switzerland:
We recommend selecting “Operator’s
Channel Number ( LCN )”.
• To change channel allocation, restart Auto Setup
in Basic Settings menu and change channel
number allocation selection. (>89)
• If channel is not found, restart Auto Setup in Basic
Settings menu. (>89)
• Switchover from DVB-T to DVB-T2 is scheduled.
After switchover to DVB-T2, perform Update
Channel List to update channels. (Germany only)
2[DVB-C]
Select “Start Auto Setup”, then press
[OK].
• Scan Mode
Quick
Full
• Frequency
Auto
The preset frequency will be
automatically used.
Manual
Enter the frequency specified by your
cable provider with number buttons.
•Network ID
Auto
The preset Network ID will be
automatically used.
Manual
Enter the Network ID specified by your
cable provider with number buttons.
• Frequency and Network ID settings may be
necessary depending on the cable provider. For
details, consult the cable provider.
6Auto Setup will start automatically.
(This operation may take some time.)
[DVB-C]
When tuning is completed, press [OK].
7Clock will be set automatically.
If the clock setting screen appears, set the
time manually (>102, Clock).
