Panasonic Palmcoder PV-D407 User manual

O_att_g _Structleas

Thank you for choosing Panasonic!
You have purchased one of the most
sophisticated and reliable products on the
market today. Used properly, it will bring
you years of enjoyment. Please take time
to fill in the information at right. The serial
number is on the tag located on the
underside of your Palmcorder. Be sure to
retain this manual as your convenient
Palmcorder information source.
I
rDate of Purchase
Dealer Purchased From
Dealer Address
Dealer Phone No.
Model No.
Serial No.
These accessories are provided in order to set up or use your Paimcorder.
1 pc. AC Adaptor
(PV-A17)
with DC Power ,_
Cable _
1 pc. VHS PlayPak
(PV-P1/VYMW0009)
and one "AA" battery
1pc. Battery Pack
(PV-BP18)
1pc. CR2025 Clock
Battery (VSBW0004)
(installed in Palmcorder)
1 pc. Audio/Video
Cable (VJAW0032)
1pc. Shoulder Strap
(VYCW0149)
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
EQUIPMENT TO RAIN OR MOISTURE,
Your Compact VHS Palmcorder is designed to record
and play back in Standard Play (SP) and Super Long
Play (SLP) modes. YOu can also play a Compact VHS
Palmeorder recording on your VHS VCR using the
VHS PlayPak supplied.
,... i
CAUI1ON: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (DR BACK)
NO USER-:_ERVICEABLE PARTS INS;DE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
This Patmcorder is equipped with the HQ System to
provide excellent video pictures, and is compatible
with standard VHS equipment.
It is recommended that only cassette tapes that have
been _esled and inspected fOr use in VCR machines
with the _ and/or _ mark be used,
This symbol warns the user that
uninsulated voltage within the unit may
have sufficient magnilude to cause electri,
shock. Therefore, it is dangerous to make
any kind el cenlact w_th any inside part of
this unit.
/_ This symbol alerts the user that imporlant
literalure concerning the operation and
maintenance of this unit has been included.
Therefore, it should be read carefully in
,,,,,,,,,,,,,, order to avoid an_' problems. ,,,,, #
|
The above markings are located on the appliance bottom cover.

1. Read Instructions-- All the safety and operating
instructions should be read before the unit is
operated,
2_ Retain Instructions -- The safety and operating
instructions should be retained for future reference,
3. Heed Warnings i All warnings on the unit and in
the operating instructions should be adhered to,
4. Follow Instructions _ All operating and
maintenance i,nsttuctions should be Ioliowed,
5. Cleaning -- Unplug this video unit from the wag
outlet before cleaning. Do not use liquid or aerosol
cleaners. Use a dry cloth for cleaning,
6. Attachments-- Do not use attachments not
reCOmmended by the video product manufacturer
as they may be hazardous.
7, Water and Moisture _ Do not use this video unit
near water -- tor example near a bath tub, wash
bowl, kitchen sink, or laundry tub, in a wet
basemonL or near a swimming POoL and the like.
8, Accessories -- Do not place this video unit on an
unstable cart, stand, tripod, bracket, or table, The
video unit may fall, causing serious injury to a child
or adult, and serious damage to the unit, Use only
with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the
video unit. Any mounting of the unit should follow
the manufacturer's instructions and should use a
mounting accessory recommended by
the manufacturer. An appliance and
cart combination should be moved
w_th care. Quick stops, excessive
force, and uneven surfaces may
cause the appliance and cart
combination to overturn.
9, Ventilation -- Slots and openings in the cabinet are
provided for ventilation and to ensure reliable
operation of the video unit and to protect it from
overheating, These openings must not be blocked
or COvered. Never p_ce the video unit on abed,
sofa, rug, or other similar surface, or near or over a
radiator or heat register• This video unit should not
be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is
provided or the manufacturer's instructions have
been adhered to.
10. Power Sources -- This video unit should be
operated only from the type of power source
indicated on the marking label. If you are not sure
of the type of power supply to your home. consult
your appliance dealer or local power company. For
video units intended to be operated from battery
power, or other sources, refer to the operating
instructions.
1t. Grounding or Polarization -- This video unit may
be equipped with either apolarized 2-wire AC
(Alternating Current) line plug (a plug having one
blade wider than the other) or 3-wire grounding
type plug, a plug having a third (grounding) pin,
The 2-wlre polarized plug will fit into the power
outlet only one way, This is a safety feature. If you
are unable to insert the plug fully into the outJet.
try reversing the plug, If the plug still fails to fit,
contact your electrician to replace your obsolete
outlet. Do not defeat the salary purpose of the
polarized plug,
The 3-wire grounding type plug wifl fit into a
grounding type power outlet, This is a safety
feature. If you are unable to insert the plug into the
outlet, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose
of the grounding type plug.
12, Power-Cord Protection -- Power-supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or
against them, paying particular attention to cords
of plugs, convenience receptacles, and the point
where they exit from the unit,
13. Outdoor Antenna Grounding -- If an outside
antenna or cable system is connected to the video
unit, be sure the antenna or cable system is •
grounded so as to provide some protection against
voltage surges and built-up static charges• Part 1
of the Canadian Electrical Code, in USA Section
810 of the National Electrical Code, provides
inlormation with respect to proper grounding of the
mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of
grounding conductors, location of antenna
discharge unit, connection to grounding
electrodes, and requirements for the grounding
electrode.
ANTENNA
wlm_
_IS_N P_G,_ _NIT
LN_¢ _EC'nQN 8to-zo_
14. Lightning -- For added protection of this video unit
receiver during a lightning storm, or when it is ]eft
unattended and unused for long periods Of time.
unplug it from the wall cutlet and disconnect the
antenna or cable system. This will prevent
damage to the video unit due to lightning and
power-line surges,
3

t5. Power Lines -- An outside antenna system should
not be located in the vicinity of overhead power
tines or other electric light or power circuits, or
where it can fall into such power Jines or circuits.
When installing an outside antenna system,
extreme care should be taken to keep from
touching such power lines or circuits as contact
with them might be fatal
16. Overloading -- Do not overload wall outlets and
extension cords as this can result in a risk Of fire or
electric shock.
17. Objects and Liquids -- Never push objects of any
kind into this video unit through openings as they
may touch dangerous voltage points or short out
parts that could result in e fire or electric shock.
Never spill liquid of any kind onto the video unit.
18. Servicing -- Do not attempt to service this video
unit yourself as opening or removing covers may
expose you to dangerous voltage or other hazards.
Refer all servicing to qualified service personnel.
19. Damage Requiring Service -- Unplug this video
unit from the wall outlet and refer servicing to
qualified service personnel under the following
conditions:
a, When the power-supply cord or plug is
damaged.
b, If any liquid has been spilled onto, or objects
have fatten into the video unit.
c. if the video unit has been exposed to rain or
water,
d. If the video unit does not operate normally by
Iollowing the operating instructions. Adjust only
those controls that are covered by the operating
instructions, as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician
to restore the video unit to its normal operation,
e. If the video unit has been dropped or the cabinet
has been damaged,
f. When the video unit exhibits a distinct change in
pedormance -- this indicates a need for service
20. Replacement Parts -- When replacement pads are
required, be sure the service technician has used
replacement parts specified by the manufacturer or
have the same characteristics as the original part.
Unauthorized substitutions may result in fire,
electric shock or other hazards.
21. Safety Check-- Upon completion of any service or
repairs to this video unit, ask the service technician
to perform safety checks to determine that the
video unit is in safe operating order_
USE & LOCATION
•TO AVOtD SHOCK HAZARD _,. Your Camcorder and power supply should not be exposed to rain or moisture.
Do not connect the power supply or operate your Camcorder if it gets wet. Your Camcorder has been designed
for outdoor use, however it is not designed to sustain direct exposure to water, rain, sleet, snow, sand, dust, or a
direct splashing from a pool or even acup of coffee. This action could permanently damage the internal parts of
your Camcorder. DO not attempt to disassemble this unit There are no user serviceable parts inside. Unplug
your Camcorder from the power supply before cleaning.
• DO NOT AIM YOUR CAMCORDER AT THE SUN OR OTHER BRIGHT OBJECTS
•DO NOT LEAVE THE PALMCORDER WITH THE EVF AIMED DIRECTLY AT THE SUN AS THIS MAY
CAUSE DAMAGE TO THE INTERNAL PARTS OF THE EVF
•DO NOT EXPOSE YOUR CAMCORDER TO EXTENDED HIGH TEMPERATURE ... Such as, in direct sunlight,
inside aclosed car, next to a heater, etc... This action could permanently damage the internal parts of your
Camcorder.
•AVOID SUDDEN CHANGES IN TEMPERATURE ... If the unit is suddenly moved from a cold place to awarm
place, moisture may form on the tape and inside the unit.
•DO NOT LEAVE YOUR CAMCORDER OR THE POWER SUPPLY TURNED ON WHEN NOT tN USE.
- STORAGE OF YOUR CAMCORDER., Store and handle your Camcorder in a manner that will not subject it to
unnecessary mOvement (avoid shaJdng and striking). Your Cemcorder contains a sensitive pick-up device which
could be damaged by improper handling or storage.
CARE
- TO CLEAN YOUR CAMCORDER _. Do not use strong or abrasive detergents when cleaning your Camcorder
body,
• TO PROTECT THE LENS ... Do not touch the surface of the lens with your hand, Use a commercial camcorder
lens solution and lens paper when cleaning the lens. improper cleaning can scratch the lens coating.
•TO PROTECT THE FINISH OF YOUR CAMCORDER o.. Before handling your Camcorder, make sure your
hands and face are free from any chemical products, such as suntan lotion, as it may damage the finish.
4

Things You Should Know .................................................................................................. 2
Important Safeguards ....................................................................................................... 3
Precautions ....................................................................................................................... 4
Quick Operation Guide ..................................................................................................... 6
Supplying Power ............................................................................................................... 7
Cassette information ....................................................................................................... 10
Setting the Clock ............................................................................................................. 11
Electronic Viewfinder tndications .................................................................................... 15
Attaching the Shoulder Strap .......................................................................................... 18
Built-in Auto Light ............................................................................................................ 19
Camera Recording .......................................................................................................... 20
Ptay Back your Recordings ............................................................................................. 23
"I:[@ _| i_ |! IK_I.-']
Four-Speed Power Zoom ............................................................................................. 26
High Speed Shutter ...................................................................................................... 26
Focus ............................................................................................................................ 27
Backlight ....................................................................................................................... 28
One-Touch Auto Fade (BLACK or WHITE only) ........................................................... 28
Color Digital Fade (other than BLACK and WHITE) ..................................................... 29
Digital Zoom .................................................................................................................. 30
Digital Electronic Image Stabilization System ............................................................... 31
Negative/Positive Transposer ....................................................................................... 31
Motion Security ............................................................................................................. 32
Tally ON/OFF during Motion Security Recording .......................................................... 33
Intelligent Titler .............................................................................................................. 34
Copying your Tapes (dubbing) ........................................................................................ 35
Llili'iili liill Ill in!;I i It] i
Palmcorder Accessory System .............................................................. 36
Palmcorder Accessory Order Form ................ 1................................................................ 37
Notes Regarding Operations .......................................................................................... 38
Specifications .................................................................................................................. 39
Before Requesting Service ............................................................................................. 40
Request for Service Notice .................................................................. i.......................... 42
Index of Controls ............................................................................................................. 43
Index ............................................................................................................................... 48
Warranty .......................................................................................................................... 49
Spanish Quick Use Guide/Guia Para Uso R&pido .......................................................... 51
5

Charge the Battery Pack fully before operation (see page 7).
-if
._ Attach afully charged Battery
(see page 7).
Slide the TAPE EJECT switch to open
door.
POWER Lamp
Insert cassette (see page 10).
Press here to close door.
Set POWER switch to CAMERA.
Built-In Lens Cover opens and POWER
Lamp lights.
Slide TAPE SPEED Selector to SP or
SLP (see page 10).
While looking into the Vlewfinder,
adjust the Vision Adjustment Control
to your eyesight.
Press RECORD/PAUSE to start
recording.
Press RECORDtPAUSE again oLO_p_g._
recording (see page 20).
6
_f Set the POWER switch to VCR.
1
Press PLAY to start playback.
press STOP to stop playback.

Charge the Battery Pack fully /,
before operation. /'_!_
POWER _ _
/IPlug in the AC Adaptor.
CHARGELamp 9POWER Lamp lights.
,i_f Insert the Battery
Align the right side of the Battery with
the line on the AC Adaptor.
(_) Press the Battery down and slide it in
the direction of the arrow.
CHARGE Lamp lights. When charging is
done (about one and a half hours) the
lamp goes out.
Remove the Battery
Slide the Battery out and lift up.
Note:
After recharging the Battery Pack about 5times,
use the BATTERY REFRESH feature as
explained on page 8.
• The useful operation time of the Battery will
gradually decrease after repeated use and
recharging, The Battery is no longer
serviceable il the operation time is very short,
even after a sufficient charge.
With a fully charged Battery Pack, you wil! have a maximum of about one and a half
hours of continuous use. (If the Built-in Light is used, battery operating t_,medecreases.)
the Battery
(_ Align the Battery with the top of the
mounting surface.
(_ Press it into place until it locks with a
click.
Remove the Battery
While sliding the BATTERY RELEASE
button, remove the Battery,
7

IS_tt_4r_ _w t_ql*r=_'ltm=r,.,r,aa__K==
This feature completely discharges the Battery before recharging begins.
To maintain your Battery's operating capacity, use the refresh feature after about every five charges.
CHARGE Lamp
1Plug in the AC Adaptor.
• The POWER Lamp remains lit as long as the
AC Adaptor is plugged in.
Caution:
•Charge onlywithspecifiedcharger,
• Bafterycan be chargedwithina temperature
rangeol 32° F {0° C) and 104°F(40° C).
•Batterymay be warm after chargingor just
after use, Thisis nnrmal.
• Donotuse an insufficientlychargedor worn-
outBattery.
Safety precautions:
• Do not get the Battery near, or dispose of in
fire.
• Do not directly connect (short circuit) the
positive (+) and negative (-) terminals.
• Never attempt to disassemble or reassemble
the Battery.
•---'--- U.S.A. CONSUMERS: ,,
ATTENTION:
8
Place the Battery into
the AC Adaptor.
Press the BATTERY REFRESH
button.
The CHARGE Lamp flashes until
discharge is complete and then stays llt
until the Battery is fully charged,
Remove the Battery.
•Should you accidentally press the BATTERY
REFRESH button, remove the Battery and
then re-insed it to begin charging.
• It takes about seven and a half hours when
both Battery Refresh and recharging are
performed.
To avoid damage to the Battery:
• Do not drop or jar Battery.
• Use Battery with specified units only.
• If Battery is used in extremely high tempera-
tures, asafety device will automatically
prevent operation.
To prolong battery life:
•While not in use, remove Battery from the
Palmcorder and AC Adaptor and store in a
cool, dark, dry place.
• Keep Battery terminals clean.
The product you have purchased is powered by a nickel cadmium battery which is
recyclable. At the end of its useful life, under various state and local laws, it is illegal to 1
dispose of this battery into your municipal waste stream. PIease call 1-800-8-BATTERY/
for information on how to recy,cl.ethis battery, , ..... )

1
POWER Lamp DC IN _Connect VCR DC OUT on the
_Con ector ACmAcdapto _ totDC 'eNDOcntheer
r_ Cable (supplied).
VCR;cou' noecto, 2P,u ,nthe,C,Oapt=.
*The POWER Lamp will tight.
Notes:
•AC Adaptor cannot be used to power the Pa_mcorder while charging the Battery.
•While not in use, unplug the AC Adaptor from the AC outlet. (When plugged into an AC outlet, the
AC Adaptor consumes 1.2W of electric power when not in use.)
DC IN
C°n nec_.._te r
Socket (1:
Car Battery Cord Cigarette
(optional) Lighter Plug
Connect a PV-C16 Car Battery Cord
(optional) to DC IN on the Pa[mcorder.
First, start your car engine, and then
insert the Car Battery Cord plug into
your cigarette lighter socket.
• A fuse is located in the lighter plug end of
the cord.
Should fuse replacement be necessary
use the exact current rating (in amps).
Notes:
•This cord can only be used in vehicles
equipped with DC 12V (negative ground)
batteries. Use only the specified car battery
cord, If you are not sure, check with your local
car/truck dealer,
• To avoid blowing the fuse, be sure to start your
car engine before inserting the cigarette lighter
plug of the Car Battery Cord into the lighter
socket.
•Because the car is running while your
Patmcorder is in operation, make sure
you're in a well ventilated area.
•Disconnect the cigarette lighter pIug when
your Palmcorder is not being used.
9

1
f-- .L Turn the Wheel in the direction
Tape
of the arrow until there is no slack.
Attach the Battery (see page 7)..
Slide the TAPE EJECT switch
to open the door.
4Insert the cassette vertically
with its window side facing
out.
Press here to close the door.
•To remove the cassette, slide the TAPE EJECT switch.
I_'_['_eJ/'_qlU_rt_&_tz_#Jt_'.i TAPE SPEED Selector
Use tapes with the _mark in this unit.
T-40
SP (Standard Ptay) 40 minutes
SLP (Super Long Play) 2 hours
Tape Speed Selector Cassette type
Position T-20 "1-30
20 minutes 30 minutes
1hour 1 hour
30 minutes
* SLP may have slightlymorepicturenoise duringplayback.
i
Cassettes have a record tab to ensure that recordings are not accidentally erased.
break off the tab with a screwdriver.
(If slide type, slide tab open.)
_S/ide tab type _:1
10
To record again,
cover the hole with adhesive tape.
(If slide type, slide tab closed.)

Setting the clock is divided into four sections: Time Zone, Daylight Saving Time,
Time. and Clock Battery. Fellow instructions in the order presented.
The Palmcorder is set to Eastern time zone
from-the factory. If you live or are traveling
in a different time zone, follow the steps to
select the appropriate time zone from the
menu screen,
Before you begin...
• Connectthe Pelmcorderto apowersource.
•Setthe POWERswitch to VCRor CAMERA.
Note:
The Patmcorderwill exitthe CLOCK SET
menu if, afteractivation, noneof the CLOCK
SET UP1DOWN.(A/V) or DISPLAY buttons
a_epressedwithin30 seconds.
The PaJmcorder'sclockmay loseor gainup
totwominutesper month.Please adjust as
necessary(rsler topage 13).
DISPLAY
Press CLOCK SET UP Ato display
the CLOCK SET menu.
Press UP •or DOWN • repeatedly
to sel ectIL't =I=INmlhVJl_l'_[e]_1=1.
Time Zone chart
! i i.i. i i,..
:Pu_ D_PLAY
Press DISPLAY to display the
SELECT TIME ZONE menu,
/ 1
Press UP • or DOWN • repeatedly
to select desired time zone,
Press DISPLAY to fix the Time Zone.
The CLOCK SET menu appears.
To exit from the CLOCK SET
menu, press DOWN •to select
|, and then press DISPLAY.
iNote:
When you traveloutsidethe eighttime zones
showninthe timezone chartat the left,
pleaseset the clock manually(see page 13).
11

I_.N'_t.,_,_it_ll]_flTJ,'tiFbN_,_._m Before you begin...
The clock will automatically adjust to
daylight saving time.
- Connect the Palmcorder to a power source.
•Set the POWER switch to VCR or CAMERA,
• Note:
The Palmcorder will exit the CLOCK SET
menu if, after activation, none of the CLOCK
SET UP/DOWN, (,&IV) or DISPLAY buttons
are pressed within 30 seconds.
Daylight saving time feature will not function
it time zone is set to Hawaii or Samoa,
DISPLAY
Spring (First Sunday in April):
In DAYLIGHT SAVING T_ME: AUTO mode,
the clock is automatically moved ahead one
hour.
=1:00 e.m. 2:00 a_m.
]Normal Time ! ¢ ¢
Daylight Saving I._ _=
Time I 3:ooa,m, 4:00 a.m.
Autumn (Last Sunday in October):
In DAYLIGHT SAVING TIME: AUTO mode,
the clock is automatically turned back one
hour.
IDaylight Saving t 1:ooa.m. 2:00 a.m.
Time I "_ e:
Normal Time ] -- _
1:0o a.m. 2:00 a.m.
12
Press CLOCK SET UP Ato display
the CLOCK SET menu.
Press UP & or DOWN •repeatedly
to selectlPJIIDT_.,'tll[e]-"IIIl.."f_.ivJI_[el il_r_l=l.
8_EI,,E_'r: PUSH v/&
Press DISPLAY to display the
DAYLIGHT SAVING TIME menu.
Press UP .& or DOWN • to select
AUTO or OFF.
Press DISPLAY to fix the
DAYLIGHT SAVING TIME setting.
The CLOCK SET menu appears.
To exit from the CLOCK SET
menu, press DOWN • to select
Lqr'-J_l, and then press DISPLAY.

The date and time is calculated, including
leap year, up to DEC 31 2095.
DISPLAY
\
Before you begin...
•Connect the Palmcordertoa powersource.
• Set the POWERswitch toVCR or CAMERA,
Note:
The Palmcorder willexit the CLOCK SET
menu if, after activation,none of the CLOCK
SET UP/DOWN, (,A,IV) orDISPLAY buttons
are pressedwithin30 seconds.
Press CLOCK SET UP • to display
the CLOCK SET menu.
Press UP •or DOWN • repeatedly
to selectKJ ml=,_l=rJIh_l=l_,'l_= II _[e/o
EXAMPLE
-o-C4J3GKSET---
_l.SNAiffr _ME ZONE
2.DAYUGNT _V]NG "rIME
Press DISPLAY to display the
DATE/TIME SETTING menu.
Press UP •or DOWN •repeatedly
(or hold down) to enter the desired
numbers, then press DISPLAY to fix
that portion and move on.
";6,'-00:00"PM-_¢_ 6":00.-00PM
J,_N 119"9_6 C_JAI_I J _ 1 996
Adjust the flashing digits for the hour,
minute, month, day, and year.
"1'2_0 O: 00_A'M"_
'A'N 1 1"996 l
ELE_"3":PUSH YI,LKL:Y |
ET : PUSH D_PLAY
When you finish setting the year, the
clock starts operating, and the CLOCK
SET menu appears.
To exit from the CLOCK SET menu,
press DOWN •to select I_, and
then press DISPLAY. 13

The date and time operates on a miniature
battery preinstatled in the underside of your 1
Palmcorder. _Jr. While pinching the stopper tabs,
pull the Battery Tray out of the
•._ Battery Compartment.
Underside View
Remove the Battery by bending the
locking tab outward.
_3Place the new Battery into the Battery
tray with the _ mark facing down.
Press down until it snaps into place.
• Do not reverse the polarity.
Insert the Battery Tray until both
triangle marks meet.
_s WARNING:
lace battery with Panasonic PART NO,
WOO04 (CR2025) only. Use ol another /
ery may present a risk of fire or explosion. /
tion-battery may explode tt mistreated. /
se of used battery promptly. Keep away |
children. Do not recharge, disassemble or|
eof in fi_e. )
Note:
* Make sure your Palmcorder is off when
replacing the Battery,
•Keep the Battery out of the reach of children
as swallowing it may be harmful.
•Improperly _nstalled. discharged, or missing
battery will cause =CLOCK BATTERY" to
appear when the DISPLAY button is pressed.
• Battery life is approximately 5 years.
14

The tape remaining and battery charge level can be displayed during recording.
Battery Charge Tape
Remaining: Remaining:
FULL I
Set the POWER
switch to CAM ERA.
Press DISPLAY repeatedly
to select the desired display.
EVF Indications
Fifth _ _ First
press i,=_,= / _reSs
iLP" ' '=" _41_,
(Initial screen) IB
IXIIIIKII DIlllllll_
I_t _FULL
mt_ I L__ _t', ,.,
mint_ 1 Fourth
,€__ E_PTy press t
•It will take several seconds tor the tape
remaining indicator to operate after the
tape starts moving.
Second
press
•__ J k_"t= ,_1_ . - J
i
rPress DISPLAY
twice to change
the display to date
only. Press once
or twice more to
remove the date/
time display.
lx/D c=mm.j
Set the POWER
switch to CAMERA.
When placed in
Record mode, the
time and date will be
recorded on the
lape.
FoNote:
nly the Oate and/or Time indications are recorded on the Tape. 1
This feature allows you to remove all Electronic Viewfinder
Indications except Intelligent Titter (see page 34).
Before Inserting a tape, press DISPLAY and STOP
together for more than one second to remove the
indk:ations except time and date*.
To disptay the Electronic Viewfinder Indications again,
turn the Palmcorder Power off and then on again.
*To remove the time and date, press the DISPLAY button
repeatedly. 15

® ® ®
lY,,,,CR-MOD El
2:oo:0oAML,
AN 1 19961
OBattery Remaining Indication -_- (see page 15)
When abattery recharge is necessary, =WARNING, LOW BATTERY" wil!
appear in the EVF. The external Power Lamp will start to flash and the
Palmcorder will automatically turn OFF in 15 seconds.
_) Tape Remaining Indication
• Ifthe Paimcorder is in the camera mode, (RECORD) with no cassette tape
inserted, or the record tab is missing, =r_" will flash for one minute and
=CHECK TAPE" will appear for 5 seconds.
•As the tape reaches the end during recording, "r-_l" wilt flash and =TAPE
END" will appear for 5 seconds as awarning.
(_) 10-Second Reminder
An elapsed time indicator appears one second for every 10 seconds that
recording continues, This iSa reminder of how long you have been shooting a
particular scene and can help keep your recordings fresh and interesting.
0,_0 0:10 0:20 ..... 59i50 •The 10-Second Reminderwillreset to0:00
Iwheneveryou pressthe RECORDIPAUSE
(return to 0:00 and continue) button.
®TAPE SPEED Indication (see page 10)
Indicates the tape speed (SP or SLP).
(_) Operating Mode Indications
REC (record)
(Appears in large then small characters.)
PAUSE
(Appears in large then small characters.)
FF (fast forward)
PLAY
REW (rewind)
16

®
®
®
®MO
@
@
®
@
@
Zoom Magnification level (see page 26).
ODigital E.I.S. Indication (see page 31).
(_ Digital Zoom Indication (see page 30).
Negative/Positive Indication (see page 31 ).
_) VCR-MODE Indication
Appears for one minute if the POWER switch is set to VCR or the RECORD/PAUSE
button is pushed in VCR MODE.
@DEW indication
If excessive moisture condenses in the unit, "WARNING DEW DETECTED" will
appear, Power Lamp wiJlflash, and the Palmcorder will automatically turn OFF in 15
seconds,
Wait until the indicator no longer flashes when your Palmcorder is turned on before
use.
@Motion Security Indication (see page 32).
@Date and Time Indication (see page 13).
Backlight Indication (see page 28),
(_ Manual Focus Indication (see page 27).
Light ON/OFF Indication (see page 19).
1_ High Speed Shutter Indication (see page 26).
Fade Indication (see page 28).
Color Digital Fade Indication (see page 29).
17

Make sure the Battery Pack is not attached.
Undo the two strap ends fromtheir
buckles,
Thread the strap ends through the
Strap Attachment Rings.
min. 1 inch (25.4mm)
Reinsert the strap ends through their
buckles.
• Make sure the straps are not twisted,
Pull a loop of the strap loose
from the buckle,
Pull the strap firmly through the buckle
to shorten or lengthen the strap.
Hand Strap
Adjust the length of the Hand Strap to the
size of your hand as illustrated.
18

• : •, t"•- • Before you begin...
To improve recording indoors or outdoors in • Connect the Palmcorder to a power source.
dim lighting conditions. • Set the POWER switch to CAMERA.
Set the LIGHT switch to AUTO.
The built-in light automatically turns on and
off depending on lighting conditions.
Or set the LIGHT switch to ON/OFF to
turn the light on and off manually.
_.1_will appear in the EVF while the light is
turned on,
Caution:
This light becomes hot during operation.
Make sure nothing covers the Light during
operation.
Built-in Light Unit Bulb Housing
rDANGER:
When replacing the bulb, use only lamp bulbs
(PART NO. VLLWO007) supplied by
Panasonic to reduce the risk of fire,
Use a cloth or tissue when handling the bulb
as finger oils will decrease the bulb life.
To prevent possible burn hazard, disconnect
the Built=in Light and allow the lamp to cool
before replacing.
_41 i IIIIIIII
Before you begin...
•Set the POWER switch to OFF.
Turn screw counterclockwise and
remove.
2(_ Slide the Built-in Light unit to the
right to unlock (_ and remove it.
Turn the Bulb Housing counterclock-
wise 1/4 of a turn and pull free from
the Built-in Light unit.
Using a clean cloth or tissue, replace
the bulb.
5(_) Replace the Bulb Housing by
turning it clockwise. _) Next, insert the
Built-in Light unit and slide it to the left
to lock it in place. (_ Finally, replace
the screw.
Note:
•Using the tight reduces battery operating time.
•If using the Built-in Light in a hot environment
for an extended period of time, be sure to
provide ventilation,
•Using the Built-in Lighl when the Patmcorder is
powered by a car battery may shorten bulb life.
•Be sure LIGHT switch is set to OFF when not
in use or before placing Palmcorder into an
optional carrying case. 19

Tally Lamp
TAPE
EJECT
Before you begin...
• Connect the Palmcorder to a power source,
•Insert a cassette with record lab (see page 10).
Set the POWER switch to CAMERA.
The built-in Lens Cover opens.
EVF
Record/Pause
mode.
With the Viewfinder Eye Cup
against your eye, adjust the Vision
Adjustment Control to your eye-
sight.
Slide the TAPE SPEED Selector
to SP or SLP (refer to page 10).
WARNING:
•Do not leave the Palmcorder with the EVF
aimed directly st the sun as this may cause
damage to the internal parts of the EVF.
Press RECORD!PAUSE to start
recording.
The Tally Lamp and REC Indicator are
lit during recording.
Press the RECORD/PAUSE again to
pause the recording.
Set the Power switch to OFF after
recording is finished.
• To remove the cassette
In Record/Pausemode, slide the TAPE EJECT
switch (refer to page 10).
•When your PaJmcorder is aimed at excessively
bright objects, or bright lights, avertical bar
may appear in the picture. This is a normal
characleristic of the CCD pick-up device. Try
to avoid this when possible.
2O
