Panasonic PV-L352 User manual

Palmcorder”
Camcorder
Panasonic
Camcorder
Operating Instructions
Model No. PV- L352
E
uonelado 91seg | pales Bunioo
Please read these instructions carefully before attempting to operate this product.
Please save this manual.
Guía para rápida consulta en español está incluida.
UOIJEUIOJU] UNO, 104 TIGER, E
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
LSQT0528A

Things You Should Know
Thank you for choosing Panasonic!
You have purchased one of the most
sophisticated and reliable products on the Dealer Purchased From
market today. Used properly, it will bring
you years of enjoyment. Please take time
to fill in the information to the right. Dealer Phone No.
The serial number is on the tag located on
Model No.
the rear side of your Camcorder. Be sure
to retain this manual as your convenient Serial No.
Camcorder information source.
Date of Purchase
Dealer Address
Unpack your Camcorder
These accessories are provided in order to set up or use your Camcorder.
1 pc. AC Adaptor 1 pc. Audio/Video Cable 1 pc. Battery Pack
(PV-A19/PV-A20) with DC (LSJA0390) (pages 21, 22) (PV-BP15) (pages 9, 10)
Power Cable (page 10)
Battery Charging
Confirmation
1 pc. Shoulder Strap 1 pc. VHS PlayPak Marker
(LSFC0012)
(page
12)
(PV-P1/VYMW0009)
and
] one “AA” battery (page 21)
Use this marker as a
reminder to yourself when
the battery is fully charged
or in need of a charge.
This marker performs no
function and is for your
1 pc. Lens Cap (LSYK0817) 1 pc. CR2025 Clock reference only.
with Lens Cap Strap Battery (VSBW0004)
(LSGQ0049) (page 12) (installed in Camcorder)
(page 35)
Q~-
==
2 For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]

Things You Should Know
WARNING : TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.
Your Compact VHS Camcorder is designed to record and play back in Standard Play (SP)
and Super Long Play (SLP) modes. You can also play a Compact VHS Camcorder
recording on your VHS VCR using the supplied VHS PlayPak.
This Camcorder is equipped with the HQ System to provide excellent video pictures, and
is compatible with standard VHS equipment.
It is recommended that only cassette tapes that have been tested and inspected for use in
VCR machines with the and/or [VHS] mark be used.
This symbol warns the user that
uninsulated voltage within the unit may
La have sufficient magnitude to cause
Pee oe NOTOPEN electric shock. Therefore, it is
dangerous to make any kind of contact
with any inside part of this unit.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, This symbol alerts the user that
DO NOT REMOVE COVER (OR BACK) important literature concerning the
NO USER-SERVICEABLE PARTS INSIDE operation and maintenance of this unit
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL has been included. Therefore, it should
be read carefully in order to avoid any
problems.
The above markings are located on the appliance's bottom cover.
FCC Warning: Any unauthorized changes or modifications to this equipment would
void the user's authority to operate.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with Part 15 and part 18 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when
operated in a residential environment.
If this equipment does cause interference to radio or television reception, which can be determined by
turning the equipment off and on, use the equipment in another location and/or utilize an electrical
outlet different from that used by the receiver.
If necessary, consult the dealer or an experienced radio/TV technician for help. You may find the
booklet, ‘Something About Interference’ available from FCC local regional offices helpful.
This product may cause interference to radio equipment and should not be installed near maritime
safety communications equipment or other critical navigation or communication equipment operating
between 0.45-30 MHz.
Doug umas

Important Safeguards
10.
Read Instructions — All the safety and
operating instructions should be read before
the unit is operated.
Retain Instructions — The safety and
operating instructions should be retained for
future reference.
Heed Warnings — All warnings on the unit
and in the operating instructions should be
adhered to.
Follow Instructions — All operating and
maintenance instructions should be followed.
Cleaning — Unplug this video unit from the
wall outlet before cleaning. Do not use liquid
or aerosol cleaners. Use a dry cloth for
cleaning.
Attachments — Do not use attachments not
recommended by the video product
manufacturer as they may be hazardous.
Water and Moisture — Do not use this video
unit near water — for example near a bath tub,
wash bowl, kitchen sink, or laundry tub, ina
wet basement, or near a swimming pool, and
the like.
Accessories — Do not place this video unit
on an unstable cart, stand, tripod, bracket, or
table. The video unit may fall, causing serious
injury to a child or adult, and serious damage
to the unit. Use only with a cart, stand, tripod,
bracket, or table recommended by the
manufacturer, or sold with the video unit. Any
mounting of the unit should follow the
manufacturer’s instructions and should use a
mounting accessory recommended by the
manufacturer. An appliance and cart
combination should be moved
with care. Quick stops,
excessive force, and uneven A
surfaces may cause the
appliance and cart combination IN
to overturn. A
Ventilation — Slots and openings in the
cabinet are provided for ventilation and to
ensure reliable operation of the video unit
and to protect it from overheating. These
openings must not be blocked or covered.
Never place the video unit on a bed, sofa,
rug, or other similar surface, or near or over a
radiator or heat register. This video unit
should not be placed in a built-in installation
such as a bookcase or rack unless proper
ventilation is provided or the manufacturer's
instructions have been adhered to.
Power Sources — This video unit should be
operated only from the type of power source
indicated on the marking label. If you are not
sure of the type of power supply to your
home, consult your appliance dealer or local
power company. For video units intended to
be operated from battery power, or other
sources, refer to the operating instructions.
Së
11
12.
13.
NEC NATIONAL ELECTRICAL CODE
14.
. Grounding or Polarization — This video unit
may be equipped with either a polarized
2-wire AC (Alternating Current) line plug (a
plug having one blade wider than the other)
or 3-wire grounding type plug, a plug having a
third (grounding) pin.
The 2-wire polarized plug will fit into the
power outlet only one way. This is a safety
feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If
the plug still fails to fit, contact your electrician
to replace your obsolete outlet.
Do not defeat the safety purpose of the
polarized plug.
The 3-wire grounding type plug will fit into a
grounding type power outlet. This is a safety
feature. If you are unable to insert the plug
into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat
the safety purpose of the grounding type plug.
Power-Cord Protection — Power-supply
cords should be routed so that they are not
likely to be walked on or pinched by items
placed upon or against them. Paying
particular attention to cords of plugs,
convenience receptacles, and the point where
they exit from the unit.
Outdoor Antenna Grounding -— If an outside
antenna or cable system is connected to the
video unit, be sure the antenna or cable
system is grounded so as to provide some
protection against voltage surges and built-up
static charges. Part 1 of the Canadian
Electrical Code, in USA Section 810 of the
National Electrical Code, provides information
with respect to proper grounding of the mast
and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size
of grounding conductors, location of antenna
discharge unit, connection to grounding
electrodes, and requirements for the
grounding electrode.
DI ISCHAF RGE UNIT
(NEC SECTION 810-20)
ELECTRIC
~ GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
Lightning — For added protection of this
video unit receiver during a lightning storm, or
when it is left unattended and unused for long
periods of time, unplug it from the wall outlet
and disconnect the antenna or cable system.
This will prevent damage to the video unit due
to lightning and power-line surges.
For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]

Important Safeguards
15. Power Lines — An outside antenna system b. If any liquid has been spilled into, or
should not be located in the vicinity of overhead objects have fallen onto, the video unit.
power lines or other electric light or power c. If the video unit has been exposed to rain
circuits, or where it can fall into such power or water.
lines or circuits. When installing an outside d. If the video unit does not operate normally
antenna system, extreme care should be taken by following the operating instructions.
to keep from touching such power lines or Adjust only those controls that are covered
circuits as contact with them might be fatal. by the operating instructions, as an improper
16. Overloading — Do not overload wall outlets adjustment of other controls may result in
and extension cords as this can result in a damage and will often require extensive
risk of fire or electric shock. work by a qualified technician to restore the
17. Objects and Liquids — Never push objects video unit to its normal operation.
of any kind into this video unit through e. If the video unit has been dropped or the
openings as they may touch dangerous cabinet has been damaged.
voltage points or short out parts that could f. When the video unit exhibits a distinct
result in a fire or electric shock. Never spill change in performance — this indicates a
liquid of any kind onto the video unit. need for service.
18. Servicing — Do not attempt to service this 20. Replacement Parts — When replacement
video unit yourself as opening or removing parts are required, be sure the service
covers may expose you to dangerous voltage technician has used replacement parts
or other hazards. Refer all servicing to specified by the manufacturer or have the
qualified service personnel. same characteristics as the original part.
19. Damage Requiring Service — Unplug this Unauthorized substitutions may result in fire,
video unit from the wall outlet and refer electric shock or other hazards.
servicing to qualified service personnel under 24, Safety Check — Upon completion of any
the following conditions: . service or repairs to this video unit, ask the
a. When the power-supply cord or plug is service technician to perform safety checks
damaged. to determine that the video unit is in safe
operating order.
Precautions
USE & LOCATION
e TO AVOID SHOCK HAZARD ... Your Camcorder and power supply should not be exposed to rain or moisture.
Do not connect the power supply or operate your Camcorder if it gets wet. Your Camcorder has been designed for
outdoor use, however it is not designed to sustain direct exposure to water, rain, sleet, snow, sand, dust, or a direct
splashing from a pool or even a cup of coffee. This action could permanently damage the internal parts of your
Camcorder. Do not attempt to disassemble this unit. There are no user serviceable parts inside. Unplug your
Camcorder from the power supply before cleaning.
e DO NOT AIM YOUR CAMCORDER AT THE SUN OR OTHER BRIGHT OBJECTS.
e DO NOT LEAVE THE CAMCORDER WITH THE EVF AIMED DIRECTLY AT THE SUN AS THIS MAY CAUSE
DAMAGE TO THE INTERNAL PARTS OF THE EVF.
e DO NOT EXPOSE YOUR CAMCORDER TO EXTENDED HIGH TEMPERATURE ... Such as, in direct sunlight,
inside a closed car, next to a heater, etc... This action could permanently damage the internal parts of your
Camcorder.
+ AVOID SUDDEN CHANGES IN TEMPERATURE ... If the unit is suddenly moved from a cold place to a warm
place, moisture may form on the tape and inside the unit.
e DO NOT LEAVE YOUR CAMCORDER OR THE POWER SUPPLY TURNED ON WHEN NOT IN USE.
e STORAGE OF YOUR CAMCORDER ... Store and handle your Camcorder in a manner that will not subject it to
unnecessary movement (avoid shaking and striking). Your Camcorder contains a sensitive pick-up device which
could be damaged by improper handling or storage.
CARE
e TO CLEAN YOUR CAMCORDER ... Do not use strong or abrasive detergents when cleaning your Camcorder
body.
e TO PROTECT THE LENS... Do not touch the surface of the lens with your hand. Use a commercial camcorder
lens solution and lens paper when cleaning the lens. Improper cleaning can scratch the lens coating.
e TO PROTECT THE FINISH OF YOUR CAMCORDER ... Before handling your Camcorder, make sure your hands
and face are free from any chemical products, such as suntan lotion, as it may damage the finish.
Doug Buniaso

Table of Contents
O Things d EN (Te Ré e EE 2-3
a Important SafeguardS mmmcoconacacanananacannnninananananananananenanenananenaa nenes 4-5
+ A NA 5
5 Am o 55. e 7
ote Quick Operation Guide mmm 8
Supplying Power (Battery Charge/Use/Refresh/Care, AC Adaptor, Car Battery Cord) .... 9-10
A] Cassette Information EE 11
"AR Before Using (Remove the Sensor tag, Using the Shoulder and Hand Straps, Lens Cap) .... 12
eh TA 13
RB Setting the Clock (Time Zone, Auto Daylight Saving Time) .ssssssssssssssssssessssersrseseesees 14~15
Gel Built-in Auto Light (Using the Light, Replacing the Bulb) .ssssssssssssssssssssssssssssutecsseesateesees 16
Au Camera Recording (Basic, Stand-by, Programmed Recording) s..sssssssssssssssessesssneen 17~19
ch Playing Back Recordings
o (Basic Playback, Visual Search, Still Picture, Tracking, TV/VCR Playback) eessen 20-21
O Copying your Tapes (dubbing) .ccommmcccccnnnnncononcnnnnnnnnnnncnccnnnnnnnnanannncnrrrrnnnnnaaaas 22
Lo)
D
=
Di
=
O
=
dr Four-Speed Power ZOOM ........ssssssssnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnn nnmnnn 23
CO ¡Back 24
d FOCUS (Auto Mandal FOCUS) EE 25
D High Speed Shutter (Auto/Manual Shutter) sssssssunnsunenunnnnnnunnnnnnnunnnnunnnnnnunnnnnnnnnnnnnnnnnn nnna 26
— AUO Fe ACG aaa O A E 27
TD Color Digital Fade cui iii 28
S Digal LOON BEE 29
2 Digital Electronic Image Stabilization (E.1.S.) ...ooocccccnnnnnnncnccnonannnnncnnnannnnnnnnos 30
T MOHONSCOSOL ai aiaa aaraa aa 31
0
LN Viewfinder/LCD Monitor Indications ..........ooccooccccoccccnnncconncconannonancnnnnnnnnns 32-33
SA Operation Notes (Cleaning EVF) enen 34
< NOU CO aii 34
e% Replacing Clock Battery inicia 35
CH Palmcorder Accessory System ENEE 36
=a Palmcorder Accessory Order FOrim .......ssssssssnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnn nnn 37
ci, E secta 38
‘eM Before Requesting Service (Video Head Cleaning) .sssssssnnnunnnnnnnnnnnnnnnnnnnnnnnnnnnnnnn nnn 39
3 Request for Service Notice ........:::sssssssssssesssseesscesssseessseeesscesssneessseessecesssneess 40
y Limited Warranty .......cecsssssessesssssnnensesesesenensesenenesesesenenseseseneeeneesenenenananees 41
Ser vicente CC ada 42
eM Spanish Quick Use Guide/Guía Para Uso Rapido...............cccccccssseeeeseeeeeeeees 43
SA O EA EEA EAT AE E AO 44
6 For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]

Self Demo Mode
Self Demo mode is on when the screen Before you begin...
below appears. To turn it off, follow - Connect Camcorder to power source.
steps 1-4 below.
EVF or LCD Monitor
Panasonic
ITS TAPES CAN PLAY
IN YOUR VCR
YES, IT’S VHS!
20x LENS / 700x D.ZOOM
DIGITAL STABILIZATION
FULL-SIZE HEAD SYSTEM
Doug Buniaso
1 Set POWER to CAMERA.
2 Press MENU for a l eege
MENU mode. VIDEO EFFECTS : FADE,
Press UP or DOWN
to select S SELECT: PUSH UP/DOWN KEY
SET : PUSH DISPLAY KEY
END : PUSH MENU KEY
3 Press DISPLAY to select OFF.
4 Press MENU to exit.
Note:
e Self Demo stops automatically if battery
is attached (page 9) and cassette tape is
inserted (page 11).
e Inserting a tape alone (or attaching a
partially charged battery) only temporarily
stops Self Demo.
e Self Demo stops for 30 seconds when the
Light is pressed.
To turn Self Demo back on:
e Set to SELF DEMO : ON in MENU screen.

Quick Operation Guide
Charge Battery Pack fully before 1 Attach fully
operation (page 9). dE Battery
> 1 Plug in AC Slide TAPE
Adaptor. EJECT to open
door.
Insert cassette
(page 11).
2 Press here to
Insert
Battery.
CHARGE
Lamp
Protection
Film
close
door.
flashes, then stays lit when Note:
charging is complete. e Remove the Protection Film before use.
Camera Recording
See page 17.
1 Press LCD-OPEN to unlock the LCD monitor.
Swing it fully open and adjust the angle.
2 Set POWER to CAMERA.
3 Press RECORD/PAUSE
to start recording.
Press RECORD/PAUSE
again to pause recording.
See page 20.
1 Press LCD-OPEN to unlock the LCD monitor.
Swing it fully open and adjust the angle (see above).
3 Press REWIND/SEARCH
to rewind tape.
2 Set POWER
to VCR.
4 Press PLAY to start
playback.
5 Press STOP to stop
playback.
8 For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]

Supplying Power
Charging the Battery Pack 1 eee ©
Charge Battery Pack fully before use. POWER Lamp lights: CG
) 3 Insert Battery. =
| Q Align left side of Battery with left edge of Ka
de E AC Adaptor. dn
e © Press Battery down and slide in direction E
of arrow. D
The CHARGE Lamp flashes, then stays lit D
when charging is complete. o
3 Remove Battery.
ay,
Slide Battery to the left and lift off.
Note:
e Charging takes about 1 hour.
e While the DC Power Cable (supplied) is connected
to the AC Adaptor, the Battery cannot be charged.
e After charging 5 times, use Battery Refresh feature
as explained below.
ll e Battery life gradually decreases after repeated use
- and recharging. If operation time becomes very
(Top View) short even after a sufficient charge, discard Battery
properly (page 10).
Using the Battery Pack
A fully charged Battery provides a maximum of about 1 hour 10 minutes of continuous use
(LCD monitor off) or about 55 minutes (LCD monitor on). Actual time may vary due to
operating conditions. Using the Built-in Light decreases operating time.
CHARGE
Lamp
A Attach Battery.
6) Insert top of Battery into top of mounting
surface.
© Press and snap into place.
BATTERY
Lë
PACK SA Ip B
a NE Remove Battery.
Slide BATTERY RELEASE and remove
Battery.
To use battery refresh, insert Battery on AC
Battery Refresh Adaptor (see steps 1-2 above), then press
This feature completely discharges BATTERY REFRESH.
Battery before recharging begins. The REFRESH Lamp lights, then goes out when
Use after every 5 charges for optimum discharge is complete. Battery charging will then
Battery performance. start automatically.
If BATTERY REFRESH is pressed by mistake,
REFRESH | remove Battery from AC Adaptor and reinsert it
Lamp for normal charging.
Note:
e Charging takes about 5 hours when Battery
Refresh is used.
BATTERY e Battery will not operate in extremely high
REFRESH
temperatures.

Supplying Power
Battery Care
Caution: To avoid Battery damage:
e Charge only with specified charger. e Do not drop or jar Battery.
e Battery can be charged within a temperature range of e Use Battery with specified units only.
10 °C (50 °F) and 35 °C (95 °F). e If Battery is used in extremely high
e Battery is normally warm after charging or just after use. temperatures, a safety device will
e Do not use an insufficiently charged or worn-out Battery. automatically prevent operation.
Safety precautions: To prolong Battery life:
e Do not get Battery near, or dispose of in, fire. e While not in use, remove Battery from
e Do not directly connect (short circuit) the positive (+) the Camcorder and AC Adaptor, and
and negative (—) terminals. store in a cool, dark, dry place.
e Never attempt to disassemble or reassemble Battery. e Keep Battery terminals clean.
AC Adaptor
DC Power Cable
Camcorder DC IN with supplied DC
Sat 1 Connect AC Adaptor DC OUT to
J Power Cable.
Plug in AC Adaptor.
POWER Lamp lights.
Note:
e While the DC Power Cable (supplied) is
Connector connected to the AC Adaptor, the Battery
cannot be charged.
ES e When not in use, unplug AC Adaptor from
DC OUT AC outlet. (Adaptor uses 1.2 W of electricity
Connector
while
plugged
in.)
CAUTION:
This unit will operate on 110/120/220/240 V AC 50/60 Hz. An AC plug adaptor may be required
for voltages other than 120 V AC. Please contact either a local or foreign electrical parts
distributor for assistance in selecting an alternate AC plug. We recommend using the accessory
power plug adaptor (VJSS0070) in an area which has special AC outlets.
Car Battery Cord (Optional) 1 Connect PV-C16 Car Battery Cord
(optional) to Camcorder DC IN.
(A) Start engine first.
Plug Car Battery Cord into
Cigarette lighter socket.
Cigarette e If Car Battery cord fuse needs replacing,
Lighter use exact current rating (in amps).
Socket (12 V) Note:
e This cord only works in vehicles equipped
with DC 12 V (negative ground) battery.
Check with your car/truck dealer. Use only
specified car battery cord.
e To avoid blowing the car battery cord fuse,
do step 2 in the proper order.
e Running vehicles must be well ventilated.
Car Battery Cord Cigarette e When not in use, disconnect cigarette
(optional) Lighter Plug lighter plug. l
e For personal safety the driver of the vehicle
should not attempt to operate the
camcorder while driving.
1 0 For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]

Cassette Information
Cassette Insertion/Removal
1 Turn Tape Wheel in direction of arrow
until there is no slack.
2 Attach Battery (page 9).
Doug Buniaso
3 Slide TAPE EJECT to open door.
4 Insert cassette as shown.
5 Press here to close door.
e To remove the cassette, slide the TAPE
EJECT switch.
Record/Playback Time
Use tapes with the NHS mark in this unit.
Tape Speed Cassette type
Selector Position | TC-20 TC-30 TC-40
SP
l
(Standard
Play)
20
minutes
|
30
minutes
|
40
minutes
SLP
1
hour
(Super
Long
Play)
|
'
hour
`
Lan
minutes
|
2
Nours
e SLP playback may contain more picture noise.
Erase Protection Tab
Protects tapes from being accidentally
erased. 1 To prevent accidental erasing,
break off tab with screwdriver.
K (Or, slide tab open.)
la To record again,
cover hole with adhesive tape.
Slide tab type (Or, slide tab closed.)
11

Before Using
How to remove the Sensor tag
Hand Strap
Open the Hand Strap as illustrated
at left.
O Remove the Sensor tag.
Then, replace the Hand Strap.
Sensor tag
Adjust the Length of the
Remove Battery Pack before completing Shoulder Strap
the following steps:
Attaching Shoulder Strap
1 Undo strap ends
from buckles.
Thread strap ends through Strap
Pull a loop of strap from buckle, then pull
Rings
on
Camcorder.
p p
p
strap tight to shorten or lengthen.
Hand Strap
3 Re-insert the strap © t2 D
ends into buckles. E f) geg
di
EE DICTA
Lem,
Adjust Hand Strap length to fit your hand as
min. 25.4 mm (1 inch) shown.
Attaching the Lens Cap
Strap:
4 Thread the Strap through 7
Y the Lens Cap attachment
ring as illustrated at left.
Attaching the Lens Cap Cord to the Hand Strap: d
Remove the Hand Strap from the front clasp and thread Sa, fa
the Strap through the loop in the Lens Cap Cord.
Reattach the Hand Strap.
1 2 For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]

Using MENU Mode
Before you begin...
e Connect Camcorder to power source.
e Set POWER to CAMERA or VCR.
1 Press MENU for MENU mode.
The CAMERA or VCR MENU screen (see below
left) appears when Menu mode is entered.
Press UP or DOWN to highlight the
desired menu item.
Q)
D
=
5
@
dÄ
=
y
ech
D
o.
Press DISPLAY to set selection.
MENU
4 Press MENU to exit.
Note:
e The Menu mode is canceled if UP/DOWN,
1 2 3 4 DISPLAY, or MENU are not pressed within
Ee E 5 minutes when Self Demo mode is off.
e The Menu mode is canceled if UP/DOWN,
DISPLAY, or MENU are not pressed within
30 seconds when Self Demo mode is on.
MENU
Mode
(CAMERA)
Screen
1
PROGRAMMED
REC
(page
19).
_--
MENU
---
PAGE
1/2
Camcorder
starts
and
stops
recording
at
a
PROGRAMMED REC preset time.
SHUTTER ` ` AUTO 2
STAND-BY RELEASE ; OFF DISPLAY (page 32).
CLOCK SET ON : On-screen Display (OSD) screens are
LIGHT MODE ; OFF/ON displayed
OO Om P GO =
y
SET; PUSH DISPLAY KEY 3 SHUTTER (page 26).
:
PUSH
MENU
KEY
Select
desired
shutter
speed.
l 4 STAND-BY RELEASE (page 18).
a ONSENSOS l = ON : Enables quick resumption of recording
EE from Stand-by mode.
5 CLOCK SET (pages 14, 15).
Select to set clock.
LIGHT MODE (page 16).
ON/OFF : Light can be set ON or OFF.
ON/OFF/AUTO : Light can be set ON, OFF, or AUTO.
SELF DEMO (page 7).
ON : SELF DEMO screen is displayed.
8 MOTIONSENSOR (page 31).
ON : Enables MotionSensor recording.
9 VIDEO EFFECTS (pages 27-28).
SELECT: PUSH UP/DOWN KEY AUTO FADE :BLACK or WHITE
PUSH MENU KEY DIGITAL FADE :TYPE — 7 types
COLOR — 8 colors
© 0 N
SELECT: PUSH UP/DOWN KEY
SET : PUSH DISPLAY KEY
END : PUSH MENU KEY 6
13

Setting the Clock
Set the following items in order: Time
Zone, Daylight Saving Time, Date,
and Time.
FOGUS
V NEAR
DOWN
MENU
DISPLAY
1,2,3,4
1 4 For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
Before you begin...
e Connect Camcorder to power source.
e Set POWER to CAMERA or VCR.
1 Press MENU for MENU mode.
Press UP or DOWN to select ¿
-- MENU --- PAGE 1/2 --- MENU ---
PROGRAMMED REC
DISPLAY ; ON
SHUTTER ; AUTO DISPLAY ; ON
STAND-BY RELEASE ; OFF
LOCK SET
LIGHT MODE ; OFF/ON
v
SELECT: PUSH UP/DOWN KEY SELECT: PUSH UP/DOWN KEY
SET : PUSH DISPLAY KEY SET : PUSH DISPLAY KEY
END : PUSH MENU KEY END : PUSH MENU KEY
[CAMERA MODE] [VCR MODE]
2
Press
DISPLAY
for
---
CLOCK
SET ---
CLOCK
SET
menu.
NA
;
EASTERN
Press
UP
or
DOWN
to
DATE/TIME
;
12
200)
00AM
select
TIME
ZONE,
DST,
SELECT:
PUSH
UP/DOWN
KEY
or
DATE/TIME. END
|
PUSH
MENU
KEY
3 Press DISPLAY for menu of item selected in
step 2.
To change the setting:
3 Go to step 3a on page 15.
3 Go to step 3b on page 15.
3 Go to step 3c on page 15.
4 Press MENU twice to exit.

Setting the Clock
3a Setting the Time Zone
---SELECT TIME ZONE ---
The Camcorder is preset to Eastern time. press Ur OF DOMINIO
Q)
=
select local time zone. ALASKA =
E cone cht | Press DISPLAY to Lë, ZS | E
A S confirm entry. E
SELECT: PUSH UP/DOWN KEY dn
SET : PUSH DISPLAY KEY ke
e When traveling, repeat this operation and ©
select one of the 8 listed time zones to o
set the clock to local time. O.
Note :
e Clock may lose or gain up to 2 minutes
per month.
e When traveling outside the listed time
zones, set clock to local time manually.
e To adjust or set clock, see “Setting Date
and Time” bottom of page.
: 8:00 : 9:00 :10:00:11:00:12:00: 1:00 32:00
3b Auto Daylight Saving Time
Clock will auto-adjust to daylight saving time (DST).
DST: AUTO
Spring (First Sunday in April) :
ahead one hour.
1:00AM 2:00AM
o
Daylight Saving A SÉ
Time 3:00AM 4:00AM
Autumn (Last Sunday in October) :
back one hour.
Daylight
Saving
1:00AM
2:00AM
Time
:
Normal Time
The Camcorder is preset to DST: 2.
If DST is not observed in your area, set
Press UP or DOWN to - - DAYLIGHT SAVING TIME - -
select OFF or AUTO. AUTO
Press DISPLAY to OFF
confirm entry.
SELECT: PUSH UP/DOWN KEY
SET : PUSH DISPLAY KEY
Note:
e Auto DST does not function if time zone
is set to Hawaii or Samoa (see “Setting
the Time Zone” above).
>
1:00AM 2:00AM
3C
Setting
Date
and
Time
EE
xi) \ lov
Date and time including leap year are AN | ODO
calculated up to DEC 31, 2099.
EXAMPLE :
SELECT: PUSH UP/DOWN KEY
SET : PUSH DISPLAY KEY
DISPLAY
Press or hold down UP or
DOWN to select hour, then
press DISPLAY to fix.
Repeat for minute, month, day,
and year.
Clock starts when year is
SELECT: PUSH UP/DOWN KEY | | SELECT: PUSH UP/DOWN KEY| | SELECT: PUSH UP/DOWN KEY entered and DISPLAY is
SET : PUSH DISPLAY KEY] (SET : PUSH DISPLAY KEY] |SET : PUSH DISPLAY KEY presse d oe rs
- - - DATE/TIME SETTING - - - - -- DATE/TIME SETTING - - -
Nee N
l + at xo TI xl,
2-00:08AM-| | 1200:08PM-| | 1-00:00PM
1 +0 0+ de
JAN 1 Z0D2 JAN 1 7602 JAK! Y 2002
15

Built-in Auto Light
Using
the
Light
Before
you
begin...
e Connect Camcorder to power source.
For recording in dim lighting. , Set POWER to CAMERA.
-- MENU --- PAGE 1/2
1 E
Press MENU for ` SE mn or
MENU mode. Press |cLock ser |
A e a mail
select |. ser:
e : PUSH DISPLAY KEY
END : PUSH MENU KEY
Press DISPLAY to set OFF/ON or
OFF/ON/AUTO. Press MENU to exit.
Press LIGHT repeatedly for Light ON,
12316") g
CAUTION:
OFF, or AUTO.
oe
poate
de
a
e
In
AUTO,
light
turns
itself
on/off
|
ever
cover
Light
while
R
according
to
lighting
conditions.
Note:
`
DER?
EVF
or
LCD
Monitor
e
Using
Light
reduces
battery
operating
time.
e Provide proper ventilation when using
Light extensively in a hot environment.
e Using Light when the Camcorder is
powered by a car battery may shorten
bulb life. 12:00:00AM
e Set Light to OFF when not in use. a
i Before you begin...
Replacing the Bulb e Order Part No. VLLW0015 for replacement
bulb.
e Set POWER to OFF.
=D : Light is on.
A =D : Light mode is auto.
1 Slightly raise portion @ of lens cover
to unhook, and slide portion
forward to remove.
2 Using Tweezers or needle-nose pliers,
carefully remove bulb.
e Take unit to service center if you need
assistance.
3 Replace bulb using a clean cloth or
tissue. (Do not touch with fingers.)
4 Replace lens cover.
Note:
e Handle bulb gently. Excessive force may
cause bulb to crack.
DANGER:
Use only replacement bulb (PART NO. VLLW0015) supplied by Panasonic to reduce risk
of fire.
Handle new bulb with cloth or tissue as skin oils will decrease bulb life.
Remove lens cover and allow bulb to cool before replacing to avoid possible burn hazard.
1 6 For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]

Camera Recording
Recording via EVF or LCD Before you begin...
Wifovalive)a
e
Connect
Camcorder
to
power
source.
e Insert cassette with record tab (page 11).
View recording scene on EVF (Electronic
Viewer Finder) or LCD (Liquid Crystal
Display) monitor.
1 Press LCD-OPEN to unlock the LCD
monitor. Swing LCD monitor fully open
and adjust viewing angle.
e If you want to record using EVF, close
and lock LCD monitor.
PAUSE
Set POWER to
3 CAMERA.
BRIGHT VISION e Be sure POWER
ADJUSTMENT ADJUSTMENT is fully turned to
1 EVF or LCD Monitor
CAMERA position. (Record/Pause mode)
baaa open LCD o nO
monitor may block cassette door turns on/off by the POWER switch.
and damage Camcorder body. e Both EVF and LCD monitor turn on
ff when LCD is at 180° (see above left).
C
AA
D
CH
O
O
ES
©
wm, /
9)
=.
O
5
This allows both you and the subject to
view the recording.
3 LCD: Press BRIGHT |17 "=" véi
ADJUSTMENT
A
Built-in
to
adjust
LCD
E
Microphone
monitor
eo
al
brightness level.
EVF : Look into EVF and adjust
VISION ADJUSTMENT to your
eyesight.
4 Hold down TAPE SPEED for about 1
second to change tape speed to SP/SLP
(page 11).
Tape speed
5 Press RECORD/ sP
Note: PAUSE to start or RECORD
e When Camcorder is aimed at excessively pause recording.
bright objects, or bright lights, a vertical 6
bar may appear in the picture. This is Set POWER to EVF or LCD Monitor
normal for the CCD pick-up. Try to avoid SES
this when possible. al OFF when finished.
e Using LCD monitor reduces battery
operation time. Return LCD monitor to « To remove the cassette, slide the
locked position when not in use. TAPE EJECT switch (page 11).
(Record mode)
17

Camera Recording
Before you begin...
Stand-by Quick Release
e Connect Camcorder to power source.
- Insert cassette with record tab (page 11). If left in RECORD/PAUSE mode for 5
minutes, Camcorder switches to Stand-by
mode to conserve battery. When set to ON,
Stand-by Quick Release lets you resume
recording by pressing RECORD/PAUSE two
times. Stand-by Quick Release is set to OFF
[SEDO bee FAR at the factory.
¡En 1 Set POWER to aoe
O CAMERA. DISPLAY ON
; OFF
CLOCK SET
2 LIGHT MODE ; OFF/ON
Press MENU for SELECT: PUSH UP/DOWN KEY
MENU mode. o PUSI e
Press UP or DOWN
3 Press DISPLAY to select ON/OFF.
ON : From Stand-by mode, press
RECORD/PAUSE two times to
resume recording.
OFF : From Stand-by mode, set
POWER to OFF, then to
CAMERA. Press RECORD/
PAUSE to record.
4 Press MENU to exit.
Manual Easy Editing Easy Edit Stand-by
For proper continuity when taping from For a smooth transition between scenes if
Stop mode or after attaching a new recording is stopped, and then started within
Battery. 24 hours.
A Set POWER to VCR. a Press RECORD/PAUSE to stop
B A recording.
€) Press REWIND/SEARCH to rewind Set POWER to OFF and leave cassette
a few seconds of tape.
@® Press PLAY to review recording.
in Camcorder.
@Press STILL where you want to C To resume recording, set POWER to
continue recording. CAMERA.
G Press RECORD/PAUSE to resume
Set POWER to CAMERA. recording.
D Press RECORD/PAUSE to resume Mote:
e Use Manual Easy Edit (left) if more than 24
recording. AA
g hours before recording is resumed.
1 8 For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]

Camera Recording
a Before you begin...
e Connect Camcorder to power source.
Set a recording start and stop time. Or, Use AC Adaptor for longer recordings.
set a 5 or 10 second interval recording e Insert cassette with record tab (page 11).
to be done each minute. e Set POWER to CAMERA.
1 2 3 1 --- MENU --- PAGE 1/2
, am, Press MENU for MENU [Recre
mode. Press UP or STAND-BY RELEASE. OFF
CLOCK SET
DOWN to select LIGHT MODE ; OFF/ON
JE SELECT: PUSH UP/DOWN KEY
SET : PUSH DISPLAY KEY
END : PUSH MENU KEY
2 Press DISPLAY.
(Current time is : 10: 20PM
displayed ) REC TIME ; 10MIN.
Each additional press ser": Push Ad KEY
of DISPLAY increases | CANCEL: PUSH MENU KEY
start
time
by
30
minutes.
10:20:00PM
WN to select
AA
D
CH
O
O
ES
O
wm, /
9)
=.
O
5
START ; 10:20PM
A LIB TOMI.
Press DISPLAY SELECT: PUSH UP/DOWN KEY
SET : PUSH DISPLAY KEY
repeatedly to select one | start ` PUSH RECORD KEY
3 CANCEL: PUSH MENU KEY
of the options shown at EEN
left.
To cancel the setup, press MENU twice.
4 Press RECORD/PAUSE STAND-BY
to place Camcorder in REC TIME | 10MIN.
stand-by mode.
REC TIME :
10MIN. —> 20MIN. —> 30MIN.
[inna « INTERVAL"! | TO TAPE |
10SEC/MIN. 5SEC/MIN. END
10:20:00PM
JUN 1 2002
Recording will be done as scheduled.
*1 Record 5 seconds each minute.
E i
2 Record 10 seconds each minute. Note:
e Start time may not be set over 24 hours from
current time.
e Camcorder shuts off at tape end, or 12 hours
after Interval Recording starts.
e To cancel, set POWER to OFF.
19

Playing Back Recordings
Before you begin...
e Connect Camcorder to power source.
Dia
che
V bow
pispray MENU
Auto Tracking
Continuously analyzes each recording for
optimum picture quality.
Manual Tracking
some recordings require manual
adjustment to reduce noise.
Press UP or DOWN until Playback picture
clears up.
Press DISPLAY to return to Auto Tracking.
20 For assistance, please call : 1-800-211-PANA(7262) or send e-mail to : [email protected]
Playback on EVF or LCD Monitor
1 Press LCD-OPEN and swing LCD
monitor fully open.
e If you want to playback on EVF, close
and lock LCD monitor.
2 Set POWER to VCR.
e If tape has no record tab, auto
playback begins.
e EVF or LCD monitor turns on/off by
the POWER switch.
3 Playback function buttons.
@)REW ` :Rewind tape.
(PLAY ` :Play tape.
@STOP :Stop tape.
(2) BRIGHT : Adjust LCD monitor brightness.
(3 VOLUME: During playback, adjust
volume of speaker.
Press “T” "Volume
up (+).
Press “W” : Volume
down
(-).
VOLUME
[-]1111====
[+]
Note:
e Using LCD monitor reduces battery
operation time. Return LCD monitor to
locked position when not in use.
Special Effects
Search Speed
e SP (Standard Play) :3 times normal.
e SLP (Super Long Play) : 9 times normal.
During playback, press:
e FF : fast forward search
e REV ` rewind search
Press again or press PLAY for normal play.
Press STILL to freeze picture.
Press again for normal play.
This feature works best in SLP mode (page 11).
Note:
e During search, horizontal noise bars will appear.
Audio is muted.
e To protect video heads and tape, operating
modes will revert as follows after 5 minutes:
Still — Stand-by
Stand-by—» Power off (when Battery Pack is
used).
e Tape auto-rewinds if played or fast forwarded to end.
