Panasonic CQ-C1325N User manual

General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Tone Controls Bass ; ±12dB at 100Hz
Treble ; ±12dB at 10kHz
Current Consumption Less than 2.2A (CD play mode,
0.5W×4ch)
Maximum Power Output 50W×4ch (at 1kHz, Vol. Max.)
Suitable Speaker Impedance 4-8Ω
Pre-Amp Output Voltage 2.5V (CD play mode; 1kHz, 0dB)
Output Impedance 200Ω
FM Stereo Radio
Frequency Range 87.5 - 108MHz
Usable Sensitivity 11.0dBf (1.25µV, 75Ω)
AM Radio
Frequency Range 531 - 1,602kHz
LW Radio
Frequency Range 153 - 279kHz
© 2006 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
CQ-C1405N
Removable Front Panel CD Player /
Receiver
Usable Sensitivity 28dB/µV (25µV, S/N 20dB)
RDS
RDS Senstivity 22dB/µV
CD Player
Sampling Frequency 8 times oversampling
Pick-Up Type Astigma 3-beam
Light Source Semiconductor Laser
Wavelength 780nm
Frequency Response 20Hz to 20,000Hz (±1dB)
Signal to Noise Ratio 96dB
Dimensions** 178×50×155mm
Weight** 1.4kg
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
AUTOMOTIVE AFTERMARKET
Specifications*
Order No. ACED061206C8

1 ABOUT LEAD FREE SOLDER (PbF) 2
2 FEATUERS 2
3 LASER PRODUCTS 2
4 REPLACEING THE FUSE 2
5 MAINTENANCE 3
6 NOTES 3
7 DIMENSIONS 3
8 WIRING CONNECTION 4
9 BLOCK DIAGRAM 5
10 TERMINALS DESCRIPTION 6
1 ABOUT LEAD FREE
SOLDER (PbF)
Distinction of PbF PCB:
PCBs (manufactured) using lead free solder will have a PbF
stamp on the PCB.
Caution :
• • •
• Pb free solder has a higher melting point than standard
solder; Typically the melting point is 50 - 70°F (30 -
40°C) higher. Please use a soldering iron with
temperature control and adjust it to 700 ± 20°F (370 ±
10°C). In case of using high temperature soldering iron,
please be careful not to heat too long.
• • •
• Pb free solder will tend to splash when heated too high
(about 1100°F/600°C)
• • •
• This lead free solder will be used for the products after
serial No. 1,000,001.
2 FEATUERS
• • •
• Remote Control.
• • •
• 18-FM, 6-AM presets with preset scan
• • •
• Digital servo for reliable CD playback.
• • •
• Removable face plate.
11 PACKAGE AND IC BLOCK DIAGRAM 9
12 REPLACEMENT PARTS LIST 13
13 EXPLODED VIEW (Unit) 18
14 CD PLAYER MECHANICAL PARTS LIST 19
15 EXPLODED VIEW (CD Deck) 20
16 WIRING DIAGRAM 21
17 SCHEMATIC DIAGRAM-1 25
18 SCHEMATIC DIAGRAM-2 27
19 SCHEMATIC DIAGRAM for printing with A4 size 29
3 LASER PRODUCTS
4 REPLACEING THE FUSE
Use fuses of the same specified rating (15A). Using different
substitutes or fuses with higher ratings, or connecting the
product directly without a fuse, could cause fire or damage to
the stereo unit.
CONTENTS
Page Page
2
CQ-C1405N

5 MAINTENANCE
Your products is designed and manufactured to ensure a
minimum of maintenance. Use a dry, a soft cloth for routine
exterior cleaning. Never use benzine, thinner or other solvents.
6 NOTES
[RADIO BLOCK]
Do not align the AM/FM package block. When the package
block is necessary, it will be supplied already aligned at the
factory.
[CD DECK BLOCK]
This model has no servo alignment points because
microcomputer controls the servo circuit.
7 DIMENSIONS
3
CQ-C1405N

8 WIRING CONNECTION
4
CQ-C1405N

9 BLOCK DIAGRAM
5
CQ-C1405N

IC601 : LC7237849D41
Ref.
No. Part No. Part Name & Description I/ OFM(V )AM(V )CD(V )
1XIN 4. 5 MHz X’tal and
Connection I2.52 2.54 2.53
2TEST2 GND connection I 0 0 0
3VREG Bypass condenser
connected. O2.94 2.95 2.95
4VSSCPU GND connection - 0 0 0
5CDC_DATA CD changer data I 0 0 0
6N.C. None - - - -
7CDC_CLK CD changer clock I 0 0 0
8CDC_REM_OUT CD changer Remote out O 0 0 0
9LCD_DO LCD data output I5.2 5.21 5.21
10 LCD_DI LCD data input O5.01 5.04 5.01
11 LCD_CLK LCD clock O5.14 5.16 5.16
12 LCD_CE LCD chip enable output O0.17 0.17 0.17
13 CD_DO CD data output I5.36 5.38 3.9
14 CD_DI CD data input O 0 0 4.74
15 CD_CLK CD clock O4.96 4.98 4.96
16 CD_CE CD chip enable O 0 0 1.57
17 CD_EM CD eject O 0 0 0
18 CD_LM CD loading O 0 0 0
19 CD_S/L CD 24PIN connection O 0 0 5.19
20 SUB_RDY CD INTB1 connection I0.12 0.1 5.22
21 CD_INSW1 CD insert SW input I0.1 0.1 0.1
22 CD_SW2 CD MECHA SW2 I5.15 5.7 0.1
23 CD_LIMIT_SW CD limit SW I 0 0 5.17
24 CD_DRF CD Mute I5.33 5.35 5.35
25 CD_RST CD reset O 0 0 5.13
26 CD_BATT CD_BATT O 0 0 5.18
27 N.C. None O5.17 5.19 5.19
28 N.C. None O 0 0 0
29 PANEL Panel detect I5.21 5.22 5.22
30 N.C. GND connection I 0 0 0
31 N.C. GND connection I 0 0 0
32 N.C. GND connection I 0 0 0
33 N.C. None - - - -
34 N.C. None - - - -
35 N.C. None - - - -
36 N.C. None - - - -
37 N.C. None - - - -
38 N.C. None - - - -
39 VDDPORT Power supply of PORT -5.17 5.19 5.19
40 VSSPORT GND of PORT - 0 0 0
41 N.C. None - - - -
42 N.C. None - - - -
43 N.C. None - - - -
44 N.C. None - - - -
45 N.C. None - - - -
46 N.C. None - - - -
47 N.C. None - - - -
48 N.C. None - - - -
49 PWR_CNT Power control O5.15 5.17 5.17
50 AMP_CNT Amp stand-by O5.15 5.17 5.17
51 AMP_MUTE Amp mute O5.17 5.19 5.19
52 N.C. None - - - -
53 SSC Tuner search
sensitivity change O 0 0 0
54 AF_MUTE AF mute O5.17 5.19 5.19
55 I2C_DATA Electronic VOL data O5.17 5.19 5.19
56 I2C_CLK Electronic VOL clock O5.17 5.19 5.19
57 ANT_CNT Motor antena control O5.17 5.19 0
58 POWER_LED Power LED O0.15 0.16 0.13
59 N.C. None - - - -
60 N.C. (
BZ_OUT ) None - - - -
61 N.C. None - - - -
62 N.C. None - - - -
63 N.C. None - - - -
Ref.
No. Part No. Part Name & Description I/ OFM(V )AM(V )CD(V )
64 N.C. None - - - -
65 N.C. None - - - -
66 TEL_MUTE External MUTE input I 0 0 0
67 BATT Battery detection I5.19 5.2 5.2
68 MODE_B ROTARY B input I5.1 5.17 5.17
69 RDS_CLK RDS clock I 0 0 0
70 REM_IN Remocon data input I5.12 5.14 5.12
71 MODE_A ROTARY A input I5.16 5.17 5.16
72 CDC_STB CD changer strobe
input I 0 0 0
73 NC None - - - -
74 MONO Compulsion MONO ON O 0 0 0
75 AM_MODE AM change O8.19 0.13 8.24
76 FM_MODE FM change O0.13 8.18 8.24
77 N.C. GND connection I 0 0 0
78 INIT_C Initial value C I 0 0 0
79 INIT_B Initial value B I5.15 5.17 5.17
80 INIT_A Initial value A I1.93 1.94 1.94
81 VSSADC GND connection - 0 0 0
82 RDS_DATA RDS data I 0 0 0
83 ST FM stereo input I5.37 5.38 5.39
84 SD_FM/AM Signal detection I3.3 3.28 0
85 N.C. GND connection I 0 0 0
86 RESET Reset Input I5.2(
PWR
OFF)
5.2(
PWR
OFF)
5.2(
EJEC
T)
87 ACC Power supply I5.4 5.4 5.41
88 N.C. GND connection I 0 0 0
89 N.C. GND connection I 0 0 0
90 FM/AM_IFC FM/AM IF input I1.46 1.47 0
91 N.C. GND connection I 0 0 0
92 SUBPD None O 0 0 0
93 VDDPLL Power supply of PLL -5.18 5.19 5.2
94 N.C. None I 0 0 0
95 OSC_FM/AM FM/AM osc input I1.46 1.39 0
96 VSSPLL None - 0 0 0
97 N.C. None - - - -
98 EO1 PLL phase comparison
error output O1.93 2.02 0
99 TEST1 GND connection I 0 0 0
100 XOUT 4. 5 MHz X’tal and
Connection O2.62 2.63 2.63
Note 1 :
Voltage measuerments are with respect to ground, with a
voltmeter (internal resistance : 10M ohms).
IC501:YEAMLC78691N
Ref.
No. Part No. Part Name & Description I/O (V)
1EFMIN RF signal input port. I1.58
2RFOUT RF signal output port. O1.67
3LPF LPF capacitor connection port
for RF signal DC level
detection.
O1.64
4PHLPF LPF capacitor connection port
for detection. O1.68
5AIN A signal input port. I1.66
6CIN C signal input port. I1.66
7BIN B signal input port. I1.66
8DIN D signal input port. I1.66
9FEC LPF capacitor connection port
for FE signal. O1.6
10 RFMON LSI build-in analog signal
monitor port. O1.64
11 VREF VREF voltage output port. O1.66
12 JITTC Capacitor connection port for
JIT detection. O 0
10 TERMINALS DESCRIPTION
10.1. Main Block
6
CQ-C1405N

Ref.
No. Part No. Part Name & Description I/O (V)
13 EIN E signal input port. I1.65
14 FIN F signal input port. I1.66
15 TEC LPF capacitor connection port
for TE signal. O1.57
16 TE TE signal output port. O1.57
17 TEIN TE signal input port for TES. I1.65
18 LDD Laser power control output port. O3.27
19 LDS Laser power detection input
port. I 0
20 AVSS GND for analog. - 0
21 AVDD VDD for analog. -3.27
22 FDO Focus control signal output
port. D/A output. O1.65
23 TDO Tracking control signal output
port. D/A output. O1.65
24 SLDO Thread control signal output
port. D/A output. O1.64
25 SPDO Spindle control signal output
port. D/A output. O1.64
26 VVSS1 GND for build-in VCO. - 0
27 PDOUT1 Phase comparison output port1
for build-in VCO control. O 0
28 PDOUT0 Phase comparison output port0
for build-in VCO control. O 0
29 PCKIST PDOUT0 1 output port for current
setting. I1.07
30 VVDD1 VDD for VCO. -3.29
31 DMUTEB DMUTEB (general) output port. - -
32 PUIN PUIN (general) I/O port. (With
built-in Pull-Up resistance.
Turning off when reset)
I/O 0
33 DEFFCT Detection signal output port. O 0
34 FSEQ Synchronous signal output port.
It becomes ¡§H” when Synchronous
Idle detected from
the EFM signal is corresponding
to Synchronous Idle of internal
generation.
O 0
35 C2F C2 error signal output port. O 0
36 DVDD VDD for Digital. -3.29
37 DVSS GND forDigital. - 0
38 DVDD18 VDD capacitor connection port
for digital circuit. O1.83
39 MONI0 Monitor port0. O 0
40 MONI1 Monitor port1. O 0
41 DVDD VDD for Digital. -3.25
42 DVSS GND forDigital. - 0
43 CE Host IF: Communication enable
signal input port. I 0
44 CL Host IF: Data transfer clock
input port. I3.56
45 DI Host IF: Data input port. I 0
46 DO Host IF: Data output port (Nch
output) Pull-Up is necessary. O5.32
47 RESB Reset input port. Make it L”
when power ON. I 0
48 INTB Interrupt signal output port.
(Servo) - -
49 SUB_READY0 For host u-com IF: SUB-RDY
output. (Nch and Pull-Up
resistance is necessary)
O 0
50 CD_MUTEO General I/O port2. (With built-
in Pull-Up resistance. Turning
off when reset)
I/O 5.31
51 LOW_BATI General I/O port1 I/O 5.16
52 CONT General I/O port0 I/O 0
53 OSCCNT OSCOFF control port . Connected
with 0V when Reset. I 0
54 STREQ Stream data demand signal output
port. I/O 0
55 STCK Clock input port for stream
data. I/O 0
56 STDATA Stream data input port. I/O 0
57 TEST1 Inputport for test. Needed
connect with 0V1 I 0
58 DATA Lch/Rch data output port. - -
59 DATACK Clock output port. - -
60 LRSY Lch/Rch clock output port - -
61 VVDD2 VDD for build-in VCO. -3.25
Ref.
No. Part No. Part Name & Description I/O (V)
62 VPREF2 Built-in VCO oscillation cooking
stove setting input terminal. I3.25
63 VCOC2 Built-in VCO control voltage
setting input port. I1.08
64 VPDOUT2 Output port for built-in VCO
control. O0.08
65 VVSS2 GNDfor building VCO. Needed
connect with 0V. - 0
66 DVDD18 VDD capacitor connection port
for digital circuit. O1.84
67 DVSS GND for Digital system. Needed
connect with 0V. - 0
68 DVDD VDD for Digital system. -3.25
69 DOUT Digital OUT output port. EIAJ
format. - -
70 AMUTEB AMUTEB (general) output port. - -
71 XVSS GND for oscillation circuit.
Needed connect with 0V. - 0
72 XOUT Connected of 16.9344MHz
oscillation. O1.39
73 XIN Connected of 16.9345MHz
oscillation. I1.35
74 XVDD VDD forOscillation circuit. -3.19
75 LCHO L channel output port. O 0
76 LRVDD VDD for LR channel. -3.21
77 LRVSS GND for LR channel. Needed
connect with 0V. - 0
78 RCHO R channel output port. O 0
79 AVDD VDD for analog . -3.27
80 SLCO Slice level control output port. O1.6
7
CQ-C1405N

10.2. Display Block
IC901 : C0HBA0000223
Pin No. Port Descriptions I/O
(V) (V)
1 - - - -
2-4 NC No connection - -
5-39 S1-35 LCD segment O2.5
40-43 C1-4 LCD common O2.5
44-49 KS1-6 Key data output O0.9
50-54 KI1-5 Key data input I 0
55 TEST (Connecting to ground) - 0
56 VDD +5V power supply -5.1
57 VDD1 Ground through capacitor -3.3
58 VDD2 Ground through capacitor -1.7
59 Vss Ground - 0
60 OSC CR oscillator -3.9
61 DO Key data output O4.4
62 CE Chip enable I 0
63 CLK LCD clock I 0
64 DI LCD data input I 0
8
CQ-C1405N

11.1. Main Block
11 PACKAGE AND IC BLOCK DIAGRAM
PA51:J3CCBC000010
IC271 : C1EA00000041
9
CQ-C1405N

IC401 : C1BB00001088
IC701 : C0DAZHF00004
10
CQ-C1405N

IC251 : C1BB00000804
11
CQ-C1405N

IC551 : C1BB00000960
12
CQ-C1405N

Ref.
No. Part No. Part Name & Description Remarks
1. IC’s and Transistors
MAIN BLOCK [E-4C312]
IC251 C1BB00000804 IC T
IC271 C1EA00000041 IC T
IC401 C1BB00001088 IC T
IC501 YEAMLC78691N IC T
IC551 C1BB00000960 IC T
IC601 LC7237849D41 IC T
IC701 C0DAZHF00004 IC T
PA51 J3CCBC000010 Tuner T
Q51 B1GDCFEH0001 Transistor T
Q52 B1GDCFEH0001 Transistor T
Q53 B1GBCFJJ0002 Transistor T
Q071 B1AAEC000002 Transistor T
Q101 B1CAHF000003 Transistor T
Q211 B1GBCFGA0023 Transistor T
Q221 B1GBCFGA0023 Transistor T
Q311 B1GBCFGA0023 Transistor T
Q321 B1GBCFGA0023 Transistor T
Q441 YEAN2SA1317T Transistor T
Q471 B1BCCF000013 Transistor T
Q681 B1GDCFNN0002 Transistor T
Q682 B1GDCFNN0002 Transistor T
Q751 B1GDCFNN0002 Transistor T
Q752 B1GBCFCJ0005 Transistor T
DISPLAY BLOCK [E-4C313]
IC901 C0HBA0000223 IC T
IC902 B3RAB0000030 IC T
Q901 B1GDCFJJ0047 Transistor T
2. Diodes
MAIN BLOCK [E-4C312]
D251 YEADMTZJ56CT Zener Diode T
D601 B0ACCK000005 Diode T
D602 B0ACCK000005 Diode T
D651 B0ACCK000005 Diode T
D652 B0ACCK000005 Diode T
D701 B0EAMM000058 Silcon Diode T
D702 B0ECKE000002 Diode T
D711 B0EAJP000001 Silcon Diode T
D712 B0EAJP000001 Silcon Diode T
D713 B0EAJP000001 Silcon Diode T
D714 B0EAJP000001 Silcon Diode T
Ref.
No. Part No. Part Name & Description Remarks
D715 B0EAJP000001 Silcon Diode T
D716 B0EAJP000001 Silcon Diode T
D717 B0EAJP000001 Silcon Diode T
D719 B0EAJP000001 Silcon Diode T
D720 B0EAJP000001 Silcon Diode T
D751 B0BC6R700006 Diode T
D871 B0ACCK000005 Diode T
DISPLAY BLOCK [E-4C313]
D901 B3AEB0000088 LED(BLUE) T
D902 YEAD19217G7C LED (YELLOW GREEN) T
D903 YEAD19217G7C LED (YELLOW GREEN) T
D905 YEAD19217G7C LED (YELLOW GREEN) T
D906 YEAD19217G7C LED (YELLOW GREEN) T
D907 YEAD19217G7C LED (YELLOW GREEN) T
D908 YEAD19217G7C LED (YELLOW GREEN) T
D909 YEAD19217G7C LED (YELLOW GREEN) T
D910 YEAD19217G7C LED (YELLOW GREEN) T
D911 YEAD19217G7C LED (YELLOW GREEN) T
D912 YEAD19217G7C LED (YELLOW GREEN) T
D913 YEAD19217G7C LED (YELLOW GREEN) T
D951 B3AAB0000213 CHIP LED (WHITE) T
D952 MAZ80560ML Zener Diode T
3. Capacitors
MAIN BLOCK [E-4C312]
C51 F1J1H470A732 Ceramic 47pF 50WV T
C54 F2A1A101A354 Electrolytic 100pF 10WV T
C55 F1J1H103A733 Ceramic 0.01MFD 50WV T
C56 F1J1H223A733 Chip 0.022MFD 50WV T
C57 F1J1H123A733 Ceramic 0.012MFD 50WV T
C60 F1J1H104A733 Ceramic 0.1MFD 50WV T
C61 F1J1H153A733 Ceramic 0.015MFD 50WV T
C62 F1J1H153A733 Ceramic 0.015MFD 50WV T
C71 F2A1A101A354 Electrolytic 100pF 10WV T
C101 F1K1H682A116 Ceramic 6800pF 50WV T
C103 F1J1H103A733 Ceramic 0.01MFD 50WV T
C104 ECQV1H683JL2 Plastic Film 0.068MFD 50WV T
C105 F2A1A221A807 Electrolytic 220pF 10WV T
C201 F1K1C105A070 Ceramic 1MFD 16WV T
C202 F1J1C105A182 Ceramic 1MFD 16WV T
C204 F2A1H1R0A407 Electrolytic 1pF 50WV T
C205 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C208 F1J1H471A733 Ceramic 470pF 50WV T
C209 F1J1H471A733 Ceramic 470pF 50WV T
C211 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C212 ECQV1H224JL2 Plastic Film 0.22MFD 50WV T
C213 F1J1H222A733 Chip 2200pF 50WV T
C221 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C222 ECQV1H224JL2 Plastic Film 0.22MFD 50WV T
C223 F1J1H222A733 Chip 2200pF 50WV T
C224 F1J1H472A733 Ceramic 0.0047MFD 50WV T
C251 F2A1C100A401 Electrolytic 10pF 16WV T
C252 F1J1H103A733 Ceramic 0.01MFD 50WV T
C253 F2A1A221A807 Electrolytic 220pF 10WV T
C254 F1J1H472A733 Ceramic 0.0047MFD 50WV T
C271 F2A1H1R0A019 Electrolytic 1pF 16WV T
C272 F1J1H103A733 Ceramic 0.01MFD 50WV T
C273 F2A1A101A023 Electrolytic 100pF 10WV T
C274 F2A1H1R0A407 Electrolytic 1pF 50WV T
C275 F1J1H103A733 Ceramic 0.01MFD 50WV T
C276 F2A1C100A401 Electrolytic 10pF 16WV T
C301 F1K1C105A070 Ceramic 1MFD 16WV T
C302 F1J1C105A182 Ceramic 1MFD 16WV T
C304 F2A1H1R0A407 Electrolytic 1pF 50WV T
C309 F1J1H471A733 Ceramic 470pF 50WV T
C311 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C312 ECQV1H224JL2 Plastic Film 0.22MFD 50WV T
12 REPLACEMENT PARTS LIST
13
CQ-C1405N

Ref.
No. Part No. Part Name & Description Remarks
C313 F1J1H222A733 Chip 2200pF 50WV T
C321 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C322 ECQV1H224JL2 Plastic Film 0.22MFD 50WV T
C323 F1J1H222A733 Chip 2200pF 50WV T
C324 F1J1H472A733 Ceramic 0.0047MFD 50WV T
C401 F2A1A101A023 Electrolytic 100pF 10WV T
C402 F1J1H103A733 Ceramic 0.01MFD 50WV T
C441 F2A0J330A406 Electrolytic 33pF 6.3WV T
C443 F1J1H103A733 Ceramic 0.01MFD 50WV T
C444 F1J1H104A733 Ceramic 0.1MFD 50WV T
C445 F3F1D105A042 Ceramic 1MFD 20WV T
C446 F1J1H104A733 Ceramic 0.1MFD 50WV T
C447 EEAFC0J560H Electrolytic 56PF 6.3WV T
C448 F1J1H104A733 Ceramic 0.1MFD 50WV T
C449 F1J1H104A733 Ceramic 0.1MFD 50WV T
C450 F2A0J101A020 Electrolytic 100pF 6.3WV T
C451 F2A0J101A409 Electrolytic 100pF 6.3WV T
C471 F1J1H104A733 Ceramic 0.1MFD 50WV T
C472 F2A1A101A354 Electrolytic 100pF 10WV T
C473 EEAFC0J101H Electrolytic 100PF 6.3WV T
C474 F1J1H103A733 Ceramic 0.01MFD 50WV T
C501 F1J1H472A733 Ceramic 0.0047MFD 50WV T
C502 F1J1H103A733 Ceramic 0.01MFD 50WV T
C503 F1J1H473A733 Ceramic 0.047MFD 50WV T
C504 F1J1H563A733 Ceramic 0.056MFD 50WV T
C505 F1J1H103A733 Ceramic 0.01MFD 50WV T
C506 F1J1H102A733 Ceramic 1000pF 50WV T
C507 F1J1H563A733 Ceramic 0.056MFD 50WV T
C508 F1J1H103A733 Ceramic 0.01MFD 50WV T
C509 F2A0J101A409 Electrolytic 100pF 6.3WV T
C510 F1J1H104A733 Ceramic 0.1MFD 50WV T
C511 F1J1C105A182 Ceramic 1MFD 16WV T
C512 F1J1H473A733 Ceramic 0.047MFD 50WV T
C513 F1J1H104A733 Ceramic 0.1MFD 50WV T
C514 F1J1H104A733 Ceramic 0.1MFD 50WV T
C515 F2A0J101A409 Electrolytic 100pF 6.3WV T
C516 F1J1H104A733 Ceramic 0.1MFD 50WV T
C517 F2A0J101A409 Electrolytic 100pF 6.3WV T
C518 F1J1H104A733 Ceramic 0.1MFD 50WV T
C519 F1J1H680A732 Ceramic 68pF 50WV T
C520 F1J1H680A732 Ceramic 68pF 50WV T
C521 F1J1H104A733 Ceramic 0.1MFD 50WV T
C522 F1J1H104A733 Ceramic 0.1MFD 50WV T
C523 F1J1H104A733 Ceramic 0.1MFD 50WV T
C524 F1J1C105A182 Ceramic 1MFD 16WV T
C525 F2A0J101A409 Electrolytic 100pF 6.3WV T
C526 F1J1H104A733 Ceramic 0.1MFD 50WV T
C527 F1J1H104A733 Ceramic 0.1MFD 50WV T
C528 F1J1H104A733 Ceramic 0.1MFD 50WV T
C529 F2A0J331A410 Electrolytic 330pF 6.3WV T
C530 F1J1H104A733 Ceramic 0.1MFD 50WV T
C531 F1J1H473A733 Ceramic 0.047MFD 50WV T
C533 F1J1H104A733 Ceramic 0.1MFD 50WV T
C534 F1J1H104A733 Ceramic 0.1MFD 50WV T
C551 F1J1H271A733 Chip 270pF 50WV T
C552 F1J1H104A733 Ceramic 0.1MFD 50WV T
C553 F1J1H103A733 Ceramic 0.01MFD 50WV T
C554 F2A0J470A407 Electrolytic 47pF 6.3WV T
C555 F1J1H100A732 Ceramic 10pF 50WV T
C556 F1J1H100A732 Ceramic 10pF 50WV T
C557 F2A1C100A401 Electrolytic 10pF 16WV T
C601 F1J1H220A732 Chip 22pF 50WV T
C602 F1J1H220A732 Chip 22pF 50WV T
C603 F1J1C105A182 Ceramic 1MFD 16WV T
C604 F1J1H103A733 Ceramic 0.01MFD 50WV T
C605 F1J1H103A733 Ceramic 0.01MFD 50WV T
C606 ECA0JM102J Electrolytic 1000PF 6.3WV T
C607 F1J1H103A733 Ceramic 0.01MFD 50WV T
C608 F1J1H101A732 Ceramic 100pF 50WV T
C609 F1J1C105A173 Ceramic 1MFD 16WV T
C610 F1J1H103A733 Ceramic 0.01MFD 50WV T
C620 F1J1C105A182 Ceramic 1MFD 16WV T
C631 F1J1H103A733 Ceramic 0.01MFD 50WV T
Ref.
No. Part No. Part Name & Description Remarks
C632 F1J1H103A733 Ceramic 0.01MFD 50WV T
C651 F1J1H104A733 Ceramic 0.1MFD 50WV T
C681 F2A1H2R2A407 Electrolytic 2.2pF 50WV T
C701 F2A1C2220082 Electrolytic 2200pF 16WV T
C702 F1J1H103A733 Ceramic 0.01MFD 50WV T
C703 F1J1H103A733 Ceramic 0.01MFD 50WV T
C704 F1J1H104A733 Ceramic 0.1MFD 50WV T
C705 F2A1C101A405 Electrolytic 100pF 16WV T
C706 F1J1H103A733 Ceramic 0.01MFD 50WV T
C707 F1J1H103A733 Ceramic 0.01MFD 50WV T
C708 F1J1H103A733 Ceramic 0.01MFD 50WV T
C709 EEAFC1A820H Electrolytic 82PF 10WV T
C710 F2A1A101A354 Electrolytic 100pF 10WV T
C711 F1J1H103A733 Ceramic 0.01MFD 50WV T
C712 F1J1H104A733 Ceramic 0.1MFD 50WV T
C871 F1J1H104A733 Ceramic 0.1MFD 50WV T
C872 F1J1H104A733 Ceramic 0.1MFD 50WV T
C881 F1J1H104A733 Ceramic 0.1MFD 50WV T
DISPLAY BLOCK [E-4C313]
C901 F1J1H104A733 Ceramic 0.1MFD 50WV T
C902 F1J1H103A733 Ceramic 0.01MFD 50WV T
C903 F1J1H103A733 Ceramic 0.01MFD 50WV T
C904 F1J1H681A733 Ceramic 680pF 50WV T
C906 F1J1H103A733 Ceramic 0.01MFD 50WV T
C907 F1J1H103A733 Ceramic 0.01MFD 50WV T
CD SERVO BLOCK [E-4C288]
C1 F1J1H104A733 Ceramic 0.1MFD 50WV T
4. Resistors
MAIN BLOCK [E-4C312]
J1 D0YFR00J0001 Chip 0 ohms 1/8W T
J2 D0YFR00J0001 Chip 0 ohms 1/8W T
J3 D0YFR00J0001 Chip 0 ohms 1/8W T
J4 D0YFR00J0001 Chip 0 ohms 1/8W T
J5 D0YFR00J0001 Chip 0 ohms 1/8W T
J6 D0YFR00J0001 Chip 0 ohms 1/8W T
J7 D0YFR00J0001 Chip 0 ohms 1/8W T
J8 D0YFR00J0001 Chip 0 ohms 1/8W T
J9 D0YFR00J0001 Chip 0 ohms 1/8W T
J10 D0YFR00J0001 Chip 0 ohms 1/8W T
J11 D0YFR00J0001 Chip 0 ohms 1/8W T
J12 D0YFR00J0001 Chip 0 ohms 1/8W T
J13 D0YFR00J0001 Chip 0 ohms 1/8W T
J14 D0YFR00J0001 Chip 0 ohms 1/8W T
J15 D0YFR00J0001 Chip 0 ohms 1/8W T
J16 D0YFR00J0001 Chip 0 ohms 1/8W T
J18 D0YFR00J0001 Chip 0 ohms 1/8W T
J19 D0YFR00J0001 Chip 0 ohms 1/8W T
J20 D0YFR00J0001 Chip 0 ohms 1/8W T
J21 D0YFR00J0001 Chip 0 ohms 1/8W T
J22 D0YFR00J0001 Chip 0 ohms 1/8W T
J23 D0YFR00J0001 Chip 0 ohms 1/8W T
J24 D0YFR00J0001 Chip 0 ohms 1/8W T
J26 D0YFR00J0001 Chip 0 ohms 1/8W T
J27 D0YFR00J0001 Chip 0 ohms 1/8W T
J28 D0YFR00J0001 Chip 0 ohms 1/8W T
J29 D0YFR00J0001 Chip 0 ohms 1/8W T
J31 D0YFR00J0001 Chip 0 ohms 1/8W T
J33 D0YFR00J0001 Chip 0 ohms 1/8W T
J34 D0YFR00J0001 Chip 0 ohms 1/8W T
J35 D0YFR00J0001 Chip 0 ohms 1/8W T
J36 D0YFR00J0001 Chip 0 ohms 1/8W T
J37 D0YFR00J0001 Chip 0 ohms 1/8W T
J38 D0YFR00J0001 Chip 0 ohms 1/8W T
J39 D0YFR00J0001 Chip 0 ohms 1/8W T
J40 D0YFR00J0001 Chip 0 ohms 1/8W T
J41 D0YFR00J0001 Chip 0 ohms 1/8W T
J42 D0YFR00J0001 Chip 0 ohms 1/8W T
14
CQ-C1405N

Ref.
No. Part No. Part Name & Description Remarks
J43 D0YFR00J0001 Chip 0 ohms 1/8W T
J44 D0YFR00J0001 Chip 0 ohms 1/8W T
J45 D0YFR00J0001 Chip 0 ohms 1/8W T
J46 D0YFR00J0001 Chip 0 ohms 1/8W T
J47 D0YFR00J0001 Chip 0 ohms 1/8W T
J49 D0YFR00J0001 Chip 0 ohms 1/8W T
J50 D0YFR00J0001 Chip 0 ohms 1/8W T
J51 D0YFR00J0001 Chip 0 ohms 1/8W T
J52 D0YFR00J0001 Chip 0 ohms 1/8W T
J53 D0YFR00J0001 Chip 0 ohms 1/8W T
J54 D0YFR00J0001 Chip 0 ohms 1/8W T
J55 D0YFR00J0001 Chip 0 ohms 1/8W T
J56 D0YFR00J0001 Chip 0 ohms 1/8W T
J57 D0YFR00J0001 Chip 0 ohms 1/8W T
J58 D0YFR00J0001 Chip 0 ohms 1/8W T
R51 D0GD5R6JA052 Chip 5.6 ohms 1/10W T
R52 D0YFR00J0001 Chip 0 ohms 1/8W T
R53 D0GD101JA017 Chip 100 ohms 1/10W T
R54 D0GD221JA017 Chip 220 ohms 1/10W T
R55 D0YFR00J0001 Chip 0 ohms 1/8W T
R56 D0GD393JA017 Chip 39k ohms 1/10W T
R60 D0GD221JA017 Chip 220 ohms 1/10W T
R61 D0YFR00J0001 Chip 0 ohms 1/8W T
R62 D0YFR00J0001 Chip 0 ohms 1/8W T
R63 D0YFR00J0001 Chip 0 ohms 1/8W T
R64 D0YFR00J0001 Chip 0 ohms 1/8W T
R71 D0GD102JA017 Chip 1k ohms 1/10W T
R101 D0GD512JA017 Chip 5k ohms 1/8W T
R102 D0GD331JA017 Chip 330 ohms 1/10W T
R103 D0GD100JA017 Chip 10 ohms 1/10W T
R205 D0GD472JA017 Chip 4.7k ohms 1/10W T
R207 D0GD123JA017 Chip 12k ohms 1/10W T
R209 D0GF682JA017 Chip 6.8k ohms 1/8W T
R211 D0GD181JA017 Chip 180 ohms 1/10W T
R212 D0GD561JA017 Chip 560 ohms 1/10w T
R213 D0GD103JA017 Chip 10k ohms 1/10W T
R221 D0GD181JA017 Chip 180 ohms 1/10W T
R222 D0GD561JA017 Chip 560 ohms 1/10w T
R223 D0GD103JA017 Chip 10k ohms 1/10W T
R251 D0GD393JA017 Chip 39k ohms 1/10W T
R252 D0GD473JA017 Chip 47k ohms 1/10W T
R271 D0GF223JA017 Chip 22k ohms 1/8W T
R273 D0YFR00J0001 Chip 0 ohms 1/8W T
R274 D0YFR00J0001 Chip 0 ohms 1/8W T
R277 D0GD682JA017 Chip 6.8k ohms 1/10W T
R278 D0GF131JA048 Chip 130 ohms 1/8W T
R305 D0GD472JA017 Chip 4.7k ohms 1/10W T
R307 D0GD123JA017 Chip 12k ohms 1/10W T
R309 D0GD682JA017 Chip 6.8k ohms 1/10W T
R311 D0GD181JA017 Chip 180 ohms 1/10W T
R312 D0GD561JA017 Chip 560 ohms 1/10w T
R313 D0GD103JA017 Chip 10k ohms 1/10W T
R321 D0GD181JA017 Chip 180 ohms 1/10W T
R322 D0GD561JA017 Chip 560 ohms 1/10w T
R323 D0GD103JA017 Chip 10k ohms 1/10W T
R401 D0AZ223JA008 Chip 22k ohms 1/6W T
R402 D0GD682JA017 Chip 6.8k ohms 1/10W T
R403 D0AE223JA131 Chip 22k ohms 1/4W T
R404 D0GD223JA017 Chip 22k ohms 1/10W T
R405 D0GD153JA017 Chip 15k ohms 1/10W T
R406 D0GD333JA017 Chip 33k ohms 1/10W T
R407 D0GD622JA017 Chip 6.2k ohms 1/10W T
R408 D0GF333JA017 Chip 33k ohms 1/8W T
R409 D0GD622JA017 Chip 6.2k ohms 1/10W T
R410 D0AZ103JA008 Chip 10k ohms 1/6W T
R441 D0GD330JA017 Chip 33 ohms 1/10W T
R442 D0GD3R3JA052 Chip 3.3 ohms 1/10W T
R443 D0GD102JA017 Chip 1k ohms 1/10W T
R444 D0GD102JA017 Chip 1k ohms 1/10W T
R445 D0GD471JA017 Chip 470 ohms 1/10W T
R471 D0GD163JA017 Chip 16k ohms 1/10W T
R472 D0GF103JA014 Chip 10k ohms 1/8W T
R501 D0GD331JA017 Chip 330 ohms 1/10W T
Ref.
No. Part No. Part Name & Description Remarks
R502 D0YFR00J0001 Chip 0 ohms 1/8W T
R503 D0YFR00J0001 Chip 0 ohms 1/8W T
R504 D0GF472JA017 Chip 4.7k ohms 1/8W T
R505 D0GF472JA017 Chip 4.7k ohms 1/8W T
R506 D0GD681JA017 Chip 680 ohms 1/10W T
R507 D0GD335JA052 Chip 3.3M ohms 1/10W T
R508 D0GD681JA017 Chip 680 ohms 1/10W T
R509 D0GD683JA017 Chip 68k ohms 1/10W T
R510 D0GDR00JA017 Chip 0 ohms 1/10W T
R511 D0GDR00JA017 Chip 0 ohms 1/10W T
R512 D0GD273JA017 Chip 27k ohms 1/10W T
R513 D0GD562JA017 Chip 5.6k ohms 1/10w T
R514 D0GD273JA017 Chip 27k ohms 1/10W T
R516 D0GD273JA017 Chip 27k ohms 1/10W T
R517 D0AZ102JA008 Chip 1k ohms 1/6W T
R518 D0AZ102JA008 Chip 1k ohms 1/6W T
R519 D0GD220JA017 Chip 22 ohms 1/10W T
R520 D0GD332JA017 Chip 3.3k ohms 1/10W T
R521 D0GD151JA017 Chip 150 ohms 1/10W T
R522 D0GD223JA017 Chip 22k ohms 1/10W T
R523 D0GD470JA017 Chip 47 ohms 1/10W T
R524 D0GD100JA017 Chip 10 ohms 1/10W T
R525 D0GD221JA017 Chip 220 ohms 1/10W T
R530 D0GD473JA017 Chip 47k ohms 1/10W T
R551 D0GDR00JA017 Chip 0 ohms 1/10W T
R554 D0GD103JA017 Chip 10k ohms 1/10W T
R555 D0GD225JA017 Chip 2.2M ohms 1/10W T
R556 D0GD103JA017 Chip 10k ohms 1/10W T
R557 D0YFR00J0001 Chip 0 ohms 1/8W T
R558 D0YFR00J0001 Chip 0 ohms 1/8W T
R601 D0GD473JA017 Chip 47k ohms 1/10W T
R602 D0GD473JA017 Chip 47k ohms 1/10W T
R605 D0GF473JA017 Chip 47k ohms 1/8W T
R607 D0GF473JA017 Chip 47k ohms 1/8W T
R610 D0GD222JA017 Chip 2.2k ohms 1/10W T
R611 D0GD473JA017 Chip 47k ohms 1/10W T
R612 D0GD103JA017 Chip 10k ohms 1/10W T
R613 D0GD103JA017 Chip 10k ohms 1/10W T
R614 D0GF102JA014 Chip 1k ohms 1/8W T
R615 D0GD102JA017 Chip 1k ohms 1/10W T
R616 D0GF473JA017 Chip 47k ohms 1/8W T
R618 D0YFR00J0001 Chip 0 ohms 1/8W T
R619 D0AE102JA131 Chip 1k ohms 1/4W T
R620 D0GD102JA017 Chip 1k ohms 1/10W T
R621 D0GD102JA017 Chip 1k ohms 1/10W T
R622 D0GD102JA017 Chip 1k ohms 1/10W T
R623 D0GD102JA017 Chip 1k ohms 1/10W T
R624 D0GD473JA017 Chip 47k ohms 1/10W T
R625 D0GD473JA017 Chip 47k ohms 1/10W T
R626 D0GD473JA017 Chip 47k ohms 1/10W T
R627 D0AZ272JA008 Chip 2.7k ohms 1/4W T
R628 D0GD122JA017 Chip 1.2k ohms 1/10W T
R633 D0GF511JA017 Chip 510 ohms 1/8W T
R634 D0GDR00JA017 Chip 0 ohms 1/10W T
R636 D0GD102JA017 Chip 1k ohms 1/10W T
R637 D0GD154JA017 Chip 150k ohms 1/10W T
R638 D0GD333JA017 Chip 33k ohms 1/10W T
R639 D0GD103JA017 Chip 10k ohms 1/10W T
R640 D0AZ473JA008 Chip 47k ohms 1/6W T
R641 D0GF473JA017 Chip 47k ohms 1/8W T
R651 D0GF102JA014 Chip 1k ohms 1/8W T
R652 D0GD104JA017 Chip 100k ohms 1/10W T
R653 D0GD102JA017 Chip 1k ohms 1/10W T
R654 D0GD104JA017 Chip 100k ohms 1/10W T
R655 D0GD102JA017 Chip 1k ohms 1/10W T
R656 D0GD102JA017 Chip 1k ohms 1/10W T
R657 D0GD104JA017 Chip 100k ohms 1/10W T
R658 D0GD102JA017 Chip 1k ohms 1/10W T
R659 D0GD104JA017 Chip 100k ohms 1/10W T
R660 D0GD122JA017 Chip 1.2k ohms 1/10W T
R661 D0AZ104JA008 Chip 100k ohms 1/6W T
R681 D0GD271JA017 Chip 270 ohms 1/10W T
R682 D0GD272JA017 Chip 2.7k ohms 1/10W T
15
CQ-C1405N

Ref.
No. Part No. Part Name & Description Remarks
R691 D0GF473JA017 Chip 47k ohms 1/8W T
R701 D0AZ823JA008 Chip 82k ohms 1/6W T
R703 D0AE102JA131 Chip 1k ohms 1/4W T
R704 D0GD473JA017 Chip 47k ohms 1/10W T
R705 D0GD102JA017 Chip 1k ohms 1/10W T
R706 D0GD153JA017 Chip 15k ohms 1/10W T
R707 D0GD332JA017 Chip 3.3k ohms 1/10W T
R713 D0GD223JA017 Chip 22k ohms 1/10W T
R751 D0GD333JA017 Chip 33k ohms 1/10W T
R752 D0GD104JA017 Chip 100k ohms 1/10W T
R753 D0GD473JA017 Chip 47k ohms 1/10W T
R871 D0GD471JA017 Chip 470 ohms 1/10W T
RA601 D1H81024A031 Chip 10.2M ohms 1/16W T
RA602 D1H81024A031 Chip 10.2M ohms 1/16W T
RA603 D1H81024A031 Chip 10.2M ohms 1/16W T
RA651 D1H81024A031 Chip 10.2M ohms 1/16W T
DISPLAY BLOCK [E-4C313]
R901 D0YFR00J0001 Chip 0 ohms 1/8W T
R902 D0GD4R7JA056 Chip 4.7 ohms 1/10W T
R903 D0GD623JA052 Chip 62k ohms 1/10W T
R904 D0GD681JA017 Chip 680 ohms 1/10W T
R905 D0GD431JA017 Chip 430 ohms 1/10W T
R906 D0GD221JA017 Chip 220 ohms 1/10W T
R907 D0GD221JA017 Chip 220 ohms 1/10W T
R908 D0GD221JA017 Chip 220 ohms 1/10W T
R909 D0GF241JA048 Chip 240 ohms 1/8W T
R912 D0GD102JA017 Chip 1k ohms 1/10W T
R913 D0GD102JA017 Chip 1k ohms 1/10W T
R914 D0GD102JA017 Chip 1k ohms 1/10W T
R915 D0GD272JA017 Chip 2.7k ohms 1/10W T
R916 D0GD102JA017 Chip 1k ohms 1/10W T
R917 D0GD102JA017 Chip 1k ohms 1/10W T
R918 D0GDR00JA017 Chip 0 ohms 1/10W T
CD SERVO BLOCK [E-4C288]
J30 D0YFR00J0001 Chip 0 ohms 1/8W T
J31 D0YFR00J0001 Chip 0 ohms 1/8W T
J32 D0YFR00J0001 Chip 0 ohms 1/8W T
J33 D0YFR00J0001 Chip 0 ohms 1/8W T
J34 D0YFR00J0001 Chip 0 ohms 1/8W T
J35 D0YFR00J0001 Chip 0 ohms 1/8W T
J36 D0YFR00J0001 Chip 0 ohms 1/8W T
J37 D0YFR00J0001 Chip 0 ohms 1/8W T
5. Connectors
MAIN BLOCK [E-4C312]
CN501 K1KA22A00001 Connector T
CN651 K1KY15BA0032 Connector T
CN701 K1FA116B0028 Connector T
CN351 YEAER120002 Connector T
DISPLAY BLOCK [E-4C313]
CN901 K1KY15BA0031 Connector T
CN951 K2HC101A0003 Aux Jack T
CD SERVO BLOCK [E-4C288]
CN1 K1KB22AA0200 Connector T
CN2 K1MY16BA0184 SMD Connector T
6. Electric Parts
SWITCHES
SW901 K0H1BA000445 Tack Swich T
SW902 K0H1BA000445 Tack Swich T
SW903 K0H1BA000445 Tack Swich T
SW904 K0H1BA000445 Tack Swich T
SW905 K0H1BA000445 Tack Swich T
Ref.
No. Part No. Part Name & Description Remarks
SW906 K0H1BA000445 Tack Swich T
SW907 K0H1BA000445 Tack Swich T
SW908 K0H1BA000445 Tack Swich T
SW909 K0H1BA000445 Tack Swich T
SW910 K0H1BA000445 Tack Swich T
SW911 K0H1BA000445 Tack Swich T
SW912 K0H1BA000445 Tack Swich T
SW913 K0H1BA000445 Tack Swich T
SW914 K0H1BA000445 Tack Swich T
SW915 K0H1BA000445 Tack Swich T
SW916 K0H1BA000445 Tack Swich T
CRYSTAL
XL501 YEXL16M9X54A Ceramic Filter T
XL551 YEXL4C4332TT Crystal(7.2MHz) T
XL601 H0A450000001 Crystal T
COILS
L51 G1C150JA0036 Coil T
L52 G1CR56JA0036 Coil T
L71 G1C8R2JA0036 Coil T
L501 G1C2R2JA0036 RF Coil T
L502 G1C2R2JA0036 RF Coil T
L551 G1C330JA0036 Coil T
L701 YETQ024C081 Choke Coil T
VR
SW951 K9AA024A0014 Encoder T
LCD
LCD901 YEXDCM4C142 LCD T
SURGE PROTECTOR
Z51 D4ZZ00000024 Surge Protector T
7. Accessories
PRINT
YFM284C622CA Operating
Instructions(ENGLISH) T
YFM284C623CA Operating
Instructions(GERMANY) T
YFM284C624CA Operating
Instructions(FRANCE) T
YFM284C625CA Operating
Instructions(HOLLAND) T
YFM284C626CA Operating
Instructions(SWEDEN) T
YFM284C627CA Operating Instructions(ITALY) T
YFM284C628CA Operating Instructions(SPAIN) T
YFM284C629CA Operating
Instructions(DENMARK) T
YFM284C630CA Operating
Instructions(POLLAND) T
YFM284C631CA Operating Instructions(CZECH) T
YFM284C632CA Operating
Instructions(HUNGARY) T
YFM284C633CA Operating
Instructions(RUSSIA) T
YFM294C078CA Installation Instructions T
YFM294C079CA Installation Instructions T
YFM294C080CA Installation Instructions T
INSTALLATION PARTS
FX0214C384ZB Escape Case T
YEAJ02874 Power Connector T
ZZBISC1021N-J Screw Kit T
YFC054C061ZB Unit Case T
YFC054C056ZB Unit Case T
16
CQ-C1405N

Ref.
No. Part No. Part Name & Description Remarks
8. Mechanical Parts
MISCELLANEOUS
ANT51 YEAA094C008 ANT JACK T(3-C)
1YFA034C053CA Upper Cover T(4-B)
2YGFD044C002 CD Deck T(4-C)
3XTB26+5FFN Screw T(4-C)
4XTW2+5FFN Screw T(4-C)
5YFF014C055CA Heat Sink T(3-C)
6YEJT034C019N Screw(CUP TIGHT 3X12) T(3-C)
7XTB3+8FFZ Screw T(3-C)
8YJS064C002FN Screw T(3-C)
9XTB26+8GFN Screw T(3-C)
10 YFA084C063CA Rear Plate T(3-C)
11 YFC034C002CA ESC Holder T(2-C)
12 YFX054C074CA Spring (HOOK) T(2-C)
13 YEFX9991682B Release Hook T(2-C)
14 YEFS02302 Dust Felt T(2-C)
15 YEFS011113 Pad T(2-C)
16 XTN2+8GFZ Screw T(2-C)
17 YFX054C071CA Spring (PUSH BUTTON) T(2-C)
18 YFE134C491YA Button (Push) T(2-C)
19 YFC024C699CB ESC Rear Cover T(2-C)
21 YFV024C108CA Sheet T(2-B)
22 YFE134C544CA Button (TUNE/TRACK) T(1-B)
23 YFX054C072CA Spring (OPEN) T(1-B)
24 YFE134C505CA Button(RELEASE) T(1-B)
25 YFE134C508CA Button (DISP/EJ) T(1-B)
26 YFC034C009CC ESC Printing T(1-B)
27 YFX014C091CA Panel Light (CD) T(1-A)
28 YFJ014C164CA ARC Panel T(1-A)
29 YFE134C513CA Button (4-6) T(1-A)
30 YFE134C514CA Button (SRC/PWR) T(1-A)
31 YFX994C126CA Two-Side Tape T(1-A)
32 YFJ014C225CA Ornament Panel T(1-A)
33 YFX014C090CA Back Light Assy T(2-B)
34 YFS014C110CA Rubber Gum T(2-B)
36 YFX214C405CA LCD Bracket T(2-B)
37 YFE134C506CA Button(BAND/MUTE) T(2-B)
38 YFE134C507CA Button (SQ) T(2-B)
39 ESCC1405N-J ESC Unit Assy T(2-
B)/RTL
40 YFX054C073CB Spring (KNOB) T(1-A)
41 YFE074C070CA Vol Knob T(1-A)
42 YFE074C071CA VOL Knob ASSY T(1-A)
43 YFE134C512CA Button (1-3) T(1-A)
44 YFC054C079YA Trim Plate T(1-A)
45 YFA054C042ZA Bottom Cover T(1-C)
46 XSB3+6FN Screw T(1-C)
47 AADK288E0-J Deck Assy T(4-C)
48 AAPB312A0-J Main PCB Ass’y T(2-
B)/RTL
49 ZZFP-192 ESC Hold Assy T(2-C)
50 APCB313A0-J Key PCB Ass’y T(2-
B)/RTL
51 APCB288A0-J Servo PCB Assy T(4-
B)/RTL
52 YFX214C407CA AUX Bracket T(2-C)
17
CQ-C1405N

13 EXPLODED VIEW (Unit)
18
CQ-C1405N

Ref.
No. Part No. Part Name & Description Remarks
13032 01 36 FRAME (M2) N(E-4)
23032 01 37 TOP COVER (M2) N(A-4)
33032 01 15 DAMPER F N(E-3)
43032 01 16 DAMPER R N(D-4)
11 3032 05 508 CHASSIS RIVET ASS’Y(M2) N(B-2)
12 3032 05 504 CHASSIS PLTAE RIVET
ASS’Y(M) N(C-4)
13 3032 05 301 CLAMPER ASS’Y N(B-3)
14 3032 05 307 SPINDLE MOTOR (M) ASS’Y T(D-1)
15 3032 05 56 CLAMPER ARM M N(B-4)
16 3032 05 03 CHANGE GEAR SPRING N(D-4)
17 3032 05 05 CHANGE GEAR 2 N(D-4)
18 3032 05 06 FEED GEAR N(D-3)
19 3032 05 51 FEED RACK M N(B-1)
20 3032 05 53 CHANGE LOCK LEVER M N(D-3)
21 3032 05 57 FEED SW HOLDER (M) N(C-1)
22 3032 05 54 PU SHAFT HOLDER (M) N(B-1);
N(B-2)
23 3032 05 13 CLAMPER SUB SPRING N(B-3)
24 3032 05 58 FD SUB HOLDER M N(B-1)
25 3032 05 65 TOP PLATE (M2) N(B-2)
26 3032 05 19 SELECT LOCK ARM N(A-1)
27 3032 05 21 SLIDE HOOK N(C-4)
28 3032 05 55 PU SHAFT M N(B-1)
29 3032 05 59 CLAMPER ARM SPRING M N(B-4)
30 3032 05 26 SELECT LOCK ARM SPRING N(A-1)
31 3032 05 62 SUSPENSION SPRING MS N(B-3);
N(C-1);
N(C-4);
N(D-2)
32 3032 05 64 SELECT ARM R (M2) N(A-2)
33 3032 05 30 LINK PLATE N(A-2)
34 3032 05 36 LINK PLATE SPRING S N(A-2)
35 3032 05 23 CUSHION F N(A-1)
36 3032 05 24 CUSHION R N(B-4)
37 3032 05 63 FEED SPR PLATE M N(C-2)
38 3032 05 61 TRIGGER ARM M N(C-4)
43 3032 08 03 SELECT PLATE L N(A-1)
44 3032 08 04 SELECT PLATE R N(A-2)
45 3032 08 05 SELECT PIECE L N(A-1)
46 3032 08 06 SELECT PIECE R N(A-2)
61 6904 16 06 PICK UP RD-DAP005-TN T(B-1)
62 6418 04 07 DET SW ESE 22MH55 N(C-1)
72 3032 10 02 MODE SW T(A-1)
73 3032 10 51 LD WIRE MN T(B-3);
T(C-1)
Ref.
No. Part No. Part Name & Description Remarks
74 3032 10 40 SW WIRE MN N(A-1)
75 3032 10 39 SP WIRE MN N(D-2)
77 3032 10 13 WIRE CLAMPER M N(C-2);
N(C-3);
N(D-4);
N(E-3)
78 3032 10 28 WIRE TUBE SPM N(D-2)
79 3032 10 29 WIRE TUBE MSW N(A-1)
81 3032 11 301 ROLLER SHAFT ASS’Y N(E-2)
82 3032 11 501 LOADING GEAR PLATE RIVET
ASS’Y N(D-2)
83 3032 11 302 LOADING PLATE ASS’Y N(C-4)
84 3032 11 504 LOCK ARM RIVET ASS’Y (S) N(E-1)
85 3032 11 305 LOADING / FEED MOTOR ASS’Y
(MB) T(B-3)
86 3032 11 01 LOADING GEAR 1 N(D-4)
87 3032 11 02 LOADING GEAR 2 N(D-3)
88 3032 11 03 LOADING GEAR 3 N(D-3)
89 3032 11 04 LOADING GEAR 4 N(D-2)
90 3032 11 05 LOADING GEAR 5 N(D-2)
91 3032 11 06 LOADING GEAR 6 N(D-2)
92 3032 11 07 LOADING GEAR 7 N(D-3)
93 3032 11 11 ROLLER GUIDE N(D-1);
N(E-3)
94 3032 11 14 ROLLER GUIDE SPRING N(D-1);
N(E-1)
95 3032 11 16 DISC STOPPER ARM N(C-1)
96 3032 11 17 DISC STOP ARM SPRING N(D-2)
97 3032 11 18 LD GEAR BRACKET N(D-2)
98 3032 11 25 L SLIDE PLATE N(D-4)
99 3032 11 31 LOADING PLATE SPRING N(C-4)
100 3032 11 37 LDG ROLLER (N) T(D-1)
101 3032 11 43 COLLAR SCREW N(E-1)
111 9P04 20 031 TAPPING SCREW 2X3 N(A-3);
N(B-3);
N(B-4);
N(D-2);
N(E-4)
112 9P04 20 041 TAPPING SCREW 2X4 N(B-1);
N(B-2)
113 9B03 20 041 TAPPING BIND SCREW 2X4 N(D-2)
114 9C01 17 183 CAMERA SCREW 1.7X1.8 N(B-2)
115 9C01 20 203 CAMERA SCREW 2X2 N(C-3)
116 9C45 17 503 CAMERA TAPPING SCREW P3
M1.7X5 N(C-1)
121 9W01 30 170 PW 3.5X8X0.3 N(D-4)
122 9W05 13 060 HLW 1.85X5X0.13 N(D-1)
123 9W07 10 070 LUMILAR WASHER 3.1X6X0.1 N(D-1)
124 9E01 00 152 E RING S 1.5 N(D-4)
125 9W01 13 020 PW 2.1X4X0.13 N(D-3)
14 CD PLAYER MECHANICAL PARTS LIST
19
CQ-C1405N

15 EXPLODED VIEW (CD Deck)
20
CQ-C1405N
