Panasonic CQDPX172U - AUTO RADIO/CD DECK User manual

General
Power Supply DC 12V (11V - 16V),
Test Voltage 14.4V
Negative Ground
Tone Adjustment Range Bass ; ±12dB at 100Hz
Treble ; ±12dB at 10kHz
Current Consumption Less than 2.2A (CD play mode,
0.5W×4ch)
Maximum Power Output 45W×4ch (at 1kHz, Vol. Max.)
Suitable Speaker Impedance 4-8Ω
Pre-AMP Output Voltage 2V (CD play mode; 1kHz, 0dB)
Output Impedance 200Ω
FM Stereo Radio
Frequency Range 87.9 - 107.9MHz
Usable Sensitivity 11.0 dBf (1.25µV, 75Ω)
AM Radio
Frequency Range 530 - 1,710kHz
Usable Sensitivity 28dB/µV (25µV, S/N 20dB)
CD Player
Sampling Frequency 32 times over sampling
Pick-Up Type Astigma 3-beam
Light Source Semiconductor Laser
©2002 Matsushita Communication Industrial Co.,
Ltd. All rights reserved. Unauthorized copying and
distribution is a violation of law.
CQ-DPX172U
Removable Front Panel MP3 CD Player
/ Receiver with Changer Control
Wavelength 780nm
Frequency Response 20Hz to 20,000Hz (±1dB)
Signal to Noise Ratio 96dB
Wow and Flutter Below measurable limits
Channel Separation 75dB
Dimensions** 7”×1 15/16”×5 7/8”
(178×50×150mm)
Weight** 3lbs. 5oz (1.5kg)
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
Avobe specifications comply with EIA standards.
AUTOMOTIVE CONSUMER ELECTRONICS
Specifications*
ORDER No. ACED020274C1
C4

1 FEATUERS 2
2 REPLACEING THE FUSE 2
3 MAINTENANCE 2
4 NOTES 2
5 DIMENSIONS 2
6 LASER PRODUCTS 2
7 WIRING CONNECTION 3
8 BLOCK DIAGRAM 4
9 TERMINALS DESCRIPTION 5
1 FEATUERS
· PLL (Phase Locked Loop) synthesized tuning.
· 18-FM, 6-AM presets with preset scan
· Digital servo for reliable CD playback.
· Removable face plate.
2 REPLACEING THE FUSE
Use fuses of the same specified rating (15A). Using different
substitutes or fuses with higher ratings, or connecting the unit
directly without a fuse, could cause fire or damage to the stereo
unit.
3 MAINTENANCE
Your products is designed and manufactured to ensure a
minimum of maintenance. Use a soft cloth for routine exterior
cleaning. Never use benzine, thinner or other solvents.
4 NOTES
[RADIO BLOCK]
Do not align the AM/FM package block. When the package
block is necessary, it will be supplied already aligned at the
factory.
[CD DECK BLOCK]
This model has no servo alignment points because
microcomputer controls the servo circuit.
10 PACKAGE AND IC BLOCK DIAGRAM 7
11 REPLACEMENT PARTS LIST 10
12 EXPLODED VIEW (Unit) 15
13 CD PLAYER PARTS 16
14 EXPLODED VIEW (CD Deck) 17
15 PACKING PARTS LIST 18
16 WIRING DIAGRAM 19
17 SCHEMATIC DIAGRAM -1 24
18 SCHEMATIC DIAGRAM -2 25
5 DIMENSIONS
6 LASER PRODUCTS
CONTENTS
Page Page
2
CQ-DPX172U

7 WIRING CONNECTION
3
CQ-DPX172U

8 BLOCK DIAGRAM
4
CQ-DPX172U

9.1. Main Block
IC600 : C2BBGF000292
Pin
No. Port Description I/O (V)
1 INIT C Initial C I 4.9
2 NC No connection - -
3 NC No connection - -
4 AVSS Analog ground - 0
5 AF MUTE AF mute O 5.1
6 AMP.CNT Power Amp. stand-by O 5.0
7 AVREF Reference voltage - 5.1
8 CD-SO CD data I 3.2
9 CD-SI CD data O 3.8
10 CD-SCK CD clock O 5.0
11 CD.C DATA CD changer data O 0
12 NC No connection - -
13 CD.C CLK CD changer clock O 0
14 REM OUT CD changer remote cont. data O 5.0
15 PLL CE PLL controller chip enable O 0
16 PLL DATA
(MI) Data from PLL I 5.1
17 PLL DATA
(MO) Data for PLL O 0
18 PLL CLK Clock for PLL O 0
19 NC No connection - -
20 NC No connection - -
21 CD-RESET CD reset O 5.0
22 NC No connection - -
23 NC No connection - -
24 NC No connection - -
25 NC No connection - -
26 NC No connection - -
27 NC (GND pull-down) - 0
28 CD-ON CD power on O 5.0
29 CD-MUTE CD mute control I 0
30 CD-SW2 Not used - -
31 NC No connection - -
32 NC No connection - -
33 Vss Ground - 0
34 NC No connection - -
35 /ST FM stereo detection I 4.5
36 IC2-CLK Electronic volume clock O 5.0
37 IC2-DATA Electronic volume data I/O 5.0
38 S.LED Not used - -
39 NC No connection - -
40 BZIN Not used - -
41 LCD-DI (MO) LCD data output O 0
42 LCD-DO (MI) LCD data input I 5.0
43 LCD-CLK LCD clock O 0
44 LCD-CE LCD chip enable output O 0.2
45 POWER
LED Pilot lamp on O 0
46 ANT.CONT Motor antenna control O 0
47 NC No connection - -
48 NC No connection - -
49 NC No connection - -
50 BZOUT Not used - -
51 NC No connection - -
52 NC No connection - -
53 NC No connection - -
54 NC No connection - -
55 PANEL Panel detect I 4.8
56 CD POWER CD power control O 5.1
57 PWR CNT Power control O 5.1
58 ACC ACC detection I 5.0
59 RDS DATA Not used - -
60 /RESET Reset input I 5.1
61 REM Remocon data input I 5.1
62 BATT Battery detection I 5.0
63 RDS CLK Not used - -
64 CD.C.STB (Ground pull-down) I 0
65 MUTE Mute control O 5.1
66 NC (Connecting to ground) - 0
67 VSS0 (Connecting to ground) - 0
68 VDD +5V power supply - 5.1
69 X2 Crystal oscillator - 3.0
70 X1 Crystal oscillator - 1.7
71 VPP (Ground pull-down) - 0
72 NC No connection - -
73 NC No connection - -
74 VDD0 +5V power supply - 5.1
75 AVREF (Connecting to VDD) - 5.1
76 NC (Connecting to ground) - 0
77 SD Search detect I 5.1
78 INIT D Initial value D I 0
79 INIT A Initial value A I 0
80 INIT B Initial value B I 0
Note 1 : Voltage measuerments are with respect to ground,
with a voltmeter (internal resistance : 10M ohms).
9.2. Display Block
IC901 : YEAMLC75854T
Pin
No. Port Description I/O (V)
1-35 SEG9-35 LCD segment O 2.5
36-39 NC No connection - -
40-43 COM1-4 LCD common O 2.5
44-49 KS1-6 Key data output O 0.9
50-54 KI1-5 Key data input I 0
55 TEST (Connecting to ground) - 0
56 VDD +5V power supply - 5.1
57 VDD1 Ground through capacitor - 3.3
58 VDD2 Ground through capacitor - 1.7
59 Vss Ground - 0
60 OSC CR oscillator - 3.9
61 DO Key data output O 4.4
62 CE Chip enable I 0
63 CLK LCD clock I 0
64 DI LCD data input I 0
9 TERMINALS DESCRIPTION
5
CQ-DPX172U

9.3. CD Servo Block
IC501 : MN101C28LAC
Pin
No. Port Description I/O (V)
1 VREF- Reference voltage for ADC (GND) - 0
2 PA0 (Connecting to GND) - 0
3 PA1 Disc-In sensor I 2.9
4 PA2 Feeder arm SW I 3
5 PA3 Disc-Out sensor I 3
6 PA4 Clamp SW I 0
7 PA5 Inner SW I 3.3
8 PA6 Disc-In sensor I 1.5
9 PA7 Not used - 3.3
10 VREF+ Reference voltage for ADC (+3.3V) - 3.3
11 VDD Power supply (+3.3V) - 3.3
12 OSC2 System clock (7.37MHz) O 1.6
13 OSC1 System clock (7.37MHz) I 1.5
14 VSS Ground - 0
15 XI (Connecting to GND) - 0
16 XO (NC) No connection - -
17 MMOD (Connecting to GND) - 0
18 SOM Serial data output O 0.5
19 SIM Serial data input I 0.5
20 SCK Shift clock for serial data I 3
21 SB01/P03 No connection - -
22 SUBC CD-TEXT data I 0
23 SBCK CD-TEXT clock O 3.3
24 P06 (NC) No connection - -
25 RESET Reset input I 3.3
26 MDATA MPU communication data O 1
27 MCLK Shift clock for MDATA O 2.5
28 SCK Shift clock for serial data I 2.2
29 STAT Servo LSI status I 0
30 TM4IO/P14 No connection - -
31 POBF MP3 DSP status I 0
32 DATAREQ MP3 DSP NEXT data request I 3
33 CD. ON CD operation mode I 3.2
34 DQSY CD-TEXT/SUBQ sync. I 0
35 BLKCK BLKCK signal I 3.3
36 SQCK Clock for sub. code data I 1.5
37 SUBQ Sub. code data I 0
38 SBT2/P32 (Connecting to GND) O 0
39 MLD MPU command load O 3.3
40 ACK MP3 DSP acknowledge O 0
41 IOSEL Servo LSI mode setting O 3.3
42 VDD2 Power supply for flash write - 3.3
43 VPP Power supply for flash write - 3.3
44 DSPP0 MP3 DSP data (bit0) I/O 0
45 DSPP1 MP3 DSP data (bit1) I/O 0
46 DSPP2 MP3 DSP data (bit2) I/O 0
47 DSPP3 MP3 DSP data (bit3) I/O 0
48 DSPP4 MP3 DSP data (bit4) I/O 0
49 DSPP5 MP3 DSP data (bit5) I/O 0
50 DSPP6 MP3 DSP data (bit6) I/O 0
51 DSPP7 MP3 DSP data (bit7) I/O 0
52 PCS MP3 DSP chip select O 0
53 PWE MP3 DSP write enable O 0
54 PRE MP3 DSP read enable O 1.3
55 PIBE MP3 status for data input I 3.3
56 DSPRST DSP reset O 3.3
57 PRST Servo LSI reset O 2.2
58 STAT Servo LSI status I 0
59 DMUTE Digital voice signal mute O 0
60 TLOCK Tracking lock I 0
61 FLOCK Focus lock I 0
62 SENSE Servo LSI detection I 0
63 STOP MP3 DSP stop O 0
64 ERROR MP3 DSP error detection I 1.3
65 MUTE Voice signal mute O 2.5
66 TRV Traverse motor control I/O 1.6
67 PC1 Loading motor drive output cont. O 0
68 PC2 Fo & Tr actuator driver output cont. O 3.3
69 LOD Loading motor control I/O 1.6
70 P75 (NC) No connection - -
71 P76 (NC) No connection - -
72 GCTL RF amp gain control O 1.3
73 P87 (NC) No connection - -
74 P86 (NC) No connection - -
75 P85 (NC) No connection - -
76 P84 (NC) No connection - -
77 P83 (NC) No connection - -
78 IPFLAG (NC) No connection - -
79 PHOTO Photo sensor power control O 0
80 P80 (NC) No connection - -
6
CQ-DPX172U

10.1. Main Block
10 PACKAGE AND IC BLOCK DIAGRAM
PA51 : C5BA00000092
IC201 : YEAMEA6320TT
7
CQ-DPX172U

IC270 : C1EA00000026
IC650 : YEAMC14584BE
IC601 : AN8065SE1
IC704 : C0DAZHF00003
IC400 : C1BB00000541
8
CQ-DPX172U

10.2. Display Block
10.3. CD Servo Block
IC901 : C0GBY0000012
IC441 : C0JBAE000087
IC541 : YEAMT7ST32UL
IC902 : YEAMSBX8035F
9
CQ-DPX172U

11 REPLACEMENT PARTS
LIST
Notes :
1.Be sure to make your orders of replacement parts
according to this list.
2.Important safety notice: Components, identified by ;
mark have special characteristics important for safety.
When replacing any of these components, use only
manufacturer´s specified parts.
3.Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4.The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
Ref.
No. Part No. Part Name & Description Remarks
[E-6882B] Main Block
ICs AND TRANSISTORs
IC201 YEAMEA6320TT IC
IC270 C1EA00000026 IC
IC400 C1BB00000541 IC
IC600 C2BBGF000292 IC
IC601 AN8065SE1 IC
IC650 YEAMC14584BE IC
IC702 YEAMPC2910HF IC
IC703 C0CAADG00035 IC
IC704 C0DAZHF00003 IC
IC706 YEAMPC2908HF IC
PA51 C5BA00000092 IC
Q230 B1GBHBEA0004 Transistor
Q231 B1GBHBEA0004 Transistor
Q330 B1GBHBEA0004 Transistor
Q331 B1GBHBEA0004 Transistor
Q400 YEANFP1F3PT1 Transistor
Q401 YEAN2SK536TB Transistor
Q660 B1GDCFJJ0002 Transistor
Q661 B1GDCFJJ0002 Transistor
Q701 YEAND1859T Transistor
Q703 B1BCCG000014 Transistor
Q704 YEANFB1F3PT1 Transistor
Q705 B1BACG000022 Transistor
Q709 B1GDCFJN0004 Transistor
Q716 B1BCCF000017 Transistor
Q717 B1GBCFNL0001 Transistor
Q718 B1BCCF000017 Transistor
Q719 B1GBCFNL0001 Transistor
DIODEs
D701 MA721TX Diode
D702 MA165TA Diode
D703 B0BA5R700006 Diode
D705 MA165TA Diode
D706 YEADDSA3A2 Diode
D707 MA736TX Diode
D708 B0BA8R700011 Diode
D728 YEAD11ES2T Diode
CAPACITORs
C51 ECEA1AKS221I Electrolytic, 220µF 10WV
C52 YECUS1H103KX Ceramic, 0.01µF 50WV
Ref.
No. Part No. Part Name & Description Remarks
C53 YECUS1H273KX Ceramic, 0.027µF 50WV
C56 YECUS1H273KX Ceramic, 0.027µF 50WV
C57 YECUS1H102KX Ceramic, 0.001µF 50WV
C201 F1J1H121A025 Ceramic, 120PF 50WV
C203 ECEA1HKS3R3I Electrolytic, 3.3µF 50WV
C204 ECEA1HKS3R3I Electrolytic, 3.3µF 50WV
C205 ECEA1HKA010I Electrolytic, 1µF 50WV
C208 YECUS1E333KX Ceramic, 0.033µF 25WV
C209 YECUS1H562KX Ceramic, 0.0056µF 50WV
C210 ECEA1CKA470I Electrolytic, 47µF 16WV
C211 YECUS1H103KX Ceramic, 0.01µF 50WV
C212 F1J1H121A025 Ceramic, 120PF 50WV
C230 ECEA1CKS100I Electrolytic, 10µF 16WV
C231 ECEA1CKS100I Electrolytic, 10µF 16WV
C240 ECEA1HKSR47I Electrolytic, 0.47µF 50WV
C241 ECEA1HKSR47I Electrolytic, 0.47µF 50WV
C249 YECUS1H122KX Ceramic, 0.0012µF 50WV
C250 YECUS1H122KX Ceramic, 0.0012µF 50WV
C278 ECEA1CKS470I Electrolytic, 47µF 16WV
C279 ECEA1HKS2R2I Electrolytic, 2.2µF 50WV
C301 F1J1H121A025 Ceramic, 120PF 50WV
C303 ECEA1HKS3R3I Electrolytic, 3.3µF 50WV
C304 ECEA1HKS3R3I Electrolytic, 3.3µF 50WV
C305 ECEA1HKA010I Electrolytic, 1µF 50WV
C308 YECUS1E333KX Ceramic, 0.033µF 25WV
C309 YECUS1H562KX Ceramic, 0.0056µF 50WV
C310 ECEA0JKA101I Electrolytic, 100µF 6.3WV
C311 ECEA1AKS221I Electrolytic, 220µF 10WV
C312 F1J1H121A025 Ceramic, 120PF 50WV
C330 ECEA1CKS100I Electrolytic, 10µF 16WV
C331 ECEA1CKS100I Electrolytic, 10µF 16WV
C340 ECEA1HKSR47I Electrolytic, 0.47µF 50WV
C341 ECEA1HKSR47I Electrolytic, 0.47µF 50WV
C349 YECUS1H122KX Ceramic, 0.0012µF 50WV
C350 YECUS1H122KX Ceramic, 0.0012µF 50WV
C401 YECUS1H150JC Ceramic, 15PF 50WV
C402 YECUS1H150JC Ceramic, 15PF 50WV
C403 ECEA0JKA101I Electrolytic, 100µF 6.3WV
C404 YECUS1H103KX Ceramic, 0.01µF 50WV
C405 F1J1H101A506 Ceramic, 100PF 50WV
C408 YECUS1E223KX Ceramic, 0.022µF 25WV
C409 ECQV1H224JL2 Plastic Film, 0.22µF 50WV
C410 YECUS1H103KX Ceramic, 0.01µF 50WV
C411 ECEA1AKS221I Electrolytic, 220µF 10WV
C413 YECUS1H103KX Ceramic, 0.01µF 50WV
C415 YECUS1H221JC Ceramic, 220PF 50WV
C417 ECEA1AKS221I Electrolytic, 220µF 10WV
C601 YECUS1H150JC Ceramic, 15PF 50WV
C602 YECUS1H180JC Ceramic, 18PF 50WV
C603 YECUS1E104ZF Ceramic, 0.1µF 25WV
C604 YECUS1H103KX Ceramic, 0.01µF 50WV
C605 ECEA0JKS331I Electrolytic, 330µF 6.3WV
C607 EECS5R5T473S Electrolytic, 0.047µF 5.5WV
C612 YECUS1E104ZF Ceramic, 0.1µF 25WV
C613 YECUS1E104ZF Ceramic, 0.1µF 25WV
C631 ECEA0JKS220I Electrolytic, 22µF 6.3WV
C650 YECUS1H103KX Ceramic, 0.01µF 50WV
C660 ECEA0JKS220I Electrolytic, 22µF 6.3WV
C661 YECUS1H103KX Ceramic, 0.01µF 50WV
C690 YECUS1H103KX Ceramic, 0.01µF 50WV
C701 ECEA1CKA101 Electrolytic, 100µF 16WV
C702 ECEA0JKS470I Electrolytic, 47µF 6.3WV
C705 YECUS1H103KX Ceramic, 0.01µF 50WV
C706 YECUS1C104KX Ceramic, 0.1µF 16WV
C707 ECA1CM221I Electrolytic, 220µF 16WV
C710 ECA1CHG102B Electrolytic, 1000µF 16WV
C711 YECUS1C224KX Ceramic, 0.22µF 16WV
C712 ECEA1CKS470I Electrolytic, 47µF 16WV
C714 ECEA0JKS101I Electrolytic, 100µF 6.3WV
C715 YECUS1C224KX Ceramic, 0.22µF 16WV
C716 YECUS1C224KX Ceramic, 0.22µF 16WV
C717 YECUS1C224KX Ceramic, 0.22µF 16WV
C718 ECEA1AKS470I Electrolytic, 47µF 10WV
10
CQ-DPX172U
