Panasonic CQRG131U - AUTO RADIO/CASSETTE User manual

R
CQ-RG131U
●
Please read these instructions carefully before using this product and save this manual for future use.
●
Prière de lire ces instructions attentivement avant d’utiliser le produit et garder ca manuel pour l’utilisation ultérieure.
●
Lea con atención estas instrucciones ante de utilizar el producto y guarde este manual para poderlo consultar en el futuro.
Removable Face High-Power Cassette/Receiver with Changer Control
Récepteur/lecteur de cassettes à puissance élevée avec contrôleur
de changeur et panneau avant amovible
Cassette de alta potencia con placa frontal
Removible/Receptor con mando de cambiadiscos

CQ-RG131U
2
E
N
G
L
I
S
H
Safety Information
Radio Frequency Interference Statement
(Part 15 of the FCC-Rules):
Applies only in U.S.A.
This equipment has been tested and found to comply with the limits for a Class B digital,
pursuant to Part 15 of the FCC Rules.
●These limits are designed to provide reasonable protection against harmful interference in an
automobile installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions may cause harmful
interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by tuning the equipment off and on, the user is
encouraged to consult the dealer or an experience radio technician for help.
FCC Warning:
Any unauthorized changes or modifications to this equipment would void the user's authority to
operate this device.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions.
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received including interference that may cause
undesired operation.
For Canada:
This Class B digital apparatus complies with Canadian ICES-003.
WARNING:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR
MOISTURE.
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, AND ANNOYING
INTERFERENCE, USE ONLY THE
INCLUDED COMPONENTS.
Identification Label
Find the model number and serial number on
either the back or bottom of the unit. Please
record them in the space below and retain this
booklet as a permanent record of your purchase
to help with identificaton in case of theft.
MODEL NUMBER
SERIAL NUMBER
DATE PURCHASED
FROM
CQ-RG131U

CQ-RG131U
3
F
R
A
N
Ç
A
I
S
E
S
P
A
Ñ
O
L
Consignes de sécurité Información para seguridad
MISE EN GARDE:
POUR RÉDUIRE LES RISOUES D'INCEN-
DIE OU D'ÉLECTROCUTION N'EXPOSEZ
PAS CET APPAREIL À LA PLUIE OU À
L'HUMIDITÉ.
AFIN DE PRÉVENIR TOUT RISOUE D'INC-
ENDIE OU D'INTERFÉRECES, UTILISER
UNIQUEMENT LES COMPOSANTS FOUR-
NIS.
ADVERTENCIA:
PARA REDUCIR EL RIESGO DE INCEND-
IOS O SACUDIDAS ELÉCTRICAS, NO
EXPONGA ESTE PRODUCTO A LA
LLUVIA NI A LA HUMEDAD.
PARA REDUCIR RIESGO DE INCENDIOS
O SACUDIDAS ELÉCTRICAS, Y PARA
EVITAR LAS INTERFERENCIAS MOLES-
TAS, UTILICE SOLAMENTE LOS COMPO-
NENTES INCLUIDOS.
l est recommandé de noter, dans l’espace prévu
ci-dessous, les numéros de modèle et de série
inscrits soit à l’arrière soit sous le fond de
l’appareil, et de conserver ce manuel comme
mémorandum de l’achat afin de permettre
l’identification de l’appareil en cas de vol.
NUMÉRO DE MODÉLE
NUMÉRO DE SÉRIE
DATE DE L'ACHAT
VENDEUR
CQ-RG131U
NÚMERO DEL MODELO
NÚMERO DE SERIE
FACHA DE COMPRA
NOMBRE DE LA TIENDA
CQ-RG131U
Busque el número del modelo y el número de
serie ya sea en la parte trasera o en el fondo de
la unidad. Sírvase anotar dichos números en el
espacio siguiente, y mantenga este librete
como una anotación permanente de su compra
para ayudar en la identificación en el caso de
robo.
Déclatalion d'interlerence the frequences
tatllo (Partie 15 des Reglements FCC):
Cst appareil numérique de Classe B est
conforme bu règlement ICES-003 canactten.

CQ-RG131U
4
❏Use This Product Safely
When Driving
Keep the volume level low enough product to be aware of road and traffic conditions.
When Car Washing
Do not expose the product, including the speakers and tapes, to water or excessive moisture. This
could cause electrical shorts, fire, or other damage.
When Parked
Parking in direct sunlight can produce very high temperatures inside your car. Give the interior a
chance to cool down before switching the unit on.
Use the Proper Power Supply
This product is designed to operate of a 12 volt, negative ground battery system (the normal system
in a North American car.)
Protect the Tape Mechanism
Keep magnets, screwdrivers, or other metallic objects away from the tape mechanism and tape
head to prevent poor performance or malfunctions.
Use Authorized Servicenters
Do not attempt to disassemble or adjust this precision product. Please refer to the Servicenter list
included with this product for service assistance.
Panasonic welcomes you to our ever growing family of electronic product owners. We know that this
product will bring you many hours of enjoyment. Our reputation is built on precise electronic and
mechanical engineering, manufactured with carefully selected components and assembled by
people who take pride in their work. Once you discover the quality, reliability, and value we have built
into this product, you too will be proud to be a member of our family.
E
N
G
L
I
S
H

CQ-RG131U
5
Contents
Radio Frequency Interference Statement
(Part 15 of the FCC Rules)......................................................................2
Use This Equipment Safely....................................................................4
❏Power and Sound Controls..............................................................10
How to adjust the volume, mute, balance, and tone for best listening
❏Radio Basics......................................................................................12
Manual and automatic tuning, band selection, preset stations
❏Cassette Tape Player Basics............................................................14
How to load, wind, play, and eject a cassette tape
❏CD Changer Basics...........................................................................16
Play, repeat, random and scan, error messages
Note:
CD changer controls are applicable to units with optional CD changer
unit (sold separately).
❏Clock Basics......................................................................................18
Setting the time, selecting the clock display
❏Installation Guide..............................................................................19
Step-by-step procedures, anti-theft system, electrical connections
❏Troubleshooting................................................................................28
Troubleshooting tips, where to get service help
Specifications .......................................................................................29
E
N
G
L
I
S
H

CQ-RG131U
6
❏Précautions à prendre
Au volant
Régler le volume à un niveau qui ne risque pas de masquer les bruits ambiants.
Lavage de la voiture
Afin de prévenir tout risque de court-circuit ou d’incendie, ne pas exposer l’équipement, y compris
les haut-parleurs et les cassettes, à l’eau ni à une humidité excessive.
Voiture stationnée
L’habitacle d’une voiture immobile exposée au soleil toutes vitres fermées devient rapidement très
chaud. Laisser rafraîchir l’intérieur du véhicule avant d’utiliser l’appareil.
Source d’alimentation
Cet appareil est conçu pour fonctionner sur un système d’alimentation avec batterie de 12 V avec
négatif à la masse (système standard sur les voitures de construction nord-américaine).
Mécanisme de défilement
Ne pas approcher d’aimants, de tournevis ou tout autre objet métallique du mécanisme de
défilement de la bande et de la tête magnétique.
Réparation
Ne pas tenter de démonter ou d’ajuster l’appareil soi-même. Confier toute réparation à un centre de
service agréé.
Panasonic est heureuse de vous compter parmi les utilisateurs de ses appareils électroniques.
Nous pouvons vous assurer que cet appareil vous procurera de longues heures d’agrément. Notre
réputation est fondée sur une ingénierie électronique et mécanique de haute précision laquelle
préside à la fabrication d’appareils ne comportant que des composants de choix assemblés par un
personnel soucieux de la bonne réputation acquise par la qualité de son travail. Après avoir
découvert la qualité, la valeur et la fiabilité de cet appareil, vous aussi serez fier d’être un client
Panasonic.
F
R
A
N
Ç
A
I
S

CQ-RG131U
7
Table des matières
Précautions à prendre............................................................................8
❏Interrupteur et commandes de réglage de la sonorité..................30
Réglage des volume, Mute (assourdissement), balance et tonalité pour
la meilleure écoute
❏Fonctionnement de la radio.............................................................32
Synotonisation manuelle et automatique, sélection de la bande et
stations en mémoire
❏Fonctionnement du lecteur de cassettes .......................................34
Chargement, rebobinage, lecture et éjection de la cassette.
❏Fonctionnement du lecteur-changeur audionumérique................36
Lecture, lecture en reprise, lecture aléatoire et balayage, message
d’erreurs
Remarque:
Les commandes de changeur de disques ne s’appliquent qu’aux auto-
radios auxquels un lecteur-changeur (vendu séparément) est raccordé.
❏Fonctionnement de I’horloge...........................................................38
Réglage de I’heure, sélection de l’affichage de l’horloge
❏Guide d’installation...........................................................................39
Marche à suivre, système antivol, raccordements électriques
❏En cas de difficulté ...........................................................................48
Guide de dépannage, service après-vente
Données techniques.............................................................................49
F
R
A
N
Ç
A
I
S

CQ-RG131U
8
❏Use este equipo de manera segura
Cuando esté conduciendo
Mantenga el nivel del volumen suficiente bajo para poder darse cuenta de las condiciones de tráfico
de la carretera.
Cuando esté lavando el auto
No exponga el equipo, incluso los altavoces y los discos compactos, a la agua o a la humedad
excesiva. Eso podría causar cortocircuitos, incendio u otros daños.
Cuando haya estacionado
El estacionar bajo la luz solar directa produce temperaturas muy altas dentro de su vehículo.
Asegúrese de enfriar el interior del vehículo antes de encender la unidad.
Use la fuente de alimentación apropiada
Este equipo está diseñado para funcionar con un sistema de 12 voltios, de polo negativo puesto a
tierra (el sistema normal en los autos norteamericanos).
Protección del mecanismo de la cinta
Mantenga imanes, destornilladores u otros objetos metálicos lejos del mecanismo de la cinta y de la
cabeza de la cinta para evitar rendimiento pobre o mal funcionamiento.
Use los centros de servicio autorizados
No intente desmontar o ajustar este equipo de precisión. Para solicitar ayuda relativa a los servicios
de mantenimiento, refiérase a la lista de los centros de servicio.
Panasonic le da la bienvenida a la familia constantemente en aumento de poseedores de
productos electrónicos. Nos esforzamos en proporcionarle las ventajas de la ingeniería mecánica y
electrónica de precisión, de una fabricación con componentes cuidadosamente seleccionados, y de
un montaje realizado por personas orgullosas de la reputación que su trabajo ha cimentado para
nuestra empresa. Estamos seguros de que este producto le proporcionará muchas horas de
distracción y, una vez comprobada la calidad, el valor y la fiabilidad incorporados, usted también se
sentirá orgulloso de pertenecer a nuestra familia.
E
S
P
A
Ñ
O
L

CQ-RG131U
9
Indice
Use este equipo de manera segura ......................................................8
❏Alimentación y mandos de sonido..................................................50
Para ajustar el volumen, el silenciamiento, el balance, y el tono para
conseguir una buena recepción
❏Operación básica del radio..............................................................52
Sintonía manual y automática, selección de la banda, estaciones
presintonizadas
❏Operación básica del tocacintas de cassette.................................54
Cómo cargar, enrollar, tocar y expulsar una cinta cassette.
❏Conocimientos básicos cambiadiscos de CD................................56
Reproducción, repetición, al azar y exploración, mensajes de errores.
Note:
Los mandos del cambiadiscos de CD son aplicables a la unidad con
cambiadiscos de CD opcional (vendido separadamente).
❏Operación básica del reloj ...............................................................58
Ajuste de las horas y selección de la visualización del reloj.
❏Guía de instalación...........................................................................59
Procedimientos paso a paso, sistema anti-robo, conexiones eléctricas
❏Localización de avería......................................................................68
Sugerencias para localización de averías, donde obtener ayuda de
servicio.
Especificaciones...................................................................................69
E
S
P
A
Ñ
O
L

CQ-RG131U
10
E
N
G
L
I
S
H
1
Power and Sound Controls
LOUD
LOUD
Power
Turn the key in the ignition until the accessory indicator lights.
Press [PWR] to switch on the power.
LOUD
Volume
●Press [VOL jj] or [VOL ii]to increase or decrease volume.
0 to 39
Volume Level
●Press [VOL jj] or [VOL ii]for more than 0.5 second to
change numeric levels on the display rapidly.
LOUD
LOUD
Mute
●Press [MUTE] to decrease volume level.
●“MUTE” blinks while this operation.
●Press [MUTE] again to cancel.
LOUD
LOUD
Tone Enhancement
●Press and hold [MUTE] (LOUD) for more than 2 seconds to
enhance bass and treble tones when listening at low or medium
volume.
●Press and hold [MUTE] (LOUD) for more than 2 seconds again
to deactivate when listening at higher volumes.
Note: This unit is equipped with an anti-volume-blast circuit which serves as an automatic
volume level adjuster so that you will not be deafened with sudden loud volume.
This system operates as follows. When [PWR] is switched on, the volume level is low. After that,
the volume level gradually returns to the level as the same as the one before turning off.
Anti-volume-blast circuit is not effective when volume level is lower than position 20 at the display.
Press and hold

CQ-RG131U
11
E
N
G
L
I
S
H
2
LOUD
Changing Audio Modes
Press [SEL] to switch the audio modes as follows.
VOL aBAS aTRE
(Volume) (Bass) (Treble)
cd
FAd bBAL
(Fader) (Balance)
LOUD
Bass and Treble
Press [SEL] to select the BASS (TREBLE) mode. Press [VOL jj]
or [VOL ii]to increase or decrease the bass/treble response.
–12 to 12 –12 to 12
Balance
Press [SEL] to select the BALANCE mode. Press [VOL jj]or
[VOL ii]to shift the sound volume to the right or left speakers.
1 to 15R or L Balance Center
Fader
Press [SEL] to select the FADER mode. Press [VOL jj]or [VOL
ii]to shift the sound volume to the front or rear speakers.
1 to 15F or R Fader Center
LOUD
Note: When a control mode (BAS/TRE/BAL/FAd) is selected but no operation is made within 5
seconds (2 seconds at volume mode), the display will return to the normal operation (Radio,
Cassette, etc.) mode. In such a case, press [SEL] again to select the next control mode.
d
(R: Right, L: Left)
(F: Front, R: Rear)

CQ-RG131U
12
E
N
G
L
I
S
H
3
Radio Basics
LOUD
LOUD
LOUD
D
Change to the tuner mode
In case of Tape mode ..............................Eject a tape.
In case of CD Changer mode ..................Press [BAND].
LOUD
Selecting a Band
Press [BAND] to select the band as follows.
FM1 aFM2 aFM3 aAM
cd
"ST" indicator lights if the station is broadcasting in stereo.
LOUD
LOUD
Manual Tuning
Press [TUNE jj]or [TUNE ii]to move to a higher or lower
frequency.
Seek Tuning
Press and hold [TUNE jj] or [TUNE ii]for more than 0.5
second, then release. The radio automatically stops on the next
station.
To reduce interference during
FM broadcasts (MONO)
Press [MONO] for monaural reception in case a lot of interference
is present in an FM stereo signal or to improve the listening quality
of weak FM broadcasts. To turn it off, press [MONO] again.
Hold and release

CQ-RG131U
13
E
N
G
L
I
S
H
4
Manual Station Preset
Press [BAND] to select a desired band.
Use manual or seek tuning to find a station that you want to
program into memory.
Press and hold one of the station selector buttons 1 through 6
until the display blinks. The memory is now set for that button
on the band you have selected.
Repeat the process to set other stations for the FM1 to AM
bands.
Auto Preset Memory
Select a band, and press and hold [BAND] (APM) for more than 2
seconds.
●The 6 strongest available stations will be automatically set in
memory on preset buttons [1] through [6].
●Once set, the preset stations are sequentially scanned for 5
seconds.
●Press the appropriate preset button for the station you want to
hear.
Note: The stations manually preset on the selected band will be
deleted.
Note: You can change the memory setting by repeating the above
procedure.
Preset Station Setting
Up to 24 stations can be preset in the station memory as follows;
FM1 FM2 FM3 AM
6 stations 6 stations 6 stations 6 stations
LOUD
LOUD
LOUD
Preset Number
LOUD


Press and hold
d
d
d
Caution: For safety reasons, do not attempt to program while driving.
Tuning in a Preset Station
Press any of the buttons [1] through [6] to tune in the station
preset by the above steps to .
LOUD

Press and hold

CQ-RG131U
14
E
N
G
L
I
S
H
5
Cassette Tape Player Basics
LOUD
LOUD
LOUD
OUD
Loading a Cassette
Gently insert a cassette with the exposed tape side facing to the
right until the mechanism captures it, and playback starts.
Program Indicator
(This indication “ ” rotates.)
Rewind and Fast Forward
When the program indicator lights, press [ ]to rewind or
press [ ]to fast forward the tape.
When the program indicator lights, press [ ]to fast forward or
press [ ]to rewind the tape.
To stop rewind or fast forward, gently press the button that is not in
use.
The tape will resume playing from that position.
Changing Sides
Press [ ]and [ ]at the same time to switch to the program
on the other side of the tape.
The display changes to indicate which program is playing.
Top Side Playing Bottom Side Playing
Press Both
“” light : Fast Forward
“” light : Rewind
“” light : Rewind
“” light : Fast Forward
Exposed Tape

CQ-RG131U
15
E
N
G
L
I
S
H
6
LOUD
LOUD
Stopping and Ejecting the
Tape
Once inserted into the unit, your tape will play continuously until
you eject it.
If you press [u](EJECT), the unit ejects the tape and returns to
radio operation.
When you stop the car engine, the tape will stop but not be
ejected.
Notes:
●You can not change to CD Changer mode or Radio mode while
tape playing. If you want to change to CD Changer mode or
Radio mode, eject the tape.
●Always remove the cassette when you stop using the cassette
player. This will prolong the life of your tape.
Notes on Cassette Tapes
Pencil
Do not touch
or pull out
the tape.
Tape Slack:
Use a pencil or similar object to take up the slack
as shown. If a loose tape is used, this may result
in the tape becoming tangled in the rotating
parts of the unit.
Notes:
●To maintain your cassette player in top condition, avoid using tapes that are longer than 90
minutes (C-90).
●If you insert into the unit a cassette with a loose tape caused by forcing it into cassette with a
finger or the like, the cassette may not be properly reproduced. In such a case, eject the
cassette, make the tape tigt, then insert it back into the deck.

CQ-RG131U
16
E
N
G
L
I
S
H
7
CD Changer Basics
Note:
CD changer functions are applicable to units with optional CD changer unit.
(sold separately)
LOUD
LOUD
To Changer mode
While a disc magazine inserted in the CD changer, press [CD·C].
Play starts from the first track.
LOUD
LOUD
Selecting a Disc
Press [DISCjj]or [iiDISC] to select discs in ascending or
descending order.
Selecting a Track
Press [TRACK  ]once to go to the next track. Press repeatedly
to step forward through all the tracks.
Press [TRACK  ]once to play from the beginning of the current
track. Press twice to play the previous track. Press repeatedly to
step backward through all the tracks.
Note: The cassette, if loaded, should be removed. Otherwise,
the CD play will not start.
LOUD
Play
Time Disc Number Track Number

CQ-RG131U
17
E
N
G
L
I
S
H
8
❏Error Display Messages
Searching a Track
Press and hold [TRACK  ]or [TRACK  ]for more than 0.5
second to activate fast forward or reverse through a track. Release
[TRACK  ]or [TRACK  ]to resume the normal CD play from
that position.
LOUD
Repeating a Track
●Press [4] (REPEAT) to repeat the current selection. “REPEAT”
indicator lights.
●The current selection continues to repeat until you press [4]
(REPEAT) again.
Hold and release
LOUD
Random Selection
●Press [5] (RANDOM) to random selection of music is played
from all available CDs. “RANDOM”indicator lights.
●To turn it off, press [5] (RANDOM) again.
Scanning Tracks
●Press [3] (SCAN). The track number blinks and the first 10
seconds of each track on the discs play in sequence.
●To stop scanning and continue with the current track, press [3]
(SCAN) again.
LOUD
Scanning Discs
Press and hold [3] (SCAN) for more than 2 seconds. The 1st track
of all the discs in the magazine is played for 10 seconds each.
Also, Disc Number blinks at the same time. To stop the current
play of the disc scanning, press and hold [3] (SCAN) for more
than 2 seconds again.
LOUD
Displays when the compact disc is
dirty or upside down. Selects the
next available compact disc.
Displays when compact disc is
scratched. Selects next available
compact disc.
Displays when the compact disc
stops operating for some reason.
Please contact your nearest
autorized panasonic Serviceter.
Displays when there is no disc in
the magazine.

CQ-RG131U
18
E
N
G
L
I
S
H
9
Clock Basics
(The clock system is 12-hours.)
LOUD
LOUD
Initial Time Setting
Press [DISP]. “AdJ”is displayed.
Press and hold [DISP] again for more
than 2 seconds. “12”blinks indicating
the time setting mode is activated.
To set hours, press [jj]or [ii].
Press [DISP] again for minute setting.
To set minutes, press [jj]or [ii].
Hold [jj]or [ii]to change numbers
rapidly.
When you have set the time, press
[DISP].
d
d
Resetting the Time
When you want to reset the time, press and hold [DISP] for more
than 2 seconds to activate the time setting mode. Then, repeat
step to above.
Selecting the Clock Display
Press [DISP] for clock display.
Press [DISP] once again, the current audio display mode
resumes.
LOUD






Press and hold
Press and hold

CQ-RG131U
19
E
N
G
L
I
S
H
10
●Warranty Card . . . . . . . . . . . . .Fill this out promptly
●Panasonic Servicenter for service
Directory . . . . . . . . . . . . . . . . .Keep this for future reference in case the unit needs servicing
●Installation Hardware . . . . . . .Needed for in-dash installation
Installation Guide
This installation information is designed for experienced installers
and is not intended for non-technical individuals. It does not contain
warnings or cautions of potential dangers in attempting to install
this product.
Any attempt to install this product in a motor car by anyone other
than qualified installer could cause damage to the electrical system
and could result in serious personal injury or death.
WARNING
❏Overview
This product should be installed by a
professional. However, if you plan to install this
unit yourself, your first step is to decide where
to install it. The instructions in these pages will
guide you through the remaining steps: (Please
refer to “WARNING”statement above).
●Identify and label the vehicle wires.
●Connect the vehicle wires to the wires of the
power connector.
●Install the unit in the dash.
●Check the operation of the unit.
If you do encounter problems, please consult
your nearest professional installer.
Caution: This unit will operate with a 12 volt
DC negative ground auto battery system only.
Do not attempt to use it in any other systems.
Doing so could cause serious damage.
Before you begin installation, look for the
following items included in the packing with
your unit.
❏Installation Hardware
No.
1
1
1
1
1
1
1
1







Item
Mounting Collar
Hex. Nut (5 mmφ)
Rear Support Strap
Tapping Screw
(5 mmφx 16 mm)
Mounting Bolt (5 mmφ)
Power Connector
Dismounting Plate
Removable Face
Plate Case
Diagram Q’ty

CQ-RG131U
20
E
N
G
L
I
S
H
11
❏Required Tools
You'll need a screwdriver, a 1.5 volt AA battery,
and the following:
❏Dashboard Specifications
Power Lead
If your car has a radio or is pre-wired for one:
Cut the connector wires one at a time from the
plug (leaving the leads as long as possible) so
that you can work with individual leads.
Turn the ignition on to the accessory position,
and ground one lead of the test bulb to the
chassis.
Touch the other lead of the test bulb to each of
the exposed wires from the cut radio connector
plug. Touch one wire at a time until you find the
outlet that causes the test bulb to light.
Now turn the ignition off and then on. If the bulb
also turns off and on, that outlet is the car
power lead.
If your car is not wired for an audio unit :
Go to the fuse block and find the fuse port for
radio (RADIO), accessory (ACC), or ignition
(IGN).
Battery Lead
If your stereo unit has a yellow lead, you will
need to locate the car’s battery lead. Otherwise
you may ignore this procedure. (The yellow
battery lead provides continuous power to
maintain a clock, memory storage, or other
function.)
If your car has a radio or is pre-wired for one:
With the ignition and headlights off, identify the
car battery lead by grounding one lead of the
test bulb to the chassis and checking the
remaining exposed wires from the cut radio
connector plug.
If your car is not wired for an audio unit :
Go to the fuse block and find the fuse port for
the battery, usually marked BAT.
THICKNESS
MIN. 3/16" (4.75 mm)
MAX. 7/32" (5.56 mm)
7-5/32" (182mm)
2-3/32" (53 mm)
❏Identify All Leads
The first step in installation is to identify all the
car wires you’ll use when hooking up your
sound system.
As you identify each wire, we suggest that you
label it using masking tape and a permanent
marker. This will help avoid confusion when
making connections later.
Note: Do not connect the power connector to
the stereo unit until you have made all
connections. If there are no plastic caps on the
stereo hooking wires, insulate all exposed leads
with electrical tape until you are ready to use
them. Identify the leads as follows.
12 V DC
TEST BULB ELECTRICAL TAPE SIDE-CUT PLIERS
Installation Guide continued
