Panasonic CR-W405U User manual

© Panasonic Corporation 2010.
Unauthorized copying and distribution is a
violation of law.
ORDER NO. ACED091202CE
C1
Model No. CR-W405U
Weather Band Receiver
TABLE OF CONTENTS PAGE PAGE
1 Service Navigation----------------------------------------------- 2
2 Specifications ----------------------------------------------------- 3
3Features------------------------------------------------------------- 4
4 Technical Descriptions ----------------------------------------- 5
5 Block Diagram----------------------------------------------------10
6 Wiring Connection Diagram ---------------------------------11
7 Schematic Diagram---------------------------------------------12
8 Printed Circuit Board-------------------------------------------15
9 Exploded View and Replacement Parts List -----------20
10 Schematic Diagram for Printing with Letter Size-----26
crw405u.book Page 1 Thursday, January 14, 2010 2:17 PM

2
1 Service Navigation
1.1. About Lead Free Solder(PbF)
Distinction of PbF PCB
• PCBs(manufacture)using lead free solder will have a PbF stamp on the PCB.
Caution
• Pb free solder has a higher melting point than standard solder; Typically the melting point is 50 - 70°F (30 - 40°C) higher. Please
use a soldering iron with temperature control and adjust it to 700 ± 20°F (370 ± 10°C). In case of using high temperature solder-
ing iron, please be careful not to heat too long.
• Pb free solder will tend to splash when heated too high (about 1100°F/600°C)
1.2. Maintenance
Your products is designed and manufactured to ensure a minimum of maintenance. Use a dry, a soft cloth for routine exterior clean-
ing. Never use benzine, thinner or other solvents.
1.3. Notes
[RADIO BLOCK]
Do not align the AM/FM package block. When the package block is necessary, it will be supplied already aligned at the factory.
crw405u.book Page 2 Thursday, January 14, 2010 2:17 PM

3
2 Specifications
2.1. Specfications
2.2. Dimensions
General
Power Supply :
12V DC (11V - 16V), Test Voltage 14.4 V
Negative Ground
Current consumption :
Less than 2.5 A (0.5 W 4-speaker)
Maximum Power Output :
37W ×4 channels at 400 Hz, Vol- ume Control Maximum
Tone adjustment range: Bass : ±12 dB at 100 Hz
Treble : ±12 dB at 10 kHz
Power Output : 18 W per channel into 4Ω, 40 to
30,000 Hz at 3% THD
Suitable Speaker Impedance : 4 Ω
Dimensions (W×H×D) :
178 mm ×50 mm ×160 mm {7” x 1-15/16“ x 6-5/16“}
Weight : 0.9 kg { 1 lbs. 16 oz. }
Front AUX Input
Input impedance : 10 kΩ
Allowable external input : 2.0 V
Connector : 3.5 mm stereo mini pin
Audio input sensitivity : 200 mVrms
FM Stereo Radio
Frequency Range : 87.9 MHz-107.9 MHz
Usable Sensitivity : 12 dBf (1.1μV/ 75Ω, S/N 30dB)
50 dB Quieting Sensitivity : 17 dBf (1.8μV/ 75Ω)
Frequency Response : 30-15,000 Hz ± 3 dB
Alternate Channel Selectivity : 75 dB
Stereo Separation : 35 dB at 1 kHz
Signal/Noise Ratio : 70 dB (Mono)
AM Radio
Frequency Range : 530 kHz-1710 kHz
Usable Sensitivity : 28 dB/μV (25uV, S/N 20 dB)
Weather Band Radio
Frequency Range : 162.400 MHz - 162.550 MHz
Usable Sensitivity : 3 dB/μV (S/N 20 dB)
Signal/Noise Ratio (40 dB/μV) : 50 dB
* Specifications and the design are subject to possible modification
without notice due to improvements.
** Dimensions and Weight shown are approximate.
crw405u.book Page 3 Thursday, January 14, 2010 2:17 PM

4
3 Features
• Front AUX terminal.
• Sound Control(FLAT,ROCK,POP and VOCAL).
• Illumination interlock control.
crw405u.book Page 4 Thursday, January 14, 2010 2:17 PM

5
4Technical Descriptions
4.1. Terminals Description
4.1.1. Main Block
IC601:LC723781XX02
Note 1 :
Voltage measuerments are with respect to ground,
with a voltmeter (internal resistance : 10MΩ).
4.1.2. Display Block
IC901:C0HBA0000225
PIN
No. Port Description I/O FM (V) AM (V) WB (V)
1 XIN Main system clock signal
input. I 2.53 2.53 2.54
2 TEST2 Test terminal 2. I 0 0 0
3 VREG Regulator output bypass
condensor connected. O333
4 VSSCPU GND -- 0 0 0
5 N.C. Not connection. O 0 0 0
6 N.C. Not connection. O 0 0 0
7 N.C. Not connection. O 0 0 0
8 N.C. Not connection. O 0 0 0
9 LCD_DO LCD data signal output. I 5.17 5.17 5.17
10 LCD_DI LCD data signal input. O 0 0 0
11 LCD_CLK LCD clock signal output. O 5.13 5.16 5.16
12 LCD_CE LCD chip enable signal out-
put. O000
13 N.C. Not connection. O 0 0 0
14 N.C. Not connection. O 0 0 0
15 PDM_SCK Radio preset direct memory
EEPROM I2C clock signal
output.
O 5.16 5.17 5.15
16 PDM_SDA Radio preset direct memory
EEPROM I2C data signal
input.
I/O 5.15 5.16 5.17
17 N.C. Not connection. O 0 0 0
18 N.C. Not connection. O 0 0 0
19 N.C. Not connection. O 0 0 0
20 N.C. Not connection. O 0 0 0
21 N.C. Not connection. O 0 0 0
22 N.C. Not connection. O 0 0 0
23 N.C. Not connection. O 0 0 0
24 N.C. Not connection. O 0 0 0
25 N.C. Not connection. O 0 0 0
26 N.C. Not connection. O 0 0 0
27 N.C. Not connection. O 0 0 0
28 N.C. Not connection. O 0 0 0
29 N.C. Not connection. I 0 0 0
30 N.C. Not connection. I 0 0 0
31 N.C. Not connection. I 0 0 0
32 N.C. Not connection. I 0 0 0
33 N.C. Not connection. O 0 0 0
34 N.C. Not connection. O 0 0 0
35 N.C. Not connection. O 0 0 0
36 N.C. Not connection. O 0 0 0
37 N.C. Not connection. O 0 0 0
38 N.C. Not connection. O 0 0 0
39 VDDPORT VDD +5V -5.16 5.16 5.16
40 VSSPORT GND -000
41 N.C. Not connection. O 0 0 0
42 N.C. Not connection. O 0 0 0
43 N.C. Not connection. O 0 0 0
44 N.C. Not connection. O 0 0 0
45 N.C. Not connection. O 0 0 0
46 N.C. Not connection. O 0 0 0
47 N.C. Not connection. O 0 0 0
48 N.C. Not connection. O 0 0 0
49 PWR_CNT Power-on control signal
output. O 5.15 5.15 5.15
50 AMP_STB Amp stby control signal out-
put. O 5.15 5.15 5.15
51 AMP_MUT
EAmp mute control signal. O 0 0 0
52 N.C. Not connection. O 0 0 0
53 SSC Tuner search sensitivity
change. O 5.15 5.15 5.15
54 AF_MUTE AF mute control signal out-
put(Pre-out). O000
55 E-
VOL_I2C_S
DA
Electronic Vol-IC data con-
trol signal. I/O 5.16 5.16 5.15
56 E-
VOL_I2C_S
CK
Electronic Vol-IC clock con-
trol signal. O 5.16 5.16 5.15
57 ILL_CNT ILLM PWM control signal
input. I0.30.30.3
58 POWER_L
ED Power LED signal control. O 0.17 0.15 0.15
59 ILL_PWM ILLM PWM control signal
output. O0.30.30.3
60 N.C. Not connection. O 0 0 0
61 ILL_P_SEN
SBacklight ILLM on/off con- trol signal detection input. I 5.21 5.21 5.21
62 N.C. Not connection. O 0 0 0
63 N.C. Not connection. O 0 0 0
64 N.C. Not connection. O 0 0 0
65 N.C. Not connection. O 0 0 0
66 N.C. Not connection. O 0 0 0
67 BATT Battery power connected
signal detection. I 5.17 5.17 5.17
68 MODE_B Rotary clock signal B out-
put. I 5.13 5.13 5.13
69 N.C. Not connection. O 0 0 0
70 N.C. Not connection. O 0 0 0
71 MODE_A Rotary clock signal A out-
put I 5.13 5.13 5.13
72 N.C. Not connection. O 0 0 0
73 WB_MODE Wbpower control signal
output. O880
74 N.C. Not connection. O 0 0 0
75 RADIO_MO
DE Radio power control signal output. O008.35
76 FM/AM SW FM/AM control signal out-
put. O080
77 N.C. Not connection. I 0 0 0
78 ST_SW Steering sw A/D control sig-
nal input. I000
79 BATT_LEV
EL Battery voltage level detec- tion signal input. I 4.04 4.04 4.04
80 N.C. Not connection. I 0 0 0
81 VSSADC GND -- 0 0 0
82 N.C. Not connection. I 0 0 0
83 ST FM stereo signal input I 5.23 5.23 1.48
84 VSM FM/AM SD signal input. I 0 0.5 0
85 N.C. Not connection. I 0 0 0
86 RESET Reset signal input I 5.17 5.17 5.17
87 ACC ACC power connected sig-
nal detection I5.35.35.3
88 N.C. Not connection. I 0 0 0
89 N.C. Not connection. I 0 0 0
90 FM/AM_IFC FM/AM IFC signal input I 0 0 0
91 N.C. Not connection. I 0 0 0
92 SUBPD None O 1.5 1.47 0
93 VDDPLL Power supply of PLL -5.17 5.17 5.17
94 WB OSC WB local oscillator signal
input. I001.49
95 OSC_FM/
AM FM/AM OSC signal input I 1.49 1.49 0
96 VSSPLL GND -000
97 N.C. Not connection. O 0 0 0
98 EO1 PLL phase comparison
error output O 1.47 1.45 1.38
99 TEST1 Test terminal 1. -000
100 XOUT Main system clock crystal
connection. O 2.62 2.62 2.62
PIN
No. Port Description I/O FM
(V) AM (V) WB (V)
crw405u.book Page 5 Thursday, January 14, 2010 2:17 PM

6
PIN No. Port Description I/O (V)
1-35 SEG1-35 LCD segment. O 2.5
36-39 NC No connection. -0
40-43 COM1-4 LCD common. O 2.5
44-49 KS1-6 Key data output. O 0.9
50-54 KI1-5 Key data input. I 0
55 TEST Connecting to ground. -0
56 VDD +5V power supply. -5.1
57 VDD1 Ground through capacitor. -3.3
58 VDD2 Ground through capacitor. -1.7
59 VSS Ground. -0
60 OSC CR oscillator. -3.9
61 DO Key data output. O 4.4
62 CE Chip enable. I 0
63 CLK LCD clock. I 0
64 DI LCD data input. I 0
crw405u.book Page 6 Thursday, January 14, 2010 2:17 PM

7
4.2. IC Block Diagram
4.2.1. Main Block
P50:C5BA00000122
P51:J3CZAB000001
crw405u.book Page 7 Thursday, January 14, 2010 2:17 PM

8
IC201:C1EA00000042
IC301:C1BB00000543
crw405u.book Page 8 Thursday, January 14, 2010 2:17 PM

9
IC602:C3EBCY000018
IC701:C0DAZHF00004
crw405u.book Page 9 Thursday, January 14, 2010 2:17 PM

10
5 Block Diagram
P5 0
FM/AM TUNER
FM ANT
L-CH
SDA
SCL
SDA
SCL
ST
FM/AM OSC
AM ANT
ANT1
R-CH
IC301
CAR AUDIO PROCESSOR
FL
RL
IC601
SYSTEM CONTROL
CR-W405U
IC201
POWER AMP
CN701
FL+
FL-
FR+
FR-
RR+
RR-
ACC
RL+
RL-
BATT
E-4C385
ACC
RR
FR
6
8
2
4
2425
10
12
14
16
1
15
3,5,7
31~34
GND
IC701
REGULATOR IC
7
3
4
5
6
8
10
11
12
14
ANT-CNT
ACC-IN
VDD +5V
SW+5V
ACC-OUT
VCC
AUDIO +9V
CTRL
CD 8V
ILL +9V
VSM
VDD
VCC
LCDDI/DO
/CLK/CE
3
FL+
FL-
RL+
RL-
FR+
FR-
RR+
RR-
49
78
53 54
51 83 70 84
16
15
58 39
26
21
20
19
18
12
13
1
2
67
FL
RL
RR
FR
11
12
14
15
5
3
21
23
9
7
17
19
P.LED
MODEA,B
VCC
7
Q51 Q50
11
10 6
7
8114 2451214
9
E-VOL IC
50
Q52 +9V
36PIN ISO
CONNECTOR
NO FUSE
15
GND
98
ST-SW
P51
Weather Band TUNER
ANT VT
4
1
8
5
2
+B
36
7
620
8
L
R
L
R
3
4
9
AF
L
R
L
R
5
6
MODE FM/AM
7675
AM/FM SW
RADIO MODE
6871 93
EO1
6
VT
CHARGE
PUMP
Q53
Q55
Q52 +9V
73
WB_MODE
87
BATT
Q701/Q702
PWM
BLOCK
11
PWM-IN
VDD
16
S-METER
SD
910 11 12
ST-SW
26
PWR-CNT
4
AMP-STB
22
AMP-MUTE
EEPROM
IC602
PDM_SCK
PDM_SDA
SW +5V
WB OSC
94
WB_OSC
9
FM/AM OSC
ST
17
VDD +5V
SW +5V
310 14
AUDIO +9V
15
GND
AUDIO +9V
Q301
Q303
Q302
Q304
Q305
Q306
AF-MUTE(PRE)
VDD +5V
54
AF-MUTE
ILL-P-SENS
13
PAR K LIGHTS
E-4C386
LCD901
IC901
LCD DRIVER
LCD DI/DO/CD/CLK
KEY MATRIX
CN903
AUX-IN
1214
9
310 6
7
824
AUX-IN
L/R CH
ILL +8V
VDD +5V
P. L E D
D919
5
LCD COM
LCD SEGMENT
VR901
MODE A/B
Q901
114
SEL
VDD +5V
GND
LR
RADIO-L
RADIO-R
WB
WB
AUX-R
AUX-L
61
57 ILL-CNT
ILL-PWM
ILL-PWM
59
CN800
CN901

11
6 Wiring Connection Diagram
POWER
CONNECTOR
FL+
FL-
FR+
FR-
RL+
RL-
RR+
RR-
BATTERY
ACC
GROUND
Illum_In
Parklights-In
CN701 36P ANT1
CN800 14P
CN901 14P
Main PCB
[E-4C385]
Display PCB [E-4C386]
4 SPK
CN903
AUX-IN
Steering-Sw
crw405u.book Page 11 Thursday, January 14, 2010 2:17 PM

12
7 Schematic Diagram
7.1. Main Block
E-4C385
The following symbols are
shown on the schematic diagram.
The following symbols are
shown on the schematic diagram.
AUDIO
AUDIO
9V
9V
8V
8V
5V
5V
3.3V
3.3V
3.3V
3.3V
ACC
ACC
+B
+B
9V
9V
8V
8V
5V
5V
CR-W405U MAIN
CN701
YEAE4CIS0003
IC201 C1EA00000042 POWER IC
IC301
C1BB00000543
P50 C5BA00000122 FM/AM TUNER
P51 J3CZAB000001
IC701 C0DAZHF00004
CN800
K1KA14A00173
IC601
LC723781XX02
E-VOL
4.53
4.55 4.51
4.51 4.51
4.53 4.56 4.49
4.51
4.53
4.52 4.52
4.59 0
4.59
4.59
4.59
4.59 4.59
4.59
4.61
4.94 5.2
5.2
9.12
4.59 4.59
0
0
3.86
3.86
0
0
3.86
0
0
3.86
0
0
0
6.87
0
5.13
6.87
13.47
6.87
0
6.87
6.71
6.87
6.74
0
6.74
6.64 6.85
6.87
0
6.87
13.47
6.87
0
6.87
0
2.42
8.99
8.7
8.09
8.7
8.9
0
8.96
0.56
0
5.2
0
0
0
0 0 0 0
1.37
8.03
8
0 0 0
3.63
00
3.61
0
0
0.11
0 0 0 0 0
8
8.03
0
8.19
8.03
0.15
8.99
8.86
1.47
1.4
0
4.78
0
8.28 3.23
0
0
00
1.81
0
0
0
8.19
8.18
0
0
00
0
0
5.16
5.16
0
5.24
12.48 12.48
4.7
5.9
5.3 5.3
13.1
5.1
5.8
9.1
5.1
8
1.28
9 0
5.2
5.18
0
0
0.87
0
3.87
3.97
0
To DISPLAY E-4C386 CN901
RR
RL
FL
FR
FR
RR
RL
FL
FR
RR
RL
FL
FR
RR
RL
FL
FR
RR
RL
FL
FR
RR
RL
FL
FR
RR
RL
FL
AUX-L
4.51
AUX-R
WB-L WB-R
RADIO-L
RADIO-R
FR
FL
RL
RR
LR
LR
LR
LR
LR
L
R
L
R
L
R
L
R
L
R
RADIO (L,R)
RADIO (L,R)
LR
L
R
L
R
L
R
L
R
L
R
L
R
L
R
L
R
L
R
5V 5V5V
5V
5V
5V
5V5V5V
5V
5V 5V
5V5V
5V5V
5V5V
5V
5V5V5V5V
5V5V5V
5V
5V5V5V5V5V
5V5V
9V
9V9V9V9V9V
9V9V9V 9V
9V9V
9V
9V
9V 9V
9V 9V
9V
9V
ILLILL
ILLILL
ILLILL
ILLILLILL
5V
9V
5V
5V 5V
5V
9V
9V
8.19
8V
8V8V
8V8V
WBWBWBWBWBWBWB
WBWB
WB
5V
5V
2V/Div,1ms/Div
2V/Div,1ms/Div
2V/Div
2V/Div 1mS/Div
2V/Div,1mS/Div
2V/Div,1ms/Div
RR
RL
FL
FR
8.2K

13
7.2. Display Block
E-4C386
The following symbols are
shown on the schematic diagram.
The following symbols are
shown on the schematic diagram.
AUDIO
AUDIO
9V
9V
8V
8V
5V
5V
3.3V
3.3V
3.3V
3.3V
ACC
ACC
+B
+B
9V
9V
8V
8V
5V
5V
CR-W405U DISPLAY
CN903
K2HC1YYA0020
AUX-IN
IC901
C0HBA0000225
LCD901 YEXDCM4C126
VR901
K9AA024A0014
CN901
K1KB14AA0173
To MAIN E-4C385 CN800
LR
LR
9V
9V
9V
9V
9V
9V
5V 5V 5V
5V 5V
9V
LR
YEADLPA675
YEAD19213BPC
YEAD19213BPC
9V 9V
820
390
390
330 430 430
470
300
D921
D920
D932
D930
D928
D925
D929
D927
D926 D924
D923
820
R929
R926
430
430
R928
R931
430
430
R925

14
7.3. Iso Block
15
u
8
B
26 17
a
33
F
e
t
2
2528
p
1
35 32
r
24
y
D
27
v
h
4
13
34
7
6
21
31
11
E
z
10
29
16
w
23
3
lnx
c
b
19
14
36
A
HG
22
j
9
18
5
C
20
30
12
df
FUSE
FUSE
gk
imq
s
o
E-4C392
CR-W405U ISO
a Battery
LR+(Speaker)
Power Ground
b
c
d
e
gPower Ground
LF+(Speaker)
f
h
j
i
k
m
l
p
o
n
q
LR-(Speaker)
Power Ground
LF-(Speaker)
Dim PWM/ANALOG
RF+(S pea ker)
RF-(Speaker)
Park Lights
RR+(Speaker)
Ignition(ACC)
RR-(Speaker)
A
D
r
H
u
t
C
G
v
B
E
w
F
y
z
s
x
ASWC
N/C
N/C
Power Ground
Power Ground
Power Ground
Power Ground
PIN DESCRIPTION
7
15
16
13
8
14
5
11
6
12
3
9
4
10
1
32
2
26
27
25
24
23
21
18
20
31
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C
N/C

15
8 Printed Circuit Board
8.1. Main Block (Top View)
[E-4C385][Top View]
CR-W405U MAIN P.C.B
crw405u.book Page 15 Thursday, January 14, 2010 2:17 PM

16
8.2. Main Block (Bottom View)
[E-4C385][Bottom View]
CR-W405U MAIN P.C.B
crw405u.book Page 16 Thursday, January 14, 2010 2:17 PM

17
8.3. Display Block
CR-W405U DISPLAY P.C.B
[E-4C386][Top View] [E-4C386][Bottom View]
crw405u.book Page 17 Thursday, January 14, 2010 2:17 PM

18
8.4. Iso Block (Top View)
[E-4C392][Top View]
CR-W405U ISO P.C.B
crw405u.book Page 18 Thursday, January 14, 2010 2:17 PM

19
8.5. Iso Block (Bottom View)
[E-4C392][Bottom View]
CR-W405U ISO P.C.B
crw405u.book Page 19 Thursday, January 14, 2010 2:17 PM

20
9 Exploded View and Replacement Parts List
9.1. Exploded View (Unit)
crw405u.book Page 20 Thursday, January 14, 2010 2:17 PM
