Panasonic SiriusXM CQ-RXBT490U User manual

© Panasonic Corporation 2012.
Unauthorized copying and distribution is a
violation of law.
ORDER NO. ACED120302CE
C1
Model No. CQ-RXBT490U
WMA MP3 CD Player/Receiver
TABLE OF CONTENTS PAGE PAGE
1 Service Navigation----------------------------------------------- 2
2 Specifications ----------------------------------------------------- 3
3Features------------------------------------------------------------- 4
4 Technical Descriptions ----------------------------------------- 5
5 Block Diagram----------------------------------------------------18
6 Wiring Connection Diagram ---------------------------------19
7 Schematic Diagram---------------------------------------------20
8 Schematic Diagram---------------------------------------------23
9 Printed Circuit Board-------------------------------------------26
10 Exploded View and Replacement Parts List -----------33
11 Schematic Diagram for Printing with Letter Size-----44
cqrxbt490u.book Page 1 Friday, April 6, 2012 9:48 AM

2
1 Service Navigation
1.1. About Lead Free Solder(PbF)
Distinction of PbF PCB
• PCBs(manufacture)using lead free solder will have a PbF
stamp on the PCB.
Caution
• Pb free solder has a higher melting point than standard sol-
der; Typically the melting point is 50 - 70°F (30 - 40°C)
higher. Please use a soldering iron with temperature control
and adjust it to 700 ± 20°F (370 ± 10°C). In case of using
high temperature soldering iron, please be careful not to
heat too long.
• Pb free solder will tend to splash when heated too high
(about 1100°F/600°C)
1.2. Laser Products
1.3. Replacing the Fuse
Use fuses of the same specified rating (15A). Using different
substitutes or fuses with higher ratings, or connecting the prod-
uct directly without a fuse, could cause fire or damage to the
stereo unit.
1.4. Maintenance
Your products is designed and manufactured to ensure a mini-
mum of maintenance. Use a dry, a soft cloth for routine exterior
cleaning. Never use benzine, thinner or other solvents.
1.5. Notes
[RADIO BLOCK]
Do not align the AM/FM package block. When the package
block is necessary, it will be supplied already aligned at the fac-
tory.
[CD DECK BLOCK]
This model has no servo alignment points because microcom-
puter controls the servo circuit.
cqrxbt490u.book Page 2 Friday, April 6, 2012 9:48 AM

3
2 Specifications
2.1. Specifications
2.2. Dimensions
General
Power supply : 12V DC (11 V - 16 V),
Test voltage 14.4 V,
Negative ground
Current consumption : Less than 2.5 A (CD mode, 0.5 W
×4 channels)
Maximum power output : 50 W ×4 channels (at 1kHz), Vol-
ume control maximum
Tone/SQ adjustment range : SQ Low/Bass :
±12 dB (at 60 Hz, 80 Hz, 100 Hz,
200 Hz)
SQ Mid :
± 12 dB (at 500 Hz, 1 kHz, 2 kHz, 3
kHz)
SQ High/Treble :
± 12 dB (at 10 kHz, 12 kHz, 15
kHz, 18 kHz)
Power output : 18 W ×4 channels (1 kHz, 1 %,
4Ω)
Speaker impedance : 4 - 8 Ω
Dimensions (W x H x D) : 178 mm ×50 mm ×158 mm { 7” ×1
15/16” ×6 1/4”}
Pre-amp output voltage : 5.0 V (CD mode, 1 kHz, 0 dB)
Pre-amp output impedance : 200 Ω
Weight : 1.2 kg {2 lbs. 10 oz }
USB connector
USB standard compatibility : 1.1/2.0 full speed
File system : FAT 12/16/32
Maximum supply current : 1 A
Playable audio format : MP3/WMA
Recommended capacity/partition : Less than 32 GB/Only supported
for 1 partition
Front AUX input
Input impedance : 10 kΩ
Maxium input level : 2.0 V
Connector : 3.5 mm Stereo mini pin
Input sensitivity : 200 mVrms
FM Radio
Frequency range : 87.9 MHz -107.9 MHz
Usable sensitivity : 10.2 dBf (0.9 μV , 75 Ω)
50 dB quieting sensitivity : 15.2 dBf (1.6 μV , 75 Ω)
Frequency response : 30 Hz -15 kHz (± 3 dB)
Alternate channel selectivity : 75 dB
Stereo separation : 35 dB (at 1 kHz)
Signal to noise ratio : 62 dB
Image rejection ratio : 55 dB
IF rejection ratio : 100 dB
AM Radio
Frequency range : 530 kHz -1710 kHz
Usable sensitivity : 27 dB/μV (22 μV , S/N 20 dB)
CD Player
Sampling frequency : 8 times oversampling
DA converter : 1 bit DAC System
Pick-up type : Astigma 3-beam
Light source : Semiconductor laser
Wavelength : 790 nm
Frequency response : 20 Hz - 20 kHz (±1 dB)
Signal to noise ratio : 96 dB
Total harmonic distortion : 0.01 % (1 kHz)
Wow and flutter : Below measurable limits
Channel separation : 75 dB
Bluetooth®
Communication Frequency: 2402MHz - 2480MHz
Number of Channels: 79 Channels
Communication Mode: Frequency Hopped Spread Spec-
trum Communication
RF Output: 0 dBm (0.8mW)
Service Area: Within 10 m
Applicable Bluetooth® Version: Version 2.1+EDR
Bluetooth QD ID B016993
* Specifications and design are subject to modification without notice
due to improvements.
* Some figures and illustrations in this manual may be different from
your product.
Above specifications comply with EIA standards
cqrxbt490u.book Page 3 Friday, April 6, 2012 9:48 AM

4
3 Features
• File search function.
• Front AUX terminal.
• Sound control.
• USB connector.
• Bluetooth®.
• SiriusXM Satellite Radio.
cqrxbt490u.book Page 4 Friday, April 6, 2012 9:48 AM

5
4 Technical Descriptions
4.1. Terminals Description
4.1.1. Main Block
IC601:C2CBYY001238
PIN
No. Port Description I/O FM(V) CD(V) USB(V)
1 N.C. Not connected. O 0 0 0
2 AMP_STB Amp standtby signal. O 3.31 3.31 3.31
3 N.C. Not connected. O 0 0 0
4 N.C. Not connected. O 0 0 0
5 N.C. Not connected. O 0 0 0
6 N.C. Not connected. O 0 0 0
7 TEST - 0 0 0
8 RESET Reset signal input. I 3.94 3.95 3.93
9 N.C. Not connected. O 0 0 0
10 VREG Bypass condenser con-
nected. -3.303.303.30
11 VSS1 GND - 0 0 0
12 XT1 Main Crystal 1
(32.768KHz) connected. I1.301.301.29
13 XT2 Main Crystal 2
(32.768KHz) connected. O1.711.71 1.70
14 VDD_CPU VDD(3.3V) - 3.30 3.31 3.30
15 INIT_A Initial distribution setup_A I 2.73 2.73 2.73
16 INIT_B Initial distribution setup_B I 0 0 0
17 INIT_C Initial distribution setup_C I 0 0 0
18 INIT_D Initial distribution setup_D I 3.30 3.30 3.30
19 INIT_E Initial distribution setup_E I 3.30 3.30 3.30
20 VBUS_DET
ECT V-BUS(4.75V/2~5.25V/2) I 2.62 2.63 2.62
21 N.C. Not connected. O 0 0 0
22 N.C. Not connected. O 0 0 0
23 N.C. Not connected. O 0 0 0
24 N.C. Not connected. O 0 0 0
25 N.C. Not connected. O 0 0 0
26 N.C. Not connected. O 0 0 0
27 N.C. Not connected. O 0 0 0
28 N.C. Not connected. O 0 0 0
29 N.C. Not connected. O 0 0 0
30 POWER_C
NT Power IC control signal output. O4.684.69 4.68
31 N.C. Not connected. O 0 0 0
32 N.C. Not connected. O 0 0 0
33 CD_SW1 CD insert detection SW 1. I 4.70 0 0
34 CD_SW2 CD Mechanism SW 2. I 4.70 0 0
35 CD_MUTE CD DSP driver IC mute
control signal. I 0 3.13 3.10
36 CD_LIMIT_
SW CD limit detection SW. I 3.14 3.13 3.11
37 MODE_A Rotary clock signal A out-
put. I 0 4.47 4.46
38 MODE_B Rotary clock signal B out-
put. I4.464.474.46
39 E-
VOL_I2C_S
CK
Electronic Vol-IC commu-
nication.O4.724.74 4.72
40 E-
VOL_I2C_S
DA
Electronic Vol-IC commu-
nication. I/O 4.72 4.74 4.72
41 N.C. Not connected. O 0 0 0
42 CD_DMUT
ECD motor driver IC action control signal. O 0 4.73 0
43 CD_S/L CD connected detection. O 4.72 4.74 4.71
44 N.C. Not connected. O 0 0 0
45 VDDPORT
1VDD - 4.72 4.73 4.71
46 VSS GND - 0 0 0
47 CD_LM+ CD eject control signal. O 0 0 0
48 CD_LM- CD loading control signal. O 0 0 0
49 LCD_CLK LCD clock signal output. O 4.67 4.68 4.66
50 LCD_DO LCD data output. I 4.77 4.78 4.77
51 LCD_DI LCD data input. O 4.62 4.63 4.62
52 EJ_ILL CD slot illumination O 4.72 4.73 4.71
53 LCD_CE LCD chip enable control
signal output. O0 0 0
54 REMO_IN Remote signal input. I 4.67 4.69 4.67
55 iPOD_CNT USB iPod communication
request signal output. O 4.70 4.72 4.69
56 PWR_LED POWER_LED control sig-
nal output. O0 0 0
57 N.C. Not connected. O 0 0 0
58 DSP_PRES
ET DSP reset control signal output. O 4.72 4.73 4.71
59 DSP_CE DSP chip enable control
signal output. O 0 2.31 2.30
60 DSP_BUSY
BDSP busy control signal input. I 3.13 2.91 2.92
61 OSCCTL12 DSP standby control
mode. O0 0 0
62 OSCCTL13 DSP standby control
mode. O0 0 0
63 DSP_CMD DSP command control
data output. O 4.72 4.23 4.22
64 DSP_DATA DSP control data signal
input. I 0 2.24 1.96
65 DSP_CL DSP clock control signal
output. O 4.72 4.71 4.69
66 USB_IN USB device connection
signal detection input. I0 03.10
67 BEEP Beep sound control signal
output. O0 0 0
68 CMD_ERR DSP Error. I/O 0 0 0
69 iPOD_TX_
UART iPod control data received input. I 2.98 2.98 2.95
70 iPOD_RX_
UART iPod control data send output. O0 0 0
71 OPEN/
CLOSE Panel flip down sensor I 0 4.55 4.53
72 EJ_KEY Eject button I 4.27 4.27 4.27
73 BATT Battery power connected
signal detection. I 4.55 4.55 4.53
74 ACC ACC power detection. I 4.89 4.90 4.89
75 BT_TX BT data received input. I 3.32 3.33 3.33
76 BT_RX BT data send output. O 4.35 4.36 4.36
77 N.C. Not connected. O 0 0 0
78 BT_RESET BT module reset signal
output. O 4.60 4.61 4.60
79 VDDPORT
2VDD - 4.72 4.74 4.72
80 VSS3 GND - 0 0 0
81 RADIO_CL
KRadio Tuner clock control signal output. O4.59 0 0
82 RADIO_DA
TA Radio Tuner data control signal input/output. I/O 4.53 0 0
83 N.C. Not connected. O 0 0 0
84 EXT_ROM
_I2C_SCK I2C clock output for stor- ing last settings. O 4.72 4.74 4.72
85 EXT_ROM
_I2C_SDA I2C data input/output for storing last settings. I/O 4.72 4.73 4.72
86 N.C. Not connected. O 0 0 0
87 SXI_TX SXI data received input I 0 4.99 4.99
88 SXI_RX SXI data send output O 4.72 4.74 4.72
89 RADIO_MO
DE Radiopowercontrolsignal output. O0 0 0
90 SXI_PWR_
EN SXI Power control signal output. O 4.72 4.74 4.72
91 SXI_PWR_
CNT SXI Power control signal output. O 4.70 4.71 4.69
92 N.C. Not connection. O 0 0 0
93 USB_FLG USB power current over-
load protection signal
input.
I 5.17 5.18 5.17
94 USB_ENBL USB V-BUS on/off control
signal output. O 4.70 4.72 4.70
95 ANT_CNT ANTcontrol signal output. O 4.69 4.72 4.69
96 VDDPLL VDD - 3.31 3.32 3.31
97 VSS4 GND - 0 0 0
98 LPF0 - 1.14 1.14 1.14
99 AF_MUTE AF MUTE control signal
input. O0 0 0
100 AMP_MUT
EAMP_MUTEcontrolsignal output. O 3.31 3.32 3.31
PIN
No. Port Description I/O FM(V) CD(V) USB(V)
cqrxbt490u.book Page 5 Friday, April 6, 2012 9:48 AM

6
IC800:C5ZBZ0000148
Pin No. Port Description I/O CD(V)
1 EFMIN RF signal input. AI 1.61
2 RFOUT RF signal output. AO 1.56
3 LPF RF signal DC level detection LPF
connection. AO 1.55
4 PHLPF Defect detection LPF connection. AO 2.20
5 AIN A signal input. AI 1.63
6 CIN C signal input. AI 1.63
7 BIN B signal input. AI 1.62
8 DIN D signal input. AI 1.66
9 SLCISET SLCO output current setting resis-
tor connection. AI 1.69
10 RFMON IC internal analog signal monitor
1. AO 1.54
11 VREF VREF voltage output. AO 1.57
12 JITTC Jitter detection capacitor connec-
tion. AO 0.68
13 EIN E signal input. AI 1.64
14 FIN F signal input. AI 1.64
15 TE TE signal output. AO 1.60
16 TEIN TE signal input used for TES sig-
nal generation. AI 1.57
17 LDD Laser power control signal output. AO 2.18
18 LDS Laser power detection signal
input. AI 0
19 AVSS Analog system ground. - 0
20 AVDD Analog system power supply. - 3.11
21 FDO Focus control signal output. AO 1.44
22 TDO Tracking control signal output. AO 1.69
23 SLDO Sled control signal output. AO 1.80
24 SPDO Spindle control signal output. AO 1.64
25 VVDD1 EFMPLL power supply. - 3.11
26 PDOUT1 EFMPLL charge pump output 1. AO 1.20
27 PDOUT0 EFMPLL charge pump output 0. AO 1.19
28 PCNCNT EFMPLL charge pump control
voltage input. AI 3.11
29 PCKIST EFMPLL charge pump current
setting resistor connection. AI 1.12
30 VVSS1 EFMPLL ground. - 0
31 GP10 General purpose I/O port with pull
down resistor. UART 1 data trans-
mit.
I/O 2.97
32 GP11 General purpose I/O port with pull
down resistor. UART 1 data
receive.
I/O 0
33 GP12 General purpose I/O port with pull
down resistor. External interrup-
tion function 2.
I/O 0
34 GP13 General purpose I/O port with pull
down resistor. External interrup-
tion function 3.
I/O 0
35 DVDD Digital system power supply. - 3.11
36 DVSS Digital system ground. - 0
37 GP43 General purpose I/O port with pull
down resistor. Transmit data out-
put for serial communication 2.
I/O 3.12
38 GP44 General purpose I/O port with pull
down resistor. Receive data input
for serial communication 2.
I/O 3.12
39 GP45 General purpose I/O port with pull
down resistor. Master clock output
for serial communication 2.
I/O 0
40 DVDD Digital system power supply. - 3.11
41 DVSS Digital system ground. - 0
42 DVDD15 Capacitor connection pin for inter-
nal regulator. AO 1.61
43 GP50 General purpose I/O port with pull
down resistor. USB over current
detection signal input.
I/O 3.12
44 GP51 General purpose I/O port with pull
down resistor. UART 2 data trans-
mit.
I/O 0
45 GP52 General purpose I/O port with pull
downr resistor. UART 2 data
receive.
I/O 0
46 GP53 General purpose I/O port with pull
down resistor. USB power supply
signal output.
I/O 0
47 GP30 General purpose I/O port with pull
down resistor. External interrup-
tion function 3.
I/O 0
48 GP31 General purpose I/O port with pull
down resistor. Bit clock input/out-
put for Stream data.
I/O 0
49 GP32 General purpose I/O port with pull
down resistor. Data input/output
for Stream data.
I/O 3.11
50 GP33 General purpose I/O port with pull
down resistor. Request flag input/
output for Stream data.
I/O 0
51 GP34 General purpose I/O port with pull
down resistor. Transmit data out-
put for serial communication 3.
I/O 0
52 GP35 General purpose I/O port with pull
down resistor. Master clock output
for serial communication 3.
I/O 0
53 GP36 General purpose I/O port with pull
down resistor. Receive data input
for serial communication 3.
I/O 0
54 GP37 General purpose I/O port with pull
down resistor. Data 2 input/output
for SD memory card.
I/O 0
55 MODE0 LSI mode set pin 0. I 0
56 MODE1 LSI mode set pin 1. I 0
57 DVDD Digital system power supply. - 3.12
58 DVSS Digital system ground. - 0
59 RESB IC reset input.L-active. I 4.69
60 SIFCK Data transmit clock input for serial
communication1. I4.67
61 SIFDI Data input for serial communica-
tion 1. I/O 4.17
62 SIFDO Data output for serial communica-
tion 1. I/O 2.00
63 SIFCE Enable signal input for serial com-
munication 1. I/O 2.30
64 BUSYB System busy signal ooutput.
External interruption function 0. I/O 2.94
65 GP03 General purpose I/O port with pull
down resistor. Watch dog timer
state monitor output.
I/O 0
66 GP04 General purpose I/O port with pull
down resistor. Master clock output
for serial communication 2.
I/O 3.12
67 GP05 General purpose I/O port with pull
down resistor. Receive data input
for serial communication 2.
I/O 3.12
68 GP06 General purpose I/O port with pull
down resistor. Transmit data out-
put for serial communication 2.
I/O 0
69 GP07 General purpose I/O port with pull
down resistor. UART 1 data
receive.
I/O 0
70 XVDD1 Oscillator power supply. - 3.12
71 XIN 12MHz oscillator connection. I 1.58
72 XOUT 12MHz oscillator connection. O 1.52
73 XVSS1 Oscillator ground. - 0
74 UDM USB data input/output. D- signal
connection. I/O 0
75 UDP USB data input/output. D+ signal
connection. I/O 0
76 UVDD USB power supply. - 3.11
77 VVDD2 System PLL power supply. - 3.11
78 VVSS2 System PLL ground. - 0
79 AFILT Audio PLL charge pump output. AO 1.66
80 VVDD3 Audio PLL power supply. - 3.11
81 MODE2 LSI mode set pin 2. I 0
82 JTRSTB JTAG reset input. I 0
83 JTCK JTAG clock input. I 0
84 JTDI JTAG data input. I 0
85 JTMS JTAG mode input. I 3.12
86 JTDO JTAG mode output. O 0
87 JTRTCK JTAG return clock output. O 0
88 DVDD Digital system power supply. - 3.11
89 DVSS Digital system ground. - 0
90 DVDD15 Capacitor connection pin for inter-
nal regulator. AO 1.62
91 XVSS2 Oscillator ground. - 0
Pin No. Port Description I/O CD(V)
cqrxbt490u.book Page 6 Friday, April 6, 2012 9:48 AM

7
Note 1 :
Voltage measuerments are with respect to ground,
with a voltmeter (internal resistance : 10MΩ).
4.1.2. Display Block
IC901:C0HBA0000324
4.1.3. BT/USB/AUX Block
IC100:YEAMNF230122
92 X16OUT 16.9344MHz oscillator connec-
tion. O1.46
93 X16IN 16.9344MHz oscillator connec-
tion. O1.51
94 XVDD2 Oscillator power supply. - 3.09
95 LRVDD Audio LPF power supply. - 3.09
96 LCHO Audio Lch data output. AO 1.56
97 LRREF Reference voltage for audio LPF. AO 1.56
98 RCHO Audio Rch data output. AO 1.56
99 LRVSS Audio LPF ground. - 0
100 SLCO Slice Level control output. AO 1.61
Pin.
No. PORT Description I/O (V)
1 P1/S1 General-purpose output. O 4.80
2 P2/S2 General-purpose output. O 4.80
3 P3/S3 General-purpose output. O 4.80
4 P4/S4 Not connected. -4.82
5 P5/S5 Segment outputs. O 2.42
6 P6/S6 Segment outputs. O 2.42
7 P7/S7 Segment outputs. O 2.42
8 P8/S8 Segment outputs. O 2.42
9 S9 Segment outputs. O 2.42
10 S10 Segment outputs. O 2.42
11 S11 Segment outputs. O 2.42
12 S12 Segment outputs. O 2.42
13 S13 Segment outputs. O 2.42
14 S14 Segment outputs. O 2.42
15 S15 Segment outputs. O 2.42
16 S16 Segment outputs. O 2.42
17 S17 Segment outputs. O 2.42
18 S18 Segment outputs. O 2.42
19 S19 Segment outputs. O 2.42
20 S20 Segment outputs. O 2.42
21 S21 Segment outputs. O 2.42
22 S22 Segment outputs. O 2.42
23 S23 Segment outputs. O 2.42
24 S24 Segment outputs. O 2.42
25 S25 Segment outputs. O 2.42
26 S26 Segment outputs. O 2.42
27 S27 Segment outputs. O 2.42
28 S28 Segment outputs. O 2.42
29 S29 Segment outputs. O 2.42
30 S30 Segment outputs. O 2.42
31 S31 Segment outputs. O 2.42
32 S32 Segment outputs. O 2.42
33 S33 Segment outputs. O 2.42
34 S34 Segment outputs. O 2.42
35 S35 Segment outputs. O 2.42
36 S36 Segment outputs. O 2.42
37 S37 Segment outputs. O 2.42
38 S38 Segment outputs. O 2.42
39 S39 Segment outputs. O 2.42
40 S40 Segment outputs. O 2.42
41 S41 Segment outputs. O 2.42
42 S42 Segment outputs. O 2.42
43 S43 Segment outputs. O 2.42
44 S44 Segment outputs. O 2.42
45 S45 Segment outputs. O 2.42
46 S46 Segment outputs. O 2.42
47 S47 Segment outputs. O 2.42
48 S48 Segment outputs. O 2.42
49 S49 Segment outputs. O 2.42
50 S50 Segment outputs. O 2.42
51 S51 Segment outputs. O 2.42
52 S52 Segment outputs. O 2.42
53 S53 Segment outputs. O 2.42
Pin No. Port Description I/O CD(V)
54 S54 Segment outputs. O 2.42
55 S55 Segment outputs. O 2.42
56 S56 Segment outputs. O 2.42
57 S57 Segment outputs. O 2.42
58 S58 Segment outputs. O 2.42
59 S59 Segment outputs. O 2.42
60 S60 Segment outputs. O 2.42
61 S61 Segment outputs. O 2.42
62 S62 Segment outputs. O 2.42
63 S63 Segment outputs. O 2.42
64 S64 Segment outputs. O 2.42
65 S65 Segment outputs. O 2.42
66 S66 Segment outputs. O 2.42
67 S67 Segment outputs. O 2.42
68 S68 Segment outputs. O 2.42
69 S69 Segment outputs. O 2.42
70 S70 Segment outputs. O 2.42
71 S71 Not connected. -2.42
72 S72 Not connected. -2.42
73 S73 Not connected. -2.42
74 COM4/S74 Common driver outputs. O 2.42
75 COM3 Common driver outputs. O 2.42
76 COM2 Common driver outputs. O 2.42
77 COM1 Common driver outputs. O 2.42
78 S75/KS1 Not connected. -4.82
79 S76/KS2 Not connected. -4.82
80 KS3 Key scan outputs. O 4.82
81 KS4 Key scan outputs. O 4.82
82 KS5 Key scan outputs. O 4.82
83 KS6 Key scan outputs. O 4.82
84 KI1 Key scan inputs. I 0
85 KI2 Key scan inputs. I 0
86 KI3 Key scan inputs. I 0
87 KI4 Key scan inputs. I 0
88 KI5 Key scan inputs. I 0
89 S77/P9 General-purpose output port. O 0
90 VDD Power supply connections. - 4.82
91 VDD1 LCD drive 2/3 biasvoltage supply
pin. -3.22
92 VDD2 LCD drive 1/3 biasvoltage supply
pin. -1.63
93 VSS Ground. - 0
94 TEST This pin must be connected to
ground. -0
95 OSC Oscillator circuit port. I/O 3.53
96 RES Reset signal input. I 4.82
97 DO Output data. O 4.76
98 CE Chip enable. I 0
99 CL Synchronization clock. I 4.60
100 DI Transfer data. I 4.55
Pin.
No. PORT Description I/O (V)
1 UART_CTS UART clear to send active low. I 0
2 UART_RTS UART request to send active low. O 0
3 UART_RX UART data input. I 0
4 UART_TX UART data output. O 3.06
5 VREGIN_L Input to internal low-voltage linear
regulator for non-audio core
circuity.(1.8V-2.7V)
I1.83
6 VDD_MEM VDD VDD 3.05
7 VDD_PIO VDD VDD 3.05
8 GND Ground GND 0
9 RESET# CMOS input with weak internal pull-
up. I3.58
10 PIO[10] Programmable input/output line. O 0
11 PIO[9] Programmable input/output line. O 0
12 PIO[15] Programmable input/output line. O 0
13 PIO[11] Programmable input/output line. O 0
14 PIO[12] Programmable input/output line. O 0
15 PIO[13] Programmable input/output line. O 0
Pin.
No. PORT Description I/O (V)
cqrxbt490u.book Page 7 Friday, April 6, 2012 9:48 AM

8
16 PIO[14] Programmable input/output line. O 0
17 PIO[8] Programmable input/output line. O 0
18 PIO[7] Programmable input/output line. O 0
19 PIO[6] Programmable input/output line. O 0
20 PIO[5] Programmable input/output line. O 0
21 PIO[4] Programmable input/output line. O 0
22 PCM_IN Synchronous data input. I 0
23 PCM_CLK Synchronous data clock. O 0
24 PCM_OUT Synchronous data output. O 0
25 PCM_SYNC Synchronous data sync. O 0
26 SPI_MOSI SPI data input. I 0
27 SPI_CLK SPI clock. I 0
28 SPI_CSB Chip select for Serial Peripheral
Interface (SPI), active low. I2.88
29 SPI_MISO SPI data output. O 0
30 LED[0] LED driver. O 0
31 LED[1] LED driver. O 0
32 VREGIN_H Input to internal high-voltage linear
regulator. (2.5V-4.9V) I3.05
33 VREGEN_H Take high to enable high-voltage
linear regulator and switch-mode
regulator.
I3.05
34 VREGOUT_H High-voltage linear regulator output.
(1.8V out) O1.84
35 N.C. Not connection. O 0
36 GND Digital Ground. GND 0
37 VDD_CHG Lithium ion/polymer battery charger
input. (4.5V-6.5V) I0
38 VDD_BAT Lithium ion/polymer battery positive
terminal.Battery charger output and
input to switch-mode regulator.
(4.2V out)
O0
39 GND Digital Ground. GND 0
40 MIC_BIAS Microphone bias. I 0
41 MIC_R_P Microphone input positive,right. I 0
42 MIC_R_N Microphine input negative,right. I 0
43 MIC_L_P Microphone input positive,left. I 0
44 MIC_L_N Microphone input negative,left. I 0
45 AGND Analogue Ground. GND 0
46 VDD_AUDIO Positive supply output for audio
circuitry and 1.5V regulated output.
(from internal low-voltage regulator)
O1.51
47 SPK_R_N Speaker output negative,right. O 0
48 SPK_R_P Speaker output positive,right. O 0
49 SPK_L_N Speaker output negative,left. O 0.71
50 SPK_L_P Speaker output positive,left. O 0.71
51 PIO[3] Programmable input/output line. O 0
52 PIO[1] Programmable input/output line.
(external TXEN) O0
53 PIO[2] Programmable input/output line. O 0
54 PIO[0] Programmable input/output line.
(external RXEN) O0
55 GND Digital Ground. GND 0
56 GND Digital Ground. GND 0
57 ANT RF out. O 0
58 GND Digital Ground. GND 0
59 AIO[0] Analogue programmable input/out
line. O0
60 VDD_ANA Positive supply output for analogue
circuitry and 1.5V regulated output.
(from internal low-voltage regulator)
O1.48
61 AIO[0] Analogue programmable input/
output line. O0
62 GND Digital Ground. GND 0
63 USB_DP USB data plus with selectable
internal 1.5kΩpull-up resistor. I3.04
64 USB_DN USB data minus. I 0
Pin.
No. PORT Description I/O (V)
cqrxbt490u.book Page 8 Friday, April 6, 2012 9:48 AM

9
4.2. IC Block Diagram
4.2.1. Main Block
IC230:C0ABCA000121
IC704:C0DBEJG00001
cqrxbt490u.book Page 9 Friday, April 6, 2012 9:48 AM

10
IC201:C1BA00000493
IC602:C3EBJY000032
cqrxbt490u.book Page 10 Friday, April 6, 2012 9:48 AM

11
IC400:C1BB00001088
cqrxbt490u.book Page 11 Friday, April 6, 2012 9:48 AM

12
IC50:C1ZBZ0004389
IC706:C0DBGYY00710
cqrxbt490u.book Page 12 Friday, April 6, 2012 9:48 AM

13
IC707:C0DBGYY00710
IC180:C0CBCYG00004
cqrxbt490u.book Page 13 Friday, April 6, 2012 9:48 AM

14
IC701:C0DAZYY00033
cqrxbt490u.book Page 14 Friday, April 6, 2012 9:48 AM

15
IC803:C1AB00003758
cqrxbt490u.book Page 15 Friday, April 6, 2012 9:48 AM

16
IC705:C0EBY0001290
cqrxbt490u.book Page 16 Friday, April 6, 2012 9:48 AM

17
IC902:B3RAB0000091
IC181:C0JBAB000255
cqrxbt490u.book Page 17 Friday, April 6, 2012 9:48 AM

18
5 Block Diagram
SDA
SCL
E-VOL-SDA E-VOL-SCK
STBY
MUTE
AMP-STB
IC803
AUDIO PROCESSOR
FL
RL
IC601
SYSTEM CONTROL
CQ-RXBT490U
IC201
POWER AMP
CN701
FL+
FL-
FR+
FR-
RR+
RR-
ACC
RL+
RL-
BATT
E-4C430
RR
FR
VCC
MOTOR
DRIVER
IC400
CD/USB DSP
IC800
LCD CLK/DO/DI/CE

FL+
FL-
RL+
RL-
FR+
FR-
RR+
RR-
40 39
2
9
7
56
21
18
20
19 6,20
4
22
FL
RL
RR
FR 11
12
14
15
3
21
23
9
7
17
19
E-VOL IC
IC50
FM-IN2
FM-IN1
AM-RFIN
RF-GND
D.GND
VCC1
L-CH
P50
R-CH
9
1
3
4
SDA
SCL
CN451
1
22
CN2
M
SPINDLE MOTOR
MODE SW
M
LOADING MOTOR
LIMIT SW
RF
AMP
TRACKING
COIL
FOCUS
COIL
E-4C413
1
22
1
1
17
CN1
4PWIRE
3PWIRE
2PWIRE
CN951
610 IC802
iPod
2.0B
IC
VCC
24
100
AMP-MUTE
IC701
REGULATOR IC
14
10
12
11
7
ANT
ACC-IN
AVDD+5V
ACC+5V
VCC
AUDIO +9V
CTRL2
CTRL1
CD+8V
ILL +9V 1
9
ACC-SENS
ACC-SENS
PWR-CNT
DVDD
ANT-CNT
45,79
49,50,51,53
MODE B/A
37,38
R
415
3
RADIO_MODE
RADIO-R
RADIO-L
AUX L/R
CD/USB-L
CD/USB-R
BATT SENSE
8
RESET
2
USB D+/D-
USB-FLG
USB-ENBL
IC704
A,B,E,F,LPD,VREF
CD/USB L/R
CD 8V
SL-/SL+/SP-/SP+/F-/F+/T-/T+/VREF
SPD0/FD0/SLD0/TD0
Q800
CD 8V
REGIN
CD_SW1/SW2/LIMIT SW
CD_FR/SL/DMUTE/LM+/LM-
DSP+3.3V
DSP+3.3V
AUDIO+9V
AUDIO+9V
AUDIO+9V
AVDD+5V
ACC
ACC
ACC
BATT
RADIO-DATA
RADIO-CLK
CD 8V CD 8V
11
12 13
1
87314
94
5
6
8
3
19
18
17
AVDD+5V
DVDD+5V
22
23
RADIO-MODE
RADIO-L
RADIO-R
AUX-L
AUX-R
8
10
P. G N D
BATT
BATT
ACC
L/R
CD/USB L/R
R
R
5
FM/AM TUNER IC
5
26 25
15
13
AMP/ANT-CNT
6
8
10
12
16
REMO-IN
NC
NC
14 NC
2
4
9
11
1
3
5
7
Q50/Q52
89
95
74
30
72
73
5
REMO-IN
AMP-CNT
AMP-CNT
82
81
93 94
DSP DI/DO/CLK/CE/RST/BUSYB
USB-IN/CMD ERR/CD MUTE
CD LIMIT SW/OSCCTL12/13
CP SDA
/SCL
RESET
iPod
CNT
REMO-IN
54
GND
AVDD+5V
iPod TX/RX
L/R
L/R
SW+5V13
GND
REMO-IN
12
13
XT1
XT2
AMP-CNT
15
EXT
VERSION
UP
CN600
7,8,79
iPod RX/TX UART
iPod CNT
55
69,70
P. G N D
P. G N D
2,8
18,24
13 PRE-GND
11,46,80,97
S.GND
A.GND
D.GND
15A
FUSE
E-4C429
LCD DISPLAY
IC901
LCD DRIVER
LCD DO/CLK/CE/DI
KEY
MATRIX
1
ILL+9V
VDD+5V
VDD+5V
D901
LCD COM
LCD SEGMENT
SW951
MODE A/B
Q901
SEL
10
LCD+5V
CN901
P. G N D
3
P.LED
IC902
REMO
LCD901
5689247
11
P.GND
14 12 13
1
24
E-4C434
1
3
1
4
CN102
CN103
1
24
CN500
110
CN990
35689247
1114 12 13
10 2
11
12 13
1
87314
94
5
CN991
E-4C431
IC707 3.3V
IC705
45,79
IC602
10
11
12
13
BT
CN500
+
+
1,5
54
52
EJ_ILL
EJECT
71
OP/CL
P. G ND
6
IC706
3.3V
IC230
CN201 CN202
4
14
1
18714
3
5
16 17
IC181
IC180
90 88 91
2
136
87
CN180
910 12
VDDPORT
SXI_TX
SXI_RX
SXI_PWR_EN
SXI_PWR_CNT

19
6 Wiring Connection Diagram
16Pin Power
Connector BATTERY
ACC
GROUND
FUSE:15A
ANT51
14P
14P
CN951
CN901
Main PCB
[E-4C430]
Display PCB [E-4C429]
<CD Interface Block>
Mode SW
Spindle Motor
Optical Pick-up Assy
Limit SW
Loading Motor
CN451
22P
CN1 17P
4P
WIRE
CN2 22P
2P WIRE
3P WIRE
CD Interface PCB
[E-4C413]
4 SPK
CN500
AUX-IN
USB-IN
AMP/ANT-CNT
REMO-IN
CN701 16P
FL+
FL-
FR+
FR-
RL+
RL-
RR+
RR-
15A FUSE
R
L
PRE OUT
CN301
CN501
MIC
CQ-RXBT490U
Hold PCB
[E-4C431]
14P CN990 14P
CN991
CN201 CN202
PRE-OUT
cqrxbt490u.book Page 19 Friday, April 6, 2012 9:48 AM

20
7 Schematic Diagram
7.1. Main Block
CQ-RXBT490U MAIN
The following symbols are
shown on the schematic diagram.
The following symbols are
shown on the schematic diagram.
RADIO (L,R)
RADIO (L,R)
AUDIO
9V
8V
5V
3.3V
3.3V
3.3V
ACC
ACC
+B
+B
9V
9V
8V
8V
5V
5V
E-4C430
YEAE4CC0N092
C0DAZYY00033
C0EBY0001290
C0DBGYY00710
C0DBGYY00710
K1MY14BA0518
C1BB00001088
C3EBJY000032
C2CBYY001238
C0JBAB000255
C0CBCYG00004
K1AY110B0002
K2JYYA000001
ZBZ0038C1 049
YEAM78696029
C1ZBZ0004014
C1AB00003758
K1KA22A00001
YEAERA46501K
C0ABCA000121
8V
9V
5V
8V
8V
8V
8V
8V 8V
8V
8V 8V
8V
8V
8V 8V
8V
8V
8V
8V
8V
8V
8V
8V
8V
8V
8V 8V
8V 8V
8V 8V
9V 9V
9V
9V
9V
9V
9V
9V 9V
9V
9V
9V
9V
5V
5V
5V
5V
5V 5V
5V
5V
5V
5V
5V
5V
5V
5V
5V 5V
5V
5V
5V
5V
5V
5V
5V
5V
5V 5V
5V
5V
5V
5V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V 3.3V
3.3V
3.3V
3.3V
3.3V 3.3V
3.3V 3.3V 3.3V 3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V 3.3V
3.3V
3.3V
3.3V 3.3V 3.3V
3.3V 3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V
3.3V 3.3V
3.3V 3.3V
3.3V
3.3V
3.3V
3.3V3.3V
3.3V 3.3V
3.3V
3.3V 3.3V
R
L
R
L
R
L
R
L
R-
L+
R+
L-
R-
L+
R+
L-
R
L
R
L
R
L
R
L
R
L
R
L
5V
4.55
6.40
0
5.25
1.28
6.39
0
3.32
4.69
0
3.32
4.05
4.69
0
2.14
4.50
. 71 5
1.58
.7 9 3
3.24
643.
3.93
363.
23. 1
411.
054.
3.75
7.9 4
1.5 7
157.
1. 85
1.58
1.5 7
18.5
0.87
0 9.2
7. 39
71.5
47.6
4.7 0
0
91.4
16.3
71.5
2.91
1.85
.218
0
0
046.
3.24
6.04
2212.
066.
0
6.05
006.
645.
5.71
0
775.
655.
5.87
5.93
0
975.
12.22
599.
3.38
016.
0
0
9.09
1.27
7.97
1.27
9.04
4.66
11.39
674.
0
4.45
964.
11.40
4.96
4.96
11.40
12.21
12.21
0
0
0
3.26
014.
0
315.
3 15.
0
8 77.
0
385.
3.84
0
043.
350.
388.
183.
641.
641.
0
453.
447.
392.
742.
8 77.
0
573.
4.78
227.
875.
875.
134.
0
0
0
9.02
8.86
04.67
0
0
6.11
6.07
6.01
12.09
6.01
6.07
6.08 6.08
6.08
6.01
0
5.67
6.08
6.08
3.21
0
0
0
0
3.12
3.12
3.12
4.95
0
4.68
0
4.83
4.95
0
0
0
0
0
0
4.69
4.69
3 32.
3.32
332.
332.
3 2.3
3.32
335.
3.35
3.35
335.
335.
3 5.3
3.35
3.34 0
4 07.
4 7.0
4.07
4 7.0
4 07.
407.
4 07.
6.19
9 4.0
469.
469.
3 41.
33.3
0
0
0
3.3V
3.3V
5V
5V
5V
5V 5V
5V
5V
5V
5V
5V
5V
5V
000
0
0
0
000
00
0
11.96
4.55
911.
52.7
0
4.71
4.71
4.99
4.99 4.99
4.99
4.97
0
0
0
0
0
00
