Panasonic CQ-JC179AA User manual

CQ-JC179AA Operating Instructions
Panasonic Taiwan Co., Ltd.
CD PLAYER ／RECEIVER
with CD CHANGER CONTROL
page1

Cover. ................................ 1
Contents. ............................. 2
Specifications、Features ..................19
Function on AUX、TELEPHONE. ...........16
Notes on MP3 .........................17
General Function and Operation ...............3
Function and Operation on CD/MP3 Player. . . . . . . .9
Function and Operation on Radio. .............7
Function and Operation on CD - CHANGER. ....14
Contents
Panasonic Taiwan Co., Ltd.
CQ-JC179AA Operating Instructions
page2

※Note：
Passwords key in times
General Function and Operation
①Power Control/Volume Adjustment [PWR/VOL]
A﹒Power [PWR/VOL]：
l﹒ Turn the key in the ignition(ACC). When the unit is ready, time displays on the screen. (the power of unit is off)
2﹒Press [PWR/VOL] to power on the unit. Starting picture displays on the screen.
Press [PWR/VOL] again to power off the unit.
Press [PWR/VOL] calls the screen to ask for keying passwords after installation, loose power, and battery change.
Function Operation
①
②
③
④
⑤
page3

B﹒Volume [PWR/VOL]：
↑ ↓
30 minutes count backwards
Selection " TREBLE " to adjust：
Regular mode ← FADER
②Audio mode [MENU]
◎Press [MENU] to select audio mode
The unit will be locked for 30 minutes if you key in the wrong passwords for more than 4 times.
General Function and Operation
passwords key in: [1]~[4] stand for thousand, hundred, tenth, single respectively. Press the key once means 1;
BASS →TREBLE →BALANCE
press the key twice means 2, etc. You can enter 0000~9999 as passwords by this way.Press [5] to confirm when password is
entered and get into the initial operation screen.
Turn the Volume [PWR/VOL] button clockwise/counterclockwise to increase/decrease volume(0~40)
※IF owner forgets or wishes to change the password, please take the unit to the Ford service center for service.
Turn the Volume [PWR/VOL] button counterclockwise to
decrease BASS（0 ～ -12）
Turn the Volume [PWR/VOL] button counterclockwise to
decrease TREBLE（0 ～ -12）
Selection " BASS " to adjust：
Turn the Volume [PWR/VOL] button clockwise to increase
BASS（0 ～ +12）
Turn the Volume [PWR/VOL] button clockwise to increase
TREBLE（0 ～ +12）
page4

※Note：
③Attention/Loud [ATT/LOUD]
Attention [ATT/LOUD]：
LOUD [ATT/LOUD]：
If no operation excused for more than 5 seconds in audio mode (BAS/TRE/BAL/FAD), the display returns to the regular
mode. Press [menu] again to select audio mode
Press [ATT/LOUD] to decrease Volume 20dB instantly and " ATT " indicator displays on screen
General Function and Operation
Turn the Volume [PWR/VOL] button clockwise to increase
right channel（R：0 ～ R15）
Selection " FADER " to adjust：
Turn the Volume [PWR/VOL] button counterclockwise to
increase rear speaker（R：0 ～ R15）
Turn the Volume [PWR/VOL] button clockwise to increase
front speaker（F：0 ～ F15）
Press [ATT/LOUD] more than 2 second again to cancel LOUD function and " LOUD " indicator is off.
Press [ATT/LOUD] more than 2 seconds to increase BASS and TREBLE under small or medium volume.
Press [ATT/LOUD] again to cancel Attention function and " ATT " indicator is off.
After this operation, " LOUD " indicator lights on the screen.
Turn the Volume [PWR/VOL] button counterclockwise to
increase left channel（L：0 ～ L15）
Selection " BALANCE " to adjust：
page5

clock display
⑤SOURCE MODE [MODE]
RADIO DISC PLAYER
AUX CD-CH
The sequency of sound source change as below.
Note： " ADJ " displays at the first time of clock adjustment
●Press [CLK] again to end time adjustment.
When the unit is power off, the screen shows clock display
●Press [MODE] to select sound source when the unit is power on .
First, hour number blinks, press [SEEK∨]∕[SEEK∧] to set hour ahead∕back.
●Press [CLK] for more than 2 seconds to adjust time.(default: 12:00)
●Press [CLK] in 2 seconds to display the time, press again to cancel time display and back to the previous mode.
General Function and Operation
④Clock[CLK] Adjustment
Press [CLK] again to make minute number blinks, press [SEEK∨]∕[SEEK∧] to set minute ahead∕back.
page6

a b c d
①Change Radio
FM1 → FM2 → FM3 → AM1 → AM2
↑↓
Auto Preset Memory
Press one of the preset buttons from [1] to [6] to select the preset station.
●Frequency displayed on screen will change with seek tunning.
" ST " display on screen, if the receiving station is stereo sound.
Press [BAND] to select a radio source, then press and hold [BAND] button(auto preset station) for more than 2 seconds.
●With this operation, 6 station with 1st to 6th highest in signal strength will be automaticlly preseted in preset station
buttons [1] to [6]. Once set, the preset stations are sequently scanned for 10 seconds each.
●Press [BAND] to change band source in radio mode, you can select the FM∕AM channel you like.
Press [BAND] to change radio band, the sequency is shown as below.
a﹒Band display
‧The FM 1 channel
b﹒Frequency of current station
c﹒Preset station number
d﹒Stereo sound indicator
‧display receiving streao sound
‧display the preset station number (1~6)
Function and Operation on Radio
FUNCTION OPERATION
SCREEN DISPLAY
①
②
③
④⑤
⑥
⑦
⑧
⑨
page7

※Number of preset stations
FM1 FM2 FM3 AM1 AM2
Up to 6 Up to 6 Up to 6 Up to 6 Up to 6
Press and hold [ SEEK∨ ] for more 2 seconds, tuning will automatically stop when the next lower frequency station is
received.
②M1③M2④M3⑤M4⑥M5⑦M6 Preset Station Calling
Press and hold [ SEEK∧ ] for more 2 seconds, tuning will automatically stop when the next higher frequency station is
received.
●Press [SEEK∨] or [SEEK∧] again to stop auto tuning.
AutoTuning
Press [BAND] to select desired band, buttons [1] to [6] remember the presaved or default station.
Press [SEEK∧] and release in 2 seconds to select the higher frequency.
Manual Tuning
Press [1] to [6] to call the corresdonding preset station in memory.
Press [SEEK∨] and release in 2 seconds to select the lower frequency.
⑧SEEK∨、⑨SEEK∧
●The step for FM is 0.1 MHz, the step for AM is 9KHz. Band frequency displayed on screen changes with tuning.
②M1③M2④M3⑤M4⑥M5⑦M6 Preset station button[1] ~ [6]
Function and Operation on Radio
Use manual or seek tuning to find your favorate station
Reapeat these steps you can save preset station on [FM1] ~ [AM2].
Press preset station button[1] ~ [6] for more than 2 seconds to save current station on button [1]~[6]
※NOTE:
Repeat these steps you can change preset station.
※NOTE:
[1]~ [6 ]saved stations are overwritten with new station
after saving procedure
page8

a
d
c e
f
①Insert and playback a CD
" LOADING " displayed on screen when inserting a disc. Then you can playback CD .
c﹒type of playing CD
d﹒" RX " Random function is active
f﹒" SCAN " Scan function is active
1.The unit can playback CD / CD-R / CD-RW / MP3 disc。
Note：If a disc is not well recorded, it may not be playable on this unit.
2.Operation and Functuon on playback CD / CD-R / CD-RW discs
" READING " displayed on screen when player is reading data on disc. Then playing starts autumatically.
e﹒" REP " Repeat function is active
a﹒Track number
b
b﹒playing time
Function and Operation on CD Player
FUNCTION OPERATION
SCREEN DISPLAY
①
②
③
④
⑤
⑥
⑦
page9

②▲EJECT button( To eject CD )
③SEEK∨button：
④SEEK∧button：
⑦REP button：
Screen displays "NO DISC", if there is no CD in player.
Press again to cancel SCAN function.SCAN indicator is off.
Press again to cancel RANDOM PLAY function. RX indicator is off.
Press [REP] to display " REP " on screen.
Press [ SEEK∨ ] twice back to the previous track.
IF you do not take away the CD which will be loaded again after 10 seconds.
⑤SCAN button：
⑥RX button：
Press [ SEEK∨ ] and hold for more than 2 seconds to begin FAST REVERSE, release holding to
stop fast reverse and resume playback normally.
Press [SEEK∧] and release in 2 seconds back to the next track.
Press [SEEK∧] and hold for more than 2 seconds to begin FAST FORWARD, release holding to
stop fast forward and resume playback normally.
Press [SCAN] to display " SCAN " on screen, then the first 10 seconds of each tracks of all CDs is
played in sequence.
Press again to cancel REPEAT PLAY function. REP indicator is off.
The current track is repeated.
Press [RX] to display " RX " on screen, then all available tracks are played in a random sequence.
Press [ SEEK∨ ] and release in 2 seconds back to the begin of current track.
Function and Operation on CD Player
Press [ ▲] button to reject CD.
page10
