Panasonic WJ-ND400/1000 User manual

Play back recorded images.
Control the playback of recorded images from the [HDD] tab.
Search for and play back recorded events (REC event search).
Play back Recorded Images
Search for and Playback Images
Select the camera channel you want to
playback and click the [PLAY] button.
Plays back recorded images. [ ] is
displayed in the status display area.
• Playback resumes from the date and
time when playback was stopped.
Click the [STOP] button to stop
playback.
[ ] disappears from the Status
display area and a live image from the
camera is displayed in the Image
display.
Click the [Go to date] button in the
Playback point operation area.
This displays the [Go to date] window.
Select the date and time of the image to
play back and then click the [PLAY]
button.
[ ] is displayed in the status display
area and images at the specified date
and time are played back.
（1）
（3） （2） （4）
Playback point
operation area
(1) [FF]/
[REW]
: Plays recorded images forward or in reverse at
high speed.
The playback speed changes each time the
button is clicked.
(Approximately 4x J8x J16x J
32x J48x J96x)
(2) [NEXT
RECORD]/
[PREV
RECORD]
: Skips forward or backward to play the recorded
image of the next event.
(3) [NEXT
IMAGE]/[PREV
IMAGE]
: Click during playback or when paused to play
one frame at a time forward or backward, or to
pause.
(1)
(2)
(3)
[HDD] Tab
Click the [Control] button and then click [Search] button in the
[Search] box.
• This will display the [Select search method] screen.
Click the [Rec event search] button.
• This displays the [Rec event search] window.
Narrow the conditions.
Select the "Time & date", "Rec event", and "Camera" for the
images you want to playback and then click the [OK] button.
• [FILTERING] is displayed on the status display area and the
filtered results are displayed on the recorded event list
window.
• Click the [All List] button to eliminate all the search conditions.
Click the recorded event time you want to play back. The
selected images are played back.
Click the [STOP] button to stop playback.
(1)
(2)
(3) (4)
Network Disk Recorder
WJ-ND400 Quick Reference Guide
Set the IP address, subnet mask, and other network settings for each port.
Display the operating window from a web browser on a PC.
Network Settings
Display the Operating Window
The Quick Reference Guide provides simple explanations for operating the product.
zFactory default network settings
Item PT#1
Camera port
PT#2
Client PC port
PT#3
Maintenance port
DHCP - OFF -
IP address 192.168.0.250 192.168.1.250 192.168.2.250
Subnet
mask
255.255.255.0 255.255.255.0 255.255.255.0
Gateway - 192.168.1.1 -
HTTP - 80 -
zHow to configure network settings
Use the arrow buttons (up or down) on the
date display screen to display the [IP
Address Setup] and then press the [SET]
button.
• The cursor is shown as an under bar
(_).
Switch to the settings screen.
• When the cursor changes to ">":
Arrow buttons (left or right): Select port
Arrow buttons (up or down): Select item
Click the [SET] button when the cursor is
[>].
The cursor moves to the number area.
Move the cursor with the arrow buttons
(left or right) to configure the settings.
• Arrow buttons (left or right): Move the
cursor
• Arrow buttons (up or down): Input a
value
Press the [ESC] button to move the cursor
to ">" and check the settings.
Press the [ESC] button again to return to
the date display screen.
zIP Address Settings
Screen
[SET]
LCD
ESC button
SET button
Arrow buttons
Launch the web browser, input the main
unit's IP address, and press the [Enter]
key.
The authentication screen opens.
Enter your user name and password to
login.
• Initial default
User name: ADMIN
Password: 12345
This will display the top page.
• The wizard for installing ActiveX
control, which is required to display
images from cameras, opens. Follow
the instructions of the wizard.
3TU001890AAA
AM0408-0
ND400_A3_E.fm 1 ページ ２００８年４月８日 火曜日 午後２時５９分

Set up the minimum settings necessary to use the recorder.
Control Items
Basic Setup
(1) [Control] button
Search for and play back recorded images, as well as
switch camera channels.
(2) [Cam. Select] button
Switch camera channels for the image displayed.
(3) [Setup] button
Set up the recorder.
(4) Status display area
Display the recording and playback status of recorded
images.
(5) Current time display area
Displays the current time.
(6) Image display
Display live and recorded images.
(7) Playback point operations area
Specify the current position in an image being played
back, and play back the most recent image.
(8) [HDD] tab
Control playback of recorded images.
(9) [CAM] tab
Control zoom, focus, and automatic functions of the camera.
(9)
(1)
(8)
(2) (3) (4) (5)
(6)
(7)
(Ι) Set the current date
Click the [Setup] button, and then click
[Quick].
This will display the "Quick" menu.
Set up the current time and date.
Under "Time & date", click the [Set]
button
(1)
(2)
(3)
(ΙΙ) Register the cameras
Select the network port for detecting
cameras.
Select camera port or client PC port.
Use the camera auto-registration item
to specify whether a detected camera
should be assigned an IP address.
Select [Register the IP address
automatically given by this unit to a
detected camera] or [Register the IP
address set with a detected camera].
Click the [Registration] J[OK] buttons. A "Camera registration result" window
will appear after registration is
complete.
Check the results of the recording and
click [OK].
Up to 64 cameras can be registered.
• If a camera you want to register is not
detected or if you want to change the
settings of a camera, do it in "NW
camera" set up.
(ΙΙΙ) Programming
When cameras have been registered,
the live video and manual recording
rate settings of the "Program1" page
are set to 1ips.
Click the [Display] button to check
programming details.
Display live images on a 1-screen or on a 4-screen (multiscreen).
Display live images in the sequential display.
You can control cameras that can pan and tilt from the [CAM] tab.
You can record manually.
Monitor Live Images
Control the Camera
Manual recording
Click the [Cam. select] button. The camera list is displayed in the
[Camera select] box.
Click [WJ-ND400] and select in order
the camera group title and camera title.
The live image from the selected
camera channel is displayed on a 1-
screen.
Click the [Multiscreen] button. The camera image is displayed on 4
separate screens.
• Each clicking the [Multiscreen] button
switches the 4-screen displays.
Click the [Cam. select] button and then
click the [Sequence] button.
Live images are displayed in the
sequential display.
• The [Sequence] button indicator
lights green and [SEQ] is displayed
on the Status display area.
Click the [Sequence] button again. The [Sequence] button indicator goes
off and the sequence operation is
stopped.
(1) [Zoom] : Zoom in/out the image from the camera.
(2) [Focus] : Adjust the focus point of the image.
(3) [Auto mode] : Select the camera's automatic mode
function.
(4) [Control buttons] : Adjust the direction of the camera.
[Control pad] : The pan/tilt movement increases as you
move from the center of the pad to the
edges.
(5) [Brightness] : Adjust the lens iris. (brightness)
(6) [Preset] : Registers the preset positions of camera
and moves the camera to the registered
preset positions.
(2)
(1) (3) (4) (5)
(6)
[CAM] Tab
Click the [S] button in the [REC] box
on the [HDD] tab.
Click the [S] button until the
[Recording] and [Recording stop]
button are displayed.
Click the [Recording] button. In the status display " [REC]" lights
red, and recording starts.
Click the [Recording stop] button. In the status display " [REC]" turns
off, and recording stops.
(2)
(1)
(3)
