Panasonic KX-TG9391 User manual

PNQW1340ZA DM0708SY0
Setting up
If you subscribe to a DSL/ADSL service, attach a DSL/ADSL filter to the telephone line between the base
unit and the telephone line jack. Refer to the operating instructions for connections.
Connecting the AC adaptor / corded handset
(120 V AC, 60 Hz)
LUse only the supplied Panasonic AC adaptor PQLV207 or PQLV219.
Hook
Press plug
firmly.
“Click”
“Click”
Connecting the telephone line cord
4-wire cord
4-wire cord
Line 2
Line 1
2-wire cord
USE ONLY a 4-wire
telephone line cord.
NTo connect to a 2-line telephone jack
NTo connect to 2 single-line telephone jacks
“Transparent” plug
“GREEN” plug
“GREEN” plug
To 2-line telephone jack (RJ14C)
To single-line telephone jacks (RJ11C)
“Click”
“Click”
Model No. KX-TG9391
KX-TG9392
Quick Guide
TG9391_QG(e).fm Page 1 Thursday, July 3, 2008 9:25 AM

– 2 –
Operating tips
Using the navigator keys
The navigator keys can be used to navigate through menus and to
select items shown on the display by pressing:
Base unit: {^}, {V}, {7}, or {8}
Handset: {^}, {V}, {<}, or {>}
To adjust the receiver or speaker volume, press {^} to increase
the volume, or press {V} to decrease the volume repeatedly while
talking.
Soft keys
Each unit features 3 soft keys. By pressing a soft key, you can select
the feature shown directly above it on the display.
{MENU}, {SELECT}, {OK}, and additional other functions are
assigned to soft keys. Pay attention to soft keys to find functions you
need during operation.
Base unit
Handset
Setting up
CHARGE FOR
ABOUT 7 HOURS
Handset
Charger
LUSE ONLY Ni-MH batteries AAA (R03) size.
L
Do NOT use Alkaline/Manganese/Ni-Cd batteries.
LConfirm correct polarities (S, T) when installing the batteries.
(120 V AC, 60 Hz)
Confirm
“Charging”is
displayed.
LUse only the supplied
Panasonic AC adaptor
PQLV209 or PQLV219.
Rechargeable Ni-MH ONLY
Base unit Handset
{V}
{^}
{<}{>}
{^}
{V}
{7}{8}
TG9391_QG(e).fm Page 2 Thursday, July 3, 2008 9:25 AM

– 3 –
Date and time (Base unit/Handset)
Program this setting using either the base unit or one of the handsets.
1{MENU}i{#}{1}{0}{1}
2Enter the current month, date, and year.
3Enter the current hour and minute (12-hour clock format).
4Press {*} to select “AM” or “PM”. i{SAVE}
5Proceed with the operation for your unit.
Base unit: {■}
Handset: {OFF}
Basic operations
Making/Answering calls (Base unit/Handset)
Making calls Base unit: Dial the phone number. iLift the corded handset, or
press {SP-PHONE}.
Handset: Dial the phone number. i{C}/{s}
Answering calls Base unit: Lift the corded handset, or press {SP-PHONE}.
Handset: {C}/{s}
To hang up Base unit: Place the corded handset on the cradle. When the
speakerphone is used, press {SP-PHONE}.
Handset: {OFF}
Making a call using the redial list 1{REDIAL}i{V}/{^}: Select the desired phone number.
2Proceed with the operation for your unit.
Base unit: Lift the corded handset.
Handset: {C}
To adjust the ringer volume 1{MENU}i{#}{1}{6}{0}
2{V}/{^}: Select the desired line. i{SELECT}
3{V}/{^}: Select the desired volume. i{SAVE}
4Proceed with the operation for your unit.
Base unit: {■}
Handset: {OFF}
TG9391_QG(e).fm Page 3 Thursday, July 3, 2008 9:25 AM

– 4 –
Basic operations
Phonebook (Base unit/Handset)
Adding entries 1Proceed with the operation for your unit.
Base unit: {C}
Handset: {MENU}i{#}{2}{8}{0}
2{ADD}
3Enter the party’s name (16 characters max.). i{OK}
4Enter the party’s phone number (24 digits max.). i{OK}
5{V}/{^}: Select the desired group. i{SELECT}2 times
6Proceed with the operation for your unit.
Base unit: {■}
Handset: {OFF}
LTo enter a name, see the character table in the operating
instructions.
Making calls 1Proceed with the operation for your unit.
Base unit: {C}
Handset: {MENU}i{#}{2}{8}{0}
2{V}/{^}: Select the desired entry.
3Proceed with the operation for your unit.
Base unit: Lift the corded handset.
Handset: {C}
Answering system (Base unit)
Answering on Press {ANSWER SELECT}repeatedly to select the desired
line(s). i{ANSWER ON}
LThe ANSWER ON indicator lights up.
Answering off {ANSWER ON}
LThe ANSWER ON indicator turns off.
Listening to messages {6}
Frequently asked questions
Question Cause/solution
How can I increase the handset
volume level?
LPress the navigator key {^} repeatedly while talking.
Why is the conversation noisy or
cutting off?
LTry to relocate the base unit so that distance from location to use
the handset will be minimized.
LIf the same problem occurs even if the handset is next to the base
unit, send your unit for service.
Can I add another accessory handset
to my base unit?
LYes, you can add up to 6 handsets (including the handset(s) sold
with your own base unit) to a single base unit.
LTo purchase accessory handset (KX-TGA939), please visit
http://www.panasonic.com
or call 1-800-332-5368. TTY users (hearing or speech impaired
users) can call 1-866-605-1277.
TG9391_QG(e).fm Page 4 Thursday, July 3, 2008 9:25 AM

– 5 –
Can I keep the batteries charging all
the time?
LYou can leave the handset on the charger anytime. This will not
harm the batteries.
How can I answer a call waiting call
(2nd call)?
LPress {CALL WAIT}when you hear the call waiting tone.
For further information, visit http://www.panasonic.com/help or refer to operating instructions.
Quick troubleshooting
Frequently asked questions
“No link to base. Reconnect AC adaptor.”
Remove the batteries for 10 seconds from the handset, and then insert the batteries into the
handset again.
Your telephone may need service.
Please visit http://www.panasonic.com/help for further troubleshooting.
Try to re-register the handset (page 7).
“No link to base. Reconnect AC adaptor.”is still displayed.
“No link to base. Reconnect AC adaptor.”is still displayed.
Re-registration failed.
Move closer to the base unit. Unplug, then plug the AC adaptor properly to the base unit and
AC outlet.
1Cordless handset shows:
TG9391_QG(e).fm Page 5 Thursday, July 3, 2008 9:25 AM

– 6 –
Quick troubleshooting
Lift up the handset from the charger.
Press {C} at the handset, then check if the display shows
“Talk”.
Check if the
telephone cord is
properly connected
to both the base
unit and telephone
line jack on the
wall.
Try to connect your
telephone into a
different line.
Press {s} , then check if the dial tone
is heard from the speaker on the back.
No dial tone Dial tone is heard.
2No dial tone is heard from handset.
Try remedy for 1
on previous page.
See if “Check tel line 1”or “Check tel line 2” is shown on the handset display.
Your telephone may need
service when only back
speaker provides a dial
tone.
Your telephone may need service.
Please visit http://www.panasonic.com/help for further troubleshooting.
“No link to base.
Reconnect AC
adaptor.”
is displayed.
“Talk”is displayed.
Displayed Not displayed
Still displayed
Still displayed
{C}
{s}
1
Talk Line1
LINE MUTE 2
MENU
2
L1
dB
=Volume
00-00-00
1
No link to base.
Reconnect AC
adaptor.
1
TG9391_QG(e).fm Page 6 Thursday, July 3, 2008 9:25 AM

– 7 –
Registering a handset to the base unit
The supplied handset and base unit are pre-registered. If for some reason the handset is not registered to
the base unit, register the handset.
{MENU}i{#}{1}{3}{0}
Press and hold {LOCATOR}for 5 seconds until the
registration tone sounds.
LThe next step should be completed within 90
seconds.
Press {OK}, then wait until a long beep sounds.
For further registration information, visit
http://www.panasonic.com/RegisterYourHandset
Handset
LINE1 LINE2MENU
{MENU}
Base unit
{LOCATOR}
Handset
BACK OK
Press LOCATOR
on base for 5sec
Then press OK
{OK}
TG9391_QG(e).fm Page 7 Thursday, July 3, 2008 9:25 AM

1Read this Quick Guide or Operating Instructions
LIf you lost the Operating Instructions, you can download a copy at
http://www.panasonic.com/help
2Visit our website:
http://www.panasonic.com/help
LFAQs and troubleshooting hints are available.
3Contact us via the web at:
http://www.panasonic.com/contactinfo
4Call us at:
1-800-211-PANA (1-800-211-7262)
LMonday - Friday 9:00am - 9:00pm (EST),
Saturday/Sunday 10:00am - 7:00pm (EST)
To order a replacement battery,
please call: 1-800-332-5368
Or visit:
http://www.panasonic.com/batterystore
IMPORTANT!
If your product is not working
properly. . .
