Panasonic AW-UE160WP User manual

Operating Instructions
Excerpted Version
Installation Instructions provided
4K Integrated Camera
DVQX2340YA
FJ1222GU1013 -FJ
Printed in Japan
ENGLISH
PJ
ENGLISH
Excerpted Version
Before installing and using this product, be sure to read “Read this rst!” (pages 4 and 25).
This manual contains information excerpted from the Operating Instructions.
For more information, please visit the Panasonic website (https://pro-av.panasonic.net/manual/en/index.html), and
refer to the Operating Instructions.
ESPAÑOL
Antes de instalar y usar este producto, asegúrese de leer “Lea esto primero!” (páginas 4 y 26).
Si desea obtener más información, visite el sitio web de Panasonic (https://pro-av.panasonic.net/manual/en/index.
html) y consulte las instrucciones de funcionamiento y las instrucciones de instalación.
Before operating this product, please read the instructions carefully and save this manual for future use.
Model No. AW‑UE160WP
Model No. AW‑UE160KP

22
 Trademarks and registered trademarks
• Microsoft®, Windows®, Windows®10, Microsoft Edge, Internet
Explorer®, ActiveX®and DirectX®are either registered trademarks
or trademarks of Microsoft Corporation in the United States and
other countries.
• Apple, Mac, macOS, iPadOS, iPhone, iPad, and Safari are
registered trademarks of Apple Inc., in the United States and other
countries.
• Android™ and Chrome™ browser are trademarks of Google LLC.
• Intel®and Intel®Core™ are trademarks or registered trademarks
of Intel Corporation in the United States and other countries.
• Adobe®and Reader®are either registered trademarks or
trademarks of Adobe Systems Incorporated in the United States
and/or other countries.
• The terms HDMI and HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of
HDMI Licensing Administrator, Inc. in the United States and other
countries.
• NDI is a registered trademark of NewTek, Inc. in the United
States.
• Other names of companies and products contained in these
Operating Instructions may be trademarks or registered
trademarks of their respective owners.
 About copyright and licence
It is expressly prohibited to distribute, copy, disassemble, reverse
compile, modify, reverse engineer, or export in violation of export
laws the software provided with the unit.
 Abbreviations
The following abbreviations are used in this manual.
• Windows®Internet Explorer® 11 32/64‑bit is abbreviated to
“Internet Explorer”.
For the purposes of this manual, the model numbers of the units are
given as listed in the table below.
Model number of unit Model number given in
manual
AW‑UE160WP AW-UE160
AW‑UE160KP
AW‑RP150G AW-RP150
AW‑RP60G AW-RP60
AV-HLC100P AV-HLC100
AV‑UHS500P AV-UHS500
 Illustrations and screen displays featured
in the manual
• What is shown in the manual’s illustrations and screen displays
may differ from how it is actually appears.
• Functions only available with Microsoft Edge (IE mode) are
indicated with the symbol.
• The screenshots are used in accordance with the guidelines of
Microsoft Corporation.

22 3
Contents
Read this first! ....................................................................................... 4
Lea esto primero! .................................................................................. 4
Installation precautions ........................................................................ 5
Before installation ................................................................................. 7
Service switch settings......................................................................... 7
How to install and connect the unit..................................................... 8
Removing the camera ......................................................................... 13
Stand-alone installation (when the mount bracket is going to be
used)................................................................................................. 14
Stand-alone installation (when the mount bracket is not going to be
used)................................................................................................. 16
When installing the unit on a desktop ................................................ 16
When mounting the unit on a tripod ................................................... 16
Connections......................................................................................... 17
Connecting an NDI|HX compatible switcher ...................................... 17
Connections with a controller (AW‑RP150) ....................................... 18
System example 1 (Serial control) ..................................................... 19
System example 2 (IP control) ........................................................... 20
System example 3 (IP image transmission, PoE++).......................... 21
System example 4 (NDI) .................................................................... 21
System example 5 (Fiber) .................................................................. 22
System example 6 (SMPTE ST2110) ................................................ 22
System example 7 (High Frame Rate)............................................... 23
System example 8 (USB tethering).................................................... 23
Appearance.......................................................................................... 24
Read this first! ..................................................................................... 25
Lea esto primero! ................................................................................ 26
Read this first! .................................................................................... 27
Note on grounding ............................................................................. 27
Before use............................................................................................ 27
Overview ............................................................................................ 27
Computer requirements ..................................................................... 27
Disclaimer of warranty ....................................................................... 28
Network security ................................................................................ 28
Features................................................................................................ 29
Accessories ......................................................................................... 31
How to remove the lens cap .............................................................. 31
Optional accessories .......................................................................... 31
Operating precautions ........................................................................ 32
Wireless remote control (optional accessory).................................. 34
Parts and their functions .................................................................... 35
Camera unit ....................................................................................... 35
Wireless remote control: AW‑RM50AG (optional accessory) ............ 48
Setting the remote control IDs ........................................................... 49
Network settings.................................................................................. 50
Use the Easy IP Setup Software to establish the unit’s settings........ 50
Using the EasyIP Setup Tool Plus to establish the unit’s settings ..... 50
Setting the initial account ................................................................... 52
Installing the plug-in viewer software ................................................. 52
How to turn the power on and off ...................................................... 53
Turning the power on ......................................................................... 53
Turning the power off ......................................................................... 53
Troubleshooting .................................................................................. 54
Specifications ...................................................................................... 63
Index ..................................................................................................... 63
Installation Instructions
Operating Instructions

Installation Instructions
Read this first!
WARNING:
To prevent injury, this apparatus must be securely attached to
the floor/wall in accordance with the installation instructions.
WARNING:
Installation should only be performed by qualified installation
personnel.
Improper installation may result in the entire apparatus falling
down and causing injury.
CAUTION:
This camera intended for use only with the Mount Bracket
enclosed with the unit.
Use with other apparatus is capable of resulting in instability
causing possible injury.
CAUTION:
To reduce the risk of fire or electric shock, install making sure
that the mounting screws do not come in contact with electrical
wiring within the wall.
indicates safety information.
Lea esto primero!
ADVERTENCIA:
Para evitar heridas, este aparato debe estar firmemente
instalado al piso/pared de acuerdo con las instrucciones de
instalación.
ADVERTENCIA:
La instalación solamente debe llevarla a cabo personal
cualificado.
Una instalación incorrecta podría provocar la caída del
dispositivo y causar lesiones.
PRECAUCIÓN:
Esta cámara ha sido diseñada para ser utilizada solamente con
la ménsula de montaje suministrada con la unidad.
La utilización con otros aparatos puede causar inestabilidad y
posibles lesiones.
PRECAUCIÓN:
Para reducir el riesgo de incendio o descarga eléctrica, instálelo
asegurándose de que los tornillos de montaje no entren en
contacto con el cableado eléctrico dentro de la pared.
indica información de seguridad.
ENGLISH
ESPAÑOL
4

Installation Instructions
Installation precautions
Panasonic does not accept any responsibility for accident or damage during installation if procedure in this manual is not followed.
To installation personnel
Read the “Installation Instructions” thoroughly and then perform the operation correctly and safely.
Also, always read the “Read this first!” (→ page 4) of this manual as they contain important information.
After the installation, give the “Installation Instructions” to the customer to save for future use.

Ensure that the installation work complies with the
technical standards governing electrical equipment.
 This unit is for indoor use only.
It cannot be used outdoors.
Avoid installation in a location where the unit will be exposed to direct
sunlight for extended periods or near a cooling or heating appliance.
Otherwise, deformation, discoloration, malfunctioning and/or
problems in operation may result. Operate the unit where it will not be
splashed or sprayed by water.
 Use the unit with an installation where the unit
is suspended from an overhead surface or with
a stand-alone installation.
Do not use the unit on its side or tilted at an angle.
<NOTE>
• Be absolutely sure to use the five bracket mounting screws (M4) for
mounting the mount bracket. These are supplied with the unit.
Do not use wood screws, nails, etc.
In the case of a concrete ceiling, secure the unit using anchor bolts
(for M4) or AY plug bolts (for M4).
Recommended clamping torque
M4 : 1.47 N · m {15 kgf · cm}
• The withdrawal strength of the mounting location for each screw
must be at least 520 N {52 kgf}.
• When installing on ceilings made from materials such as
plasterboard which may lack the required strength, reinforce
sufficiently or use an installation surface base (supplied by the
customer) (→ page 12).
• When using a mount bracket which is sold separately, read the
handling instructions.
• Do not hold the camera head while undertaking the installation work.
Doing so may cause malfunctioning.
OK NG OK NG
Desktop installation Hanging installation
 Concerning the installation location
Install the unit in a stable location which will not be susceptible to
shaking. If the unit is installed in a location which is susceptible to
shaking, this will cause the unit’s images to shake in turn.
Install the unit after conferring in detail with your dealer.
Install the unit on a ceiling that is strong enough (such as a concrete
ceiling).
If the unit is to be installed on a ceiling which is not strong enough,
reinforce the ceiling sufficiently first.
Install this unit in a stable location where it will not be shaken and
that has sufficient rigidity. Shaking of the installation location can
be the cause of performance deterioration and malfunctions in the
camera.
If the camera is installed in a location with insufficient stiffness,
the pan and tilt control characteristics may be adversely affected,
leading to unstable operation.
• In environments such as the following, there may be unusual operation
sounds during pan and tilt, and operational errors may occur.
If you are concerned about unstable pan and tilt operations after
installation, please contact your dealer.
<Installation examples that may cause performance
deterioration and malfunctions>
ASingle point attachment to a cylindrical pole structure that has a
small diameter
BSingle point attachment to a movable structure
 
 Do not install or use the unit in the following
kinds of locations.
• On walls (where the unit would be installed sideways)
• In locations (including places such as under the eaves of a
building) where the unit would be directly exposed to rain or water
• In locations such as kitchens where there are high concentrations
of steam and grease
• In outdoor locations or hot places where the temperature will
exceed 40 °C (104 °F)
• In cold locations where the temperature will drop below 0 °C (32 °F)
• In locations where the humidity will exceed 85%
• In locations where chemicals are used such as near swimming pools
• At sea, in coastal areas or in locations where corrosive gases are emitted
• In locations where radiation, X-rays, or strong radio waves or
magnetic fields are generated
• In locations where the unit would be subject to a great deal
of vibration such as on board a vehicle or ship (this unit is not
designed to be used in vehicles)
• In locations where the temperature is subject to sudden changes
such as near the air outlet of an air conditioner or near a door
which allows the outside air to come in
AW-UE160
main unit
Mounting conditions
Applicable mount bracket Mounting onto the ceiling
Mass Model No. Mass Mounting Recommended
screws
No. of
screws
Minimum withdrawal strength
(per screw)
Approx.
4.6 kg (10.12 lb)
(excluding mount
bracket)
Direct mount
(supplied
accessory)
Approx.
0.25 kg
(0.55 lb)
Hanging/Desktop M4 screws
(supplied accessory) 5
520 N {52 kgf}
• Ensure that the mounting strength
can support a weight that is at least
five times the total mass of the
equipment, including the camera’s
main unit.
4 5

Installation Instructions
 What to avoid to ensure that the unit will
perform stably over a prolonged period
• Using the unit for a prolonged period in a location with high
temperature and humidity levels will cause its parts to deteriorate
and shorten its service life.
• Ensure that a cooling unit or heating unit will not blow any air
directly toward the installation location.
 Be absolutely sure to use the supplied brackets
and screws to install the camera.
• Do not mount the unit by employing any methods other than those
specified.
• Do not remodel the mounting bracket or mounting screws provided
with the unit.

Before installation, always disconnect the DC
connector
When installing, always use the supplied components.
Do not disassemble or modify the wall mount adaptor.
 Tightening up the mounting screws
• Tighten up the screws and bolts securely to the degree that is
appropriate for each of the materials used in the mounting location
and structures.
• After tightening up the screws and bolts, check that there is no
unsteadiness and that the parts have been tightened securely.
• Use the specified tools and tighten the screws firmly.
• Tighten up the screws using the specified torque driver. Do not
use electrical drivers or impact drivers.

When the unit is no longer going to be used, do
not leave it lying around, but be absolutely sure
to dispose of it properly.
For details on how to remove the unit, refer to “Removing the
camera” (→ page 13).
 When installing, transferring or disposing of
the unit, be absolutely sure to hold it by its
pedestal area.
Problems may result if the camera head is held or rotated.
 Do not attach a filter, hood, extender or other
parts to the unit.
 Install the external DC power supply near the
main power outlet, and position it in such a
way that its power plug can be plugged into
and unplugged from the outlet easily.
When connecting the external DC power supply to a power outlet on
the ceiling or on any other surface where dust may collect, wipe off
the dust on the power plug at periodic intervals as an anti-tracking
measure.
 Power switch
This unit does not have a power switch. When the power
is supplied, the pan, tilt, zoom and focusing operations are
performed.*1Before proceeding with maintenance, be absolutely
sure to disconnect the power plug from the power outlet.
*1• Under factory default conditions, the unit will be in Power ON
mode when power is supplied for the first time. (Status display
lamp: Lit green)
• When the power supply is cut off while the unit is in Standby
mode, the unit will be in Standby mode the next time power is
supplied. (Status display lamp: Lit orange)
• When the power supply is cut off while the unit is in Power ON
mode, the unit will be in Power ON mode the next time power
is supplied. (Status display lamp: Lit green)
(For details, refer to “How to turn the power on and off”
(→ page 53).)
 Grounding
Before operating the unit, check that SIGNAL GND has been
securely grounded.
 If there is a possibility of noise interference
Either wire the cables so that the power cable (ceiling light cord) of
AC 100 V or more, and the signal cable are placed at least 1 meter
(3.3 ft) apart.
Alternatively run each cable through its own metal conduit.
(The metal conduits must be grounded.)
 Radio signal interference
If the unit is positioned near a TV or radio transmitting antenna or a
strong electrical field or magnetic field (such as that generated by a
motor, transformer or power lines), its images may be distorted and/
or the images may be affected by noise.
 When connecting the cables, ensure that the
connector areas will not be subject to any load.
Doing so may cause malfunctioning.
 Allowing the generated heat to escape
This unit allows the heat generated inside to escape from its
surfaces.
Do not install the unit in a location where it will be surrounded by
walls or other surfaces and where heat will be trapped.
In addition, the heat is dissipated to the bottom panel which will
warm up over time: This is normal and not indicative of any trouble.
 PoE++ power supplies
Use a PoE++ (IEEE 802.3bt compliant) compatible hub or power
supply device.
 Network settings
The network function of this unit does not work unless an initial
account is set up (except when using the Easy IP Setup Software
(→ page 50)). A personal computer is required to set up an initial
account. (→ page 52)
<NOTE>
• Network connection with AW‑RP150 or AW‑RP60 requires setup
of an initial account. (→ page 52)
When an initial account is not set up, AW‑RP150 or AW‑RP60 can
detect but cannot control this unit.
6
Installation precautions (continued)

Installation Instructions
Before installation
Be sure to configure the switches on the connector panel and bottom of
the unit before installing it.
Configuring the switches after the unit is installed may prove difficult.
Service switch settings
The service switches are located on the connector panel of the unit.
Perform switch settings before turning the unit on.
LAN
LINK ACT
SIGNAL
GND
12 V IN
G/L IN
1 2/PM
3G SDI OUT
SFP+ 12G SDI OUT
USB3.0 HOST
RS-422
SERVICE
1 - AUDIO INPUT - 2
SW1
ON
OFF
SW2 SW3 SW4
Service switch
Function Factory settings
SW1
Switches for initializing and initial settings
(Refer to the explanations in “Initialization 1”,
“Initialization 2”, “Direct start mode”)
OFF
SW2 OFF
SW3 OFF
SW4 OFF
Initialization 1
• Reset the user authentication settings and host authentication settings
for network connection.
(This will delete all the registered user information (IDs/passwords)
and host information (IP addresses).)
• With the service switches set as shown below, turn on the power of
the unit.
SW1
ON
OFF
SW2 SW3 SW4
<NOTE>
When initialization is complete, the status display lamp on the front of
the unit blinks green. Set the service switches back to their original
positions (SW1 to SW4 all OFF), then restart the unit.
Initialization 2
• The unit is reset to the state it was in at the time of purchase. (All
camera menu setting values and network setting values are reset.)
• With the service switches set as shown below, turn on the power of
the unit.
SW1
ON
OFF
SW2 SW3 SW4
<NOTE>
• When initialization is complete, the status display lamp on the front
of the unit blinks green. Set the service switches back to their original
positions (SW1 to SW4 all OFF), then restart the unit.
Direct start mode
• When the power of the unit is turned on, the pan‑tilt head (tilt) is not
returned to horizontal as part of the lens initializing operation. Use
when the tilt cannot be returned to horizontal, such as when the unit is
installed in a tight space.
SW1
ON
OFF
SW2 SW3 SW4
<NOTE>
• This may result in a slight change in tracking performance.
 Setting the installation method (“DESKTOP” or
“HANGING”) from the OSD menu
Set [DESKTOP] or [HANGING] in [PAN/TILT] – [INSTALL POSITION]
from the OSD menu of this unit.
INSTALL POSITION [DESKTOP, HANGING]
[DESKTOP] or [HANGING] is selected here as the method used to
install the unit.
DESKTOP Stand-alone installation
HANGING Suspended installation
<NOTE>
• When [HANGING] has been selected, the top, bottom, left and right
of the images will be reversed, and up/down/left/right control for
panning and tilting will also be reversed.
 Setting the wireless remote control ID
Set [CAM1] to [CAM4] in [MAINTENANCE] – [WIRELESS CONTROL] –
[WIRELESS ID] from the OSD menu of this unit.
WIRELESS ID [CAM1, CAM2, CAM3, CAM4]
Set the remote control ID (CAM1 to CAM4).
The “CAM1” to “CAM4” in this setting correspond to the CAMERA <1> to
<4> buttons on the wireless remote control.
(The factory setting is “CAM1”.)
SET MODE ON ー OPT ー OFF
OFF LOW HI AUTO
MENU
CAMERA
GAIN
1 2 3 4
1
4
7
10 11 12
8 9
5 6
2 3
PRESET MEMORY
PRESET
LIMIT
HOME
CAMERA <1> to <4> buttons
67

Installation Instructions
Be absolutely sure to read through the “Read this first!” (→ page 4) and “Installation precautions” (→ pages 5 to 6).
The procedure given here is for the kind of installation where the unit is suspended from an overhead surface, but the same steps are followed for a
stand‑alone installation.
If the ceiling panel is not strong enough to bear the unit’s weight, use the kind of mount bracket that is supported by anchor bolts
between the concrete ceiling and ceiling panel.
It is also recommended that you provide an inspection space or opening for access purposes in the area near where the equipment is
installed in order to facilitate installation and the wiring connections work.
For details on supplied accessories, refer to the page 31.
1. Check the mounting space.
• Refer to the illustration, and determine where the unit is to be installed and in which direction it should be mounted.
Factor in the unit mounting area and include space for the wires extending from its rear panel.
• The asterisk () in the illustration marks the position and dimensions of the hole for mounting the mount bracket.
168 (6-5/8)
(Space for the wires from the
rear panel)
350 (13-25/32) or more
(Space for the wires)
Hole for checking the positioning
The front panel of the unit on this side.
Unit: mm (inch)
Mount bracket
Hook for mounting the
drop-prevention wire
Unit mounting area
Through-hole for cable ø 40
(ø 1-9/16) (reference)
() Holes for mounting the
mount bracket: ø 4.5 (ø 3/16) × 5
Hole for mounting the
main unit mounting screw
() 50
(1-31/32)
() 25
(31/32) () 100
(3-15/16)
128 (5-1/32)
146.7 (5-25/32)
160.2 (6-5/16)
() 86.6
(3-13/32)
177 (6-31/32)
182.7 (7-3/16)
() 130 (5-1/8)
88.5 (3-15/32)
91.3 (3-19/32)
<NOTE>
• Before proceeding to install and connect the main unit, connect the LAN cable, HDMI cable and coaxial cables in the space above the ceiling panel,
and then pass the cables through the cable holes.
• For a power outlet which is used on the ceiling, be absolutely sure to take measures to deal with the tracking that may be caused by the accumulation
of dust and other foreign matter.
How to install and connect the unit
8

Installation Instructions
2. Mount the mount bracket onto the installation surface.
• Use the bracket mounting screws (M4, bind‑head: 10 mm (13/32 inches) long) supplied with the unit.
• For proper clamping torque, securely attach the screws using the specified tools.
Screw
diameter Clamping torque
M4 1.47 N · m {15 kgf · cm}
Bracket mounting screws × 5 (supplied)
(M4, bind-head)
<NOTE>
• Use only the screws supplied with the unit. Do not use any other screws such as wood screws, nails, etc.
3. Attach the drop-prevention wire.
• Loop the circle part of the drop-prevention wire, which has been attached to the bottom panel of the unit, around the end of the hook part of the
mount bracket.
• Pull the drop‑prevention wire, and check that it has been attached securely to the hook.
End of hook
Drop-prevention wire ALoop the circle part of the
drop-prevention wire around
the end of the hook part of the
mount bracket.
BPull the drop-prevention wire
back to check that it has
been attached securely to the
hook.
<NOTE>
• Do not do this work while holding the camera head since doing so may result in malfunctioning of the unit.
• The drop-prevention wire is designed to be used for installation where the unit is suspended from an overhead surface so do not subject it to the
weight of units other than the unit.
8 9
How to install and connect the unit (continued)

Installation Instructions
4. Mount the unit.
• Align the position of the hole for checking the positioning with the status display lamp.
• Align the holes on the camera main unit used to insert the bottom panel with the protrusions on the mount bracket used for inserting the camera,
push the bracket and camera firmly together, and rotate the main unit by about 15 degrees in the direction of the arrow.
• Secure the mount bracket to the unit using the main unit mounting screw (M3) as supplied.
• Attach the mount bracket securely with the prescribed tool using the clamping torque below.
• Be absolutely sure to verify that none of the screws are loose.
Screw
diameter Clamping torque
M3 0.78 N · m {8 kgf · cm}
Main unit mounting screw (M3 screw)
(with flat washer, spring washer)
Status display
lamp
Approx. 15°
On the camera
main unit:
Holes (×3)
used to insert
the bottom
panel
On the mount
bracket:
Protrusions (×3)
used for inserting
the camera
Hole for
checking the
positioning
<NOTE>
• Do not do this work while holding the camera head since doing so may result in malfunctioning of the unit.
• Use only the screws supplied. Do not use any other screws.
• Check that the unit has been mounted securely with no tilting or wobbling.
• The unit must be secured without fail using the main unit mounting screw before any of the cables are connected.
5. Check the mounting.
Check out the following points.
• The main unit mounting screw must be mounted securely.
• The unit must not tilt, and it must be mounted exactly.
• The unit must be securely installed.
• The unit pedestal part must not rotate even when an attempt
is made to turn it.
10
How to install and connect the unit (continued)

Installation Instructions
6. Connect the rear panel connectors.
<NOTE>
• Do not connect PoE cable to the RS‑422 port.
• For details on recommended products, refer to the catalog or consult your local dealer.
• Always disconnect the power supply before connecting or disconnecting cables.
Connecting or disconnecting cables while the power is turned on may result in malfunctions.
DC cable (External DC power supply)
LAN cable
USB cable
HDMI cable
Coaxial cable
10 11
How to install and connect the unit (continued)

Installation Instructions
This section describes the procedure for a hanging installation, but the same steps apply for a desktop installation.
First, mount the installation surface bracket (accessory) on the installation surface.
Next, attach the drop‑prevention wire to the installation surface bracket, and mount the unit onto the installation surface bracket.
 Mounting the installation surface bracket on the installation surface
• The use of anchor bolts is required for the installation.
1. Drive the anchor bolts into the concrete ceiling (withdrawal strength of 520 N (52 kgf) or more).
2. Mount the installation surface base.
• Provide the installation surface base that is appropriate for the installation location.
• Prepare an installation surface base that is sufficiently capable of bearing loads of 520 N (52 kgf) or more.
• Be sure to mount the installation surface base securely using nuts and flat washers.
3. Open holes for mounting the installation surface bracket (supplied) to the ceiling board (refer to the installation surface
bracket diagrams).
4. Attach the installation surface bracket to the installation surface base through the ceiling board.
• Make sure that the mounting screws (M4 screw × 5) you select are of sufficient length, taking into consideration the thicknesses of the ceiling panel
and the installation surface base (supplied by the customer).
• Prepare flat washers and nuts (all supplied by the customer) to ensure the attachment is secure.
Mounting screw (M4 screw × 5)
Concrete ceiling
Anchor bolt (withdrawal strength of 520 N
(52 kgf) or more)
Nut
Flat washer
Nut
Ceiling board
Installation surface bracket
Nut
Flat washer
Installation surface base
Approx. 50 mm (1-31/32") to 100 mm (3-15/16")
(ensure enough height to allow the tools to go in)
Nut
Anchor bolt
Flat washer
Nut
Installation surface base
Ceiling board
Installation surface bracket
Mounting screw (M4 screw × 5)
Approx. 300 mm
(11-13/16")
Approx. 200 mm
(7-7/8")
12
How to install and connect the unit (continued)

Installation Instructions
Removing the camera
1. Turn off the circuit breaker and power.
2. Disconnect the cables.
Disconnect the LAN cable, and HDMI cable, etc.
3. Remove the main unit mounting screw used to secure the unit and mount bracket.
4. Push the unit (A). Turn it approximately 15 degrees away from the installed position (B), and remove it (C).
Main unit mounting
screw (M3 screw) (with
flat washer, spring
washer)
Approx. 15°
<NOTE>
• Do not do this work while holding the camera head since doing so may result in malfunctioning of the unit.
5. Disengage the drop-prevention wire from the mount bracket.
APull the drop-prevention
wire in the direction
shown by the arrow
above.
BTwist the wire, and
remove the wire loop
through the opening in
the hook.
CPull the wire in the direction
shown by the arrow above, and
simply pull it out.
12 13

Installation Instructions
Stand-alone installation (when the mount bracket is going to be used)
The same steps are followed as for the kind of installation where the unit is suspended from an overhead surface (→ pages 8 to 11).
1. Check the mounting space.
<NOTE>
• As with installing the unit suspended from an overhead surface, carefully check the space where the unit will be mounted, and then decide if it is
appropriate to install the unit in that space.
2. Mount the mount bracket onto the installation surface.
Bracket mounting screws × 5 (supplied)
(M4, bind-head)
3. Attach the drop-prevention wire.
4. Mount the unit.
• Align the position of the hole for checking the positioning with the status display lamp.
• Align the holes on the camera main unit used to insert the bottom panel with the protrusions on the mount bracket used for inserting the camera,
push the bracket and camera firmly together, and rotate the main unit by about 15 degrees in the direction of the arrow.
• Secure the mount bracket to the unit using the main unit mounting screw (M3) as supplied.
Main unit mounting screw
(M3 screw) (with flat
washer, spring washer)
Status display lamp
On the camera main unit:
Holes (×3) used to insert
the bottom panel
On the mount bracket:
Protrusions (×3) used for
inserting the camera
Hole for checking the positioning
Attach the drop-prevention wire.
Approx. 15°
14

Installation Instructions
5. Check the mounting.
6. Connect the rear panel connectors.
<NOTE>
• Do not connect PoE cable to the RS‑422 port.
• For details on recommended products, refer to the catalog or consult your local dealer.
• Always disconnect the power supply before connecting or disconnecting cables.
Connecting or disconnecting cables while the power is turned on may result in malfunctions.
Coaxial cable
HDMI cable
USB cable
LAN cable
DC cable (External DC power supply)
14 15
Stand-alone installation (when the mount bracket is going to be used) (continued)

Installation Instructions
Stand-alone installation (when the mount bracket is not going to be used)
When installing the unit on a desktop
Place the unit flat on the surface.
<NOTE>
• Install the unit in a stable location which will not be susceptible to shaking. If the unit is installed in a location which is susceptible to shaking, this will
cause the unit’s images to shake in turn.
• Take care not to allow the unit to fall or otherwise be damaged during installation.
• When carrying the unit, do not hold it by its head.
• Do not take hold of the camera head or rotate it. Doing so may cause malfunctioning.
• Take care not to pull the connected cables. Doing so may cause the unit to fall and/or it may result in injury.
Ensure that the unit will not fall off.
OK NG
When mounting the unit on a tripod
Attach the tripod to the threaded holes for mounting the camera on the camera’s bottom panel.
Place the tripod on a completely flat and level surface.
Tighten the screws by hand to mount the tripod securely.
Use screw for mounting the tripod that satisfy the following standard.
Screw for mounting tripod
1/4-20UNC, ISO1222 (6.35 mm)
4.5 mm to 9 mm
(3/16 inches to 11/32 inches)
<NOTE>
• Do not install the unit where people will be passing back and forth.
• When using the unit mounted on a tripod, do not put the tripod high above the floor level.
• Mount the unit securely so there is no looseness. Looseness may cause the unit to fall off and/or result in injuries.
• When the unit is going to be used for a prolonged period of time, take steps to ensure that the unit will not topple or fall over and that it will not fall off
or fall down. After using the unit, restore the installation location to its original state without delay.
16

Installation Instructions
Connections
Connecting an NDI|HX compatible switcher
External DC
power supply
AW-UE160
AW-UE160
LAN cable
Switching hub
NDI|HX compatible switcher
AV-HLC100
Monitor Monitor
External DC
power supply
Remote Camera Controller
AW-RP150
16 17

Installation Instructions
Connections with a controller (AW-RP150)
 Example of connection for the function for cropping (CROP) 4K images to HD images
AW-UE160 AW-UE160
Remote camera controller
AW-RP150
External DC power
supply
External DC
power supply
Monitor
Monitor
12G SDI OUT
3G SDI OUT
3G SDI
ACTIVE THRU OUT
SDI IN
LAN cable
(Straight cable or cross cable)
Max. 100 m (328 ft)
LAN cable
(Straight cable or cross
cable)
Max. 100 m (328 ft)
• Use a category 5e cable for the LAN cable.
• When using 12G SDI OUT and 3G SDI OUT for the cropping and output, use HDMI output for 4K video.
18
Connections (continued)

Installation Instructions
System example 1 (Serial control)
AW-UE160 AW-UE160
SDI video signal
Live Switcher
AV-UHS500
Monitor 1 Monitor 2
Monitor Monitor
Pan-tilt head and camera
control signal (LAN
straight cable)
System TALLY
Third party controller
Genlock signal
generator
External DC
power supply RS-422
connector
Accessory
AC adaptor
18 19
Connections (continued)

Installation Instructions
System example 2 (IP control)
AW-UE160 AW-UE160
Genlock signal
generator
SDI video signal
Switching hub
LAN cable
Live Switcher
AV-UHS500
Monitor 1
Monitor 2
Monitor Monitor
LAN cable
Remote Camera Controller
AW-RP150
External DC
power supply
Accessory
AC adaptor
External DC
power supply
LAN connector
20
Connections (continued)
