Sound Control Technologies RC8-CQC User manual

Module Dimensions
RC8-CE™: 1.625”H x 7.5”W x 4.375”D
RC8-HE™: 1.375”H x 9.25”W x 5.375”D
RC8-HE™
RC8-CE™
Cisco Codec Plus, Codec Pro & SX80
Cisco Quadcam
W PS-48 48VDC
100-240V~47-63Hz
Power Supply
Cisco Touch10
Ethernet/POE
*Cisco Provided*
RCC-H001 [2]
3’ HDMI Cables
RCC-H016
3’ UTP Cable
Pin 1
RJ45 Pinout
o O g B b G br BR
1 2 3 4 5 6 7 8
T-568B
g G o B b O br BR
1 2 3 4 5 6 7 8
T-568A
LINK Cable Specs
Integrator-Supplied CAT6 STP Cable
EIA568A or EIA568B (Min. 30’ to 300’ Max)
LINK Cable
Power, Control, Audio & Video
PPC-018
1’ Power Cable
RCC-C037-0.3M
Angled UTP Cable
RCC-C014 [2]
1’ Angled
HDMI Cables
Important: Due to the power
demands of Cisco’s QuadCam, it
is best practice to utilize SCT’s
provided RC-RKL™ rack shelf to
facilitate ventilation.
RC8-CQC™ Application Guide

RC8-CQC™ Installation Instructions
Supporting the Cisco Quad Camera and
Cisco SX80, Plus & Pro Codecs
TEST YOUR SCTLink™ CABLE
We highly recommend using an Ethernet Network Tester/Analyzer alongside our provided PowerSniffer to confirm your
SCTLink™ wiring. Our PowerSniffer only tests conductor continuity and will not identify data integrity or capacity issues.
1. Test and verify your CAT6 STP or FUTP SCTLink™ cable for UTP 568A/568B. This cable must be between 30ft - 300ft.
The SCTLink™ cable between the RC8-CE module (transmitter) & RC8-HE module (receiver)
must always be a single, point-to-point CAT cable with no couplers or interconnections.
2. Connect the provided PowerSniffer to the Quad Camera end of your CAT6 STP or FUTP SCTLink™ cable.
3. Connect the other end of the SCTLink™ cable to the blue “SCTLink™” connection on the Head End module.
4. Connect the WPS-48 power supply to the Head End module.
5. Connect the WPS-48 power supply to AC mains.
6. If the SCTLink™ cable is properly terminated, it will display eight GREEN LEDs.
If you get any other result, stop and re-terminate cable .
7. Once your SCTLink™ cable has been tested, please disconnect the WPS-48 power supply from the RC8-HE module,
and the PowerSniffer from the SCTLink™ cable, before proceeding to install.
INSTALL THE EXTENSION KIT
Connect the camera-end cables:
1. Connect the RCC-C014 HDMI cables between the Quad
Camera’s HDMI 1 & 2 connectors RC8-CE’s “HDMI 1” and
“HDMI 2” ports.
2. Connect the RCC-C037-0.3M UTP cable between the
Quad Camera’s RJ45 Ethernet port and the RC8-CE’s
Ethernet port.
3. Connect the PPC-018 power cable between the Quad
Camera’s power connector and the RC8-CE’s “12VDC
Output” port.
Connect the codec-end cables:
4. Connect two 3 ft RCC-H001 HDMI cables between
the codec’s HDMI camera inputs and the RC8-HE’s
corresponding “HDMI Out 1 A” and “HDMI Out 2 A” port.
5. Connect the 3ft RCC-H016 UTP control cable between
the codec’s RJ45 camera Ethernet port and the RC8-
HE’s “Ethernet 1”.
Connect and Initiate the Extended System:
6. Connect one end of your CAT6 STP/FUTP SCTLink™
cable to the RC8-HE module’s blue “SCTLink™” port.
7. Connect the other end of the CAT6 STP/FUTP SCTLink™
cable to the RC8-CE module’s blue “SCTLink™” port.
8. Connect the WPS-48 power supply to the RC8-HE.
TECH SUPPORT: 203-854-5701 • WWW.SOUNDCONTROL.NET • © SOUND CONTROL TECHNOLOGIES, INC
•ALLOW UP TO TWO MINUTES FOR THE QUAD CAMERA SYSTEM TO INITIALIZE •
Power Supply Specications (AC-Mains Side): Input Voltage: 100VAC to 240VAC 47Hz to 63Hz. Efficiency: 85% minimum.
Turn-on Surge: Less than 60 amperes for a duration less than 1mS. Power Factor: 0.9 minimum (where applicable). 48VDC
power supply uses 2.80 amperes AC maximum. All specifications subject to change without notice.
Installation Status - Refer to our modules’ LEDs for installation status.
For assistance troubleshooting INACTIVE LED statuses, please contact Tech Support at 203-854-5701.
MODULE LED LABEL ACTIVE STATUS INACTIVE STATUS
RC8-CE OK LED 1 & 2 Blinking Green (~1 second interval) Blinking or Solid Red
RC8-HE OK LED 1 & 2 Blinking Green (~1 second interval) Blinking or Solid Red
RC8-HE LINK LED Solid Blue Solid Red or Dormant
RC8-HE HDCP 1 & 2 Blinking Green N/A
Cable Table - Part numbers, descriptions and functions of all SCT cables provided for the RC8-CQC™.
This kit is also inclusive of [1] RC-RKL™ Rack Shelf.
CABLE DESCRIPTION FUNCTION
[2] RCC-C014 1’ HDMI Cables Video connection between Quad Camera and RC8-CE module.
RCC-C037-0.3M 1’ Angled UTP Cable Control connection (Ethernet) between Quad Camera and RC8-CE module.
PPC-018 1’ Power Cable Power connection between Quad Camera and RC8-CE module.
[2] RCC-H001 3’ HDMI Cables Video connection between the codec and RC8-HE module.
RCC-H016 3’ UTP Cable Control connection (Ethernet) between the codec and RC8-HE module.
Updated: 5/14/2020
