Panasonic DMC-F2K Technical specifications

Basic
Operating Instructions
Digital Camera
GN VQT2T58
H0210HM0
Before use, please read these instructions completely.
Please also refer to Operating
Instructions (PDF format) recorded
on the CD-ROM containing the
Operating Instructions (supplied).
You can learn about advanced operation methods and
check the Troubleshooting.
Model No. DMC-F2
VQT2T58_DMC-F2_GN_EN.indd 1VQT2T58_DMC-F2_GN_EN.indd 1 2010/02/03 15:26:272010/02/03 15:26:27

2VQT2T58 (ENG)
Information for Your Safety
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT DAMAGE,
• DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING OR
SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES,
SHALL BE PLACED ON THE APPARATUS.
• USE ONLY THE RECOMMENDED ACCESSORIES.
• DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
Carefully observe copyright laws. Recording of pre-recorded tapes or discs or other
published or broadcast material for purposes other than your own private use may
infringe copyright laws. Even for the purpose of private use, recording of certain
material may be restricted.
• Please note that the actual controls and components, menu items, etc. of your Digital
Camera may look somewhat different from those shown in the illustrations in these
Operating Instructions.
• SDHC Logo is a trademark of SD-3C, LLC.
• Microsoft product screen shot(s) reprinted with permission from Microsoft Corporation.
• Other names, company names, and product names printed in these instructions are
trademarks or registered trademarks of the companies concerned.
THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE EQUIPMENT AND SHALL
BE EASILY ACCESSIBLE.
Product Identification Marking is located on the bottom of units.
Dear Customer,
We would like to take this opportunity to thank you for purchasing this Panasonic Digital
Camera. Please read these Operating Instructions carefully and keep them handy for
future reference.
VQT2T58_DMC-F2_GN_EN.indd 2VQT2T58_DMC-F2_GN_EN.indd 2 2010/02/03 15:26:292010/02/03 15:26:29

3
(ENG) VQT2T58
About the battery pack

CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
• Do not heat or expose to flame.
• Do not leave the battery(ies) in an automobile exposed to direct sunlight for a long
period of time with doors and windows closed.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 ºC or incinerate.
About the battery charger

CAUTION!
• DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN CABINET
OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS WELL VENTILATED.
TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE HAZARD DUE TO
OVERHEATING, ENSURE THAT CURTAINS AND ANY OTHER MATERIALS DO
NOT OBSTRUCT THE VENTILATION VENTS.
• DO NOT OBSTRUCT THE UNIT’S VENTILATION OPENINGS WITH NEWSPAPERS,
TABLECLOTHS, CURTAINS, AND SIMILAR ITEMS.
• DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED CANDLES,
ON THE UNIT.
• DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY FRIENDLY MANNER.
• The battery charger is in the standby condition when the AC power supply cord is
connected.
The primary circuit is always “live” as long as the power cord is connected to an
electrical outlet.
– If you see this symbol –
Information on Disposal in other Countries outside the European Union
This symbol is only valid in the European Union. If you wish to discard this
product, please contact your local authorities or dealer and ask for the
correct method of disposal.
VQT2T58_DMC-F2_GN_EN.indd 3VQT2T58_DMC-F2_GN_EN.indd 3 2010/02/03 15:26:292010/02/03 15:26:29

4VQT2T58 (ENG)
Cautions for Use
•
Do not use any other cables except a genuine Panasonic AV cable (DMW-AVC1:optional).
• Do not use any other USB connection cables except the supplied one.
• Always use a genuine Panasonic AC adaptor (DMW-AC5G: optional).
• When using an AC adaptor, use the AC cable supplied with the AC adaptor.
Keep the camera as far away as possible from electromagnetic equipment (such as
microwave ovens, TVs, video games etc.).
• If you use the camera on top of or near a TV, the pictures and sound on the camera may
be disrupted by electromagnetic wave radiation.
• Do not use the camera near cell phones because doing so may result in noise adversely
affecting the pictures and sound.
• Recorded data may be damaged, or pictures may be distorted, by strong magnetic fields
created by speakers or large motors.
• Electromagnetic wave radiation generated by microprocessors may adversely affect the
camera, disturbing the pictures and sound.
• If the camera is adversely affected by electromagnetic equipment and stops functioning
properly, turn the camera off and remove the battery or disconnect AC adaptor (DMW-
AC5G: optional). Then reinsert the battery or reconnect AC adaptor and turn the camera
on.
Do not use the camera near radio transmitters or high-voltage lines.
• If you record near radio transmitters or high-voltage lines, the recorded pictures and
sound may be adversely affected.
Care of the camera
• Do not strongly shake or bump the camera by dropping it etc.
This unit may malfunction, recording pictures may no longer be possible or the lens or
the LCD monitor may be damaged.
• We strongly recommend you do not leave the camera in your trousers pocket when you
sit down or forcefully insert it into a full or tight bag etc.
Damage to the LCD monitor or personal injury may result.
• Be particularly careful in the following places as they may cause this unit to
malfunction.
– Places with a lot of sand or dust.
– Places where water can come into contact with this unit such as when using it on a
rainy day or on a beach.
• Do not touch the lens or the sockets with dirty hands. Also, be careful not to
allow liquids, sand and other foreign matter to get into the space around the lens,
buttons etc.
• If water or seawater splashes on the camera, use a dry cloth to wipe the camera
body carefully.
About Condensation (When the lens is fogged up)
• Condensation occurs when the ambient temperature or humidity changes. Be careful of
condensation since it causes lens stains, fungus and camera malfunction.
• If condensation occurs, turn the camera off and leave it for about 2 hours. The fog will
disappear naturally when the temperature of the camera becomes close to the ambient
temperature.
■


VQT2T58_DMC-F2_GN_EN.indd 4VQT2T58_DMC-F2_GN_EN.indd 4 2010/02/03 15:26:292010/02/03 15:26:29

5
(ENG) VQT2T58
About cards that can be used in this unit
You can use an SD Memory Card and an SDHC Memory Card.
• When the term card is used in these operating instructions this refers to the following
types of Memory Cards.
– SD Memory Card (8 MB to 2 GB)
– SDHC Memory Card (4 GB to 32 GB)
More specific information about memory cards that can be used with
this unit.
• When you use a card of 4 GB or more capacity, you can use only
the SDHC Memory Card with SDHC logo that is based on the SD
Standard.
Please confirm the latest information on the following website.
http://panasonic.jp/support/global/cs/dsc/
(This Site is in English only.)
• Keep the Memory Card out of reach of children to prevent swallowing.
About illustrations in these operating instructions
• Please note that the appearance of the product, the illustration or the menu screen are a
little different from those in actual use.


Contents
Information for Your Safety.................................................................................................. 2
Standard Accessories......................................................................................................... 6
Names of the Components................................................................................................. 7
Charging the Battery .......................................................................................................... 8
Inserting/Removing the Battery/Card (Optional) .............................................................. 10
Setting Date/Time (Clock Set).......................................................................................... 11
About the Mode and Menu Operation .............................................................................. 12
Mode switching .......................................................................................................... 12
About the menu operation.......................................................................................... 13
Taking Pictures Using the Automatic Function (Auto Scene Mode) ................................. 15
Scene detection ......................................................................................................... 16
Taking Pictures with Your Favorite Settings (Normal Picture Mode) ................................. 17
Focusing..................................................................................................................... 17
Playing Back Pictures (Normal Playback Mode) .............................................................. 18
Deleting Pictures ..............................................................................................................19
To delete a single picture ........................................................................................... 19
To delete multiple pictures (up to 50) or all the pictures............................................. 19
Reading the Operating Instructions (PDF format) ............................................................ 20
Specifications ................................................................................................................... 21
•
•
•
•
•
•
VQT2T58_DMC-F2_GN_EN.indd 5VQT2T58_DMC-F2_GN_EN.indd 5 2010/02/03 15:26:292010/02/03 15:26:29

6VQT2T58 (ENG)
1 CGA-S/106C
4 K1HA08AD0001
6 VFC4297
2 DE-A60A
5 VFF0628
7 VGQ0D56
3 K2CJ29A00002
Check that all the accessories are included before using the
camera. Product numbers are correct as of January 2010. These
may be subject to change.
1 Battery Pack
(Indicated as battery in the text)
Charge the battery before use.
2 Battery Charger
(Indicated as charger in the text)
3 AC Cable
4 USB Connection Cable
5 CD-ROM
• Software:
Use it to install the software to your PC.
• Operating Instructions
6 Hand Strap
7 Battery Case
• SD Memory Card and SDHC Memory Card are indicated as
card in the text.
• Card is optional.
You can record or play back pictures on the built-in
memory when you are not using a card.
• Consult the dealer or your nearest Service Centre if you lose
the supplied accessories. (You can purchase the accessories
separately.)
Standard Accessories
VQT2T58_DMC-F2_GN_EN.indd 6VQT2T58_DMC-F2_GN_EN.indd 6 2010/02/03 15:26:302010/02/03 15:26:30

7
(ENG) VQT2T58
98
4
7
56
3
2
1
AV OUT
DIGITAL
10
16
14
13
11
15
17
12
18
1 Zoom lever
2 Shutter button
3 Camera ON/OFF switch
4 Microphone
5 Speaker
6 Self-timer indicator
AF assist lamp
7 Flash
8 Lens part
9 Lens barrel
10 LCD monitor
11 Recording/playback switch
12 Cursor buttons
A: e/Exposure compensation
B: r/Macro button
C: w/Self-timer button
D: q/Flash mode button
In these operating instructions, operations using the cursor buttons
are described as follows.
e.g.: When you press the r(p) button.
or Press
r
19 20
21 22
13 [MODE] button
14 [MENU/SET] button
15 [DISPLAY] button
16 [Q.MENU]/Delete button
17 Hand strap eyelet
• Attach the strap when using the camera to prevent it from dropping.
18 [AV OUT/DIGITAL] socket
19 Tripod receptacle
• When you use a tripod, make sure the tripod is stable with
the camera attached to it.
20 Card/Battery door
21 DC coupler cover
• When using an AC adaptor, ensure that the Panasonic DC
coupler (DMW-DCC4; optional) and AC adaptor (DMW-
AC5G; optional) are used.
22 Release lever
Names of the Components
VQT2T58_DMC-F2_GN_EN.indd 7VQT2T58_DMC-F2_GN_EN.indd 7 2010/02/03 15:26:302010/02/03 15:26:30

8VQT2T58 (ENG)
About batteries that you can use with this unit
Supplied battery or dedicated optional batteries (DMW-BCF10E) can be used with
this camera.
It has been found that counterfeit battery packs which look very similar to the genuine
product are made available to purchase in some markets. Some of these battery packs
are not adequately protected with internal protection to meet the requirements of
appropriate safety standards. There is a possibility that these battery packs may lead
to fire or explosion. Please be advised that we are not liable for any accident or failure
occurring as a result of use of a counterfeit battery pack. To ensure that safe products are
used we would recommend that a genuine Panasonic battery pack is used.
• Use the dedicated charger and battery.
•
The camera has a function for distinguishing batteries which can be used safely. The
dedicated battery supports this function. The only batteries suitable for use with this unit are
genuine Panasonic products and batteries manufactured by other companies and certified
by Panasonic. (Batteries which do not support this function cannot be used). Panasonic
cannot in any way guarantee the quality, performance or safety of batteries which have been
manufactured by other companies and are not genuine Panasonic products.
• The battery is not charged when the camera is shipped. Charge the battery before use.
• Charge the battery with the charger indoors.
• Charge the battery in a temperature between 10 °C to 35 °C. (The battery temperature
should also be the same.)
1Attach the battery paying attention to the direction
of the battery.
2Connect the charger to the electrical outlet.
• Charging starts when the [CHARGE] indicator Alights
green.
• Charging is complete when the [CHARGE] indicator A
turns off (after approx. 100 min).
• The AC cable does not fit entirely into the AC input
terminal. A gap will remain as shown on the right.
3Detach the battery after charging is completed.

Charging the Battery
VQT2T58_DMC-F2_GN_EN.indd 8VQT2T58_DMC-F2_GN_EN.indd 8 2010/02/03 15:26:302010/02/03 15:26:30

9
(ENG) VQT2T58
When the [CHARGE] indicator flashes
• The battery temperature is excessively high or low. The charging time will be longer than
normal. Also, charging may not be completed.
• The terminals of the charger or the battery are dirty. In this case, wipe them with a dry
cloth.
Note
• After charging is completed, be sure to disconnect the power supply device from the
electrical outlet.
• The battery becomes warm after using it, and while and after charging. The camera also
becomes warm during use. This is not a malfunction.
• The battery will be exhausted if left for a long period of time after being charged.
• The battery can be recharged even when it still has some charge left, but it is not
recommended that the battery charge be frequently topped up while the battery is fully
charged. (The battery has characteristics that will reduce its operating duration and
cause the battery to swell up.)
• When the operating time of the camera becomes extremely short even after properly
charging the battery, the life of the battery may have expired. Buy a new battery.
• Do not leave any metal items (such as clips) near the contact areas of the power
plug. Otherwise, a fire and/or electric shocks may be caused by short-circuiting or
the resulting heat generated.
Battery life
The number of recordable pictures (By CIPA standard in Normal Picture Mode [1])
Supplied battery Optional battery
Number of recordable
pictures Approx. 300 pictures Approx. 390 pictures
Recording time Approx. 150 min Approx. 195 min
Recording conditions by CIPA standard
• Temperature: 23 °C/Humidity: 50% when the LCD monitor is on.
• Using a Panasonic SD Memory Card (32 MB)
• Starting recording 30 seconds after the camera is turned on.
• Recording once every 30 seconds, with full flash every second recording.
• Rotating the zoom lever from Tele to Wide or vice versa in every recording.
•
Turning the camera off every 10 recordings. Leaving the camera until the battery cools down.
• CIPA is an abbreviation of [Camera & Imaging Products Association].
The number of recordable pictures varies depending on the recording interval
time. If the recording interval time becomes longer, the number of recordable
pictures decreases. (e.g. When recording once every 2 minutes: about 1/4 of the
number when recording once every 30 seconds)
Supplied battery Optional battery
Playback time Approx. 330 min Approx. 420 min
The number of recordable pictures and playback time will vary depending on the
operating conditions and storing condition of the battery.


VQT2T58_DMC-F2_GN_EN.indd 9VQT2T58_DMC-F2_GN_EN.indd 9 2010/02/03 15:26:302010/02/03 15:26:30

10 VQT2T58 (ENG)
Charging
Supplied battery Optional battery
Charging time¼Approx. 100 min Approx. 130 min
with the supplied charger
The charging time will vary slightly depending on the status of the battery and the
conditions in the charging environment.
When the charging has been completed successfully, the [CHARGE] indicator turns off.
Note
• The battery may swell and its operating time may become shorter as the number of
times it is charged increases. For long term battery use, we recommend you do not
frequently charge the battery before it is exhausted.
• The performance of the battery may temporarily deteriorate and the operating time may
become shorter in low temperature conditions (e.g. skiing/snowboarding).
Inserting/Removing the Battery/Card (Optional)
• Check that the camera is turned off.
• We recommend using a Panasonic card.
1Slide the release lever in the direction of
the arrow and open the card/battery door.
• Always use genuine Panasonic batteries (CGA-
S/106C: supplied or DMW-BCF10E: optional).
• If you use other batteries, we cannot guarantee
the quality of this product.
2Battery: Insert it fully being careful about
the direction for insert. Pull the lever A
in the direction of the arrow to remove
the battery. Card: Push it fully until it
clicks being careful about the direction
for insert. To remove the card, push the
card until it clicks, then pull the card out
upright.
BDo not touch the connection terminals of the
card.
• The card may be damaged if it is not fully inserted.

¼
VQT2T58_DMC-F2_GN_EN.indd 10VQT2T58_DMC-F2_GN_EN.indd 10 2010/02/03 15:26:312010/02/03 15:26:31

11
(ENG) VQT2T58
31: Close the card/battery door.
2: Slide the release lever in the direction
of the arrow.
• If the card/battery door cannot be completely
closed, remove the card, check its direction and
then insert it again.
Setting Date/Time (Clock Set)
• The clock is not set when the camera is shipped.
A
B
ON OFF
1Turn the camera on.
• When you turn the camera on, [PLEASE SET THE
CLOCK] message appears. (It does not appear in
Playback Mode.)
A[MENU/SET] button
BCursor buttons
2Press [MENU/SET].
3Press
w/qto select the items (year, month, day, hour, minute, display
sequence or time display format), and press e/rto set.
Cq
Dw
CTime at the home area
DTime at the travel destination
4: Cancel without setting the clock.
• Select either [24HRS] or [AM/PM] for the
time display format.
• AM/PM is displayed when [AM/PM] is
selected.
4Press [MENU/SET].
• After completing the clock settings, turn the camera off. Then turn the camera
back on, switch to Recording Mode, and check that the display reflects the
settings that were performed.
• When [MENU/SET] has been pressed to complete the settings without the clock
having been set, set the clock correctly by following the “Changing the clock
setting” procedure.
VQT2T58_DMC-F2_GN_EN.indd 11VQT2T58_DMC-F2_GN_EN.indd 11 2010/02/03 15:26:312010/02/03 15:26:31

12 VQT2T58 (ENG)
Changing the clock setting
1Press [MENU/SET] in Normal Picture Mode.
2Press
e/rto select [CLOCK SET].
3Press
qand perform steps 3and 4for setting.
4Press [MENU/SET] to close the menu.
• You can also set the clock in the [SETUP] menu.
• The clock setting is maintained for 3 months using the built-in clock battery even without
the battery. (Leave the charged battery in the unit for 24 hours to charge the built-in
battery.)
About the Mode and Menu Operation
Mode switching
MODE
1Slide the recording/playback switch Ato
1(right) or 5(left).
1: Recording Mode
5: Playback Mode
MODE
2Press [MODE] to display the mode
selection screen.
(Example: Normal Picture Mode)
3
Press e/rto select a mode and press
[MENU/SET] to close the menu.
VQT2T58_DMC-F2_GN_EN.indd 12VQT2T58_DMC-F2_GN_EN.indd 12 2010/02/03 15:26:312010/02/03 15:26:31

13
(ENG) VQT2T58
List of Recording Modes
;Auto Scene Mode Taking pictures easily.
1Normal Picture Mode Taking pictures in the desired setting.
5Scene Mode Taking pictures according to the scene.
6Motion Picture Mode This mode allows you to record motion pictures
with audio.
List of Playback Modes
9Normal Play Mode Playing back the pictures normally.
8Slide Show Mode Playing back the pictures continuously.
zFavorite Play Mode
Playing back the pictures set as your favorite.
• Pictures do not appear when the [FAVORITE]
is set to [OFF].
About the menu operation
The camera comes with menus that allow you to set the settings for taking pictures and
playing them back just as you like.
In particular, the [SETUP] menu contains some important settings relating to the camera’s
clock and power. Check the settings of this menu before proceeding to use the camera.
In Recording Mode
In Playback Mode 
1[REC] menu 9[PLAYBACK] menu
This menu lets you set the coloring, sensitivity,
or number of pixels, etc. of the pictures you are
recording.
This menu lets you make the protection or
print settings, etc. of recorded pictures.
e[SETUP] menu
• This menu lets you perform the clock settings, select the operating beep tone settings and
set other settings which make it easier for you to operate the camera.
• Available in Recording or Playback Mode.
How to use the menu
1Press [MENU/SET] to display the menu.
• You can switch menu screens by the page from
any menu item by rotating the zoom lever.
(Example: Selecting the Normal Picture Mode
[1])
2Press
e/rto select a menu item.
(Example: Selecting [AF MODE])
• You can move to the next page by pressing rat
the very bottom.



VQT2T58_DMC-F2_GN_EN.indd 13VQT2T58_DMC-F2_GN_EN.indd 13 2010/02/03 15:26:312010/02/03 15:26:31

14 VQT2T58 (ENG)
3Press
q.
• Depending on the item, the settings may not
appear or it may be displayed in a different way.
4Press
e/rto select a setting.
(Example: Selecting [3])
5Press [MENU/SET] to confirm your
setting.
6Press [MENU/SET] to close the menu.
Switching to the [SETUP] menu
When the camera shows the menu screen after step 1on “How to use the menu”:
1Press
wto move the menu icon.
2Press
rto select the [SETUP] menu icon [e].
3Press
qto move to the menu item list.
Proceed to step 2on “How to use the menu”.
VQT2T58_DMC-F2_GN_EN.indd 14VQT2T58_DMC-F2_GN_EN.indd 14 2010/02/03 15:26:322010/02/03 15:26:32

15
(ENG) VQT2T58
Taking Pictures Using the Automatic Function
(Auto Scene Mode)
Recording Mode: ;
The camera automatically sets the appropriate settings according to the subject and
recording condition. This mode is recommended for beginners to take pictures easily.
MODE
• The following functions are activated
automatically.
– Scene detection/Face detection/Motion
detection/Backlight Compensation
AShutter button
BRecording/playback switch
1Slide the recording/playback switch to [1] and
press [MODE].
2Press
e/rto select [AUTO SCENE MODE] and
then press [MENU/SET].
3Hold this unit gently with both hands, keep your
arms still at your side and stand with your feet
slightly apart.
CFlash
DAF assist lamp
4Press the shutter button halfway to focus.
• The focus indication Elights green when the subject is focused.
F
E
• The AF area Fis displayed around the subject’s
face by the face detection function. In other cases,
it is displayed at the point on the subject which is in
focus.
• The focus range is 5 cm (Wide)/50 cm (Tele) to 7.
• The maximum close-up distance (the shortest
distance at which the subject can be taken) differs
depending on the zoom magnification.
5Press the shutter button fully (push it in further), and take
the picture.
• The access indication lights red when pictures are being recorded on
the built-in memory (or the card).
VQT2T58_DMC-F2_GN_EN.indd 15VQT2T58_DMC-F2_GN_EN.indd 15 2010/02/03 15:26:322010/02/03 15:26:32

16 VQT2T58 (ENG)
Scene detection
When the camera identifies the optimum scene, the icon of the scene concerned is
displayed in blue for 2 seconds, after which its color changes to the usual red.
;3[i-PORTRAIT]
4[i-SCENERY]
2[i-MACRO]
5[i-NIGHT PORTRAIT] • Only when [q] is selected
1[i-NIGHT SCENERY]
• [;] is set if none of the scenes are applicable, and the standard settings are set.
Face detection
When [3] or [5] is selected, the camera automatically detects a
person’s face, and it will adjust the focus and exposure.
Note
• Due to conditions such as the ones below, a different scene may
be identified for the same subject.
– Subject conditions: When the face is bright or dark, The size of the subject, The
distance to the subject, The contrast of the subject, When the subject is moving, When
zoom is used
– Recording conditions: Sunset, Sunrise, Under low brightness conditions, When the
camera is shaken
• To take pictures in an intended scene, it is recommended that you take pictures in the
appropriate Recording Mode.
The backlight compensation
Backlight refers to when light comes from the back of a subject.
In this case, the subject will become dark, so this function compensates the backlight by
brightening the whole of the picture automatically.


VQT2T58_DMC-F2_GN_EN.indd 16VQT2T58_DMC-F2_GN_EN.indd 16 2010/02/03 15:26:332010/02/03 15:26:33

17
(ENG) VQT2T58
Taking Pictures with Your Favorite Settings
(Normal Picture Mode)
Recording Mode: 1
This mode allows you to take pictures freely as more options are available than Auto
Scene Mode [;].
MODE
1Slide the recording/playback switch to [1]
and press [MODE].
ARecording/playback switch
2Press
e/rto select [NORMAL PICTURE]
and press [MENU/SET].
3Aim the AF area to the point you want to
focus on.
4Press the shutter button Bhalfway to focus.
• The focus indication (green) lights when the subject is focused.
• The focus range is 50 cm to 7.
5Press the shutter button fully (push it in further), and take
the picture.
• The access indication lights red when a picture is being recorded on
the built-in memory (or the card).
Focusing
Aim the AF area at the subject, and then press the shutter button halfway.
Focus When the subject
is focused
When the subject
is not focused
Focus indication On Blinks
AF area WhiteGreen WhiteRed
Sound Beeps 2 times Beeps 4 times
CFocus indication
DAF area (normal)
EAF area (when using the digital zoom or when it is dark)
VQT2T58_DMC-F2_GN_EN.indd 17VQT2T58_DMC-F2_GN_EN.indd 17 2010/02/03 15:26:332010/02/03 15:26:33

18 VQT2T58 (ENG)
Playing Back Pictures (Normal Playback Mode)
Playback Mode: 9
A
1Slide the recording/playback switch Ato [5].
• Normal playback is set automatically in the following
cases:
– When the mode was switched to the Playback Mode.
– When the camera was turned on while the recording/
playback switch was at [5].
2Press
w/qto select the picture.
B
C
w: Play back the previous picture
q: Play back the next picture
• Speed of picture forwarding/rewinding
changes depending on the playback status.
Fast forwarding/Fast rewinding
Press and hold w/qduring playback.
• The file number Band the picture number Conly
change one by one.
Release w/qwhen the number of the desired picture appears to play back the picture.
• If you keep pressing w/q, the number of pictures forwarded/rewound increases.

VQT2T58_DMC-F2_GN_EN.indd 18VQT2T58_DMC-F2_GN_EN.indd 18 2010/02/03 15:26:332010/02/03 15:26:33

19
(ENG) VQT2T58
Deleting Pictures
Playback Mode: 9z
Once deleted, pictures cannot be recovered.
• Pictures on the built-in memory or the card, which are being played back, will be deleted.
To delete a single picture
DISPLAY
1Select the picture to be deleted, and then press
[4].
2Press
wto select [YES] and then press
[MENU/SET].
To delete multiple pictures (up to 50) or all the pictures
1Press [4].
2Press
e/rto select [DELETE MULTI] or [DELETE ALL] and then
press [MENU/SET].
• [DELETE ALL] step 5.
DISPLAY
3Press
e/r/w/qto select the picture and
then press [DISPLAY] to set. (Repeat
this step.)
• The selected pictures appear with [b]. When
[DISPLAY] is pressed again, the setting is
canceled.
4Press [MENU/SET].
5Press
eto select [YES] and then press [MENU/SET] to set.
VQT2T58_DMC-F2_GN_EN.indd 19VQT2T58_DMC-F2_GN_EN.indd 19 2010/02/03 15:26:332010/02/03 15:26:33

20 VQT2T58 (ENG)
Reading the Operating Instructions (PDF format)
• You have practised the basic operations introduced in these operating instructions and
want to progress to advanced operations.
• You want to check the Troubleshooting.
In these kinds of situations refer to Operating Instructions (PDF format) recorded on the
CD-ROM containing the Operating Instructions (supplied).
[Windows]
1Turn the PC on and insert the CD-ROM containing the Operating
Instructions (supplied).
2Click the [Operating Instructions].
3Select the desired language and
then click [Operating Instructions]
to install.
ATo return to the install menu.
4Double click the “Operating In-
structions” shortcut icon on the
desktop.
When the Operating Instructions (PDF
format) will not open
You will need Adobe Acrobat Reader 5.0 or later or Adobe Reader 7.0 or later to browse
or print the Operating Instructions (PDF format).
Insert the CD-ROM containing the Operating Instructions (supplied), click [B] and then
follow the messages on the screen to install.
(Compatible OS: Windows 2000 SP4/Windows XP SP2 or SP3/Windows VISTA SP1 or
SP2/Windows 7)
• You can download and install a version of Adobe Reader that you can use with your OS
from the following Web Site.
http://get.adobe.com/reader/otherversions
To uninstall the Operating Instructions (PDF format)
Delete the PDF file from the “Program Files\Panasonic\Lumix\” folder.
• When the contents in the Program Files folder cannot be displayed, click the [Show the
contents of this folder] to display them.
[Macintosh]
1Turn the PC on and insert the CD-ROM containing the Operating
Instructions (supplied).
2Open the “Manual” folder in the CD-ROM and then copy the PDF file
with the desired language inside the folder.
3Double click the PDF file to open it.


B A
VQT2T58_DMC-F2_GN_EN.indd 20VQT2T58_DMC-F2_GN_EN.indd 20 2010/02/03 15:26:342010/02/03 15:26:34
