Panasonic DMC-F3K Technical specifications

Basic Operating Instructions
Digital Camera
Model No. DMC-F3
DMC-F4
Before use, please read these instructions completely.
Please also refer to Operating
Instructions (PDF format)
recorded on the CD-ROM
containing the Operating Instructions
(supplied).
You can learn about advanced operation methods
and check the Troubleshooting.
until
2010/2/20
EB
Web Site: http://www.panasonic-europe.com
VQT2R92
1AG6P1P5786--(S)
Model number suffix “EB” denotes UK model.
DMC-F3Basic-VQT2R92_eng.book 1 ページ ２０１０年１月１３日 水曜日 午後１時２０分

VQT2R92 (ENG)
2
Dear Customer,
We would like to take this opportunity to thank you for purchasing this
Panasonic Digital Camera. Please read these Operating Instructions
carefully and keep them handy for future reference. Please note that the
actual controls and components, menu items, etc. of your Digital Camera
may look somewhat different from those shown in the illustrations in these
Operating Instructions.
Carefully observe copyright laws.
•Recording of pre-recorded tapes or discs or other published or broadcast
material for purposes other than your own private use may infringe copyright
laws. Even for the purpose of private use, recording of certain material may be
restricted.
Information for Your Safety
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT
DAMAGE,
•DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING
OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH
AS VASES, SHALL BE PLACED ON THE APPARATUS.
•USE ONLY THE RECOMMENDED ACCESSORIES.
•DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE
EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.
Product Identification Marking is located on the bottom of units.
DMC-F3Basic-VQT2R92_eng.book 2 ページ ２０１０年１月１３日 水曜日 午後１時２０分

3
(ENG) VQT2R92
Caution for AC mains lead
For your safety, please read the following
text carefully.
This appliance is supplied with a moulded
three pin mains plug for your safety and
convenience.
A 5-ampere fuse is fitted in this plug.
Should the fuse need to be replaced
please ensure that the replacement fuse
has a rating of 5-ampere and that it is
approved by ASTA or BSI to BS1362.
Check for the ASTA mark or the BSI
mark on the body of the fuse.
If the plug contains a removable fuse
cover you must ensure that it is refitted
when the fuse is replaced.
If you lose the fuse cover the plug must
not be used until a replacement cover is
obtained.
A replacement fuse cover can be
purchased from your local dealer.
CAUTION!
IF THE FITTED MOULDED PLUG IS
UNSUITABLE FOR THE SOCKET
OUTLET IN YOUR HOME THEN THE
FUSE SHOULD BE REMOVED AND
THE PLUG CUT OFF AND DISPOSED
OF SAFELY.
THERE IS A DANGER OF SEVERE
ELECTRICAL SHOCK IF THE CUT OFF
PLUG IS INSERTED INTO ANY 13-
AMPERE SOCKET.
If a new plug is to be fitted please
observe the wiring code as stated below.
If in any doubt please consult a qualified
electrician.
IMPORTANT
The wires in this mains lead are coloured
in accordance with the following code:
Blue: Neutral, Brown: Live.
As these colours may not correspond with
the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured Blue must be
connected to the terminal which is marked
with the letter N or coloured Black or Blue.
The wire which is coloured Brown must be
connected to the terminal which is marked
with the letter L or coloured Brown or Red.
WARNING: DO NOT CONNECT EITHER
WIRE TO THE EARTH TERMINAL
WHICH IS MARKED WITH THE LETTER
E, BY THE EARTH SYMBOL OR
COLOURED GREEN OR
GREEN/YELLOW.
THIS PLUG IS NOT WATERPROOF-
KEEP DRY.
Before use
Remove the connector cover.
How to replace the fuse
The location of the fuse differ according to
the type of AC mains plug (figures A and
B). Confirm the AC mains plug fitted and
follow the instructions below.
Illustrations may differ from actual AC
mains plug.
1. Open the fuse cover with a screwdriver.
2. Replace the fuse and close or attach
the fuse cover.
Fuse cover
Figure A Figure B
Figure A Figure B
Fuse
(5 ampere)
Fuse
(5 ampere)
DMC-F3Basic-VQT2R92_eng.book 3 ページ ２０１０年１月１８日 月曜日 午前１０時５４分

VQT2R92 (ENG)
4
∫About the battery pack
•Do not heat or expose to flame.
•Do not leave the battery(ies) in an automobile exposed to direct sunlight for a
long period of time with doors and windows closed.
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose
of used batteries according to the manufacturer’s instructions.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC
or incinerate.
DMC-F3Basic-VQT2R92_eng.book 4 ページ ２０１０年１月１８日 月曜日 午前１０時５４分

5
(ENG) VQT2R92
∫About the battery charger
•The battery charger is in the standby condition when the AC power supply cord
is connected. The primary circuit is always “live” as long as the power cord is
connected to an electrical outlet.
∫Cautions for Use
•Always use a genuine Panasonic AC adaptor (DMW-AC5E; optional).
•When using an AC adaptor, use the AC cable supplied with the AC adaptor.
•Do not use any other AV cables except the supplied one.
•Do not use any other USB connection cables except the supplied one.
Keep the camera as far away as possible from electromagnetic
equipment (such as microwave ovens, TVs, video games etc.).
•If you use the camera on top of or near a TV, the pictures and sound on the
camera may be disrupted by electromagnetic wave radiation.
•Do not use the camera near cell phones because doing so may result in noise
adversely affecting the pictures and sound.
•Recorded data may be damaged, or pictures may be distorted, by strong
magnetic fields created by speakers or large motors.
•Electromagnetic wave radiation generated by microprocessors may adversely
affect the camera, disturbing the pictures and sound.
•If the camera is adversely affected by electromagnetic equipment and stops
functioning properly, turn the camera off and remove the battery or disconnect
AC adaptor (DMW-AC5E; optional). Then reinsert the battery or reconnect AC
adaptor and turn the camera on.
Do not use the camera near radio transmitters or high-voltage lines.
•If you record near radio transmitters or high-voltage lines, the recorded pictures
and sound may be adversely affected.
CAUTION!
•DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN
CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS
WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE
HAZARD DUE TO OVERHEATING, ENSURE THAT CURTAINS AND ANY
OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION VENTS.
•DO NOT OBSTRUCT THE UNIT’S VENTILATION OPENINGS WITH
NEWSPAPERS, TABLECLOTHS, CURTAINS, AND SIMILAR ITEMS.
•DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED
CANDLES, ON THE UNIT.
•DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY FRIENDLY
MANNER.
DMC-F3Basic-VQT2R92_eng.book 5 ページ ２０１０年１月１８日 月曜日 午前１０時５４分

VQT2R92 (ENG)
6
Information for Users on Collection and Disposal of Old Equipment
and used Batteries
These symbols on the products, packaging, and/or
accompanying documents mean that used electrical and
electronic products and batteries should not be mixed with
general household waste.
For proper treatment, recovery and recycling of old
products and used batteries, please take them to applicable
collection points, in accordance with your national
legislation and the Directives 2002/96/EC and 2006/66/EC.
By disposing of these products and batteries correctly, you
will help to save valuable resources and prevent any
potential negative effects on human health and the
environment which could otherwise arise from inappropriate
waste handling.
For more information about collection and recycling of old
products and batteries, please contact your local
municipality, your waste disposal service or the point of sale
where you purchased the items.
Penalties may be applicable for incorrect disposal of this
waste, in accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment,
please contact your dealer or supplier for further
information.
[Information on Disposal in other Countries outside the
European Union]
These symbols are only valid in the European Union. If you
wish to discard these items, please contact your local
authorities or dealer and ask for the correct method of
disposal.
Note for the battery symbol (bottom two symbol
examples):
This symbol might be used in combination with a chemical
symbol. In this case it complies with the requirement set by
the Directive for the chemical involved.
Cd
DMC-F3Basic-VQT2R92_eng.book 6 ページ ２０１０年１月１８日 月曜日 午前１０時５４分

7
(ENG) VQT2R92
Contents
Information for Your Safety ........................................................................... 2
Accessories................................................................................................... 8
Namesof the Components......................................................................... 10
Charging the Battery ................................................................................... 12
About the Built-in Memory/the Card ............................................................ 14
Inserting and Removing the Card (optional)/the Battery ............................. 15
Setting Date/Time (Clock Set)..................................................................... 16
• Changing the clock setting.................................................................... 16
Setting the Menu......................................................................................... 17
Selecting the [REC] Mode........................................................................... 18
Taking picturesusing the automatic function ( : Auto Scene Mode) ....... 19
• Scene detection .................................................................................... 20
Motion Picture Mode ................................................................................... 21
Playing back Pictures([NORMAL PLAY])................................................... 22
Deleting Pictures......................................................................................... 22
Reading the Operating Instructions(PDF format)....................................... 23
Specifications.............................................................................................. 25
DMC-F3Basic-VQT2R92_eng.book 7 ページ ２０１０年１月１３日 水曜日 午後１時２０分

VQT2R92 (ENG)
8
Accessories
Check that all the accessories are included before using the camera.
Product numbers correct as of January 2010. These may be subject to change.
1 Battery Pack
(Indicated as battery pack or
battery in the text)
Charge the battery before use.
2 Battery Charger
(Indicated as battery charger or
charger in the text)
3 AC Mains Lead
4 USB Connection Cable
5AVCable
6 CD-ROM
•Software:
Use it to install the software to your
PC.
•Operating Instructions
7 Hand Strap
8 Battery Case
•SD Memory Card, SDHC Memory Card
and SDXC Memory Card are indicated
as card in the text.
•The card is optional.
You can record or play back pictures
on the built-in memory when you are
not using a card.
•Consult the dealer or your nearest
Service Centre if you lose the supplied
accessories. (You can purchase the
accessories separately.)
3
12
4
56
78
CGA-S/106C
VFC4297
DE-A60A
VFF0622
VGQ0D56
VU6451023810
VU6451024237
VU6450808883
DMC-F3Basic-VQT2R92_eng.book 8 ページ ２０１０年１月１３日 水曜日 午後１時２０分

9
(ENG) VQT2R92
Sales and Support Information
Customer Care Centre
•For customers within the UK: 0844 844 3852
•For customers within the Republic of Ireland: 01 289 8333
•Visit our website for product information
www.panasonic.co.uk.
•E-mail: [e-mail]
Technical Support for AV Software
•For customers within the UK: 0844 844 3869
•For customers within the Republic of Ireland: 01 289 8333
Direct Sales at Panasonic UK
•For customers: 0844 844 3856
• Order accessory and consumable items for your product with ease and confidence
by phoning our Customer Care Centre Monday – Thursday 9.00 a.m. – 5.30 p.m.,
Friday 9.30 a.m. – 5.30 p.m. (Excluding public holidays)
•Or go on line through our Internet Accessory ordering application at
www.pas-europe.com.
•Most major credit and debit cards accepted.
•All enquiries transactions and distribution facilities are provided directly by
Panasonic UK Ltd.
•It couldn’t be simpler!
•Also available through our Internet is direct shopping for a wide range of finished
products, take a browse on our website for further details.
Interested in purchasing an extended guarantee?
Please call 0870 240 6284 or visit our website www.panasonic.co.uk/guarantee.
∫Optional Accessories
•SDXC Memory Card
64 GB: RP-SDW64GE1K
48 GB: RP-SDW48GE1K
•SDHC Memory Card
32 GB: RP-SDW32GE1K/RP-SDP32GE1K
24 GB: RP-SDP24GE1K
16 GB: RP-SDW16GE1K/RP-SDP16GE1K
8 GB: RP-SDW08GE1K/RP-SDP08GE1K/RP-SDR08GE1A
4 GB: RP-SDW04GE1K/RP-SDP04GE1K/RP-SDR04GE1A
•SD Memory Card
2 GB: RP-SDP02GE1K/RP-SDR02GE1A
¢Ensure that the AC adaptor and DC coupler are purchased in a set. Do not
use if sold separately.
Some optional accessories may not be available in some countries.
•Battery Pack
DMW-BCF10E
•AC Adaptor
DMW-AC5EB
•DC Coupler¢
DMW-DCC4E
DMC-F3Basic-VQT2R92_eng.book 9 ページ ２０１０年１月１８日 月曜日 午前１０時５４分

VQT2R92 (ENG)
10
Names of the Components
1Flash
2Lens
3 Self-timer indicator
AF assist lamp
4 Microphone
5 LCD monitor
6 [MENU/SET] button
7 [DISPLAY] button
8 [Q.MENU]/Delete button
9 [MODE] button
10 [REC]/[PLAYBACK] selector switch
11 Cursor buttons
A: 3/Exposure compensation
B: 4/Macro Mode
C: 2/Self-timer button
D: 1/Flash setting button
In these operating instructions, the cursor buttons are described as shown
in the figure below or described with 3/4/2/1.
e.g.: When you press the 4(down) button
or Press 4
123
4
51110
68
9
7
DMC-F3Basic-VQT2R92_eng.book 10 ページ ２０１０年１月１３日 水曜日 午後１時２０分
