Panasonic Lumix DC-ZS200 Installation and service instructions

DVQX1409ZA
M0118KZ0
Basic Owner’s Manual
Digital Camera
Model No. DC-ZS200
Please read these instructions carefully before using this product, and
save this manual for future use.
More detailed owner’s manual is available in “Owner’s Manual for
advanced features (PDF format)”. To read it, download it from the
website. (→68)
Register online at http://shop.panasonic.com/support (U.S. customers only)
P
If you have any questions, visit:
USA : http://shop.panasonic.com/support
Canada : www.panasonic.ca/english/support
PP

2DVQX1409 (ENG)
Dear Customer,
Thank you for choosing Panasonic!
You have purchased one of the most sophisticated and reliable products on the
market today. Used properly, we’re sure it will bring you and your family years of
enjoyment. Please take time to fill in the information below. The serial number is on
the tag located on the underside of your camera. Be sure to retain this manual as
your convenient camera information source.
Date of Purchase Dealer Phone No.
Dealer Purchased From Model No.
Dealer Address Serial No.
Please note that the actual controls and components, menu items, etc. of your
Digital Camera may look somewhat different from those shown in the illustrations in
this Owner’s Manual.
Carefully observe copyright laws.
• Recording of pre-recorded tapes or discs or other published or broadcast
material for purposes other than your own private use may infringe copyright
laws. Even for the purpose of private use, recording of certain material may be
restricted.
For the U.S.A. and Canada only
A lithium ion battery that is recyclable powers the product
you have purchased. Please call 1-800-8-BATTERY for
information on how to recycle this battery.

3
DVQX1409 (ENG)
Information for Your Safety
WARNING:
To reduce the risk of fire, electric shock or product damage,
• Do not expose this unit to rain, moisture, dripping or splashing.
• Use the recommended accessories.
• Do not remove covers.
• Do not repair this unit by yourself. Refer servicing to qualified service
personnel.
The socket outlet shall be installed near the equipment and shall be easily
accessible.
■ Product identification marking
Product Location
Digital camera Bottom

4DVQX1409 (ENG)
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
Certification and Compliance
See Camera for the certification and compliance mark specific to that device.
1 Select [Wi-Fi] in the [Setup] menu
2 Select [Wi-Fi Setup] in the [Wi-Fi]
3 Press to select [Approved Regulations], and press [MENU/SET]
Contains FCC ID : VPYLB1JS955
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines. This equipment has very low levels of RF energy that is deemed to
comply without testing of specific absorption rate(SAR).
DC-ZS200

5
DVQX1409 (ENG)
THE FOLLOWING APPLIES ONLY IN THE U.S.A.
FCC Note:
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, follow the attached installation
instructions and use only shielded interface cables with ferrite core when
connecting to computer or peripheral devices.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Declaration of Conformity
Trade Name: Panasonic
Model No.: DC-ZS200
Responsible Party: Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ 07102-5490
Support Contact: http://shop.panasonic.com/support

6DVQX1409 (ENG)
THE FOLLOWING APPLIES ONLY IN CANADA.
Certification and Compliance
See Camera for the certification and compliance mark specific to that device.
1 Select [Wi-Fi] in the [Setup] menu
2 Select [Wi-Fi Setup] in the [Wi-Fi]
3 Press to select [Approved Regulations], and press [MENU/SET]
CAN ICES-3(B)/NMB-3(B)
Contains IC : 772C-LB1JS955 HMN: DC2801
This device complies with Industry Canada’s licence-exempt RSSs. Operation is
subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may
cause undesired operation of the device.
The available scientific evidence does not show that any health problems are
associated with using low power wireless devices. There is no proof, however,
that these low power wireless devices are absolutely safe. Low power Wireless
devices emit low levels of radio frequency energy (RF) in the microwave range
while being used. Whereas high levels of RF can produce health effects (by
heating tissue), exposure of low-level RF that does not produce heating effects
causes no known adverse health effects. Many studies of low-level RF exposures
have not found any biological effects. Some studies have suggested that some
biological effects might occur, but such findings have not been confirmed by
additional research. DC-ZS200 has been tested and found to comply with IC
radiation exposure limits set forth for an uncontrolled environment and meets
RSS-102 of the IC radio frequency (RF) Exposure rules.

7
DVQX1409 (ENG)
■ About the battery pack
CAUTION
Battery pack (Lithium ion battery pack)
• Use the specified unit to recharge the battery pack.
• Do not use the battery pack with equipment other than the specified unit.
• Do not get dirt, sand, liquids, or other foreign matter on the terminals.
• Do not touch the plug terminals (+ and −) with metal objects.
• Do not disassemble, remodel, heat or throw into fire.
If any electrolyte should come into contact with your hands or clothes, wash it off
thoroughly with water.
If any electrolyte should come into contact with your eyes, never rub the eyes.
Rinse eyes thoroughly with water, and then consult a doctor.
CAUTION
• Danger of explosion if battery is incorrectly replaced. Replace only with the
type recommended by the manufacturer.
• When disposing of the batteries, please contact your local authorities or dealer
and ask for the correct method of disposal.
• Do not heat or expose to flame.
• Do not leave the battery(ies) in a car exposed to direct sunlight for a long period
of time with doors and windows closed.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 °C (140 °F)
or incinerate.

8DVQX1409 (ENG)
■ About the AC adaptor (supplied)
CAUTION!
To reduce the risk of fire, electric shock or product damage,
• Do not install or place this unit in a bookcase, built-in cabinet or in
another confined space. Ensure this unit is well ventilated.
AC adaptor
This AC adaptor operates on AC between 110V and 240V.
But
• In the U.S.A. and Canada, the AC adaptor must be connected to a 120V AC
power supply only.
• When connecting to an AC supply outside of the U.S.A. or Canada, use a plug
adaptor to suit the AC outlet configuration.
■ Cautions for Use
• Do not use any other USB connection cables except the supplied one.
• Use a “High Speed HDMI micro cable” with the HDMI logo.
Cables that do not comply with the HDMI standards will not work.
“High Speed HDMI micro cable” (Type D - Type A plug, up to 2 m (6.6 feet) long)
Keep this unit as far away as possible from electromagnetic equipment (such
as microwave ovens, TVs, video games etc.).
• If you use this unit on top of or near a TV, the pictures and/or sound on this unit
may be disrupted by electromagnetic wave radiation.
• Do not use this unit near cell phones because doing so may result in noise
adversely affecting the pictures and/or sound.
• Recorded data may be damaged, or pictures may be distorted, by strong
magnetic fields created by speakers or large motors.
• Electromagnetic wave radiation may adversely affect this unit, disturbing the
pictures and/or sound.
• If this unit is adversely affected by electromagnetic equipment and stops
functioning properly, turn this unit off and remove the battery or disconnect AC
adaptor. Then reinsert the battery or reconnect AC adaptor and turn this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
• If you record near radio transmitters or high-voltage lines, the recorded pictures
and/or sound may be adversely affected.

9
DVQX1409 (ENG)
• To clean your camera, remove the battery, the DC coupler (DMW-DCC11:
optional) or a card, or disconnect the power plug from the outlet, and wipe
with a soft, dry cloth.
• Do not press the monitor with excessive force.
• Do not press the lens with excessive force.
• Do not allow camera to come into contact with pesticides or volatile
substances (can cause surface damage or coating to peel).
• Do not keep rubber or plastic products in contact with the camera for a
long period of time.
• Do not use solvents such as benzine, thinner, alcohol, kitchen detergents,
etc., to clean the camera, since it may deteriorate the external case or the
coating may peel off.
• Do not leave the camera with the lens facing the sun, as rays of light from
the sun may cause it to malfunction.
• Always use the supplied cords and cables.
• Do not extend the supplied cord or cable.
• While the camera is accessing the card (for an operation such as picture
writing, reading, deletion, or formatting), do not turn off the camera or
remove the battery, card, AC adaptor (DMW-AC10PP: optional) or DC
coupler (DMW-DCC11: optional).
Furthermore, do not subject the camera to vibration, impact or static
electricity.
• The data on the card may be damaged or lost due to electromagnetic waves,
static electricity or breakdown of the camera or the card. We recommend storing
important data on a PC etc.
• Do not format the card on your PC or other equipment. Format it on the camera
only to ensure proper operation.

10 DVQX1409 (ENG)
• The battery is not charged when the camera is shipped. Charge the battery
before use.
• The battery is a rechargeable lithium ion battery. If the temperature is too
high or too low, the operating time of the battery will become shorter.
• The battery becomes warm after using and during and after charging. The
camera also becomes warm during use. This is not a malfunction.
• Do not leave any metal items (such as clips) near the contact areas of the
power plug or near the batteries.
• Store the battery in a cool and dry place with a relatively stable temperature.
(Recommended temperature: 15 °C to 25 °C (59 °F to 77 °F), Recommended
humidity: 40%RH to 60%RH)
• Do not store the battery for a long time while fully charged. When storing the
battery for a long period of time, we recommend charging it once a year. Remove
the battery from the camera and store it again after it has completely discharged.
How to use this manual
■ About the symbols in the text
Indicates that the menu can be set by pressing [MENU/SET] button.
Steps for setting a menu item are described as follows:
→ [Rec] → [Quality] → [ ]
• This Owner’s Manual expresses the up, down, left, and right of the cursor button
as .
Recording mode:
• In Recording modes that show icons in black, you can select and execute
indicated menus and functions.
(Custom Mode) has different functions depending on the recording mode that
is registered.

11
DVQX1409 (ENG)
Contents
■ Information for Your Safety ...................... 3
Preparations/Basics
■ Before use................................................ 12
■ Standard accessories ............................. 13
■ Names and Functions of Main Parts ..... 14
■ Quick Start Guide .................................... 16
Inserting the battery and/or
SD memory card (optional) ....................... 16
Charging the battery.................................. 17
Setting the clock ........................................ 19
Formatting the card (initialization) ............. 20
[LVF] button
(Recording pictures using the viewfinder) ... 20
Mode dial (Select the recording mode) ..... 21
Holding the camera ................................... 22
Shutter button (Taking pictures) ................ 22
■ Basic operations ..................................... 23
■ Setting the menu ..................................... 27
Recording
■ Taking pictures with automatic settings
(Intelligent Auto Mode) ........................... 28
■ Recording with the 4K Photo
function .................................................... 29
■ Adjusting the focus after recording
([Post Focus] / [Focus Stacking]) .......... 33
■ Recording Motion Picture/
4K Motion Picture .................................... 36
Playback
■ Viewing your pictures ............................. 40
Menu
■ Menu list ................................................... 44
Wi-Fi/Bluetooth
■ What you can do with the
Wi-Fi®/Bluetooth® function .................... 48
■ Operating the camera by connecting
it to a smartphone ................................... 50
Others
■ Downloading software ............................ 57
■ List of monitor/viewfinder displays ....... 58
■ Q&A
Troubleshooting ...................................... 61
■ Specifications .......................................... 63
■ Digital Camera Accessory System ........ 67
■ Reading the Owner’s Manual
(PDF format) ............................................ 68
■ Limited Warranty (ONLY FOR U.S.A.) .... 69
■ Limited Warranty
(ONLY FOR CANADA) ............................. 73

12 DVQX1409 (ENG)
Preparations/Basics
Before use
■ Camera handling
Keep the camera away from excessive vibration, force, or pressure.
● Avoid using the camera under the following conditions, which may damage the
lens, monitor, viewfinder, or camera body. This may also cause the camera to
malfunction or prevent recording.
• Dropping or hitting the camera against a hard surface
• Sitting down with the camera in your pants pocket or forcing it into a full bag
• Adding accessories to the camera strap
• Pushing with excessive force on the lens or monitor
The camera is not dust resistant, splash resistant, or waterproof.
Avoid using the camera in places with excessive dust or sand, or where
water can come into contact with the camera.
■ Condensation (When the lens, the monitor, or viewfinder, is
fogged up)
● Condensation may occur when the camera is exposed to sudden changes of
temperature or humidity. Avoid these conditions, which may make the lens,
monitor, or viewfinder dirty, cause mold, or damage the camera.
● If condensation does occur, turn off the camera and wait about two hours before
using it. Once the camera adjusts to the surrounding temperature, the fogging
will clear naturally.
■ When in use
● Do not keep objects that may be influenced magnetically close to the speaker.
• Magnetized objects such as bank cards, commuter passes, watches, may be
adversely affected by the magnetic influence of the speaker.

13
DVQX1409 (ENG)
Preparations/Basics
Standard accessories
Check that all the accessories are supplied before using the camera. Part numbers
are as of February 2018. These may be subject to change.
Battery pack
DMW-BLG10PP
• Charge the battery before
use.
• Battery pack is indicated as battery
pack or battery in the text.
AC adaptor
SAE0012A
USB connection cable
K1HY04YY0106
Hand strap
VFC4297
• Cards are optional. (SD Memory Card, SDHC Memory Card and SDXC
Memory Card are indicated as card in the text.)
– This unit is compatible with UHS- UHS Speed Class 3 standard SDHC/SDXC
memory cards.
– The following SD standard-based cards can be used.
SD Memory Card (512 MB to 2 GB)/SDHC Memory Card (4 GB to 32 GB)/
SDXC Memory Card (48 GB to 128 GB)
– Depending on recording conditions, the required card differs.
Latest information:
http://panasonic.jp/support/global/cs/dsc/
(This site is available in English only.)
(For U.S.A. only)
•
If accessories are lost, customers can visit us at http://shop.panasonic.com/support
for further information about obtaining replacement parts.
(For Canada only)
• If any accessories are lost, customers in Canada should visit our support page at
www.panasonic.ca/english/support for further information about obtaining
replacement parts.
• Please dispose of all packaging appropriately.
• The illustrations and screens in this manual may differ from the actual product.

14
Preparations/Basics
DVQX1409 (ENG)
Names and Functions of Main Parts
20
21
22
23
24
25
26
27
28
29
17 12
33 32 31 30 35
18 19
34
1 2 3
4 6
8 9
12
13 14 15
16
7
5
10
11

15
DVQX1409 (ENG)
Preparations/Basics
1 Shutter button (→22)
2 Zoom lever (→23)
3 Motion picture button (→36)
4 Rear dial (→25)
5 Camera [ON/OFF] switch (→19)
6 Mode dial (→21)
7 Flash (→22)
8 Viewfinder (→20)
9 Diopter adjustment dial (→20)
10 Eye sensor (→20)
11 Stereo microphone
12 Strap eyelet
• To prevent dropping, be sure to
attach the supplied strap and fit it to
your wrist.
13 Control ring (→25)
14 Lens barrel
15 Lens
16 Self-timer indicator / AF Assist Lamp
17 [LVF] button (→20) / [Fn4] button (→26)
18 Flash open lever
• The flash opens, and recording with the
flash becomes possible.
19 [AF/AE LOCK] button
• You can take pictures by locking the
focus and/or exposure.
20 Charging lamp (→17, 18) /
WIRELESS connection lamp (→49)
21 [ ] ([Post Focus]) button (→33) /
[Fn2] button (→26)
22 [ ] (Delete) button (→40) /
[Q.MENU/ ] (Cancel) button /
[Fn3] button (→26)
• You can easily call some of the menu
items and set them during recording.
23 [ ] (4K photo mode) button (→29) /
[Fn1] button (→26)
24 [ ] (Playback) button (→40)
25 Cursor button (→24)
26 [MENU/SET] button
• Confirmation of setting contents, etc.,
is performed.
27 [DISP.] button
• Use this to change display.
28 [HDMI] socket
• You can view pictures on a TV screen
by connecting your camera to your TV
with the HDMI micro cable.
29 [USB/CHARGE] socket (→17)
30 Card/Battery door (→16)
31 Release lever (→16)
32 DC coupler cover (→67)
33 Tripod mount
• Do not attach this unit to tripods that
have screws with a length of 5.5 mm
(0.22 inch) or more. Doing so may
damage this unit or the unit may not be
secured properly on the tripod.
34 Speaker
35 Touch screen (→26) / monitor (→58)
● Always use a genuine Panasonic AC
adaptor (DMW-AC10PP: optional).
(→67)
When using an AC adaptor, ensure
that the Panasonic DC coupler
(DMW-DCC11: optional) and AC
adaptor (DMW-AC10PP: optional)
are used.
Function buttons [Fn5] to [Fn9] are
touch icons.
They can be displayed by touching the
[ ] tab on the recording screen.

16
Preparations/Basics
DVQX1409 (ENG)
Quick Start Guide
Inserting the battery and/or SD memory card (optional)
Make sure that the camera is turned off.
1 Slide the release lever ( ) to the [OPEN]
position and open the card/battery door
[OPEN] [LOCK]
2 Insert the battery and card, making sure
that their orientation is correct
• Battery: Insert the battery all the way firmly and
check that it is locked by lever ( ).
• Card: Insert the card all the way firmly until it
clicks. Do not touch the terminal.
3 Close the door
Slide the release lever to the [LOCK] position.
■ To remove
• To remove battery
Move lever ( ) in direction of
arrow.
• To remove card
Press the center of the card.
Press Pull out
● Always use genuine Panasonic batteries (DMW-BLG10PP).
● If you use other batteries, we cannot guarantee the quality of this product.
● Keep the memory card out of reach of children to prevent swallowing.

17
DVQX1409 (ENG)
Preparations/Basics
Charging the battery
• The battery that can be used with this unit is DMW-BLG10PP.
• We recommend charging in a location where the ambient temperature is
between 10 °C and 30 °C (50 °F to 86 °F).
Insert the battery into the camera.
Make sure that the camera is turned off.
[USB/CHARGE] socket
• This terminal is located at the bottom when the
camera is in an upright position.
• Always check the direction of the socket, and hold the plug straight to insert
or remove it. (If the cable is inserted in the wrong direction, the socket could
become deformed and cause faulty operation.) Also, do not insert into the
wrong socket. Doing so may cause damage to this unit.
Charging lamp (Red)
AC adaptor (supplied)
To the electrical outlet
USB connection cable
(supplied)
Computer
Getting ready:
Turn on the computer.

18
Preparations/Basics
DVQX1409 (ENG)
Charging from the power outlet
Connect the AC adaptor (supplied) and this camera with the USB connection cable
(supplied), and insert the AC adaptor (supplied) into the power outlet.
Charging from a computer
Connect the computer and this camera with the USB connection cable (supplied).
■ Charging lamp indications (Red)
On: Charging in progress
Off: Charging complete (After charging stops, disconnect the camera from the
electrical outlet or your computer.)
Flashing: Charging error (→61)
■ Charging time
When using the AC adaptor (supplied) Approx. 190 min.
• The charging time indicated above is the time required for charging in case
when the battery is completely used up. The time required for charging
differs depending on conditions of battery usage. Charging takes longer in
cases when temperatures are either high or low and when the battery has
not been used for a long period of time.
• The time required for charging through the computer varies depending on the
power supply capacity of the computer.
● Do not use any other USB connection cables except the supplied one.
● Do not use any other AC adaptors except the supplied one.

19
DVQX1409 (ENG)
Preparations/Basics
Setting the clock
The clock is not set when the camera is shipped.
1 Turn the camera on
2 Press [MENU/SET]
3 Press to select the language and press [MENU/SET]
• The [Please set the clock] message appears.
4 Press [MENU/SET]
5 Press to select the items (year,
month, day, hour, minute), and press
to set
6 Press [MENU/SET]
7 When [The clock setting has been
completed.] is displayed, press
[MENU/SET]
8 When [Please set the home area] is displayed, press
[MENU/SET]
9 Press to set your home area and
press [MENU/SET]

20
Preparations/Basics
DVQX1409 (ENG)
Formatting the card (initialization)
Format the card before recording a picture with this unit.
Since data cannot be recovered after formatting, make sure to back up
necessary data in advance.
→ [Setup] → [Format]
[LVF] button (Recording pictures using the viewfinder)
1 Press [LVF] ( ) button
[LVF] button
Eye Sensor
Diopter adjustment dial
Automatic switching between
viewfinder and monitor Viewfinder display Monitor display
■ Automatic switching between viewfinder and monitor
The eye sensor ( ) automatically switches the display to viewfinder when your eye
or an object moves close to the viewfinder. When the eye or object moves away
from the viewfinder, the camera returns to monitor display.
■ About diopter adjustment
Rotate the diopter adjustment dial ( ) to adjust until you are able to clearly see the
characters displayed in the viewfinder.
● If [LVF Display Speed] is set to [ECO 30fps] when the viewfinder is used,
the camera can be operated for a longer period since battery drainage is
reduced.
