Basic Operating Instructions
Digital Camera
Model No. DMC-FX78
until
2011/2/21
DMC-FX77&FX78GN-VQT3G32_eng.book 1 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

VQT3G32 (ENG)
2
Dear Customer,
We would like to take this opportunity to thank you for purchasing this
Panasonic Digital Camera. Please read these Operating Instructions
carefully and keep them handy for future reference. Please note that the
actual controls and components, menu items, etc. of your Digital Camera
may look somewhat different from those shown in the illustrations in these
Operating Instructions.
Carefully observe copyright laws.
•Recording of pre-recorded tapes or discs or other published or broadcast
material for purposes other than your own private use may infringe copyright
laws. Even for the purpose of private use, recording of certain material may be
restricted.
Information for Your Safety
IF THE POWER CORD OF THIS EQUIPMENT IS DAMAGED, IT MUST BE
REPLACED WITH AN ELECTRICALLY APPROVED POWER CORD.
∫Product identification marking
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT
DAMAGE,
•DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING
OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH
AS VASES, SHALL BE PLACED ON THE APPARATUS.
•USE ONLY THE RECOMMENDED ACCESSORIES.
•DO NOT REMOVE THE COVER (OR BACK); THERE ARE NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THE SOCKET OUTLET SHALL BE INSTALLED NEAR THE
EQUIPMENT AND SHALL BE EASILY ACCESSIBLE.
Product Location
Digital camera Bottom
Battery charger Bottom
DMC-FX77&FX78GN-VQT3G32_eng.book 2 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

3
(ENG) VQT3G32
∫About the battery pack
•Do not heat or expose to flame.
•Do not leave the battery(ies) in an automobile exposed to direct sunlight for a
long period of time with doors and windows closed.
∫About the battery charger
•The battery charger is in the standby condition when the AC power supply cord
is connected. The primary circuit is always “live” as long as the power cord is
connected to an electrical outlet.
CAUTION
Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose
of used batteries according to the manufacturer’s instructions.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC
or incinerate.
CAUTION!
•DO NOT INSTALL OR PLACE THIS UNIT IN A BOOKCASE, BUILT-IN
CABINET OR IN ANOTHER CONFINED SPACE. ENSURE THE UNIT IS
WELL VENTILATED. TO PREVENT RISK OF ELECTRIC SHOCK OR FIRE
HAZARD DUE TO OVERHEATING, ENSURE THAT CURTAINS AND ANY
OTHER MATERIALS DO NOT OBSTRUCT THE VENTILATION VENTS.
•DO NOT OBSTRUCT THE UNIT’S VENTILATION OPENINGS WITH
NEWSPAPERS, TABLECLOTHS, CURTAINS, AND SIMILAR ITEMS.
•DO NOT PLACE SOURCES OF NAKED FLAMES, SUCH AS LIGHTED
CANDLES, ON THE UNIT.
•DISPOSE OF BATTERIES IN AN ENVIRONMENTALLY FRIENDLY
MANNER.
DMC-FX77&FX78GN-VQT3G32_eng.book 3 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

VQT3G32 (ENG)
4
∫Cautions for Use
•Do not use any other AV cables except the supplied one.
•Always use a genuine Panasonic HDMI mini cable (RP-CDHM15, RP-CDHM30;
optional).
Part numbers: RP-CDHM15 (1.5 m), RP-CDHM30 (3.0 m)
•Do not use any other USB connection cables except the supplied one.
In the event of abnormal operation (e.g. if the unit emits smoke or an unusual
smell), immediately stop operating the unit and consult the Panasonic
Customer Care Centre on 132600.
Keep this unit as far away as possible from electromagnetic equipment
(such as microwave ovens, TVs, video games etc.).
•If you use this unit on top of or near a TV, the pictures and/or sound on this unit
may be disrupted by electromagnetic wave radiation.
•Do not use this unit near cell phones because doing so may result in noise
adversely affecting the pictures and/or sound.
•Recorded data may be damaged, or pictures may be distorted, by strong
magnetic fields created by speakers or large motors.
•Electromagnetic wave radiation generated by microprocessors may adversely
affect this unit, disturbing the pictures and/or sound.
•If this unit is adversely affected by electromagnetic equipment and stops
functioning properly, turn this unit off and remove the battery or disconnect AC
adaptor (DMW-AC5G; optional). Then reinsert the battery or reconnect AC
adaptor and turn this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
•If you record near radio transmitters or high-voltage lines, the recorded pictures
and/or sound may be adversely affected.
DMC-FX77&FX78GN-VQT3G32_eng.book 4 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

5
(ENG) VQT3G32
-If you see this symbol-
Information on Disposal in other Countries outside
the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your
local authorities or dealer and ask for the correct
method of disposal.
DMC-FX77&FX78GN-VQT3G32_eng.book 5 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

VQT3G32 (ENG)
6
Contents
Information for Your Safety ........................................................................... 2
Standard Accessories ................................................................................... 7
Names of the Components ........................................................................... 8
How to Use the Touch Panel ......................................................................10
Charging the Battery ...................................................................................12
• Charging ............................................................................................... 12
• Approximate operating time and number of recordable pictures .......... 13
About the Built-in Memory/the Card ............................................................ 14
Inserting and Removing the Card (optional)/the Battery ............................. 15
Setting Date/Time (Clock Set)..................................................................... 16
• Changing the Clock Setting .................................................................. 16
Selecting the [Rec] Mode ............................................................................ 17
Taking pictures using the automatic function
(ñ: Intelligent Auto Mode) ......................................................................... 18
• Scene Detection.................................................................................... 19
Recording Motion Pictures.......................................................................... 20
Playing Back Pictures ([Normal Play]) ........................................................ 21
Deleting Pictures ......................................................................................... 21
Setting the Menu......................................................................................... 22
Reading the Operating Instructions (PDF format)....................................... 23
Specifications.............................................................................................. 25
DMC-FX77&FX78GN-VQT3G32_eng.book 6 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

7
(ENG) VQT3G32
Standard Accessories
Check that all the accessories are supplied before using the camera.
Product numbers correct as of January 2011. These may be subject to change.
1 Battery Pack
(Indicated as battery pack or
battery in the text)
Charge the battery before use.
2 Battery Charger
(Indicated as battery charger or
charger in the text)
3ACCable
4 USB Connection Cable
5AVCable
6 CD-ROM
•Software:
Use it to install the software to your
PC.
•Operating Instructions
7 Hand Strap
8 Stylus Pen
•SD Memory Card, SDHC Memory Card
and SDXC Memory Card are indicated
as card in the text.
•The card is optional.
You can record or play back pictures
on the built-in memory when you are
not using a card.
•Consult the dealer or your nearest
Service Centre if you lose the supplied
accessories. (You can purchase the
accessories separately.)
3
12
4
56
78
DMW-BCK7E
VFC4297
DE-A92A
K1HY08YY0019
K1HY08YY0020
VGQ0C14
VFF0762
K2CJ29A00002
DMC-FX77&FX78GN-VQT3G32_eng.book 7 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

VQT3G32 (ENG)
8
Names of the Components
1Flash
2Lens
3 Self-timer indicator
AF Assist Lamp
4 Touch panel/LCD monitor
5 Speaker
6 Microphone
7 Camera ON/OFF switch
8 Motion picture button
9 Shutter button
10 Zoom lever
12 3
91087654
DMC-FX77&FX78GN-VQT3G32_eng.book 8 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

9
(ENG) VQT3G32
11 Strap eyelet
•Be sure to attach the strap when
using the camera to ensure that
you will not drop it.
12 Lens barrel
13 [HDMI] socket
14 [AV OUT/DIGITAL] socket
15 Tripod receptacle
16 Card/Battery door
17 Release lever
18 DC coupler cover
•When using an AC adaptor, ensure that
the Panasonic DC coupler (DMW-DCC10;
optional) and AC adaptor (DMW-AC5G;
optional) are used.
•Always use a genuine Panasonic AC
adaptor (DMW-AC5G; optional).
•When using an AC adaptor, use the AC
cable supplied with the AC adaptor.
•It is recommended to use a fully charged
battery or AC adaptor (DMW-AC5G;
optional) and DC coupler (DMW-DCC10;
optional) when recording motion pictures.
•If while recording motion pictures using the
AC adaptor and the power supply is cut off
due to a power outage or if the AC adaptor
is disconnected etc., the motion picture
being recorded will not be recorded.
13
14
12
11


OPEN LOCK
15 16
1718
DMC-FX77&FX78GN-VQT3G32_eng.book 9 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

VQT3G32 (ENG)
10
How to Use the Touch Panel
This touch panel is a type that detects pressure.
Touch the screen
To touch and release the touch panel.
Drag
A movement without releasing the
touch panel.
Use this to perform tasks such as
selecting icons or images displayed on
the touch panel.
•It may not operate properly when
multiple icons are touched
simultaneously, so try to touch the
centre of the icon.
This is used when performing tasks
such as moving to the next image by
dragging horizontally, or changing the
range of the displayed image.
This can also be used to perform tasks
such as switching the screen by
operating the slide bar.
DMC-FX77&FX78GN-VQT3G32_eng.book 10 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

11
(ENG) VQT3G32
Note
•If you use a commercially available liquid crystal
protection sheet, please follow the instructions that
accompany the sheet. (Some liquid crystal protection
sheets may impair visibility or operability.)
•Apply a little extra pressure when touching if you
have a commercially available protection sheet affixed
or if you feel it is not responding well.
•Touch panel will not operate properly when the hand holding this unit is pressing
on the touch panel.
•Do not press using anything with a sharp tip or anything hard, except for the
supplied stylus pen.
•Do not operate with your fingernails.
•Wipe the LCD monitor with dry soft cloth when it gets dirty with finger prints and
others.
•Do not scratch or press the LCD monitor too hard.
∫About the Stylus pen
It is easier to use the stylus pen (supplied) for detailed
operation or if it is hard to operate with your fingers.
•Do not place it where small children can reach.
•Do not place the stylus pen on the LCD monitor when
storing. LCD monitor may break when the stylus pen
is pressed strongly against the LCD monitor.
DMC-FX77&FX78GN-VQT3G32_eng.book 11 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

VQT3G32 (ENG)
12
Preparation
Charging the Battery
∫About batteries that you can use with this unit
The battery that can be used with this unit is DMW-BCK7E.
•Use the dedicated charger and battery.
•The battery is not charged when the camera is shipped. Charge the battery
before use.
•Charge the battery with the charger indoors.
It has been found that counterfeit battery packs which look very similar
to the genuine product are made available to purchase in some markets.
Some of these battery packs are not adequately protected with internal
protection to meet the requirements of appropriate safety standards.
There is a possibility that these battery packs may lead to fire or
explosion. Please be advised that we are not liable for any accident or
failure occurring as a result of use of a counterfeit battery pack. To
ensure that safe products are used we would recommend that a genuine
Panasonic battery pack is used.
Charging
Attach the battery paying
attention to the direction of the
battery.
Connect the AC cable.
•Disconnect the charger from the
electrical socket and detach the battery
after charging is completed.
DMC-FX77&FX78GN-VQT3G32_eng.book 12 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

13
(ENG) VQT3G32
∫About the [CHARGE] indicator
The [CHARGE] indicator turns on:
The [CHARGE] indicator Ais turned on during charging.
The [CHARGE] indicator turns off:
The [CHARGE] indicator Awill turn off once the charging has completed without
any problem.
•When the [CHARGE] indicator flashes
–The battery temperature is too high or too low. It is recommended to charge
the battery again in an ambient temperature of between 10 oC to 30 oC.
–The terminals of the charger or the battery are dirty. In this case, wipe them
with a dry cloth.
∫Charging time
Recording conditions by CIPA standard
•CIPA is an abbreviation of [Camera & Imaging Products Association].
•Normal Picture Mode
•Temperature: 23 oC/Humidity: 50%RH when LCD monitor is on.
•Using a Panasonic SD Memory Card (32 MB).
•Using the supplied battery.
•Starting recording 30 seconds after the camera is turned on. (When the Optical
Image Stabilizer function is set to [ON].)
•Recording once every 30 seconds with full flash every second recording.
•Changing the zoom magnification from Tele to Wide or vice versa in every
recording.
•Turning the camera off every 10 recordings and leaving it until the temperature
of the battery decreases.
Charging time Approx. 120 min
Approximate operating time and number of recordable pictures
Number of recordable
pictures Approx. 200 pictures
Recording time Approx. 100 min
Playback time Approx. 150 min
DMC-FX77&FX78GN-VQT3G32_eng.book 13 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

VQT3G32 (ENG)
14
About the Built-in Memory/the Card
•Memory size: Approx. 70 MB
• The access time for the built-in memory may be longer than the access time for a card.
The following cards which conform to the SD video standard can be used with this unit.
(These cards are indicated as card in the text.)
¢SD Speed Class is the speed standard regarding continuous writing. Check
via the label on the card, etc.
•Please confirm the latest information on the following website.
http://panasonic.jp/support/global/cs/dsc/
(This Site is English only.)
Note
•Keep the Memory Card out of reach of children to prevent swallowing.
Built-in Memory
Card
Type of card which
can be used with
this unit
Remarks
SD Memory Card
(8 MB to 2 GB)
•Use a card with SD Speed Class¢with “Class 4” or
higher when recording motion pictures in [AVCHD].
Also, use a card with SD Speed Class with
“Class 6” or higher when recording motion pictures
in [Motion JPEG].
•SDHC Memory Card can be used with SDHC Memory
Card or SDXC Memory Card compatible equipment.
•SDXC Memory Card can only be used with SDXC
Memory Card compatible equipment.
•Check that the PC and other equipment are compatible
when using the SDXC Memory Cards.
http://panasonic.net/avc/sdcard/information/
SDXC.html
•Only the cards with capacity listed left can be used.
SDHC Memory Card
(4 GB to 32 GB)
SDXC Memory Card
(48 GB, 64 GB)
e.g.:
DMC-FX77&FX78GN-VQT3G32_eng.book 14 ページ ２０１１年２月１日 火曜日 午後２時５４分

15
(ENG) VQT3G32
Inserting and Removing the Card
(optional)/the Battery
•Check that this unit is turned off.
•We recommend using a Panasonic card.
Slide the release lever in the
direction of the arrow and open the
card/battery door.
•Always use genuine Panasonic batteries
(DMW-BCK7E).
•If you use other batteries, we cannot
guarantee the quality of this product.
Battery: Being careful about the
battery orientation, insert all the
way until you hear a locking sound
and then check that it is locked by
lever A.
Pull the lever Ain the direction of
the arrow to remove the battery.
Card: Push it securely all the way
until you hear a “click” while being
careful about the direction in
which you insert it.
To remove the card, push the card until it clicks, then pull
the card out upright.
B: Do not touch the connection terminals of the card.
1:Close the card/battery door.
2:Slide the release lever in the
direction of the arrow.
OPEN LOCK
CARD
OPEN LOCK
DMC-FX77&FX78GN-VQT3G32_eng.book 15 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

VQT3G32 (ENG)
16
Setting Date/Time (Clock Set)
•The clock is not set when the camera is shipped.
Touch [Clock Set].
Touch the items you wish to set (Year/Month/Day/Hours/
Minutes), and set using [3]/[4].
•Touch [ ] to cancel the date and time settings without setting a date
and time.
Touch [Set] to set.
Touch [Set] in the confirmation screen.
Select [Clock Set] in the [Rec] or [Setup] menu.
•It can be changed in steps 3and 4 to set the clock.
Turn the camera on.
Changing the Clock Setting
DMC-FX77&FX78GN-VQT3G32_eng.book 16 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

17
(ENG) VQT3G32
Basic
Selecting the [Rec] Mode
∫List of [Rec] Modes
Touch [ ].
Touch the mode icon.
!Normal Picture Mode
The subjects are recorded using your own settings.
¦Intelligent Auto Mode
The subjects are recorded using settings automatically selected by the camera.
ÛScene Mode
This allows you to take pictures that match the scene being recorded.
3D Photo Mode
Takes a 3D picture.
Cosmetic Mode
Takes a picture adjusting the skin texture.
My Colour Mode
Use this mode to check colouring effects, select a colour mode from among 8
colour modes, and then take pictures.
DMC-FX77&FX78GN-VQT3G32_eng.book 17 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

VQT3G32 (ENG)
18
[Rec] Mode: ñ
Taking pictures using the automatic
function (ñ: Intelligent Auto Mode)
The camera will set the most appropriate settings to match the subject and the
recording conditions so we recommend this mode for beginners or those who
want to leave the settings to the camera and take pictures easily.
Touch [ ].
Touch [ ].
Press the shutter button halfway
to focus.
•The focus indication 1(green) lights when
the subject is focused.
•The AF area 2is displayed around the
subject’s face by the Face Detection
function. In other cases, it is displayed at
the point on the subject which is in focus.
Press the shutter button fully
(push it in further), and take the
picture.
2
1
DMC-FX77&FX78GN-VQT3G32_eng.book 18 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

19
(ENG) VQT3G32
When the camera identifies the optimum scene, the icon of the scene concerned
is displayed in blue for 2 seconds, after which its colour changes to the usual red.
•[¦] is set if none of the scenes are applicable, and the standard settings are
set.
•When [ ], [ ] or [ ] is selected, the camera automatically detects a person’s
face, and it will adjust the focus and exposure. (Face Detection)
Scene Detection
¦>[i-Portrait]
[i-Scenery]
[i-Macro]
[i-Night Portrait] •Only when [ ] is selected
[i-Night Scenery]
[i-Sunset]
[i-Baby]
DMC-FX77&FX78GN-VQT3G32_eng.book 19 ページ ２０１１年１月３１日 月曜日 午前１０時１０分

VQT3G32 (ENG)
20
[Rec] Mode: ñ·¿
Recording Motion Pictures
This can record full high definition motion pictures compatible with the AVCHD
format or motion pictures recorded in Motion JPEG.
Audio will be recorded in monaural.
Note
•Maximum time to record motion pictures continuously with [FSH] in [AVCHD] is
29 minutes 59 seconds.
•Motion picture recorded continuously in [Motion JPEG] is up to 2 GB. Only the
maximum recordable time for 2 GB is displayed on the screen.
Start recording by pressing the
motion picture button.
AAvailable recording time
BElapsed recording time
•You can record motion pictures fitting each
Recording Mode.
•Release the motion picture button right
after you press it.
•The recording state indicator (red) C will
flash while recording motion pictures.
Stop the recording by pressing the motion picture button
again.
B
A C
DMC-FX77&FX78GN-VQT3G32_eng.book 20 ページ ２０１１年１月３１日 月曜日 午前１０時１０分
