Panasonic AW-UE20KP User manual

DVQP2657YA
W0222AM1042 -AV-PS
ENGLISH
Model No. AW-UE20KP
Model No. AW-UE20WP
Model No. AW-UE20KE
Model No. AW-UE20WE
Model No. AW-UE20KED
Model No. AW-UE20WED
Operating Instruction
Operations and Settings
4K Integrated Camera
Operations and Settings
Operating Instructions
This "Operations and Settings" describes how to operate the unit and how to
establish its settings.
For more information on how to perform basic operation and installation, refer to
the Operating Instructions "Basics".

2
Operating Instructions
Read this first! (For AW-UE20KP, AW-UE20WP)
ENGLISH

3

4
Read this first! (For AW-UE20KE, AW-UE20WE, AW-UE20KED, AW-UE20WED) ENGLISH

5
Importer for UK:
Panasonic Connect UK,
a branch of Panasonic Connect Europe GmbH,
Maxis 2, Western Road, Bracknell, Berkshire, RG12 1RT
Read this first!
(For AW-UE20KE, AW-UE20WE, AW-UE20KED, AW-UE20WED) (continued)
ENGLISH
Caution for AC Mains Lead
FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT CAREFULLY.
This product is equipped with 2 types of AC mains cable. One is for continental Europe,etc. and
the other one is only for U.K.
Appropriate mains cable must be used in each local area, since the other type of mains cable isnot suitable.
indicates safety information
FOR CONTINENTAL EUROPE,ETC.
Not to be used in the U.K.
FOR U.K. ONLY
If the plug supplied is not suitable for
your socket outlet, it should be cut off and
appropriate one fitted.
FOR U.K. ONLY
This appliance is supplied with a moulded three pin
mains plug for your safety and convenience.
A 13 amp fuse is fitted in this plug.
Should the fuse need to be replaced please ensure that
the replacement fuse has a rating of 13 amps and that it
is approved by ASTA or BSI to BS1362.
Check for the ASTA mark
or the BSI mark on
the body of the fuse.
If the plug contains a removable fuse cover you must
ensure that it is refitted when the fuse is replaced.
If you lose the fuse cover the plug must not
be used
until a replacement cover is obtained.
A replacement fuse cover can be purchased from your
local Panasonic Dealer.
How to replace the fuse
1. Open the fuse compartment with a
screwdriver.
Or
2. Replace the fuse.
Or Fuse
Fuse

6
Manufactured by: Panasonic Connect Co., Ltd.
4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japan
Importer: Panasonic Connect Europe GmbH
Authorized Representative in EU: Panasonic Testing Centre
Winsbergring 15, 22525 Hamburg, Germany
Read this first!
(For AW-UE20KE, AW-UE20WE, AW-UE20KED, AW-UE20WED) (continued)
ENGLISH
EMC NOTICE FOR THE PURCHASER/USER OF THE APPARATUS
1. Pre-requisite conditions to achieving compliance with the above standards
<1> Peripheral equipment to be connected to the apparatus and special connecting cables
The purchaser/user is urged to use only equipment which has been recommended by us as peripheral
equipment to be connected to the apparatus.
The purchaser/user is urged to use only the connecting cables described below.
<2> For the connecting cables, use shielded cables which suit the intended purpose of the apparatus.
Video signal connecting cables
Use double shielded coaxial cables, which are designed for 75-ohm type high-frequency applications, for
SDI (Serial Digital Interface).
Coaxial cables, which are designed for 75-ohm type high-frequency applications, are recommended for
analog video signals.
Audio signal connecting cables
If your apparatus supports AES/EBU serial digital audio signals, use cables designed for AES/EBU.
Use shielded cables, which provide quality performance for high-frequency transmission applications, for
analog audio signals.
Other connecting cables (IEEE1394, USB)
Use double shielded cables, which provide quality performance for high-frequency applications, as
connecting cables.
When connecting to the DVI signal terminal, use a cable with a ferrite core.
If your apparatus is supplied with ferrite core(s), they must be attached on cable(s) following instructions in
this manual.
2. Performance level
The performance level of the apparatus is equivalent to or better than the performance level required by these
standards.
However, the apparatus may be adversely affected by interference if it is being used in an EMC environment,
such as an area where strong electromagnetic fields are generated (by the presence of signal transmission
towers, cellular phones, etc.). In order to minimize the adverse effects of the interference on the apparatus in
cases like this, it is recommended that the following steps be taken with the apparatus being affected and with its
operating environment:
1. Place the apparatus at a distance from the source of the interference.
2. Change the direction of the apparatus.
3. Change the connection method used for the apparatus.
4. Connect the apparatus to another power outlet where the power is not shared by any other appliances.

7

8
Trademarks and Registered Trademarks
Microsoft®, Windows®, Windows®7, Windows®10, Microsoft Edge, and Internet Explorer® are either registered
trademarks or trademarks of Microsoft Corporation in the United States and other countries.
Apple, Mac, macOS, OS X, Safari are registered trademarks of Apple Inc., in the United States and other
countries.
Google Chrome™ browser trademarks of Google LLC.
Intel®and Intel®Core™ are trademarks or registered trademarks of Intel Corporation in the United States and
other countries.
Adobe®and Reader®are either registered trademarks or trademarks of Adobe Systems Incorporated in the
United States and/or other countries.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
Other names of companies and products contained in these Operating Instructions may be trademarks or
registered trademarks of their respective owners.
About Copyright and License
Distributing, copying, disassembling, reverse compiling, reverse engineering, and also exporting in violation of export
laws of the software provided with this unit are expressly prohibited.
Abbreviations
For the purposes of this manual, the model numbers of the units are given as listed in the table below.
Model number of unit Model number given in manual
AW-UE20KP, AW-UE20WP
AW-UE20KE, AW-UE20WE
AW-UE20KED,
AW-UE20WED
AW-UE20
AW-RP60 AW-RP60
AW-RP150G AW-RP150
Illustrations and screen displays featured in the manual
What is shown in the manual’s illustrations and screen displays may differ from how it is actually appears.

9
Disclaimer of Warranty
IN NO EVENT SHALL Panasonic Connect Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR
REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT
NOT LIMITED TO BELOW:
1. ANY DAMAGE AND LOSS, INCLUDING WITHOUT LIMITATION, DIRECT OR INDIRECT, SPECIAL,
CONSEQUENTIAL OR EXEMPLARY, ARISING OUT OF OR RELATING TO THE PRODUCT;
2. PERSONAL INJURY OR ANY DAMAGE CAUSED BY INAPPROPRIATE USE OR NEGLIGENT OPERATION
OF THE USER;
3. UNAUTHORIZED DISASSEMBLE, REPAIR OR MODIFICATION OF THE PRODUCT BY THE USER;
4. INCONVENIENCE OR ANY LOSS ARISING WHEN IMAGES ARE NOT DISPLAYED, DUE TO ANY REASON
OR CAUSE INCLUDING ANY FAILURE OR PROBLEM OF THE PRODUCT;
5. ANY PROBLEM, CONSEQUENTIAL INCONVENIENCE, OR LOSS OR DAMAGE, ARISING OUT OF THE
SYSTEM COMBINED BY THE DEVICES OF THIRD PARTY;
6. ANY DEMANDS FOR COMPENSATION, CLAIMS, ETC. OCCASIONED BY THE INFRINGEMENT OF
PRIVACY BY INDIVIDUALS OR ORGANIZATIONS WHOSE IMAGES WERE SHOT BY THE USER BECAUSE
THESE IMAGES (INCLUDING THE RECORDINGS MADE) WERE MADE AVAILABLE BY THE USER
BECAUSE IN THE PUBLIC DOMAIN. FOR SOME REASON OR OTHER OR BECAUSE THE IMAGES ENDED
UP BEING USED FOR PURPOSES OTHER THAN THE ONE DESCRIBED ABOVE;
7. LOSS OF REGISTERED DATA CAUSED BY ANY FAILURE.

10
Contents
Operating Instructions......................................................................................................................2
Read this first! (For AW-UE20KP, AW-UE20WP) .............................................................................2
Read this first! (For AW-UE20KE, AW-UE20WE, AW-UE20KED, AW-UE20WED)..........................4
Disclaimer of Warranty.....................................................................................................................9
Getting Started...............................................................................................................................14
Required Personal Computer Environment ............................................................................14
Network security .....................................................................................................................15
Characteristics...............................................................................................................................16
Accessories ...................................................................................................................................18
Optional Accessories ..............................................................................................................18
Operating Precautions ...................................................................................................................19
Parts and Functions.......................................................................................................................21
Wireless Remote Control (optional accessory)..............................................................................25
Network Settings............................................................................................................................29
Use the Easy IP setup Software .............................................................................................29
Use the EasyIP Setup Tool Plus Software to Establish the Unit’s Settings.............................31
Setting the Initial Account .......................................................................................................33
Basic Shooting Operation ..............................................................................................................35
Power on and Power Off the Camera Unit.....................................................................................36
Power on the Camera Unit .....................................................................................................36
Power off the Camera Unit .....................................................................................................36
Priority Mode..................................................................................................................................37
Selecting the Scene Mode ...........................................39
Scene Mode Types.................................................................................................................39
How to select the Scene mode...............................................................................................39
Operating the Camera unit ............................................................................................................41
Control the Picture’s Direction (using the wireless remote control).........................................41
Zoom In/Out Function (using the wireless remote control) .....................................................41
Switching the Direction or Zoom Speed (using the wireless remote control) ..........................41
Control the Picture’s Direction (using the controller)...............................................................41
Zoom In/Out Function (using the controller) ...........................................................................41
Switching the Direction or Zoom Speed (using the controller) ................................................41
What to do when Encountering Problems in the Basic Shooting Operations.................................42
Advanced Operations ....................................................................................................................43
Preset Memories ....................................................................................................................43
Adjust the White Balance .......................................................................................................44
Automatic Adjustment (AWB: AWB A or AWB B) .............................................................44
Auto Tracking White Balance Adjustment (ATW).............................................................45
3200K and 5600K Presets...............................................................................................45
Menu Operation.............................................................................................................................46
