Panasonic LUMIX DMC-G80M User manual

EB
Web Site: http://www.panasonic.com
Model number suffix “EB” denotes UK model.
Basic Operating Instructions
Digital Camera/
Lens Kit/Body
Model No. DMC-G80M/DMC-G80H
DMC-G80
DMC-G81M/DMC-G81H
DMC-G81
Please read these instructions carefully before using this product, and
save this manual for future use.
More detailed operating instructions are available in “Operating Instructions
for advanced features (PDF format)”. To read it, download it from the website.
(P70)
DVQX1015ZC
F0816HN2042
DVQX1015~Cover_mst.fm 1 ページ ２０２２年７月６日 水曜日 午後１時２７分

2DVQX1015 (ENG)
Dear Customer,
We would like to take this opportunity to thank you for purchasing this Panasonic Digital
Camera. Please read these Operating Instructions carefully and keep them handy for
future reference. Please note that the actual controls and components, menu items, etc. of
your Digital Camera may look somewhat different from those shown in the illustrations in
these Operating Instructions.
Carefully observe copyright laws.
•Recording of pre-recorded tapes or discs or other published or broadcast material for purposes
other than your own private use may infringe copyright laws. Even for the purpose of private
use, recording of certain material may be restricted.
Information for Your Safety
∫Product identification marking
WARNING:
To reduce the risk of fire, electric shock or product damage,
•Do not expose this unit to rain, moisture, dripping or splashing.
•Use only the recommended accessories.
•Do not remove covers.
•Do not repair this unit by yourself. Refer servicing to qualified service personnel.
The socket outlet shall be installed near the equipment and shall be easily accessible.
Product Location
Digital Camera Bottom
Battery charger Bottom
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 2 ページ ２０１６年７月２７日 水曜日 午後６時１８分

3
(ENG) DVQX1015
∫About the battery pack
•Do not heat or expose to flame.
•Do not leave the battery(ies) in a car exposed to direct sunlight for a long period of time with
doors and windows closed.
•Do not expose to low air pressure at high altitudes.
•Do not expose to extremely low air pressure, as this may result in explosions or leakage of
flammable liquids and gases.
∫About the battery charger
•The battery charger is in the standby condition when the AC power supply cord is connected.
The primary circuit is always “live” as long as the power cord is connected to an electrical
outlet.
Declaration of Conformity (DoC) for EU:
Hereby, “Panasonic Entertainment & Communication Co., Ltd.” declares that this
product is in compliance with the essential requirements and other relevant provisions
of Directive 2014/53/EU.
Customers can download a copy of the original DoC for our RE products from our DoC server:
https://www.ptc.panasonic.eu/compliance-documents
Importer for EU: Panasonic Marketing Europe GmbH
Authorized Representative in EU: Panasonic Testing Centre, Winsbergring 15, 22525
Hamburg, Germany
Declaration of Conformity (DoC) for UK:
Hereby, “Panasonic Entertainment & Communication Co., Ltd.” declares that this
product is in compliance with the essential requirements and other relevant provisions
of the Radio Equipment Regulations 2017.
Customers can download a copy of the original DoC for our RE products from our DoC server:
https://www.ptc.panasonic.eu/compliance-documents
Importer for UK: Panasonic UK, a branch of Panasonic Marketing Europe GmbH
Maxis 2, Western Road, Bracknell, Berkshire, RG12 1RT
Wireless transmitter:
Frequency range used: 2412 MHz to 2462 MHz (Central frequency)
Max. output power: 13 dBm (EIRP)
CAUTION
•Danger of explosion if battery is incorrectly replaced. Replace only with the type
recommended by the manufacturer.
•When disposing of the batteries, please contact your local authorities or dealer and ask for
the correct method of disposal.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above 60 xC or incinerate.
CAUTION!
To reduce the risk of fire, electric shock or product damage,
•Do not install or place this unit in a bookcase, built-in cabinet or in another confined
space. Ensure this unit is well ventilated.
DVQX1015~Safety_mst.fm 3 ページ ２０２２年７月６日 水曜日 午後１時３０分

4DVQX1015 (ENG)
•Do not use any other USB connection cables except the supplied one.
•Use a “High Speed HDMI micro cable” with the HDMI logo.
Cables that do not comply with the HDMI standards will not work.
“High Speed HDMI micro cable” (Type D–Type A plug, up to 2 m (6.6 feet) long)
•Always use a genuine Panasonic shutter remote control (DMW-RSL1: optional).
Keep this unit as far away as possible from electromagnetic equipment (such as
microwave ovens, TVs, video games etc.).
•If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be
disrupted by electromagnetic wave radiation.
•Do not use this unit near cell phones because doing so may result in noise adversely affecting
the pictures and/or sound.
•Recorded data may be damaged, or pictures may be distorted, by strong magnetic fields
created by speakers or large motors.
• Electromagnetic wave radiation may adversely affect this unit, disturbing the pictures and/or sound.
•If this unit is adversely affected by electromagnetic equipment and stops functioning properly,
turn this unit off and remove the battery or disconnect AC adaptor (DMW-AC10E: optional).
Then reinsert the battery or reconnect AC adaptor and turn this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
•If you record near radio transmitters or high-voltage lines, the recorded pictures and/or sound
may be adversely affected.
Cautions for Use
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 4 ページ ２０１６年７月２７日 水曜日 午後６時１８分

5
(ENG) DVQX1015
•Before cleaning the camera, remove the battery or the DC coupler (DMW-DCC8:
optional), or disconnect the power plug from the outlet.
•Do not press the monitor with excessive force.
•Do not press the lens with excessive force.
•Do not spray the camera with insecticides or volatile chemicals.
• Do not keep rubber or plastic products in contact with the camera for a long period of time.
•Do not use solvents such as benzine, thinner, alcohol, kitchen detergents, etc., to clean
the camera, since it may deteriorate the external case or the coating may peel off.
•Do not leave the camera with the lens facing the sun, as rays of light from the sun may
cause it to malfunction.
•Always use the supplied cords and cables.
•Do not extend the cords or the cables.
•During access (image writing, reading and deleting, formatting etc.), do not turn this unit
off, remove the battery, card or disconnect the AC adaptor (DMW-AC10E: optional).
Furthermore, do not subject the camera to vibration, impact or static electricity.
•The data on the card may be damaged or lost due to electromagnetic waves, static electricity or
breakdown of the camera or the card. We recommend storing important data on a PC etc.
•Do not format the card on your PC or other equipment. Format it on the camera only to ensure
proper operation.
•The battery is not charged when the camera is shipped. Charge the battery before use.
•The battery is a rechargeable lithium ion battery. If the temperature is too high or too
low, the operating time of the battery will become shorter.
•The battery becomes warm after using and during and after charging. The camera also
becomes warm during use. This is not a malfunction.
•Do not leave any metal items (such as clips) near the contact areas of the power plug or
near the batteries.
•Store the battery in a cool and dry place with a relatively stable temperature: [Recommended
temperature: 15 oC to 25 oC (59 oF to 77 oF), Recommended humidity: 40%RH to 60%RH]
•Do not store the battery for a long time while fully charged. When storing the battery for a
long period of time, we recommend charging it once a year. Remove the battery from the
camera and store it again after it has completely discharged.
These symbols indicate separate collection of waste
electrical and electronic equipment or waste batteries.
More detailed information is contained in “Operating
Instructions for advanced features (PDF format)”.
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 5 ページ ２０１６年７月２７日 水曜日 午後６時１８分

6DVQX1015 (ENG)
Contents
Information for Your Safety .....................2
Preparation/Basic
Care of the camera.................................7
Standard Accessories.............................8
About cards that can be used with
this unit ...................................................9
Quick Start Guide .................................10
Names and Functions of
Components .........................................16
Basic Operations ..................................19
Setting menu items...............................22
Calling frequently-used menus
instantly (Quick Menu) ..........................23
Assigning frequently used functions to
the buttons (function buttons) ...............23
Recording
Taking Pictures using the Automatic
Function (Intelligent Auto Mode)...........24
Adjusting Focus Manually.....................26
Select a Drive Mode .............................27
Recording 4K Photos............................27
Controlling Focus After Recording
(Post Focus/Focus Stacking) ................29
Taking Pictures While Adjusting a
Setting Automatically
(Bracket Recording)..............................32
Image Stabiliser ....................................34
Recording Motion Picture/
4K Motion Picture .................................36
Recording Motion Pictures with
4K Live Cropping ..................................38
Playback
Playing Back Pictures .......................... 40
Playing Back Motion Pictures .............. 40
Deleting Pictures.................................. 41
Menu
Menu list............................................... 42
Wi-Fi
What you can do with the Wi-FiR
function ................................................ 49
Controlling with a Smartphone/
Tablet ................................................... 50
Others
Downloading software.......................... 54
Monitor Display/Viewfinder Display...... 55
Troubleshooting ................................... 59
Specifications ....................................... 63
Digital Camera Accessory System....... 69
Reading the Operating Instructions
(PDF format) ........................................ 70
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 6 ページ ２０１６年７月２７日 水曜日 午後６時１８分

7
Preparation/Basic
(ENG) DVQX1015
Care of the camera
Do not subject to strong vibration, shock, or pressure.
•The lens, monitor, or external case may be damaged if used in the following conditions.
It may also malfunction or image may not be recorded if you:
–Drop or hit the camera.
–Press hard on the lens or the monitor.
∫Splash Proof
Splash Proof is a term used to describe an extra level of protection this camera offers against
exposure to a minimal amount of moisture, water or dust. Splash Proof does not guarantee
that damage will not occur if this camera is subjected to direct contact with water.
In order to minimise the possibility of damage please be sure the following precautions are taken:
–The Splash Proof feature works in conjunction with the lenses that were specifically designed
to support this feature.
–Make sure the built-in flash is closed.
–Make sure that all doors, socket caps and terminal covers are securely closed.
–Make sure that you are in a dry and secure place when changing the battery, lens or memory
card. After changing, make sure their protective doors are securely closed.
–If this camera is exposed to water, sand or any other foreign material clean it as soon as
possible, taking the necessary precautions that the foreign substance does not get inside the
camera.
–Under no circumstances should you touch or place any foreign objects within the camera or
in close proximity of the camera’s image sensor.
If sand, dust, or liquids such as water droplets adhere to the monitor, wipe them off with a
dry soft cloth.
–Not doing so may cause the monitor to respond incorrectly to touch operations.
–If the monitor is closed when such liquids are present, malfunction may result.
∫About Condensation (When the lens, the viewfinder or monitor is fogged up)
•Condensation occurs when the ambient temperature or humidity changes. Be careful of
condensation since it causes lens, viewfinder and monitor stains, fungus and camera malfunction.
•If condensation occurs, turn the camera off and leave it for about 2 hours. The fog will disappear
naturally when the temperature of the camera becomes close to the ambient temperature.
For smoother recording, we recommend updating the firmware of the interchangeable lens
to the latest version.
•To view the latest information on the firmware or to download the firmware, visit the
support site below:
http://panasonic.jp/support/global/cs/dsc/
(This Site is English only.)
•To check the firmware version of the interchangeable lens, attach it to the camera body and
select [Version Disp.] in the [Setup] menu.
If you shake the camera while it is turned off, its sensors may move or a rattling sound may
be heard. The sound is caused by the In-Body Image Stabiliser, and this is not a malfunction.
About the firmware of your interchangeable lens
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 7 ページ ２０１６年７月２７日 水曜日 午後６時１８分

Preparation/Basic
8DVQX1015 (ENG)
Standard Accessories
Check that all the accessories are supplied before using the camera.
Product numbers correct as of September 2016. These may be subject to
change.
Digital Camera Body
(This is referred to as camera body in these operating instructions.)
¢1 This is referred to as lens in these operating
instructions.
¢2 This is attached to the interchangeable lens at
the time of purchase.
¢3 This is attached to the camera body at the time
of purchase.
¢4 The interchangeable lens (H-FS12060)
included in DMC-G80M/DMC-G81M is dust-
and splash-proof.
¢5 The interchangeable lens (H-FS14140)
included in DMC-G80H/DMC-G81H is not dust-
and splash-proof.
•SD Memory Card, SDHC Memory Card and SDXC Memory Card are indicated as card in the text.
•The card is optional.
•Description in these operating instructions is based on the interchangeable lens (H-FS12060).
•Some digital camera kits may not be commercially available in some regions.
•Consult the dealer or Panasonic if you lose the supplied accessories. (You can purchase the
accessories separately.)
1Interchangeable Lens¢1,4,5
2Lens Hood
3Lens Cap¢2
4Lens Rear Cap¢2
5Body Cap¢3
6
Battery Pack
(Indicated as battery pack or battery in the
text)
Charge the battery before use.
7
Battery Charger
(Indicated as battery charger or charger in
the text)
8AC mains Lead
9USB Connection Cable
10 Shoulder Strap
11 Hot shoe cover
12 Cover for the battery grip connector
1
2
3
4
DMC-G80M,
DMC-G81M
H-FS14140
VYC1119
VYF3514
VFC4605
DMC-G80H,
DMC-G81H
VKF4971
DMW-BLC12E
6
10
K2CT3YY00034
8
5
K1HY04YY0106
9
DE-A80A
7
11
12
SKF0106K
SKF0145K
VFC4605
H-FS12060
SYA0066
VYF3514
DVPW1001Z
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 8 ページ ２０１６年７月２７日 水曜日 午後６時１８分

9
Preparation/Basic
(ENG) DVQX1015
About cards that can be used with this unit
∫About motion picture/4K photo recording and speed class ratings
Use a card that meets the following ratings of the SD Speed Class or UHS Speed Class.
•SD Speed Class and UHS Speed Class are the speed standards regarding continuous writing.
To check the class, see the labelled side, etc. of the card.
•Please confirm the latest information on the following website.
http://panasonic.jp/support/global/cs/dsc/
(This Site is English only.)
•Keep the Memory Card out of reach of children to prevent swallowing.
SD Memory Card
(512 MB to 2 GB)
•This unit is compatible with UHS-I/UHS-II UHS Speed Class
3 standard SDHC/SDXC memory cards.
•Operation of the cards on the left has been confirmed with
Panasonic’s cards.
SDHC Memory Card
(4 GB to 32 GB)
SDXC Memory Card
(48 GB to 128 GB)
[Rec Format] [Rec Quality] Speed class Label example
[AVCHD] All Class 4 or higher
[MP4] FHD/HD
[MP4] 4K UHS Speed Class 3
When recording with the 4K Photo/
Post Focus function UHS Speed Class 3
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 9 ページ ２０１６年７月２７日 水曜日 午後６時１８分

Preparation/Basic “Quick Start Guide”
10 DVQX1015 (ENG)
Quick Start Guide
•Check that the camera is turned off.
•We recommend attaching the shoulder strap when using the camera to prevent it from
dropping.
•Perform steps 1 to 8 and then attach the other side of the shoulder strap.
•Use the shoulder strap around your shoulder.
–Do not wrap the strap around your neck.
–It may result in injury or accident.
•Do not leave the shoulder strap where an infant can reach it.
–It may result in an accident by mistakenly wrapping around the neck.
The battery that can be used with this unit is DMW-BLC12E.
1Attach the battery paying attention to the direction of the battery.
2Connect the AC mains Lead.
•The [CHARGE] indicator A lights up and charging begins.
∫ About the [CHARGE] indicator
1Attaching the Shoulder Strap
2Charging the Battery
On: Charging.
Off: Charging has completed.
(Disconnect the charger from the electrical socket and detach the
battery after charging is completed.)
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 10 ページ ２０１６年７月２７日 水曜日 午後６時１８分

11
Preparation/Basic “Quick Start Guide”
(ENG) DVQX1015
•When the [CHARGE] indicator flashes
–The battery temperature is too high or too low. It is recommended to charge the battery again
in an ambient temperature of between 10 oC and 30 oC (50 oF and 86 oF).
–The terminals of the charger or the battery are dirty. In this case, wipe them with a dry cloth.
∫Charging time
•The indicated charging time is for when the battery has been discharged completely.
The charging time may vary depending on how the battery has been used.
The charging time for the battery in hot/cold environments or a battery that has not been
used for a long time may be longer than normal.
•Always use genuine Panasonic batteries (DMW-BLC12E).
•If you use other batteries, we cannot guarantee the quality of this product.
•Being careful about the battery orientation, insert all the way until you hear a locking sound and
then check that it is locked by lever A.
Pull the lever A in the direction of the arrow to remove the battery.
•Push it securely all the way until you hear a “click” while being careful about the direction in
which you insert it.
To remove the card, push the card until it clicks, then pull the card out upright.
Charging time Approx. 140 min
3Inserting the Battery
4Inserting the Card (Optional)
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 11 ページ ２０１６年７月２７日 水曜日 午後６時１８分

Preparation/Basic “Quick Start Guide”
12 DVQX1015 (ENG)
•Change lenses where there is not a lot of dirt or dust.
•Do not press the lens release button A when you attach a lens.
∫Detaching the lens
1Attach the lens cap.
2While pressing on the lens release button B, rotate
the lens toward the arrow until it stops and then
remove.
•Hold the part around the base of the lens to rotate it.
At the time when this camera is purchased, the monitor is stowed in the camera body.
Bring out the monitor as shown below.
1Open the monitor. (Maximum 180o)
2It can be rotated 180o forward.
3Return the monitor to its original position.
•Only rotate the monitor after opening it wide enough, and be careful not to use
excessive force as it may be damaged.
•When not using the monitor it is recommended that you close it with the screen facing inward to
prevent dirt and scratches.
5Attaching/Removing the Lens
6Opening the Monitor
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 12 ページ ２０１６年７月２７日 水曜日 午後６時１８分

13
Preparation/Basic “Quick Start Guide”
(ENG) DVQX1015
•The clock is not set when the camera is shipped.
1Turn the camera on.
•When the camera is turned on, the status indicator 1
lights up green.
2Press [MENU/SET].
3Press 2/1 to select the items (year, month, day,
hour, minute), and press 3/4 to set.
4Press [MENU/SET] to set.
5When [The clock setting has been completed.] is
displayed, press [MENU/SET].
6When [Please set the home area] is displayed, press
[MENU/SET].
7Press 2/1 to select the home area, and then press
[MENU/SET].
Adjust the diopter to suit your vision so that you can see
the characters displayed in the viewfinder clearly.
7Setting Date/Time (Clock Set)
8Diopter adjustment
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 13 ページ ２０１６年７月２７日 水曜日 午後６時１８分

Preparation/Basic “Quick Start Guide”
14 DVQX1015 (ENG)
Format the card before recording a picture with this unit.
Since data cannot be recovered after formatting, make sure to back up necessary
data in advance.
Set the mode dial to [¦].
•The settings of the main functions are adjusted automatically.
1Hold the camera gently with both hands, keep your arms still at your side and
stand with your feet slightly apart.
•Make sure your footing is stable and there is no danger of colliding with another person or
object in the vicinity while taking pictures.
•Do not cover the flash, AF Assist lamp A, microphone B, or speaker C with your
fingers or other objects.
9Formatting the card (initialisation)
> [Setup] > [Format]
10 Set the mode dial to [ ]
11 Taking pictures
MENU


DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 14 ページ ２０１６年７月２７日 水曜日 午後６時１８分

15
Preparation/Basic “Quick Start Guide”
(ENG) DVQX1015
2Press the shutter button halfway to focus.
AAperture value
BShutter speed
CFocus indication
•Aperture value and shutter speed are displayed.
(It will flash in red if the correct exposure is not achieved,
except when set to flash.)
•Once the subject is in focus, the focus indication is
displayed. (When the subject is not in focus, the indication
flashes.)
3Press the shutter button fully (push it in further), and
take the picture.
•Be careful not to move the camera when you press the shutter button.
•Pictures cannot be taken until focus is achieved when [Focus/Release Priority] is set to
[FOCUS].
∫Free angle shooting
The monitor can be rotated to suit your needs. This is convenient as it allows you to take
pictures from various angles by adjusting the monitor.
•The [Auto Review] function displays the picture you have just
taken.
•To display the picture in Playback Mode, press [(].
Taking pictures at a high angle Taking pictures at a low angle
12 Check the picture you have taken
6060603.53.53.5
C
AB
1/981/981/981/98
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 15 ページ ２０１６年７月２７日 水曜日 午後６時１８分

Preparation/Basic
16 DVQX1015 (ENG)
Names and Functions of Components
∫Camera body
6
4
24 2327 2526
12
7
9
10
20
1 32
22 5
22
13
11
8
18
19 21
16
15
14
17
1Focus distance reference mark
2Status indicator (P13)/
Wi-Fi® connection lamp (P49)
3Camera ON/OFF switch (P13)
4Motion picture button (P36)
5[ ] (Exposure Compensation) button/[Fn1]
button (P23)
6Function button (Fn11) (P23)
7Rear dial (P19)
8Shutter button (P15)
9Front dial (P19)
10 Self-timer indicator/
AF Assist Lamp
11 Mode dial (P20)
12 Flash
13
Hot shoe (Hot shoe cover)
•Keep the Hot Shoe Cover out of reach of
children to prevent swallowing.
14
Stereo microphone
•Be careful not to cover the microphone with
your finger. Doing so may make sound
difficult to record.
15
Flash open lever
•The flash opens, and recording with the flash
becomes possible.
16 Diopter adjustment dial (P13)
17 Drive mode dial (P27)
18 [MIC] socket
19 [REMOTE] socket
20 USB socket
21 [HDMI] socket
22 Shoulder strap eyelet (P10)
23 Lens release button (P12)
24 Lens lock pin
25 Mount
26 Sensor
27 Lens fitting mark (P12)
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 16 ページ ２０１６年７月２７日 水曜日 午後６時１８分

17
Preparation/Basic
(ENG) DVQX1015
リヴヰ
ョㄏピ
28
39
40
42
30 31
34
35
3633
32
47 4344
37
41
29
46 45
38
∫About the function button ([Fn6] to
[Fn10])
•Function buttons ([Fn6] to [Fn10]) (P23) are
touch icons. Touch the [ ] tab on the
recording screen to display them.
28 Touch screen (P21)/monitor (P55)
29 [LVF] button (P21)/[Fn5] button (P23)
30 Viewfinder (P21)
31 Eye sensor (P21)
32 Eyecup
33 [Q.MENU] button (P23)/[Fn2] button (P23)
34 [(] (Playback) button (P40)
35 Speaker
36
[DISP.] button
•Each time this is pressed, the display on the
monitor is switched.
37 [AF/AE LOCK] button
38 Focus mode lever (P26)
39
Cursor buttons (P19)
3/[ ] (ISO sensitivity)
1/[ ] (White Balance)
2/[ ] (Auto Focus Mode)
4/[Fn3] (P23)
40 [MENU/SET] button (P22)
41 Card door (P11)
42 [ ] (Delete/Cancel) button (P41)/
[Fn4] button (P23)
43 Battery door (P11)
44
DC coupler cover (P69)
•When using an AC adaptor, ensure that the
Panasonic DC coupler (DMW-DCC8:
optional) and AC adaptor (DMW-AC10E:
optional) are used.
•Always use a genuine Panasonic AC
adaptor (DMW-AC10E: optional).
•When using an AC adaptor, use the AC
mains Lead supplied with the AC adaptor.
45 Release lever (P11)
46
Cover for the battery grip connector
•Keep the cover for the battery grip connector
out of reach of children to prevent
swallowing.
47
Tripod mount
•It may not be possible to attach and securely
fasten a tripod with a screw length of 5.5 mm
(0.22 inch) or more to the camera. Doing so
may also damage the camera.
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 17 ページ ２０１６年７月２７日 水曜日 午後６時１８分

Preparation/Basic
18 DVQX1015 (ENG)
∫Lens
∫Removing the Hot Shoe Cover
The camera comes with a hot shoe cover attached to the hot shoe.
Remove the hot shoe cover by pulling it in the direction
indicated by arrow 2 while pressing it in the direction
indicated by arrow 1.
H-FS12060 H-FS14140
34
678
125
1349 6 825
1Lens surface
2Tel e
3Focus ring (P26)
4Zoom ring
5Wide
6Contact point
7Lens mount rubber
8Lens fitting mark (P12)
9O.I.S. switch
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 18 ページ ２０１６年７月２７日 水曜日 午後６時１８分

19
Preparation/Basic
(ENG) DVQX1015
Basic Operations
Pressing the cursor button:
Selection of items or setting of values etc., is performed.
Pressing [MENU/SET]:
Confirmation of setting contents, etc., is performed.
•These operating instructions expresses the up, down, left, and
right of the cursor button as 3/4/2/1.
Rotating:
Selection of items or setting of values is performed during the various settings.
•These operating instructions describe operations of the front dial/rear dial as follows:
Allows you to set the aperture, shutter speed, and other settings when in / / /
modes.
Cursor buttons/[MENU/SET] button
Front Dial/Rear Dial
e.g.: When rotating
the front dial to the
left or right
e.g.: When rotating
the rear dial to the
left or right
Mode dial Front dial Rear Dial
Programme Shift Programme Shift
Aperture value Aperture value
Shutter speed Shutter speed
Aperture value Shutter speed
リヴヰ
ョㄏピ
リヴヰ
ョㄏピ
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 19 ページ ２０１６年７月２７日 水曜日 午後６時１８分

Preparation/Basic
20 DVQX1015 (ENG)
Select the mode by rotating the mode dial.
•Rotate the mode dial slowly to select the desired mode.
Mode dial (Selecting a Recording Mode)
Intelligent Auto Mode (P24)
Intelligent Auto Plus Mode (P24)
Programme AE Mode
Records at the aperture value and shutter speed set by the camera.
Aperture-Priority AE Mode
The shutter speed is automatically determined by the aperture value you set.
Shutter-Priority AE Mode
The aperture value is automatically determined by the shutter speed you set.
Manual Exposure Mode
The exposure is adjusted by the aperture value and the shutter speed which
are manually adjusted.
Creative Video Mode
Records motion pictures with a manually set aperture value and shutter
speed.
1Press the motion picture button (or the shutter button) to start
recording a motion picture.
2Press the motion picture button (or the shutter button) to stop
recording a motion picture.
•You can adjust the aperture and shutter speed in the same way as you
adjust them when the mode dial is set to , , or . The method
for adjusting the aperture and shutter speed can be selected in [Exposure
Mode] in the [Motion Picture] menu.
/Custom Mode
Use this mode to take pictures with previously registered settings.
Scene Guide Mode
This mode allows you to take pictures that match the scene being recorded.
Creative Control Mode
Record while checking the image effect.
DMC-G80MHBody&G81MHBody_EB-DVQX1015_mst.book 20 ページ ２０１６年７月２７日 水曜日 午後６時１８分
