Panasonic Lumix DMC-TZ30 Technical specifications

VQT4B90
M0212KZ0
Basic Operating Instructions
Digital Camera
Model No. DMC-TZ30
Before use, please read these instructions completely.
More detailed instructions on the operation of this
camera are contained in “Operating Instructions
for advanced features (PDF format)” in the
supplied disc. Install it on your PC to read it.
GN

2 VQT4B90 (ENG)
Dear Customer,
We would like to take this opportunity to thank you for purchasing this Panasonic
Digital Camera. Please read these Operating Instructions carefully and keep them
handy for future reference. Please note that the actual controls and components,
menu items, etc. of your Digital Camera may look somewhat different from those
shown in the illustrations in these Operating Instructions.
Carefully observe copyright laws.
• Recording of pre-recorded tapes or discs or other published or broadcast material
for purposes other than your own private use may infringe copyright laws. Even
for the purpose of private use, recording of certain material may be restricted.
Information for Your Safety
WARNING:
To reduce the risk of fire, electric shock or product damage,
•Do not expose this unit to rain, moisture, dripping or splashing.
•Do not place objects filled with liquids, such as vases, on this
unit.
•Use only the recommended accessories.
•Do not remove covers.
•Do not repair this unit by yourself. Refer servicing to qualified
service personnel.
The socket outlet shall be installed near the equipment and shall be
easily accessible.
■Product identification marking
Product Location
Digital camera Bottom

(ENG) VQT4B90 3
■About the battery pack
CAUTION
• Danger of explosion if battery is incorrectly replaced. Replace only
with the type recommended by the manufacturer.
• When disposing the batteries, please contact your local authorities or
dealer and ask for the correct method of disposal.
• Do not heat or expose to flame.
• Do not leave the battery(ies) in a car exposed to direct sunlight for a
long period of time with doors and windows closed.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above
60 °C or incinerate.

4 VQT4B90 (ENG)
■About the AC adaptor (supplied)
CAUTION!
To reduce the risk of fire, electric shock or product damage,
•Do not install or place this unit in a bookcase, built-in cabinet or in
another confined space. Ensure this unit is well ventilated.
• The unit is in the standby condition when the AC adaptor is connected. The
primary circuit is always “live” as long as the AC adaptor is connected to an
electrical outlet.

(ENG) VQT4B90 5
■Cautions for Use
• Do not use any other USB connection cables except the supplied one.
• Always use a genuine Panasonic HDMI mini cable
(RP-CDHM15, RP-CDHM30: optional).
Part numbers: RP-CDHM15 (1.5 m), RP-CDHM30 (3.0 m)
• Always use a genuine Panasonic AV cable (DMW-AVC1: optional).
In the event of abnormal operation (e.g. if the unit emits smoke or an unusual
smell), immediately stop operating the unit and consult the Panasonic Customer
Care Centre on 132600.
Keep this unit as far away as possible from electromagnetic equipment (such
as microwave ovens, TVs, video games etc.).
• If you use this unit on top of or near a TV, the pictures and/or sound on this unit
may be disrupted by electromagnetic wave radiation.
• Do not use this unit near cell phones because doing so may result in noise
adversely affecting the pictures and/or sound.
• Recorded data may be damaged, or pictures may be distorted, by strong
magnetic fields created by speakers or large motors.
• Electromagnetic wave radiation generated by microprocessors may adversely
affect this unit, disturbing the pictures and/or sound.
• If this unit is adversely affected by electromagnetic equipment and stops
functioning properly, turn this unit off and remove the battery or disconnect AC
adaptor (supplied). Then reinsert the battery or reconnect AC adaptor and turn
this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
• If you record near radio transmitters or high-voltage lines, the recorded pictures
and/or sound may be adversely affected.
For information about the software used for this product, press [MENU/SET] and
select [Setup] to display [Version Disp.] before pressing [MENU/SET] again.
This product is licensed under the AVC patent portfolio license for the personal
and non-commercial use of a consumer to (i) encode video in compliance with
the AVC Standard (“AVC Video”) and/or (ii) decode AVC Video that was encoded
by a consumer engaged in a personal and non-commercial activity and/or was
obtained from a video provider licensed to provide AVC Video. No license is
granted or shall be implied for any other use. Additional information may be
obtained from MPEG LA, LLC.
See http://www.mpegla.com.

6 VQT4B90 (ENG)
Contents
Before use
Information for Your Safety .......2
Before use ...................................6
Standard accessories ................7
Names and Functions of
Main Parts ...................................8
Touch operations ........................9
Inserting and removing the
card (optional)/the battery .......10
Charging the battery ................11
Setting the clock .......................12
Setting the menu ......................14
Taking pictures .........................15
Taking motion pictures ............16
Viewing your pictures
[Normal Play] ............................18
Deleting pictures ......................18
GPS and map functions ...........19
Reading the Operating
Instructions (PDF format) ........22
Installing supplied software ....23
Specifications ...........................24
■Camera handling
●Keep the camera away from excessive vibration, force, or pressure.
●The camera is not dust resistant, splash resistant, or waterproof.
Avoid using the camera in places with excessive dust or sand, or
where water can come into contact with the camera.
■Condensation (When the lens or the LCD monitor is fogged up)
●Condensation may occur when the camera is exposed to sudden
changes of temperature or humidity. Avoid these conditions, which
may make the lens or LCD monitor dirty, cause mould, or damage the
camera.
●If condensation does occur, turn off the camera and wait about two
hours before using it. Once the camera adjusts to the surrounding
temperature, fogginess will clear naturally.

(ENG) VQT4B90 7
Standard accessories
• SD Memory Card, SDHC Memory Card and SDXC Memory Card are
indicated as card in the text.
• Memory cards are optional. You can record or play back pictures on the
built-in memory when you are not using a card.
• Consult the dealer or your nearest Service Centre if you lose the
supplied accessories. (You can purchase the accessories separately.)
• Please dispose of all packaging appropriately.
• Keep small parts in a safe place out of the reach of children.
• The illustrations and screens in this manual may differ from the actual
product.
Check that all the accessories are supplied before using the camera. Part
numbers are as of January 2012.
Battery pack
DMW-BCG10E
• Charge the battery
before use.
Battery pack is indicated as
battery pack or battery in the
text.
AC adaptor
VSK0776
Hand strap
VFC4297
USB connection
cable
K1HY08YY0025
DVD
VFF0978
• Software:
Use it to install the
software on your
PC.
• Map data
• Operating
Instructions for
advanced features
DVD is indicated as disc in the
text.

8 VQT4B90 (ENG)
Names and Functions of Main Parts
Camera ON/OFF switch
Shutter button
Mode dial
Flash
Self-timer indicator/AF Assist Lamp
Lens barrel
Lens
Zoom lever
We recommend using the
supplied hand strap to
avoid dropping the camera.
GPS status indicator
[EXPOSURE] button
[MAP] button
LCD monitor
Cursor buttons
[DISP.] button
[Q.MENU]/[ / ] (Delete/Cancel)
button
Built-in GPS antenna
Microphone
Speaker
Motion picture button
REC/PLAY switch
[HDMI] socket
[AV OUT/DIGITAL]
socket
[MENU/SET] button
Charging lamp
Tripod receptacle
• Ensure that the tripod is stable.
Card/Battery door
Release lever

(ENG) VQT4B90 9
Touch operations
This camera’s touch screen senses pressure that is applied to the screen.
Touch
To “touch” is to press the touch screen and then pull
the finger back again.
Touching is used to select icons or pictures, among other
actions.
• Touch an icon near its centre. If multiple icons are
touched simultaneously, the camera may not operate
normally.
Drag
To “drag” is to touch and slide your finger across the
touch screen surface.
Dragging (sliding your finger across the screen) is used
to scroll the pictures or change the range of the pictures
displayed.
●If the type of sheet to protect LCD screens that are available on the
market is to be used, observe the precautions that are contained with
the sheet. (Some types of protective sheets may impair the screen’s
visual recognition and ease of operation.)
●If the camera is used with a protective sheet available on the market
attached to its screen or if the screen is not very responsive, touch the
screen with a little more pressure.
●If your hand is pressed against the touch screen when holding the
camera, the touch screen will not work properly.
●Do not press on the LCD monitor with hard pointed tips, such as
ballpoint pens.
●Do not press the touch screen with your fingernails.
●Clean the LCD monitor with a soft dry cloth if there are fingerprints or
other kinds of dirt on it.

10 VQT4B90 (ENG)
Inserting and removing the card (optional)/
the battery
To charge the battery, insert it into the camera.
Set the camera ON/OFF switch
to OFF and slide the release
lever ( ) to [OPEN] before
opening the card/battery door
[OPEN] [LOCK]
Insert the battery and card,
making sure that their
orientation is correct
• Battery: Insert all the way firmly until a
locking sound is heard, and check
that it is locked by lever ( ).
• Card: Insert all the way firmly until it
clicks.
Do not touch the
terminals on the
back of the card.
Close the card/battery door
Slide the release lever to the [LOCK]
position.
■To remove
•To remove battery:
Move lever in direction of arrow.
•To remove card:
Push the card until it clicks,
then pull the card out.
Lever
●Always use genuine Panasonic batteries (DMW-BCG10E).
●If you use other batteries, we cannot guarantee the quality of this
product.
●Keep the Memory Card out of reach of children to prevent swallowing.
●We recommend using a Panasonic Memory card.

(ENG) VQT4B90 11
Charging the battery
•The battery is not charged when the camera is shipped. Charge
the battery before use.
•Charge the battery with the AC adaptor (supplied) indoors (10 °C
to 30 °C).
•Always use the dedicated AC adaptor (supplied), USB connection
cable (supplied), and battery.
• To charge the battery, insert it into the camera.
• Make sure that the camera is turned off.
Connect the AC adaptor ( ) (supplied) and the
camera using the USB connection cable ( )
(supplied), and plug the AC adaptor ( ) (supplied)
into the electrical outlet
To the electrical outlet
●Do not use any other USB connection cables except the supplied one.
Doing so may cause malfunction of the camera.
●Do not use any other AC adaptors except the supplied one.
■Charging lamp ( )
On: Charging in progress (approx. 260 min. if fully depleted)
Off: Charging stops
■About batteries that you can use with this unit
The battery that can be used with this unit is DMW-BCG10E.

12 VQT4B90 (ENG)
Setting the clock
The clock is not set when the camera is shipped.
Set REC/PLAY switch to before turning the camera on.
Turn the camera on ( )
Press [MENU/SET] ( )
Press to select the items
(year, month, day, hour, minute,
display order or time display
format), and press to set
Press [MENU/SET] to set
Confirm the setting and press [MENU/SET]
• To return to the previous screen, press [ / ].
Press to select [Yes] and press [MENU/SET]
if automatically correcting time of day using the
GPS function
• To manually set date and time →select [No].
• When you select automatic time adjustment using the GPS
function, [GPS Setting] is set to [ON].

(ENG) VQT4B90 13
When [Please set the home area] is displayed,
press [MENU/SET]
Press to set your home area
and press [MENU/SET]
The current time and home area are set.
■To change the time setting
Select [Clock Set] from [Rec] or [Setup] menu, perform and .

14 VQT4B90 (ENG)
Setting the menu
Refer to the following procedures to operate the menus.
Example: Setting [AF Mode] from to in the [Program AE] Mode
Press [MENU/SET] to display the menu
Switching to the [Rec] menu
Use cursor button to select [Rec] and
press [MENU/SET].
• The menu type can also be selected by
touch operations.
Press to select [AF Mode]
and then press [MENU/SET]
• Depending on the item, its setting may not
appear or it may be displayed in a different
way.
Press to select and then
press [MENU/SET] to set
Press [ / ] several times to
close the menu

(ENG) VQT4B90 15
Taking pictures
Turn the camera on ( ) Shutter button
Slide the REC/PLAY switch ( )
to
Set to the desired recording mode
( )
■Recording mode
Take pictures with automatic settings.
The subjects are recorded using your own settings.
The shutter speed is automatically determined by the aperture value you
set.
The aperture value is automatically determined by the shutter speed you
set.
The exposure is adjusted by the aperture value and the shutter speed
which are manually adjusted.
Use this mode to take pictures with previously registered setting.
Record 3D still pictures.
Take pictures according to the scene.
Take pictures while confirming the picture effect.
Take a picture
Press halfway
(press lightly and focus)
Press fully
(press the button
all the way to record)

16 VQT4B90 (ENG)
Taking motion pictures
Recording mode:
You can record motion pictures with audio (stereo). Zoom can also be
used during recording.
Slide the REC/PLAY switch ( )
to
Press the motion picture button ( )
to start recording
Press the motion picture button ( )
again to end recording
Remaining recording time (approx.)
Elapsed recording time

(ENG) VQT4B90 17
●We recommend you use a battery with sufficient battery power when
recording motion pictures.
●Immediately release the motion picture button after pressing it all the
way.
●You can continuously record a motion picture in [MP4] for up to
29 minutes 59 seconds or approx. 4 GB. In this case, you can
continuously record a motion picture in [FHD] for up to approx.
27 minutes 12 seconds.
●If [Rec Quality] of [AVCHD] motion pictures is set to [GPH], [PSH],
[GFS] or [FSH], you can continuously record a motion picture for up to
29 minutes 59 seconds.
●If the surrounding temperature is high, or a motion picture is
recorded continuously, is displayed and recording may be
stopped halfway through to protect the camera. (Only when [Rec
Quality] is set to [GPH], [PSH], [GFS] or [FSH])
●Motion pictures cannot be recorded in the built-in memory.

18 VQT4B90 (ENG)
Viewing your pictures [Normal Play]
Deleting pictures
Slide the REC/PLAY switch ( )
to
Drag your finger
across the screen,
and select the
picture to be played
back
●To play back a motion picture, touch or press after selecting a
picture.
●You can print pictures by connecting a camera to your computer or
printer, or by giving an SD card to a shop assistant at a photo shop.
Deleted pictures cannot be recovered.
Press [ / ] ( ) to delete the
displayed picture
Press to select [Yes] and then
press [MENU/SET] ( )

(ENG) VQT4B90 19
GPS and map functions
Before using the camera, be sure to read “Licence Agreement for Place
Name and Map Data” (Operating Instructions for advanced features).
This camera can record the location information of a place where a
picture was taken on the pictures. The camera can also automatically
adjust the time or display a place where a picture was taken on a map
during playback.
Using the GPS function to execute positioning
Press [MENU/SET] ( )
Use cursor button to select
[GPS] menu and press
[MENU/SET]
Use cursor button to select
[GPS Setting] and press
[MENU/SET]
Use cursor button to select [ON] and press
[MENU/SET]
• A message appears on the screen. After confirming the message,
press [MENU/SET].
■When [GPS Setting] is [ON], the GPS function works even if the
camera’s power is off.
• Electromagnetic waves from the camera can affect instruments and
meters. During takeoff and landing of airplanes or in other restricted
areas, set [GPS Setting] to [OFF] or set [Airplane Mode] to [ON], and
then turn off the camera.
• When [GPS Setting] is [ON] and [Airplane Mode] is [OFF], power will
drain from the battery even if the camera is turned OFF.

20 VQT4B90 (ENG)
GPS and map functions
■Displaying the status and result of positioning
The icons that indicate the status and result of positioning will
appear on the LCD monitor. When the camera successfully executes
positioning, it records the current location and displays the place name
information on the screen.
Place name
information
GPS reception icon
Positioning
executed
successfully
The same number of icons as the
number of the GPS satellites (from
which radio signals are successfully
received) stop flashing and light (blue).
If the three bars of the GPS reception
icon do not light and the icon turns
off, it means that positioning was
unsuccessful.
Positioning result icons
(Time elapsed after successful positioning)
(minute)
: No positioning information has been
acquired.
●Positioning will take time in environments where it is difficult to
receive the signals from the GPS satellites. For details, refer
to “Using the GPS function to record the location of a picture”
(Operating Instructions for advanced features).
●Even if GPS reception is good, it will take approx. 2 to 3 minutes
to successfully execute positioning under the following conditions;
when positioning is executed for the first time, or when positioning is
executed after the camera is turned off with the [GPS Setting] set to
[OFF] or [Airplane Mode] set to [ON], and then turned on again.
