Panasonic AK-SHB800G User manual

Operating Guide
8K Multi Purpose Camera
ENGLISH
DVQP2086ZA
W0819GU0 -FJ
Model No.
Model No.
Image Processing Unit
Model No.
Model No.
Refer to this document when connecting a 8K Multi Purpose Camera (AK-SHB800)
and Image Processing Unit (AK-SHU800) for use.
PSJ EJ
AK-SHB800PS
AK-SHB800G
AK-SHU800PS
AK-SHU800E
GJ

– 2 –
rAbout trademarks and registered trademarks
fMicrosoft®, Windows®, Windows®7, Windows®8, Windows®8.1, Windows®10, Internet Explorer®, ActiveX®, and DirectX®are registered trademarks or
trademarks of Microsoft Corporation in the United States, Japan, and/or other countries.
fApple, Mac, and OS X are trademarks of Apple Inc., registered in the United States and other countries.
fIntel®, Intel®CoreTM are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and/or other countries.
fAll other names, company names, product names, etc., contained in this instruction manual are trademarks or registered trademarks of their
respective owners.
How to read this document
rIllustrations
fIllustrations of the camera, menu screens, and other items, may vary from the actual products.
fScreenshots are used according to guidelines provided by Microsoft Corporation.
rConventions used in this manual
fWords and phrases in [ ] brackets indicate content displayed in the monitor.
fWords and phrases in < > brackets indicate design text used on this camera, such as button names.
rReference pages
fReference pages in this document are indicated by (page 00).
rTerminology
fMicrosoft®Windows®7 Professional SP1 32/64-bit is referred to as Windows 7.
fMicrosoft®Windows®8 Professional 32/64-bit is referred to as Windows 8.
fMicrosoft®Windows®8.1 Professional 32/64-bit is referred to as Windows 8.1.
fMicrosoft®Windows®10 Professional 32/64-bit is referred to as Windows 10.
fWindows®Internet Explorer®8.0, Windows®Internet Explorer®9.0, Windows®Internet Explorer®10.0, and Windows®Internet Explorer®11.0 are
referred to as Internet Explorer.
fSD memory cards, SDHC memory cards, and SDXC memory cards are all referred to as “memory cards” in this manual. They are individually written
when explaining each type.
fThe 8K Multi Purpose Camera is referred to as “camera”. (Page 15)
fThe Image Processing Unit is referred to as “IPU”. (Page 19)
fRemote operation panel is referred to as “ROP”.
For the purposes of this manual, the model numbers of the units are given as listed in the table below.
Model number of unit Model number given in manual
AK-SHB800G AK-SHB800
AK-SHB800PS
AK-SHU800PS AK-SHU800
AK-SHU800E
AK-HRP1000G AK-HRP1000
AK-SFC101G AK-SFC101

Contents
– 3 –
Contents
Chapter 1 Overview 4
Before using the camera 5
Notes 6
Required environment for computer 6
Disclaimer 6
Notes regarding network 6
Memory cards (IPU only) 6
Using the camera in a system 7
Basic conguration devices 7
Expanded conguration devices 7
System block diagram 7
Accessories 13
8K Multi Purpose Camera AK-SHB800 13
Image Processing Unit AK-SHU800 13
Chapter 2 Description of Parts 14
8K Multi Purpose Camera AK-SHB800 15
Front side 15
Left side 16
Right side 16
Rear side 17
Upper side 18
Bottom side 18
Image Processing Unit AK-SHU800 19
Front panel 19
Rear panel 20
Chapter 3 Operation 21
On-screen displays of the monitor 22
Data 24
User le 24
Operation procedure 25
Adjustment for shooting 26
White balance adjustment 26
Black balance adjustment 26
Genlock adjustment 26
Shutter mode 26
Shutter mode/speed setting 27
Synchro scan mode setting 27
Image quality adjustment 28
Detail function 28
Skin tone function 29
RB gain control function 30
Chroma setting function 30
Matrix function 30
Color correction function 31
Black control function 31
Gamma function 31
Knee function 32
High color function 32
White clip function 32
Multi-formats 33
Superimposing of character 33
List of output formats (<SDI OUT 1> to <SDI OUT 4> terminals) 34
List of output formats (<HD SDI OUT 1>/<HD SDI OUT 2>
terminals) 35
Convenient shooting functions 36
Scan reverse shooting 36
Displaying the zebra pattern 36
Displaying the center marker 36
Color bar 37
Focus assist function 37
ROI function 37
Chapter 4 Menu Operations 38
Menu operations (AK-SHU800) 39
Basic operations 39
Menu conguration (AK-SHU800) 41
[MAIN MENU] 41
Menu list (AK-SHU800) 42
[DISPLAY SETUP] 42
[SWITCH MODE] 45
[PAINT (MAIN)] 48
[PAINT (DC-HD)] 57
[PAINT (CROP)] 65
[SYSTEM MODE] 67
[IN/OUT SELECT] 68
[NETWORK SETUP] 69
[FILE] 69
[MAINTENANCE] 71
[DIAGNOSTIC] 74
Chapter 5 Connecting to External Devices 75
Connecting the remote operation panel (AK-HRP1000) 76
Serial connection with the <ROP> terminal 76
IP connection with the <LAN> terminal 76
Chapter 6 Network Settings 77
Setting the user account 78
Software 78
Use the User Account Setup Software to set the user
accounts in this unit 78
Chapter 7 Maintenance 79
Troubleshooting 80
For operations 80
Recharging the internal battery 81
Checking the operating time 82
Warning displays 83
Camera warning displays 83
Other warning displays 83
Updating the camera rmware 84
Chapter 8 Specications 85
Specications 86
8K Multi Purpose Camera AK-SHB800 86
Image Processing Unit AK-SHU800 87
Details of the connector signals 88
8K Multi Purpose Camera AK-SHB800 88
Image Processing Unit AK-SHU800 89
Index 91

Before using the camera, read this chapter.
Chapter 1 Overview

– 5 –
Chapter 1 Overview — Before using the camera
Before using the camera
rUse appropriate lighting when shooting to capture images with clear color
fTo make the color of images clear, use appropriate lighting for shooting.
fColors may not be reproduced correctly under uorescent lighting. Select appropriate lighting as necessary.
fUse the ND lter in excessively bright locations.
rTurn off the power before connecting or disconnecting the cables
fTurn off the power of the devices before connecting or disconnecting the cables.
rHandling of the camera
fDo not drop or add strong impact or vibration to the camera. Doing so may lead to failure.
rDo not touch optical system parts
fThe optical system parts are the “life” of the camera. Do not touch the optical systems on occasions such as when the lens is removed. In the event
that dust has adhered, use a blower for cameras or lens cleaning paper (for use with glasses or cameras) to gently remove the dust.
rDo not shoot images toward sunlight or a laser beam
fShooting toward sunlight or a laser beam for a long period of time may result in damage of the MOS.
rWhen using the camera in rain or snow, or on a beach or shore
fPrevent water from splashing on or entering the camera.
rHumidity and dust
fThe internal parts of the camera are more easily damaged in humid and dusty locations. Avoid such locations.
rTemperature range for use
fUsing the camera under the following conditions may have negative effects on the image quality or internal parts of the camera. Avoid such locations.
8K Multi Purpose Camera AK-SHB800
Cold places where the temperature is −10 °C (14 °F) or below
Hot places where the temperature is 45 °C (113 °F) or above
Image Processing Unit AK-SHU800
Cold places where the temperature is 0 °C (32 °F) or below
Hot places where the temperature is 40 °C (104 °F) or above
fPreheating is required in a low-temperature environment. Conrm display is not lit before using the camera.
rCleaning
fTurn off the power and clean the camera with a dry cloth. If the dust cannot be removed with a dry cloth, try soaking the cloth with kitchen detergent to
gently wipe off the dust.
fUse lens cleaning paper (for use with glasses or cameras) when cleaning the lens.
rCooling fan
fThe camera has an internal cooling fan.
fThe cooling fan is a consumable supply. Replace it after approximately 40,000 hours of use. Be sure to contact your dealer for the replacement.
rPeripheral devices and software
fThe software of the peripheral device that is connected to the camera may require updating.
fFor details, contact your dealer.
rInformation on software used with this product
1 This product includes GNU General Public License (GPL) and GNU Lesser General Public License (LGPL) licensed software, and the
customer is entitled to obtain, modify, or redistribute the source code for the software.
2 This product includes MIT Licensed software.
3 This product includes software developed by the OpenSSL Project for use in the OpenSSL Toolkit (http://www.openssl.org/).
4 This product includes OpenBSD Licensed software.
For details, refer to the license conditions.
For details on these descriptions (originally provided in English) and how to obtain the source code, visit the following website.
https://pro-av.panasonic.net/
However, do not contact Panasonic for questions regarding obtained source codes.
With the exception of open source software licensed according to GPL/LGPL and other similar licenses, distributing, copying, disassembling, reverse
compiling, and reverse engineering of software provided with the unit are expressly prohibited. Furthermore, it is expressly prohibited to export any
software provided with the unit in violation of export laws.
rCarrying
fWhen carrying the camera, carry it with two hands using the handle ttings.
rDust-proof lterl (camera only)
fThe cooling performance drops when the lter is dirty. As a guide, it should be replaced about every 6 months. If you notice clogging or deterioration
during inspections, replace the lter.

– 6 –
Chapter 1 Overview — Notes
Notes
Required environment for computer
Refer to the following website for information about recommended PCs.
https://pro-av.panasonic.net/
Disclaimer
In any case, Panasonic will not liable for any of the following:
fIncidental, special, or consequential damage or harm caused directly or indirectly in regard to the camera
fTrouble or malfunctions caused by the misuse or careless use of a user
fDisassembly, repair, or modication of the camera performed by a user
fInconvenience, damage, or harm arising from the inability to display images as a result of any reason or cause including failure or malfunction of the
camera
fMalfunctions arising from a system that has been combined with a third party device or any inconvenience, damage, or harm caused as a result
thereof
fInconvenience, damage, or harm caused by such as improper installation or any reason other than a defect of the camera
fAny loss of stored information due to any reason
fAny damage or claim regarding loss or leakage of image data or setting data saved in the camera, memory card, or computer
Notes regarding network
This camera is provided with functions which are used upon connecting to a network.
When the camera is used while connected to a network, there are the following potential risks.
fLeakage or disclosure of information via the camera
fManipulation of the camera by a malicious third party
fInterference or interruption of the camera caused by a malicious third party
To prevent such risks, users are responsible for implementing sufcient network security measures inclusive of the following.
fUse the camera over a network where safety is ensured with the installation of a rewall, etc.
fWhen the camera is used in a system to which a computer is connected, be sure to perform regular checks or detections for computer viruses and
malware.
In addition, be sure to observe the following precaution.
fDo not install the camera or cables in a place where they may easily be damaged.
Memory cards (IPU only)
Memory cards used with the unit should conform to SD, SDHC or SDXC standards.
Be sure to use the unit to format memory cards.
Memory cards with the following capacity can be used with the unit.
SD: 2 GB
SDHC: 4 GB to 32 GB
SDXC: 64 GB
For the latest information not described in the Operating Instructions, refer to the following website.
https://pro-av.panasonic.net/
Observe the following points when using and storing this unit.
●Avoid high temperature and humidity.
●Avoid water droplets.
●Avoid static electricity.

– 7 –
Chapter 1 Overview — Using the camera in a system
Using the camera in a system
An example of a standard system congured with the 8K Multi Purpose Camera (AK-SHB800), Image Processing Unit (AK-SHU800) and peripheral
devices is as follows.
Basic conguration devices
The following are the basic conguration devices of this camera, such as lens.
Part name Part No. Remark
Lens — —
Remote operation panel AK-HRP1000
This is the controller to control this camera.
@@NOTE
tUpdate the version on AK-HRP1000. The software needs to be
changed for AK-SHB800 and AK-SHU800.
For details, contact your dealer.
Expanded conguration devices
In addition to the basic conguration devices, the following expanded conguration device (for a fee) is available.
Part name Part No. Remark
Software key AK-SFC101
This is the software key that enables cropping of HD images in the
specied places in 8K images.
@@NOTE
tFor details, visit the following website.
https://pro-av.panasonic.net/
System block diagram
@@NOTE
tUse the following cables for connection.
Optical ber cable for connecting AK-SHB800 and AK-SHU800: Single-mode optical ber cable
BNC cable for 12G SDI output from AK-SHU800: BNC cable for 12G
BNC cable for SDI output other than 12G from AK-SHU800: BNC cable 5CFB or above
tThe 8K Multi Purpose Camera (AK-SHB800) and Image Processing Unit (AK-SHU800) do not work separately so make sure they are connected with
optical ber cable for use.

– 8 –
Chapter 1 Overview — Using the camera in a system
Conguration for outputting 8K and HD
RESERVE ROPAUX TRUNK COMMUNICATION LAN
IN
OUT
75Ω
AUTO
HD SDI OUT HD SDI PROMPT
12IN
IN
OUT
OUT
SDI OUT
OPTAC IN 〜
SIGNAL GND
REF
1234
AK-SHB800G
AK-SHU800E
AK-SHU800PS
AK-HRP1000
AK-SHB800PS
DCIN
EFLENS
ACIN
OPTOUT
OPTINOPTOUT
OPTIN
ab
ROP,LAN
SDIOUT1
SDIOUT2
SDIOUT3
SDIOUT4
f
12G
12G
12G
12G
HDSDIOUT1
HDSDIOUT2
3G
1.5G
c
e
d
g
SDI OUT
1234
a: Optical ber cable ×2
b: External DC power supply
c: HD monitor
d: HD monitor
e: 5CFB BNC cable ×2
f: 12G BNC cable ×4
g: 8K monitor
@@NOTE
tWhen connecting AK-HRP1000 via LAN, PoE power supply is required for the AK-HRP1000 <LAN> terminal.

– 9 –
Chapter 1 Overview — Using the camera in a system
Conguration for outputting 4K and HD (Example 1)
RESERVE ROPAUX TRUNKCOMMUNICATION LAN
IN
OUT
75Ω
AUTO
HD SDI OUT HD SDI PROMPT
12IN
IN
OUT
OUT
SDI OUT
OPTAC IN 〜
SIGNAL GND
REF
1234
AK-SHB800PS
EFLENS
b
OPTOUT
OPTIN
a
ACIN
HDSDIOUT1
HDSDIOUT2
3G
1.5G
c
e
d
OPTINOPTOUT
AK-SHU800PS
AK-HRP1000
ROP,LAN
gf
DCIN
12G SDIOUT1,SDIOUT2
SDI OUT
1234
AK-SHB800G
AK-SHU800E
a: Optical ber cable ×2
b: External DC power supply
c: HD monitor
d: HD monitor
e: 5CFB BNC cable ×2
f: 12G BNC cable
g: 4K monitor
@@NOTE
tWhen connecting AK-HRP1000 via LAN, PoE power supply is required for the AK-HRP1000 <LAN> terminal.

– 10 –
Chapter 1 Overview — Using the camera in a system
Conguration for outputting 4K and HD (Example 2)
RESERVE ROPAUX TRUNK COMMUNICATION LAN
IN
OUT
75Ω
AUTO
HD SDI OUT HD SDI PROMPT
12IN
IN
OUT
OUT
SDI OUT
OPTAC IN 〜
SIGNAL GND
REF
1234
AK-SHB800PS
EFLENS
b
OPTOUT
OPTIN
a
ACIN
OPTINOPTOUT
HDSDIOUT1
HDSDIOUT2
3G
1.5G
c
e
d
SDIOUT1
SDIOUT2
SDIOUT3
SDIOUT4
AK-SHU800PS
DCIN
AK-HRP1000
ROP,LAN
g
f
3G
3G
3G
3G
SDI OUT
1234
AK-SHB800G
AK-SHU800E
a: Optical ber cable ×2
b: External DC power supply
c: HD monitor
d: HD monitor
e: 5CFB BNC cable ×2
f: 5CFB BNC cable ×4
g: 4K monitor
@@NOTE
tWhen connecting AK-HRP1000 via LAN, PoE power supply is required for the AK-HRP1000 <LAN> terminal.

– 11 –
Chapter 1 Overview — Using the camera in a system
RESERVE ROPAUX TRUNK COMMUNICATION LAN
IN
OUT
75Ω
AUTO
HD SDI OUT HD SDI PROMPT
12IN
IN
OUT
OUT
SDI OUT
OPTAC IN 〜
SIGNAL GND
REF
1234
AK-SHB800PS
EFLENS
b
OPTOUT
OPTIN
a
ACIN
OPTINOPTOUT
HDSDIOUT1
HDSDIOUT2
3G
1.5G
c
e
dAK-SHU800PS
DCIN
AK-HRP1000
ROP,LAN
AK-SHB800G
AK-SHU800E
Conguration for outputting HD
a: Optical ber cable ×2
b: External DC power supply
c: HD monitor
d: HD monitor
e: 5CFB BNC cable ×2
@@NOTE
tThe output from SDI OUT 1 to 4 is HD videos cropped from the center of 8K videos.
tWhen connecting AK-HRP1000 via LAN, PoE power supply is required for the AK-HRP1000 <LAN> terminal.

– 12 –
Chapter 1 Overview — Using the camera in a system
RESERVE ROPAUX TRUNK COMMUNICATION LAN
IN
OUT
75Ω
AUTO
HD SDI OUT HD SDI PROMPT
12IN
IN
OUT
OUT
SDI OUT
OPTAC IN 〜
SIGNAL GND
REF
1234
AK-SHU800PS
AK-HRP1000
LAN
LAN LAN
AK-SFC101
LAN
AK-SHB800PS
DCIN
EFLENS
ACIN
OPTOUT
OPTINOPTOUT
OPTIN
ab
HDSDIOUT1
HDSDIOUT2
3G
3G
3G
3G
3G
1.5G
c
e
d
c
h
SDIOUT1(CROP1)
SDIOUT2(CROP2)
SDIOUT3(CROP3)
SDIOUT4(CROP4)
f
g
i
AK-SHB800G
AK-SHU800E
a: Optical ber cable ×2
b: External DC power supply
c: HD monitor
d: HD monitor
e: 5CFB BNC cable ×2
f: 5CFB BNC cable ×4
g: Switching hub
h: PC for ROI control
i: Joystick controller
@@NOTE
tA separately available personal computer, software key AK-SFC101 and joystick controller will be required for ROI control. For details, contact your
dealer.
tWhen connecting AK-HRP1000 via LAN, PoE power supply is required for the AK-HRP1000 <LAN> terminal.
Conguration for HD ROI control

– 13 –
Chapter 1 Overview — Accessories
Accessories
8K Multi Purpose Camera AK-SHB800
Mount cap (already attached to the product)
Flange nut (x 2)
Wire mounting screws (x 4)
Image Processing Unit AK-SHU800
Power cable
●for AK-SHU800PS (x 1)
●for AK-SHU800E (x 2)
Rack mount adaptors (x 2) (already attached to the product)
@@NOTE
tAfter removing the product from its container, dispose of the power cable cap (if supplied) and packing materials in an appropriate manner.

This chapter describes the names of the parts, functions, and operations of this camera and Image Processing Unit (IPU).
Chapter 2 Description of Parts

– 15 –
Chapter 2 Description of Parts — 8K Multi Purpose Camera AK-SHB800
8K Multi Purpose Camera AK-SHB800
Front side
2
1
3
1 Lens mount (EF mount)
This is where the lens is mounted.
2 Front tally lamp
Lights up when the tally signal is supplied.
Blinks in red while displaying warning, and blinks in green during the rmware update.
@@NOTE
tBrightness can be set in the menus of the IPU.
During rmware updating, irrespective of the brightness setting, the lamp blinks in green at the [LOW] setting. This can also be turned off in the
menus of the IPU.
3 Rotating axis for maintenance
Do not touch under normal circumstances.

– 16 –
Chapter 2 Description of Parts — 8K Multi Purpose Camera AK-SHB800
Left side
1
Φ
2
1 < > mark
Indicates the imaging plane inside the camera.
2 Handle tting
Right side
Φ
2
1
1 Handle tting
2 < > mark
Indicates the imaging plane inside the camera.

– 17 –
Chapter 2 Description of Parts — 8K Multi Purpose Camera AK-SHB800
Rear side
1
2
10
7
6
3
45
9
8
AK-SHB800G
1
2
AK-SHB800PS
1 <OPT IN> terminal
Connect to the <OPT OUT> terminal on the IPU using an optical ber cable.
@@NOTE
tThere is a protective cap on the terminal. Remove it before use.
2 <OPT OUT> terminal
Connect to the <OPT IN> terminal on the IPU using an optical ber cable.
@@NOTE
tThere is a protective cap on the terminal. Remove it before use.
3 <DC IN> terminal
This is an input terminal for the external DC power supply. Connects to the external DC power supply. (DC 11 V to 17 V)
4 <OPT> lamp
This indicates the status of the optical signal reception level on the camera.
When the level is strong: Lights green
When the level is weak: Lights yellow
When there is no reception: Off
@@NOTE
tIf the reception level is weak, turn off this unit and the IPU, then clean the optical ber connectors.
If this does not improve reception, turn off the units immediately and contact your dealer.
5 Back tally lamp
Lights up when the tally signal is supplied.
Blinks in red while displaying warning, and blinks in green during the rmware update.
@@NOTE
tBrightness can be set in the menus of the IPU.
During rmware updating, irrespective of the brightness setting, the lamp blinks in green at the [LOW] setting. This can also be turned off in the
menus of the IPU.
6 <HD SDI PROMPT OUT> terminal
This outputs images input to the <HD SDI PROMPT IN> terminal on the IPU.
7 <TRUNK> terminal
This is the terminal for transmitting and receiving IPU trunk data.
8 Cooling fan
This is the fan for cooling the unit.
@@NOTE
tDo not block or disturb the ventilation while operation. Doing so may cause re due to overheating.
tExpected life of this fan is approximately 40,000 hours. (When used at room temperature of 25 ºC) Replace when it reaches the expected life.
tBe sure to contact your dealer for the replacement.
9 Dust-proof lterl
This prevents dust from getting into the unit.
@@NOTE
tReplace the lter after turning off the main unit.
tThe cooling performance drops when the lter is dirty. As a guide, it should be replaced about every 6 months. If you notice clogging or
deterioration during inspections, replace the lter.
tUse the specied lter when replacing it. For details, contact your dealer.
tDo not wash the lter in water.
10 <DC IN> lamp
This will illuminate in green when power is supplied to the camera.

– 18 –
Chapter 2 Description of Parts — 8K Multi Purpose Camera AK-SHB800
Upper side
1
1 Mounting screw holes
This is used when installing in a camera housing, etc.
fMounting hole size
-3/8-16 UNC (x 9)
@@NOTE
tDepth of the screw hole is 8 mm. Use mounting screws 8 mm or shorter.
2 Drop prevention wire mounting screw hole
fMounting hole size
-M4
Bottom side
1
1 Mounting screw holes
This is used when installing in the camera housing, or attaching the pan/tilt head or the tripod.
fMounting hole size
-3/8-16 UNC (x 9)
@@NOTE
tDepth of the screw hole is 8 mm. Use mounting screws 8 mm or shorter.
2 Drop prevention wire mounting screw hole
fMounting hole size
-M4
3 Set feet
fThe set feet may be taken off the main unit to suit the usage situation.
2
2
3

– 19 –
Chapter 2 Description of Parts — Image Processing Unit AK-SHU800
Image Processing Unit AK-SHU800
Front panel
MENU
SELECT
USER 1
USER 2
ROP
FRONT
REAR
G/L ON FANALARM
STATUS
OPTICAL LEVEL
CAM
IPU 12345
TALLY CAMERA No.
POWER
8
7
65432
1
9101112
1 <POWER> switch
This is the unit’s power switch. Set to the ON (l) position when turning the unit on.
2 <TALLY> lamps
The lamp remains lit while tally signals (R, G) are input.
A
B
AR TALLY lamp
BG TALLY lamp
3 <CAMERA No.> display
Indicates the camera number that has been assigned to the unit.
4 <STATUS> indicators
Lights to indicate the unit status.
t<G/L ON> indicator
Lights when the external sync signal is synchronized.
t<FAN> indicator
Lights when the rotation speed of the unit's cooling fan drops below the normal value.
t<ALARM> indicator
Lights when the unit malfunctions.
5 Memory card access lamp
This is lit while the memory card is being accessed.
6 Memory card slot
Insert a memory card (sold separately).
A memory card can be used to set this unit.
7 <ROP FRONT/REAR> selector switch
This switch switches between the <ROP> terminals on the front and rear panels.
You can enable or disable this switch in the menus of the IPU.
8 <ROP> terminal (FRONT)
This connector is for connecting a ROP (sold separately).
9 <OPTICAL LEVEL> indicators
Indicates the reception strength of optical transmission.
t<CAM> indicator
Indicates the reception strength on the camera side.
t<IPU> indicator
Indicates the reception strength on the IPU side.
10 <MENU> button
When you press the <MENU> button, the menu for the <HD SDI OUT 2> terminal is displayed on the screen and the <MENU> button lights.
If you hold down the <MENU> button while the menu is displayed, the menu closes and the <MENU> button turns off.
11 <SELECT> dial
This <SELECT> dial is for menu screen operations.
When the <SELECT> dial is turned to the right the cursor moves down, and when turned to the left it moves up.
Press the <SELECT> dial when selecting menu items.
12 <USER1> and <USER2> buttons
These buttons are used for assigning functions.
Assign functions with settings in the IPU menus.
The following functions are assigned by factory default.
t<USER1> button: INH
t<USER2> button: INH

– 20 –
Chapter 2 Description of Parts — Image Processing Unit AK-SHU800
Rear panel
RESERVE ROPAUX TRUNK COMMUNICATION LAN
IN
OUT
75Ω
AUTO
HD SDI OUT HD SDI PROMPT
12IN
IN
OUT
OUT
SDI OUT
OPT AC IN 〜
SIGNAL GND
REF
1234
AK-SHU800E
AK-SHU800PS
76543
1
2
10 11 12 13 14 15
9
8
1 <HD SDI OUT 1> terminal
This is the main line output terminal dedicated for HD SDI.
<HD SDI OUT 2> terminal
This is the monitor output terminal dedicated for HD SDI.
@@NOTE
tUse a cable that is 5C-FB or above.
2 <SDI OUT> terminal
This is the main line output terminal dedicated for 8K, 4K and HD CROP SDI
@@NOTE
tUse a cable that is 5C-FB or above for 3G SDI.
tUse a BNC cable for 12G for 12G SDI.
3 <OPT OUT> terminal
Connect to the <OPT IN> terminal on the camera using an optical fiber cable.
@@NOTE
tThere is a protective cap on the terminal. Remove it before use.
4 <OPT IN> terminal
Connect to the <OPT OUT> terminal on the camera using an optical fiber cable.
@@NOTE
tThere is a protective cap on the terminal. Remove it before use.
5 <HD SDI PROMIT IN> terminal
These connectors are for inputting HD SDI prompter signals.
Input images can be viewed through the <HD SDI PROMPT OUT> terminal on the camera.
<HD SDI PROMIT OUT> terminal
This is active through output from the <HD SDI PROMPT IN> terminal.
6 <REF IN> terminal
This is the reference signal input connector when applying external synchronization.
BB (black burst) signals or tri-level signals can be input, and are automatically recognized.
<REF OUT> terminal
This is the loop through output from the <REF IN> terminal.
@@NOTE
tWhen a cable is not connected to the <REF OUT> terminal, it automatically becomes a 75 Ω terminal. The 75 Ω terminal is released when a cable is connected.
tWhen a cable is connected to the <REF OUT> terminal, do not leave the connector at other end of the cable open.
7 Cooling fan
This is the unit's cooling fan.
tDo not block fans or ventilation during operation. Heat can build up internally and this may cause a fire.
tExpected life of these fans is approximately 40,000 hours. (When used at a room temperature of 25°C) Replace when they reach the expected life.
tBe sure to contact your dealer for the replacements.
8 AC power socket
This socket is for inputting AC power.
Connect the supplied power cable, and use a 3-prong outlet and ground the unit properly.
9 <SIGNAL GND> terminal
Connect this to the system ground.
10 <RESERVE> terminal
Not used.
11 <ROP> terminal
This terminal is for connecting a ROP (sold separately).
12 <AUX> terminal
This connector is used for controlling tally output.
13 <TRUNK> terminal
It is possible to transmit and receive camera trunk data.
14 <COMMUNICATION> terminal
This connector is for connecting the tally signal with an external system.
15 <LAN> terminal
This connector is for connecting an ROP and PC for ROI control with an IP connection.
Use a switching hub and connect using a 1000BASE-T/100BASE-TX straight cable.
