Operating Instructions
(Household use) Rechargeable Shaver
Model No. ES‑LS6A
English��������������������������������������������� 3
Русский ����������������������������������������� 21
Українська ������������������������������������ 41
Қазақша����������������������������������������� 61

2

3
English
Thank you for purchasing this Panasonic product.
Before operating this unit, please read these instructions completely and save them for future use�
Operating Instructions
(Household use) Rechargeable Shaver
Model No. ES‑LS6A
Safety precautions..................... 4
Important information �������������������������8
Parts identication ����������������������������10
Preparation�����������������������������������������10
How to use ����������������������������������������� 11
Cleaning the shaver ��������������������������14
Replacing the system outer foil �������15
FAQ �����������������������������������������������������16
Troubleshooting ��������������������������������16
Battery life������������������������������������������19
Removing the built-in rechargeable
battery�������������������������������������������������19
Specications ������������������������������������20
Contents

4
English
Safety precautions
Make sure to follow these instructions.
To prevent accidents, injuries or damage to property,
please follow the instructions below.
■The following chart indicates the degree of
damage caused by improper operation�
DANGER
Indicates a potential hazard that
will result in serious injury or death.
WARNING
Indicates a potential hazard that
could result in serious injury or
death.
CAUTION
Indicates a potential hazard that
could result in minor injury or
property damage.
■ The symbols are classied and explained as
follows�
This symbol indicates prohibition.
This symbol indicates requirement that must be
followed.
WARNING
►This product
This product has a built-in rechargeable
battery. Do not throw into re, apply heat, or
charge, use, or leave in a high temperature
environment�
‑ Doing so may cause overheating, ignition, or
explosion.
Do not modify or repair�
‑ Doing so may cause re, electric shock, or
injury.
Contact an authorized service centre for repair
(replacement of battery etc).
Never disassemble except when disposing of
the product�
‑
Doing so may cause re, electric shock, or injury.

5
English
WARNING
►In case of an abnormality or malfunction
Immediately stop using and remove the AC
adaptor if there is an abnormality or
malfunction�
‑ Failure to do so may cause re, electric shock,
or injury.
<Abnormality or malfunction cases>
•The main unit, AC adaptor or cord is
deformed or abnormally hot�
•The main unit, adaptor or cord smells of
burning�
•There is an abnormal sound during use or
charging of the main unit�
‑ Immediately request inspection or repair at an
authorized service centre.
►Power supply
Do not connect or disconnect the adaptor to
a household outlet with a wet hand�
‑ Doing so may cause electric shock or injury.
Do not immerse the AC adaptor in water or
wash with water�
Do not place the AC adaptor over or near
water lled sink or bathtub.
Never use the appliance if the AC adaptor is
damaged or if the power plug ts loosely in a
household outlet�
Do not damage the cord or the power plug�
•Do not deface, modify, forcefully bend or
pull the cord or the power plug� Also, do
not place anything heavy on, twist or pinch
the cord�
‑ Doing so may cause electric shock or re due
to a short circuit.
Do not use in a way that would exceed the
rating of the household outlet or the wiring�
‑ Exceeding the rating by connecting too many
plugs to one household outlet may cause re
due to overheating.
Do not use anything other than the supplied
AC adaptor for any purpose�
Also, do not use any other product with the
supplied AC adaptor� (See page 10�)
‑ Doing so may cause burn or re due to a short
circuit.
Fully insert the power plug�
‑
Failure to do so may cause re or electric shock.
Disconnect the AC adaptor when cleaning the
main body with water�
‑
Failure to do so may cause electric shock or injury.

6
English
WARNING
Regularly clean the power plug and the
appliance plug to prevent dust from
accumulating�
‑ Failure to do so may cause re due to insulation
failure caused by humidity.
►Preventing accidents
Do not place within reach of children or
infants� Do not let them use it�
‑ Putting parts or accessories in the mouth may
cause an accident or injury.
If oil is consumed accidentally, do not induce
vomiting, drink a large amount of water and
contact a physician�
If oil comes into contact with eyes, wash
immediately and thoroughly with running
water and contact a physician�
‑ Failure to follow these instructions may result in
physical problems.
►Note the following precautions
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety�
Children should be supervised to ensure that
they do not play with the appliance�
‑ Failure to do so may cause an accident or
injury.
The supply cord cannot be replaced� If the
cord is damaged, the AC adaptor should be
scrapped�
‑ Failure to do so may cause an accident or
injury.
CAUTION
►Protecting the skin
Do not use excessive pressure to apply the
system outer foil to your lip or other part of
your face�
Do not apply the system outer foil directly to
blemishes or injured skin.
‑ Doing so may cause injury to skin.

7
English
CAUTION
Do not forcefully press the system outer foil�
Also, do not touch the system outer foil with
ngers or nails when in use.
Do not use this product for hair on head or
any other part of the body�
‑ Doing so may cause injury to skin or reduce the
life of the system outer foil.
Check the system outer foil for cracks or
deformations before use�
‑ Failure to do so may cause injury to the skin.
►Note the following precautions
Do not allow metal objects or trash to adhere
to the power plug or the appliance plug�
‑ Doing so may cause electric shock or re due
to a short circuit.
Do not share your shaver with your family or
other people�
‑ Doing so may result in infection or inammation.
Disconnect the adaptor from the household
outlet when not charging�
‑ Failure to do so may cause electric shock or re
due to electrical leakage resulting from
insulation deterioration.
Handling of the removed battery when
disposing
DANGER
•The rechargeable battery is exclusively for
use with this appliance� Do not use the
battery with other products�
•Do not charge the battery after it has been
removed from the product�
•Do not throw into re or apply heat.
•Do not hit, disassemble, modify, or puncture
with a nail�
•Do not let the positive and negative
terminals of the battery get in contact with
each other through metallic objects�
•Do not carry or store the battery together
with metallic jewellery such as necklaces
and hairpins�
•Do not use or leave the battery where it will
be exposed to high temperatures, such as
under direct sunlight or near other sources
of heat�
•Never peel off the tube�
‑ Doing so may cause overheating, ignition, or
explosion.

8
English
WARNING
After removing the rechargeable battery, do
not keep it within reach of children and infants.
‑ The battery will harm the body if accidentally
swallowed.
If this happens, consult a physician immediately.
If the battery uid leaks out and comes in
contact with the eyes, do not rub the eyes,
and thoroughly rinse with clean water, such
as tap water�
‑ Failure to do so may cause eye injury.
Consult a physician immediately.
CAUTION
If the battery uid leaks out and comes in
contact with the skin or clothes, rinse off with
clean water, such as tap water�
‑ Failure to do so may cause inammation.
Important information
• This WET/DRY shaver can be used for wet shaving
using shaving lather or for dry shaving. You can use
this watertight shaver in the shower and clean with
water. The following symbol means suitable for use in
a bath or shower.
• Treat yourself to wet lather shaves for at least three
weeks and notice the difference. Your Panasonic
WET/DRY shaver requires a little time to get used to
because your skin and beard need about a month to
adjust to any new shaving method.
• If you clean the shaver with water, do not use salt
water or hot water. Do not soak the shaver in water for
a long period of time.
• The following symbol indicates that a specic
detachable power supply unit is required for
connecting the electrical appliance to the supply
mains. The type reference of power supply unit is
marked near the symbol.
• Charge the appliance correctly according to these
Operating Instructions. (See page 10 “Charging the
shaver”.)
• This appliance contains battery that is only
replaceable by skilled persons. Please contact an
authorized service centre for the details of repair.

9
English
Note the following precautions
►When using
• Do not bring the system outer foil into contact with
hard objects.
Doing so may damage the system outer foil as it is
very thin and deforms easily.
• Do not drop or hit against other objects.
Doing so may cause injury.
►When storing
• Store the shaver in a place with low humidity after
use.
Failure to do so may cause malfunction due to
condensation or rust.
• Be sure to place the protective cap on the shaver
when carrying around or storing.
Failure to do so may cause injury to skin or reduce the
life of the system outer foil.
►When cleaning
• Do not dry the main unit with a dryer or a fan heater.
Doing so may cause malfunction or deformation of the
parts.
• Do not leave the shaver exposed to direct sunlight
with the foil frame detached.
Doing so may deteriorate the waterproof rubber and
degrade waterproof function, which may cause to
malfunction.

10
English
Parts identication









a
b
c




Back






AMain body
1Protective cap
2System outer foil
3Foil frame
4Smooth rollers
• They help to glide
over the skin more
easily.
5Foil frame release
buttons
6Power switch
7Lamp display
a. Battery capacity
lamp
b. Charge status
lamp ( )
c. Switch lock lamp
()
Appliance socket
Outer foil section
System outer foil
release buttons
Trimmer
Trimmer handle
BAC adaptor (RE7-87)
Adaptor
Power plug
Cord
Appliance plug
Accessories
CTravel case
DCleaning brush
EOil
Preparation
Charging the shaver
• Turn the shaver off.
• Wipe off any water droplets on the appliance socket.
1 Insert the appliance plug
into the shaver�
2 Plug the adaptor into a
household outlet�
• Check that the charge status
lamp ( ) is glowing.
• Charging is completed after
approx. 1 hour.
3
Disconnect the adaptor
after charging is completed�
1
2
Note
You cannot operate the shaver while charging.

11
English
Quick charge
Even though the battery runs out, you can shave
once after 3‑minute charge.
(This will differ depending on usage.)
While charging After charging is
completed
glows.
The battery capacity
lamp will increase as
charging progresses.
All the battery capacity
lamp and will glow and
then turn off after
5 seconds.
Notes
• When charging the shaver for the rst time or when it
has not been in use for more than 6 months, the
charging time may change or the charge status lamp
() may not glow for a few minutes. It will eventually
glow if kept connected.
• Recommended ambient temperature for charging is
10 °C – 35 °C. It may take longer to charge, or the
charge status lamp ( ) will blink quickly and the
battery may fail to charge properly in extremely high
or low temperatures.
• The shaver can be used for approximately 2 weeks
with a full charge.
(Based on one 3‑minute dry‑shave usage per day in
an ambient temperature range of 20 °C – 30 °C.)
The number of usable days varies depending on the
following conditions.
‑ Beard thickness
‑ Pressure applied to the skin
‑
Usage frequency of the sonic vibration cleaning mode
• If there is noise from the radio or other sources while
using or charging the appliance, move to a different
location to use the appliance.
How to use
Shaving beard
1 Press and shave�
• The “shaving sensor”, which
automatically adjusts the power
depending on the beard thickness,
will operate.
It will shave with high power on areas
where the beard is heavy, and reduce
the power on areas where the beard
is thin, to reduce burden on the skin.

12
English
Tips for better shaving
Apply the whole system outer foil
perpendicularly against the skin
and shave by slowly gliding the
shaver over the face against the
grain of the beard.
• The beard under the chin and
around the throat can be shaved
better by stretching the skin so
the beard will stand.
• To prevent damaging the system
outer foil, do not shave with only
a part of the system outer foil.
2 Press when nished.
While using After use
The remaining battery
capacity are shown and
then turn off after
5 seconds.
• Approximate amount of
battery capacity is
displayed.
The remaining battery
capacity blink and then
turn off after 5 seconds.
When the battery capacity is low
The lowest battery capacity lamp glows when
operating the shaver.
The appliance beeps twice after switched off.
• You can shave 2 to 3 times. (This will differ
depending on usage.)
Notes
• The appliance may not operate in an ambient
temperature lower than approximately 5 °C.
• The shaving sensor may not respond depending on
the type and quantity of the shaving gel. This is not
abnormal.
• Depending on the beard thickness or the amount of
beard trimmings in the shaver head, the shaving
sensor may not react and the driving sound may not
change. This is not abnormal.

13
English
• To prevent erroneous operation, place your ngers on
the nger rest while using the shaver.
• The sonic vibration cleaning mode is activated when
the power switch is pressed for more than 2 seconds
while the shaver is not operating. (See page 14.)
You cannot shave in this mode.
Operation and display of the switch lock
►Locking the power switch
1.Press once
and then
release.
• The shaver
starts
operating.
2.Press for
more than
2 seconds until
the switch lock
lamp ( ) turns
on.
• The shaver will
stop operating.
3.
Release .
• The switch
lock lamp
() will
light up for
5 seconds
and turn
off.
►Unlocking the power switch
1.Press for more than
2 seconds until the
switch lock lamp ( )
turns off.
2.Once the shaver starts
operating, release .
• The switch lock lamp
() will turn off.
• The power switch is locked when the switch lock lamp
() blinks for 5 seconds and the shaver does not
operate even though the power switch is pressed.
►Using the trimmer
1.Slide the trimmer handle up to
the “ ” position so that the
trimmer stands upright.
2.Press and use.
Press and hold the top knob ( a )
and slide the trimmer handle
down to lower the trimmer.

Tips for better usage
Apply the trimmer edge perpendicular to skin gently
and move downward slowly.
Trimming sideburns Pre‑shave of long beards

14
English
►Switching the shaver head
You can change the pivot action.
“”
The shaver head is moved to
prevent missed spots.
“ ”
You can lock the shaver head.
Cleaning the shaver
We recommend cleaning the shaver after each use.
Cleaning with water
• Turn the shaver off and disconnect the AC adaptor.
1 Apply some hand soap and
some water to the system
outer foil�
2 Press for more than
2 seconds to activate the
sonic vibration cleaning
mode�
• Splashing of foam is
suppressed.
• The lamps blink alternately.
• After about 20 seconds, it will be automatically
turned off, or you can turn it off by pressing the
power switch.
3 Remove the outer foil
section and clean with
running water�
• See page 15 for removing
the outer foil section.
• Splashing is reduced by rinsing the shaver in sonic
vibration cleaning mode.
• After rinsing with water, shake the shaver up and
down for a few times to remove excess moisture and
then wipe off any drops of water with a dry cloth.
4 Dry the outer foil
section, the shaver, and
the trimmer completely�
• Allow the shaver to dry in
the shade, avoid direct
sunlight.
5 Lubricate the shaver�
It will keep the movement of the
blades smooth and maintain a
comfort shave.
1.Apply one drop of oil to each of
the system outer foils.
2.Raise the trimmer and apply a drop of oil.
3.Switch the shaver on, and run it for approximately
ve seconds.

15
English
4.Switch off the shaver, and wipe off any excess oil
from the system outer foil with a soft cloth.
Notes
• Do not use any kitchen or bathroom detergents other
than hand soap.
Doing so may cause malfunction.
• Be careful not to hit the main body on the sink or any
other object while draining the water. Failure to do so
may cause malfunction.
• Do not wipe with thinners, benzine, alcohol etc.
Doing so may cause malfunction, cracking or
discoloration of the parts.
Wipe with diluted soapy water.
Cleaning with the brush
Remove the outer foil section.
(See this page.)
Clean the system outer foil in the areas
indicated by the circles every time you
use the shaver. Otherwise, abnormal
sound may be generated.
►Cleaning with the long brush
Clean the foil frame, system
outer foil, the main body
and the trimmer using the
long brush.
Replacing the system outer foil
system outer foil once every 18 months
►Removing the outer foil section
Press the foil frame release buttons and
lift the outer foil section upwards.
►Attaching the outer foil section
After turning the foil frame mark ( ) to the
front, securely attach the outer foil section
to the shaver until it clicks.
►Replacing the system outer foil
1.Press the system outer foil release
buttons and pull down the system
outer foil.
• Do not press the system outer foil
release buttons with excessive
force.
Doing so may bend the system outer foil, preventing
complete attachment to the foil frame.
2.
Align the foil frame mark ( ) and the system outer foil
mark ( ) and securely attach together until it clicks.
Note
Do not throw away the foil frame.

16
English
►Replacement parts
Replacement parts are available at your dealer or
Service Centre.
Replacement parts
for ES‑LS6A System outer foil WES9600
FAQ
Question Answer
Does this product
require inner blades?
Outer foils and inner blades
are integrated into the
system outer foil.
Will the battery
deteriorate if not used
for an extended
period of time?
The battery will deteriorate if
not used for over 6 months,
so make sure to perform a
full charge at least once
every 6 months.
Can I charge the
shaver after every
use?
The battery used is a
lithium‑ion, so charging after
every use will have no effect
on battery life.
Why should the
adaptor be
disconnected after
charge?
Charging the battery for more
than 1 hour will not affect
battery performance, but
disconnect the adaptor for
safety and to save energy.
What is the
constituent of the
dedicated oil?
Constituent of the oil is
liquid parafn.
Question Answer
Why does the
appliance beep twice
after switched off?
The sound indicates that the
battery capacity is running
low. Please charge the
appliance.
Troubleshooting
Perform the following actions.
If the problems still cannot be solved, contact the
store where you purchased the unit or a service
centre authorized by Panasonic for repair.
Problem Action
The power switch
does not turn ON.
Unlock the switch lock. (See
page 13.)

17
English
Problem Action
The shaving sensor
does not respond.
Depending on the beard
thickness or the amount of
beard trimmings in the
shaver head, the shaving
sensor may not react and the
driving sound may not
change. This is not abnormal.
The shaving sensor may not
respond depending on the
type and quantity of the
shaving gel. This is not
abnormal.
The shaving sensor may not
respond when the remaining
battery capacity is low. If
this happens, recharge the
shaver.
Apply oil. (See page 14.)
The shaving sensor may not
respond when there is not
enough oil on the system
outer foil.
Problem Action
The shaving sensor
responds even though
the shaver is not in
contact with the skin.
Clean the beard trimmings
from the shaver.
Clean the system outer foil
with the brush. (See
page 15.)
When the shaver is
extremely dirty, remove the
foil frame and wash with
water.
(See page 14.)
Replace the system outer foil.
Expected life of system
outer foil:
Approximately 18 months

18
English
Problem Action
Operating time is
short even after a full
charge.
Although the shaver can be
used for about 2 weeks after
a full charge (assuming
dry‑shave usages for 3
minutes per day), the usable
number of days might be
lower depending on how the
shaver is used (for example,
when used for wet shaving).
Apply oil.
Clean the shaver.
When the number of
operations per charge starts
to decrease, the battery is
nearing the end of its life.
Shaver does not
operate even after
charging.
Use the appliance in an
ambient temperature
approximately 5 °C or higher.
The battery has reached the
end of its life.
The shaver will not operate
with the AC adaptor
connected. Please use the
shaver after it has been
sufciently charged and the
AC adaptor disconnected.
Problem Action
The driving sound
changes while
shaving.
The shaving sensor is
operating. The sound
changes depending on the
beard thickness.
Makes a loud sound.
Apply oil.
The blades will not move
smoothly when there is no
oil on the system outer foil,
requiring more power.
The shaver makes a high‑
pitched sound due to the
linear motor drive. This does
not indicate a problem.
Conrm that the system outer
foil is properly attached.
Clean the system outer foil
with the brush. (See
page 15.)
Wash the system outer foil
with water. (See page 14.)
The odor is getting
stronger. Clean the shaver.
System outer foil gets
hot.
Apply oil.
Replace the system outer
foil if it is damaged or
deformed.
(See page 15.)

19
English
Problem Action
You do not get as
close a shave as
before.
Clean the shaver.
Apply oil.
Replace the system outer foil.
Expected life of system
outer foil:
Approximately 18 months
Battery life
The life of the battery is 3 years. The battery in this shaver
is not intended to be replaced by consumers. Have the
battery replaced by an authorized service centre.
Removing the built-in rechargeable
battery
Remove the built-in rechargeable battery before
disposing of the shaver�
The battery is to be disposed of safely.
Please make sure that the battery is disposed of at an
ofcially designated location if there is one.
This gure must only be used when disposing of the
shaver, and must not be used to repair it. If you
dismantle the shaver yourself, it will no longer be
waterproof, which may cause it to malfunction.
• Remove the shaver from the AC adaptor.
• Press the power switch to turn on the power and then
keep the power on until the battery is completely
discharged.
• Perform steps 1to 5and lift the battery, and then
remove it.
• Take care not to short circuit the positive and negative
terminals of the removed battery, and insulate the
terminals by applying tape to them.





For environmental protection and recycling of
materials
This shaver contains a Lithium‑ion battery.
Please make sure that the battery is disposed of at an
ofcially assigned location, if there is one in your country.

20
English
Specications
Power source
See the name plate on the AC
adaptor.
(Automatic voltage conversion)
Motor voltage 3.6 V
Charging time Approx. 1 hour
This product is intended for household use only.
Notes
1.Install on a hard, at surface, except for handheld
parts or xed parts.
2.Store in a dry place indoors.
3.Transport without dropping, excessive vibration or
hitting against other objects.
4.Dispose of according to national and/or local
legislation.
Terms and conditions of sale are not set up by the
manufacturer and must comply with national and/or
local legislation of the country of sale of goods.
